Califone LP3 User manual

LP3
Multipurpose Laser Presenter
User Manual
LP3 User Manual - JH 2010.04.20.indd 1 4/21/2010 10:23:41 AM

califone.com
1
LP3
Multipurpose Laser Presenter
Thank you for purchasing the Califone® LP3 Multipurpose Laser
Presenter.
We encourage you to visit our website www.califone.com to register
your product for its warranty coverage, to sign up to receive our
newsletter, download our catalog, and learn more about the complete
line of Califone® audio visual products, including portable and installed
wireless PA systems, multimedia players and recorders, headphones
and headsets, computer peripheral equipment, visual presentation
products and language learning materials.
Table of Contents
1. IMPORTANT SAFETY INSTRUCTIONS 2
2. PACKAGE CONTENTS 4
3. PART NAMES AND FUNCTIONS 4
4. SETUP AND INSTALLATION 5
5. BASIC OPERATION 5
6. TROUBLESHOOTING 8
7. SPECIFICATIONS & FEATURES 9
8. WARRANTY 9
LP3 User Manual - JH 2010.04.20.indd 2-3 4/21/2010 10:23:42 AM

califone.com
2
califone.com
3
1. IMPORTANT SAFETY INSTRUCTIONS
Before using this product, read the instruction manual for important safety
information. Please retain this manual for future reference and warranty
information.
Troubleshooting & Servicing
Do not attempt to service or repair the device yourself. Refer all servicing
to qualied service personnel. Do not attempt to modify the device in any
way. Doing so could invalidate your warranty.
Moisture and heat sources
Do not use this apparatus near water (for example, sinks, baths, pools) or
expose it to rain, moisture, dripping or splashing liquids. Do not expose
the unit to high temperatures, high humidity or direct sunlight.
Cleaning
When cleaning the device, please use a soft, dry cloth. Never use
benzene, paint-thinner, or other chemicals on the device.
Location
Place the device in stable location, so it will not fall causing damage to
the device or bodily harm.
Intended use
The product may only be used with the original parts intended for it. The
product may only be used in closed and dry rooms. The intended use
includes adherence to the specied installation instructions. The
manufacturer accepts no liability for damage arising due to improper use.
WARNING
• This laser device can be harmful if used improperly. Avoid direct
body exposure since the laser beam can be harmful to the eyes
and skin. DO NOT look directly into the laser beam.
• This product is not a toy. Keep out of reach of children. Due
to small parts, this product is not suitable for children under 3
years old.
WARNING: Changes or modications to this unit not expressly approved
by the party responsible for compliance could void the user’s authority to
operate the equipment.
IMPORTANT
This device complies with Part 15 of the FCC Rules. Operation is subject
to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may
cause undesired operation.
The unit’s circuitry may cause interference to nearby radios. To prevent
interference, either switch the unit off or move away from the affected
radio.
NOTE: This equipment has been tested and found to comply within the
limits for a class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on,
the user is encouraged to try to correct the interference by one or more of
the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
• Consult the dealer or an experienced radio / TV technician for
help.
NOTE: Shielded cables may be required to be used with this unit to en-
sure compliance with the Class B FCC limits.
SAFETY CERTIFICATION
This product is made and tested to meet safety standards of the FCC,
requirements and compliance with safety performance of the U.S.
Department of Health and Human Services, and also with FDA Radiation
Performance Standards 21 CFR Subchapter J.
LP3 User Manual - JH 2010.04.20.indd 4-5 4/21/2010 10:23:42 AM

califone.com
4
califone.com
5
2. PACKAGE CONTENTS
• LP3 Multipurpose Laser Presenter
• USB Receiver
• 2pcs AAA Batteries
• Carrying bag
• User manual
Unpacking the Unit
Inspect the unit once the packaging has been opened for any damage
that occurred during shipping and contact us immediately. Please keep
the packing material for further use.
3. PART NAMES AND FUNCTIONS
1. LP3 Multipurpose Laser Presenter (pointer/mouse)
2. USB Receiver
1
2
4. SETUP AND INSTALLATION
1. Push and remove the battery cover located on the bottom of the
pointer/mouse. Insert 2 x AAA batteries into the battery holder and
ensure the proper polarity. Push the battery cover back into position
until it “clicks” rmly into place.
2. Plug the USB dongle/receiver into the USB port on your PC. The
system will automatically detect it.
3. Start using the pointer/mouse. The LEDs on the pointer/mouse and
USB Receiver should light during operation.
5. BASIC OPERATION
Important: The presenter provides two working modes: M1 & M2.
Certain functions may not work on every operating system/PC.
5.1 M1 Mode Operation
1. Set the LP3 mode by sliding the mode switch to M1.
2. The M1 mode has the following functions:
LP3 User Manual - JH 2010.04.20.indd 6-7 4/21/2010 10:23:51 AM

califone.comcalifone.com
7
Key Function
Open Email Program
Show Desktop
Open Internet Browser
Page Up
Page Down
Alt / Tab Alt+Tab - Switch programs in Windows
Laser
R Mouse Right Button
Mouse Left
Button
Mouse Left Click
Trackball Operate the mouse.
6
califone.com
5.2 M2 Mode Operation
1. Set the LP3 mode by sliding the mode switch to M2.
2. The M2 mode has the following functions:
Key Function
Close Program
Open My Computer
Add Favorite
Zoom In
Zoom Out
ESC ESC
Laser
R Mouse Right Click
Mouse Left
Button
Mouse Left Click
LP3 User Manual - JH 2010.04.20.indd 8-9 4/21/2010 10:23:59 AM

califone.comcalifone.com
8
califone.com
9
5.3 Pairing
Important: Only use this procedure if the the device is not working
and the USB receiver LED does not light when operating the pointer/
mouse.
1. Plug the USB receiver into the PC USB port.
2. On the PC keyboard, turn on “CAPS LOCK”, NUM LOCK”, and
SCROLL LOCK”.
3. Press these 3 buttons simultaneously in very rapid succession about
10 times.
4. Once successful, the USB receiver LED will blink for about 1.5
seconds. Within this time, quickly press any button on the pointer/
mouse to complete the pairing.
5. If the USB Receiver LED lights when any function on the pointer/
mouse is operated, then the pairing was successful. If not, try the
above procedure again.
6. TROUBLESHOOTING
Issue Resolution
Not working • Ensure that the polarity of the batteries is correct
and batteries are still charged (LED on pointer/
mouse lights when operated).
• Check to see if the USB receiver is rmly attached
to the USB port on the computer.
• Ensure the LP3 and USB receiver are paired.
Check that the LED lights on the receiver when
any function is operated on the pointer/mouse. If
not, then re-pair the devices.
7. SPECIFICATIONS & FEATURES
Control Interface 2.4GHz
Control Distance Up to 10 meters
RF Power 0 dBm
Trackball Resolution Up to 400 DPI
Operating System Compatibility Windows 98/ME/2000/XP/Vista,
Windows 7 32/64-bit, Mac OS, Linux
USB Compatibility USB 2.0 and 1.1 compatible
Laser Pointer Distance Up to 200 meters
Battery Usage Time: > 10 hours (depends on battery and
usage)
Power Consumption LP3:
• Working mode < 100 mA
• Sleep mode < 10 uA
USB Receiver: < 45 mA
Product Dimensions LP3: 125 × 51 × 47 mm
USB Receiver: 73 x 26 x 14 mm
Product Weight (incl.
accessories)
LP3: 4 oz
8. WARRANTY
Califone warrants this product to be free from defective material
and workmanship for one year from the purchase date. Our “Project
Intercept” Customer Satisfaction program will replace defective parts and
repair malfunctioning equipment under this warranty when the defect
occurs under normal use.
All Damage Claims Must Be Made With the Freight Carrier
Notify the freight carrier immediately if you observe any damage to the
shipping carton or product. Repack the unit in the carton and await
inspection by the carrier’s claim agent. Notify your dealer of the pending
freight claim.
Returning Your Unit for Service or Repairs
Should your unit require service, contact our Customer Service
Department online at califone.com/techsupport or via email warranty@
califone.com or by phone at 800-722-0500 / 818-407-2400 to rst obtain
an RA (Return Authorization) number before returning it to Califone. The
unit must be returned to our factory via prepaid transportation only after
the factory issues an RA number, which must be clearly written on the
outside of the box.
