Calix T072G Instruction Manual

Calix T07xG HGU ONT Operation
and Maintenance Guide
July 2013
#220-00589, Rev 10

Proprietary Information: Not for use or disclosure except by written agreement with Calix.
© Calix. All Rights Reserved.
Contents
About This Document..............................................................5
Revision History ........................................................................................................6
Product Introduction.................................................................................................7
Chapter 1: ONT Configuration..............................................11
Web GUI Access Through LAN Ports....................................................................12
ONT Login................................................................................................................14
Web GUI Access Through Active WAN Ports.......................................................15
Configuration Interface Introduction .....................................................................16
Status .......................................................................................................................17
Device Information..........................................................................................17
LAN Status......................................................................................................18
WAN Status....................................................................................................19
Network ....................................................................................................................20
LAN.................................................................................................................20
WAN ...............................................................................................................22
Wi-Fi ...............................................................................................................24
Public Bridged WiFi.........................................................................................27
Routing ...........................................................................................................30
DNS................................................................................................................32
TR-069............................................................................................................33
DSCP Remark ................................................................................................34
DNS_Suffix.....................................................................................................36
Security ....................................................................................................................37
Firewall ...........................................................................................................37
MAC Filter.......................................................................................................38
IP Filter ...........................................................................................................39
DMZ and ALG.................................................................................................41

4
Proprietary Information: Not for use or disclosure except by written agreement with Calix.
© Calix. All Rights Reserved.
Application...............................................................................................................42
NAT.................................................................................................................42
DDNS..............................................................................................................44
NTP.................................................................................................................45
USB Storage...................................................................................................46
Maintain....................................................................................................................47
Password........................................................................................................47
SLID Configuration..........................................................................................48
Configuration Backup......................................................................................49
Configuration Restore.....................................................................................50
Firmware Upgrade..........................................................................................51
Reboot Device................................................................................................52
Factory Default ...............................................................................................53
Diagnose.........................................................................................................54
Log..................................................................................................................55
Language........................................................................................................56
Chapter 2: LEDs.....................................................................57
T072G LEDs .............................................................................................................58
T073G, T076G, and T077G LEDs............................................................................60
Chapter 3: Frequent Asked Questions ................................63
Chapter 4: Abbreviations......................................................65

5
Proprietary Information: Not for use or disclosure except by written agreement with Calix.
© Calix. All Rights Reserved.
About This Document
This document describes the Web based configuration management interface of the T07xG
Optical Network Termination (ONT). T07xG ONTs include T072G, T073G, T076G, and
T077G, this document is applicable to them all. The differences on the management
interface to the four models are identified by Notes.

6
Proprietary Information: Not for use or disclosure except by written agreement with Calix.
© Calix. All Rights Reserved.
Revision History
Revision History
Revision Summary of Changes
A Initial document for the T07xG ONT.
B Document updated for the LED figures.
C Document updated for the DNS_Suffix and DSCP Remark web GUI
screens.
D Document updated for the NAT Fullcone web GUI screen.
E Document updated for the Web GUI access through active WAN ports
with R11A CP8.
10 Updated to include the Public Bridged WiFi configuration (for SW release
4.1.31.411 or greater).

7
Proprietary Information: Not for use or disclosure except by written agreement with Calix.
© Calix. All Rights Reserved.
Product Introduction
The T07xG ONTs are ITU-T G.984 compliant devices that receive voice, data, and video
traffic in the form of optical signal from the service provider Passive Optical Network
(PON) and transmitted it to the desired format at residential or business premises. Upstream
traffic is likewise transmitted to the PON network through the fiber optic cable. A single
optical fiber carries both upstream and downstream traffic. Figure T072G Overview shows
the T072G ports and buttons.
Figure 1: T072G Overview

8
Proprietary Information: Not for use or disclosure except by written agreement with Calix.
© Calix. All Rights Reserved.
Figure T073G Overview shows the T073G ports and buttons.
Figure T076G Overview shows the T076G ports and buttons.
Figure 2: T073G Overview
Figure 3: T076G Overview

9
Proprietary Information: Not for use or disclosure except by written agreement with Calix.
© Calix. All Rights Reserved.
Figure T077G Overview shows the T077G ports and buttons.
Figure 4: T077G Overview

10
Proprietary Information: Not for use or disclosure except by written agreement with Calix.
© Calix. All Rights Reserved.

Proprietary Information: Not for use or disclosure except by written agreement with Calix.
© Calix. All Rights Reserved.
Chapter 1
ONT Configuration
This chapter describes the ONT configuration.

12
Proprietary Information: Not for use or disclosure except by written agreement with Calix.
© Calix. All Rights Reserved.
Web GUI Access Through LAN Ports
Before accessing ONT, make sure that PC properly connects to the ONT. Then, do the
following configurations and operations:
1. Connect PC LAN port and ONT LAN1 port with a standard Ethernet Cable
2. Configure IP address of PC through one of the following ways: Configure IP address,
mask, and gateway address. For example:
Obtain an IP address automatically. In this case, the PC will obtain an IP address
from ONT through DHCP
Configure static IP address for PC
IP address: 192.168.1.X (2-254)
Mask: 255.255.255.0
Gateway address: 192.168.1.1
Note: Make the configurations based on actual ONT versions.
3. Ping the ONT IP address (Default is 192.168.1.1).

13
Proprietary Information: Not for use or disclosure except by written agreement with Calix.
© Calix. All Rights Reserved.
If PC gets the proper reply to the ping command, the connection between PC and ONT is
correct.
Note: Do not power off the ONT while managing the ONT on the configuration
management interface. Otherwise, the ONT might be damaged.
Figure 5: Pinging ONT Address

14
Proprietary Information: Not for use or disclosure except by written agreement with Calix.
© Calix. All Rights Reserved.
ONT Login
To log into the ONT, do the following steps:
1. Open an explorer and type http://192.168.1.1/, the default ONT IP address, in the
address bar.
2. Type the user name and the password in the login window and log in as an administrator.
The default user name is admin, the password is admin.
Note: The default username and password can also be customized according to customer
requirements.
The following figure shows the login window.
After log into ONT with administrator, you can query, configure, and modify the ONT
settings. Some configurations and modifications only take effect after ONT restart.
Note: The Web GUI access through LAN ports has two level user accounts, one is
administrator level, the other is end user level. End user level has limited Web GUI.
Figure 6: Login Window

15
Proprietary Information: Not for use or disclosure except by written agreement with Calix.
© Calix. All Rights Reserved.
Web GUI Access Through Active WAN Ports
Open a web browser and enter one of the IP addresses of active WAN ports in the Uniform
Resource Locator (URL) address field. Press Enter. Type the user name and the password in
the login window and log in as an administrator. The default user name is superadmin, the
password is superadmin.
Note: Web GUI access through WAN ports is disabled by default, which can be enabled by
OMCI plus configuration file and TR-069. The configuration set by OMCI plus
configuration file and TR-069 has no priority difference.

16
Proprietary Information: Not for use or disclosure except by written agreement with Calix.
© Calix. All Rights Reserved.
Configuration Interface Introduction
The ONT Configuration Interface consists of navigation bar and configuration area. The
upper part is the navigation bar. By clicking the links, you can enter the relevant
configuration pages. The right side of the page is configuration area. The content in this area
changes according to the selection in navigation bar. Please refer to following sections for
detail service configurations.

17
Proprietary Information: Not for use or disclosure except by written agreement with Calix.
© Calix. All Rights Reserved.
Status
After successful login, the default page is Status. There are 3 options, including Device
Information, LAN Status, WAN Status.
Device Information
In the Device Information page, you can view the device name, serial number, hardware
version, software version, and device running time.
Figure 7: Device Information Page

18
Proprietary Information: Not for use or disclosure except by written agreement with Calix.
© Calix. All Rights Reserved.
LAN Status
In the LAN Status page, you can view the information of Wireless Interface and Ethernet
interfaces.
Note: The Wireless Information pane only applies to T073G and T077G.
Figure 8: LAN Status

19
Proprietary Information: Not for use or disclosure except by written agreement with Calix.
© Calix. All Rights Reserved.
WAN Status
In the WAN Status page, you can view the WAN Connection List, Connection Mode,
Enable/Disable, VLAN, WAN Link Status, IPv4 link status, IPv6 link status, PON Link
Status, Up FEC Enable, Down FEC Enable, TX Packets, Rx Packets, Tx Dropped, Rx
Dropped, and Error Packets.
Figure 9: WAN Status

20
Proprietary Information: Not for use or disclosure except by written agreement with Calix.
© Calix. All Rights Reserved.
Network
In the Network page, there are eight options, including LAN, WAN, Wi-Fi, Routing, DNS,
TR-069, DSCP Remark, and DNS_Suffix.
LAN
The LAN configuration is used to configure ONT maintenance address and DHCP related
parameters.
Figure 10: LAN
