Caloric CSG3601 User manual

Please Read Manual Before
Operating Range
• Safety
• Installation
• Use
Installer
Leavethismanualandotherliteraturewithconsumerfor
futureuse.
Customer
Keeptheseinstructionsforfuturereference.Ifappliance
changesownership,be sure this manual accompanies
range.
Gas Range
Owner's Manual
Model CSG3601
Manual Clean Oven
Sealed Surface Burners

2
Contents
Model Identification
Completeenclosedregistrationcardandpromptlyreturn.
If registration card is missing, call Consumer Affairs
Departmentat1-800-843-0304insideU.S.A.
319-622-5511outsideU.S.A.WhencontactingCaloric
SalesCo.L.P.,provideproductinformationlocated on
ratingplate. Rating plate is located onthe oven frame.
Recordthefollowing:
ModelNumber: ______________________________
ManufacturingNumber: ________________________
SerialorS/N Number: _________________________
Dateofpurchase:_____________________________
Dealer’snameandaddress: ____________________
__________________________________________
__________________________________________
ImportantSafetyInformation........................................ 3
Installation................................................................... 6
ConvertingforUsewithLP/Propane Gas ..................... 9
ConvertingforUsewithNatural Gas .......................... 11
Setting Clock and Timer ............................................ 16
OperatingSurfaceBurners ........................................ 17
UtensilRecommendations ........................................ 18
Baking & Broiling ...................................................... 19
AdjustingFactorySet Baking Temperature................ 20
CookingGuidelines ................................................... 21
Careand Cleaning..................................................... 23
BeforeCallingfor Service........................................... 26
Warranty ................................................................... 28
Recognize Safety Symbols, Words,
Labels DANGER
!
DANGER—ImmediatehazardswhichWILL resultin
severepersonalinjuryordeath.
WARNING
!
WARNING—Hazards or unsafepracticeswhichCOULD
resultinseverepersonalinjury or death.
CAUTION
!
CAUTION—Hazardsor unsafe practiceswhich COULD
resultin minor personal injury or productor
propertydamage.
What You Need to Know about Safety
Instructions
Warning and Important Safety Instructions appearing in this
manual are not meant to cover all possible conditions and
situations that may occur. Common sense, caution, and care
must be exercised when installing, maintaining, or operating
range.
Always contact your dealer, distributor, service agent, or
manufacturer about problems or conditions you do not
understand.
Parts and Accessories
Purchasereplacement parts and additionalaccessories
(e.g.,oven racks, cooktop modules)over the phone. To
order accessories for your Caloric Sales Co. L.P.
product,call 1-800-843-0304 inside U.S.A.or
319-622-5511 outside U.S.A.
Service
Keepa copy of sales receipt forfuture reference or in
case warranty service is required. Any questions or to
locateanauthorizedservicer, call 1-800-NAT-LSVC
(1-800-628-5782)insideU.S.A. 319-622-5511 outside
U.S.A.Warranty service must beperformed by an
authorizedservicer. Caloric Sales also recommends
contactinganauthorizedservicerifserviceisrequired
afterwarrantyexpires.
Asure™ Extended Service Plan
CaloricSalesCo. L.P. offerslong-termserviceprotection
forthis new range. Asure™ ExtendedService Plan is
specially designed to supplement Caloric Sales’ strong
warranty.Thisplancoversparts,labor, and travel
charges.Call1-800-528-2682 forinformation.

3
IMPORTANTSAFETYINFORMATION
CAUTION
!
Do not obstruct the flow of combustion or ventilation
air.
WARNING
!
Toavoiddeath,personalinjury or property damage,
information in this manual must be followed exactly.
Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any other
appliance.
WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use
anyphonein your building.
• Immediatelycall your gas supplier from a
neighbor’sphone.Followthegassupplier’s
instructions.
• If you cannot reach your gas supplier, call the fire
department.
Installationandservicemustbe performed by a
qualifiedinstaller, service agency or the gas
supplier.
WARNING
!
To reduce risk of the appliance tipping, it must
be secured by a properly installed anti-tip
bracket(s). To make sure bracket has been
installed properly, remove the storage drawer
and look under the range with a flashlight.
Bracket(s) must be engaged in the rear corner of
the range.
• ALL RANGES CAN TIP
• INJURY TO PERSONS
COULDRESULT
• INSTALLANTI-TIP
BRACKET(S) PACKED
WITHRANGE
• SEEINSTALLATION
INSTRUCTIONS
WARNING
!
To avoid personal injury, do not sit, stand or lean on
ovendooror ovendrawer.
WARNING
!
To avoid risk of electrical shock, personal injury, or
death,make sure your range has been properly
groundedand always disconnect it frommain power
supplybeforeany servicing.
California Safe Drinking Water and
Toxic EnforcementAct(Proposition 65)
TheGovernorofCaliforniaisrequiredtopublisha list of
substances known to the state of California to cause
cancerorreproductiveharmandrequiresbusinessesto
warn customers of potential exposures to such
substances.
Someappliances contain or produce a chemical or
chemicals which can cause death or serious illness and
which are known to the State of California to cause
cancer, birth defects, or other reproductive harm. To
reduce the risk from substances in the fuel or from fuel
combustion, or that may be released during the self-
cleaning cycle, make sure this appliance is installed,
operated,andmaintainedaccordingtothemanufacturer’s
instructions.
SAVETHESEINSTRUCTIONS

4
IMPORTANTSAFETYINFORMATION
SURFACE COOKING UNITS
1. UseProperPanSize—Thisappliance is equipped
withoneormoresurface burners of different sizes.
Selectutensilshaving flat bottoms large enough to
coverthesurfaceburnerflame.The use of undersized
utensils will expose a portion of the burner flame to
direct contact and may result in ignition of clothing.
Properrelationshipof utensil to burner will also
improveefficiency.
2. NeverLeaveSurfaceBurnersUnattended—Boilover
causes smoking and greasy spillovers that may
ignite.
3. ProtectiveLiners—Donot use aluminum foil to line
surface unit drip bowls or oven bottom, except as
suggestedinmanual.Improperinstallation of these
liners may result in a risk of electric shock, or fire.
4. GlazedCookingUtensils—Only certain types of
glass, ceramic, earthware, or other glazed utensils
aresuitableforrangetopservicewithout breaking due
tosuddenchangeintemperature.
5. UtensilHandlesShouldbeTurned Inward and Not
ExtendOverAdjacentSurfaceBurners—To reduce
the risk of burns, ignition of flammable materials, and
spillage due to unintentional contact with the utensil,
the handle of a utensil should be positioned so that it
isturnedinward, and does not extend over adjacent
surfaceunits.
ALL APPLIANCES
1. ProperInstallation—Be sure your appliance is
properlyinstalledandgroundedbyaqualified
technician.
2. NeverUseApplianceforWarmingorHeatingthe
Room.
3. Do NotLeaveChildrenAlone—Childrenshouldnot be
aloneorunattendedintheareawheretheappliance
is in use. They should never be allowed to sit or stand
on any part of the appliance.
4. WearProperApparel—Loosefittingor hanging
garmentsshouldneverbewornwhile using appliance.
5. UserServicing—Donotrepairorreplaceanypartof
theapplianceunless specifically recommended in the
manual.Allotherservicingshould be referred to a
qualifiedtechnician.
6. StorageinoronAppliance—Flammablematerials
shouldnot be stored in oven ornear surface units.
7. DoNotUse Water on Grease Fires—Smother fireor
flame,or use dry chemical or foam-typeextinguisher.
8. UseOnlyDry Potholders—Moist or damp potholders
on hot surfaces may result in burns from steam. Do
not let potholder touch elements. Do not use a towel
or other bulky cloth.
SAVE THESE INSTRUCTIONS
OVEN
1. UseCareWhen Opening Door—Let hot air orsteam
escapebeforeremoving or replacing food.
2. DoNotHeatUnopened Food Containers—Build-up of
pressure may cause container to burst and result in
injury.
3. KeepOvenVents Ducts Unobstructed.
4. PlacementofOvenRacks—Alwaysplace oven racks
in desired location while oven is cool. If rack is
removedwhileovenishot,donotletpotholder
contacthotheating element in oven.
VENTILATION HOOD
1. CleanVentilation Hood Frequently—Grease should
not be allowed to accumulate on hood or filter.
2. Whenflamingfoods under hood, turn fanon.
CAUTION
!
Do not store items of interest to children in cabinets
abovearangeoronthebackguardofarange—
children climbing on the range to reach items could
beseriouslyinjured.

5
In Case of Fire
Fires can occur as a result of over cooking or excessive
grease. Though a fire is unlikely, if one occurs, proceed
as follows:
Surface Fire
1. Smotherthefire with a nonflammable lid or baking
soda, or use a Class ABC or BC extinguisher. Not
water. Not salt. Not flour.
2. As soon as it is safe to do so, turn the surface
burnercontrols to OFF .
• Asan added precaution, turn off gas supplyand
power at main circuit breaker or fuse box.
Oven Fires
1. Ifyousee smoke from oven, donot open oven door.
2. Turnovenoff.
3. As an added precaution, turn off gas supply and
power at main circuit breaker or fuse box.
4. Turnonvent to remove smoke.
5. Allow food or grease to burn itself out in oven.
6. If smoke and fire persist, call fire department.
7. If there is any damage to components, call repair
servicebeforeusingrange.
Precautions
• Do not cook food directly on rangetop surface, always
usecookware.
• Do not mix household cleaning products. Chemical
mixturesmay interact with objectionable or even
hazardousresults.
• Oven door contains a glass window. While this glass is
built to be sturdy and resistant, it is glass and should
be treated with care.
• Donot lift or move range bygrasping oven door. This
can result in window glass breaking or shattering.
• Do not put plastic items on warm cooking areas. They
may stick and melt.
• Do not slide rough metal objects across rangetop
surface. Scratching or metal marking can result.
• Do not use damp sponge or dishcloth to clean rangetop
when range is hot. Steam from sponge or dishcloth can
burn.
• Do not leave fat heating unless you remain nearby. Fat
can ignite if overheated by spilling onto hot surfaces.
• Do not allow pots to boil dry as this can cause damage
to cooking surface and pan.
• Do not use rangetop surface as a cutting board.
Delayed Ignition
Surface Burners
Burnershould ignite within 4 seconds. Ifburner does not
ignite within 4 seconds turn control knob to OFF position
andfollowdirectionsin“Placing Grates and Burner Caps”
and“BeforeCallingforService”section. Try burner again.
If burner still does not ignite in 4 seconds, contact an
authorizedservicer.
Burner Flame
Allownomorethan40–60secondsbeforeburnerignites
and heat is felt. To check for heat, open oven door to first
stopand place hand over oven door. If heat is notfelt, turn
ovencontrol to OFF.Ifburnerrepeatedly fails to ignite,
contactanauthorizedservicer.
IMPORTANTSAFETYINFORMATION
SAVE THESE INSTRUCTIONS

6
Installation
Packing Material
Removeprotectivepacking material from range.Tape
residue can be cleaned with a soft cloth and alcohol.
Range Location
Choosealocationbasedonfollowingfactors.
• Draftscausedby home heating and air conditioning and
opendoorsorwindowscandisruptventilationair
pattern.Rangeshouldnotbe installed near windows or
doors.
• Makesurethere is adequate space for proper
installation.
• Carefullyreadallinstructionsbeforebeginning
installation.
Cabinet Opening
WARNING
!
Toavoidriskof burns or fire byreaching over burners,
cabinetstorage space located above range shouldbe
avoided.
Rangeshouldextend approximately 2 inches from cabinet
fronttoovendoorhandle.Usedimensionsinfigurebelow
and listed in Special Countertop Conditions section to
preparecabinetopening.
A
C
B
D
A—301/8to 30¼ inches
B—36 inches standard
C—35 inches standard
D—24 inches standard
Standard Cabinet and Countertop Height
Minimum Clearances to Combustible
Surfaces
• Minimum clearance to rear wall is 0 inches.
• Minimum clearance to a vertical right or left side wall
extendingabovecooking surface is 3 inches.
• Minimumclearanceto countertop/cabinet on each side
is 0 inches.
• Minimumof30 inches between top of cookingsurface
andbottomof an unprotected wood or metalcabinet.
• 24inchesbetweencookingsurfaceandprotectedwood
ormetalcabinet above range. Cabinet bottom must be
protected by at least ¼ inch thick millboard with not
less than No. 28 MSG sheet steel, .015 inch thick
stainless steel, .024 inch thick aluminum, or .020 inch
thick copper.
A
B
C
D
EF
G
H
J
A—30 inches minimum
B— 0 inches
C—30 inches unprotected/24 inches protected minimum
D—13 inches
E—0 inches
F—25 inches maximum
G—36 inches maximum
H—3 inches minimum (Both sides of range)
J—18 inches minimum
Clearances to Combustible Surfaces

7
Electrical Connection Clearance
Electrical connection must be located in the area shown.
Electricalconnectionmustnotinterferewithgasconnection.
A
B
C
D
A
A—2 inches (Both sides)
B—19½ inches
C—12 inches
D—6 inches
ElectricalConnectionClearance
Gas Connection Requirements
Before connecting this appliance to the gas supply piping
system,confirm installationmeetstherequirementsoflocal
codes, or in the absence of local codes, with the National
FuelGasCode,ANSIZ223.1-LatestEdition.
When installed in mobile housing, installation is to be in
accordancewithCSAstandardZ241.1gasequipped
mobilehousing.
Theinstallationofappliancesdesigned for manufactured
(mobile)homeinstallation must conform with
ManufacturedHomeConstructionandSafetyStandard,
Title 24 CFR, Part 3280, or when such standard is not
applicable,theStandardforManufactured Home
Installation,ANSI225.1/NFPA501A-LatestEdition,or with
localcodesorthestandard CAN/CSA-z240MH, “Mobile
Homes”,andwithlocalcodes where applicable.
The installation of appliances is to be in accordance with
CAN1-B149.1orB149.2installationcodeforgasburning
appliancesandequipmentand/orlocal codes.
Refer to National Fuel Gas Code or local codes for supply
pipe size requirements to assure sufficient gas supply to
unit.
Installation (cont’d)
Special Countertop Conditions
Countertops such as ceramic tile tops cause cabinet and
countertoptobehigherthan36inches. Followinstructions
belowwhencountertopishigherthan 36 inches.
1. Raiselevelinglegstomaximum level.
2. Measurefromfloor to side trim. Ifmeasurement is
less than height of countertop floor must be shimmed.
3. Shim floor using a piece of plywood same size as
rangeopening. Secureplywoodtofloor. Plywood
must be as secure as original flooring.
4. Install anti-tip bracket(s) and slide range into place.
Electrical Connection Requirements
WARNING
!
To avoid the risk of serious electrical shock or
propertydamage, do not cut or remove thethird
(ground)prongfrom the power plug. A 3-wire
grounded conductor system must be used. Relying
on the flexible connector, hard piping or any other
part of the gas supply line as a ground may cause
fire, electrical shock and/or erratic control operation.
Rangemust be electrically grounded in accordance with
local codes or in the absence of local codes, with the
NationalElectrical Code, ANSI/NFPA No. 70-Latest
Edition.
In Canada, electrical connections are to be made in
accordancewith CSA C22.1 CanadianElectrical Code.
All electrical connections are to be made in accordance
withCSA standards Z240.6.1 electrical requirementsfor
mobilehomes.
Useadedicated 120 volt, 60 hertz, 3-prong receptacle
protected by a 15 amp circuit breaker or time delay fuse.
A qualified electrician should confirm the outlet is properly
grounded.
Ifa 2-prong outlet is encountered,range owner must
replace outlet before using range. Do not cut off cord, use
plugadapteror extension cord, or remove groundingplug.
Grounded Plug and Receptacle

8
Pressure Regulator Location
Remove rear cover to expose pressure regulator.
Regulator Cover
Gas Supply Location
Gas supply must be located in the area shown. Gas
connection must not interfere with the electrical
connection.
A
BCD
A
B
A—26 inches
B—20 inches
C—2¼ inches
D—4 inches
Gas Supply Location
Gas Supply Pressure
CAUTION
!
To avoid propertydamage, maximum gas supply
pressure must not exceed 14" WCP.
• Applianceandindividual shut-off valve mustbe
disconnected from the gas supply piping system during
any pressure testing of that system at test pressures in
excess of ½ psig (3.5kPa) (14" WCP).
• Appliance must be isolated from gas supply piping
systembyclosingmanualshut-off valve during any
pressure testing of the gas supply piping system at
test pressures equal to or less than ½ psig (3.5kPa)
(14"WCP).
• Gassupplypressure for checking regulator setting
must be at least 1" WCP above manifold pressure
shownonratinglabel.
Installation (cont’d)

9
Thisrangearrives from factoryadjusted for use with
natural gas. If using LP/Propane gas is desired, range
mustbeconverted.See“Type 1” or “Type 2” regulator.
Converting Type 1 Pressure Regulator for Use with
LP/Propane
1. Removepressureregulatorcapwitha wrench.
2. Removeplasticinsertfrompressureregulatorcap.
• Plastic insert fits tightly in cap.
3. Reverseplasticinsert and carefully push plastic
insert firmly into hole in pressure regulator cap.
• Capmustshow“LPG10”or “LP10”.
A
B
C
A—Cap
B—Plastic Insert (LP setting)
C—Spring Location
Type 1 Pressure Regulator
4. Placepressureregulatorcaponpressureregulator
andtighten.
• Insertshouldnot disturb spring in body ofregulator.
WARNING
!
To avoid electric shock that can cause personal
injury or death, disconnect main electrical supply to
rangebeforeservicing.
Converting for Use With LP/Propane Gas
Converting Type 2 Pressure Regulator for Use with
LP/Propane
1. Removepressureregulatorcapwitha wrench.
2. Reversepressureregulatorcap.
• Cap must show “LP”.
3. Placepressureregulatorcaponpressureregulator
andtighten.
Cap
LP
Type 2 Pressure Regulator

10
Converting Surface Burners for Use with LP/Propane
1. Remove(pulloff)all(5)burner control knobs from
range.
• Exposes 2 screws on burner control panel.
2. Remove2screwsfromburnercontrol panel.
• Paneldropsslightlyafterscrews are removed.
3. Graspbottomof burner control panel, gently liftand
pulloutpanel until clear of burner valve stems.
• Afterburner
controlpanel
clearsvalve
stems, continue to
rollpaneluntilfree
fromrange.Set
aside. See Pivot
Point infigure.
• Gasvalveand
orificehoodare
visibleafter burner
control panel is
removed.
A—Burner Control Knob
B—Pivot Point
C—Burner Control Panel
D—Screw
Burner Control Panel
4. Whilefacingrange front, turn orificehoods
counterclockwise 1½ to 2 turns or until snug.
• Use½ inch open end or 90° offsetopen end
wrench.
• Donotovertightenorificehoods.Iforificehoods are
overtightened,gas supply can be cutoff or orifice
hoods can strip.
5. Openairshutter fully.
A—Orifice Hood
B—Air Shutter
Converting Surface Burners for Use with LP/Propane
6. Reassembleburnercontrolpanelafteradjustingair
shutter.
• See Adjusting Surface Burner Flame section.
Converting for Use With LP/Propane(cont’d)
Converting Oven Burner for Use with LP/Propane
1. Openbroilerdoorandremovebroilerrack,pan,and
grid.
2. Throughrectangularholeonrearof broiler cavity,turn
orificehood(tighten),clockwisewhenfacingfrontof
range, 1½ to 2 turns or until snug. Use ½ inch open
endwrench.
• Donotovertightenorificehood.Orificehoodcan
strip.
3. Loosen air shutter lock screw and open air shutter
fully.
• Tightenair shutter lock screw after adjusting.
A—Air Shutter
Screw
B—Orifice Hood
C—Air Shutter
Converting Oven Burner
Converting Oven Thermostat for Use with
LP/Propane
1. Remove(pulloff)all(5)controlknobsfromrange.
• Exposes 2 screws on burner control panel.
2. Remove2screwsfromburnercontrol panel.
• Paneldropsslightlyafterscrews are removed.
3. Graspbottomof burner control panel, gently liftand
pulloutpanel until clear of burner valve stems.
• Afterburnercontrolpanelclearsvalvestems,
continueto roll panel until free fromrange. Set
aside.
4. Turn the selector screw on oven thermostat so the
pointeris towards “LP”.
5. Reversesteps1–3 to replace controlpanel and
knobs.
Converting Oven Thermostat
AB
C
D
A
B
Open Fully
Selector Screw
LP N
OFF
LP N
OFF
LP N
OFF
A
B
C
Open
Full
y

11
Converting for Use with Natural Gas
Converting Surface Burners for Use with
Natural Gas
1. Remove(pulloff)all(5)controlknobsfromrange.
• Exposes 2 screws on burner control panel.
2. Remove2screwsfromburnercontrol panel.
• Paneldropsslightlyafterscrews are removed.
3. Graspbottomof burner control panel, gently liftand
pulloutpanel until clear of burner valve stems.
• Afterburnercontrolpanelclearsvalvestems,
continueto roll panel until free fromrange. Set
aside.
• Gasvalveand orifice hood arevisibleafterburner
controlpanelare removed.
4. Whilefacingrange front, turn orifice hoods clockwise
1½ to 2 turns.
• Use½ inch open end or 90° offsetopen end
wrench.
5. Close air shutter to approximately 3/8inch.
Converting Oven Burner for Use with Natural Gas
1. Openbroilerdoorandremovebroilerrack,pan,and
grid.
2. Turnorificehoodcounterclockwise(loosen)2full
turns using ½ inch open end wrench.
3. Close air shutter to approximately 3/8inch.
4. Replacebroilerdoor.
Converting Oven Thermostat for Use with Natural
Gas
1. Remove(pulloff)all(5)controlknobsfromrange.
• Exposes 2 screws on burner control panel.
2. Remove2screwsfromburnercontrol panel.
• Paneldropsslightlyafterscrews are removed.
3. Graspbottomof burner control panel, gently liftand
pulloutpanel until clear of burner valve stems.
• Afterburnercontrolpanelclearsvalvestems,
continueto roll panel until free fromrange. Set
aside.
4. Turn the selector screw so the pointer is towards “N”.
5. Reversesteps1-3 to replace controlpanel and
knobs.
Converting Type 1 Pressure Regulator for Use with
Natural Gas
1. Removepressureregulatorcapwitha wrench.
2. Removeplasticinsertfrompressureregulatorcap.
• Plastic insert fits tightly in cap.
3. Reverse plastic insert and carefully push plastic insert
firmlyinto hole in pressure regulator cap.
• Insertmust show “NAT”or be blank.
4. Placepressureregulatorcaponpressureregulator
andtighten.
• Insertshouldnot disturb spring in body ofregulator.
Converting Type 2 Pressure Regulator for Use with
Natural Gas
1. Removepressureregulatorcapwitha wrench.
2. Reversepressureregulatorcap.
• Insert shows “NAT” or is blank.
3. Placepressureregulatorcaponpressureregulator
andtighten.

12
A
BCD
E
F
G
A—Regulator
B—Union
C—Manual Shut OffValve
D—Reducing Elbow (3/4-inch to 1/2-inch)
E—3/4-inch Stub (Typical)
F—1/2-inch Nipple
G—1/2-inch Black Pipe
HardpipeConnection
Testing for Gas Leaks
After final gas connection is made, turn on manual gas
valve and test all connections in gas supply piping and
range for gas leaks. Leak testing of the appliance
shall be conducted according to the manufacturer’s
instructions.
WARNING
!
Toavoidpropertydamageor serious personal injury,
never use a lighted match to test for gas leaks.
Gas Connection
Connectgassupply to regulator using hard pipeorflexible
connector(Checklocalcodes).Pressure regulator
supplied with this appliance has a ½ inch NPT female
connection.Ifgasunionisused,removestoragedrawer,
slide range into place, and connect union.
• Referto National Fuel Gas Code orlocal codes for
supply pipe size requirements to assure sufficient gas
supply to unit.
• Amanual Shut-off, not supplied with range, mustbe
installed in an accessible location outside of range.
• Use joint compound that is resistant to action of
propanegason all male pipe threads.
• Usesuppliedpressureregulatoronly.
• Donotovertighten gas fitting when attaching to
pressureregulator. Overtighteningmaycrackregulator.
• Supportpressureregulatorwithwrenchwheninstalling
gas fitting.
WARNING
!
Toavoidpropertydamageor personal injury, only use
a new flexible connector that is AGA/CGA design
certified.
• Do not use an old connector.
• Do not reuse a connector after moving appliance.
A
B
C
D
E
A—Regulator
B—Adaptor
C—FlexibleConnector
D—Manual Shut OffValve
E—3/4 Inch Stub (Typical)
FlexibleConnection
Gas Connection
1. Mix container with soapy water.
2. Place soap suds on connection.
• Bubbles appear if leak is present.
3. Ifbubblesappear, shut offgas supply valve.
4. Tighten joint if leak is at factory fitting.
• If leak is not at factory fitting, unscrew, apply more
joint compound, and tighten to correct leak.
5. Retestconnectionfor leak after tightening.
• Retest any connections that were disturbed.
Test for Gas Leaks

13
Anti-Tip and Burner Installation
Anti-tip Bracket Installation
Toreduceriskof range tipping, secure rangewith a
properlyinstalledanti-tip bracket.
1. Measure 31/2inches from back wall on right and left
sideof cabinet cutout. Mark measurements on floor
and draw a straight line connecting marks.
2. Position anti-tip bracket.
• Ifrange is installed besidecabinet(s), place anti-tip
bracketwith back edge on line drawnon floor and
side of bracket against cabinet.
• If range is not installed beside cabinet(s), position
rangewhere it will be installed. Draw aline along
sideofrangeonfloorfromfronttoback. Remove
range.Placeanti-tip bracket with back edge over
line drawn 31/2inches from back wall and side of
bracketoverlinedrawnalongsideofrangeonfloor.
• Anti-tip bracket can be installed on either right or
left side.
or
3 1/2"
Anti-tipBracketLocation
3. Mark 2 hole locations in anti-tip bracket.
4. Drill 2 holes.
• If drilling into wood, use a 3/32 inch drill bit.
• If drilling into concrete, use a 3/16 inch masonry drill
bit and insert plastic anchors.
5. Secure bracket to floor using screws supplied.
6. Afterrangeis slid into position,verify the range
levelingleghasengagedanti-tipbracket.
Verifying anti-tip bracket position
1. Afterrangeis in place, open broiler doorand remove
broiler rack, pan, and grid.
2. Removescrewsin front of broiler areaon side of
range that antitip bracket is installed.
3. Removepaneland look towards back of oven and
checkanti-tip bracket has engaged leveling leg.
4. Reinstall panel after checking anti-tip bracket.
Remove
Screws
Remove
Panel
VerifyAnti-tip Bracket Position

14
Correct
Not centered Too small Too large
Burner Caps
Test and Adjust Surface Burner Flame
WARNING
!
To avoid electric shock that can cause personal
injury or death, disconnect main electrical supply to
rangebeforeservicing.
Turnonburner. See OperatingSurfaceBurners sectionfor
burneroperatinginstructions.Surfaceburnershouldignite
within4seconds.Properlyadjusted surface burner flames
are clean and blue with a distinct inner cone
approximately ¼ inch to ½ inch long. Some yellow flame
isnormalwhen burning LP/Propane. See AdjustingAir
Shutter section.
• Ifburnerflame is blowing or noisy, reduce airflow to
burner by closing air shutter
• Ifburnerflame does not hold its shape, increase airflow
toburnerby opening air shutter.
A
Burner
A—¼ inch to ½ inch long
Surface Burner Flame
Burner Installation (cont’d)
Place Range
Plug in range. Slide range into place. Connect gas supply
asneeded.Carefullylevel range using legsprovided.
Rangemust be level tocook and bake uniformly.
• Placea level on top oven rackor on top of range when
leveling.
• Leveling legs must be extended out ¼ inch to engage
anti-tipbracket.
Removal and Reinstallation of Range
1. Unplugrangecord.
2. Turnoffgas valve and disconnect gas supply.
3. Removerangeand place aside.
4. Removeanti-tipbracketandre-install anti-tip bracket
intonewlocationusinginstructions provided with
bracket.
5. To re-installrange, follow instructions in Installation
section of this manual.
• Donotreuseaflexibleconnectoraftermoving
appliance.
Place Grates and Burner Caps
Placeburnercaponburner base and grate on rangetop.
A
B
C
A—Burner grate
B—Burner cap
C—Burner base
Place Grates and Burner Caps
Pegs in the burner base fit into recess in underside of
burnercap. Tomake sure cap isproperly aligned and
leveled,moveburner cap around onburnerbase.Burner
capmust be correctly seated on burnerbase for proper
operationof burner.
Make sure proper cap size is on each burner base.
Burnerdoesnot burn properly if wrong sizeburnercap is
placedonburnerbase.
Turnonburnerstocheckforproperoperation.See
OperatingSurfaceBurners sectionforburneroperating
instructions.

15
Adjusting Air Shutter
1. Removeall(5)burnercontrolknobs from range.
• Exposes 2 screws on burner control panel.
2. Remove2screwsfromburnercontrol panel.
• Paneldropsslightlyafterscrews are removed.
3. Graspbottomof burner control panel, gently liftand
pulloutpanel until clear of burner valve stems.
• Afterburnercontrolpanelclearsvalvestems,
continueto roll panel until free fromrange. Set
aside. See Pivot Point in figure.
• Gasvalveand orifice hood arevisibleafterburner
controlpanelisremoved.
AB
C
D
A—Burner Control Knob
B—Pivot Point
C—Burner Control Panel
D—Screw
Burner Control Panel
4. Slide air shutter open or closed depending on
appearanceofburnerflame.
• If flame is yellow and does not hold its shape, open
airshutter.
• If flame is blowing or noisy, close air shutter.
5. Repeat test if necessary.
6. Reassembleburnercontrolpanel.
Open Close
AdjustingAir Shutter
Test and Adjust Oven Burner Flame
Properlyadjustedovenburnerflamesarebluewitha
distinct deep blue inner cone approximately ½ inch long.
Whenusingnatural gas, flame should not haveanyyellow
flamewhenburning.Someyellowtipping when burning
LP/Propanegasis normal.
1/2"
ProperlyAdjusted Flame
Flameshouldnotbevisible in the oven cavity when
burningandshouldnotextend into the oven cavity beyond
theremovableovenbottom.
Removing Oven Bottom
CAUTION
!
Toavoidriskofcuts, wear protective gloves when
removingovenbottom.Sharp edges around oven
bottom can cut.
1. Pullovenbottom forward and lift out.
2. Replaceovenbottom. Oven bottom has tabs in rear
that fit into oven floor slots and lip at front that fits
underburnerwell.
BurnerArea
Burner Installation (cont’d)

16
Setting Clock and Timer
Use to increase time
Use to decrease time
Setting Electronic Clock
1. Press CLOCK pad.
2. Press up or down arrow pad until correct minutes display.
3. Press CLOCK pad to set time of day.
Setting Electronic Timer
Electronic timer does not control bake or broil. Timer can be set up to 12 hours. Time displays and counts
down in hours and minutes when more than 59 minutes are entered. For example, 1:30 equals one hour and
thirty minutes, or 90 minutes total.
1. Press TIMER pad.
• 0:00 minutes displays.
2. Press up or down arrow pad to set time.
• Press an arrow pad once to advance 1 minute at a time, or press and hold arrow pad to advance in
increments of 10 minutes.
• If desired time is more than 1 hour press and hold up arrow pad until desired time displays.
3. Colon in display flashes and the timer begins counting down automatically after time is entered.
4. When the timer count down reaches 1 minute, the timer beeps once to remind you that 1 minute of time
remains.
5. After time elapses, timer beeps 3 times, and then once every 10 seconds until TIMER pad is pressed.
• Display returns to time of day after TIMER pad is pressed.
Canceling Electronic Timer
Press TIMER pad to cancel timer.
TIMER
CLOCK
++

17
Adjusting Burner Flame Size
• While turning the burner control knob, watch the
burner flame.
• Flame size should match the size of the pan. Do not
allow the flame to extend up the sides of the pan.
Flames that extend up the sides of the pan can ignite
clothing, make handle hot, or burn.
Adjusting Burner Flame Size
Operating Surface Burner during a Power
Failure
Although the system that lights the burners is electric,
surfaceburnerscanbeignitedduringapowerfailure.
Never attempt to light bake/broil burner during
power failure.
1. Hold match at base of desired burner.
2. Push in burner control knob and turn to LITE
position.
3. After gas ignites, remove match from burner and
turn burner control knob to desired setting.
WARNING
!
Toavoidriskof serious personal injury, property
damage,orfire, do not leave burners unattended
whilein operation. Grease and spilloverscan ignite
causing a fire.
1. Push in and turn control knob counterclockwise to
LITE position.
• Burner should ignite within 4 seconds. If burner
does not ignite within 4 seconds turn control knob
to OFF position and follow directions in “Placing
GratesandBurnerCaps”and“Before Calling for
Service”section.Tryburneragain.Ifburnerstill
does not ignite in 4 seconds, contact an authorized
servicer.
Control Knob
2. After gas ignites, turn control knob to desired setting.
• Each control knob can be set to any required
cooking temperature. Burner settings do not have
distinct clicks.
• Use HI tobring food to boiling temperatures. When
food is boiling temperature setting should be
reduced.
• After lighting burner do not operate burner for long
periods of time without cookware on the grate. The
finish on the grate can chip without cookware to
absorb heat.
3. Turncontrolknob to OFF positionwhen finished
cooking.
Operating Surface Burners
O
F
F
H
I
L
I
T
E
G
A
S
O
N

18
• Use proper pan size. Do not use a pan that has a
smaller bottom than surface burner. Do not use
utensilsthat overhang grate by more than 1inch.
More than 1 inch
overhang
Does not cover burner
Use proper pan size
• Use care when using glazed cooking utensils. Some
glass, earthenware, or other glazed utensils break due
to sudden temperature changes.
• Select utensils without broken or loose handles.
• Handles should not be heavy enough to tilt pan.
• Do not use stove top grills on your range. Stove top
grills cause incomplete combustion and can create
levels of carbon monoxide above allowable standards.
• Do not use a wok with a ring stand. Use flat bottom
wok.
Wok
Toavoidpan wobbling, use a panwith a flat bottom.
Determine if pan has a flat bottom.
1. Rotate a ruler along bottom of pan. If pan is not flat,
gaps between bottom of pan and edge of ruler occur.
2. A small groove or mark on a pan does not effect
cooking times. However, if a pan has a gap, formed
rings, or an uneven bottom, it does not cook
efficiently and in some cases may not boil liquid.
Use Pan with Flat Bottom
Utensil Material Characteristic
Type Temperature
Response Uses
Aluminum Heats and
cools quickly Frying, braising, roasting
Cast Iron Heats and
cools slowly Low heat cooking, frying
Copper Tin
Lined Heats and cools quickly Gourmet cooking, wine
sauces, egg
dishes
Enamelware Depends on
base metal Low heat cooking
Ceramic (Glass) Heats and
cools slowly Low heat cooking
Stainless Steel Heats and
cools at
moderate rate
Soups, sauces,
vegetables,
general cooking
Utensil Recommendations

19
Prepare to Bake
Remove Items Stored in Oven
Remove any pans and other cooking utensils stored in
oven. Items left in oven can cause damage to the oven or
itemin oven.
Remove Items Stored in Oven
Oven Rack Placement
Position oven rack before turning ovenon.
WARNING
!
Toavoiddamagingovenlinerorcreating fire, do not
line oven bottom or oven racks with foil.
1. Pull rack forward to stop position.
2. Raise front edge of rack and pull until rack is out of
oven.
3. Place rack in new rack position.
• Curvededgeof rack must be toward rear of oven.
Oven Rack Placement
Pan Placement
• Keep pans and baking sheets 2 inches from oven
walls.
• Stagger pans placed on different racks so one is not
directlyoverthe other.
PanPlacement
Baking
1. To preheat oven,turnoventemperatureknobto
desiredtemperature.
• Preheatovenfor approximately 15-20 minutes.
2. Placefoodin oven.
3. Aftercooking,removefoodandturnoventemperature
knobto OFF .
Temperature Knob
Check for Bake Burner Flame
Allownomorethan40–60secondsbeforeburnerignites
and heat is felt. To check for heat, open oven door to first
stopand place hand over oven door. If heat is notfelt, turn
control knob to OFF position. If burner repeatedly fails to
ignite,contactanauthorizedservicer.
Baking and Broiling

20
Adjusting Factory Set Baking Temperature
Oven temperature is set at factory. When first using oven,
follow recipe times and temperatures. If you think oven is
too hot or too cool, temperature can be adjusted. Before
adjusting oven baking temperature, test a recipe by using
atemperature set higher or lower thanthe recommended
temperature. The baking results should help you to
decide how much adjustment is needed.
1. Pull oven thermostat knob straight out from control
panel.
2. Turnknobover and loosen screwsusing Phillips
screwdriver.
•Do not remove screws.
3. While holding knob front, turn outer part of knob until
pointer points to next line.
• Turnouterknob clockwise to decrease or
counterclockwisetoincreasetemperature.
• Eachlineadjusts temperature approximately 10
degreesFahrenheit.
• Only move knob one line at a time.
4. Tighten screws with pointer in new position and
replaceknob on control panel.
• Useovenwith known recipe beforemovingpointer
again.
D
E
C
R
E
A
S
E
I
N
C
R
E
A
S
E
Loosen screws
Pointer
Temperature Knob Back
Prepare to Broil
WARNING
!
To avoid risk of fire, do not line the broiler grid with foil.
• Foil may trap grease on top of grid close to burner
causingafire.
• Neverleave ovenunattendedwhile broiling.
Overcookingmayresult in a fire.
Check Broiler Flame
Allownomorethan40–60secondsbeforeburnerignites
and flame is seen. If burner does not ignite turn
temperatureknobto OFF position.Ifburnerrepeatedly
fails to ignite within 40–60 seconds contact an authorized
servicer.
Broiling Tips
• Removeexcessfatfrommeatbeforebroiling.Cut
edgesofmeattoprevent curling.
• Placefood on a cold ungreasedbroiling pan. If pan is
hot, food sticks.
• All food except fish should be turned at least one time.
Begin broiling with skin side down.
• Seasonmeatafter it has browned.
• Broilingdoesnotrequirepreheating.
• Begin cooking using suggested rack levels in Broiling
Guide section to test broiler results. If food is not brown
enough, cook on a higher rack position. If food is too
brown, cook on a lower rack position.
Broiling
1. Openbroilerdoor, slide outbroiler rack, center food
onbroiling grid, and slidebroiler rack into oven.
2. Closebroilerdoor.
3. TurnoventemperatureknobtoBROIL.
4. After broiling, open broiler door, slide out broiler rack,
removefood from broiling grid, slidebroiler rack into
oven,andclose broiler door.
5. Turnoventemperature knob to OFF.
A
B
C
A—Broiler Grid
B—Broiler Pan
C—BroilerRack
Broiler Pan and Grid
Baking and Broiling (cont’d)
