C&T Solution ACO-6000-KBL Series User manual

USER’S
MANUAL
ACO-6000-KBL Series
Surveillance Applied Fanless System

ACO-6000-KBL | User’s Manual
2
Please note, the ACO-6000 is now
referred to as “ACO-6000-KBL" due to
a model name change. All product
features and functionality remain the
same. If any questions, please
contact us for more information.
Name Change Guide:
LEGACY Model Name
NEW Model Name
ACO
-6000
ACO
-6000-KBL
ACO
-6010-16L
ACO
-6000-KBL-16X
ACO
-6010-16L-M12
ACO
-6000-KBL-16XM12
ACO
-6011
ACO
-6000-KBL-1

ACO-6000-KBL | User’s Manual
Table of Contents
Prefaces ……………………………………………………………………………………………….. 04
Revision ………………………………………………………..……………………………..……………….……….. 04
Disclaimer ……………………………………………………….…….……………….………………….………….. 04
Copyright Notice …………………………………….…….….………………………………….………………… 04
Trademarks Acknowledgment …………..………….………………………………………................... 04
Environmental Protection Announcement ……………………………………..……..……………….. 04
Safety Precautions ……………………………………………………………………………………….….…….. 05
Technical Support and Assistance ………………………………...……………………..…….…….……. 06
Conventions Used in this Manual …………………………………..……………………......….……….. 06
Package Contents ……………………………………………………………………..…..…………………….… 07
Ordering Information …………………………..……………………………………..………..….….………… 07
Optional Accessory …………...……………………………………................................................. 08
Chapter 1 Product Introductions ……………………………………………………..… 09
1.1 Overview ………………….………………………………..………….…………..……………….. 10
1.1.1 Key Feature ………….…………………..…………….……….…..…..…………....... 10
1.2 Hardware Specification ….………..………….....…………….……..……..……………… 11
1.3 System I/O ………..……………..……………………..……………………..…………………… 12
1.3.1 ACO-6000 ………………………......................……………………………………… 12
1.3.2 ACO-6000-4L(P) ………………………..……………..……………….………………... 14
1.3.3 ACO-6000-4L(P)-M12 ……………………………..…….……………………..……... 16
1.3.4 ACO-6000-8L(P) ………………………………………………………..………………... 18
1.3.5 ACO-6000-8L(P)-M12 ………………….……………….…..…..….………………... 20
1.3.6 ACO-6010-16L(P) …………….……................………………..…………………… 22
1.3.7 ACO-6010-16L(P)-M12 ……………………..……..…………..….………………... 24
1.3.8 ACO-6011E(P) ………….………………………………..…….…..…….……………... 26
1.3.9 ACO-6011E(P)-4L(P) …………………………………..…….…..…….……………... 28
1.3.10 ACO-6011E(P)-4L(P)-M12 ………………...……………………………………… 30
1.3.11 ACO-6011E(P)-8L(P) …………………………………….…………………………… 32
1.3.12 ACO-6011E(P)-8L(P)-M12 …………………………….…………………………… 34
1.4 Mechanical Dimension ……………………..………………………..…..………….………. 36
1.4.1 ACO-6000 / ACO-6000-4L(P) / ACO-6000-4L(P)-M12 /
ACO-6000-8L(P) / ACO-6000-8L(P)-M12 …………………………………….… 36
1.4.2 ACO-6010-16L(P) / ACO-6010-16L(P)-M12 …….………………………….… 37
1.4.3 ACO-6011E(P) / ACO-6011E(P)-4L(P) / ACO-6011E(P)-4L(P)-M12 /
ACO-6011E(P)-8L(P) / ACO-6011E(P)-8L(P)-M12 …..………………….... 38
Chapter 2 Switches and Connectors …………….……………………………………. 39
2.1 Switch and connector Locations ………………………………………..…….….…….... 40
2.1.1 Top View ………………………………………………………………………..…..……… 40
2.1.2 Bottom View ……………………………………………………………..……..……….. 41
2.2 Connector / Switch Definition ……………………………….……….…….……............. 42
2.3 Switch Definitions ………….……………............................................................. 43
2.4 Connector Definitions …………………………..................................................... 46
Chapter 3 System Setup …………………………..…………………………….…………… 61
3.1 Removing chassis bottom cover ………………...………………………………………..... 62
3.2 Removing PCIe/PCI expansion module …….……………..….…….…..….…………... 63
3.3 Removing chassis top cover …………….…………………………….….………………...... 64
3.4 Installing SODIMM …………….…………………………..…….…………………………....... 65
3.5 Installing CPU ……………………...…………………………..….……………………………...... 66
3

ACO-6000-KBL | User’s Manual
4
3.6 Installing mini PCIe card / mSATA ……………………...…….….……………………...... 71
3.7 Installing antenna ………………...…….………………….……………………..…………...... 72
3.8 Assembly chassis top cover …...…….………………………………………..…………...... 74
3.9 Installing HDD on internal SATA HDD bay …...…….…………………..….………...... 76
3.10 Installing HDD on removable SATA HDD bay ………………..…….……..………...... 78
3.11 Installing PCIe/PCI expansion card ………………..…………………..……..………...... 79
3.12 Assemble PCIe/PCI expansion module ……………….……………..……..………...... 80
3.13 Assemble chassis bottom cover ………………..………………..……..……….……...... 81
3.14 Installing SIM card ………………..…………………..…….………..………….…….……...... 82
3.15 Installing wall mount kit …………..……………....………………..……..……….……...... 84
Chapter 4 BIOS Setup …………………………………………………………..……………… 85
4.1 BIOS Introduction …….……….……………………………………….…….…..….…………... 86
4.2 Main Setup ……..……….………………….…………………………..….….………………...... 87
4.3 Advanced Setup …………………………………………..………………………………………… 88
4.3.1 CPU Configuration ..…………...………………………………………..………………. 89
4.3.2 PCH-FW Configuration ……..……………….………..………..……………..……... 90
4.3.3 SATA And RST Configuration ………………..……………….………………..….... 91
4.3.4 RST (UEFI RAID) Configuration ……………………………………….………….... 92
4.3.5 Trusted Computing ……………………………..……………….………………..….... 94
4.3.6 ACPI Settings ……………………………………………………….………………..….... 95
4.3.7 NCT6106D Super IO Configuration ……………………….………………..….... 96
4.3.8 NCT6106D HW Monitor ………………………………......………………..……..... 99
4.3.8 Serial Port Console Redirection ……………..………….………….….…….….... 99
4.3.10 Network Stack Configuration ……………..…………………………..…………....100
4.3.11 CSM Configuration ……………………………..……………..……..…………………. 101
4.3.12 USB Configuration …………………………..………………………….………..…….. 102
4.4 Chipset ………..………………….…..….…..…………………………………………………..….... 103
4.4.1 System Agent (SA) Configuration ………….…………………..………………….. 103
4.4.2 PCH-IO Configuration ………….……………………….………………..…………….. 106
4.5 Security …………...….………………….…..….………………………………………..…………... 109
4.6 Boot …………...……….….………………….…..………………………..…………..……………... 110
4.7 Save & Exit …...……….….………………….…..….…..………………………………………..... 111
Appendix WDT & GPIO …………………………………………………………………………… 112
WDT Sample Code …….……………………….……………….……………..….…….…….…………... 113
GPIO Sample Code ………………………………………………………..…………………………………. 114

ACO-6000-KBL | User’s Manual
5
Revision
Disclaimer
All specifications and information in this User’s Manual are believed to be accurate and up to date. We do
not guarantee that the contents herein are complete, true, accurate or non-misleading. The information in
this document is subject to change without notice.
We disclaim all warranties, express or implied, including, without limitation, those of merchantability,
fitness for a particular purpose with respect to contents of this User’s Manual. Users must take full
responsibility for the application of the product.
Copyright Notice
All rights reserved. No part of this manual may be reproduced or transmitted in any form or by any means,
electronic or mechanical, including photocopying, recording, or information storage and retrieval systems.
Trademarks Acknowledgment
Intel®, Celeron® and Pentium® are trademarks of Intel Corporation.
Windows® is registered trademark of Microsoft Corporation.
AMI is trademark of American Megatrend Inc.
IBM, XT, AT, PS/2 and Personal System/2 are trademarks of International Business Machines Corporation
All other products and trademarks mentioned in this manual are trademarks of their respective owners.
Environmental Protection Announcement
Do not dispose this electronic device into the trash while discarding. Please recycle to minimize pollution
and ensure environment protection.
Prefaces
Revision
Description
Date
1.0
Manual Released
2017/09/12
1.1
LAN Chipset Revised
2017/10/16
1.2
Power Connector Definition Revised
2017/11/02
1.3
GPIO Sample Code Revised
2018/02/09
1.4
New
-added CPU support, OS revised, and switches definition
revised
2018/10/09
1.5
WDT & GPIO
Sample Code Revised
2018/11/28
1.6
New
-added TPM 1.2 support
2019/08/12
1.7
New
-added RST (UEFI RAID) configuration & TPM 2.0 support
2020/03/12
1.8
Remove VGA feature for ACO
-6000 Series
2021/12/08

ACO-6000-KBL | User’s Manual
6
Safety Precautions
Before installing and using the equipment, please read the following precautions:
⚫Put this equipment on a reliable surface during installation. Dropping it or letting it fall could
cause damage.
⚫The power outlet shall be installed near the equipment and shall be easily accessible.
⚫Turn off the system power and disconnect the power cord from its source before making any
installation. Be sure both the system and the external devices are turned OFF. Sudden surge
⚫of power could ruin sensitive components. Make sure the equipment is properly grounded.
⚫When the power is connected, never open the equipment. The equipment should be opened
only by qualified service personnel.
⚫Make sure the voltage of the power source is correct before connecting the equipment to the
power outlet.
⚫Disconnect this equipment from the power before cleaning. Use a damp cloth. Do not use
liquid or spray detergents for cleaning.
⚫Avoid the dusty, humidity and temperature extremes.
⚫Do not place heavy objects on the equipment.
⚫If the equipment is not used for long time, disconnect it from the power to avoid being
damaged by transient over-voltage.
⚫The storage temperature shall be above -30°C and below 85°C.
⚫The computer is provided with a battery-powered real-time clock circuit. There is a danger of
explosion if incorrectly replaced. Replace only with the same or equivalent type
recommended by the manufacturer.
⚫If one of the following situation arises, get the equipment checked be service personnel:
•The power cord or plug is damaged.
•Liquid has penetrated into the equipment.
•The equipment has been exposed to moisture.
•The equipment does not work well or it cannot work according the user’s manual.
•The equipment has been dropped and damaged.
•The equipment has obvious signs of breakage.
Preface

ACO-6000-KBL | User’s Manual
7
Technical Support and Assistance
Contact your distributor, our technical support team or sales representative for technical support if you
need additional assistance. Please have following information ready before you call:
⚫Model name and serial number
⚫Description of your peripheral attachments
⚫Description of your software (operating system, version, application software, etc.)
⚫A complete description of the problem
⚫The exact wording of any error messages
Conventions Used in this Manual
Preface
This indication alerts operators to an operation that, if not strictly observed,
may result in severe injury.
WARNING
This indication alerts operators to an operation that, if not strictly observed,
may result in safety hazards to personnel or damage to equipment.
CAUTION
This indication provides additional information to complete a task easily.
NOTE

ACO-6000-KBL | User’s Manual
8
Package Contents
Before installation, please ensure all the items listed in the following table are included in the package.
Preface
Item
Description
Q’ty
1
ACO
-6000 Series Fanless Embedded System 1
2
Utility DVD Driver
1
3
Wall Mount Kit
1
4
Accessory Kit
1
Ordering Information
Model No. Product Description
ACO-6000 Surveillance Applied Fanless System with LGA 1151 for Intel® 6th/7th Gen Processor and Q170 PCH,
2x LAN
ACO-6000-4L Surveillance Applied Fanless System with LGA 1151 for Intel® 6th/7th Gen Processor and Q170 PCH,
6x LAN
ACO-6000-4L-M12 Surveillance Applied Fanless System with LGA 1151 for Intel® 6th/7th Gen Processor and Q170 PCH,
2x LAN, 4x M12 LAN
ACO-6000-8L Surveillance Applied Fanless System with LGA 1151 for Intel® 6th/7th Gen Processor and Q170 PCH,
10x LAN
ACO-6000-8L-M12 Surveillance Applied Fanless System with LGA 1151 for Intel® 6th/7th Gen Processor and Q170 PCH,
2x LAN, 8x M12 LAN
ACO-6010-16L Surveillance Applied Fanless System with LGA 1151 for Intel® 6th/7th Gen Processor and Q170 PCH,
18x LAN
ACO-6010-16L-M12 Surveillance Applied Fanless System with LGA 1151 for Intel® 6th/7th Gen Processor and Q170 PCH,
2x LAN, 16x M12 LAN
ACO-6010-4P Surveillance Applied Fanless System with LGA 1151 for Intel® 6th/7th Gen Processor and Q170 PCH,
2x LAN, 4x PoE
ACO-6010-4P-M12 Surveillance Applied Fanless System with LGA 1151 for Intel® 6th/7th Gen Processor and Q170 PCH,
2x LAN, 4x M12 PoE
ACO-6010-8P Surveillance Applied Fanless System with LGA 1151 for Intel® 6th/7th Gen Processor and Q170 PCH,
2x LAN, 8x PoE
ACO-6010-8P-M12 Surveillance Applied Fanless System with LGA 1151 for Intel® 6th/7th Gen Processor and Q170 PCH,
2x LAN, 8x M12 PoE
ACO-6010-16P Surveillance Applied Fanless System with LGA 1151 for Intel® 6th/7th Gen Processor and Q170 PCH,
2x LAN, 16x PoE
ACO-6010-16P-M12 Surveillance Applied Fanless System with LGA 1151 for Intel® 6th/7th Gen Processor and Q170 PCH,
2x LAN, 16x M12 PoE
ACO-6011E Surveillance Applied Fanless System with LGA 1151 for Intel® 6th/7th Gen Processor and Q170 PCH,
2x LAN, 1x PCIe x16 Expansion
ACO-6011E-4L Surveillance Applied Fanless System with LGA 1151 for Intel® 6th/7th Gen Processor and Q170 PCH,
6x LAN, 1x PCIe x16 Expansion

ACO-6000-KBL | User’s Manual
9
Preface
Model No. Product Description
ACO-6011E-4L-M12 Surveillance Applied Fanless System with LGA 1151 for Intel® 6th/7th Gen Processor and Q170 PCH,
2x LAN, 4x M12 LAN, 1x PCIe x16 Expansion
ACO-6011E-8L Surveillance Applied Fanless System with LGA 1151 for Intel® 6th/7th Gen Processor and Q170 PCH,
10x LAN, 1x PCIe x16 Expansion
ACO-6011E-8L-M12 Surveillance Applied Fanless System with LGA 1151 for Intel® 6th/7th Gen Processor and Q170 PCH,
2x LAN, 8x M12 LAN, 1x PCIe x16 Expansion
ACO-6011E-4P Surveillance Applied Fanless System with LGA 1151 for Intel® 6th/7th Gen Processor and Q170 PCH,
2x LAN, 4x PoE, 1x PCIe x16 Expansion
ACO-6011E-4P-M12 Surveillance Applied Fanless System with LGA 1151 for Intel® 6th/7th Gen Processor and Q170 PCH,
2x LAN, 4x M12 PoE, 1x PCIe x16 Expansion
ACO-6011E-8P Surveillance Applied Fanless System with LGA 1151 for Intel® 6th/7th Gen Processor and Q170 PCH,
2x LAN, 8x PoE, 1x PCIe x16 Expansion
ACO-6011E-8P-M12 Surveillance Applied Fanless System with LGA 1151 for Intel® 6th/7th Gen Processor and Q170 PCH,
2x LAN, 8x M12 PoE, 1x PCIe x16 Expansion
ACO-6011P Surveillance Applied Fanless System with LGA 1151 for Intel® 6th/7th Gen Processor and Q170 PCH,
2x LAN, 1x PCI Expansion
ACO-6011P-4L Surveillance Applied Fanless System with LGA 1151 for Intel® 6th/7th Gen Processor and Q170 PCH,
6x LAN, 1x PCI Expansion
ACO-6011P-4L-M12 Surveillance Applied Fanless System with LGA 1151 for Intel® 6th/7th Gen Processor and Q170 PCH,
2x LAN, 4x M12 LAN, 1x PCI Expansion
ACO-6011P-8L Surveillance Applied Fanless System with LGA 1151 for Intel® 6th/7th Gen Processor and Q170 PCH,
10x LAN, 1x PCI Expansion
ACO-6011P-8L-M12 Surveillance Applied Fanless System with LGA 1151 for Intel® 6th/7th Gen Processor and Q170 PCH,
2x LAN, 8x M12 LAN, 1x PCI Expansion
ACO-6011P-4P Surveillance Applied Fanless System with LGA 1151 for Intel® 6th/7th Gen Processor and Q170 PCH,
2x LAN, 4x PoE, 1x PCI Expansion
ACO-6011P-4P-M12 Surveillance Applied Fanless System with LGA 1151 for Intel® 6th/7th Gen Processor and Q170 PCH,
2x LAN, 4x M12 PoE, 1x PCI Expansion
ACO-6011P-8P Surveillance Applied Fanless System with LGA 1151 for Intel® 6th/7th Gen Processor and Q170 PCH,
2x LAN, 8x PoE, 1x PCI Expansion
ACO-6011P-8P-M12 Surveillance Applied Fanless System with LGA 1151 for Intel® 6th/7th Gen Processor and Q170 PCH,
2x LAN, 8x M12 PoE, 1x PCI Expansion
Optional Accessories
Model No. Product Description
1
-E09A12002
Adapter AC/DC 24V 5A 120W with 3pin Terminal Block Plug 5.0mm
Pitch, GST120A24
-CT1
1
-E09A22102
Adapter AC/DC 24V 9.2A 220W with 3pin Terminal Block Plug
5.0mm Pitch
, GST220A24-CT1
SFICBL022
Power Cord, 3
-pin US Type, 180cm
1
-TPCD00002
Power Cord, European Type, 180cm
1
-TPCD00001
Power Cord, 3
-pin UK Type, 180cm

Chapter 1
Product Introductions

ACO-6000-KBL | User’s Manual
11
1.1.1 Key Features
⚫LGA 1151 socket for 7th Gen. Intel® Core™i7-7700T (3.8GHz, Quad Core) / i5-7500T (3.3GHz, Quad Core),
i3-7101TE (3.4GHz, Dual Core) or 6th Gen. Intel® Core™i7-6700TE (3.4GHz, Quad Core) / i5-6500TE
(3.3GHz, Quad Core) / i3-6100TE (2.7GHz, Dual Core) or Pentium® G4400TE (2.4GHz, Dual Core) / Celeron®
G3900TE (2.3GHz, Dual Core) Desktop Processor
⚫Intel® Q170 Chipset
⚫2x 260-pin DDR4 SODIMM. Max up to 32GB
⚫Triple independent display supported by 1x DVI-I and 2x DisplayPort
⚫2x Intel® GbE supporting Wake-on-LAN and PXE (ACO-6000, ACO-6011E, ACO-6011P Only)
⚫6x Intel® GbE (w/ 2x supporting Wake-on-LAN and PXE) (ACO-6000-4L, ACO-6011E-4L, ACO-6011P-4L Only)
⚫10x Intel® GbE (w/ 2x supporting Wake-on-LAN and PXE) (ACO-6000-8L, ACO-6011E-8L, ACO-6011P-8L Only)
⚫18x Intel® GbE (w/ 2x supporting Wake-on-LAN and PXE) (ACO-6010-16L Only)
⚫4x Intel® GbE with M12 connector (ACO-6000-4L-M12, ACO-6011E-4L-M12, ACO-6011P-4L-M12 Only)
⚫4x Intel® GbE with PoE function (ACO-6000-4P, ACO-6011E-4P, ACO-6011P-4P Only)
⚫4x Intel® GbE with M12 PoE function (ACO-6000-4P-M12, ACO-6011E-4P-M12, ACO-6011P-4P-M12 Only)
⚫8x Intel® GbE with PoE function (ACO-6000-8P, ACO-6011E-8P, ACO-6011P-8P Only)
⚫8x Intel® GbE with M12 PoE function (ACO-6000-8P-M12, ACO-6011E-8P-M12, ACO-6011P-8P-M12 Only)
⚫16x Intel® GbE with M12 connector (ACO-6010-16L-M12 Only)
⚫16x Intel® GbE with PoE function (ACO-6000-16P Only)
⚫16x Intel® GbE with PoE function (ACO-6000-16P-M12 Only)
⚫2x Removable 2.5" SATA HDD Bay and 2x Internal 2.5” SATA SSD/HDD Bay supporting RAID 0, 1, 5, 10
⚫3x Full-size Mini-PCIe Socket with 3x SIM Card Socket for communication or expansion modules
⚫2x mSATA (Shared by 2x Mini-PCIe Socket)
⚫5x RS-232/422/485 (w/ 3x internal), 6x USB 3.0, 2x USB 2.0 (internal), TPM 2.0
⚫8x DI + 8x DO with Isolation
⚫1x PCI or 1x PCIe x16 Expansion (ACO-6011E, ACO-6011P Series Only)
⚫9 to 48VDC wide range power input supporting AT/ATX mode
⚫-25°C to 70°C extended operating temperature
⚫Power ignition management
1.1 Overview
Based on 7th Gen. Intel® Core™i7-7700T (3.8GHz, Quad Core) / i5-7500T (3.3GHz, Quad Core) / i3-7101TE
(3.4GHz, Dual Core) or 6th Gen. Intel® Core™i7-6700TE (3.4GHz, Quad Core) / i5-6500TE (3.3GHz, Quad Core) /
i3-6100TE (2.7GHz, Dual Core) or Pentium® G4400TE (2.4GHz, Dual Core)/ Celeron® G3900TE (2.3GHz, Dual Core)
Desktop processor (LGA 1151), ACO-6000 series is an extreme features integration, outstanding system
performance, versatile I/O connections, and rugged reliability fanless embedded systems. Compliant with E-Mark
and EMC Conformity with EN50155 & EN50121-3-2 certification, as well as support up to 18x LAN or 16x PoE
versions and power ignition function, It offers dramatically enhanced CPU and graphics performance, wide power
and feature scalability, and advanced features, modularize expansion I/O, rich connectivity interfaces, wide range
(9~48V) DC power input, and high reliability even operating in temperature extremes (-25 ° C~+70 ° C).
Featuring with completely cable-less designed, high functional, one-piece housing design, and anti-vibration,
ACO-6000 series are ruggedized systems that can operate in harsh environments and easy to install and maintain.
A build in over voltage protection (OVP), over current protection (OCP), reverse protection, and wide range DC
power input makes ACO-6000 series are safety system for all industrial applications.
Chapter 1: Product Introductions
ACO-6000 Series ACO-6011 SeriesACO-6010 Series

ACO-6000-KBL | User’s Manual
12
1.2 Hardware Specification
Chapter 1: Product Introductions
Processor System
•Support 6th & 7th Gen Intel® Core™i7 / i5 / i3 / Pentium® /
Celeron® Desktop Processor (LGA 1151) with AMI 128Mbit SPI
BIOS
- 7th Gen Intel® Core™i7-7700T, Quad Core,
8MB cache, up to 3.8 GHz
- 7th Gen Intel® Core™i5-7500T, Quad Core,
6MB cache, up to 3.3 GHz
- 7th Gen Intel® Core™i3-7101TE, Dual Core,
3MB Cache, 3.4 GHz
- 6th Gen Intel® Core™i7-6700TE, Quad Core,
8MB cache, up to 3.4 GHz
- 6th Gen Intel® Core™i5-6500TE, Quad Core,
6MB Cache, up to 3.3 GHz
- 6th Gen Intel® Core™i3-6100TE, Dual Core,
4MB Cache, 2.7 GHz
- Intel® Pentium G4400TE, Dual Core, 3MB Cache, 2.4 GHz
- Intel® Celeron G3900TE, Dual Core, 2MB Cache, 2.3 GHz
Memory
•2x 260-Pin DDR4 1866/2133MHz SODIMM. Max. up to 32GB
Display
Triple Display
•1x DVI-I and 2x DisplayPort
Expansion
•3x Full-size Mini PCIe Socket for Wi-Fi / GSM / Expansion
Module
•1x PCIe x16 expansion (ACO-6011E only)
•1x PCI expansion (ACO-6011P only)
•Card Dimension: 235 (L) x 112 (H) mm
Ethernet
•1x Intel®i210-AT GbE LAN Port and 1x Intel® i219LM GbE LAN ,
Support Wake-on-LAN and PXE
•4x Intel®I350-AM4 GbE LAN Port (ACO-60xx-4L and ACO-60xx-4L-M12
only)
•8x Intel®I350-AM4 GbE LAN Port (ACO-60xx-8L and ACO-60xx-8L-M12
only)
•16x Intel ®I350-AM4 GbE LAN Port (ACO-6010-16L and ACO-6010-16L-
M12 only)
•4x 802.3at Compliant PoE Port, The Maximum DC Power
Delivery on Each PoE is 25.5W (ACO-60xx-4P and ACO-60xx-4P-M12 only)
•8x 802.3at Compliant PoE Port, The Maximum DC Power
Delivery on Each PoE is 25.5W. 80W total power budget (ACO-
60xx-8P and ACO-60xx-8P-M12 only)
•16x 802.3at Compliant PoE Port, The Maximum DC Power
Delivery on Each PoE is 25.5W. 160W total power budget (ACO-
6010-16P and ACO-6010-16P-M12 only)
Audio
•Codec: Realtek ALC888S
•1x Mic-in and 1x Speak-out
Watchdog Timer
•Software Programmable Supports 1~255 sec. System Reset
TPM
•TPM 2.0
Storage
•2x Removable 2.5" SATA HDD Bay
•2x Internal 2.5" SATA HDD Bay
•2x Internal mSATA Slot (Shared by 2x Mini-PCIe Socket)
•2x External SIM Card Socket
•1x Internal SIM Card Socket
•Support RAID 0, 1, 5, 10
I/O Ports
•6x USB 3.0 Port and 2x internal USB 2.0 port
•8 Isolated DI and 8 Isolated DO Port
•2x DB9 for COM1~2, Support RS232/422/485 with Auto Flow
Control
•3x Internal connector for COM3~5, Support RS232/422/485
with Auto Flow Control
•6x Antenna Hole
•1x Power Switch
•1x AT/ATX Switch
•1x Remote Power on/off Connector
Digital Input & Output
•8x Digital Input (Source Type)
- Input Voltage (Dry Contact):
Logic 0: Close to GND
Logic 1: Open
- Input Voltage:
Logic 0: 3V max.
Logic 1: 5V min. (DI to COM-)
•8x Digital Output
- Supply Voltage: 5~30VDC
- Sink Current: 200 mA Max. Per Channel
Power
•Support AT, ATX Mode
•1x 3-pin Terminal Block Connector with Power Input 9~48VDC
•1x Optional AC/DC 24V/5A, 120W Power Adapter
•1x Optional AC/DC 24V/9.2A, 220W Power Adapter (ACO-60xx-
4P, ACO-60xx-4P-M12, ACO-60xx-8P, ACO-60xx-8P-M12, ACO-6010-16P, and
ACO-6010-16P-M12 only)
Environment
•Operating Temperature: Ambient with Air Flow:
-25°C to 70°C (with Industrial Grade Peripherals)
•Storage Temperature: -30°C to 85°C
•Relative humidity: 10%~95% (non-condensing)
Physical
•ACO-6000 Series
✓Dimension (WxDxH): 240 x 261 x 79 mm
✓Weight: 3.94 kg ~ 4.98 kg
•ACO-6010 Series
✓Dimension (WxDxH): 240 x 261 x 100 mm
✓Weight: 5.34 kg ~ 6.82 kg
•ACO-6011 Series
✓Dimension (WxDxH): 240 x 261 x 107 mm
✓Weight: 5.14 kg ~ 6.21 kg
•Construction: Extruded Aluminum with Heavy Duty Metal
•Mounting: Wall Mounting
Operating System
•6th Gen CPU: Windows 10, Windows 7, WES7
•7th Gen CPU: Windows 10
•Linux kernel 4.X
Certifications
•CE, FCC Class A, E-Mark, EMC Conformity with EN50155 &
EN50121-3-2

ACO-6000-KBL | User’s Manual
13
1.3 System I/O
1.3.1 ACO-6000
Chapter 1: Product Introductions
Front Panel
ATX power on/off switch
Press to power-on or power-off the system
Reset switch
Press to reset the system
USB 3.0 port
Used to connect USB 3.0/2.0/1.1 device
AT/ATX mode select switch
Used to select AT or ATX power mode
12V/24V power input select switch
Used to car mode select 12V or 24V power input
PC/Car mode select switch
Used to select PC or Car mode
Delay time select switch
Used to select car mode PC turn off delay time
Clear CMOS
Used to clear CMOS
SIM card
Used to insert SIM card
COM port
COM1 ~ COM2 support RS232/422/485 serial
device
Universal I/O Bracket
Used to customized I/O output
HDD port
Removable 2.5" SATA HDD Area
Power LED
Indicates the power status of the system
HDD LED
Indicates the status of the hard drive
Watchdog LED
Indicates the status of the watchdog active
GPIO LED
Indicates the status of the customer define
Ethernet LEDs
Indicates the status of the LAN active
Antenna hole
Used to connect an antenna for optional Mini-
PCIe WiFi module

ACO-6000-KBL | User’s Manual
14
Chapter 1: Product Introductions
Rear Panel
DC IN
Used to plug a DC power input with terminal
block
Speaker-out
Used to connect a speaker
Mic-in
Used to connect a microphone
Digital I/O Terminal Block
The Digital I/O terminal block supports 8 digital
input and 8 digital output
COM port
COM1 ~ COM2 support RS232/422/485 serial
device
DVI-I port
Used to connect a DVI monitor or connect
optional split cable for dual display mode
DisplayPort
Used to connect a DisplayPort monitor
USB 3.0 port
Used to connect USB 3.0/2.0/1.1 device
LAN port
Used to connect the system to a local area
network
Remote Power on/off Terminal Block
Used to plug a remote power on/off terminal
block
Antenna hole
Used to connect an antenna for optional Mini-
PCIe WiFi module

ACO-6000-KBL | User’s Manual
15
1.3.2 ACO-6000-4L(P)
Chapter 1: Product Introductions
Front Panel
ATX power on/off switch
Press to power-on or power-off the system
Reset switch
Press to reset the system
USB 3.0 port
Used to connect USB 3.0/2.0/1.1 device
AT/ATX mode select switch
Used to select AT or ATX power mode
12V/24V power input select switch
Used to car mode select 12V or 24V power input
PC/Car mode select switch
Used to select PC or Car mode
Delay time select switch
Used to select car mode PC turn off delay time
Clear CMOS
Used to clear CMOS
SIM card
Used to insert SIM card
COM port
COM1 ~ COM2 support RS232/422/485 serial
device
LAN Port
Used to connect the system to a local area
network (ACO-6000-4L Only)
PoE Port
Used to connect the system to a local area
network with power over Ethernet
(ACO-6000-4P Only)
Universal I/O Bracket
Used to customized I/O output
HDD port
Removable 2.5" SATA HDD Area
Power LED
Indicates the power status of the system
HDD LED
Indicates the status of the hard drive
Watchdog LED
Indicates the status of the watchdog active
GPIO LED
Indicates the status of the customer define
Ethernet LEDs
Indicates the status of the LAN active
Antenna hole
Used to connect an antenna for optional Mini-
PCIe WiFi module

ACO-6000-KBL | User’s Manual
16
Chapter 1: Product Introductions
Rear Panel
DC IN
Used to plug a DC power input with terminal
block
Speaker-out
Used to connect a speaker
Mic-in
Used to connect a microphone
Digital I/O Terminal Block
The Digital I/O terminal block supports 8 digital
input and 8 digital output
COM port
COM1 ~ COM2 support RS232/422/485 serial
device
DVI-I port
Used to connect a DVI monitor or connect
optional split cable for dual display mode
DisplayPort
Used to connect a DisplayPort monitor
USB 3.0 port
Used to connect USB 3.0/2.0/1.1 device
LAN port
Used to connect the system to a local area
network
Remote Power on/off Terminal Block
Used to plug a remote power on/off terminal
block
Antenna hole
Used to connect an antenna for optional Mini-
PCIe WiFi module

ACO-6000-KBL | User’s Manual
17
1.3.3 ACO-6000-4L(P)-M12
Chapter 1: Product Introductions
Front Panel
ATX power on/off switch
Press to power-on or power-off the system
Reset switch
Press to reset the system
USB 3.0 port
Used to connect USB 3.0/2.0/1.1 device
AT/ATX mode select switch
Used to select AT or ATX power mode
12V/24V power input select switch
Used to car mode select 12V or 24V power input
PC/Car mode select switch
Used to select PC or Car mode
Delay time select switch
Used to select car mode PC turn off delay time
Clear CMOS
Used to clear CMOS
SIM card
Used to insert SIM card
COM port
COM1 ~ COM2 support RS232/422/485 serial
device
M12 LAN Port
Used to connect the system to a local area
network (ACO-6000-4L-M12 Only)
M12 PoE Port
Used to connect the system to a local area
network with power over Ethernet
(ACO-6000-4P-M12 Only)
Universal I/O Bracket
Used to customized I/O output
HDD port
Removable 2.5" SATA HDD Area
Power LED
Indicates the power status of the system
HDD LED
Indicates the status of the hard drive
Watchdog LED
Indicates the status of the watchdog active
GPIO LED
Indicates the status of the customer define
Ethernet LEDs
Indicates the status of the LAN active
Antenna hole
Used to connect an antenna for optional Mini-
PCIe WiFi module

ACO-6000-KBL | User’s Manual
18
Chapter 1: Product Introductions
Rear Panel
DC IN
Used to plug a DC power input with terminal
block
Speaker-out
Used to connect a speaker
Mic-in
Used to connect a microphone
Digital I/O Terminal Block
The Digital I/O terminal block supports 8 digital
input and 8 digital output
COM port
COM1 ~ COM2 support RS232/422/485 serial
device
DVI-I port
Used to connect a DVI monitor or connect
optional split cable for dual display mode
DisplayPort
Used to connect a DisplayPort monitor
USB 3.0 port
Used to connect USB 3.0/2.0/1.1 device
LAN port
Used to connect the system to a local area
network
Remote Power on/off Terminal Block
Used to plug a remote power on/off terminal
block
Antenna hole
Used to connect an antenna for optional Mini-
PCIe WiFi module

ACO-6000-KBL | User’s Manual
19
1.3.4 ACO-6000-8L(P)
Chapter 1: Product Introductions
Front Panel
ATX power on/off switch
Press to power-on or power-off the system
Reset switch
Press to reset the system
USB 3.0 port
Used to connect USB 3.0/2.0/1.1 device
AT/ATX mode select switch
Used to select AT or ATX power mode
12V/24V power input select switch
Used to car mode select 12V or 24V power input
PC/Car mode select switch
Used to select PC or Car mode
Delay time select switch
Used to select car mode PC turn off delay time
Clear CMOS
Used to clear CMOS
SIM card
Used to insert SIM card
COM port
COM1 ~ COM2 support RS232/422/485 serial
device
LAN Port
Used to connect the system to a local area
network (ACO-6000-8L Only)
PoE Port
Used to connect the system to a local area
network with power over Ethernet
(ACO-6000-8P Only)
HDD port
Removable 2.5" SATA HDD Area
Power LED
Indicates the power status of the system
HDD LED
Indicates the status of the hard drive
Watchdog LED
Indicates the status of the watchdog active
GPIO LED
Indicates the status of the customer define
Ethernet LEDs
Indicates the status of the LAN active
Antenna hole
Used to connect an antenna for optional Mini-
PCIe WiFi module

ACO-6000-KBL | User’s Manual
20
Chapter 1: Product Introductions
Rear Panel
DC IN
Used to plug a DC power input with terminal
block
Speaker-out
Used to connect a speaker
Mic-in
Used to connect a microphone
Digital I/O Terminal Block
The Digital I/O terminal block supports 8 digital
input and 8 digital output
COM port
COM1 ~ COM2 support RS232/422/485 serial
device
DVI-I port
Used to connect a DVI monitor or connect
optional split cable for dual display mode
DisplayPort
Used to connect a DisplayPort monitor
USB 3.0 port
Used to connect USB 3.0/2.0/1.1 device
LAN port
Used to connect the system to a local area
network
Remote Power on/off Terminal Block
Used to plug a remote power on/off terminal
block
Antenna hole
Used to connect an antenna for optional Mini-
PCIe WiFi module
