COMPONENT
PS200 and CH200
Smart Power Supply and Charge Controller
Overview
The PS200 and CH200 are charge controllers that manage amperage
and voltage for safe, optimized battery charging from a solar-panel
or ac power source. They also measure various input, output, and
status parameters to allow close monitoring of the battery during
charging and use. The PS200 includes a 12 Vdc valve-regulated lead-
acid (VRLA) battery, while the CH200 is for use with a separate larger
battery such as our BP12, BP24, or a user-supplied battery.
www.campbellsci.com/ps200
More info: 435.227.9000
Benets and Features
Protects against high-amperage and high-voltage damage to
power supply
Ability to monitor both load and battery current
Real-time measurements of charge input voltage, battery voltage,
on-board temperature, battery current, and load current
Battery reversal protection
Two-step constant voltage charging and temperature compensa-
tion optimize battery charging and increase the battery’s life
Allows simultaneous connection of two charging sources (e.g.,
solar panel, ac wall charger)
Ordering Information
Power Supplies
CH200 12 V Charging Regulator. Choose a warranty option (see below).
PS200 12 V Power Supply with Charging Regulator and 7 Ah Sealed
Rechargeable Battery. Choose a warranty option (see below).
Warranty Options (choose one)
-SW Standard 1 Year Warranty. See manual for full warranty policy.
-XW 4 Year Warranty Extension (available only at the time of
original product purchase).
Technical Description
The PS200 and CH200 are micro-controller-based smart chargers
with two-step constant voltage charging and temperature compen-
sation that optimize battery charging and increase the battery’s life.
Two input terminals enable simultaneous connection of two charg-
ing sources. They also incorporate a maximum power point tracking
algorithm for solar inputs that maximize available solar charging
resources. RS-232 and SDI-12 terminals allow the PS200 and CH200
to convey charging parameters to a datalogger.
The PS200 and CH200 have several safety features intended to
protect the charging source, battery, charger, and load devices. Both
the SOLAR – G and CHARGE – CHARGE input terminals incorporate
hardware current limits and polarity-reversal protection. A fail-safe,
self-resettable thermal fuse protects the CHARGE – CHARGE inputs in
the event of a catastrophic AC/AC or AC/DC charging source failure.
Another self-resettable thermal fuse protects the 12 V output termi-
nals of the charger in the event of an output load fault. The PS200
and CH200 also have battery-reversal protection, and include ESD
and surge protection on all of its inputs and outputs.

Campbell Scientic, Inc. | 815 W 1800 N | Logan, UT 84321-1784 | [phone] | www.campbellsci.com
USA |AUSTRALIA |BRAZIL |CANADA | CHINA | COSTA RICA |ENGLAND |FRANCE |GERMANY |SOUTH AFRICA |SPAIN
© 2011, 2013
Campbell Scientic, Inc.
May 15, 2014
Specications
Operational Temperaturea: −40° to +60°C
Dimensions:
Height Length Width
PS200 10.6 cm (4.2 in) 19 cm (7.5 in) 7.6 cm (3 in)
CH200 10 cm (3.9 in) 7.5 cm (3 in) 3.7 cm (1.5 in)
CHARGE – CHARGE Terminals (AC or DC Source)
AC: 18 to 24 V RMS with 1.2 A RMS maximum
DC: 16 to 40 Vdc with 1.1 A DC maximum
SOLAR Terminals (Solar Panel or Other DC Source)b
Input Voltage Range: 15 to 40 Vdc
Maximum Charging Current: 3.6 Adc typical;
2.8 Adc to 4.3 Adc depending on individual charger)
Battery Chargingc
CYCLE Charging: Vbatt(T) = 14.70 V − (24 mV) x (T − 25°C)
FLOAT Charging: Vbatt(T) = 13.65 V − (18 mV) x (T − 25°C)
Accuracy: ±1% accuracy on charging voltage over -40° to +60°C
Quiescent Current
No Charge Source Present: 300 μA maximum
No Battery Connected: 2 mA maximum
Power Out (+12 terminals)
Voltage: Unregulated 12 V from battery
4 A Self-Resettable Thermal Fuse Hold Current Limits
<20°C 20°C 50°C 60°C
> 4 A 4.0 A 3.1 A 2.7 A
Measurements
Average Battery Voltage (-40° to +60°C): ±(1% of reading + 15 mV)
Average Battery/Load Current Regulator Input Voltage
(-40° to +60°C)d: ±(2% of reading +2 mA)
Solar (-40° to +60°C)e: ±(1% of reading − 0.25 V) / −(1% of reading + 1 V)
Continuous (-40° to +60°C)f:
±(1% of reading − 0.5 V) / − (1% of reading + 2 V)
Charger Temperature: ± 2°C
Ordering Information Continued
aVRLA battery manufacturers state that “heat kills batteries” and recommend operating batteries ≤50°C.
bBattery voltages below 8.7 V may result in <3.0 A current limit because of fold-back current limit.
cTwo-step temperature compensated constant-voltage charging for valve-regulated lead-acid batteries. Cycle and oat charging voltage parameters are
programmable with the default values listed.
dImpulse type changes in current may have an average current error of ±(10% of reading + 2 mA).
e1.0 V negative oset is worst-case due to reversal protection diode on input. Typical diode drop is 0.35 V.
f2.0 V negative oset is worst-case due to two series diodes in AC full-bridge. Typical diode drops are 0.35 V each for 0.7 V total.
12 Vdc Battery Packs for CH200
BP12 12 Ah Sealed Rechargeable Battery with Mounts
BP24 24 Ah Sealed Rechargeable Battery with Mounts
Cables (interface and external battery)
20769 SDI-12 Interface Cable with a 2 ft length. Connects the power
supply’s SDI-12 terminal to the datalogger’s terminals, allowing
the datalogger to receive the power supply’s charging, load, bat-
tery voltage and current information.
25356 RS-232 Pigtail Interface Cable with a 2 ft length. Connects the
power supply’s RS-232 terminal to the datalogger’s terminals,
allowing the datalogger to receive the power supply’s charging,
load, battery voltage and current information.
20770 9-pin RS-232 Interface Cable with 6 ft length. Connects a PS200
or CH200 to a computer for changing its settings or downloading
a new operating system.
6186 Battery Cable for connecting a an external 12 Vdc ooded bat-
tery such as a deep-cycle marine or RV battery.
Adapters
Only one adapter can be used at a time.
A100 Null Modem Adapter for powering peripherals and external
devices at non-datalogger sites such as repeater stations.
A105 12 V Terminal Expansion Adapter that increases the number of
12 V and ground terminals available on the PS200 or CH200.
Wall Chargers
29796 Wall Charger 24 Vdc 1.67 A Output, 100 to 240 Vac, 1A Input,
5 ft Cable. Must choose a power plug option (see below).
22110 Wall Charger 24 Vdc 1.67 A Output, 100 to 240 Vac, 1A Input for
prewired enclosure. Must choose a power plug option (see below).
Power Plug Options (choose one)
-US US/Canada Plug
-IP 7 International Plugs
Unregulated Solar Panels
Regulated solar panels such as the SP10R are not recommended.
SP10 10 W Solar Panel with 20 ft cable
SP10-PW 10 W Solar Panel with 20 ft cable for prewired enclosure
SP20 20 W Solar Panel with 15 ft cable
SP20-PW 20 W Solar Panel with 15 ft cable for prewired enclosure
SP50-L 50 W Solar Panel with user-specied cable length (used with
the CH200 only). Enter length, in feet, after the -L. A 20 ft length
is typical; maximum length is 50 ft. Must choose a cable termi-
nation option (see below).
Cable Termination Options for the SP50-L (choose one)
-PT Cable terminates in stripped and tinned leads for connection
to the CH200.
-PW Cable terminates in a connector that attaches to a
prewired enclosure.
