Cadco CAPO-203 User manual

June
2008
Cadco, Ltd.
Commercial
Product Catalog
Cadco, Ltd. l 145 Colebrook River Road, Win ted, CT 06098
Phone: [phone]
l Fax: [phone]
E-mail: [email protected]
l Vi it our web ite at www.cadco-ltd.com.
The Performance Leader
in Food ervice Oven
The Performance Leader
in Food ervice Oven
June
2008
Cadco, Ltd.
Commercial
Product Catalog
Product Categories Page
Convection Ovens 2-6
Holding Towers 7
Combination Ovens 8-9
Ovens Accessories 1 -11
Mobile Buffet Warming Carts 12
Warming Cabinets & Buffet Servers 13-15
Warming Shelves 16
Kettles & Well Warmers 17
Panini Grills 18
Griddles 18
Portable Ranges 19
Toasters 2

2
XAF-130: Half Size Convection Oven with NO Humidity
4 Shelves Classic Control Panel, stainless -StefaniaTM
(Same as XAF-135 except: NO HUMIDITY or Water ump)
l Programmable controls: Time, Temperature
l Handles 4 half size sheet pans (not included)
l Four shelves included l Also handles steam pans
l Cooking chamber is 13 H x 19-1/2 W x 15-1/2 D
(2.27 cubic eet) l One an l Freight class 85
l Electrical: 208-240 Volts / 2,700 Watts /
12.3 Amps / Single Phase l NEMA 6-15P Plug
NOTE: This model must ship by truck, not UPS
UL NSF CSA
CONVECTION OVENS - DIGITAL
NEMA 6-15P
Plug
NEMA 6-15P
Plug
NEMA 6-15P
Plug
* does not include weight o shipping skid
XAF-135: Half Size Convection Oven with Humidity
4 Shelves Dynamic Control Panel, stainless -AriannaTM
l Programmable controls: Time, Temperature, Humidity
l Handles 4 half size sheet pans (not included)
l Four shelves included l Also handles steam pans
l Includes EL080 Auxiliary Water Pump
l Cooking chamber is 13 H x 19-1/2 W x 15-1/2 D
(2.27 cubic eet) l One an l Freight class 85
l Electrical: 208-240 Volts / 2,700 Watts /
12.3 Amps / Single Phase l NEMA 6-15P Plug
NOTE: This model must ship by truck, not UPS
* does not include weight o shipping skid
Cadco Digital Convection Ovens advanced features
enhance the cooking performance and extend durability for long lasting use
Dimensions listed are for the assembled piece of equipment without shipping carton. Shipping weights are for equipment packed in shipping carton.
Digital Convection Oven
Width
235/8
Height
20
Depth
281/8
Ship Wt.
97 lbs.*
Width
235/8
Height
20
Depth
281/8
Ship Wt.
97 lbs.*
XAF-115: Half Size Convection Oven with Humidity
3 Shelves Dynamic Control Panel, stainless -StefaniaTM
l Programmable controls: Time, Temperature, Humidity
l Handles 3 half size sheet pans (not included)
l Three shelves included l Also handles steam pans
l Includes EL080 Auxiliary Water Pump
l Cooking chamber is 10 H x 19-1/2 W x 15-1/2 D
(1.75 cubic eet) l One an l Freight class 85
l Electrical: 208-240 Volts / 2,700 Watts /
12.3 Amps / Single Phase l NEMA 6-15P Plug
NOTE: This model must ship by truck, not UPS * does not include weight o shipping skid
Width
235/8
Height
167/8
Depth
281/8
Ship Wt.
78 lbs.*
* does not include weight o shipping skid
Width
235/8
Height
167/8
Depth
281/8
Ship Wt.
78 lbs.*
NEMA 5-15P
Plug
XAF-111: Half Size Convection Oven with NO Humidity
3 Shelves Classic Control Panel, stainless -StefaniaTM
(Same as XAF-115 except: NO HUMIDITY or Water ump, 120V)
l Programmable controls: Time, Temperature
l Handles 3 half size sheet pans (not included)
l Three shelves included l Also handles steam pans
l Cooking chamber is 10 H x 19-1/2 W x 15-1/2 D
(1.75 cubic eet) l One an l Freight class 85
l Electrical: 120 Volts / 1,450 Watts /
12 Amps / Single Phase l NEMA 5-15P Plug
NOTE: This model must ship by truck, not UPS
All Digital Oven Models feature:
l Advanced airflow design with patented baffle & automatically reversible fan for even heat
l Digital programmable controls - up to 70 programs l Heat settings rom 175o-500o F
l 10 hour timer or continuous on l Timer beeps at end o cycle l 3 between shelves
l Dura-Body heavy duty stainless steel construction l High temperature motor bearings
l Sa ety design: cool-touch double wall glass door l Oven cavity is wrapped in high R value insulation
l Interior halogen light l Rein orced door design l Micro sa ety switch shuts oven o when door is opened
l NSF, UL through CSA Standards / listed by UNOX S.p.A. l Che Support  on-line and via phone
l Two Year Limited On-site Warranty
120 Volt
List Price $2,250.00
List Price $2,590.00
List Price $2,350.00
List Price $2,150.00

3
XAF-195: Full Size Convection Oven with
Humidity 4 Shelves Dynamic Control Panel,
stainless -RossellaTM
l Programmable controls: Time, Temperature, Humidity
l Handles 4 full size sheet pans (not included)
l Four shelves included l Also handles steam pans
l Includes electro valve for direct water connection
l Cooking chamber is 13 H x 27-1/4 W x 18-3/4 D
(3.85 cubic eet) l Two ans
l Electrical: 208-240 Volts / 5,600 Watts / 24.4 Amps /
Single Phase l NEMA L6-30 Plug
l Freight class 85
NOTE: This model must ship by truck, not UPS
XAF-188: Full Size Convection Oven with
Humidity 3 Shelves Dynamic Control Panel,
stainless -ElenaTM
l Programmable controls: Time, Temperature, Humidity
l Handles 3 full size sheet pans (not included)
l Three shelves included l Also handles steam pans
l Includes electro valve for direct water connection
l Cooking chamber is 10 H x 27-1/4 W x 18-3/4 D
(3 cubic eet) l One an
l Electrical: 208-240 Volts / 4,600 Watts / 20 Amps /
Single Phase l NEMA L6-30 Plug
l Freight class 85
NOTE: This model must ship by truck, not UPS
* does not include weight o shipping skid
NEMA
L6-30 Plug
NEMA
L6-30 Plug
* does not include weight o shipping skid
Digital Convection Oven
UL NSF CSA
CONVECTION OVENS - DIGITAL
Width
311/2
Height
197/8
Depth
32
Ship Wt.
119 lbs.*
Width
311/2
Height
23
Depth
32
Ship Wt.
142 lbs.*
XAL135:
Proofer for XAF-115 & XAF-135 Half Size Ovens
l Handles 8 hal size sheet pans (not included)
l Temperatures to 122
o
F.
l Unit : W: 23-5/8 x D: 22-13/16 x H: 29-7/8
l Ship Wt.*: 57 lbs.
l Electrical: 208-240 Volts / 1200 Watts / 5.5 Amps / NEMA 6-15P Plug
NOTE: This model must ship by truck, not UPS
XAL195:
Proofer for XAF-188 & XAF-195 Full Size Ovens
l Handles 8 ull size sheet pans (not included)
l Temperatures to 122
o
F.
l Unit: W: 31-1/2 x D: 28 x H: 29-7/8
l Ship Wt.*: 91 lbs.
l Electrical: 208-240 Volts / 1200 Watts / 5.5 Amps / NEMA 6-15P Plug
NOTE: This model must ship by truck, not UPS
NOTE: In modular configurations, oven & proofer are both controlled by the
digital Dynamic control panel on the oven. roofers not designed for stand-alone use.
NEMA
6-15P
Plug
* Does not include weight of shipping skid
NEMA
6-15P
Plug
DIGITAL PROOFERS
For additional convection oven
accessories, see pages 10-11
Dimensions listed are for the assembled piece of equipment without shipping carton. Shipping weights are for equipment packed in shipping carton.
List Price $3,590.00 List Price $4,290.00
List Price $2,390.00
List Price $2,190.00

4
120 Volt
120 Volt
Dimensions listed are for the assembled piece of equipment without shipping carton. Shipping weights are for equipment packed in shipping carton.
XAF-113: Half Size Convection Oven with
Manual Controls 3 Shelves, stainless -StefaniaTM
l Manual control knobs: Time, Temperature
l Handles 3 half size sheet pans (not included)
l Three shelves included l Also handles steam pans
l Cooking chamber is 10 H x 19-1/2 W x 15-1/2 D
(1.75 cubic eet) l One an
l Electrical: 120 Volts / 1,450 Watts / 12 Amps /
Single Phase l NEMA 5-15 Plug
l Freight class 85
NOTE: This model must ship by truck, not UPS
NEMA 6-15P
Plug
Width
235/8
Height
167/8
Depth
281/8
Ship Wt.
78 lbs.*
* does not include weight o shipping skid
* does not include weight o shipping skid
XAF-103: Quarter Size Convection Oven with
Manual Controls 3 Shelves, stainless -CristinaTM
l Manual control knobs: Time, Temperature
l Handles 3 quarter size sheet pans (not included)
l Three shelves included l Also handles steam pans
l Cooking chamber is 10 H x 14-1/2 W x 11 D
(.92 cubic eet) l One an
l Electrical: 120 Volts / 1,450 Watts / 12 Amps /
Single Phase l NEMA 5-15 Plug
l Freight class 85
NOTE: *This model UPS-able i overwrapped
All LineChef TM Manual Convection Oven Models feature:
NEMA 5-15P
Plug
XAF-133: Half Size Convection Oven with
Manual Controls 4 Shelves, stainless -AriannaTM
l Manual control knobs: Time, Temperature
l Handles four half size sheet pans (not included)
l Four shelves included l Also handles steam pans
l Cooking chamber is 13 H x 19-1/2 W x 15-1/2 D
(2.27 cubic eet) l One an
l Electrical: 208-240 Volts / 2,700 Watts / 12.3 Amps /
Single Phase
l NEMA 6-15 Plug
l Freight class 85
NOTE: This model must ship by truck, not UPS
NEMA 5-15P
Plug
Manual Convection Oven
UL NSF CSA
CONVECTION OVENS - MANUAL
Cadco LineChef TM Manual Convection Ovens possess cooking performance
similar to the LineChefTM Digital Convection Ovens, except with manual controls,
and they extend durability for long lasting use
Width
1815/16
Height
167/8
Depth
223/16
Ship Wt.
61 lbs.*
Width
235/8
Height
20
Depth
281/8
Ship Wt.
92 lbs.*
l Advanced air low design with patented ba le l Manual controls l Heat settings rom 175
o
- 500
o
F
l 60 minute timer beeps at end o cycle l High temperature motor bearings
l Dura-Body heavy duty stainless steel construction
l Rein orced door design l Interior halogen light l 3 between shelves
l Sa ety design: cool-touch double wall glass door l Oven cavity wrapped in high R value insulation
l Dimensions are designed to accommodate modular stacking or customized con iguration
l NSF, UL through CSA Standards / listed by UNOX S.p.A.
l Two Year Limited On-site Warranty on 208-240V models;
Two-year Limited Carry-in Warranty on 120V models
List Price $1,490.00
$1,850.00
List Price $2,100.00

5
XAF-193: Full Size Convection Oven with
Manual Controls 4 Shelves, stainless
l Manual controls: Time, Temperature
l Handles 4 full size sheet pans (not included)
l Four shelves included l Also handles steam pans
l Automatically reversible fans for even heat
l Cooking chamber is 13 H x 27-1/4 W x 18-3/4 D
(3.85 cubic eet) l Two ans
l Electrical: 208-240 Volts / 5,600 Watts / 24.4 Amps /
Single Phase
l NEMA L6-30 Plug
l Freight class 85
NOTE: This model must ship by truck, not UPS
XAF-183: Full Size Convection Oven with
Manual Controls 3 Shelves, stainless
l Manual controls: Time, Temperature
l Handles 3 full size sheet pans (not included)
l Three shelves included l Also handles steam pans
l Automatically reversible fan for even heat
l Cooking chamber is 10 H x 27-1/4 W x 18-3/4 D
(3 cubic eet) l One an
l Electrical: 208-240 Volts / 4,600 Watts / 20 Amps /
Single Phase l NEMA L6-30 Plug
l Freight class 85
NOTE: This model must ship by truck, not UPS
NEMA
L6-30 Plug NEMA
L6-30 Plug
UL NSF CSA
CONVECTION OVENS - MANUAL
Manual Convection Oven
CONVECTION OVEN STANDS
For additional convection oven
accessories, see pages 10-11
Width
311/2
Height
197/8
Depth
32
Ship Wt.
119 lbs.*
* does not include weight o shipping skid * does not include weight o shipping skid
Width
311/2
Height
23
Depth
32
Ship Wt.
142 lbs.*
-ElenaTM -RossellaTM
Dimensions listed are for the assembled piece of equipment without shipping carton. Shipping weights are for equipment packed in shipping carton.
XR130: Stand for XAF-111, XAF-113, XAF-115, XAF-130, XAF-133 & XAF-135 Half Size Ovens
l Handles 8 hal size pans (not included) l Stainless steel l Unit: W: 23-5/8 x D: 20-13/32 x H: 30-13/16 l Ship Wt: 32 lbs.
XR130
XR190
OST-195
XR190: Stand for XAF-183, XAF-188, XAF-193 & XAF-195 Full Size Ovens
l Handles 8 ull size pans (not included) l Stainless steel l Unit: W: 31-7/16  x D: 23-5/8  x H: 30-13/16 l Ship Wt: 38.5 lbs.
OST-195: Heavy-Duty Stand with Wheels for XAF-183, XAF-188, XAF-193 & XAF-195
Full Size Ovens
l Handles 8 ull size shepans (not included) l Aluminum l 4 Wheels w/brakes included
l Unit: W: 30  x D: 32  x H: 34-3/4 (incl. wheels) l Ship Wt: 46 lbs. (ships in 2 cartons)
XR621: Wheels Kit
for Oven Stands
l 2 wheels with brake,
2 without brake
l Ship Wt: 5 lbs.
XR621
OST-34A: Heavy-Duty Stand with Wheels for Half Size Ovens
l Handles 7 hal size sheet pans (not included) l Aluminum (assembly required)
l 4 Wheels w/brakes included l Unit: W: 20-3/4 x D: 24-1/2  x H: 31-1/2 l Ship Wt: 29.5 lbs.
OST-34A
List Price $3,190.00 List Price $3,850.00
List Price $760.00
List Price $950.00
List Price $840.00
List Price $240.00
List Price $630.00

6
UL NSF CSA
CONVECTION OVENS - BASIC MANUAL
All Compact Manual Convection Oven Models feature:
l Advanced air low design with patented ba le l Manual controls l Heat settings rom 175
o
- 500
o
F
l 60 minute timer; green signal light goes o at end o cycle l High temperature motor bearings
l Dura-Body heavy duty stainless steel construction
l Sa ety design: cool-touch double wall glass door l Rein orced door design
l 2-1/2 between shelves l Oven cavity wrapped in high R value insulation
l NSF, MET through UL Standards / listed by UNOX S.r.l.
l Two Year Limited On-site Warranty on 208-240V model;
Two-year Limited Carry-in Warranty on 120V models
Cadco Compact Manual Convection Ovens provide Small Footprint & Large roduction
120 Volt
120 Volt
OV-013: Half Size Convection Oven with
Manual Controls 3 Shelves, stainless -LisaTM
l Manual control knobs: Time, Temperature
l Handles 3 half size sheet pans (not included)
l Three shelves included l Also handles steam pans
l Cooking chamber: 9 H x 18-3/4 W x 13-3/4 D
(1.34 cubic eet) l One an
l Electrical: 120 Volts / 1,450 Watts / 12 Amps /
Single Phase
l NEMA 5-15 Plug
l Freight class 85
NOTE: *This model UPS-able i overwrapped
NEMA 6-15P
Plug
Width
235/8
Height
153/4
Depth
233/4
Ship Wt.
62 lbs.
* does not include weight o shipping skid
OV-003: Quarter Size Convection Oven with
Manual Controls 3 Shelves, stainless -RobertaTM
l Manual control knobs: Time, Temperature
l Handles 3 quarter size sheet pans (not included)
l Three shelves included l Also handles steam pans
l Cooking chamber: 9 H x 14-1/8 W x 11-1/4 D
(.83 cubic eet) l One an
l Electrical: 120 Volts / 1,450 Watts / 12 Amps /
Single Phase l NEMA 5-15 Plug
l Freight class 85
NOTE: *This model UPS-able i overwrapped
NEMA 5-15P
Plug
OV-023: Half Size Convection Oven with
Manual Controls 4 Shelves, stainless -AnnaTM
l Manual control knobs: Time, Temperature
l Handles four half size sheet pans (not included)
l Four shelves included l Also handles steam pans
l Cooking chamber: 11-3/4 H x 18-3/4 W x 13-3/4 D
(1.75 cubic eet) l One an
l Electrical: 208-240 Volts / 2,700 Watts / 12.3 Amps /
Single Phase
l NEMA 6-15 Plug
l Freight class 85
NOTE: This model must ship by truck, not UPS
NEMA 5-15P
Plug
Width
187/8
Height
153/4
Depth
211/2
Ship Wt.
47 lbs.
Width
235/8
Height
185/8
Depth
233/4
Ship Wt.
70 lbs.*
Dimensions listed are for the assembled piece of equipment without shipping carton. Shipping weights are for equipment packed in shipping carton.
NEW
NEW
NEW
OV350CB: Carry Bag (for OV-013 & OV-350 Ovens)
l Designed to it OV-013 & OV-350 Ovens
l Per ect or carrying OV-013 & OV-350 ovens to catering jobs!
l Black, heavy-duty nylon material l Sturdy 15 high carry straps
l Unit Dimensions: W: 25" x D: 24" x H: 16" l Ship Wt: 3 lb.
Compact Countertop Convection Oven
List Price $950.00
List Price $1,500.00
List Price $1,750.00
List Price $100.00

7
HOLDING TOWERS
UL Safety & Sanitary C-UL
NEMA 5-15P
Plug
CMLW-103: Quarter Size Holding Tower
l For 1 4 size XAF & OV Compact series convection ovens
l Holds 3 quarter size sheet pans 3 half size steam pans
(pans not included)
l Heat baffle bracket (included) attaches to tower and
oven with self-drilling screws included
l Warming sur ace: 16 x 14-1/8
l Variable heat control - 155o to 205o F
l Electrical: 120 Volts / 900 Watts /
7.5 Amps / Single Phase
l NEMA 5-15 Plug
l Freight class 85
Width
191/8
Height
161/4
Depth
151/4
Ship Wt.
27 lbs.
CMLW-130: Half Size Holding Tower
l For half size XAF & OV Compact series convection ovens
l Holds 3 half size sheet pans 6 half size steam pans
(pans not included)
l Heat baffle bracket (included) attaches to tower and
oven with self-drilling screws included
l Warming sur ace: 20-5/8 x 14-1/8
l Variable heat control - 155o to 205o F
l Electrical: 120 Volts / 900 Watts /
7.5 Amps / Single Phase
l NEMA 5-15 Plug
l Freight class 85
Width
233/4
Height
161/4
Depth
151/4
Ship Wt.
31 lbs.
CMLW-190: Full Size Holding Tower
l For full size XAF series convection ovens
l Holds 3 full size sheet pans 3 full size steam pans
(pans not included)
l Heat baffle bracket (included) attaches to tower and
oven with self-drilling screws included
l Warming sur ace: 28-1/2 x 16
l Variable heat control - 155o to 205o F
l Electrical: 120 Volts / 1500 Watts /
12.5 Amps / Single Phase
l NEMA 5-15 Plug
l Freight class 85
Width
315/8
Height
161/4
Depth
171/8
Ship Wt.
45 lbs.
pans not included)
Dimensions listed are for the assembled piece of equipment without shipping carton. Shipping weights are for equipment packed in shipping carton.
NEMA 5-15P
Plug
NEMA 5-15P
Plug
NEW
NEW
NEW
Shown:
CMLW-103 Tower on XAF-103 Oven
l Designed to stack on top o Cadco XAF
& LineMicro
TM
Series Convection Ovens
l Towers (without ba le) may also
stand alone on countertop
l 5-3/4 between shelves
l Foods should be ully cooked and
already hot be ore being placed on
Warming/Holding Tower shelves;
designed or keep-warm unction only.
l NEMA 5-15P plug
l UL Sa ety & Sanitary, C-UL
Make Cadco XAF & LineMicroTM
Series Convection Ovens
even more productive!
Convenient: time & space saving.
Heat baffle bracket attaches
to tower and oven with self-
drilling screws included.
l Protects tower control knob
rom oven heat.
l Stabilizes tower on oven top.
Holding / Warming Tower
All Holding Warming Towers feature:
List Price $600.00
List Price $700.00
List Price $800.00

8
...The Oven Solution that combines hot air convection with variable humidity
at precision temperatures...now available in a simple compact design at a great value
Dimensions listed are for the assembled piece of equipment without shipping carton. Shipping weights are for equipment packed in shipping carton.
All CAPO series Combination Ovens feature:
l Steam convection: roast, bake, cook & hold or any combination
l Compact design maximizes available space l Heat settings rom 175o - 500o F l Even heat system
l 10 hour timer or continuous on l Digital controls provide easy operation l Programmable
l Variable steam l Venturi drying system l Probe l Cool-touch, easy-clean sa ety door l All stainless exterior
l Insulated double wall construction l Water eed, drain lines, ilter, hose and pressure regulator not included
l Complete internet or phone technical support or installation o water, electricity, drainage, controls
and general start-up l A ter-market support system to insure that units are properly serviced.
l Che Support  on-line and via phone l Two year warranty on heating element
Combination Oven
* includes stand in separate ctn.;
does not include weight o shipping skid
NOTE: Model CAPO-603 comes in two different configurations. They are identical except or the
side racks that support shelves or pans, the number o shelves included, and the number/size o pans
each model will accomodate. All steam pan quantities are based on 2-1/2 deep pans.
Specify the desired model when ordering:
MODEL CAPO-603-6 (shown)
l Handles 6 full size steam pans or 6 full size sheet pans (pans not included)
l Six GR1090AO shelves included
MODEL CAPO-603-7 (not shown; designed or maximizing steam pan capacity)
l Handles up to 7 full size steam pans or up to 6 half size sheet pans** (pans not included)
**Six GR1055AO shelves needed to use 6 half size sheet pans l Three GR1055AO shelves included
NEMA
6-50 Plug
CAPO-603: Full Size Combination Oven with Stand, stainless
l Cooking chamber: 22 H x 27-1/2 W x 20 D (7 cu. t.)
l Two ans l NEMA 6-50 plug
l Oven Stand included. 7 double tiers (adjustable width)
l Electrical: 208/240 volts /10,000 watts/ 50 amps/
single phase l Freight class 85
NOTE: This model must ship by truck, not UPS
Width
37
Height
60
Depth
34-3/4
Ship Wt.*
262 lbs.
UL NSF CSA
COMBINATION OVENS
CAPO-203: Countertop Combination Oven, stainless
l Handles 5 - 2 3 size steam pans** or 5 half size steam pans**
or 5 - 1 4 size sheet pans (pans not included)
l Five shelves included
l Cooking chamber is 14-1/2 H x 15 W x 15 D (1.9 cu. t.)
l One an l NEMA L6-30 plug
l Electrical: 208/240 volts / 5,500watts/ 30 amps/
single phase l Freight class 85
NOTE: This model must ship by truck, not UPS
NEMA
L6-30 Plug
* does not include weight o shipping skid
Width
24-3/4
Height
28-1/4
Depth
30
Ship Wt.*
120 lbs.
** All steam pan quantities are based on 2-1/2 deep pans
CAPO-403: Full Size Countertop Combination Oven, stainless
l Handles up to 4 full size steam pans** or 4 full size sheet pans
(pans not included)
l Four shelves included
l Cooking chamber: 14-1/2 H x 27-1/2 W x 20 D
(4.6 cu. t.)
l Two ans l NEMA 6-50 plug
l Electrical: 208/240 volts /10,000 watts/ 50 amps/
single phase l Freight class 85
NOTE: This model must ship by truck, not UPS
NEMA
6-50 Plug
* does not include weight o shipping skid
Width
37
Height
30
Depth
34-3/4
Ship Wt.*
165 lbs.
List Price $11,000.00
List Price $9,290.00
List Price $6,295.00

9
Dimensions listed are for the assembled piece of equipment without shipping carton. Shipping weights are for equipment packed in shipping carton.
UL NSF CSA
COMBINATION OVENS
COMBINATION OVEN ACCESSORIES NOTE: Water filtration is required
on all CA O series ovens.
Call Cadco for current filter model.
HOSE: Hose Attachment for CAPO Combi Ovens
l Hose or washing inside all CAPO combi ovens l Ship Wt: 5 lb.
LSR-603-7: Lateral Side Rack Shelf Supports (Set) For CAPO-603-7
l Can use on CAPO-603-6 to hold 7 steam pans l Ship Wt: 5 lb.
WPR-2B: Water Pressure Regulator 2 BAR
l For all CAPO combi ovens l Ship Wt: 5 lb.
GR1055AO: Shelf For CAPO-303 CAPO-603-7
l Hal size shel or CAPO combi ovens l Ship Wt: 4 lb.
GR1090AO: Shelf For CAPO-403 CAPO-603-6
l Full size shel or CAPO combi ovens l Ship Wt: 5 lb.
For more combi oven
accessories, see page 10.
l CAPO 603-6 Full SIze Oven with 6 shelves (See specs or CAPO-603-6 on page 8, but no stand)
l CAPO-403 Full Size Oven (See specs or CAPO-403 on page 8)
l Stacking Separator will hold up to 6 pans
(3 sheet pans and 3 steam table pans) 3 o each pan shown in use
in Stacking Separator; Pans not included.)
l Base dolly with wheels l Pressure Regulator (1)
l Water Filter (1) l Water & drain connection (1) l Hoses
CAPO-6403S: Full Size Stacking Kit with
CAPO-403 & CAPO-603-6 Combination Ovens - Includes:
Width
37
Height
72
Depth
34-3/4
Ship Wt.*
489 lbs.
* Ships in 3 cartons on 2 skids; does not include weight o shipping skids
XR402:
Stand for CAPO-403 603 803 Full Size Ovens
l Handles up to 8 pans (not included) l Stainless steel
l Unit: W: 37 x D: 23-5/8  x H: 20-5/32 l Ship Wt: 38 lbs.
XR401:
Stand for CAPO-403 603 803 Full Size Ovens
l Handles up to 14 pans (not included) l Stainless steel
l Unit: W: 37 x D: 23-5/8  x H:29 l Ship Wt: 42 lbs.
XR402 XR030
XR621: Wheels Kit for Oven Stands
l 2 wheels with brake, 2 without brake
l Ship Wt: 5 lbs.
XR401
COMBINATION OVEN STANDS
For additional combination oven
accessories, see page 10
XR621
XR030:
Stand for CAPO-203 Quarter Size Ovens
l Handles up to 7 pans (not included) l Stainless steel
l Unit: W: 21  x D: 23-5/8  x H: 29 l Ship Wt: 30 lbs.
CAPO-803: Full Size Combination Oven with Stand, stainless
l Handles 10 full size steam pans** or 10 full size sheet pans
l Ten shelves included
l Cooking chamber: 34 H x 27-1/2 W x 20 D (10.8 cu. t.)
l Three ans
l Oven Stand included. 4 double tiers (adjustable width)
l No cord or plug; quali ied electrician must install
l Electrical: 230/240 volts /16,000 watts/3 phase
NOTE: This model must ship by truck, not UPS
l Freight class 85
** All steam pan quantities are based on 2-1/2 deep pans
* includes stand in separate ctn.;
does not include weight o shipping skid
Width
37
Height
67-1/2
Depth
34-3/4
Ship Wt.*
366 lbs.
Two
NEMA
6-50 Plugs
List Price $1,050.00
List Price $1,000.00
List Price $240.00
List Price $780.00
List Price $21,000.00
List Price $16,800.00
List Price $400.00
List Price $140.00
List Price $70.00
List Price $44.00
List Price $60.00

Dimensions listed are for the assembled piece of equipment without shipping carton. Shipping weights are for equipment packed in shipping carton.
OVEN ACCESSORIES
Combination Ovens
Convection Ovens
Proofers
All ovens made to Cadco Ltd. specs by UNOX S.r.l., Italy l NSF/ANSI Standard 4 (www.ns .com) Listed as UNOX
Cadco UNOX
Model = Model
CAPO-203 = XAV203
CAPO-403 = XAV403
CAPO-603 = XAV603
CAPO-803 = XAV803
Cadco UNOX
Model = Model
XAL135 = XAL135
XAL195 = XAL195
Cadco UNOX
Model = Model
XAF-103 = XAF103
XAF-111 = XAF111
XAF-113 = XAF113
XAF-115 = XAF115
XAF-130 = XAF130
XAF-133 = XAF133
Cadco UNOX
Model = Model
XAF-135 = XAF135
XAF-183 = XAF183
XAF-188 = XAF188
XAF-193 = XAF193
XAF-195 = XAF195
OVENS & PROOFERS MODEL NUMBER CROSS REFERENCE for NSF, MET & CSA LISTINGS
Combination & Convection Oven Acce orie
l FAKIROTM plates provide very ast baking times, up to 50% aster than traditional baking pans.
It takes as little as 4-5 minutes to bake a resh Pizza on the FAKIROTM plate!
l The plates are manu actured rom alloys which provide superior heat storage and produce
ast, even cooking o both top and bottom o the ood product simultaneously.
l FAKIROTM plates are designed with burls on the lower sur ace o the plate, which intensi y the heating action.
l FAKIROTM plates help ovens maintain better temperature stability under normal door opening/closing conditions.
FAKIROTM Heat Plate : For all Cadco Half Size & Full Size Convection & Combination Ovens
The exclusive patented FAKIRO
TM
Heat Plates bake everything in shorter time
for fast baking of Pizza, Breads, and other Snacks Baked goods
Burls on the lower
sur ace o the plate
intensi y the heat
Non-stick
Baking sur ace
GRF018: Oven Fry Basket (Full Size)
l Stainless steel l Ship Wt.: 3 lbs. l Unit: W: 20-7/8" x D:12-3/4" x H:1-1/2"
GRH018: Oven Fry Basket (Half Size)
l Stainless steel l Ship Wt.: 2 lbs. l Unit: W: 17-7/8" x D:12-3/4" x H:1-1/2"
TG845: FAKIROTM Grill Plates
l FAKIROTM Grill Plates allow grilling o ish, meats, and
vegetables in the oven
l For ull size ovens only
l Ribbed grilling sur ace or appetizing grill marks on oods
l Easy to clean Te lon coated aluminum grill sur ace
l Unit: W: 20-7/8 x D: 12-3/4 x H: 5/8 l Ship Wt.: 8 lbs.
GRP815: (Full Size) Poultry Rack
l Holds up to eight 3 lb. poultry
l Stainless steel l Ship Wt.: 5 lbs.
l Unit: W: 20-7/8" x D: 12-7/8" x H: 6-3/4"
GRF018 GRH018
TG450: Full Size Heat Plate
l Unit: W: 26-1/4" x D: 17-7/8" x H: 5/8"
l Ship Wt.: 14 lbs.
TG320: Half Size Heat Plate
l Unit: W: 18-1/8" x D: 13" x H: 5/8"
l Ship Wt.: 8 lbs.
NEW
OV Series Compact
Convection Ovens
Cadco UNOX
Model = Model
OV-003 = XAF003
OV-013 = XAF013
OV-023 = XAF023
CSA to requirements o UL 197 (http://directories.csa-international.org)
Listed as UNOX S.r.l., File #202281
MET to UL requirements
(http://www.metlabs.com/)
Listed as UNOX S.r.l.
List Price $150.00
List Price $140.00
List Price $250.00
List Price $150.00
List Price $320.00 List Price $160.00

11
OVEN ACCESSORIES
Convection Oven Only Acce orie
Model XC646: Stacking Kit for Full Size XAF Ovens
(Models XAF-183, XAF-188, XAF-193, XAF-195)
l Ship Wt: 20 lbs.
XC600: Air Deflector Plate (for XAF Ovens)
l De lects air in oven cavity; or baking delicate oods like pu pastry
l Attaches without tools to the an protection grid in the oven cavity
l Use one air de lector plate per oven an
l Unit: Diam: 5" x H: 3/4" l Ship Wt: 0.6 lbs.
NEW
OQFSP: 1 4 Size Flat Sheet Pan
l Designed to it 1/4 size ovens, and to it an extra row o cookies vs. standard sheet pans
l Low 3/16 sides or easy removal o cookies, etc. l Aluminum
l Unit: W: 13-1/2" x D: 10-3/16" x H: 3/16" l Ship Wt: 1 lb.
OCR250: Cooling Rack for 1 4 Size Pans
l Fits standard 1/4 size sheet pans (pans not included) l Chrome w/black rubber eet
l Holds 3 standard sheet pans l Unit: W: 14" x D: 10-11/16" x H: 6"
l Ship Wt: 1 lb.
XC651: Stacking Kit for Half Size XAF Ovens
(Models XAF-111, XAF-113, XAF-115, XAF-130, XAF-133, XAF-135)
l Ship Wt: 20 lbs.
STACKING KITS:
(Maximize floor and counterspace; for LineChefTM XAF Series Ovens only)
l Designed or LineChe
TM
XAF series ovens only. Everything needed to securely stack one
XAF oven on top o another and protect the top ovens control panel rom heat rising rom
bottom oven
l Each kit includes: Four special oven legs (2-3/4 high) or the top oven, one heat ba le
(protects top ovens control panel rom heat rom bottom oven), one bottom oven vent
extension, and all needed brackets, screws & clamps.
XC655: Portable Water Tank
(for XAF ovens w Pump kit)
l Unit: W: 18" x D: 8" x H: 6" l Ship Wt: 5 lbs.
NEW
XC660: Electrovalve Kit
l Water Electrovalve Kit or Hal Size Digital Dynamic ovens (XAF-115 & XAF-135),
to connect the oven to a water supply
l Ship Wt: 5 lbs.
NEW
XC615: Water Connection Kit for Multiple Digital Dynamic Ovens
l Hose & connector to connect two stacked XAF Digital Dynamic Ovens or sharing water
hookup
l Ship Wt: 5 lbs.
NEW
OV350CB: Carry Bag (for OV-013 & OV-350 Ovens)
l Designed to it OV-013 & OV-350 Ovens
l Per ect or carrying OV-013 & OV-350 ovens to catering jobs!
l Black, heavy-duty nylon material l Sturdy 15 high carry straps
l Unit Dimensions: W: 25" x D: 24" x H: 16" l Ship Wt: 3 lb.
NEW
NEW
List Price $30.00
List Price $35.00
List Price $15.00
List Price $100.00
List Price $400.00
List Price $500.00
List Price $230.00
List Price $276.00
List Price $70.00

12
MOBILE BUFFET WARMING CARTS
Dimensions listed are for the assembled piece of equipment without shipping carton. Shipping weights are for equipment packed in shipping carton.
CBC-3RT CBC-4RT
UL Safety & Sanitary C-UL
NEW
NEW
(See page 16 for more accessories for all Buffet Server/Warmer models)
l Foods should be ully cooked and already hot be ore being placed in/on Warming Carts:
designed or keep-warm unction only.
l Carts ship pre-assembled except or wheels & skirt
l One year warranty on carts; 30 day initial de ect warranty only on skirts l PATENT PENDING
CBC-4RT: Jumbo Buffet Warming Cart w Clear Rolltop Lids, stainless
l Four half size stainless steam pans l Two clear polycarbonate rolltop lids l High rolltop lids accessible from front & back
l Half size steam pans hold over 30 four oz. servings ea. l Two steam pan holders attach securely to cart
l Stainless tops (pan holders & pans) removable; can use top level of cart as warming tray
l Grand size cart with extra large 46 x 18 stainless top warming sur ace (active heat area: 43 x 15)
l Two variable heat controls (one per side) - 155o to 205o F l Two sa ety signal lights
l Two lower storage shelves l 2 wheels with brakes; 2 wheels without l Handles on both ends o cart
l Removable black, heavy-duty ire retardant skirting on 3 sides; attaches with included Velcro
l Electrical: 120 volts / 600 watts / 5 amps / single phase l 3-prong commercial SJTO cordset
l 72 (6) long cord l Freight class 85; NOT UPS-able, must ship by truck
Width
52-3/4
H
eight
45
1/2 
Depth
18 1/2 
Ship Wt.*
101 lbs.
CBC-5RT: Grand Buffet Warming Cart w Clear Rolltop Lids, stainless
Same as CBC-4RT, except:
l Two half size stainless steam pans & three third size stainless steam pans,
plus two clear polycarbonate high rolltop lids
l Half size steam pans hold over 30 four oz. servings ea.
l Third size steam pans hold over 20 four oz. servings ea.
CBC-2RT: Double Buffet Warming Cart w Clear Rolltop Lids, stainless
l Two half size stainless steam pans l One clear polycarbonate high rolltop lid, accessible from front & back
l Steam pan holder attaches securely to cart l Half size steam pans hold over 30 four oz. servings ea.
l Stainless top (pan holder & pans) removable; can use top level of cart as warming tray
l Standard size cart with large 25-1/8 x 18 stainless top warming sur ace (active heat area: 22-1/8 x 15)
l Two lower storage shelves l 2 wheels with brakes; 2 wheels without l 72 (6) long cord
l Variable heat control - 155o to 205o F l Sa ety signal light l Freight class 85; UPS-able
l Removable black, heavy-duty ire retardant skirting on 3 sides; attaches with included Velcro
l Electrical: 120 volts / 300 watts / 2.5 amps / single phase l 3-prong commercial SJTO cordset
CBC-3RT: Triple Buffet Warming Cart w Clear Rolltop Lids, stainless
Same as CBC-2RT, except:
l Three third size stainless steam pans l One clear polycarbonate high rolltop lid
l Third size steam pans hold over 20 four oz. servings ea.
Width
29
H
eight
45
1/2 
Depth
18 1/2 
Ship Wt.
67 lbs.
Width
29
H
eight
45
1/2 
Depth
18 1/2 
Ship Wt.
67 lbs.
(CBC-4RT
shown without skirt)
S-GC: Grand Cart Replacement Skirt
l Drapes front and sides of grand size Cadco cart; attaches with included Velcro strips
Cart skirt
is open
at back for
easy access
to lower
shelves
S-SC: Standard Cart Replacement Skirt
l Drapes front and sides of standard size Cadco cart; attaches with included Velcro strips
Keep prepared food warm until ready to serve!
Width
52-3/4
H
eight
45
1/2 
Depth
18 1/2 
Ship Wt.*
100 lbs.
* does not include weight o shipping skid
* does not include weight o shipping skid
(CBC-3RT
shown)
Each cart
has two
lower
stainless
storage shelves
List Price $1,400.00
List Price $900.00
List Price $900.00
List Price $200.00
List Price $100.00
List Price $1,400.00

13
Dimensions listed are for the assembled piece of equipment without shipping carton. Shipping weights are for equipment packed in shipping carton.
WARMING CABINETS & BUFFET SERVERS
UL Safety & Sanitary C-UL
CMLW-CSG: Warming Cabinet w Sneeze Guard
& Warming Shelf Top, stainless
l Warming cabinet with clear polycarbonate sneeze guard over
top level warming shelf
Keep prepared food warm until ready to serve!
l Foods should be ully cooked and already hot be ore being placed in/on Warming Cabinets:
designed or keep-warm unction only.
Features of Cadco Warming Cabinet Buffet Servers Models On This Page:
l Large 28 x 14 stainless warming surface on top level
l Lower cabinet may be used as a food plate warmer (plates/pans not included unless indicated)
l Two variable heat controls - 155o to 205o F: one operates cabinet and the other operates top warming shel
l Electrical: 120 volts / 600 watts / 5 amps / single phase l UL Sa ety & Sanitary, C-UL l PATENT PENDING
l Doors included l Sa ety signal lights l Where included, hal size steam pans hold over 30 our oz. servings ea.
l Where included, third size steam pan holds over 20 our oz. servings l 4 non-skid eet l Freight class 85
NEW
CMLB-C2RT: Warming Cabinet w Buffet Server
w Low Profile Roll-top Lid, stainless
l Warming cabinet with two half size stainless steam pans
l One clear polycarbonate low-profile rolltop lid
l Half size steam pans will hold over 30 four oz. servings ea.
l One large stainless steam pan holder
l Stainless top removable; can use top level as warming shelf
Width
28
Height
167/8
Depth
151/4
Ship Wt.
42 lbs.
NEW
CMLB-CSG: Warming Cabinet w Sneeze Guard
& Buffet Server Top, stainless
l Warming cabinet with clear polycarbonate sneeze guard over
top level warming shelf
l Two half size stainless steam pans &
one third size stainless steam pan
l One large stainless steam pan holder
l Stainless top removable; can use top level as warming tray
Width
28
Height
221/2
Depth
181/4
Ship Wt.
48 lbs.
CMLB-CSLP: Warming Cabinet w Buffet Server
w Clear Lids, stainless
l Warming cabinet with two half size stainless steam pans &
one third size stainless steam pan
l Three clear polycarbonate lids with utensil slots
l Half size steam pans will hold over 30 four oz. servings ea.
l Third size steam pan will hold over 20 four oz. servings
l One large stainless steam pan holder
l Stainless top removable; can use top level as warming shelf
Width
28 
Height
14
Depth
151/4
Ship Wt.
40.25 lbs.
NEW
NEW
Width
28
Height
221/2
Depth
181/4
Ship Wt.
42 lbs.
(Ships in 2 cartons)
(Ships in 2 cartons)
(See page 16
for more
accessories for
all Buffet
Server/Warmer
models)
(Also available; not shown) CMLW-C: Warming
Cabinet w Warming Shelf Top, stainless
l Warming cabinet with top level warming shelf
Width
28
Height
87/8
Depth
151/4
Ship Wt.
32 lbs.
(Ships in 2 cartons)
List Price $550.00
List Price $500.00
List Price $600.00
List Price $500.00
List Price $400.00

14
WTBS-2P: Double Buffet Server w Clear Lids, stainless
l Two half size stainless steam pans l Two clear polycarbonate lids with utensil slots
l Stainless steam pan holder l Each steam pan will hold over 30 four oz. servings
l Stainless top removable; can use base as warming tray
l Large 201/2 x 14 stainless warming sur ace
l Variable heat control - 155o to 205o F l Cool-touch handles
l Sa ety signal light l 4 non-skid eet l Freight class 85
l Electrical: 120 volts / 300 watts / 2.5 amps / single phase
ELECTRIC CHAFERS BUFFET SERVERS
UL Safety & Sanitary
C-UL
WTBS-2: Double Buffet Server, stainless
Same as WTBS-2P, except with stainless steel lids
WTBS-3: Triple Buffet Server, stainless
Same as WTBS-3P, except with stainless steel lids
(See page 16 for more accessories for all Buffet Server models)
Width
26
Height
77/8
Depth
151/4
Ship Wt.
17.65 lbs.
Width
26
Height
65/8
Depth
151/4
Ship Wt.
18.25 lbs.
Width
26
Height
77/8
Depth
151/4
Ship Wt.
17.45 lbs.
Width
26
Height
65/8
Depth
151/4
Ship Wt.
17.75 lbs.
CMLB-24P: Multi-Level Buffet Server w Clear Lids, stainless
l Two-level warming tray: two large 20-1 2 x 14 stainless warming surfaces
l Four half size stainless steam pans with clear polycarbonate lids with utensil slots
l Each steam pan will hold over 30 four oz. servings l Two stainless steam pan holders
l Steam pan holders removable; can use bases as warming trays
l Control knobs and signal lights on back o unit;
top & bottom levels controlled separately
l Variable heat control - 155o to 205o F
l 4 non-skid eet l Freight class 85
l Electrical: 120 volts / 600 watts / 5 amps / single phase
CMLB-24RT: Multi-Level Buffet Server w Clear Low-Profile Rolltop
Lids, stainless
l Two-level warming tray: two large 20-1 2 x 14 stainless warming surfaces
l Four half size stainless steam pans l Two clear polycarbonate low-profile rolltop lids
l Each steam pan will hold over 30 four oz. servings l Two stainless steam pan holders
l Steam pan holders removable; can use bases as warming trays
l Control knobs and signal lights on back o unit;
top & bottom levels controlled separately
l Variable heat control - 155o to 205o F
l 4 non-skid eet l Freight class 85
l Electrical: 120 volts / 600 watts / 5 amps / single phase
Dimensions listed are for the assembled piece of equipment without shipping carton. Shipping weights are for equipment packed in shipping carton.
WTBS-3RT: Triple Buffet Server w Clear Low-Profile Rolltop Lid, stainless
l Three third size stainless steam pans l Clear polycarbonate low-profile rolltop lid
l Stainless steam pan holder l Each steam pan will hold over 20 four oz. servings
l Stainless top removable; can use base as warming shelf
l Large 201/2 x 14 stainless warming sur ace
l Variable heat control - 155o to 205o F l Cool-touch handles
l Sa ety signal light l 4 non-skid eet l Freight class 85
l Electrical: 120 volts / 300 watts / 2.5 amps / single phase
Width
26
Height
111/4
Depth
151/4
Ship Wt.
24.3 lbs.
NEW
WTBS-3P: Triple Buffet Server w Clear Lids, stainless
l Three third size stainless steam pans l Three clear polycarbonate lids with utensil slots
l Stainless steam pan holder l Each steam pan will hold over 20 four oz. servings
l Stainless top removable; can use base as warming shelf
l Large 201/2 x 14 stainless warming sur ace
l Variable heat control - 155o to 205o F l Cool-touch handles
l Sa ety signal light l 4 non-skid eet l Freight class 85
l Electrical: 120 volts / 300 watts / 2.5 amps / single phase
Width
231/4
Height
203/4
Depth
151/4
Ship Wt.
43 lbs.
Width
231/4
Height
24
Depth
151/4
Ship Wt.
44 lbs.
NEW
WTBS-2RT: Double Buffet Server w Clear Low-Profile Rolltop Lid, stainless
l Two half size stainless steam pans l Clear polycarbonate low-profile rolltop lid
l Stainless steam pan holder l Each steam pan will hold over 30 four oz. servings
l Stainless top removable; can use base as warming shelf
l Large 201/2 x 14 stainless warming sur ace
l Variable heat control - 155o to 205o F l Cool-touch handles
l Sa ety signal light l 4 non-skid eet l Freight class 85
l Electrical: 120 volts / 300 watts / 2.5 amps / single phase
Width
26
Height
111/4
Depth
151/4
Ship Wt.
23.5 lbs.
NEW
List Price $310.00
List Price $290.00
List Price $290.00
List Price $310.00
List Price $330.00
List Price $750.00
List Price $700.00
List Price $310.00

15
Dimensions listed are for the assembled piece of equipment without shipping carton. Shipping weights are for equipment packed in shipping carton.
LARGE ELECTRIC CHAFERS BUFFET SERVERS
(See page 16 for more accessories
for all Buffet Server models)
WTBS-4RT: Jumbo Buffet Server w Clear Low-profile Rolltop Lids, stainless
l Four half size stainless steam pans l Two clear polycarbonate low-profile rolltop lids
l Each steam pan will hold over 30 four oz. servings
l Two stainless steam pan holders l Stainless top removable; can use base as warming shelf
l Extra large 41-1/4 x 14 stainless warming sur ace l Two variable heat controls - 155o to 205o F l Cool-touch handles
l Sa ety signal light l 4 non-skid eet l Freight class 85 l Electrical: 120 volts / 600 watts / 5 amps / single phase
Width
46
Height
111/4
Depth
151/4
Ship Wt.
42 lbs.
WTBS-5RT: Grand Buffet Server w Clear Low-profile Rolltop Lids, stainless
l Two half size stainless steam pans & three third size stainless steam pans l Two clear polycarbonate low-profile rolltop lids
l Half size steam pans will hold over 30 four oz. servings ea. l Third size steam pans will hold over 20 four oz. servings ea.
l Two stainless steam pan holders l Stainless top removable; can use base as warming shelf
l Extra large 41-1/4 x 14 stainless warming sur ace l Two variable heat controls - 155o to 205o F l Cool-touch handles
l Sa ety signal light l 4 non-skid eet l Freight class 85 l Electrical: 120 volts / 600 watts / 5 amps / single phase
NEW
WTBS-5P: Grand Buffet Server w Clear Lids, stainless
l Two half size stainless steam pans & three third size stainless steam pans, all with clear polycarbonate lids with utensil slots
l Half size steam pans will hold over 30 four oz. servings ea. l Third size steam pans will hold over 20 four oz. servings ea.
l Two stainless steam pan holders l Stainless top removable; can use base alone as warming shelf
l Extra large 41-1/4 x 14 stainless warming sur ace l Variable heat control - 155o to 205o F l Cool-touch handles
l Sa ety signal light l 4 non-skid eet l Freight class 85 l Electrical: 120 volts / 600 watts / 5 amps / single phase
Width
46
Height
77/8
Depth
151/4
Ship Wt.
33 lbs.
WTBS-4: Jumbo Buffet Server, stainless
l Four half size stainless steam pans with stainless lids l Each steam pan will hold over 30 four oz. servings
l Two stainless steam pan holders l Stainless top removable; can use base as warming shelf
l Extra large 41-1/4 x 14 stainless warming sur ace l Variable heat control - 155o to 205o F l Cool-touch handles
l Sa ety signal light l 4 non-skid eet l Freight class 85 l Electrical: 120 volts / 600 watts / 5 amps / single phase
Width
46
Height
65/8
Depth
151/4
Ship Wt.
33.4 lbs.
WTBS-4P: Jumbo Buffet Server w Clear Lids, stainless
l Four half size stainless steam pans with clear polycarbonate lids and two steam pan holders l Lids have utensil slots
l Each steam pan will hold over 30 four oz. servings l Stainless top removable; can use base as warming shelf
l Extra large 41-1/4 x 14 stainless warming sur ace l Variable heat control - 155o to 205o F l Cool-touch handles
l Sa ety signal light l 4 non-skid eet l Freight class 85 l Electrical: 120 volts / 600 watts / 5 amps / single phase
Width
46
Height
77/8
Depth
151/4
Ship Wt.
32.8 lbs.
Width
46
Height
111/4
Depth
151/4
Ship Wt.
41 lbs.
UL Safety & Sanitary
C-UL
NEW
Ships in 2 cartons)
Ships in 2 cartons)
List Price $660.00
List Price $620.00
List Price $620.00
List Price $620.00
List Price $660.00

16
Dimensions listed are for the assembled piece of equipment without shipping carton. Shipping weights are for equipment packed in shipping carton.
BUFFET SERVER & WARMING SHELF ACCESSORIES
Use these Accessories for WT-100, WT-10S and WT- 40S Warming Trays to build your own Buffet Server.
CMLW-2: Multi-Level Warming Shelves, stainless
l Two-level warming tray: two large 20-1 2 x 14 stainless warming surfaces
l Control knobs and signal lights on back o unit;
top & bottom levels controlled separately
l Variable heat control - 155o to 205o F
l 4 non-skid eet l Freight class 85
l Electrical: 120 volts / 600 watts / 5 amps / single phase
Width
231/4
Height
161/4
Depth
151/4
Ship Wt.
28 lbs.
WARMING SHELVES
l Extra-large 41-1 4 x 14 warming surface (Fits 4 half size, six 1 3 size, or two full size steam table pans (not included)
l Two variable heat controls - 155o to 205o F l Easy-to-clean stainless steel sur ace l Two sa ety signal lights
l 4 non-skid eet l Freight class 85 l Electrical: 120 volts/600 watts/5 amps/single phase
WT-100: Countertop Warming Shelf, black
l Large 20-1 2 x 14 warming surface
l Variable heat control - 155o to 205o F
l Easy-to-clean black porcelain warming sur ace
l Sa ety signal light l 4 non-skid eet l Freight class 85
l Electrical: 120 volts/300 watts/2.5 amps/single phase
WT-10S: Countertop Warming Shelf, stainless
Same as WT-100 except:
l Easy-to-clean stainless steel warming sur ace
UL Safety & Sanitary C-UL
Width
26
Height
27/8
Depth
151/4
Ship Wt.
8.6 lbs.
Width
46
Height
27/8
Depth
151/4
Ship Wt.
17.5 lbs.
WT-40S: Large Countertop Warming Shelf, stainless
WT-5S: Small Countertop Warming Shelf, stainless
l 13-1 4 x 14 warming surface
l Variable heat control - 155o to 205o F
l Easy-to-clean stainless steel warming sur ace
l Sa ety signal light l 4 non-skid eet l Freight class 85
l Electrical: 120 volts/300 watts/2.5 amps/single phase
Width
18
Height
3
Depth
151/4
Ship Wt.
7.2 lbs.
NEW
PS-TBS CL-3 CL-2 SPL-2SPL-3SPL-2PSPL-3P ITBS-3P ITBS-2P
All Accessories:
UL Safety & Sanitary
W: 211/8 x H: 5 x D: 131/8, Total Ship Wt.: 3 lbs.
PS-TBS: Steam Pan Holder Accessory
l Accessory or WT-10S and WT-40S Warming Trays l Stainless steel l Two #PS-TBS will it on # WT-40S Large Warming Tray
l Holds 3 third size, 2 hal size, or one ull size 2-1/2 deep steam pans (not incl.) on WT-10S warming sur ace or optimum heat retention
W: 203/4 x H: 21/2 x D: 141/4, Ship Wt.: 3 lbs.
CL-3: Third Size Clear Lids Accessory Pack
l Three clear polycarbonate lids or third size steam pans Three lids, Each lid W: 127/8 x H: *21/2 x D: 7 , Total Ship Wt.: 2.2 lbs.
CL-2: Half Size Clear Lids Accessory Pack
l Two clear polycarbonate lids or hal size steam pans Two lids, Each lid W: 127/8 x H: *21/2 x D: 101/2, Total Ship Wt.: 2 lbs.
SPL-3P: Third Size Steam Pan with Clear lid
l One third size (2-1/2 deep) stainless steam pan w/clear lid W:127/8 x H: 5 x D: 7, Ship Wt.: 1.8 lbs.
SPL-2P: Half Size Steam Pan with Clear lid
l One hal size (2-1/2 deep) stainless steam pan w/clear lid W:127/8 x H: 5 x D: 101/2, Ship Wt.: 2 lbs.
SPL-3: Third Size Steam Pan with Stainless Lid
l One third size (2-1/2 deep) stainless steam pan w/ stainless lid / NSF W:123/4 x H: *33/4 x D: 7, Ship Wt.: 2 lbs.
*Heights o models with stainless lids include knobs
SPL-2: Half Size Steam Pan with Stainless Lid
l One hal size (2-1/2 deep) stainless steam pan w/ lid / NSF
W:123/4 x H: *33/4 x D: 101/2, Ship Wt.: 2.5 lbs.
ITBS-3P: Third Size Accessory Pack with Clear Lids
l 3 third size (2-1/2 deep) stainless steam pans w/clear lids + S team Pan Holder
W: 203/4 x H: 5 x D: 141/4, Ship Wt.: 7.25 lbs.
ITBS-2P: Half Size Accessory Pack with Clear Lids
l 2 hal size (2-1/2 deep) stainless steam pans w/ clear lids + Steam Pan Holder
W: 203/4 x H: 5 x D: 141/4, Ship Wt.: 6.85 lbs.
C-DPF1: Clear Low-profile Rolltop Lid
l Fits on PS-TBS; its over 3 third size or 2 hal size 2-1/2 deep steam pans (not incl.)
C-DPF1
List Price $160.00
List Price $180.00
List Price $320.00
List Price $150.00
List Price $600.00
List Price $50.00
List Price $50.00
List Price $40.00
List Price $40.00
List Price $40.00
List Price $50.00
List Price $40.00
List Price $50.00
List Price $160.00
List Price $140.00

17
Dimensions listed are for the assembled piece of equipment without shipping carton. Shipping weights are for equipment packed in shipping carton.
PJC20: Professional Manual Juicer, chrome
l Quickly and easily extracts juice rom oranges, lemons, limes and small grape ruits
l Up to 1,000 PSI o pressure or e icient juice extraction
l Stainless steel strainer and cone or quick, easy cleanup
l Chrome plating over zinc or durability
l One step juicing lever l Rubber eet or countertop stability
l Height o unit is 20-1/4 closed and 28 open
PROFESSIONAL MANUAL JUICER
Width
8
Height
28
Depth
9
Ship Wt.
13 lbs.
KETTLES & WELL WARMERS
SKC-1: Copper Soup Kettle
l High wattage (950 watt) cooker warmer l Generous 3 gallon capacity l 12 heat settings
l Wet or dry operation l Gleaming copper base and collar
l Stainless hinged lid and liner
l Cast aluminum inner water holder
l Electrical: 120 volts/950 watts/8.0 amps/single phase
l Freight class 85
FS-10C: Countertop Food Steamer
l Stainless electric steamer - holds up to 24 quarts of food
l Stainless steel steam basket with cool-touch handles makes it easy to remove
basket rom steam chamber
l Removable steam basket divider; keeps di erent oods separate while steaming
l Stainless steel lid with cool-touch knob
l Cool-touch handles on unit and steam basket
l Adjustable thermostat up to 212°F/100°C
l Wet operation only l Power light
l 3-prong commercial cordset
l Freight class 85
l Electrical: 120 volts / 1,600 watts / 13.4 amps
ETL NSF
FOOD STEAMER
Width
121/2
Height
15
Depth
121/2
Ship Wt.
18 lbs.
Width
19
Height
193/4
Depth
151/2
Ship Wt.
20.5 lbs.
DWW-11: Double Well Warmer, stainless
Same as DWW-3P except:
l Electrically heated warmer with 9 quart capacity
in each well (18 quarts total)
l Two stainless well inserts with hinged covers
Width
133/8
Height
135/8
Depth
237/8
Ship Wt.
30 lbs.
Width
133/8
Height
121/2
Depth
237/8
Ship Wt.
27 lbs.
DWW-3P: Triple Well Warmer w Clear Lids, stainless
l Electrically heated warmer with 5 quart capacity in each well steam pan (15 quarts total)
l Three 1/3 size, 6" deep stainless steam pans with clear polycarbonate lids
l Lids have utensil slots l Stainless steel inner water holder
l Sa ety water drain spigot l Polished stainless inish
l 13 heat settings: 104o - 212oF (40o-100oC)
l Wet operation use only l ETL, NSF, CETL l Freight class 85
l Electrical: 120 volts/1200 watts/10 amps/single phase
Width
133/8
Height
121/2
Depth
237/8
Ship Wt.
28 lbs.
DWW-2P: Double Well Warmer w Clear Lids, stainless
l Electrically heated warmer with 9 quart capacity in each well steam pan (18 quarts total)
l Two 1/2 size, 6" deep stainless steam pans with clear polycarbonate lids
l Lids have utensil slots l Stainless steel inner water holder
l Sa ety water drain spigot l Polished stainless inish
l 13 heat settings: 104o - 212oF (40o-100oC)
l Wet operation use only l ETL, NSF, CETL l Freight class 85
l Electrical: 120 volts/1200 watts/10 amps/single phase
List Price $1,300.00
List Price $420.00
List Price $190.00
List Price $400.00
List Price $400.00
List Price $420.00

18
Dimensions listed are for the assembled piece of equipment without shipping carton. Shipping weights are for equipment packed in shipping carton.
Our Panini Grills & FTCG-200 Griddle are made to Cadco Ltd. specifications by UNOX S.p.A.
l NSF, UL through CSA Standards
Model No. Cross Reference: FTCG-200 = UNOX XAP 200; CPG-10 = UNOX XAP 010R, CPG-10F = UNOX XAP 010,
CPG-20 = UNOX XAP 020PR, CPG-20F = UNOX XAP 020P
FTCG-200: Glass-Ceramic Fry Top Griddle, stainless
Features fast heat-up and easy-clean surface
l Large 11 x 17-1/3 glass cooking sur ace
l Adjustable thermostat up to 700 ° F; ast heat-up
l Not intended or all-day use.
l Large pull-out grease tray
l Easy-clean sur ace l Special cleaning scraper included
l Freight class 85 l UL, C-UL, NSF
l NEMA 6-15P Plug
l Electrical: 208/240 volts/2500 watts/11.4 amps
PANINI CLAMSHELL GRILLS
UL C-UL NSF
GRIDDLES
PCG-10C: Griddle, charcoal stainless
erfect for Caterers, Concessionaires, + other 120V Applications!
l Large, heavy cast cooking area : 21 x 12
l Charcoal grey, high-tech, non-stick commercial cooking sur ace
l Even heat up to 425° F l Removable stainless steel splash guard
l Cool-touch stainless steel handles l Base immersible or easy cleaning
l Large stainless steel removable grease tray
l 3-prong commercial SJTO cordset
l Freight class 85 l UL Sa ety & Sanitary
l Electrical: Standard voltage or maximum lexibility:
120 volts -1500 watts - 12.5 amps
CPG-10: Single Panini Clamshell Grill, stainless
l One 9-7/8 x 9-7/8 grilling area
l High-tech glass grill surface: ribbed top plate & smooth bottom plate
l Ribbed top plate or appetizing grill marks on ood
l Adjustable thermostat up to 700 ° F
l Power light l 4 non-skid eet l Cool-touch handles
l Easy to clean stainless steel housing
l Ribbed top plate easily cleaned with special brass wool
supplied with unit l Cleaning scraper included
l Freight class 85 l UL, C-UL, NSF
l NEMA 5-15P Plug l 120 volts / 1500 watts / 12.5 amps
NEMA 5-15P Plug
CPG-20: Double Panini Clamshell Grill, stainless
l Two 9-7/8 x 9-7/8 grilling areas
l High-tech glass grill surface: ribbed top plate & smooth bottom plate
l Ribbed top plate or appetizing grill marks on ood
l Adjustable thermostat up to 700 ° F
l Power light l 4 non-skid eet l Cool-touch handles
l Easy to clean stainless steel housing
l Ribbed top plate easily cleaned with special brass wool
supplied with unit l Cleaning scraper included
l Freight class 85 l UL, C-UL, NSF l NEMA 6-15P Plug
l Electrical: 208/240 / 3200 watts / 14.5 amps
NEMA 6-15P Plug
NEMA 6-15P Plug
Glass-Ceramic anini Grills feature fast heat-up and easy-clean surfaces
CPG-10F: Single Panini Clamshell Grill, stainless
Same as CPG-10 except:
l High-tech glass grill surface has smooth top
and bottom plates/ no ribbed plates
CPG-20F: Double Panini Clamshell Grill, stainless
Same as CPG-20 except:
l High-tech glass grill surfaces have smooth top
and bottom plates/ no ribbed plates
Width
13
Height
7
Depth
18
Ship Wt.
22 lbs.
Width
24
1/3 
Height
7
Depth
18
Ship Wt.
37.5 lbs.
Width
29
Height
5
1/2 
Depth
12 1/2 
Ship Wt.
13.25 lbs.
Width
15
3/4 
Height
5
Depth
25 1/4 
Ship Wt.
22 lbs.
List Price $1,260.00
List Price $2,150.00
List Price $200.00
List Price $1,090.00
List Price $1,260.00
List Price $2,150.00

19
Dimensions listed are for the assembled piece of equipment without shipping carton. Shipping weights are for equipment packed in shipping carton.
HOT PLATES PORTABLE RANGES
Width
191/4
Height
21/2
Depth
11
Ship Wt.
13 lbs.
BRC-S1: Light Duty Single Burner Buffet Range, chrome
l Industrial rated single burner with 5-1 2 diameter high speed tubular element
l In inite heat control l Easy-to-clean chrome sur ace
l Adjustable leg or leveling unit on countertop
l Compact to it in the smallest o areas
l Electrical: 120 Volts/1100 Watts/9.0 Amps/ single phase
l UL Sa ety & Sanitary/C-UL l Freight class 85
Width
111/2
Height
31/2
Depth
111/2
Ship Wt.
5.3 lbs.
BRC-D1: Light Duty Double Burner Buffet Range, chrome
l Two industrial rated burners with 5-1 2 diameter high speed tubular elements
l Two in inite heat controls
l Adjustable leg or leveling unit on countertop
l Easy-to-clean chrome sur ace
l Electrical: 120 Volts/1650 Watts/13.8 Amps/ single phase
l UL Sa ety & Sanitary/C-UL l Freight class 85
Width
171/2
Height
31/2
Depth
111/2
Ship Wt.
7.7 lbs.
DKR-S2: Double Cast Iron Range, stainless
l Two cast iron elements: 7-3 8 dia. = 1,000w; 6 dia. = 650w
l Signal lights glow only during heat cycle
l Easy-to clean stainless housing
l In inite heat controls or each burner
l Electrical: 120 Volts/1650 Watts/13.8 Amps/ single phase
l UL Sa ety & Sanitary/C-UL l Freight class 85
Width
12
Height
3
Depth
161/4
Ship Wt.
8.0 lbs.
PHR-1C: Glass-Ceramic Range, stainless
l Power-saving two-circle heat technology, allows or 5.5 diameter / 600 watt heating zone
or an extra-large 8.25 diameter/ 1500 watt heating zone, matching heat zone to pot/pan size
l Fast heat-up / ast heat o l In inite heat control l Sleek glass cooking sur ace
l Brushed stainless steel housing l Contemporary styling / low silhouette or countertop stability
l Power light l Residual heat sa ety light
l Electrical: 120 volts -1500 watts (8.25 heating zone) /
600 watts (5.5 heating zone) /12.5 amps
l CSA to UL Standards l Freight class 85
Width
12
Height
3
Depth
161/4
Ship Wt.
8.0 lbs.
NEW
KR-1: Portable Cast Iron Range, black
l 7-1 8 diameter cast iron element
l Signal light glows only during heat cycle
l Easy-to clean black enamel housing l In inite heat control
l Electrical: 120 Volts/1500 Watts/12.5 Amps/ single phase
l UL Sa ety & Sanitary/C-UL l Freight class 85
Width
111/2
Height
3
Depth
14
Ship Wt.
8.8 lbs.
KR-S2: Portable Cast Iron Range, stainless
l 7-1 8 diameter cast iron element
l Signal light glows only during heat cycle
l Easy-to clean stainless housing l In inite heat control
l Electrical: 120 Volts/1500 Watts/12.5 Amps/ single phase
l UL Sa ety & Sanitary/C-UL l Freight class 85
Width
111/2
Height
3
Depth
14
Ship Wt.
8.8 lbs.
LKR-220: Large Cast Iron Heavy Duty Range, stainless
l 9 diameter cast iron element handles pots pans up to 15 qt.
l Large base creates stability l In inite heat control
l Signal light glows only during heat cycle
l Easy-to clean stainless housing l NEMA 6-15P plug
l Electrical: 220 Volts - 2000 Watts - 9.1 Amps/ single phase
l UL Sa ety & Sanitary/C-UL l Freight class 85
Width
153/8
Height
43/8
Depth
151/2
Ship Wt.
13 lbs.
NEW
BIR-1C: Buffet Induction Range, stainless
l No preheat - immediate power fast heat off
l SCHOTT CERAN® glass-ceramic cooking surface
l Pot recognition: Heats only within pot/pan circum erence or maximum energy e iciency
l Requires lat-bottomed pot/pan made o cast iron, enameled steel, or stainless steel.
(Check with magnet) l Handles pot/pans with 3-5/32 _ 10-1/4 diameter
l Contemporary styling with low silhouette or countertop bu et use l Freight class 85
l Electronic controls with audible acknowledgement signals
l Brushed stainless steel housing l 3 prong commercial cordset
l Control cooking with power level OR temperature level
l Temperatures rom 160°F - 450°F l 1-99 minute timer
l Power light l Residual heat sa ety light over 160°F
l Electrical: 120 volts -1400 watts - 11.7 amps l ETL Listed
220 V
List Price $230.00
List Price $98.00
List Price $140.00
List Price $650.00
List Price $350.00
List Price $175.00
List Price $195.00
List Price $300.00

20
CTW-4M: Mica 4-slot Toaster, stainless metallic grey
l Heavy duty KoverTec mica heating elements with two year warranty
l 1 x 5 x 5 slots l Selector switch or 2 or 4 slot operation.
l Manual timer control l Manual ejector with keep-warm eature
l Pull-out crumb tray or easy cleaning
l Stainless with metallic grey end panels l Freight class 85
l Electrical: 120 volts/1745 watts/14.5 amps/single phase
also available:
CTW-4M(208): 208 volts/2080 watts/10.0 amps
CTW-4M(220): 220 volts/2350 watts/10.6 amps/no plug
CTS-4: Mica 4-slot Toaster, Stainless Plus
l Heavy duty KoverTec mica heating elements with two year warranty
l 1 x 5 x 5 slots l Selector switch or 2 or 4 slot operation.
l Manual timer control l Manual ejector with keep-warm eature
l Pull-out crumb tray or easy cleaning l Freight class 85
l Stainless with heavy duty aluminum end panels
l Electrical: 120 volts/1745 watts/14.5 amps/single phase
also available:
CTS-4(208): 208 volts/2080 watts/10.0 amps
CTS-4(220): 220 volts/2350 watts/10.6 amps/no plug
TOASTERS
UL NSF CSA
atented KoverTec
TM
Elements
CBF-4M: 4-slot Buffet Toaster, stainless metallic grey
l Heavy duty KoverTec mica heating elements with two year warranty
l Designed for Hotel Self-Service Areas
l Two manual timer controls for independent 2-slot operation
l Two manual ejectors with keep-warm feature
l 1 x 5 x 5 slots it standard size bagels
l Pull-out crumb tray or easy cleaning
l Stainless with metallic grey end panels l Freight class 85
l Electrical: 120 volts/1750 watts/14.5 amps/single phase
CTW-6M: 6-slot Toaster, stainless metallic grey
l Heavy duty KoverTec mica heating elements with two year warranty
l 1 x 5 x 5 slots it standard size bagels l Selector switch or 2, 4, or 6 slot operation
l Manual timer control l Manual ejector with keep-warm eature
l Pull-out crumb tray or easy cleaning
l Stainless with metallic grey end panels l Freight class 85
l Electrical: 208 volts/2225 watts/10.7 amps/single phase
also available:
CTW-6M(220): 220 volts/2480 watts/11.3 amps/no plug
Dimensions listed are for the assembled piece of equipment without shipping carton. Shipping weights are for equipment packed in shipping carton.
CTB-2: 2-slot Toaster, stainless black
CTW-2: 2-slot Toaster, stainless white
l Heavy duty KoverTec mica heating elements with two year warranty
l 1 x 5 x 5 slots l Selector switch or 1 or 2 slot operation
l Manual timer control l Manual ejector with keep-warm eature
l Pull-out crumb tray or easy cleaning
l Stainless with black end panels l Freight class 85
l Electrical: 120 volts/1250 watts/10.5 amps/single phase
CBT-2: 2-slot Bagel Toaster; stainless white
CBT-2B: 2-slot Bagel Toaster; stainless black
l Heavy duty KoverTec mica heating elements with two year warranty
l 1-1/4 x 5 x 5 slots it wider sized bagels
l Manual timer turns on both slots at once
l Manual ejector with keep-warm eature
l Pull out crumb tray or easy cleaning
l Freight class 85
l Electrical: 120 volts/1200 watts/10.0 amps/single phase
Width
15.5
Height
9
Depth
8
Ship Wt.
12 lbs.
Width
131/2
Height
9
Depth
8
Ship Wt.
10 lbs.
Width
131/2
Height
9
Depth
8
Ship Wt.
10 lbs.
Width
17
Height
9
Depth
8
Ship Wt.
12 lbs.
Width
11
Height
9
Depth
8
Ship Wt.
10 lbs.
Width
10
Height
9
Depth
8
Ship Wt.
8 lbs.
List Price $670.00
List Price $500.00
List Price $500.00
List Price $700.00
List Price $480.00
List Price $400.00
