We provide several example networks, beginning with a simple network and progressing to more
complex networks. You may find the configuration instructions provided for each example helpful
when configuring your own network.
We include the following chapters:
• Simple Remote Bridging Network
An example ofa simple network using remote bridge devices to access a CyberSWITCH’s four
basic rate lines.
• Remote Bridging Network with Security
A bridged network with Calling Line Id security and Bridge MAC Address security enabled.
The network is configured with two devices. One device will be configured to require a Bridge
MAC Address security password, and one device will not. This network uses BRI lines.
•IPRoutingNetwork
An IP routing network with devices accessing the network from their homes.
• IP Routing Network with Remote Bridge Devices
A smart bridging interface to allow the two remote bridge devices to connect to an IP subnet.
The CyberSWITCH treats these devices connected to the Smart Bridging network interface as
if they were connected to the same Ethernet segment.
• IP Routing Network with PPP Devices
Uses IP routing to connect two of our products, both using PPP. Each system is on a separate
LAN. The configuration for this network is designed to allow three different types of accesses.
•IPXRoutingNetwork
A sample network using IPX protocol to communicatewith remote bridges as well as a remote
IPX router.
• AppleTalk Network
An AppleTalk network made up of two LANs, separated by the WAN.

S IMPLE R EMOTE B RIDGING N ETWORK
OVERVIEW
This chapter provides an example of a simple network using remote bridge devices to access four
basic rate lines in the CyberSWITCH. Bridges are formed between each of the LANs to which the
remote bridge devices are connected, and the LAN to which the CyberSWITCH is connected.
The following section provides the initial installation steps that would be used with any type of
network installation.
INITIAL INSTALLATION STEPS
The initial steps in the CyberSWITCH installation process are basically the same no matter how
complicated the network. These steps are:
• completing the requirement worksheets
•orderingISDNservice
• powering on the system
• accessing Release Notes
• connecting an administration console
• setting up Telnet access
• upgrading system software
• changing defaults to secure system
• returning configuration to factory defaults
The chapters Accessing the CyberSWITCH and Upgrading System Software (in the User’s Guide)
describe each of these steps in detail.
Worksheets for this network are included on the next few pages.
CONFIGURING THE SIMPLE REMOTE BRIDGE
Because this is a simple bridged network, you only need to fill out the System Details and Bridging
and Routing Information worksheets. The worksheets for Example 1 are on the following pages.

EXAMPLE NETWORKS
10 CyberSWITCH
System Name: SITE1 PAP Password:_______________ CHAP Secret:___________________
RESOURCES
LINES
BRI Lines
PRI Lines
V.35 and RS232 Lines
Type Slot Switch type Synchronization type
BRI 15ESS
Ethernet_1 2
Name Slot Port Line type Call screen TEI SPID Directory number
Line1 1 1 PPP Auto
Line2 1 2 PPP Auto
Line3 1 3 PPP Auto
Line4 1 4 PPP Auto
Name Slot Port Framing type Line coding Sig. method Line build-out
Name Slot Port Device/Network Idle character
SYSTEM DETAILS

Workgroup Remote Access Switch 11
S IMPLE R EMOTE B RIDGING N ETWORK
Bridging and Routing Information
BRIDGING
IP ROUTING
Network Interface Information
Static Routes
Bridging X enabled ❒disabled
Mode of Operation ❒restricted ❒unrestricted
Bridge Filters
Bridge Dial Out/
Known Connect List
IP Routing X enabled ❒disabled
Mode of Operation ❒router X IP host
LAN Name
IP address
Mask
Unnumbered WAN ❒need
❒don’t need
Remote LAN Name
IP address
Mask
Traditional WAN Name
IP address
Mask
Direct Host WAN Name
IP address 192.42.1.6 192.42.1.7
Mask
IP Host Mode IP address
Mask
Destination network address Mask Next hop
❒ default?
❒default?
❒default?
❒default?
BRIDGING AND ROUTING INFORMATION

EXAMPLE NETWORKS
12 CyberSWITCH
CONFIGURE THE CYBERSWITCH
Using CFGEDIT, we will guide you through the steps to configure the CyberSWITCH for a simple
remote bridge network. We will execute these steps in the same order as they appear in the
configuration menus.
Start the CFGEDIT configuration utility. Type the following command at the system prompt:
cfgedit <return>
The following Main Menu will then be displayed:
CONFIGURING THE PHYSICAL RESOURCE INFORMATION
We start with configuring the Physical Resource information. Press 1 at the Main Menu to display
the Physical Resource Configuration Menu:
You may only configure the switch type. The rest of the resource information may only be
displayed.
We will next add the line information. Press 2 at the Physical Resources Menu and press 1 to add a
line. First, you will be prompted for the line name. You will then be asked to select which slot and
port you wish to use. We will use LINE1 as the line name, and slot 1, port 1 as the slot and port
combination:
You will then be prompted for the line interface type. For our example, we will be using point-to-
point lines. Press 1 as shown below to select this line type.
Main Menu:
1) Physical Resources
2) Options
3) Security
4) Save Changes
Select function from above or <RET> to exit:
Physical Resource Menu:
1) Resources
2) Data Lines
3) Access
4) ISDN Subaddress
Select function from above or <RET> for previous menu:
LINE NAME or press <RET> for previous menu: LINE1
Currently available Ports:
SLOT Resource Type Available Ports Switch Type
---- --------------- ----------------- ---------------
1 BASIC_RATE 1, 2, 3, 4 BRI_5ESS
Slot number from above? 1
Port number from Slot 1? 1

Workgroup Remote Access Switch 13
S IMPLE R EMOTE B RIDGING N ETWORK
Bridging and Routing Information
The nextitem thatyou need to configureis the Data Linkfor theline. Depending on the switch type,
there may be more than one Data Link per line. In our example, we use one Data Link with
Automatic TEI Negotiation:
After entering the above information, press <return> to display the line menu. Because there are
four lines in this example, the steps for adding a line should be repeated for lines 2, 3, and 4. After
all lines have been added, press <return> twice to return to the Main Menu.
CONFIGURING THE OPTIONS
The default configuration for the CyberSWITCH is bridging disabled and IP routing enabled. For
reasons we provide below, we want both bridging and IP routing enabled. Under the Option Menu,
select the bridging option and follow the instructions to enable bridging.
This network is abridged network, but we are going to configure an IP option (the IP host operating
mode) so that we may use an IP application (such as Telnet, TFTP, or SNMP) to manage the
CyberSWITCH. Refer to the graphic below for clarification.
LINE TYPE = BR_ISDN
1) POINT_TO_POINT
2) POINT_MULTIPOINT
Select Option [default = POINT_TO_POINT] or press <RET> for previous menu: 1
Current DATA LINK Configuration for this line:
id TEI
-- ----
There are currently no Data Links configured for this line.
Enter (1) to Add or press <RET> for previous menu: 1
Automatic TEI Negotiation (Y or N) [default = Y]? Y
Current Data Link Configuration for this line:
id TEI
-- ----
1 AUTO
(1) Add, (2) Change, (3) Delete a DATA LINK or press <RET> for previous menu? <RET>

EXAMPLE NETWORKS
14 CyberSWITCH
The network illustrated above is a bridged network. Each system, SITE1 and SITE2 have been
configured with all the necessary bridging information. SITE1and SITE2 have also been configured
in the IP host operating mode, and each have an IP host interface. This will allow each system to be
managed remotely by the PC using Telnet client software (once the initial configuration has been
completed).
Note that the IP address associated with each system is on the same LAN as the PC. This does not
have to be the case. As long as the PC has access to the systems through their IP addresses, it can
manage the systems using Telnet (or one of the other IP applications).
The steps below describe the configuration steps needed for the above example:
To enable the IP Host Operating Mode:
1. Select IP Operating Mode from the IP configuration menu.
2. Select IP host operating mode.
Note: The IP operating mode can not be set to host unless bridging is enabled.
3. When you select the IP host operating mode, an abbreviated IP configuration will be displayed
(similar to the following):
IP Menu:
1) IP Routing (Enable/Disable)
2) IP Operating Mode
3) IP Interfaces
4) IP Static Routes
5) RIP (Enable/Disable)
6) IP Static ARP Table Entries
7) Isolated Mode (Enable/Disable)
8) Static Route Lookup via RADIUS (Enable/Disable)
9) IP Address Pool
10) IP Filter Information
11) DHCP Information
Select function from above or <RET> for previous menu:
Telnet Client
192.42.1.0 IP Host Interface
192.42.1.6
IP Host Interface
192.42.1.7
ISDN
CSX1200 "A"
CSX1200 "B"
POWER SERVICE TX RX 10BASE- T
LAN B-CHANNELS E1ONLY
B2 B4 B6 B8 B26B28
B22 B24
B18 B20
B14 B16
B10 B12 B30 L1
B1 B3 B5 B7 B25B27
B21 B23
B17 B19
B13 B15
B9 B11 B29B31
E1
DT1
D
POWER SERVICE TX RX 10BASE- T
LAN B-CHANNELS E1ONLY
B2 B4 B6 B8 B26B28
B22 B24
B18 B20
B14 B16
B10 B12 B30 L1
B1 B3 B5 B7 B25B27
B21 B23
B17 B19
B13 B15
B9 B11 B29B31
E1
DT1
D

Workgroup Remote Access Switch 15
S IMPLE R EMOTE B RIDGING N ETWORK
Bridging and Routing Information
To configure the IP host interface:
1. Select IP Interfaces from the IP configuration menu.
2. Select to add an interface.
3. Enter the IP address assigned to this interface. For SITE1, this is 192.42.1.6; for SITE2, this is
192.42.1.7.
4. Enter the subnet mask.
5. Enter the MTU size.
6. Select the transmit broadcast address.
If IP RIP is enabled, enter the following additional information:
7. IP RIP receive control.
8. IP RIP respond control.
9. IP RIP v2 authentication control.
10. IP RIP v2 authentication key (required only if the IP RIP v2 authentication control has been
configured with a value other than “No Authentication.“
For more detailed information on the IP host operating mode, refer to the IP Operating Mode section
in the Configuring Basic IP Routing chapter of the User’s Guide.
CONFIGURING THE SECURITY
For this network configuration, we require no security. The default configuration is device security
enabled. To make the required configuration change, select Security from the Main Menu. Then
select Security Level. Finally, select No Security.
SAVE CONFIGURATION FILES
We have now configured all of the required information. Press 4 from the Main menu to save the
changes and then press <RET> to exit. Reboot the system to activate your changes.

EXAMPLE NETWORKS
16 CyberSWITCH
VERIFY THE INSTALLATION
Steps on how to verify the installation are detailed in the System Verification chapter of the User’s
Guide. This section gives an outline of which steps should be executed.
On the CyberSWITCH:
Verify resources are operational
Issue
dr command
Look for BRI line messages
Look for LAN initialized messages
Look for Bridge initialized messages
Verify WAN Lines Available
Connect WAN lines
Issue
dr command
Look for “Data Link up 1,1” in reports
On each Combinet LAN:
Attempt accessing a resource on the system LAN. This may require that you reboot your machine
and proceed through the logon sequence.

R EMOTE B RIDGING N ETWORK WITH S ECURITY
OVERVIEW
This example network is a bridged network with Calling Line Id security and Bridge MAC Address
security enabled. The network is configured with two devices. One device will be configured to
require a Bridge MAC Address security password, and one device will not. This network uses BRI
lines.
Worksheets for this network are included on the following pages.
Note that a Hunt Group is used for the BRI lines pictured in the Network Topology Worksheet.
Remote devices will thenonly need to configure one telephone number (the Hunt Group number)
for the CyberSWITCH instead of all four phone numbers. If the first line is busy, the next line is
automatically used, and so on until a free line is found. A Hunt Group number can be arranged
through your Service Provider.
INITIAL INSTALLATION STEPS
The initial steps in the CyberSWITCH installation process are basically the same no matter how
complicated the network. These steps are:
• completing the requirement worksheets
•orderingISDNservice
• powering on the system
• accessing Release Notes
• connecting an administration console
• setting up Telnet access
• upgrading system software
• changing defaults to secure system
• returning configuration to factory defaults
The chapters Accessing the CyberSWITCH and Upgrading System Software (in the User’s Guide)
describe each of these steps in detail.
Worksheets for this network are included on the next few pages.

EXAMPLE NETWORKS
18 CyberSWITCH
File Server
BRIBRI
PC
PC
PC
BRI
Hunt Group Number:
13135551111
13135551111
13135551112 13135551113
13135551114
13135551212
13135552121 13135556789 13135559876
Bridge Ethernet Address:
000123456789
Password: JXF30
Bridge Ethernet Address:
003456789000
Password: None
User Name:
Mike Mann User Name: Pat Smith
Bridges
ISDN
POWER SERVICE TX RX 10BASE - T
LAN B-CHANNELS E1 ONLY
B2 B4 B6 B8 B26 B28
B22 B24
B18 B20
B14 B16
B10 B12 B30 L1
B1 B3 B5 B7 B25 B27
B21 B23
B17 B19
B13 B15
B9 B11 B29 B31
E1
DT1
D
NETWORK TOPOLOGY

Workgroup Remote Access Switch 19
R EMOTE B RIDGING N ETWORK WITH S ECURITY
Initial Installation Steps
System Name: Remote Bridge PAP Password:_______________ CHAP Secret:___________________
RESOURCES
LINES
BRI Lines
* Hunt Group Number: 13135551111
PRI Lines
Type Slot Switch type Synchronization type
BRI 1NI-1
Ethernet_1 2
Name Slot Port Line type Call
screen TEI SPID Directory number
Line1 1 1 PPP Auto 3135551111 13135551111*
3135551112 13135551112*
Line2 1 2 PPP Auto 3135551113 13135551113*
3135551114 13135551114*
Name Slot Port Framing type Line coding Sig. method Line build-out
SYSTEM DETAILS

EXAMPLE NETWORKS
20 CyberSWITCH
Device Name: Mike Mann
Calling (ISDN, FR, etc.) Information X.25 Information
Authentication Information : Frame Relay Information
* HDLC Bridge only
Protocol for this particular device?
Bridge IP
IPX AppleTalk
Line Protocol HDLC bridge PVC
Base Data Rate SVC
Initial Data Rate
Max Data Rate
Dial-Out Number(s)
PAP Password DLCI
CHAP Secret
IP Host ID
Bridge Ethernet Address* 000123456789
Bridge Password* JXF30
CLID(s) 13135551212 13135552121
Bridging enabled? ❒enabled ❒disabled IP enabled? ❒enabled ❒disabled
Make calls
for bridged data? ❒enabled ❒disabled IP Address (on WAN link)
For IP RLAN, IP (Sub-)
network number ❒0.0.0.0 if unnumbered link
For IPX RLAN, external
network number Make calls for IP data? ❒enabled ❒disabled
IPX enabled? ❒enabled ❒disabled AppleTalk enabled? ❒enabled ❒disabled
Callable by IPX? ❒enabled ❒disabled AppleTalk Address
IPXWAN protocol? ❒enabled ❒disabled Make calls for
AT data? ❒enabled ❒disabled
IPX routing protocol?
❒none ❒RIP/SAP
❒ triggered RIP/SAP
AT Routing Protocol
IPX spoofing?
DEVICE INFORMATION
