CammSys CH-300 User manual

User Manual
www.blacksys.co.kr/en

1
CAMMSYS CH-300
Contents
1. Safety Precautions
2. Before Use
3. Product Feature
4. Package
5. Structure
6. Installation
7. External GPS Installation
8. How to Record
9. REC Time
10. LED Guide
11. Voice Guide
12. PC Viewer Installation
13. PC Viewer Program
14. Playback
1. Playback in normal video
2. Playback in dedicated video
15. ADAS set up
16. Mobile download (Wi-Fi)
1. How to download
2. Smartphone Wi-Fi - iOS
3. How to use Smartphone Wi-Fi
4. Smartphone Wi-Fi – Variable bitrate applied
17. How to separate video
18. F/W Upgrade
19. SD card format
20. How to use Multi-key
21. Specification
22. After-sales service Guide
2
4
5
6
7
8
11
12
13
14
15
16
18
20
20
21
22
23
23
24
25
28
29
30
30
31
33
34

2
CAMMSYS CH-300
Cautions
Do not operate the product during driving. It may cause
accidents.
The Product must be mounted at a point which would not
obstruct the driver’s view.
Do not allow unauthorized disassembly or alteration to the
product. It may cause malfunction and the consequent
product damage will not be covered under the warranty.
If the product is damaged or power is cut off by a serious
accident, the product may not be able to record such an
event.
Always keep the windshield clean to enable normal
recording.
Since the product is the purpose to record video data during
driving the video quality may be deteriorated when in/out
the tunnel and at night or by contrast and backlight.
Contaminated Camera Lens may deteriorate the video
quality. Always keep the Lens clean.
Do not leave the product under direct sunlight or inside the
closed vehicle as it may cause malfunction.
Do not use chemicals or detergent to clean the product.
Clean gently with soft cloth.
Temperature conditions below -20°C or above 70°C (-20°
C or 60°C) may cause malfunction or breakdown of the
product. (Please keep the storage temperature when not
using the product.)
Do not use the product in places at high temperature/
humidity.
Do not force the product (especially buttons and cradle). It
may cause malfunction or breakdown.
Operate the product for 3-5 minutes to check for correct
recording before each use.
If the product is exposed to sunlight or high temperature
for a long time in summer, it may be difficult to operate
normally.
Do not turn off power, or remove the SD card during
firmware upgrading as it may cause malfunction.
Do not touch the power cable (cigar lighter cable / hardwire
cable) with wet hands as it may cause electric shock.
Do not use a damaged cigar lighter cable or hardwire cable
as it may cause electric shock or fire.
Do not leave the cigar lighter cable or hardwire cable in near
heating devices.
Do not leave the product with connected cigar lighter cable
while not use for a long time. please remove the cable from
the product.
Insert the cigar lighter cable or hardwire cable securely.
Do not bend or pull the cigar lighter cable or hardwire cable
by excessive force, or leave heavy objects on the cable. It
may damage the cord and electric shock or fire.)
Even if overwriting is set to Off, some recorded files may be
deleted to make free space at boot time.
1. Safety Precautions

3
CAMMSYS CH-300
Caution to use SD card
Please check the record file of the SD card and format
it regularly in order to check the product condition. ( PC
format once or twice a month)
Since the SD card is a consumable good, data loss or
recording may not be possible due to an error during long-
term use.
Do not force the SD card out if the product is being
recorded. It may cause poor SD card performance and data
loss.
Excessive temperature increase inside the vehicle may cause
data storage and data loss. Please park in a shady place in
the summer.
Please keep the SD card separately when checking for
accident or damage to the vehicle. Important data may be
deleted due to overwriting.
Please note that the last recorded file may not be saved if
you turn off the main unit and remove the SD card before
the end of the announcement or before the power LED
turns off.
Typically, SD cards are consumable good and may not be
able to save data when used for a long time. In this case,
please purchase a new SD card and check the recorded
video and SD card to make sure there is no problem for
data storage.
Do not remove the SD card while driving.
Please remove it safely on parking and stop.
After power on, please check whether it is normal to drive.
Please contact the manufacturer in case of an SD card
error, as the warranty period of our SD card is 6 months.
Third party SD cards are not provided with After-sales
service except for the SD card provided by us. We shall not
take any responsibility for loss and damage of the device if
used with other SD card.

4
CAMMSYS CH-300
Thank you for purchasing CAMMSYS product.
This user manual contains important information
about the proper use and cautions in use of the
product. please read carefully before use.
The CH-300 is an auxiliary product to alert
users for safe driving and prevent accidents, by
recording video while driving. Also, purpose for
evidence of an accident.
The CH-300 does not guarantee that all
accidental images will be stored and accidental
moments due to small shocks that do not trigger
the shock detection sensor may not be recorded.
We are not responsible for any possible damages
such as data loss and product loss due to
product malfunction that may occur at the time
of an accident or any other case.
All rights of design and software of CH-300 are
in CAMMSYS and protected by copyright law.
The CH-300 may change without notice for
further function improvement.
This user manual is based on current standards
and may contain technical or editorial errors or
omissions.
This user manual is subject to change without
notice to improve the product.
2. Before Use

5
CAMMSYS CH-300
Hight quality Lens and high image quality
resolution support
Front QHD(2560*1440P) Rear FHD(1920*1080P)
Front 30FPS / Rear 30FPS
Various recording function and video
data
It offers a variety of recording functions such as driving,
event, motion, automatic parking Recording
Set recording image quality (Super high quality / High
quality / Normal quality)
Possible to save driving record with GPS support (optional)
Built-in G sensor - Event recording
It is possible to check the position of the vehicle on the
map when changing various set values with GPS and PC
viewer software. (It is also possible to play back recorded
video on a general video player (eg, Gom Player))
Ability to set each capacity of the driving / Event / Motion
folder
High quality voice record and voice
guidance
Operating instructions service by voice guidance
Voice recording ON/OFF function and speaker output ON/
OFF function
High performance microphone built-in
Back-up battery and vehicle constant
power discharge protection function
Large capacitors are built-in so that images can be saved
safely when the power cut off and current consumption
of less than 2.5mA (12V standard)
"If below the set cut-off voltage is maintained for more
than 30 seconds, the dashcam will automatically shut
down to prevent vehicle battery drain. "(Some differences
may occur depending on vehicle type and vehicle
condition)
Other
Smooth and emotional design ( easy removable main
unit)
Security LED lamp on the Front body (LED lighting
function ON / OFF can be set in PC viewer only)
3. Product Feature

6
CAMMSYS CH-300
CH-300
Hardwire cable
Bracket
※ Before using the micro SD card, please install the viewer program on the PC.
(If the viewer program has deleted from the SD card, you can download it from our website.)
The picture of the packaged product in the User's Manual may differ from the actual product.
Micro SD card & Adapter Rear Camera
Rear Camera cable
External GPS
Cigar lighter cable
4. Package
Option Accessories
Standard Package

7
CAMMSYS CH-300
Bracket
Power port
GPS port
SD card socket
Rear Camera port
MIC/Speaker
Security LED
REC LEDGPS LED
Power ON/OFF
WLAN
(Multi Key)
Front Camera
5. Structure

8
CAMMSYS CH-300
1. Insert Micro SD card to the slot of the
device.
(check the any faulty of the SD card)
6. After checking the device, clean up the
cables.
2. Remove the protection film from the
bracket’s tape.
4. Attach the bracket at the left which
from the windshield.
3. Connect the Hardwire cable to DC-IN
port.
5. Connect the Hardwire cable into car
fuse box. (except cigar lighter cable)
6. Installation
1. Front Camera Installation

9
CAMMSYS CH-300
4. Connect video cable
Plug (ㅡ) shape's rear end of the plug to
the camera connection, (ㄱ) shape's one
to the device. (※caution : Please note that if
the wrong connection, the video will not be
output.)
Please power off the car before installation.
(disconnect the power connection)
1. Vehicle / Main unit Power OFF 2. Install a rear camera
5. Check an operation
3. Adjust a rear camera angle
6. Arrange a front/rear camera cable
Arrange the wire by using the cable clip.
(Please be careful not to drop or damage
the cable during installation.)
Remove the protection film of the bracket
and attach the Camera in the proper
location.
Adjust the camera angle and fix it.
(To adjust the angle, the horizon is seen
above the right center of the screen.)
Turn the device on and check whether to
record properly.
(Left / Right setting using inverting switch)
2. Rear Camera Installation

10
CAMMSYS CH-300
1. How to install a fuse cable
Fuse cable has 3 lines.(connect to the fuse box only)
Battery Line (Red) : Connect to stop and emergency light.
ACC Line (Yellow) : Connect to Fuse power
Ground Line (Black) : GND
1
2
3
3
1
2
3. Fuse cable installation

11
CAMMSYS CH-300
Connect the external GPS to GPS port
on the device.
Fix the external GPS into appropriate
place, and tidy up the cable.
Caution on GPS Installation
This feature may not be available in some countries.
ㆍOther electronic devices may have interfered with GPS signal if placed too close to the device. Keep its
distance from them as much as possible.
ㆍGPS may be affected by weather conditions, satellite signal, or surrounding geographical features.
ㆍCoated windshields can interfere with GPS signal which may result in poor or blocked GPS reception.
7. External GPS Installation

12
CAMMSYS CH-300
1. Recording : CH-300 is automatically booting at power on, and a constant(normal) recording starts
as an initial recording mode.
2. Recording Mode : it is classified into driving recording mode and parking (motion) recording mode.
3. Recording Method : it is classified into a continuous(normal) recording, event recording, motion
recording.
※ For automatic recording and manual recording methods, please refer the below table.
8. How to Record
REC Mode
Driving
Mode
Parking
(Motion)
Mode
REC Method REC file folder
Continuous(N)
REC -Normal
Event
Parking
Event REC
Motion REC
In G-sensor detect shock
When detecting motion
If the ACC power cut-
off continues for 30 sec
on the permanent power
connection,
Switching the automatic
motion Recording
10sec before Motion, 10sec
above after Motion
(10 seconds added when
motion continues)
10sec before Motion, 10sec
above after Motion
(10 seconds added when
motion continues)
10sec before Event, 10sec
above after event
10sec before Event, 10sec
above after event
Auto REC Mode REC Time

13
CAMMSYS CH-300
3-5. 녹화 시간
9. REC Time
▶ Default Setting
ㆍBy Time: If there is insufficient storage space, the old recording files have automatically deleted from the oldest
recording file.
ㆍBy Type: When saving a recording file, set the memory usage ratio by recording type.
If the memory space is full then the recording files have automatically deleted sequentially. Hence, the accident
video recording files may also have deleted.
(Unit : Min)
CH
1CH
2CH
Video
Quality Camera
32GB 64GB 128GB
Super High Front
High Front
Normal Front
Super High Front/Rear
High Front/Rear
Normal Front/Rear
Normal
(50%)
Normal
(50%)
Normal
(50%)
Motion
(20%)
Motion
(20%)
Motion
(20%)
Event
(30%)
Event
(30%)
Event
(30%)
152
177
211
98
113
133
61
71
84
39
45
53
91
106
126
59
68
80
304
353
421
195
226
267
122
141
168
78
90
107
182
212
253
117
135
160
608
706
842
391
451
534
243
282
337
156
180
213
365
424
505
234
271
320

14
CAMMSYS CH-300
10. LED Guide
Item Front
LED
POWER LED
Red Green
Rear LED
GPS LED (Blue)
NO GPS GPS OFF GPS ON
Booting
-
OFF ON
ON ON ON
ON ON
ON
ONON
OFF ON
OFF
OFF
OFF
OFF
OFF
OFF
1sec ON/
1sec OFF
0.25sec ON/
0.25sec OFF
1sec ON/
1sec OFF
1sec ON/
1sec OFF
1sec ON/
1sec OFF
Quickly ON/
OFF repeat
1sec ON/
1sec OFF
F/W update
Continuous REC (N)
Event REC (E)
Parking REC (P)
Parking REC
standby
Wi-Fi ON

11. Voice Guide
Situation Announcement
No SD Card or SD Card Error
Continuous(Normal) Recording
Event Recording
Parking Recording
Power off
Wi-Fi On / Off
MIC On / Off
No Rear Camera
“ Please check SD Card ”
“ Start regulary recording ”
“ Ding - Dong ”
“ Start parking recording ”
“ Shutting down the system ”
“ Wi-Fi is enabled/disabled ”
“ Microphone is on/off ”
“ Check your rear camera ”
※ Only when the recording method is set to event recording in the configuration setting, the voice
announcement “ Event recording starts” is displayed.

16
CAMMSYS CH-300
1. System Requirements
2. Install
Windows XP(32bit), Windows Vista(32bit), Windows7(32/64bit), Windows8(32/64bit),
Windows10(32/64bit)
Pentium4 2.8GHz & RAM 1GB.
Display monitor resolution : 1024 X 768
DirectX support (WPF)
Download the latest CAMMSYS Viewer on the website. (www.blacksys.co.kr/en) If you run “Setup.exe“,
CAMMSYS Viewer will be installed.
After the installation, it will be continued following to the installation sequence of setting up the dialog box.
12. PC Viewer Installation

17
CAMMSYS CH-300
1.Click the Next button 2. Select the save location
to install
3. Click the install button
4. Click the Finish button
※ Depending on your PC environment, the program installation
may take a long time.

18
CAMMSYS CH-300
13. PC Viewer Program
2 3 4 5 6 7 8
9
10
1
28
11
13 14 15 16 17 18 19 20 21 22
23 24 25 26 27
12

19
CAMMSYS CH-300
Full screen
Item Item
Function Function
1CH / 2CH View Rewind 5 sec
Viewer Configuration Playback or Pause
System Configuration Play Stop
Print Forward 5 sec
Screen Capture File Skip
Zoom Control Volume
Play list / Map button
Total File Time / Playback Time
Finding file location
Brightness / Contrast
REC file list/Map display switching button
GPS Signal Condition
Playback Video display
Driving Speed
Playing bar Latitude / Longitude
G-sensor Information
Switching Left & Right
File separation
Switching Up & down
File Skip Back
116
217
318
419
520
621
722
823
924
10 25
11 26
12 27
13 28
14
15
