CamTron VRCD-5371 Manual

Vandal Color Dome Camera
1
INFORMATION - This equipment has been tested and found to comply with
limits for a Class A digital device, pursuant to part 15 of the FCC Rules & CE Rules.
These limits are designed to provide reasonable protection against harmful
interference when the equipment is operated in a commercial environment.
This equipment generates, uses, and can radiate radio frequency energy and, if
not installed and used in accordance with the instruction manual, may cause
harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful
interference in which case the user will be required to correct the interference at
his own expense.
◆ Do NOT use power sources other than those specified.
◆ Do NOT expose this appliance to rain or moisture.
This installation should be made by a qualified service person and
should conform to all local codes.
The lightning flash with an arrowhead symbol, within an equilateral
triangle is intended to alert the user to the presence of uninsulated
dangerous voltage within the product's enclosure that may be of
sufficient magnitude to constitute a risk of electric shock to persons.
The exclamation point within an equilateral triangle is intended to alert
the user to the presence of important operating and maintenance
(servicing) instructions in the literature accompanying the appliance.
WARNING - Changes or modifications not expressly approved by the
manufacturer could void the user's authority to operate the equipment.
CAUTION : To prevent electric shock and risk of fire hazards:

■Features Warning ■
High Resolution color for crisp,
clear video
ㆍProgressive image capture
ㆍ540 HTVL equivalent
High Sensitivity for low-light
images
ㆍAdvanced noise reduction
technology
Wide Dynamic Range provides
excellent quality in high-contrast
environments
ㆍ120dB maximum dynamic range
DNR (Digital Noise Reduction)
ㆍThe amount of low illuminance noise
has been significantly reduced, and
the signal to noise ratio (S/N ratio)
as well as horizontal resolution have
been improved, resulting in a clear
and sharp image display even in
the dark.
Controlled by OSD Menu
ㆍThe camera can be controlled by selecting
text displayed on the monitor screen.
Additional Functions
ㆍAutomatic White Balance
ㆍBacklight Compensation
ㆍAutomatic Gain Control
ㆍMotion Detection
ㆍDigital Zoom (x4)
ㆍDay / Night
3 Axis built-in Vandal Resistant
Dome Housing
Weather Proof (IP66)
The camera requires periodic inspection.
Contact an authorised technician to carry out the inspection.
Stop using your camera when you find it malfunctioning.
If the camera emits smoke or is unusually hot for a long period, a fire may
be caused.
Do not Install the camera on a surface that can not support it.
If the camera is installed on an inappropriate surface, it may fall
and cause injury.
Do not hold plug with wet hands.
It could cause an electric shock.
Do not dis-assemble the camera.
It may result in an electric shock or other hazards.
Do not use the camera close to a gas or oil leak.
It may result in a fire or other hazards.
2
Vandal Color Dome Camera Vandal Color Dome Camera
3

4
Vandal Color Dome Camera Vandal Color Dome Camera
5
■Contents
Features
Warnings and Precautions
Names and Functions of Parts
Installation & Dimension
2
3
9
12
■Components
■Cable Connection
8
8
■Installation
■Dimension
10
10
Components & Cable Connection 8
Menu Flow
■Setup Page Menu
■Special Page Menu
ㆍLENS
ㆍWDR
ㆍWHITE BALANCE
ㆍAGC (Auto Gain Control)
ㆍDNR (Digital Noise Reduction)
ㆍSENS-UP
14
14
18
■Advanced Page Menu 21
14
14
15
15
16
17
ㆍVIDEO STANDARD
ㆍRESOLUTION
ㆍBACKLIGHT
ㆍSYNC
ㆍSHARPNESS
ㆍAPERTURE
21
21
22
22
23
23
ㆍCAMERA ID
ㆍDAY & NIGHT
ㆍMIRROR
ㆍDZOOM
ㆍMOTION
18
19
19
20
20
Specification 24

6
Vandal Color Dome Camera Vandal Color Dome Camera
7
■Precautions
Do not install the camera in
extreme temperature conditions.
Do not install the camera under
unstable lighting conditions.
Do not touch the front lens of the
camera.
Only use the camera under conditions
where temperatures are between
-10¡C and +50¡C. Be especially
careful to provide ventilation when
operating under high temperatures.
It can cause the image quality to be
poor.
Severe lighting change or flicker can
cause the camera to work improperly.
This is one of the most important parts of
the camera. Be careful not to leave
fingerprints on the lens cover.
Do not install or use the camera in an
environment where the humidity is high.
It can cause malfunctions to occur.
If it gets wet, wipe it dry immediately.
Liquids can contain minerals that
corrode the electronic components.
If exposed to radioactivity the CCD
will fail.
It can damage the CCD.
Do not drop the camera or protect
it from physical shocks.
Do not expose the camera to rain
or spill beverage on it.
Do not expose the camera to
radioactivity.
Never keep the camera pointed
directly at strong light.

■
Components & Cable Connection Names and Functions of Parts ■
Names and Functions of Parts
②OSD PCB
ㆍSETUP button : Used for the menu display. This button can be used to
confirm settings after changing the value of the selected function or current
conditions.
ㆍUP & DOWN buttons : Used for selecting items by moving the cursor up
or down on the menu screen.
ㆍLEFT & RIGHT buttons : Used when changing item values, by moving the
cursor to the left or right on the menu screen.
①LENS : Vari-Focal Auto Iris Lens (2.9mm~10.0mm / F1.2)
③VBS-EXTRA FOR CONNECTING TO LCD
Please use the supplied wire when connecting to LCD
④ 3 AXIS BRACKE
Please loosen screws and fix tilted and panned position.
⑤SMPS PCB FOR DUAL POWER
8
Vandal Color Dome Camera Vandal Color Dome Camera
9
1. COLOR DOME CAMERA
2. SCREWS
3. WRENCH
4. MANUAL
Components
Cable Connection
DC12V ＋ －

■
Installation & Dimension Menu Flow ■
Setup Page Menu
SETUP
LENS DC
VIDEO
MANUAL
Level(DynamicRangeLimit : 0~36)
WDR AUTO
HIGH
USER..
OFF
LOW
R Gain, B Gain
WHITE BAL. ATW
ATWDes
AWC
MANUAL
AGC MIDDLE
HIGH
OFF
LOW
DNR AUTO
OFF
SENS-UP AUTO
OFF
SPECIAL
EXIT
Installation
Dimension
(unit : mm)
Ø145.0
83.5
46.0
100.0
HEMISPHERE
BOLT
MOUNT
No. 8-32
UNC
DECORATION
RING
M4*10
RUBBER
BOTOTOM
BASE
HOUSING
10
Vandal Color Dome Camera Vandal Color Dome Camera
11

■Menu Flow
Menu Flow ■
Special Page Menu
ADVANCED MENU
RESOLUTION NORMAL
HIGH
VIDEO STANDARD PAL
NTSC
BACKLIGHT OFF
ON
INT
LL
SHARPNESS -8 --------------------- 8
-8 --------------------- 8APERTURE
SYNC
RETURN
Advanced Page Menu
SPECIAL
DAY&NIGHT AUTO
BW
COLOR
CAMERA ID OFF
ON ID, Position
MIRROR OFF
ON
DZOOM OFF
ON
MOTION OFF
ON
ADVANCED MENU
RESET
RETURN
12
Vandal Color Dome Camera Vandal Color Dome Camera
13

■
Setup Page Menu Setup Page Menu ■
LENS
WDR
SETUP
LENS DC
VIDEO
MANUAL
WDR AUTO
WHITE BAL. ATW
AGC MIDDLE
DNR AUTO
SENS-UP AUTO
SPECIAL
EXIT
ㆍLens
Choose the lens type DC, Video
and manual lens by using the
selector button.
Wide Dynamic Range is essential for capturing the images at all light levels.
The main function of the WDR is to accumulate the scope of contrast between the
brightest and darkest points in the picture. With the AUTO option, the distribution
of brightness values is automatically adapted to the recording scenario.
ㆍUser can select the desired level HIGH, CUSTOM & LOW, in addition to
automatic adaptation (Auto), by moving the selector button.
SETUP
LENS
WDR AUTO
HIGH
USER
OFF
LOW
WHITE BAL. ATW
AGC MIDDLE
DNR AUTO
SENS-UP AUTO
SPECIAL
EXIT
14
Vandal Color Dome Camera Vandal Color Dome Camera
15
SETUP
LENS
WDR AUTO
WHITE BAL. ATW
ATWDes
AWC
MANUAL
ㆍATWDesat (ATW Desaturating)
When WB is set to ATWDesat, the Extended Color temperature is desaturated
i.e when there is a excess of light temperature, ATWDesat Function is used as
well as it reduces the Noise. The limits of the color temperature setting remain
2000K and 11,000K
ㆍAWC (Auto White Balance)
When set to AWC, Color temperature of the Light is automatically adjusted.
ㆍManual (Manual White Balance)
Manual WhiteBalance(MWB)Mode is used when other White Balance Options
are failed.
WHITE BALANCE
Automatic Gain Control is a feature which adjust automatically according to the
incoming Signal. By positioning the arrow to 'AGC' on the SETUP menu with the
help of UP and DOWN buttons, you can select the Mode you wish to go
White Balance is a function which compensates different colors of light being
emitted from different light sources.
Users can select the above levels as they desire according to the environment.
ㆍATW (Auto Tracking White Balance) The ATW mode continuously monitors
color temperature. With WB Control set to ATW, color temperature & White
balance can be automatically adjusted accordingly.
AGC
AGC MIDDLE
DNR AUTO
SENS-UP AUTO
SPECIAL
EXIT

■
Setup Page Menu Setup Page Menu ■
AUTO
OFF
SETUP
LENS DC
WDR AUTO
WHITE BAL. ATW
AGC OFF
DNR AUTO
SENS-UP
SPECIAL
EXIT
ㆍPosition the arrow to point to 'SENS UP' on the SETUP menu by using the UP
and DOWN buttons.
ㆍSelect the value required by pressing the LEFT or RIGHT button.
● AUTO : Low light level automatic mode.
● OFF : The function does not operate.
ㆍPress the SET button when all the settings are complete.
SENS-UP
Sens-up helps maintain a bright, clear screen image by automatically detecting
changes in the level of light in low light level conditions.
16
Vandal Color Dome Camera Vandal Color Dome Camera
17
DNR
SETUP
LENS DC
WDR AUTO
WHITE BAL. ATW
AGC MIDDLE
HIGH
OFF
LOW
AUTO
SENS-UP OFF
AUTO
DNR
SPECIA
EXIT
SETUP
LENS DC
WDR AUTO
WHITE BAL. ATW
AGC MIDDLE
DNR AUTO
OFF
SENS-UP
SPECIAL
EXIT
ㆍAUTO
The Sensitivity increases automa-
tically when the light is low.
ㆍOFF
A Low Noise Picture is obtained
under a low light.
ㆍAs the level of gain increases, the
screen gets brighter and the level
of noise also increases.
ㆍAUTO
There is a reduction in noise
level with almost no ghost image.
ㆍOFF
There is no reduction in noise
level.
DNR is Digital Noise Reduction System with a maximum gain of 24 DB.

■
Special Page Menu Special Page Menu ■
18
Vandal Color Dome Camera Vandal Color Dome Camera
19
SPECIAL
CAMERA ID ON
DAY&NIGHT AUTO
MIRROR OFF
ON
DZOOM OFF
OFF
ADVANCED MENU
MOTION
RESET
RETURN
MIRROR
Select "OFF" to show the image as normal. Select "ON" to reflect image horizontally.
MIRROR ON MIRROR OFF
DAY & NIGHT
CAMERA ID OFF
DAY&NIGHT AUTO
BW
COLOR
MIRROR OFF
DZOOM OFF
OFF
ADVANCED MENU
MOTION
RESET
RETURN
SPECIAL
This camera has a function that automatically selects the mode that is appropriate
for daytime or night-time conditions. The COLOR mode operates in daytime conditions
to provide optimum colors, and BW mode operates in nighttime conditions to enhance
the definition of the image.
SPECIAL
CAMERA ID OFF
ON
DAY&NIGHT AUTO
MIRROR OFF
DZOOM OFF
OFF
ADVANCED MENU
MOTION
RESET
RETURN
CAMERA ID
ID CAM-001
POSITION UP-LEFT
PREVIOUS PAGE.
CAMERA ID
ID CAM-001
POSITION UP-LEFT
PREVIOUS PAGE.
ㆍYou can choose the ON and OFF
with the selector. If you select ON,
the entered camera ID is displayed
at the selected position in the video
picture (normal operation).
ㆍ Please select the setup button while
in ON mode.
ㆍSelect the desired position with the
selector.
① Move the cursor to the letter
requiredbyusingtheSet-Upbutton.
② Select an ID from A,B~Y,Z, a,b~y,z
0,1~8,9 by using the LEFT and
RIGHT buttons.
③ Repeat the above steps until the ID
is complete.
① Select the position where the ID
is to be displayed by using the
LEFT and RIGHT buttons.
CAMERA ID
User can enter a unique name for the respective camera.
The maximum length of the ID is ten characters.

■
Special Page Menu Advanced Page Menu ■
RESOLUTION
ADVANCED MENU
VIDEO STANDARD PAL
NTSC
RESOLUTION NORMAL
BACKLIGHT OFF
SHARPNESS -8----------8
SYNC
-8----------8APERTURE
RETURN
ADVANCED MENU
VIDEO STANDARD
RESOLUTION NORMAL
HIGH
BACKLIGHT OFF
PAL
SHARPNESS -8----------8
SYNC
-8----------8APERTURE
RETURN
ㆍThe high resolution supports
Progressive Rate video up to
540 TV Line and normal resolution
supports 480 TV Line.
Choose resolution between high and normal with the selector (RIGHT/LEFT)
VIDEO STANDARD
Choose video system between PAL and NTSC by moving the selector.
20
Vandal Color Dome Camera Vandal Color Dome Camera
21
MOTION
This product has a feature that allows you to observe movements of objects in
on the screen, and the words 'MOTION DETECTED!' appear on the screen
when movement is detected; hence a single individual can conduct supervision
efficiently. The camera detects an object's movement by sensing disparity of
outline, and level of brightness and color.
ㆍOff : Motion detection mode is
cancelled.
ㆍOn : Any motion in the selected
areas is observed.
DZOOM
ㆍBy Selecting ON, DZoom is
enabled.
ㆍBy Selecting OFF, DZoom is
disabled.
Digital P/T/Z are used to create a zoom lens effect. Zoom Factor (1X to 4X)
Pan(±100%, center of image can be moved to left and right edges of screen)
Tilt(±100%, center of image can be moved to top and bottom edges of screen)
SPECIAL
CAMERA ID ON
DAY&NIGHT AUTO
MIRROR OFF
DZOOM OFF
ON
OFF
ADVANCED MENU
MOTION
RESET
RETURN
SPECIAL
CAMERA ID ON
DAY&NIGHT AUTO
MIRROR OFF
DZOOM OFF
OFF
ON
ADVANCED MENU
MOTION
RESET
RETURN

22
Vandal Color Dome Camera Vandal Color Dome Camera
23
■
Advanced Page Menu Advanced Page Menu ■
ㆍ The available range of level is -8 ~ 8
The outline of the video image becomes cleaner and more distinctive as the level
of APERTURE increases. If the level gose up excessively, however, it may
affect the video image and generate noise.
APERTURE
ADVANCED MENU
VIDEO STANDARD PAL
RESOLUTION NORMAL
BACKLIGHT OFF
SHARPNESS -8----------8
SYNC
-8----------8APERTURE
RETURN
ADVANCED MENU
VIDEO STANDARD PAL
RESOLUTION NORMAL
BACKLIGHT OFF
SHARPNESS -8----------8
SYNC
-8----------8APERTURE
RETURN
ㆍ The available range of level is -8 ~ 8
SHARPNESS
The outline of the video image becomes cleaner and more distinctive as the level
of SHARPNESS increases. If the level gose up excessively, however, it may
affect the video image and generate noise.
BACKLIGHT
ADVANCED MENU
VIDEO STANDARD
RESOLUTION NORMAL
BACKLIGHT OFF
ON
SHARPNESS -8----------8
SYNC
-8----------8APERTURE
RETURN
ㆍWhen Backlight is ON, Back Light
gets activated.
ㆍ When Backlight is OFF, it is inactiv-
ated.
- INT : Internal synchronisation
- LL : External line-lock synchronisation
ㆍ If 'LL' is selected, it can be adjusted
to the desired phase.
Press the SET button.
ㆍAdjust to the desired phase from
0 to 624.
ㆍ "Sync" mode is fixed to INT in DC12V
input power
Backlight is feature of a Camera which compensates when there is a large
amount of background light.
SYNC
ADVANCED MENU
VIDEO STANDARD
RESOLUTION NORMAL
BACKLIGHT OFF
PAL
PAL
SHARPNESS -8----------8
INT
LL
SYNC
-8----------8APERTURE
RETURN
Two sychronisation modes are available, INTERNAL and EXTERNAL LINE-
LOCK. In LINE-LOCK mode, it synchronises the video signal between cameras
without a synchronous generator. The line-lock synchronisation is only used in
areas of 60Hz (NTSC) / 50Hz (PAL).

24
Vandal Color Dome Camera
■
Specifications
ITEM NTSC PAL
Image Sensor
Sync System
Scanning System
Electronic Shutter
Main Video Output
Service Monitor Output
Horizontal Resolution
Min. Illumination
S/N Ratio
Dynamic Range
AGC Control
Lens Options (DC Auto Iris)
Camera Control&Setup
Weatherproof
Power Consumption
Power Requirement
Operating Temperature
Operating Humidity
Weight
1/3'' C-MOS
INT / LL Selectable
525 Lines, Interlaced 625 Lines, Interlaced
1/60~1/100,000 1/50~1/100,000
1.0 Vp-p Composite, 75 ohm
1.0 Vp-p Composite, 75 ohm
480 TV Lines (Color), 530 TV Lines (B/W)
0.1 Lux (Color), 0.3 Lux (B/W)
48dB
120dB(max), 95dB(typical)
0~46dB
Vari-focal : 2.6~6mm, 3.8~9.5mm, 2.9~10mm
OSD Menu
IP66
200mA
DC12V / AC24V Dual Voltage
0℃~ +45℃
Within 90% RH
1,100g

Printed in KOREA
WDR Vandal Resistant
Color Dome Camera
Instruction Guide
WDR Vandal Resistant Color Dome Camera
