Camp Chef PRO 90X User manual

Tank Sold Separately
Réservoir vendu séparément
Read and follow all warnings and instructions in included instruction manual before assembly and use of appliance.
MAX POT DIAMETER 10"
KEEP FOR FUTURE REFERENCE FOR OUTDOOR USE ONLY
Regulator Model
R329, RA329,
JY95A7A (JY95-007)
THIS INSTRUCTION MANUAL CONTAINS IMPORTANT INFORMATION NECESSARY FOR THE PROPER ASSEMBLY AND SAFE USE OF THIS PRODUCT.
PRO 90X
STABILIZER INSTALLATION
Place stove upside down on ground. Press push
button in and unfold legs. Make sure push button
locks into place. Stand stove upright on solid, level
ground.
To level the stove simply twist the leg leveler in the
bottom of each leg.
PRO 90X TROUBLESHOOTING
BURNERS WILL NOT IGNITE
1. Make sure there is propane in the tank and that the propane tank is turned on.
2. Follow all instructions in instruction manual for lighting the burner
BURNERS WILL NOT LIGHT WITH ROTARY IGNITER BUT DO LIGHT WITH MATCH
1. Turn the gas OFF at the supply tank valve.
2. Check the spark electrode. The wire of the spark electrode should be placed directly over one of the
burner gas ports. There should be about a 1/8” vertical gap between the wire and the burner port.
3. Turn the rotary ignitor and watch for the spark to jump from the spark electrode wire to the burner port.
Ideally the spark should hit the center of the gas port.
4. Repeat for each of the spark electrodes.
5. Follow all instructions in instruction manual for lighting the burner.
YELLOW FLAME
1. Adjust Air Shutter until burner has blue flame. Some yellow tipping of the flame is normal.
2. See Instruction Manual for Cleaning the burner
FLAME IS VERY SMALL AND WON’T INCREASE.
1. Make sure there is propane in the tank and the propane tank is turned on a minimum of 3 full turns
2. Follow all instructions in manual for leak testing the stove.
3. Turn all valves on the stove to the off position. Turn the Propane Tank off. Disconnect regulator from the
tank. Reconnect regulator to the tank. Slowly turn tank on. Follow all instructions in the manual for leak
testing the stove. If no leaks are found follow all instructions in the manual for lighting the appliance.
Model PRO90X-2
• Three cast aluminum 30,000 BTU burners
•Matchless ignition
• Three-sided windscreen
• Deluxe folding legs
• Folding side shelves
• Fully adjustable, kitchen style heat-control knobs
•
•
Large cooking grate (608 sq in.)
Includes leg levelers

PRO90X-2 PARTS LIST
0916PRO90X-2parts
WINDSCREEN (1)
PRO90-4
GRILL (1)
1095
LP BURNER (3)
0808-AL
AIR VENT (3)
0826L
LP SPRING (3)
0980
VALVE (3)
PRO-2
KNOB (3)
PRO-1
DEFLECTOR (1)
TS90-4
LP REGULATOR (1)
HRL
MANIFOLD (1)
PRO90-1
SNAP BUTTON (4)
TS90-1
1/4 LOCK NUT (4)
1/4 X 1-3/4 BOLT (4)
ELECTRODE (3)
PRO90ING
LEFT LEG (2)
TS90-2
SQUARE LEG LEVELER (4)
LEGXS
RIGHT LEG (2)
TS90-3
SHELF(2)
PRO90-3
HOLD DOWN BRACKET (2)
1046HDB
#8 SCREW (3)
0789-HEX
#8 SHELF NUT (4)
330029
#8 SHELF SCREW (4)
330028
GRATE HOOK (1)
YK01
THUMB SCREW (1)
YK02
ROLL PIN (8)
3/16" X 1-1/4"
HANDLE (2)
PRO90-2
Rotate handle up and push in to lock into position as shown.
Warning - Ensure pins in handle are secured in front and rear brackets before folding shelf into position.
Fold shelf over to rest on handle.
Warning - Max shelf capacity is 20 lbs.
Note - Handle and shelf may be folded down when not in use.
