CADnetwork Deep Learning Box Rack Manual
Technical Specification
Deep Learning Box Rack
Contents
Safety information..................................................................................................... iii
About this guide....................................................................................................... iv
Series specifications summary.................................................... v
Package contents..................................................................................................... vi
Installation tools and components..........................................................................vii
Chapter 1: Product Introduction
1.1 Motherboard overview............................................................................... 1-1
Chapter 2: Basic Installation
2.1 Building your PC system...........................................................................2-1
2.2 BIOS update utility................................................................................... 2-10
2.3 Motherboard rear and audio connections .............................................2-11
2.4 Starting up for the first time.................................................................... 2-15
2.5 Turning off the computer ........................................................................2-15
i
Safety information
Electrical safety
• To prevent electrical shock hazard, disconnect the power cable from the electrical outlet
•
•
•
•
• If the power supply is broken, do not try to x it by yourself. Contact a qualied service
Operation safety
•
•
•
•
•
• If you encounter technical problems with the product, contact a qualied service
v
Conventions used in this guide
DANGER/WARNING:
CAUTION:
IMPORTANT:
NOTE:
Typography
Bold text
v
Model Name
CPU
* The Intel®Turbo Boost & Hyper-Threading Technology 2.0 support depends
on the CPU types.
** Refer to www..com for Intel®CPU support list
Chipset
Memory
* Maximum memory capacity support depends on CPU type
** Refer to www..com for the Memory QVL (Qualified Vendors Lists).
Expansion slots
VGA
Multi-GPU support
* Actual numbers of Multi-graphic supported differs per Vendors’ Graphic
cards. Please check with Vendor beforehand.
Storage
Intel®C621 with Intel®RSTe(for Windows only; Support software
RAID 0, 1, 10 &5)
ASMedia®SATA RAID Controller*
* The functions will work depending on the CPU installed.
** H/W Key to be purchased separately, functions will depend on H/W Key
purchased
LAN
Series specifications summary
vi
Series specifications summary
Model Name
USB
ASMedia USB 3.1 Controllers
Intel®C621 Chipset
Audio
Realtek®ALC S1220A 8-Channel High Definition Audio CODEC
Audio Feature:
Workstation Unique
Features
* Due to limitations in HDA bandwidth, 32-Bit/192kHz is not supported for
8-Channel audio. 32-Bit/192kHz is only available under Windows®10.
v
Model Name
Rear Panel I/O Ports
Internal I/O
Connectors
specifications summary
v
Model Name
Special
Features
CPU Power
DRAM Power
Dual Front Panel USB 3.0 Support
Q-Design
EZ DIY
TPM header
UEFI BIOS
SafeSlot Designed
BIOS Features
Manageability
Operating System
Form Factor
specifications summary
ix
Package contents
x
Installation tools and components
PC chassis
Power supply unit
Intel®LGA3647 compatible CPU Fan
Intel®LGA3647 CPU
DIMM
SATA hard disk drive
Graphics card
Phillips (cross) screwdriver
SATA optical disc drive (optional)
1 bag of screws
Chapter 1
Product Introduction
Chapter 1: Product Introduction
•
•
•
•
•
1.1 Motherboard overview
1.1.1 Before you proceed
Chapter 1
1.1.9 Internal connectors2.3.1 Rear I/O connection
1.1.2 Motherboard layout
Chapter 1
Layout contents
Connectors/Jumpers/Buttons and switches/Slots Page
BMCconnector(14-1pinASMB9)(for(BMC)only)
Chapter 1
1.1.3 Central Processing Unit (CPU)
EnsurethatallpowercablesareunpluggedbeforeinstallingtheCPU.
Uponpurchaseofthemotherboard,ensurethatthePnPcapisonthesocketandthe
socketcontactsarenotbent.ContactyourretailerimmediatelyifthePnPcap
ismissing,orifyouseeanydamagetothePnPcap/socketcontacts/motherboard
components.willshoulderthecostofrepaironlyifthedamageisshipment/transit-
Keepthecapafterinstallingthemotherboard.willprocessReturnMerchandise
Authorization(RMA)requestsonlyifthemotherboardcomeswiththecaponthe
LGA3647socket.
Theproductwarrantydoesnotcoverdamagetothesocketcontactsresultingfrom
incorrectCPUinstallation/removal,ormisplacement/loss/incorrectremovalofthePnP
cap.
Chapter 1
1.1.4 System memory
Forsystemstability,useamoreefficientmemorycoolingsystemtosupportafull
memoryload(12DIMMs)oroverclockingcondition.
AlwaysinstalltheDIMMSwiththesameCASLatency.Foranoptimumcompatibility,
werecommendthatyouinstallmemorymodulesofthesameversionordatacode
(D/C)fromthesamevendor.Checkwiththevendortogetthecorrectmemory
VisitthewebsiteforthelatestQVL.
Memory configurations
Chapter 1
Dual CPU configuration
A1 B1 C1 D1 E1 F1 G1 H1 J1 K1 L1 M1
2 DIMMs PP
4 DIMMs P P P P
6 DIMMs PPP PPP
8 DIMMs P P P P P P P P
12 DIMMs PPPPPPPPPPPP
Dual CPU configuration
Single CPU configuration (must be installed on CPU1)
A1 B1 C1 D1 E1 F1
1 DIMM P
2 DIMMs P P
4 DIMMs P P PP
6 DIMMs PPPPPP
Single CPU configuration
Chapter 1
1.1.5 Expansion slots
Slot No. Slot Description
Chapter 1
®
PCI Express 3.0 operating mode
Slot No. Single VGA 2-way SLI®/
CrossFireX™
3-way SLI®/
CrossFireX™
4-way SLI®/
CrossFireX™
Chapter 1
1.1.6 Onboard buttons and switches
1. Power-on button
2. Reset button
Chapter 1
1.1.7 Jumpers
1. Clear RTC RAM (3-pin CLRTC1)
