Cadenceberge CAD-HV-HCA05 User manual

U S E R M A N U A L
4K HD Video Capture Box
Dual Mode
Model : CAD-HV-HCA05

Enjoy the vivid world!
Dear Customer
Thank you for purchasing this product. For optimum performance and safety, please read these instructions
carefully before connecting, operating or adjusting this product. Please keep this manual for future reference.
Features
1. 4K2K UHD Recording from DVD, OTT, Receiver, PC, PS and Xbox
2. Dual mode design, HD recording on external USB
storage (Standalone) and TF CARD or PC HDD
3. OSD control with multi-language
4. H.264 HD hardware encoding up to 1080P 30FPS
5. 2 Port HDMI input,1Port HDMI output,AV/L/R Cable
6. HDMI pass-through without latency

7. Recording data rate up to 16Mbits/sec in MP4 format
8. Recording audio via integrated microphone input
9. Support remote control (IR)
Specification
Bit rate
Bit rate Max: 16Mbps, default 10Mbps
Recording file size
Max 2GB, new recording file generated automatically after each 2GB recorded
Input
HDMI
Analog MMI (Component (YPbPr) + Composite (CVBS) + VGA)
MIC (Audio in) & Remote controller (IR in)
Output
HDMI
USB 2.0 storage (HDD & Pen drive)
Micro USB for PC connection
Support resolutions
Connection Diagram:
Loop Through Video Resolution
720*480(30p) , 720*480(60p) , 720*576(30p) , 720*576(60p)
1280*720(30p),1280*720(60p),1920*1080p(30p),1920*1080p(6
0p), 2560x1040, 4096x2160
Capture resolution
Up to 1080p@30fps

Interface
1. 2 HDMI input/output
2. CVBS / L/R/ Microphone input / Audio out
3. USB 2.0 external hard drive (IDE and SATA/2.5” & 3.5”/7200, 5400, 4200)
4. USB output to PC and TF Card
5. Power 5V/2A input
Package Content
1. UHD capture box
2. Remote control unit
3. HDMI cable
4. Micro USB to USB cable
5. AV/L/R Cable
6. Software DVD
7. Power Adapter 5V/2A
