CanMore GT-730F(G) User manual

GPS/GLONASS Receiver
User’s Manual
P
P
Pu
u
ur
r
re
e
e
W
W
Wh
h
hi
i
it
t
te
e
e
S
S
Sh
h
hi
i
in
n
ne
e
e
S
S
Sl
l
li
i
iv
v
ve
e
er
r
r
G
G
Ga
a
al
l
la
a
ax
x
xy
y
y
B
B
Bl
l
la
a
ac
c
ck
k
k

C
C
Ca
a
au
u
ut
t
ti
i
io
o
on
n
n
Read before you start to use:
Global position system (GPS)& The Global Navigation Satellite System(GLONASS) is obtained by American Ministry of National Defense, and
they got the full responsibility about the preciseness and the maintenance. Any changes may cause the capacity and preciseness o
f
GPS/GLONASS differed.
If you use this device inside of buildings, tunnels, or any huge objects beside you, the GPS/GLONASS signals might be cut-off or disturbed.
Please do not consider that the receiver is malfunction.
The receiver operating temperature is located between – 20°C and + 60°C.

1. Introduction
The GPS/GLONASS USB Dongle Receiver is a total solution of dual GPS/GLONASS receiver , all-in-view tracking technology.
This GPS/GLONASS USB Dongle Receiver can communicate with other electronic devices by USB interface.
The GPS/GLONASS USB Dongle Receiver is designed as an ultra low power consumption device, and high position accuracy. It will update the
satellite position every second. This GPS/GLONASS USB Dongle Receiver auto-locating feature is capable of automatically determining a
navigation solution without intervention. However, acquisition performance could be interfered and do cold start if the receiver were initialized with
occurrence of the following events:
1) First in use
2) The GPS receiver is not in use for more than 3 months or transportation over distances further than 500 kilometers.
2. Features and Functions
1) Signal detection better than -162dBm
2) Cold start < 30 seconds at –147dBm
3) Hot start < 1sec. under open sky.
4) 2.5m CEP accuracy.
5) Signal reacquisition 1 sec.
6) Acquire and track 34 satellites simultaneously
7) USB Version 1.1/2.0, 4dBm output level Up to 10m of operation
C
C
C
h
h
he
e
ec
c
ck
k
k
t
t
th
h
he
e
eP
P
Pa
a
ac
c
ck
k
ka
a
ag
g
ge
e
e
C
C
Co
o
on
n
nt
t
te
e
en
n
nt
t
t
Before you start using, please check out if your package includes the following items. If any item is damaged or missed, please
contact your reseller at once.
GPS/GLONASS USB Dongle receiver X 1
USB Adapter X 1(Option)
DVD manual ,driver, E-map for trial version X 1 (Option)

B
B
BA
A
AS
S
SI
I
IC
C
C
O
O
OP
P
PE
E
ER
R
RA
A
A
T
T
TI
I
IO
O
ON
N
NS
S
S
How to install for Laptop/UMPC
GPS/GLONASS USB Dongle
USB Connector
1) Plug USB connector(1) into Notebook USB port, see Fig 1.1

Fig 1.1
2) Install USB driver, users can find the USB driver on the attached DVD (file name: USB Driver), the USB driver can be installed for Microsoft
Windows 8, 7, XP, Vistar. User can easily install USB driver, the USB driver can automatically install the driver when user execute it.
3) Turn on Laptop/UMPC, please identify which COM port has been used (occupied) by USB GPS Dongle. The ways how to check COM port has
been used by GPS/GLONASS USB Dongle are as following ; Double clicks “Control panel ( C )“ Double clicks “System” Click “hardware”Click
“Hardware Manager” Double clicks “COM Port”, then user can find which COM port has been occupied by GPS/GLONASS USB Dongle.
4) Load your GPS mapping or routing software, along with the corresponding maps of the areas that you are occupying or plan
to travel. Start the application. Make sure the application is set for the COM port that your Laptop/UMPC device will use for
serial communication. Now you should be ready to use your GPS/GLONASS application as directed by the user documentation that
came with the software. More configurations may be necessary.
5) eMap will search GPS/GLONASS satellites automatically, users’ current position will be showed in the eMap after 3 satellites has
been

searched.( In firstly use of this GPS USB Dongle, we strongly recommend you to bring your GPS/GLONASS USB Dongle receiver outdoor or
open sky at least 15~20 minutes for sure 3D position fixed and almanac updated.). See Fig 1.2
Fig 1.2
6) How to identify GPS/GLONASS USB Dongle working status, please read the following description LED
Indicator.
1
LED OFF Receiver switching Off
2
LED Flashing Flashing 1sec. ON / 1sec. Off , Position is fixed
3
LED ON Signal searching

Concerning of Poor GPS Signal
It is possible unable to receive GPS/GLONASS signal or signal low in these places:
Inside the tunnel, GPS/GLONASS signal is
blocked.
Beside some buildings,
GPS/GLONASS signal is low or
disturbed.
Covers above,GPS/GLONASS signal are
blocked.
Inside forests, or too many covers,
GPS/GLONASS signal is low or
disturbed.
Inside buildings, GPS/GLONASS signal is
blocked.
If you use the GPS/GLONASS Receiver inside the car, some anti-sunlight windscreen film will make the GPS/GLONASS signal degraded or
signal blank.
GPS/GLONASS satellite is owned by America military; sometimes they will tune-down the accuracy by some reason. In such cases, the
GPS/GLONASS position may not fixed exactly.

★
★
★
N
N
No
o
ot
t
te
e
e:
:
:
Directly pluging GPS/GLONASS USB Dongle into the USB port may degrade GPS/GLONASS performance due to RF interference from
notebook or UMPC. Please add the USB extended adapter, and will be better performance. See Fig 1.3
Fig 1.3

Used equipment must be disposed of in compliance with current environmental protection regulations.
Y
ou should return it to your reseller or dispose of it in an approved recycling centre.
DECLARATION: We hereby declare that this product complies with essential requirements and other related
requirements, of the 1999/5/EC R&TTE directive and particularly with article 3 sections 1a, 1b and 3.
