SC32B Optically Isolated RS-232
Interface
1. Function
Figure 1-1. SC32B Optically Isolated RS-232 Interface
The SC32B interfaces an RS-232 peripheral, commonly a computer or terminal, to
the CS I/O port of a Campbell Scientific datalogger. The SC32B has the same
functions as the SC32A. Functions include:
1. Converting datalogger logic levels to RS-232 logic levels.
2. Optically isolating the datalogger and the RS-232 peripheral. Optical
isolation separates the SC32B into a datalogger section and an RS-232
section. Signals entering from either side are electrically independent,
protecting against ground loops, normal static discharge, and noise.
3. Passing data when modem enable pin 5 is high and SDE/printer enable pin 6
is low (normal telecommunications mode).
The SC32B blocks data sent out the datalogger CS I/O port when the SDE/print
enable pin 6 is high. This prevents data sent to an SDE device (for example,
storage module) or printer output from being sent out the RS-232 port. The
SC32B cannot be configured to pass Instruction 96 serial printer or computer data.
Contact Campbell Scientific if this capability is required.

SC32B Optically Isolated RS-232 Interface
2
2. Specifications
Operating Temperature: –25° to +50C (typical)
Power: Powered by datalogger; see Section 4, Operation
Ports: 9 pin female RS-232 configured as DCE.
9 pin male CS I/O
Baud Rate: 1200 bps to 115.2 kbps; see Section 4, Operation
Size: 4.1 x 2.3 x 7.6 cm (1.6 x 0.9 x 3 in)
Weight: 45.4 g (1.6 oz)
3. Connector Descriptions
Table 3-1. SC32B Connector Descriptions
RS-232
9 Pin Female Connector
CS I/O
9 Pin Male Connector
Pin #
I/O
Description
Pin #
I/O
Description
1
Out
DCD
1
In
+5 V
2
Out
RXD
2
Ground
3
In
TXD
3
Out
Ring
4
In
DTR
4
Out
RX
5
Ground
5
In
ME
6
Out
DSR
6
In
PE (SDE)
7
In
RTS
7
No Connection
8
Out
CTS
8
No Connection
9
No Connection
9
In
TX
3.1 RS-232
The DB9 RS-232 port is configured as Data Communications Equipment (DCE)
for direct cable connection to Data Terminal Equipment (DTE). Most computers
are configured as DTE. For connection to DCE devices such as modems, the
SC932 or SC932A should be used in place of the SC32B.
3.2 9 Pin
The CS I/O port connects to the datalogger through the SC12 Two Peripheral
Cable supplied with the SC32B. Pin descriptions and direction (Input/Output) are
given in Table 3-1.
4. Operation
Power for the SC32B datalogger section comes from the 5 V supply on pin 1 of
the datalogger CS I/O. Communication logic levels to and from the datalogger are
referenced to this voltage, ranging from 0 to slightly less than 5 V.

Instruction Manual
3
Power for the RS-232 section is isolated from the datalogger 5 V supply via a
transformer/isolator. An on-board DC to DC converter supplies the negative
voltage required for RS-232 signals.
When the SC32B first receives a character from the RS-232 peripheral (pin 3),
5 V is applied to the datalogger Ring line (pin 3) until the datalogger Modem
Enable (ME) goes high, putting the datalogger into the Telecommunications
Mode.
The SC32B does not perform baud rate translation. The data speed going out will
match the data speed coming in. If you are having trouble communicating, check
that the datalogger’s CS I/O ME baud rate matches that being used by the
computer/LoggerNet. When other devices are also connected to the datalogger’s
CS I/O port, it may be necessary to lower the baud rate used for the SC32B. If
you encounter communication issues, consider starting at 9600. If communication
is successful, you can increase the baud rate until communication problems
return.
5. Application
The SC32B provides a direct interface between the CS I/O port on a Campbell
Scientific datalogger and the RS-232 port on a computer. Some Campbell
Scientific dataloggers (for example, the CR23X and CR5000) have a built-in
RS-232 port in addition to the CS I/O port. With these dataloggers, the SC32B is
only necessary if you wish to connect to the CS I/O port instead of the
RS-232 port.
The SC32B blocks data sent out the CS I/O port when the datalogger sets the
printer enable/SDE (pin 6) high. The SC932 or SC932A (CS I/O to RS-232 DTE
interface) can be used to interface to an RS-232 modem.
