SERVICEMANUAL
ColorTelevisionReceiver
Model: KS21TK305A
PDF 件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.com.cn

SERVICE MANUAL
2
CONTENTS
I.IMPORTANTSERVICESAFETY INFORMATION 3
II.ALIGNMENTPROCEDURESPLEASEREAD BEFOREATTEMPTING
SERVICE 5
III. TVSPECIFICATION ...5
IV. TVADJUSTMENT7
V.ICINFORMATION ....12
1.PHILIPS UOCIII CHIP(N603)12
2.SWITCHPOWERIC(N901)41
3.VERTICALDEFLECTIONBOOSTER(N401)45
4.AUDIOPOWERAMPLIFIER(N202)49
5.EEPROM24C16(N602)52
VI. TVBLOCKDIAGRAM57
Appendix1:SchematicCircuitDiagram58
Appendix2:PCBLayoutDiagram59
Appendix3:ExplodedViews63
PDF 件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.com.cn

SERVICE MANUAL
3
IMPORTANTSERVICESAFETYINFORMATION
Operatingthereceiveroutsideofitscabinetorwithitsbackremovedinvolvesashockhazard.
Workonthesemodelsshouldonlybeperformedbythosewhoarethoroughlyfamiliar with
precautionsnecessarywhenworkingonhighvoltageequipment.
Exercisecarewhenservicingthischassiswithpowerapplied.ManyBplusand highvoltage
RFterminalsareexposedwhich,if carelesslycontacted, cancauseseriousshockorresultindamage
tothechassis.Maintaininterconnectinggroundleadconnectionsbetweenchassis,escutcheon,
picturetubedagandtunerwhenoperating chassis.
Thesereceivershavea polarized”AClinecord.TheACplugisdesignedtofitintostandard
ACoutletsinonedirectiononly.Thewidebladeconnectstothe ground side”andthenarrowblade
connectstothehot side”oftheACline. ThisassuresthattheTVreceiverisproperlygroundedto
thehousewiring.Ifanextensioncordmustbeused,makesureitisofthe polarized”type.
SincethechassisofthisreceiveisconnectedtoonesideoftheACsupplyduringoperation,
service shouldnotbeattemptedbyanyonenotfamiliar withtheprecautionsnecessarywhen
working on thesetypesofequipment.
WhenitisnecessarytomakemeasurementsortestswithACpowerappliedtothereceiver
chassis, anIsolationTransformermustbeusedasasafetyprecautionand topreventpossible
damagetotransistors. TheIsolation TransformershouldbeconnectedbetweentheTVlinecord
plug andtheACpoweroutlet.
CertainHighvoltage(HV) maybecauseX-rayradiation. Receiversshouldnotbeoperatedwith
HV levelsexceedingthespecifiedratingfortheir chassistype.Highervoltagemayalsoincreasethe
possibilityoffailureintheHV supply.
Itisimportanttomaintainspecifiedvaluesofall componentsinthehorizontalandhighvoltage
circuitsand anywhereelseinthereceivethatcouldcauseariseinhighvoltage,oroperatingsupply
voltages.Nochangesshouldbemadetheoriginaldesignofthereceiver.
Componentsshownintheshadedareasontheschematicdiagramand/oridentifiedbyinthe
replacementpartslistshouldbereplacedonlywithexactfactoryrecommendedreplacementparts.
Theuseofunauthorizedsubstitutepartsmancreatsmaycreateshock,fire,X-rayradiation,orother
hazards.
Todeterminethepresenceofhighvoltage,useanaccuratehighimpedanceHV meter
connectedbetweenthesecond anodeleadandheCRTdaggroundingdevice. Whenservicingthe
PDF 件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.com.cn

SERVICE MANUAL
4
HighVoltageSystemremovestaticchargesfromitbyconnectinga10KOhmresistorinseriesWan
insulatedwire(suchastestprobe)betweenthepicturetubedagand2nd anodelead(HaveACline
corddisconnectedfromACsupply).
Thepicturetubeuseinthisreceiveremployintegralimplosion protection. Replace withatube
ofthesametypenumber forcontinuedsafety. Donotliftpicturetubebytheneck.Handlethe
picturetubeonlywhenwearingshatterproofgogglesandafter dischargingthehighvoltage
completely, Keepotherswithoutshatter proofgogglesaway.
Beforereturning thereceiver totheuser,performthefollowing safetychecks:
1.Inspectall leaddresstomakecertainthatleadsarenotpinchedor thathardwareisnot
lodgedbetweenthechassisandothermetalpartsinthereceiver.
2.Replaceallprotectivedevicessuchasnon-metalliccontrolknobs, insulatingfish-papers,
cabinetbacks,adjustmentandcompartmentcoversofshields, isolationresistor-capacitornetworks,
mechanicalinsulatorsetc.
3.Tobesurethatnotshockhazardexists, acheckforthepresenceofleakagecurrentshouldbe
madeateachexposedmetalparthaving areturnpathtothechassis(antenna, cabinetmetal,screw
headsknobsand/or shafts, escutcheon,etc.) inthefollowingmanner.
PlugtheAClinecorddirectlyintoa110V/240V(or180V/240V),ACreceptacle. (Donotuse
anIsolation Transformer duringthesechecks.)All checksmustberepeatedwiththeAClinecord
plug connectionreversed.(Ifnecessary, anon-polarizedadapter plugmustbeusedonlyforthe
purposeof completingthesechecks.)
If available, measurethecurrentusinganaccurateleakagecurrenttester. Anyreading of
0.35mAormoreisexcessiveandindicatesapotentialshockhazardwhichmustbecorrectedbefore
returningthereceivertoowner.
If areliableleakagecurrenttesterisnotavailable, thisalternatemethodofmeasurementshould
beused.Usingtwoclipleads, connecta1500Ohm,10wattresistor paralleledbya0.15MF
capacitorinserieswithaknownearthground,suchasawater pipeor conduit andthemetalpartto
bechecked. UseaVTVMor VOMwith1000OhmsperVolt, orhigher, sensitivitytomeasurethis
ACvoltagedropacrosstheresistor,. Anyreading of0.35voltRMSofmoreisexcessiveand
indicatespotentialshockhazardwhichmustbecorrectedbeforereturning hereceivertotheowner.
PDF 件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.com.cn

SERVICE MANUAL
5
ALIGNMENTPROCEDURES
PLEASEREAD BEFOREATTEMPTINGSERVICE
1. UseanIsolation Transformerwhenperforming anyservice onthischassis.
2. Neverdisconnectanyleadswhilereceiverisinoperation.
3. Disconnectallpowerbeforeattempting anrepairs.
4. Donotshortanypositionofthecircuitwhilethepowerison.
5. For safetyreasons,replacinganycomponentsshouldbeaccordingwithidenticalreplacement
parts.
6. Beforetesting, warmuptheTVfor atleast30minutesanddemagnetizetheCRTwithanexternal
degaussingcoil.
7. WhenremovingaPCB or relatedcomponent,afterunfasteningorchangingawire,besuretoput
thewirebackinitsoriginalposition.
8.Inferiorsilicon greasecandamageIC’sandtransistors.Whenreplacing IC’sandtransistors,use
onlyspecifiedsilicongrease,.Removealloldsilicon whenapplying newsilicon.
9. Beforeremoving theanodecap,dischargedrasticallybecauseit containshighvoltage.
TVSPECIFICATION
1. AmbientConditions:
1.1AmbientTemperatures:
a.Operating:-10~+40 ℃
b. Storage:-15 ~+45 ℃
1.2Humidity
a.Operation:<80%
b. Storage:<90%
1.3AirPressure:86kpa~106kpa
2. GeneralSpecification
2.1MainIC:PHILIPS UOCIII CHIP(TDA12060or TDA12062)
2.2TVBroadcastingSystem:
PDF 件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.com.cn

SERVICE MANUAL
6
PALDK/BG/I
SECAMDK/BG
2.3ScanningLines&Frequencies
525 lines/60Hzor625lines/50Hz
15.75KHz/15.625KHz
2.4ColorSub-Carrier:4.433MHz/3.579MHz
2.5IF:Picture38.9MHzSound5.5/6.5MHz
2.6PowerConsumption:75W;
2.7PowerSupply:AC110-240V50Hz±10%
2.8AudioOutputPower (7%THD):1.5WX2;
2.9AerialInputImpedance:75 ΩUnbalancedDinJackAnt. Input
3. BasicFeaturesofController
3.1ChannelTuningMethod:FrequencySynthesizer
3.2PresettableProgram:240Programs
3.3TuningforVHF and UHF Bands:AutoTuning/ManualTuning
3.4Pictureand SoundAdjustment
Bright,Contrast,Color, SharpnessControland ColorTemperatureAdjustment
TINTControl(NTSConly)
VolumeControl(MorecontrolscandoinTVModel21SL39and29F08)
3.5OSD
GeneralFeatures(Volume,Brightness,Contrast, Color,Program, Band,AutoSearch,Manual
Tune, Muting,AV/TV,ChildLockand SleepTimer)
AVStereo
RussiaandEnglishLanguage
3.6SleepTimer:5-120Minuteswith5MinutesIncrement
3.7AutoStandbyWhenNoBroadcastingSignal: 5minutes
3.8FullFunction InfraredRemoteControl
3.9RemoteEffectiveDistance:8m
4. ConstructionofFrontPanel
PDF 件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.com.cn

SERVICE MANUAL
7
MainPowerSwitch
RemoteSensor
StandbyIndicator
MenuSelect
TV/AVSelect
ProgramandVolumeUp/Down
5. TV’sTerminals
75 ΩAerialTerminal
3AVInputs
1S-VideoInput
1Y/U/VInput
1AVOutput
6. Other Informations
6.1MagneticField:Bv=0.3~0.65Gs
6.2StandardColourTemperature:9300K(X=0.284,Y=0.299)
TVADJUSTMENT
TestEquipment
1. Oscilloscope
2. Multifunctionmeter(Internalresistance:DC≥20kΩ/VAC≥5kΩ/V
3. High voltmeter:35kV
4. StandardSignalGenerator
5. Degaussing coil
Factorymenu
SomeadjustmentsmustbeperformedintheFactorymenu.You canentertheFactorymenuin
thefollowingway:
1.PresstheMENU button ontheremotecontrolthenpress theQ.VIEWbuttonontheremote
PDF 件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.com.cn

SERVICE MANUAL
8
controlatleast5timesimmediately.
2.PresstheMENU buttonstoselectthedesiredFactorymenupagesor press0-9numberbuttonsto
entertheFactorymenupagesdirectlyandthenpress thePROG.+/-buttonstoselectthedesired
items.
3. PresstheVOL+/-buttonstochangethesettings.
B+Adjustment
TestEquipment:Multifunctionmeter
1. OperatetheTVsetwithAC110-240V(50/60Hz).
2. ReceiveTelevisionbroadcastsignal,setPICTUREtoNormalmode.
2.Connectthemultifunctionmeter+leadtoC960andGND.AdjusttheRP950 untilthemeter
readingtheproperDCvalue:B+=115±0.5Vdc.
Highvoltagecheckandfilamentvoltagecheck
TestEquipment:Highvoltmeter
1. MakesureACpowersupplyand+B arewithinpointedrangebeforecalibratinghighvoltage.
2. Connecthighvoltmetertoanode(G4)of CRT.
3. TurnontheTV, settheBRIGHTNESS andCONTRASTtotheminimum(zerobeamcurrent),
swaptoAVmode(Noanysignalapplied).
4. Highvoltagepleasesee therelatedmodelBOM.
5. FilamentvoltagemeasuredbyvirtualvaluemeterpleaseseetherelatedmodelBOM,usually
withintherangeof6.3±0.2Vrms.
Gridvoltageadjustment
1. Enter intoFAC3andselectVG2, thenadjustpotentiometertoIN/OUTflashonthescreen.
VG2XXPleasesee therelatedmodelBOM
VSDBrightness XX PleaseseetherelatedmodelBOM
VSDXXPleasesee therelatedmodelBOM
2. ReceivePHILIPS fivecirclespatternaftersettingsfinishing,setPICTUREtoNormalmode.
PDF 件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.com.cn

SERVICE MANUAL
9
RFAGCadjustment
1. Receivea60dBμVgrayscalesignal(PALorSECAM).
2.EnterFactorymenu andselectAGCTAKEOVER,thenadjustit until thepicturenoiseisjust
disappeared.
FOCUSadjustment
1. Receivefivecirclespattern, adjustthepatterntoNormalmode.
2. Adjustfocuspotentiometer(horizontaloutputtransformer)sothatthecenter andfourcornersof
patternarethebestfocus.
Horizontalscanning,verticalscanning and geometrycorrectionadjustment
(adjustwithPAL/SECAMandNTSCsignalseparately)
1. Receivefivecirclespatternsignal,enterintofactorymenutocallupFAC2.
VERTSLOPE 50(60)XXAdjustitsothathorizontalmidlineofthepatternsuperpose
withtheblackedgeofthepattern.
VERTSHIFT 50(60)XXAdjustitsothatthepatternmidlinesuperposesoverCRT
geometriccenter.
VERTAMPLE 50(60)XXAdjustitsothatthepictureverticalreproductiondisplayratio
ismorethan92%.
SCORR 50(60)XXAdjustit sothatupperpaneandbottompanofthepatternare
thesameasthemiddlepane.
V.LIN.CTRL 50(60)0
VLINEARITY 50（60）XXAdjustverticallinear.
VERTZOOM 50(60)25 Adjustverticalamplitude（fixedvalue25）.
2. Call up FAC1
EWWIDTH 50（60）XXAdjustitsothatthepicturehorizontalreproductiondisplay
ratioismorethan92%(H-sizeadjustment).
PDF 件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.com.cn

SERVICE MANUAL
10
HOR.SHIFT 50（60）XXAdjustitsothatthelefthalfissymmetricalwiththeright
half(H.CENcorrection).
EWPARABOLA 50（60）XXAdjustitsothatparallelogramwillbetransformedto
rectangleortrapezium(Receivecross hatchsignal)(Parallelogramcorrection).
TRAPEZIUM 50（60）XXAdjustitsothattrapeziumdistortionisjustdisappeared
(Receivecrosshatchsignal)(Trapezium).
UC PARABOLA 50（60）XXAdjustitsothatuppercorner (leftand right) verticallineare
straightline(Receivecrosshatchsignal)(Uppercorner pincushion).
LCPARABOLA 50（60）XX Adjustitsothatbottomcorner(leftand right) verticalline
arestraightline(Receivecrosshatchsignal)(Bottomcorrectionpincushion).
HOR.BOW 50（60）XXAdjustit sothatverticallineisthestraightline.(Receive
crosshatchsignal)(Bowcorrection).
PARALLEL 50（60）XXAdjustitsothatleftand rightlinearestraightlines
(Pincushioncorrection).
Whitebalance adjustment(PALorSECAMsignal)
1. Enter intomenufirstlyand setCOLORmodetonormal.(9300K)
2. Enter intoAVmodeandreceiveleftblackrightwhitesignalwhichwithcolorsyncsignal.
3.PlugXS805,adjustit automaticallywithwhitebalance adjustmentsoftware,enterintofactory
menuwhenadjustmentisOK,thenenterintoFAC6、FAC7、FAC8menutocheckthefollowing
dataareconsistentwithdataincomputer.
Standard：Color temperature9300K （X=0.284Y=0.299）FAC6
Coldcolor：Colortemperature12000K（X=0.272Y=0.279）FAC8
Warmcolor：Colortemperature6500K （X=0.313 Y=0.329）FAC7
FAC6
ADJcontent
X=0.284
Y=0.299
value
FAC7
ADJContent
X=0.313
Y=0.329
value
FAC8
ADJContent
X=0.272
Y=0.279
value
BLOR-NxxBLOR-WxxBLOR-Cxx
PDF 件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.com.cn
