WPIM-DI Local Management Guide 1-1
CHAPTER 1
INTRODUCTION
Welcome to the Cabletron Systems WPIM-DI Local Management
Guide . The WPIM-DI resides in and provides connectivity/functionality
to Cabletron Systems Wide Area Network (WAN) devices such as the
CSX400.
Before using this manual you must perform the following:
• Install the WPIM-DI in aWideArea Network host device. Refer to the
appropriate manual (i.e., the CSX400 and CSX400-DC User’s Guide )
for installation and troubleshooting procedures.
• Set up and access Local Management. Refer to the appropriate
standalone device or module User’s Guide for instructions on setting
up and accessing Local Management.
1.1 USINGTHIS MANUAL
Read through this guide completely to become familiar with the content
and to gain an understanding of the features and capabilities of the
WPIM-DI.You should have a general working knowledge of the
following data communications networks and their physical layer
components before using the WPIM-DI.
•WAN
• Ethernet and IEEE 802.3
The following briefly summarizes each chapter of the WPIM-DI manual.
Chapter 1, Introduction , outlines the contents of this guide, describes
WPIM-DI features, provides a list of related manuals, and concludes with
instructions for obtaining help from Cabletron Systems Technical
Support.
Chapter 2, Local Management , describes how to use Local Management
to set up the WPIM-DI.

Chapter 1: Introduction
1-2 WPIM-DI Local Management Guide
Appendix A, WPIM-DI Specifications , provides specifications for the
WPIM-DI and also gives Cabletron Systems part numbers and connector
information for WPIM-DI interface cables.
Appendix B, Typical Configurations , presents common configurations
for the WPIM-DI.
Appendix C, FCC Part 68 - User’s Information , explains the FCC rules
governing the WPIM-DI.
Appendix D, WAN Terms and Acronyms , provides a brief glossary of
the terms used in this book.
1.2 WPIM-DI FEATURES
The WPIM-DI extends the functionality of a Wide Area Network module
to allow remote connectivity using WAN services such as T-1, or
Fractional T-1.
The WPIM-DI provides a T-1 interface that includes a built-in Channel
Service Unit/Digital Service Unit (CSU/DSU) for direct connection to a
T-1 line. This WPIM supports both Full T-1 or Fractional T-1 using 56 or
64 Kbps timeslots.
The WPIM-DI also provides a Drop and Insert (DI) interface which
allows for a second WAN module (e.g., WPIM-T1) to utilize any
timeslots that are not used for host data. The WPIM-DI is capable of T1
multiframe alignment.
WAN Protocols
The module in which the WPIM-DI is installed supports the following
WAN protocols (refer to the Release Notes included with the host MIM or
standalone device for a list of current protocols):
• Point-to-Point Protocol (LCP) as defined by RFC 1661
• Point-to-Point Protocol (BNCP) as defined by RFC 1638
• Point-to-Point Protocol LAN Extender (PPP/LEX)
• Frame Relay as defined by RFC 1490
MIB Support
Refer to the Release Notes included with the host MIM or standalone
device for a list of all MIBs supported by the WPIM-DI. For information
about how to extract and compile individual MIBs, contact Cabletron
Systems Technical Support (refer to Section 1.5, Getting Help ).

Document Conventions
WPIM-DI Local Management Guide 1-3
1.3 DOCUMENT CONVENTIONS
The following conventions are used throughout this document:
Navigate through the WPIM Local Management screens by using the
following keyboard commands:
• SPACE bar to toggle between selections in a field.
• ENTER (RETURN) to implement a selection.
• Arrow keys to move up, down or across within the screen.
1.4 RELATED MANUALS
Refer to the manual included with the host Wide Area Network device
(e.g., the CSX400 and CSX400-DC User’s Guide ) to supplement the
procedures and other technical data provided in this manual. Refer to the
standalone device or module User’s Guides and/or Local Management
Guides for Local Management setup information. This manual references
procedures in these manuals, where appropriate, but does not repeat them.
NOTE
Note symbol. Calls the reader’s attention to any item of
information that may be of special importance.
TIP
Tip symbol. Conveys helpful hints concerning procedures or
actions.
!
CAUTION
Caution symbol. Contains information essential to avoid
damage to the equipment.

Chapter 1: Introduction
1-4 WPIM-DI Local Management Guide
1.5 GETTING HELP
For additional support related to this device or document, contact the
Cabletron Systems Global Call Center:
Before calling the Cabletron Systems Global Call Center, have the
following information ready:
• Your Cabletron Systems service contract number
• A description of the failure
• A description of any action(s) already taken to resolve the problem
(e.g., changing mode switches, rebooting the unit, etc.)
• The serial and revision numbers of all involved Cabletron Systems
products in the network
• A description of your network environment (layout, cable type, etc.)
• Network load and frame size at the time of trouble (if known)
• The device history (i.e., have you returned the device before, is this a
recurring problem, etc.)
• Any previous Return Material Authorization (RMA) numbers
Phone [phone]
Internet mail suppor[email protected]
FTP ctron.com (134.141.197.25)
Login
anonymous
Password your email address
BBS [phone]
Modem setting 8N1: 8 data bits, No parity, 1 stop bit
For additional information about Cabletron Systems or its products, visit the
World Wide Web site: http://www.cabletron.com/
For technical support, select Service and Support .
To send comments or suggestions concerning this document, contact the
Cabletron SystemsTechnical Writing Department via the following
email address: [email protected]
Make sure to include the document Part Number in the email message.

WPIM-DI Local Management Guide 2-1
CHAPTER 2
LOCAL MANAGEMENT
This chapter explains how to configure the WPIM-DI through Local
Management. The WAN Physical Configuration screen and the WAN
Interface Configuration screen appear as Local Management menu
selections in a host device, when the WPIM-DI is installed into a host
device. The WPIM-DI can be installed directly into a CSX400. Refer to
the appropriate host device technical documentation for instructions about
how to set up and access Local Management.
This chapter contains the following sections:
• The WAN Physical Configuration Screen, Section 2.1
• The WAN Interface Configuration Screen, Section 2.2
• WPIM-DI Configuration, Section 2.3
Read Section 2.1 and Section 2.2 to gain an understanding of the
WPIM-DI Local Management screens. Section 2.3 provides instructions
for setting up the WPIM-DI for full or fractional T-1 in a PPP (LEX or
BNCP) environment, or for configuring the WPIM-DI for Frame Relay.
Navigate through the WPIM Local Management screens by
using the following keyboard commands:
SPACE bar to toggle between selections in a field.
ENTER (RETURN) to implement a selection.
Arrow keys to move up, down or across within the screen.
TIP

Chapter 2: Local Management
2-2 WPIM-DI Local Management Guide
2.1 THEWAN PHYSICAL CONFIGURATION SCREEN
To access the WAN Physical Configuration screen from the Setup Menu
screen, use the arrow keys to highlight the WAN Setup option, then press
ENTER. The screen shown in Figure 2-1 appears.
Figure 2-1 WAN Physical Configuration Screen
2.1.1 WAN Physical Configuration Screen Fields
The following sections describe the WAN Physical Configuration screen
fields and the instructions for setting them. The WAN Physical
Configuration screen allows the user to configure the WPIM or “Physical
Interface.”
Cabletron Systems offers a variety ofWPIMs. The Physical Configuration
screen example (Figure 2-1) shows what the screen would look like with
the WPIM-DI and the WPIM-SY installed. Select the WPIM you wish to
configure by using the arrow keys to highlight the WPIM command field
at the bottom of the screen. Use the SPACE bar to select the appropriate
WPIM, then press ENTER. The WAN Physical Configuration screen
automatically displays unique configuration fields for each WPIM as
shown in Figure 2-1.
1482_01
SAVE WAN INT CONFIG RETURN
WPIM 1
TYPE: WPIM-DI
BRIM #: 1
MODE: PRIMARY
ACTIVE: YES
IFACES: 003-026
WPIM 2
TYPE: WPIM-SYNC
BRIM #: 2
MODE: PRIMARY
ACTIVE: NO
IFACES: 027
WAN PHYSICAL CONFIGURATION
NI/DI Timeslot View: [ Active]
NI/DI Line Coding: [ B8ZS]
NI/DI Frame Type: [ ESF]
NI/DI Tx Clock Source: [Loop Timing]
NI/DI Line Buildout: [ 0 db]
NI/DI Loopback [None]
DI Enabled [Yes]
WPIM 1 Timeslot Configuration
000 000 000 000 000000 000 00001-08
09-16
17-24
WPIM 1 LINE CONFIGURATION
000 000 000 000 000000 000 000
000 000 000 000 000000 000 000
[WPIM 1]
CSX400 Local Management Flash Image Version: xx.xx.xx

TheWAN Physical Configuration Screen
WPIM-DI Local Management Guide 2-3
The WAN Physical Configuration screen displays the following
information for each WPIM:
WPIM 1-4
Displays configuration information for as many as four WPIMs.
TYPE
Displays the WPIM type.
BRIM #
Displays the BRIM slot in which the WPIM resides.
MODE
Displays the WPIM mode. This field toggles between Primary and
Secondary. In a device such as the BRIM-W6 where two WPIMs are
utilized but only one can be active at a given time, the second WPIM
installed or recognized defaults to Secondary.
ACTIVE
Displays the status of the WPIM. This field displaysYES for active
WPIMs and NO for inactive WPIMs.
IFACES
Displays the interfaces available to each WPIM.
2.1.2 WPIM-DI Line Configuration Fields
The line configuration fields displayed on the Physical Configuration
screen shown in Figure 2-1 vary depending on the type of WPIM. The
examples in this Local Management Guide cover the fields available to
the WPIM-DI. Each Cabletron Systems WPIM has a Local Management
Guide that provides specific line configuration guidelines and examples.

Chapter 2: Local Management
2-4 WPIM-DI Local Management Guide
NI/DITimeslot View
Displays the status of the Timeslot Configuration table. This field toggles
between Active and New. The Active setting displays current Timeslot
Configuration table settings. The New setting allows you to change
Timeslot Configuration table settings. The default setting is Active . The
default setting for the Timeslot Configuration table is all Timeslots not
assigned ( 000 ).
NI/DI Line Coding
Displays the line coding for the physical T-1 line. This field toggles
between B8ZS and AMI. The default setting is B8ZS .
NI/DI FrameType
Displays the T-1 Frame type. This field toggles between ESF and D4. The
default setting is ESF .
NI/DITx Clock Source
Displays the T-1 Transmit Clock Source. This field toggles between Loop
Timing (Extracted Line Data) and Local Timing (Internal Clock). The
default setting is Loop Timing . If the DI Enabled field is set to
diDataEnable, Local Timing cannot be selected as a choice.
NI/DI Line Buildout
Displays the line coding for the physical T-1 line. Set this field to 0 dB
unless the service provider recommends another setting. The default
setting is 0 dB . This field steps between the following levels:
• 0 db
• -7.5 db
• -15 db
• -22.5 db
NOTE
The service provider (i.e., AT&T, Sprint, MCI, NYNEX, etc.)
determines the settings for the following fields.Consult the
service provider for the correct settings.

TheWAN Physical Configuration Screen
WPIM-DI Local Management Guide 2-5
NI/DI Loopback
Displays the loopback for the WPIM-DI. Loopback is a testing procedure
that segments the line and allows the user to isolate faults. This field
toggles between None, Line-Loop, and Payload-Loop. In Line-Loop the
entire T1 is looped back. In Payload-Loop only the 24 timeslots are
looped back. The NI/DI Tx Clock Source must be in Loop Timing mode
to use this option. The default setting is None .
DI Enabled
Displays the status of the Drop-and-Insert function of the WPIM-DI. This
field steps between On, Off, and diDataEnable. Choosing On allows
another device (e.g., WPIM-T1) that is connected to the DI interface of
the WPIM-DI to use any timeslots that the WPIM-DI is not using (Drop
and Insert is enabled between the two ports). The data from the host
device passes through the NI port. Choosing Off allows the Network
Interface to be used as a standard T-1 port. Choosing diDataEnable
enables Drop and Insert, and data from the host device will pass through
the DI port. The default setting is On.
2.1.2.1 WPIM-DITimeslot ConfigurationTable
The WPIM Timeslot Configuration table allows you to configure the way
in which the WAN module uses the T-1 line. The configuration table
consists of 24 Timeslots.You must assign each Timeslot an Interface
number (for example, 002 for an active Interface number or 000 if the
Timeslot is not used). When you lease an entire T-1 line, you can use all
24 Timeslots (the full T-1 bandwidth). If you lease only a fraction of the
T-1, the service provider tells you which Timeslots to use.
The WPIM-DI supports Time Division Multiplexing (TDM) allowing
channelization of circuits (Timeslots) within the public network.You can
use Timeslots any way you choose. When using the WPIM-DI, you have
the option of implementing all the available leased Timeslots with the
WPIM-DI, or you may map any of the available Timeslots to another
WAN module through the DI interface.
NOTE When the diDataEnable option is selected in the DI Enabled
field, data from the host device passes through the DI port and
not the NI port on the WPIM-DI.

Chapter 2: Local Management
2-6 WPIM-DI Local Management Guide
For example, if your CSX400 has access to a full T-1 (24 Timeslots), and
you want to communicate with two other sites through the WPIM-DI,
your configuration might look like the sample configuration shown in
Figure 2-2.
Figure 2-2 Sample Network Configuration #1
Figure 2-3 shows a sample Timeslot configuration for the three sites
shown in Figure 2-2. Of the 24 Timeslots, Site #1 uses 16 to communicate
with Site #2 and the remaining 8 to communicate with Site #3. This
configuration varies tremendously depending on how the service provider
maps out the T-1 Timeslots.Your service provider will tell you which
Timeslots are active.
Figure 2-3 SampleTimeslot Configuration #1
SITE #1
SITE #2
Telco Cloud
24 Timeslots
16 Timeslots
SITE #3
8 Timeslots
1482_02
SITE #2
01-08
09-16
17-24
SITE #3
01-08
09-16
17-24
SITE #1
01-08
09-16
17-24
1482_03
005
005
000
005
005
000
005
005
000
005
005
000
005
005
000
005
005
000
005
005
000
005
005
000
006
000
000
006
000
000
006
000
000
006
000
000
006
000
000
006
000
000
006
000
000
006
000
000
005
005
006
005
005
006
005
005
006
005
005
006
005
005
006
005
005
006
005
005
006
005
005
006

TheWAN Physical Configuration Screen
WPIM-DI Local Management Guide 2-7
Site #1 is using the full T-1, so all the Timeslots must have an Interface
assignment. Site #2 and Site #3 only use a fraction of the T-1, but the total
quantity of Timeslots must match those of Site #1. Unused Timeslots
receive an Interface number of 000.
Mapping UnusedTimeslots
In the previous example, the WPIM-DI made use of all 24 timeslots.
None of the timeslots were mapped to another device and the Drop and
Insert function was not used. If, however, you wanted another WAN
device (e.g., a WPIM-T1) at the same site as the WPIM-DI to be able to
communicate with Site #3, your configuration might look like the sample
configuration shown in Figure 2-4.
Figure 2-4 Sample Network Configuration #2
Figure 2-5 shows a sample timeslot configuration for the network shown
in Figure 2-4. Of the 24 Timeslots, the WPIM-DI at Site #1A uses 16 to
communicate with Site #2 and the remaining 8 are mapped to the
WPIM-T1 at Site #1B. The WPIM-T1 at Site #1B uses these to
communicate with Site #3. This configuration varies tremendously
depending on how the service provider maps out the T-1 Timeslots.Your
service provider will tell you which Timeslots are active.
NOTE The Interface numbers of Site #1, Site #2 and Site #3 do not
have to match.Only the quantity ofTimeslots must match (the
service provider assigns the Timeslots).
SITE #1A
SITE #2
Telco Cloud
24 Timeslots
16 Timeslots
SITE #3
8 Timeslots
148202
WPIM-DI
SITE #1B
WPIM-T1
(8 Not Used)
8 Timeslots

Chapter 2: Local Management
2-8 WPIM-DI Local Management Guide
Figure 2-5 SampleTimeslot Configuration #2
Site #1 is using the full T-1, so all the Timeslots must have an Interface
assignment. Site #2 and Site #3 only use a fraction of the T-1, but the total
quantity of Timeslots must match those of Site #1. Unused Timeslots
receive an Interface number of 000.
NOTE When the WPIM-DI Physical Configuration screen is saved and
the Drop-and-Insert function is enabled, any timeslots initially
set to 000 in the Timeslot Configuration table change to DI to
reflect that these timeslots are mapped to the DI interface.
In order to map unused timeslots to another device connected
to the DI port of theWPIM-DI, the DI Enable option on theWAN
Physical Configuration screen must be set to On.
TIP For block diagrams of typical supported configurations, see
Appendix B.
1482_03
005
005
000
005
005
000
005
005
000
005
005
000
005
005
000
005
005
000
005
005
000
005
005
000
SITE #2
01-08
09-16
17-24
SITE #3
01-08
09-16
17-24
006
000
000
006
000
000
006
000
000
006
000
000
006
000
000
006
000
000
006
000
000
006
000
000
01-08
09-16
17-24
000
000
006
000
000
006
000
000
006
000
000
006
000
000
006
000
000
006
000
000
006
000
000
006
SITE #1B
SITE #1A
01-08
09-16
17-24
005
005
000
005
005
000
005
005
000
005
005
000
005
005
000
005
005
000
005
005
000
005
005
000
