Cambium Networks PTP 820S Parts list manual

Cambium
PTP 820S
Technical Description
System Release 7.9

Accuracy
While reasonable efforts have been made to assure the accuracy of this document, Cambium
Networks assumes no liability resulting from any inaccuracies or omissions in this document, or
from use of the information obtained herein. Cambium reserves the right to make changes to
any products described herein to improve reliability, function, or design, and reserves the right
to revise this document and to make changes from time to time in content hereof with no
obligation to notify any person of revisions or changes. Cambium does not assume any liability
arising out of the application or use of any product, software, or circuit described herein; neither
does it convey license under its patent rights or the rights of others. It is possible that this
publication may contain references to, or information about Cambium products (machines and
programs), programming, or services that are not announced in your country. Such references
or information must not be construed to mean that Cambium intends to announce such
Cambium products, programming, or services in your country.
Copyrights
This document, Cambium products, and 3rd Party software products described in this document
may include or describe copyrighted Cambium and other 3rd Party supplied computer programs
stored in semiconductor memories or other media. Laws in the United States and other
countries preserve for Cambium, its licensors, and other 3rd Party supplied software certain
exclusive rights for copyrighted material, including the exclusive right to copy, reproduce in any
form, distribute and make derivative works of the copyrighted material. Accordingly, any
copyrighted material of Cambium, its licensors, or the 3rd Party software supplied material
contained in the Cambium products described in this document may not be copied, reproduced,
reverse engineered, distributed, merged or modified in any manner without the express written
permission of Cambium. Furthermore, the purchase of Cambium products shall not be deemed
to grant either directly or by implication, estoppel, or otherwise, any license under the
copyrights, patents or patent applications of Cambium or other 3rd Party supplied software,
except for the normal non-exclusive, royalty free license to use that arises by operation of law in
the sale of a product.
Restrictions
Software and documentation are copyrighted materials. Making unauthorized copies is
prohibited by law. No part of the software or documentation may be reproduced, transmitted,
transcribed, stored in a retrieval system, or translated into any language or computer language,
in any form or by any means, without prior written permission of Cambium.
License Agreements
The software described in this document is the property of Cambium and its licensors. It is
furnished by express license agreement only and may be used only in accordance with the
terms of such an agreement.
High Risk Materials
Cambium and its supplier(s) specifically disclaim any express or implied warranty of fitness for
any high risk activities or uses of its products including, but not limited to, the operation of
nuclear facilities, aircraft navigation or aircraft communication systems, air traffic control, life
support, or weapons systems (“High Risk Use”). Any High Risk is unauthorized, is made at your
own risk and you shall be responsible for any and all losses, damage or claims arising out of any
High Risk Use.
© 2014 Cambium Networks Limited. All Rights Reserved.
phn-3973 001v000

Contents
About This User Guide .......................................................................................................................... 1
Contacting Cambium Networks.................................................................................................... 1
Purpose ........................................................................................................................................... 2
Cross references............................................................................................................................. 2
Feedback ......................................................................................................................................... 2
Problems and warranty ........................................................................................................................ 3
Reporting problems ....................................................................................................................... 3
Repair and service.......................................................................................................................... 3
Hardware warranty ........................................................................................................................ 3
Security advice ...................................................................................................................................... 4
Warnings, cautions, and notes ............................................................................................................ 5
Warnings ......................................................................................................................................... 5
Cautions .......................................................................................................................................... 5
Notes ............................................................................................................................................... 5
Caring for the environment.................................................................................................................. 6
In EU countries ............................................................................................................................... 6
In non-EU countries ....................................................................................................................... 6
Chapter 1:
Introduction...................................................................................................................1-1
Product Overview...............................................................................................................................1-2
Unique PTP 820S Feature Set ...........................................................................................................1-3
System Configurations ......................................................................................................................1-4
Chapter 2:
PTP 820S Hardware Description ..................................................................................2-1
PTP 820S Unit Description ................................................................................................................2-2
Hardware Architecture................................................................................................................2-3
Interfaces......................................................................................................................................2-4
Management Connection for Protection Configurations ........................................................2-5
PoE Injector.........................................................................................................................................2-7
PoE Injector Interfaces ................................................................................................................2-7
Chapter 3:
Licensing .......................................................................................................................3-1
Working with License Keys ...............................................................................................................3-2
Demo License .....................................................................................................................................3-3
Licensed Features ..............................................................................................................................3-4
Chapter 4:
Feature Description.......................................................................................................4-1
Innovative Techniques to Boost Capacity and Reduce Latency ....................................................4-2
Capacity Summary......................................................................................................................4-3
Header De-Duplication................................................................................................................4-3
Frame Cut-Through.....................................................................................................................4-6
Page i

Contents
Adaptive Coding Modulation (ACM) .........................................................................................4-7
External Protection....................................................................................................................4-10
ATPC...........................................................................................................................................4-14
Radio Utilization PMs................................................................................................................4-15
Ethernet Features .............................................................................................................................4-16
Ethernet Services Overview .....................................................................................................4-16
PTP 820S’s Ethernet Capabilities .............................................................................................4-30
Supported Standards................................................................................................................4-31
Ethernet Service Model ............................................................................................................4-31
Ethernet Interfaces ....................................................................................................................4-49
Quality of Service (QoS) ...........................................................................................................4-58
Global Switch Configuration....................................................................................................4-84
Automatic State Propagation...................................................................................................4-84
Adaptive Bandwidth Notification (EOAM) ..............................................................................4-86
Network Resiliency....................................................................................................................4-87
OAM............................................................................................................................................4-91
Synchronization ...............................................................................................................................4-95
PTP 820S Synchronization Solution ........................................................................................4-95
Available Synchronization Interfaces ......................................................................................4-96
Synchronous Ethernet (SyncE) ................................................................................................4-96
IEEE-1588 Transparent Clock ...................................................................................................4-97
SSM Support and Loop Prevention.........................................................................................4-99
Chapter 5:
PTP 820S Management ................................................................................................5-1
Management Overview .....................................................................................................................5-2
Management Communication Channels and Protocols.................................................................5-3
Web-Based Element Management System (Web EMS).................................................................5-6
Command Line Interface (CLI) ..........................................................................................................5-7
Configuration Management ..............................................................................................................5-8
Software Management ......................................................................................................................5-9
Backup Software Version ...........................................................................................................5-9
In-Band Management ......................................................................................................................5-11
Local Management ..........................................................................................................................5-12
Alarms ...............................................................................................................................................5-13
Configurable RSL Threshold for Alarms and Traps...............................................................5-13
Alarms Editing ...........................................................................................................................5-13
NTP Support .....................................................................................................................................5-14
UTC Support .....................................................................................................................................5-15
System Security Features................................................................................................................5-16
Layered Security Concept ........................................................................................................5-16
Defenses in Management Communication Channels ...........................................................5-17
Defenses in User and System Authentication Procedures....................................................5-18
Secure Communication Channels ...........................................................................................5-20
Security Log...............................................................................................................................5-23
Page ii

Contents
Chapter 6:
Standards and Certifications ........................................................................................6-1
Supported Ethernet Standards .........................................................................................................6-2
Chapter 7:
Specifications................................................................................................................7-1
Radio Specifications ..........................................................................................................................7-2
General .........................................................................................................................................7-2
Frequency Accuracy....................................................................................................................7-5
Radio Capacity Specifications....................................................................................................7-5
Transmit Power Specifications ................................................................................................7-10
Receiver Threshold Specifications ..........................................................................................7-13
Overload Thresholds.................................................................................................................7-22
Frequency Bands.......................................................................................................................7-22
Mediation Device Losses ..........................................................................................................7-33
Networking Specifications ..............................................................................................................7-34
Ethernet Latency Specifications...............................................................................................7-34
Interface Specifications.............................................................................................................7-39
Carrier Ethernet Functionality ..................................................................................................7-39
Synchronization Functionality .................................................................................................7-41
Network Management, Diagnostics, Status and Alarms .............................................................7-42
Physical and Electrical Specifications ............................................................................................7-43
Mechanical Specifications........................................................................................................7-43
Antenna Specifications .............................................................................................................7-43
Power Specifications.................................................................................................................7-44
PoE Injector Specifications.......................................................................................................7-45
Cable Specifications..................................................................................................................7-46
Glossary ..................................................................................................................................................I
List of Figures
Figure 1 PTP 820S Rear View (Left) and Front View (Right)................................................................2-2
Figure 2 Cable Gland Construction........................................................................................................2-2
Figure 3 PTP 820S Block Diagram .........................................................................................................2-3
Figure 4 PTP 820S Interfaces..................................................................................................................2-4
Figure 5 Protection Signalling Cable Pinouts .......................................................................................2-5
Figure 6 PoE Injector ...............................................................................................................................2-7
Figure 7 PoE Injector Ports .....................................................................................................................2-8
Figure 8 Header De-Duplication.............................................................................................................4-3
Figure 9 Header De-Duplication Operation on Frame Structure.........................................................4-5
Figure 10 Propagation Delay with and without Frame Cut-Through .................................................4-6
Figure 11 Frame Cut-Through................................................................................................................4-7
Figure 12 Frame Cut-Through................................................................................................................4-7
Figure 13 Adaptive Coding and Modulation with 11 Working Points ................................................4-8
Figure 14 1+1 HSB Protection – Line Protection Mode ......................................................................4-10
Figure 15 1+1 HSB Protection – Split Protection Mode .....................................................................4-11
Page iii

Contents
Figure 16 Multiple Traffic Interfaces with Optical Splitters ...............................................................4-11
Figure 17 Internal and Local Management .........................................................................................4-12
Figure 18 Basic Ethernet Service Model .............................................................................................4-17
Figure 19 Ethernet Virtual Connection (EVC)......................................................................................4-17
Figure 20 Point to Point EVC ................................................................................................................4-18
Figure 21 Multipoint to Multipoint EVC...............................................................................................4-18
Figure 22 Rooted Multipoint EVC ........................................................................................................4-19
Figure 23 MEF Ethernet Services Definition Framework...................................................................4-20
Figure 24 E-Line Service Type Using Point-to-Point EVC ..................................................................4-22
Figure 25 EPL Application Example.....................................................................................................4-22
Figure 26 EVPL Application Example ..................................................................................................4-23
Figure 27 E-LAN Service Type Using Multipoint-to-Multipoint EVC ................................................4-23
Figure 28 Adding a Site Using an E-Line service ...............................................................................4-24
Figure 29 Adding a Site Using an E-LAN service ...............................................................................4-24
Figure 30 MEF Ethernet Private LAN Example ...................................................................................4-25
Figure 31 MEF Ethernet Virtual Private LAN Example.......................................................................4-26
Figure 32 E-Tree Service Type Using Rooted-Multipoint EVC ..........................................................4-26
Figure 33 E-Tree Service Type Using Multiple Roots ........................................................................4-27
Figure 34 MEF Ethernet Private Tree Example ...................................................................................4-27
Figure 35 Ethernet Virtual Private Tree Example ...............................................................................4-28
Figure 36 Mobile Backhaul Reference Model .....................................................................................4-29
Figure 37 Packet Service Core Building Blocks ..................................................................................4-29
Figure 38 PTP 820S Services Model ....................................................................................................4-32
Figure 39 PTP 820S Services Core.......................................................................................................4-33
Figure 40 PTP 820S Services Flow.......................................................................................................4-34
Figure 41 Point-to-Point Service ..........................................................................................................4-35
Figure 42 Multipoint Service ................................................................................................................4-36
Figure 43 Management Service ...........................................................................................................4-38
Figure 44 Management Service and its Service Points .....................................................................4-40
Figure 45 SAPs and SNPs.....................................................................................................................4-41
Figure 46 Pipe Service Points...............................................................................................................4-41
Figure 47 SAP, SNP and Pipe Service Points in a Microwave Network...........................................4-42
Figure 48 Service Path Relationship on Point-to-Point Service Path ...............................................4-47
Figure 49 Physical and Logical Interfaces ...........................................................................................4-49
Figure 50 Grouped Interfaces as a Single Logical Interface on Ingress Side ..................................4-50
Figure 51 Grouped Interfaces as a Single Logical Interface on Egress Side ...................................4-50
Figure 52 Relationship of Logical Interfaces to the Switching Fabric ..............................................4-53
Figure 53 QoS Block Diagram ..............................................................................................................4-58
Figure 54 Standard QoS and H-QoS Comparison..............................................................................4-59
Figure 55 Hierarchical Classification ...................................................................................................4-60
Figure 56 Classification Method Priorities ..........................................................................................4-61
Figure 57 Ingress Policing Model ........................................................................................................4-66
Figure 58 PTP 820S Queue Manager...................................................................................................4-69
Page iv

Contents
Figure 59 Synchronized Packet Loss ...................................................................................................4-70
Figure 60 Random Packet Loss with Increased Capacity Utilization Using WRED .........................4-70
Figure 61 WRED Profile Curve .............................................................................................................4-71
Figure 62 Detailed H-QoS Diagram .....................................................................................................4-75
Figure 63 Scheduling Mechanism for a Single Service Bundle........................................................4-77
Figure 64 Network Topology with PTP 820S Units and Third-Party Equipment.............................4-86
Figure 65 ABN Entity.............................................................................................................................4-86
Figure 66 G.8032 Ring in Idle (Normal) State .....................................................................................4-88
Figure 67 G.8032 Ring in Protecting State ..........................................................................................4-89
Figure 68 Load Balancing Example in G.8032 Ring ...........................................................................4-89
Figure 69 PTP 820S End-to-End Service Management......................................................................4-92
Figure 70 SOAM Maintenance Entities (Example) .............................................................................4-93
Figure 71 EFM Maintenance Entities (Example).................................................................................4-94
Figure 72 Transparent Clock Delay Compensation ............................................................................4-98
Figure 73 Integrated PTP 820S Management Tools.............................................................................5-2
Figure 74 Security Solution Architecture Concept.............................................................................5-16
List of Tables
Figure 1 PTP 820S Rear View (Left) and Front View (Right)................................................................2-2
Figure 2 Cable Gland Construction........................................................................................................2-2
Figure 3 PTP 820S Block Diagram .........................................................................................................2-3
Figure 4 PTP 820S Interfaces..................................................................................................................2-4
Figure 5 Protection Signalling Cable Pinouts .......................................................................................2-5
Figure 6 PoE Injector ...............................................................................................................................2-7
Figure 7 PoE Injector Ports .....................................................................................................................2-8
Figure 8 Header De-Duplication.............................................................................................................4-3
Figure 9 Header De-Duplication Operation on Frame Structure.........................................................4-5
Figure 10 Propagation Delay with and without Frame Cut-Through .................................................4-6
Figure 11 Frame Cut-Through................................................................................................................4-7
Figure 12 Frame Cut-Through................................................................................................................4-7
Figure 13 Adaptive Coding and Modulation with 11 Working Points ................................................4-8
Figure 14 1+1 HSB Protection – Line Protection Mode......................................................................4-10
Figure 15 1+1 HSB Protection – Split Protection Mode .....................................................................4-11
Figure 16 Multiple Traffic Interfaces with Optical Splitters ...............................................................4-11
Figure 17 Internal and Local Management .........................................................................................4-12
Figure 18 Basic Ethernet Service Model .............................................................................................4-17
Figure 19 Ethernet Virtual Connection (EVC)......................................................................................4-17
Figure 20 Point to Point EVC ................................................................................................................4-18
Figure 21 Multipoint to Multipoint EVC...............................................................................................4-18
Figure 22 Rooted Multipoint EVC ........................................................................................................4-19
Figure 23 MEF Ethernet Services Definition Framework...................................................................4-20
Figure 24 E-Line Service Type Using Point-to-Point EVC ..................................................................4-22
Figure 25 EPL Application Example.....................................................................................................4-22
Page v

Contents
Figure 26 EVPL Application Example ..................................................................................................4-23
Figure 27 E-LAN Service Type Using Multipoint-to-Multipoint EVC ................................................4-23
Figure 28 Adding a Site Using an E-Line service ...............................................................................4-24
Figure 29 Adding a Site Using an E-LAN service ...............................................................................4-24
Figure 30 MEF Ethernet Private LAN Example ...................................................................................4-25
Figure 31 MEF Ethernet Virtual Private LAN Example.......................................................................4-26
Figure 32 E-Tree Service Type Using Rooted-Multipoint EVC ..........................................................4-26
Figure 33 E-Tree Service Type Using Multiple Roots ........................................................................4-27
Figure 34 MEF Ethernet Private Tree Example...................................................................................4-27
Figure 35 Ethernet Virtual Private Tree Example ...............................................................................4-28
Figure 36 Mobile Backhaul Reference Model .....................................................................................4-29
Figure 37 Packet Service Core Building Blocks ..................................................................................4-29
Figure 38 PTP 820S Services Model ....................................................................................................4-32
Figure 39 PTP 820S Services Core.......................................................................................................4-33
Figure 40 PTP 820S Services Flow.......................................................................................................4-34
Figure 41 Point-to-Point Service ..........................................................................................................4-35
Figure 42 Multipoint Service ................................................................................................................4-36
Figure 43 Management Service ...........................................................................................................4-38
Figure 44 Management Service and its Service Points .....................................................................4-40
Figure 45 SAPs and SNPs.....................................................................................................................4-41
Figure 46 Pipe Service Points...............................................................................................................4-41
Figure 47 SAP, SNP and Pipe Service Points in a Microwave Network...........................................4-42
Figure 48 Service Path Relationship on Point-to-Point Service Path ...............................................4-47
Figure 49 Physical and Logical Interfaces ...........................................................................................4-49
Figure 50 Grouped Interfaces as a Single Logical Interface on Ingress Side ..................................4-50
Figure 51 Grouped Interfaces as a Single Logical Interface on Egress Side ...................................4-50
Figure 52 Relationship of Logical Interfaces to the Switching Fabric ..............................................4-53
Figure 53 QoS Block Diagram ..............................................................................................................4-58
Figure 54 Standard QoS and H-QoS Comparison..............................................................................4-59
Figure 55 Hierarchical Classification ...................................................................................................4-60
Figure 56 Classification Method Priorities ..........................................................................................4-61
Figure 57 Ingress Policing Model ........................................................................................................4-66
Figure 58 PTP 820S Queue Manager...................................................................................................4-69
Figure 59 Synchronized Packet Loss ...................................................................................................4-70
Figure 60 Random Packet Loss with Increased Capacity Utilization Using WRED .........................4-70
Figure 61 WRED Profile Curve .............................................................................................................4-71
Figure 62 Detailed H-QoS Diagram .....................................................................................................4-75
Figure 63 Scheduling Mechanism for a Single Service Bundle........................................................4-77
Figure 64 Network Topology with PTP 820S Units and Third-Party Equipment.............................4-86
Figure 65 ABN Entity.............................................................................................................................4-86
Figure 66 G.8032 Ring in Idle (Normal) State .....................................................................................4-88
Figure 67 G.8032 Ring in Protecting State ..........................................................................................4-89
Figure 68 Load Balancing Example in G.8032 Ring ...........................................................................4-89
Page vi

Contents
Figure 69 PTP 820S End-to-End Service Management......................................................................4-92
Figure 70 SOAM Maintenance Entities (Example) .............................................................................4-93
Figure 71 EFM Maintenance Entities (Example).................................................................................4-94
Figure 72 Transparent Clock Delay Compensation............................................................................4-98
Figure 73 Integrated PTP 820S Management Tools.............................................................................5-2
Figure 74 Security Solution Architecture Concept.............................................................................5-16
Page vii

About This User Guide
This guide describes the PTP 820S installation procedures and provides additional information
concerning system parts and frequency bands
This guide contains the following chapters:
•Chapter 1: Introduction
•Chapter 2: PTP 820S Hardware Description
•Chapter 3: Licensing
•Chapter 4: Feature Description
•Chapter 5: PTP 820S Management
•Chapter 6: Standards and Certifications
•Chapter 7: Specifications
Contacting Cambium Networks
Support website: http://www.cambiumnetworks.com/support
Main website: http://www.cambiumnetworks.com
Sales enquiries: [e-mail]
Support enquiries: [e-mail]
Telephone number list: http://www.cambiumnetworks.com/support/contact-support
Address: Cambium Networks Limited,
Linhay Business Park,
Eastern Road,
Ashburton,
Devon, UK,
TQ13 7UP
Page 1

About This User Guide Problems and warranty
Purpose
Cambium Networks Point-To-Point (PTP) documents are intended to instruct and assist personnel
in the operation, installation and maintenance of the Cambium PTP equipment and ancillary
devices. It is recommended that all personnel engaged in such activities be properly trained.
Cambium disclaims all liability whatsoever, implied or express, for any risk of damage, loss or
reduction in system performance arising directly or indirectly out of the failure of the customer, or
anyone acting on the customer's behalf, to abide by the instructions, system parameters, or
recommendations made in this document.
Cross references
References to external publications are shown in italics. Other cross references, emphasized in
blue text in electronic versions, are active links to the references.
This document is divided into numbered chapters that are divided into sections. Sections are not
numbered, but are individually named at the top of each page, and are listed in the table of
contents.
Feedback
We appreciate feedback from the users of our documents. This includes feedback on the structure,
content, accuracy, or completeness of our documents. Send feedback to
[e-mail].
Page 2

About This User Guide Problems and warranty
Problems and warranty
Reporting problems
If any problems are encountered when installing or operating this equipment, follow this
procedure to investigate and report:
1
Search this document and the software release notes of supported releases.
2
Visit the support website.
3
Ask for assistance from the Cambium product supplier.
4
Gather information from affected units, such as any available diagnostic downloads.
5
Escalate the problem by emailing or telephoning support.
Repair and service
If unit failure is suspected, obtain details of the Return Material Authorization (RMA) process from
the support website.
Hardware warranty
Cambium’s standard hardware warranty is for one (1) year from date of shipment from Cambium
Networks or a Cambium distributor. Cambium Networks warrants that hardware will conform to
the relevant published specifications and will be free from material defects in material and
workmanship under normal use and service. Cambium shall within this time, at its own option,
either repair or replace the defective product within thirty (30) days of receipt of the defective
product. Repaired or replaced product will be subject to the original warranty period but not less
than thirty (30) days.
To register PTP products or activate warranties, visit the support website. For warranty assistance,
contact the reseller or distributor.
Caution
Using non-Cambium parts for repair could damage the equipment or void warranty.
Contact Cambium for service and repair instructions.
Portions of Cambium equipment may be damaged from exposure to electrostatic
discharge. Use precautions to prevent damage.
Page 3

About This User Guide Security advice
Security advice
Cambium Networks systems and equipment provide security parameters that can be configured
by the operator based on their particular operating environment. Cambium recommends setting
and using these parameters following industry recognized security practices. Security aspects to
be considered are protecting the confidentiality, integrity, and availability of information and
assets. Assets include the ability to communicate, information about the nature of the
communications, and information about the parties involved.
In certain instances Cambium makes specific recommendations regarding security practices,
however the implementation of these recommendations and final responsibility for the security of
the system lies with the operator of the system.
Page 4

About This User Guide Warnings, cautions, and notes
Warnings, cautions, and notes
The following describes how warnings and cautions are used in this document and in all
documents of the Cambium Networks document set.
Warnings
Warnings precede instructions that contain potentially hazardous situations. Warnings are used to
alert the reader to possible hazards that could cause loss of life or physical injury. A warning has
the following format:
Warning
Warning text and consequence for not following the instructions in the warning.
Cautions
Cautions precede instructions and are used when there is a possibility of damage to systems,
software, or individual items of equipment within a system. However, this damage presents no
danger to personnel. A caution has the following format:
Caution
Caution text and consequence for not following the instructions in the caution.
Notes
A note means that there is a possibility of an undesirable situation or provides additional
information to help the reader understand a topic or concept. A note has the following format:
Note
Note text.
Page 5

About This User Guide Caring for the environment
Caring for the environment
The following information describes national or regional requirements for the disposal of
Cambium Networks supplied equipment and for the approved disposal of surplus packaging.
In EU countries
The following information is provided to enable regulatory compliance with the European Union
(EU) directives identified and any amendments made to these directives when using Cambium
equipment in EU countries.
Disposal of Cambium equipment
European Union (EU) Directive 2002/96/EC Waste Electrical and Electronic Equipment (WEEE)
Do not dispose of Cambium equipment in landfill sites. For disposal instructions, refer to
http://www.cambiumnetworks.com/support
Disposal of surplus packaging
Do not dispose of surplus packaging in landfill sites. In the EU, it is the individual recipient’s
responsibility to ensure that packaging materials are collected and recycled according to the
requirements of EU environmental law.
In non-EU countries
In non-EU countries, dispose of Cambium equipment and all surplus packaging in accordance with
national and regional regulations.
Page 6

Chapter 1: Introduction
Cambium’s PTP 820S represents a new generation of radio technology, capable of high bit rates
and longer reach, and suitable for diverse deployment scenarios.
PTP 820S supports cutting edge capacity-boosting techniques, such as QPSK to 2048 QAM and
Header De-Duplication, to offer a high capacity solution for every network topology and every site
configuration. Its green, compact, all-outdoor configuration makes PTP 820S ideal for any location.
This chapter includes:
•Product Overview
•Unique PTP 820S Feature Set
•System Configurations
Page 1-1

Chapter 1: Introduction Product Overview
Product Overview
Delivering ultra-high capacity in any licensed band (6-38 GHz) PTP 820S provides a new level of
wireless capacity in current and emerging backhaul scenarios. PTP 820S combines a compact, all-
outdoor design, QPSK to 2048 QAM modulation, and an advanced feature set for Carrier Ethernet
Transport that includes a sophisticated Ethernet services engine, cutting-edge header de-
duplication techniques, frame cut-through, and more, to provide a compact and efficient solution
for a wide variety of cost-effective deployment scenarios including macrocell backhaul, small-cell
aggregation and emerging front haul applications.
PTP 820S is easily and quickly deployable compared with fiber, enabling operators to achieve
faster time to new revenue streams, lower total cost of ownership, and long-term peace of mind.
PTP 820S is an integral part of the family of high-capacity wireless backhaul products. Together,
the product series provides a wide variety of backhaul solutions that can be used separately or
combined to form integrated backhaul networks or network segments.
The series “pay-as-you-go” licensing model further enables operators to build for the future by
adding capacity and functionality over time to meet the needs of network growth without requiring
additional hardware.
Page 1-2

Chapter 1: Introduction Unique PTP 820S Feature Set
Unique PTP 820S Feature Set
The following table summarizes the basic PTP 820S feature set.
Table 1
PTP 820S Feature Set
Extended Modulation Range
ACM 4-2048 QAM (11 ACM points)
Frequency Bands
6-38 GHz
Wide Range of Channels
28, 30, 40, 50, 56, 60, 80 MHz
Power over Ethernet (PoE)
Proprietary
Small Form Factor
(H)230mm x (W)233mm x (D)98mm
(H) 9.06in x (W)9.17in x (D) 3.86in
Durable All-Outdoor System
IP66-compliant
Page 1-3

Chapter 1: Introduction System Configurations
System Configurations
PTP 820S is designed to support the following site configurations:
•1+0 Direct Mount
•1+1 HSB Direct Mount
•2+0 Direct Mount
Page 1-4

Chapter 2: PTP 820S Hardware Description
This chapter describes the PTP 820S components, interfaces and mediation devices.
This chapter includes:
•PTP 820S Unit Description
•PoE Injector
Page 2-1
