Camec RV Media 043169 User manual

Instruction Manual
12/24/240V Full HD LED TV/DVD/USB Combo
043169 (22")

Contents
1
What’s in the Box
TV Controls
TV Inputs and Outputs
Remote Control
SYSTEM CONNECTIONS
AV Input
PC Input
HDMI Input
YPbPr Component Input
USB Input
5
6
7
12-14
8
8
9
9
10
COAXIAL Output 10
OSD MENU OPERATION
Sound
Channel
Feature
Setup
EPG
MEDIA OPERATION
Music
Mocie
E-Book
Built-in DVD Player Operation
16-17
18-19
20-24
25-27
28-29
30-33
38-39
40-42
43
43
44-49
PVR 33
Cleaning and Maintenance
Troubleshooting
50
51-52
53
Specifications
Antenna Connection 11
Important Safety Instructions
Source Selection 15
Auto Installation 34-37
Stand mount guide
7

Important Safety Instructions Important Safety Instructions (cont)
reference, along with the warranty card, purchase receipt and carton. The safety
correctly adhered to.
• Before installing this TV set, make sure your outlet voltage corresponds to the
voltage stated on the appliance rating label of the power adaptor being used..
• Do not overload the power outlet.
• CAUTION
the power supply cord, plug and antenna cable to rain or moisture; do not use it
anywhere near water; do not touch the power plug with wet hands.
• Do not let the cord hang over the edge of a table or counter, or touch hot surfaces.
• Do not allow anything to rest on or roll over the power cord and antenna cable.
Protect the cord and run all cables so that no one steps on or trips over them.
• Do not run the cord near heat-producing appliances such as radiators, stoves or
irons. The excessive heat could melt the insulation and expose live wires.
• Only use this TV with the power adaptors supplied. If either plug does not
fit into your outlets, consult your dealer or an RV service center for
• When not in use, disconnect the power cord from the outlet. Hold the plug, not
the cord, when disconnecting the unit. Pulling the cord can damage the internal
wires and may cause a fire.
• Never touch the TV screen, antenna or cord during thunderstorms. Stop use
during thunderstorms; unplug the unit when a thunderstorm is approaching.
Position
• If a television is not positioned in a sufficiently stable location, when stand
mounted, it can potentially be hazardous if it falls. Many injuries, particularly to
children, can be avoided by taking simple precautions such as:
• Using cabinets, shelves or stands that provide a sturdy support for the TV and are
not in areas where the TV can be accidently knocked or bumped .
• Only using furniture that can safely support the television.
• Ensuring the TV is not overhanging the edge of the supporting furniture.
• Not placing the TV on tall furniture (for example, cupboards or bookcases)
without anchoring both the furniture and the TV to a suitable support.
• Educating children about the dangers of climbing up to reach the TV controls.
• Not standing the TV on cloth or other materials placed between the TV and
supporting furniture.
Usage conditions and restrictions
• Follow the instructions in this manual when installing and adjusting the TV set.
Only adjust those controls that are covered in this instruction manual; improper
adjustment of other controls may result in damage. If this happens, unplug the TV
and have it serviced by appropriately qualified personnel.
• Do not change or modify the TV set in any way. Only use the attachments/
accessories specified.
• Do not cover the ventilation openings with items such as newspapers, tablecloths,
curtains etc., as this could impede ventilation.
• Do not insert any objects of any kind into this unit through the ventilation slots or
DVD slot, as they could touch the current-carrying parts or short-circuit parts,
resulting in fire, electric shock or damage to the unit.
• Do not touch the screen with fingers, as this may scratch or smudge the TV screen.
• Do not expose the batteries to excessive heat such as sunshine, fire or the like.
• Unplug the TV set in all of the following circumstances:
• If it has been subject to impact or has been dropped and is damaged.
• If its voltage adaptor plugs, or the wall socket, are damaged.
• The appliance is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge,
unless they have been given supervision or instruction concerning use of the
appliance by a person responsible for their safety.
• Young children should be supervised to ensure they do not play with the TV.
2 3
56cm (22")
Full HD LED TV
Part Number: 043169
INPUT DC 12V Max 3A 36W
June 2 015

4 5
What’s in the Box
22" TV with inbuilt DVD Player
Manual
• When deciding where to put the TV set, make sure the location is:
• Well ventilated. Leave at least a 20cm space all around the TV set for good
ventilation.
• Protected from overheating and away from direct sunlight.
• Away from damp and cold.
• Away from areas with extremes of temperature (below 0°C or exceeding 40°C)
or moisture.
• Away from moisture drips or splashes.
• Protected from excessive dust.
• Do not install this equipment in a confined space such as a bookcase or similar.
• Do not put any objects filled with liquids, such as vases, on top of the TV set.
• Do not place any naked flame sources, such as lighted candles, on top of the TV.
Important Safety Instructions (cont)
Instruction Man ua l
12/24/240V FHD LED TV/DVD/USB Combo
043169(22")
Column bracket
4 Screws
Remote Control
4 Screws

TV Controls
TV Controls
76
100 100
1. VOL(+) - This button increases the TV’s volume. If the OSD menu is active, pressing this button will
move the selection to the right.
2. VOL(-) - This button decreases the TV’s volume. If the On Screen Display(OSD) menu is active,
pressing this button will move the selection to the left.
3. CH(+) - This button performs the channel up function. If the OSD menu is active, this button functions
as up control for the menu.
4. CH(-) - This button performs the channel down function. If the OSD menu is active, this button
functions as down control for the menu.
6. MENU - This button activates the OSD menu. If a sub-menu is active, pressing this button will return
the selection to the previous menu level.
5. SOURCE - This button switches between all the different sources of the TV. When the OSD is active,
this button acts as the enter button and confirms the menu selection.
7. After you load a disc, press to play the disc, and press twice to pause.
8. Press the button when the power is on the disc will eject, Press the button again to load the
disc automatically.
9. POWER( ) - Turn on the TV by pressing the button once. Press the button again to turn off the TV.
Stand mount guide
1. POWER: (DC 12V) input
2. Earphone out: Output for headphones or head units such as RV Media Head Units with TV input.
3. AV Inputs: Composite Video & Audio (A/V) in.
4. PC Audio Input: Connect to the audio output jack on a computer.
5. VGA Input: Connect to a computer’s VGA output jack.
6. HDMI Input: HDMI in.
7. COAXIAL Out: Digital Audio output for Surround Sound amplifiers and other devices.
8. RF Input: Connect to an external antenna to receive ATV/DTV TV signals
in ATV/DTV modes.
9. USB: USB/Multimedia input.
10. Y/Pb/Pr Input: Component Video in.
Rear Bottom
Rear Side
1 2 3 5 64
DC 12V
EARPHONE
OUT VIDEO RL VGA HDMI
PC
AUDIO
IN
RF
IN USB
9
COAXIAL
OUT Y PrPb
8 107
IN
IN
TV Inputs & Outputs
Screws
Screw hole A
Screw hole B
Instructions:
1. Place the TV unit on a flat and clean surface.
2. Attach stand mount using 4 screws through holes B into A.
3. Place the base on to the mount with the supplied screws
through holes D into C.
Screws
Screw hole C
Screw hole D
four

8 9
System Connection System Connection
NOTE: Please, make sure the inputs and outputs have firm connections before
connecting power.
1. COMPOSITE A/V INPUT
Audio/video input: Use the SOURCE button to select AV on the remote control.
VGA O UTPU T
PC AUDIO
OUTPUT
VGA OUTPUT
2. PC INPUT
PC input: Use the SOURCE button on the remote control to select PC.
Video Cable Red/White/Yellow (Not supplied)
3. HDMI INPUT
HDMI input: Use the SOURCE button on the remote control to select HDMI.
Source eg. Blu-ray, DVD, Satellite, camcorder etc
HDMI 1
4. YPbPr COMPONENT INPUT
Video component input: Use the SOURCE button on the remote control to select YPbPr.
This input consists of both Video (Green/Blue/Red) and Audio (Red/White)
YPb Pr
RF
IN USB
COAXI AL
OUT Y PrPb
IN
DC 12V
EARPH ON E
OUT VID EO RL VGA HDM I
PC
AUDIO
IN
IN
RF
IN USB
COAXI AL
OUT Y PrPb
IN
DC 12V
EARPH ON E
OUT VID EO RL VGA HDM I
PC
AUDIO
IN
IN
RF
IN USB
COAXI AL
OUT Y PrPb
IN
DC 12V
EARPH ON E
OUT VID EO RL VGA HDM I
PC
AUDIO
IN
IN
RF
IN USB
COAXI AL
OUT Y PrPb
IN
DC 12V
EARPH ON E
OUT VID EO RL VGA HDM I
PC
AUDIO
IN
IN

11
System Connection
Remote Control
7. Antenna connection
Antenna input impedance of this unit is 75ohm. VHF/UHF 75ohm coaxial cable can be
connected to the antenna jack directly.
75ohm coaxial cable
Antenna cable
Antenna lead with 75 ohm male PAL Connector
- Batteries should not be exposed to excessive heat such as direct
sunlight, fire or the like.
- If not being used for a period of time, please remove the batteries
from the remote in case of leakage.
- Do not mix old & new batteries together.
Installing Batteries
1Open the battery compartment
cover on the back of the remote.
2Insert two 1.5V AAA size batteries
using the correct polarity as shown.
Don’t mix old or used batteries with.
3Replace the cover.
Battery
Cover
2 x size AAA 1.5V
Battery
Cover
System Connection
new ones..
To use the remote control, point
it towards the remote sensor at
the front of the television. The
remote control has a range of up
to approximately seven meters
from the TV at an angle of up to
60 degrees.
5. COAXIAL OUTPUT
Allows connection of Digital audio systems and Surround Sound.
6. USB INPUT
Use the SOURCE button on the remote controller to select Media.
USB memory
COAXIAL Cable (Not supplied)
COAXIAL
10
RF
IN USB
COAXI AL
OUT Y PrPb
IN
DC 12V
EARPH ON E
OUT VID EO RL VGA HDM I
PC
AUDIO
IN
IN
RF
IN USB
COAXI AL
OUT Y PrPb
IN
DC 12V
EARPH ON E
OUT VID EO RL VGA HDM I
PC
AUDIO
IN
IN

12 13
Remote-Control Unit
P.MODE S.MODE A UTO
DIS PLAY SOU RCE
EXIT MENU
AUDIO
REC.MENU
POWER MUTE
FAV EPG
HOLD
SUBTITLE
INDEX
REVEAL TEXT
SUBPAGE SIZE
REC
OK
QT
TIME SHIFT
ASPECT
TV/RADIO
CANCEL MIX
D.MENU SETUP D.DISP
A-B
REPEAT
I/II
SLEEP
1
4
6
11
15
9
21/25
22/26
29
30
33
37
41
34
38/45
42/48
16
2
3
5
8
7
10
13
14
12
17
18/19
20 24/28
23/27
32
31
36
35
40/47
39/46
44/50
43/49
Allows you to navigate the on‐screen menus and adjust the
system settings to your preference.
Press these two buttons to increase/decrease the volume.
Press to change the DTV or DVD audio language.
No. Button Description
POWER Turns the TV on or off to standby mode. 1
2MUTE Press to mute the sound. Press again to regain sound.
0‐9 Press 0‐9 to select a TV channel directly. The cannel will
change after 2 seconds.
3
4
5Return to the previously viewed program.
6
7
AUTO
8
9
P.MODE
10
S.MODE
11
12
Select the picture mode.
Select the sound mode.
EXIT
MENU
Exit from the current menu or sub‐menu.
Allows you to navigate the on screen menus (OSD).
13
14 OK Select the option.
15
16 VOL+/‐
CH+/‐ Press these two buttons to change channels up/down.
AUDIO
17
18
ASPECT Press this button to select the aspect ratio of the screen.
20
DISPLAY Press to display the source and channel info.
25
26
27
28
Use for adjustments in PC mode.
Delete function button.
Rename function button.
Move function button.
Skip function button.
R (DELETE)
G (RENAME)
Y (MOVE)
B (SKIP)
29 FAV Selects favorite channel(s).
30
TEXT Switch on/off of Teletext window.
31
32
33
34
35
36
SUBTITLE Press to select the subtitle language.
INDEX Returns to Index page by Teletext.
REVEAL Shows hidden words or pages by Teletext.
EPG Press to display EPG (Electronic Program Guide).
SOURCE Press to select signal the source for the TV.
QT
Eject/insert disc.
D.MENU Quick Teletext navigation or setup settings / DVD: Video
DVD Menu button.
SETUP DVD system setup.
D.DISP Quick navigation during Teletext or setup settings / DVD: DVD
Information button.
TIME SHIFT Press to switch to TIME SHIFT mode.
SLEEP Set the delay time for the TV to turn off automatically.
Press to record the program immediately.
REC/
37
38 TV/RADIO Press to switch between DTV and radio programs
21
22
23
24
Quick Tune. Quick TV Channel Autotune Button.
I/II
19
Select NICAM audio mode.
Only be available for TV programmers with NICAM transmission,
and default mode is mono.
REC.MENU Press to switch to REC.MENU immediately (DTV only).

14 15
OSD Menu Operation
Press SOURCE button to display the input source list.
Press the ▼/▲ buttons to select the input source you want
to watch,
Press the OK button to select the input source.
Source Selection
No. Button Description
42
45
46
47
48
49
50
SIZE Zoom In or Out of the Teletext window.
Play and Pause Media‐Player / DVD.
Stops playback Media‐Player and DVD.
Fast Rewind Media‐Player and DVD.
Fast Forward Media‐Player and DVD.
Plays the previous Media Player or DVD file/chapter.
Plays the next Media Player or DVD file/chapter..
Holds on the current Teletext page.
HOLD
Displays a sup‐page of upper Teletext options.
SUBPAGE
MIX Sets the transparency of Teletext window.
DVD: Repeat mode selection.
REPEAT
40
41
43
44
39 CANCEL Switches the Teletext window to the background; only the
current page no is visible.
Press MENU button to display the MAIN OSD MENU.
Press ▼/▲ buttons to select the sub MENU that you want.
Press ENTER button or button to enter the sub menu, and press button to return back ► ◄
to the previous menu.
Press ▼/▲ buttons to select an option in the submenu and then press ENTER button or ►
button to select the option. Press buttons to adjust the value or press ▼/▲ buttons to ◄ / ►
select drop down options.
You can press MENU button to save and return back to the previous menu, and press
EXIT button to exit the entire menu.s
Input
DTV
ATV
AV
YPbPr
HDMI
PC
Media
DVD
Main Menu

16 17
OSD Menu Operation
Picture Menu
Press TV MENU button to display the main menu.
Press ▼/▲ buttons to select Picture in the main menu,
then press ENTER button or ► button to select.
OSD Menu Operation
Press ▲/▼ buttons to select the option that you want to adjust in the Picture menu,
and then press ENTER button or ► button to select..
Press ◄/► buttons to adjust or press ▲/▼ button to select. And press ENTER button
or ► button to select the sub menu.
After finishing your adjustment, press MENU button to save and return back to the
previous menu, and press EXIT button to exit the entire menu..
Brightness
Press ▲/▼ buttons to select Brightness, then press ENTER button or ► button to
enter and press ◄/► buttons to adjust. Then press MENU button to return back
the previous menu.
Contrast
Press ▲/▼ buttons to select Contrast, then press ENTER button or ► button to enter
and press ◄/► buttons to adjust. Then press MENU button to return back the previous
menu.
Sharpness
Press ▲/▼ button to select Sharpness, then press ENTER button or ► button to enter
and press ◄/► buttons to adjust. Then press MENU button to return back the previous
menu directly.
Colour
Press ▲/▼ button to select Colour, then press ENTER button or ► button to enter
and press ◄/► buttons to adjust. Then press MENU button to return back the previous
menu directly.
Tint
Press ▼/▲ buttons to select Tint, then press ENTER button or ►button to enter and
press◄ / ►buttons to adjust.
Colour Temperature
Press ▲/▼ buttons to select Colour Temperature, then press ENTER button or ►
button to enter and ▲/▼ button to select Standard, Cool, Warm.
Aspect Ratio
Press ▲/▼ button to select Aspect Ratio, then press ENTER button or ► button
to highlight and ▲/▼ button to select Auto,4:3,16:9,Zoom1,Zoom2 or Panorama.

18 19
OSD Menu Operation OSD Menu Operation
Sound Menu
Press MENU button to display the main menu..
Press ▲/▼ buttons to select Sound in the main menu, then press ENTER button
or ► button to select.
Press ▲/▼ buttons to select the option that you want to adjust in the Sound menu, then
press ENTER button or ► button to enter..
Press ◄/► buttons to adjust or press ▲/▼ to select, and press ENTER or ► button to
return to the submenu..
After finishing your adjustment, Press MENU button to save and return back to the
previous menu, or press EXIT button to exit the entire menu.
Sound Mode
Press ▲/▼ buttons to select Sound Mode, and then press ENTER or ► button to enter.
Then press ▲/▼ buttons to select. (Available Sound mode: Bass, Treble, EQ, Balance).
You can change the value of bass and treble, Balance and EQ, when the sound is in
User mode.
TIP: You can press S-MODE button on the remote control to change the Sound Mode
directly..
Bass
Press ▲/▼ buttons to select Bass, then press ENTER or ► button to enter and press
◄/► buttons to adjust. Then press MENU button to return back the previous menu.
Treble
Press ▲/▼ buttons to select Treble, then press ENTER or ► button to enter and press
◄/► buttons to adjust. Then press MENU button to return back the previous menu.
Balance
Press ▲/▼ buttons to select Balance, then press ENTER or ► button to enter and press
◄/► buttons to adjust. Then press MENU button to return back the previous menu.
Surround
Press ▲/▼ button to select Surround, then press ENTER or ► button to enter and press
▲/▼button to select ON or OFF. Turning this setting ON can also be useful in increasing the
TV’s overall volume level.
AVL - Auto Volume
This function when turned on will help even out the volume level between different A/V
sources so one is not greatly louder than another. It can also help reduce the volume of
loud TV ads compared to TV shows, although could lower the overall volume of the TV.
The result depends greatly on the A/V source so this function is set by default to off.
Press ▲/▼ button to select AVL, then press ENTER or ► button to enter and press ▲/▼
button to select ON or OFF.
SPDIF
Press ▲/▼ button to select SPDIF, then press ENTER or ► button to enter and press ▲/▼
button to select .
(Available SPDIF modes: Off, PCM, Bitstream)
Then press ENTER button or ► button to enter and press ◄/► buttons to adjust, then
press MENU button to return back the previous menu.
Audio Description
Press ▲/▼ buttons to select Audio Description, then press ENTER or ► button to enter and
press ▲/▼buttons to select ON or OFF.

20 21
OSD Menu Operation OSD Menu Operation
Channel Menu
Press MENU button to display the main menu.
Press ▲/▼ buttons to select Channel in the main menu, then press ENTER button
or ► button to enter.
1. Press ▲/▼ buttons to select the option that you want to adjust in the Channel menu,
then press ENTER or ► button to enter.
2. Press ▲/▼ buttons to select and press ENTER or ► button to select the sub menu.
3. After finishing your adjustment, press MENU button to save and return back to the
previous menu, or press EXIT button to exit the entire menu.
Channel Management
Press ▲/▼ buttons to select Channel Management, then press ENTER or ► button to enter.
Press the RED button to set the current channel to lock, if the current channel already
locked, press the RED button again cancel the lock.
Press the GREEN button to delete the current channel.
Press the YELLOW button to skip the current channel, if the current channel already
skipped, press the YELLOW button again to cancel the skip function.
Press the BLUE button to swap the channel position.
If one of the channel has been incorrectly placed in the station listing, you may move it to
the current position you want using the ▲/▼ keys. Select the channel to be moved, press the
BLUE button, move the channel to the new location and press the ENTER button or the
BLUE button, this will move the station to the new location.
If there is a delete channel icon, press the MENU button or the ENTER button. The following
notification will appear:
Press ◄ to choose OK, or press ► to cancel, press ENTER to confirm.

OSD Menu Operation OSD Menu Operation
22 23
Press ▲/▼ buttons to select the channel, then press ENTER to open the rename channel menu.
Press the RED button to enter a space.
Press the GREEN button to change case,
Press ▲/▼ or ▲/▼ buttons to select the character, and then press ENTER to confirm.
Press the YELLOW button to delete the previous character.
Press the BLUE button to save the change and return to the previous page.
Press the EXIT button and the menu will appear as follows:
Select “Cancel” to exit the entire menu without changes.
Select “OK” to save the changes and the following notification will be displayed:
Favorites Manager
Press ▲/▼ buttons to select Favorite Manager, then press ENTER or ► button to enter.
Press ▲/▼ buttons to select Channel, press the RED button to set to Fav1.
Press ▲/▼ buttons to select Channel, press the GREEN button to set to Fav2.
Press ▲/▼ buttons to select Channel, press the YELLOW button to set to Fav3.
Press ▲/▼ buttons to select Channel, press the BLUE button to set to Fav4.
If the current channel already be one of your favorite channels, press the RED/ GREEN/
YELLOW/ BLUE button again will set it to a normal channel.
Press the MENU button or EXIT button and the successfully updated menu will appear.
Country
Press ENTER button or ► button to enter, then Press ▲/▼ button to select the appropriate
country, and press ENTER or ► button to confirm.
TV Connection
The default setting for this mode is “AIR”. This setting does not need to be changed for RV
operation in Australia.
Channel Auto Search
Press ▲/▼ button to select TV Channel Auto Search, then press ENTER or ► button to enter
(When the System Lock is on, please input the default password “0000”).

OSD Menu Operation OSD Menu Operation
24 25
Auto Search - cont’d
Press ▲/▼ buttons to select All, Digital or Analogue, then press ENTER or ► button to select.
Press ENTER to Auto Search the selected channels, otherwise select CANCEL.
NOTE: For most applications in Australia, only DTV channels are used for regular TV
broadcasts.
When auto search finished, a “Save Successful” will appear to confirm the Auto Search
function has completed.
Feature Menu
Press MENU button to display the main menu.
Press ▲/▼ button to select Feature in the main menu, then press ENTER or ► to enter.
1. Press ▲/▼ buttons to select the option that you want to adjust in the Feature menu,
then press ENTER or ► button to enter.
2. Press ◄/►buttons to adjust or press ▲/▼button to select.
3. After finishing your adjustment, press MENU button to save and return back to the
previous menu and press EXIT button to exit the entire menu.
Child Lock
Press ▲/▼ buttons to select Child Lock, then press ENTER or ► button to enter.
(Please enter the default password “0000”)
PVR/Timeshift

OSD Menu Operation OSD Menu Operation
26 27
Enter the old password at (if the old password is incorrect, “Invalid
Password” will be displayed). Then enter the new password. Finally, enter the new password
again to confirm the new password.
If successful, a notification will be displayed to confirm this.
Lock Channel
This enables Parental Guidance to be activated and the TV’s Password to be changed.
Press ▲/▼ buttons to select Child Channel, then press ◄/► key to select off or on.
Then press ENTER or ► button to confirm.
Parental Guidance
Press ▲/▼ buttons to select Parental Rating, then press ENTER or ► button to enter the
sub menu. Then press ▲/▼ button to select the highest allowed program rating.
Then press ENTER or ► button to confirm.
Change Pin Code
Press ▲/▼ buttons to select Change Pin Code, then press ENTER or ► button to enter and
the Change Pin Code menu will appear as follows:
Language
Press ▲/▼ button to select Language, then press ENTER or ► button to enter the sub menu.
OSD Language
Press ▲/▼ buttons to select OSD Language, then press ENTER or ► button to enter the
sub menu, then press ▲/▼ buttons to select, then press ENTER or ► button to confirm.
Preferred Subtitle (Language)
Press ▲/▼ buttons to select Preferred Subtitle, then press ENTER or ► button to enter
the sub menu, then Press ▲/▼ buttons to select, then press ENTER or ► button to confirm.
Preferred Audio (Language)
Press ▲/▼ buttons to select Preferred Audio, press ENTER or ► button to enter the sub
menu, then press ▲/▼ buttons to select, then press ENTER or ► button to confirm.
Digital Teletext Language (DTV)
Press ▲/▼ buttons to select Digital Teletext language, then press ENTER or ► button to
enter the sub menu, then Press ▲/▼ buttons to select, then press ENTER or ► button to
confirm.
Analog Teletext Language (ATV)
Press ▲/▼ buttons to select Analog Teletext language, then press ENTER or ► button
to enter the sub menu, then Press ▲/▼ buttons to select, then press ENTER or ► button
to confirm.
Clock
Press ▲/▼ buttons to select Clock, then press ENTER or ► button to enter the sub menu,
By default the clock information is supplied by DTV data. Press ▲/▼ buttons to select your
time zone, then press ENTER or ► button to confirm. If you want to manually adjust the
clock settings, first change “DST” to “OFF” then manually adjust the other clock settings.
Sleep (Timer)
Press ▲/▼ buttons to select Sleep, then press ENTER or ► button to select and press
▲/▼ buttons to select the desired time for the TV to automatically turn off.
Auto Power Off
Press ▲/▼ buttons to Auto Power Off, then press ENTER or ► button to enter and press
▲/▼ buttons to select the desired time of no activity (eg if you do not change the TV channel
or adjust the volume for the selected time).
Hearing Impaired
Offers additional information and subtitles on selected programmes. Press ▲/▼ buttons to
select Hearing Impaired, then press ENTER or ► button to enter and press ▲/▼ buttons
to select ON or OFF.

OSD Menu Operation OSD Menu Operation
28 29
Setup Menu
Press MENU button to display the main menu.
Press ▲/▼ button to select Setup in the main menu, then press ENTER or ► to enter.
1. Press ▲/▼ buttons to select the option that you want to adjust in the Setup menu, then
press ENTER or ► button to select.
2. Press ◄/►buttons to adjust or press ▲/▼button to select.
3. After finishing your adjustment(s), press MENU button to save and return back to the
previous menu and press EXIT button to exit the entire menu.
OSD Timer
Press ▲/▼ buttons to select OSD Timer which controls how long the OSD menus will be
displayed, then press ENTER or ► button to enter the sub menu, then Press ▲/▼ buttons to
select. (OSD Timer options: 5 Second, 10 Second, 15 Second, 20 Second, 25 Second, 30
Second, never), then press ENTER or ► button to confirm.
PC Setup
Press ▲/▼ buttons to select PC Setup, then press ENTER or ► to enter the sub menu,
Then Press ► to enter, then press ENTER or ► to confirm (when a PC signal is connected).
Blue
Press ▲/▼ buttons to select Blue screen when there is no input source, then press ENTER
or ► to enter the sub menu, then Press ▲/▼ to select On or Off. Press ENTER or ► to confirm.
Home Mode (Picture Mode)
Press ▲/▼ buttons to select OSD Timer, then press ENTER or ► button to enter the sub
menu, Then Press ▲/▼ buttons to select. (Home, Dynamic, Standard, Mild.), then press
ENTER or ► button to confirm.
Reset TV Setting
To reset the TV to its fatory settings, press ▲/▼ buttons to select Reset TV Setting, and then
press ENTER or ► to select. The password menu will appear when the Child Lock is on.
Software Upgrade
Caution - this function is only to be used with Software supplied for use with this RV Media
TV by Camec. Load the supplied software on to the root directory of an empty USB drive and
plug it into the TV ‘s USB interface then press the ENTER key to upgrade. Do not turn the TV
off during the upgrade process. The TV will restart when the upgrade process has completed..
PC Setup
Blue Screen
Home Mode
Reset TV Setting
Software Upgrade
PVR/Timeshift
Press MENU button to display the main menu. Press ▲/▼ buttons to select PVR/Timeshift in
the main menu, then press ENTER or ► to enter.
Partition Select
This function is not necessarily required but you have the ability to use partitions on your
USB drive for the PVR (Personal Video Recorder) function. Press the ▲/▼ buttons to select
Partition Select, then press ENTER or ► button to enter the sub menu, then Press ▲/▼
buttons to select the partition you want to use and press the GREEN button to set the
highlighted partition as default. This will restrict PVR recordings to the selected partition.
Auto Timeshift
Press ▲/▼ button to select Auto Timeshift, then press ENTER or ► to enter the sub menu,
then Press ▲/▼ to select On or Off.
Timeshift Buffer
This sets the period of time the Time Shift function con work for. This also depends on the
available space on the USB drive. Press ▲/▼ buttons to select Timeshift Buffer, then press
the ENTER or ► button to open the sub menu, then Press ▲/▼ buttons to select between:
auto, 30Mins, 1Hr & 2Hr.
Timer (Manual Recording)
Use the Timer function to set up timer DTV recording. Press ▲/▼ button to select Timer,
then press ENTER or ► button to enter the sub menu, then Press ▲/▼ buttons to select and
use the following functions. Recorder - Turn the record function on/off; Channel - select the
channel you want to record; Start Time - set the start time to record; Duration - set the
record duration; Date - set the record date; Mode - select the record mode.
Record List
Press ▲/▼ button to view the program Record List, then press ENTER or ► button to enter
the sub menu, then Press ▲/▼ buttons to select.
Recorder Start
Press ▲/▼ buttons to select Recorder Start, then press ENTER or ► button to enter the sub
menu, then Press ▲/▼ buttons to select.

OSD Menu Operation OSD Menu Operation
30 31
Channel List
Press the LIST button on the remote control to display the channel list menu.
Press ▲/▼ button to select channel that you want to view, then press ENTER to view.
FAV List
Press the FAV button on the remote control to display the Favorite List menu..
Press ▲/▼ buttons to select channel that you want to view, then press the ENTER button to
view the channel.
Press ◄/► buttons to switch between Favorite 1, Favorite 2, Favorite 3 and Favorite 4.
Subtitle
Press the subtitle button on the remote control and subtitle menu will appear as follows:
Press ◄/► buttons to turn OFF, then press the ENTER button to turn off subtitles.
Press ▲/▼ buttons to you select ENG, then press the ENTER button to display subtitles in
English. Press EXIT to exit.
EPG (ELECTRONIC PROGRAM GUIDE)
Press the EPG button on the remote control to display the EPG daily view.

OSD Menu Operation OSD Menu Operation
32 33
1. The display shows the current channel No. and channel name.
2. The display shows the program’s start and finish time plus program name.
3. The display shows the current date and time.
Press ▲/▼ buttons to select the channel or program.
Press ◄/► buttons to select the channel program.
Press the RED the button to switch between EPG weekly mode and EPG daily mode.
1
2
3
To view programs from the previous day or further back, press the YELLOW button to
move to an earlier date.
To view programs for the next day or further on, press the BLUE button increase the date.
For more information about a particular program, press INFO.
Press the GREEN button once to add the selected channel to the record list.
Press the GREEN button twice to set a Reminder for the program, which will display a small
icon beside the selected program.
Press EPG once more or EXIT once to cancel the operation.
TEXT
Press the TT/CC button on the remote control to display the text/closed captions; press the
TT/CC button on the remote control again to stop the display.
Multi-Audio
Press AUDIO button on the remote control to display the multi-audio menu if available.
Press ◄/► buttons to select the audio language format - (available audio format: right,
stereo, left). Press ▲/▼ buttons to change the setting.
PVR Function (DTV Only)
Press on the remote control to record the current programme when DTV is selected as the●
current Source. NOTE you must have a USB drive inserted in TV. If the USB drive is not fast
enough to record on, the following message will be displayed:
It is advisable to try another USB drive but you can select “OK” to continue with the current
drive.Press on the remote control to start recording which will display the following dialog:
Select “Yes” to start recording. The following dialog will be displayed:
While Recording is in progress, a small dialog box will be displayed on the left of screen:
Press on the remote control again to set the Record duration time.●
Rec Duration Time 0 0 : 0 0
Press on the remote control to stop recording.
To stop recording select “Yes”; to continue recording select “No”.

OSD Menu Operation OSD Menu Operation
34 35
Auto Installation
If you are turning on the TV for the first time and there are no TV stations stored on the TV,
the “Auto Installation” menu will appear on the screen.
There are 5 steps as follows:
Step 1: Set Home Mode (Picture Mode)
Step 2: Set the Country
Note: Australia is set as the default country.
Step 3: Set the Language
Note: Australia is set as the default country
Step 4: Set Auto Power Off
Note: The default setting is “Off”.

OSD Menu Operation OSD Menu Operation
36 37
Step 5: Set up the TV Connection
The default connection for this TV is “Air”.
Step 6: Set up the Auto Search
Only DTV is required for most applications in Australia.
