INSTRUCTION MANUAL
SC929 RS232 Interface
9/96
Copyright (c) 1996
Campbell Scientific, Inc.

Warranty and Assistance
The SC929 RS232 INTERFACE is warranted by CAMPBELL SCIENTIFIC,
INC. to be free from defects in materials and workmanship under normal use
and service for twelve (12) months from date of shipment unless specified
otherwise. Batteries have no warranty. CAMPBELL SCIENTIFIC, INC.'s
obligation under this warranty is limited to repairing or replacing (at
CAMPBELL SCIENTIFIC, INC.'s option) defective products. The customer
shall assume all costs of removing, reinstalling, and shipping defective products
to CAMPBELL SCIENTIFIC, INC. CAMPBELL SCIENTIFIC, INC. will
return such products by surface carrier prepaid. This warranty shall not apply
to any CAMPBELL SCIENTIFIC, INC. products which have been subjected to
modification, misuse, neglect, accidents of nature, or shipping damage. This
warranty is in lieu of all other warranties, expressed or implied, including
warranties of merchantability or fitness for a particular purpose. CAMPBELL
SCIENTIFIC, INC. is not liable for special, indirect, incidental, or
consequential damages.
Products may not be returned without prior authorization. The following
contact information is for US and International customers residing in countries
served by Campbell Scientific, Inc. directly. Affiliate companies handle repairs
for customers within their territories. Please visit www.campbellsci.com to
determine which Campbell Scientific company serves your country. To obtain
a Returned Materials Authorization (RMA), contact CAMPBELL
SCIENTIFIC, INC., phone [phone]. After an applications engineer
determines the nature of the problem, an RMA number will be issued. Please
write this number clearly on the outside of the shipping container.
CAMPBELL SCIENTIFIC's shipping address is:
CAMPBELL SCIENTIFIC, INC.
RMA#_____
815 West 1800 North
Logan, Utah 84321-1784
CAMPBELL SCIENTIFIC, INC. does not accept collect calls.

1
SC929 RS232 INTERFACE
The SC929 temporarily connects a Campbell Scientific battery-powered PC to a datalogger for data
retrieval and program transfer. This interface is typically used in remote locations.
1. SPECIFICATIONS
Operating
temperature: -25°C to +50°C
Power: Powered by datalogger; current
consumption typically 8 mA
Connections: 9-pin male; connects to
datalogger
9-pin female; configured as DCE,
connects to AT-type portable PC
Length: 2 m (6 ft.) cable fitted with two
9-pin ‘D’ connectors
Weight: 225 g (∼8 oz.)
2. APPLICATION
The SC929 provides a two-way conversion
between datalogger logic levels (0 V low, 5 V
high) and RS232 logic levels (e.g., -8 V low, + 8
V high). It may be used in applications where a
battery-powered laptop is taken to the field to
communicate with the datalogger (e.g., transfer
data or programs, set clock, monitor data, etc.).
It provides a neat, single-cable alternative to an
SC12 cable, 7026 cable, and an SC32A
Interface, but with some differences (see
adjoining note).
NOTE:
There are some significant differences
between the SC929 and the SC32A:
a. The SC929 does not provide opto-
isolation. To prevent ground loops, do
not use the SC929 with a computer
directly connected to power, powered
AC, or other ground-referenced power
supplies.
b. Unlike the SC32A, the SC929
consumes significant levels of power
from the datalogger. To avoid
unnecessary power drain, disconnect
the SC929 from the datalogger serial
I/O port when the SC929 is not in use.
c. The SC929 does not have the jumper
option that is available with the SC32A
and in certain situations odd characters
may appear on the PC screen.
However, this will not affect the correct
operation of Campbell Scientific
software.
CAMPBELL
SCIENTIFIC
INC.
CR10X
MADE IN USA
WIRING PANEL NO.
EARTH
DIFF
SE AG H L AG H L AG H L AG GGE3 AG
4 5 6
78 910 1112 GGGG 12V 12V SWITCHED
12V
G 12V
POWER
IN
SERIAL I/O
SE
DIFF AG H L AG H L AG H L AG GGE1 E2
1 2 3
12 34 56 G 5V5V P1 P2 C8 C7C6C5C4C3C2 C1
CONTROL
12V
SWITCHED
FIGURE 1. The SC929 connects the datalogger’s Serial I/O with a laptop’s serial port for
two-way communication.

SC929 RS232 INTERFACE
2
