Calix GigaSpire BLAST u4hm User manual

GigaSpire BLAST u4hm (GM1028H)
Installation Guide
July 2023
#220-01305 R10

Proprietary Information: Not for use or disclosure except by written agreement with Calix.
May, 2023.
Contents
About this Guide.......................................................................3
Chapter 1 GigaSpire BLAST u4hm (GM1028H) Product
Overview....................................................................................7
Introducing the GigaSpire BLAST u4hm .................................................................8
Product Dimensions................................................................................................10
Exploring Product Interfaces..................................................................................11
Mounting Options....................................................................................................13
Powering Options....................................................................................................14
Installation Variables...............................................................................................16
Chapter 2 Installing the GM1028H GigaSpire
BLAST Satellite.......................................................................19
Unpacking the GigaSpire BLAST GM1028H..........................................................20
Installing Power and Network Cables....................................................................21
Identifying the Installation Location ......................................................................23
Installing the System on a Wall..............................................................................25
Installing the System on a Pole..............................................................................28
Grounding the Unit..................................................................................................31

4
Proprietary Information: Not for use or disclosure except by written agreement with Calix.
May, 2023.
Chapter 3 Final Setup and Activation..................................35
Powering Up the System.........................................................................................36
Replacing Removed Covers ...................................................................................38
Sealing Cable Entry Locations ...............................................................................39
Appendix A Appendix ...........................................................41
System LED Behavior .............................................................................................41
System Specifications ............................................................................................43
Agency Listings.......................................................................................................44

5
Proprietary Information: Not for use or disclosure except by written agreement with Calix.
May, 2023.
About this Guide
This document provides the installation practice for the Calix GigaSpire BLAST GM1028H
(u4hm) outdoor satellite system.
Intended Audiences
This document is intended for use by network planning engineers, outside plant engineers,
and field/craft personnel responsible for installation and maintenance of Calix premises
equipment.
Safety and Regulatory Information
Federal Communications Commission (FCC) Statement
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the
FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee
that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct
the interference by one of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the
user’s authority to operate this equipment.
Professional installation is required.
IMPORTANT NOTE: FCC Radiation Exposure Statement
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be
installed and operated with minimum distance 43cmbetween the radiator & your body.
This device contains license-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and Economic Development
Canada’s license-exempt RSS(s). Operation is subject to the following two conditions:
(1) This device may not cause interference.
(2) This device must accept any interference, including interference that may cause undesired operation of the device.
Cet appareil contient des émetteurs / récepteurs exempts de licence qui sont conformes au (x) RSS (s) exemptés de licence
d'Innovation, Sciences et Développement économique Canada. L'opération est soumise aux deux conditions suivantes:
(1) Cet appareil ne doit pas provoquer d'interférences.
(2) Cet appareil doit accepter toute interférence, y compris les interférences susceptibles de provoquer un fonctionnement
indésirable de l'appareil.
IMPORTANT NOTE: IC Radiation Exposure Statement
This equipment complies with IC RSS-102 radiation exposure limits set forth for an uncontrolled environment. This equipment
should be installed and operated with minimum distance 25cm between the radiator &your body.
Cet équipement estconforme aux limites d'exposition aux rayonnements IC établies pour un environnement non contrôlé. Cet
équipement doitêtre installé et utilisé avec un minimum de 25cm de distance entre la source de rayonnement et votre corps.
This document uses the following safety notice conventions.

6
Proprietary Information: Not for use or disclosure except by written agreement with Calix.
May, 2023.
DANGER! Danger indicates the presence of a hazard that will cause severe
personal injury or death if not avoided.
DANGER! Danger indique la présence d'un danger qui entraînera des
blessures graves ou la mort s'il n'est pas évité.
!
WARNING! Warning indicates the presence of a hazard that can cause
severe personal injury if not avoided.
ATTENTION! Avertissement indique la présence d'un danger pouvant
entraîner des blessures graves s'il n'est pas évité.
!
CAUTION! Caution indicates the presence of a hazard that can cause minor
to moderate personal injury if not avoided.
MISE EN GARDE! Attention indique la présence d'un danger qui peut
causer des blessures légères à modérées s'il n'est pas évité
ALERT! Alert indicates presence of a hazard that can cause damage to
equipment or software, loss of data, or service interruption if not avoided.
ALERTE! L'alerte indique la présence d'un danger susceptible
d'endommager l'équipement ou les logiciels, de perdre des données ou
d'interrompre le service s'il n'est pas évité.
DANGER! CLASS 1 LASER PRODUCT. INVISIBLE LASER RADIATION
MAY BE PRESENT. Fiber optic radiation can cause severe eye damage or
blindness. Do not look into the open end of an optical fiber.
DANGER! PRODUIT LASER DE CLASSE 1. UN RAYONNEMENT LASER
INVISIBLE PEUT ÊTRE PRÉSENT. Le rayonnement de la fibre optique
peut causer de graves lésions oculaires ou la cécité. Ne regardez pas dans
l'extrémité ouverte d'une fibre optique.
Important Safety Instructions
When using your equipment, basic safety precautions must always be followed to reduce the
risk of fire, electric shock, and injury to persons, including the following:
Do not use this product near water. For example, near a bathtub, washbowl, kitchen sink,
or laundry tub, in a wet basement, or near a swimming pool.
Use only the power cord indicated in this manual.
For external power supplies, the external power supply used in this device is to be Class
II or a Limited Power Source (LPS) power supply.

Proprietary Information: Not for use or disclosure except by written agreement with Calix.
May, 2023.
Chapter 1
GigaSpire BLAST u4hm (GM1028H)
Product Overview
This chapter introduces the Calix GigaSpire BLAST u4hm (GM1028H) outdoor mesh Wi-Fi
satellite system and provides an overview of installation considerations.
Topics Covered
This chapter covers the following topics:
Introducing the GigaSpire BLAST u4hm (on page 8)
Product Dimensions (on page 10)
Exploring the Product Interfaces (on page 11)
Mounting Options (on page 13)
Powering Options (on page 14)
Installation Considerations (on page 16)

8
Proprietary Information: Not for use or disclosure except by written agreement with Calix.
May, 2023.
Introducing the GigaSpire BLAST u4hm
The Calix GigaSpire BLAST u4hm (GM1028H) is a new generation, dual-band, outdoor PoE
or local powered Wi-Fi 6 mesh system, ideal for residential applications, bringing high-
bandwidth services outdoors to the barn, patio, pool, and more. It features the latest Wi-Fi 6
technology, offering the optimal Wi-Fi experience. Besides supporting data and video
services, this intelligent, high-performance system has GE LAN and WAN interface,
allowing it to support Gigabit throughput for video and data services.
The GigaSpire BLAST u4hm is a dual-band, outdoor PoE or local powered Wi-Fi 6 system
that leverages the 2.4 and 5 GHz spectrum. Using a Gigabit Ethernet interface supporting
either WAN or LAN allows broadband service providers (BSPs) to provide high bandwidth
for the most demanding environments.
With integrated power of Ethernet (PoE), the GigaSpire BLAST u4hm can be placed in an
optimal location; even without power availability. Coupled with the Calix GigaPro
GPR8802x, the GigaSpire BLAST u4hm can be powered via an Ethernet cable. In addition,
the GigaSpire BLAST u4hm can also be powered locally (with a traditional power adapter),
offering the ultimate outdoor location flexibility.
u4hm Satellite
Key attributes of the hardened u4hm include the following:
Environmentally hardened system for outdoor operation in extreme conditions
Layer 2 bridge and Layer 3 routing for High Speed Internet (HSI) data and IPTV
video services
2.4 GHz and 5 GHz 802.11ax (Wi-Fi 6) certified, 802.11a/b/g/n/ac compatible
WPA/WPA2/WPA3; WEP 64/128 bit encryption

9
Proprietary Information: Not for use or disclosure except by written agreement with Calix.
May, 2023.
Dynamic Mesh: load balancing, band/node steering; interference management
Remote WAN side GUI access
Gigabit Ethernet LAN/WAN interface; single port of multi-rate 10/100/1000
BASE-T Ethernet, auto-negotiating for residential IPTV and data services
Dynamic Mesh: load balancing, band/node steering; interference management
Supports a Power of Ethernet (PoE) input power option on its Gigabit WAN port to
operate as a PoE Powered Device (PD); or can be powered locally with a traditional
AC/DC power adapter.

10
Proprietary Information: Not for use or disclosure except by written agreement with Calix.
May, 2023.
Product Dimensions
Dimensions for the GigaSpire BLAST u4hm are included here for reference.
Note: The GM1028H must be wall or pole mounted using the appropriate mounting
bracket.
Note: The u4hm includes the wall mount bracket affixed to the back of the unit.
Wall Mount Dimensions - GM1028H Satellite

11
Proprietary Information: Not for use or disclosure except by written agreement with Calix.
May, 2023.
Exploring Product Interfaces
The GM1028H uses a combination of covers and cut-outs to keep the incoming fiber
protected and dry.
GM1028H Outer Cover
With the bottom cover removed a partial view of the ports can be seen.
Relative positions of interface ports
By tilting the GM1028H downward, the bottom surface of the satellite can be seen. The
image below provides information on interface ports and their functions.

12
Proprietary Information: Not for use or disclosure except by written agreement with Calix.
May, 2023.
Note: The view below shows the GM1028H with the Wall Mount Bracket already attached.
Interface locations

13
Proprietary Information: Not for use or disclosure except by written agreement with Calix.
May, 2023.
Mounting Options
Currently, there are two methods for mounting the u4hm:
Wall Mount (on page 25) - The u4hm wall mount bracket is standard equipment on the
GM1028H. Mounting instructions (on page 25) are included in this guide.
Pole Mount (on page 28) - A pole mount bracket kit can be ordered separately.
100-05967 Pole mount bracket for GigaSpire BLAST GM1028H (u4hm)
Additional Mounting Considerations
From a best practice’s standpoint, keep the following in mind:
Calix recommends mounting the BLAST u4hm as high as practical for Wi-Fi
performance reasons. However, this deployment scenario still mandates that an AC
power outlet is located within the power cord distance of the Wi-Fi source. If installing in
a greenfield environment (initial installation), plan on placing the GM1028H within 10
feet of the power supply. As an alternative, longer power cords are available to extend the
distance between the u4hm and the power supply.
Calix also recommends keeping cabling neat and well secured wherever possible. A tidy
installation allows for increased safety and an overall neater appearance. Common tools
used for this purpose include cable ties and velcro straps for routing cable out of the way.
Also, custom made wall plates may be used where the majority of cabling is hidden
behind a wall.
27 inch/pounds of torque or less should be used when tightening fasteners to both the
bracket and the u4hm.

14
Proprietary Information: Not for use or disclosure except by written agreement with Calix.
May, 2023.
Powering Options
Attach to any 110/220 VAC power outlet using the supplied 12 VDC transformer.
Note: For the GM1028H, the power cord configuration must be appropriate for use in
the country where the device is being deployed.
Note: Only provided and approved power cords or voltage adapters should be used to
connect to this product.
The power supply provided is suitable for both indoor and outdoor deployments and
provides the following:
Ext. Power Adapter: 12 VDC, 3A
AC Power Cord (from incoming line voltage power): 10 feet (3 meters)
DC Power Cord (to u4hm): 6 feet (1.8 meters)
2-pin barrel connector to u4hm
Input voltage: 12 VDC (nominal), 10 VDC (min.), 15 VDC (max)
PoE 802.3bt PD
Power Supply (3-pin)

15
Proprietary Information: Not for use or disclosure except by written agreement with Calix.
May, 2023.
PoE Power Option
DC Power Option - An RJ-45 Ethernet connector for Powered Devices (PD) that provides
input to the 802.3BT compliant Power over Ethernet (PoE) system.
PoE - Supports personal devices only on the WAN uplink.
Daisy chain uplinks to any satellite unit are supported from the LAN port but not the
PoE port.
When employing PoE, added hardware specific to this powering option are not
provided by Calix nor does Calix recommend any specific solution.
If additional help is needed on implementing a power supply, please contact your
local Calix service professional.

16
Proprietary Information: Not for use or disclosure except by written agreement with Calix.
May, 2023.
Installation Variables
General Guidelines
Follow these general guidelines and practices:
Read this document completely before starting any installation activities.
Determine the system powering method to use for your installation, from among two
options. See Powering Options (on page 14) and Identifying the Installation Location (on page
23) for details and guidance.
Determine the system mounting method to use for your installation, from among two
options. See Mounting Options (on page 13) and Identifying the Installation Location (on page
23) for details and guidance.
Follow standard safety precautions when performing installation tasks.
Keeping all cabling neat and secured for safety and strain relief. Use cable ties, screw
clips, and velcro straps for dressing cables as needed.
Network Uplink
The u4hm system is equipped with a 1GE WAN Ethernet port for uplink connections to the
network. Connect the system to the network following these guidelines:
Connect the system to the network using either a wired (ethernet) or wireless backhaul link
to connect to the RG system.
Supported Topologies
The GigaSpire BLAST u4hm Wi-Fi AP system operates in satellite mode. can operate in
either RG mode or satellite mode. Deployment topologies supported depend on the
operating mode, as shown below.
The GigaSpire BLAST u4hm Wi-Fi AP system can connect to the RG system via a wired or
wireless connection. You can arrange satellites in a star or daisy-chain topology, adhering to
the following guidelines:
Maximum of (4) satellites supported per RG
Star topology preferred; daisy chain topology also supported
For star arrays, wired or wireless links to the RG are supported
For daisy-chains, a maximum of 2 hops are supported (from RG to last satellite)
For daisy-chains, only wireless backhaul links are supported

17
Proprietary Information: Not for use or disclosure except by written agreement with Calix.
May, 2023.
Satellite mode
When operating as a WAP satellite, the satellite system can connect to the RG system via a
wired or wireless connection. You can arrange satellites in a star or daisy-chain topology,
adhering to the following guidelines:
Maximum of (4) satellites supported per RG
Star topology preferred; daisy chain topology also supported
For star arrays, wired or wireless links to the RG are supported
For daisy-chains, a maximum of 2 hops are supported (from RG to last satellite)
For daisy-chains, only wireless backhaul links are supported
Star Topology
Daisy Chain Topology

18
Proprietary Information: Not for use or disclosure except by written agreement with Calix.
May, 2023.
User-Supplied items
Bring the following tools and materials to the installation site, as required:
Materials
An Ethernet cable up to 100 m in length (for a wired uplink to the RG)
Silicone sealant/caulk; for sealing cable entry holes
(2) mounting screws for wall-mount bracket
PoE power supply equipment (PSE)/PoE injector, to install nearby; only if using PoE
power option
Tools
Bring the following tools to the installation site:
Phillips head screwdrivers (#2 head, #1 head)
Level for aligning the installed bracket to the wall or pole
Pencil (to mark bracket and drill hole locations; wall-mount kit)
Nut driver, 5/16" (to tighten hose clamps; pole-mount kit)

Proprietary Information: Not for use or disclosure except by written agreement with Calix.
May, 2023.
Chapter 2
Installing the GM1028H GigaSpire
BLAST Satellite
In this section, the following topics are covered:
Unpacking (on page 20)
Identifying the Installation Location (on page 23)
Wall Mounting Dimensions and Instructions (on page 25)
Optional: Pole Mounting (on page 28)
Grounding the u4hm (on page 31)
Installing Power and Network Cables (on page 21)
!
CAUTION! Use of controls or adjustments or performance of procedures other
than those specified here may result in hazardous radiation exposure.
MISE EN GARDE! L'utilisation de commandes ou de réglages ou l'exécution de
procédures autres que celles spécifiées ici peuvent entraîner une exposition à
des rayonnements dangereux.
Note: Before mounting the u4hm to a wall or pole, complete all internal wiring. Once the
u4hm is attached, very little room exists due to mounting bracket interference.
Follow these tips when installing a GigaSpire BLAST GM1028H device:
For subscribers using data services, all data wiring inside the home must be CAT5 cable
or better.
Make sure subscriber connections are tightened properly.
Check the contents of each box carefully as you receive them. Components may not be
located where you might expect them due to certain items being tested immediately before
shipment.

20
Proprietary Information: Not for use or disclosure except by written agreement with Calix.
May, 2023.
Unpacking the GigaSpire BLAST GM1028H
Each device is shipped individually in its own carton and contains the following:
Part Number 100-05839 GigaSpire Blast u4hm (GM1028H) hardened dual band 2x2 Wi-Fi 6,
GE WAN includes the following additional parts and supplies:
The u4hm main device with interface cover pre-installed.
The wall mount bracket
The grounding plug and the grounding screw (M4, Phillips head)
Safety card
After opening the carton, remove the protective packaging, ensure all components above are
present, and prepare for mounting the unit.
Before proceeding, the bottom cover must be removed.
In addition to the above, the following optional accessories are available (sold separately):
Part number 100-05967 GigaSpire BLAST u4hm (GM1028H), pole mount bracket kit
Pole Mount Bracket
Qty. 2 hose clamps for 2" to 6" diameter pole.
Qty. 1 M4 Phillips head screw
