Canon MF4010 Series User guide

ENG
Basic Guide
Please read this guide before operating this product.
After you finish reading this guide, store it in a safe place for future reference.
Before Using the Machine
Document Handling
Print Media
Copying
Printing
Scanning
Maintenance
Troubleshooting
Machine Settings
Appendix
Series
What Can I Do with This Machine?

i
Manuals for the Machine
●Machine Set-Up
●Software Installation
●Basic Features
●Maintenance
Starter Guide
●Basic Features
●Maintenance
●Machine Settings
●Specifications
Basic Guide
(This Document)
●Advanced Features
●System Monitor
●Troubleshooting Advanced Guide
●Scanning Features
Scanner Driver Guide
Indicates the manual is supplied in PDF format in the accompanying CD-ROM.
●To view the manual in PDF format, Adobe Reader/Adobe Acrobat Reader is required. If Adobe
Reader/Adobe Acrobat Reader is not installed on your system, please download it from the Adobe
Systems Incorporated website.
●Considerable effort has been made to ensure that the manuals for the machine are free of
inaccuracies and omissions. However, as we are constantly improving our products, if you need an
exact specification, please contact Canon.
●The machine illustration on the cover may differ slightly from your machine.
CD-ROM
CD-ROM
CD-ROM
CD-ROM

ii
What Can I Do with This Machine?
What Can I Do with This
Machine?
Copy Features
Select a scan mode depending on
the type of image
Image Quality
→p. 4-3
Adjust the density level of scanned
images
Density
→p. 4-4
Enlarge or reduce copied images
Zoom Ratio
→p. 4-6
Sorts copies by page order
Collate Copy
→Advanced Guide
ABC
ABC
ABC
ABC
AA
DDDD
DDDD
DDDD
DDDD
4
CCCC
CCCC
CCCC
CCCC
3
BBBB
BBBB
BBBB
BBBB
2
AAAA
AAAA
AAAA
AAAA
1
AAAA
AAAA
AAAA
AAAA
1
AAAA
AAAA
AAAA
AAAA
1
AAAA
AAAA
AAAA
AAAA
1
AAAA
AAAA
AAAA
AAAA
1

iii
What Can I Do with This Machine?
Printer Feature
Scanner Feature
Copy two documents on one sheet
2 on 1 Combination
→Advanced Guide
Print a document from a PC
Printing
→Online Help
Specify detailed scanning options
to suit various images
Scanning
→Scanner Driver Guide
ABC
ABC
ABC
ABC
1
DEF
DEF
DEF
DEF
2
DEF
DEF
DEF
DEF
2
ABC
ABC
ABC
ABC
1
ABC
ABC
ABC
ABC
1
D
E
F
D
EF
ABC
ABC
ABC
ABC

iv
What Can I Do with This Machine?
Contents
Manuals for the Machine.................................................................i
What Can I Do with This Machine? ...............................................ii
Copy Features ................................................................. ii
Printer Feature.................................................................iii
Scanner Feature ..............................................................iii
Contents .........................................................................................iv
How to Use This Guide.................................................................vii
Symbols Used in This Manual ........................................vii
Illustrations Used in This Manual...................................viii
Legal Notices .................................................................................ix
Trademarks..................................................................... ix
Copyright ........................................................................ ix
Disclaimers ..................................................................... ix
1 Before Using the Machine ......................................................1-1
Machine Components .................................................................1-1
Operation Panel ...........................................................................1-4
Main Operation Panel ...................................................1-4
LCD (Standby Mode) ...................................................................1-6
Copy Mode ...................................................................1-6
Scan Mode....................................................................1-6
Toner Cartridge............................................................................1-7
Maintaining the Toner Cartridge ...................................1-8
Timer Settings..............................................................................1-9
Setting the Sleep Mode ................................................1-9
2 Document Handling.................................................................2-1
Document Requirements ............................................................2-1
Scanning Area..............................................................................2-2
Loading Documents ....................................................................2-3

v
What Can I Do with This Machine?
3 Print Media ...............................................................................3-1
Paper Requirements....................................................................3-1
Printable Area ..............................................................................3-2
Paper Guidelines .........................................................................3-3
Loading Paper..............................................................................3-4
Into the Multi-Purpose tray............................................3-4
Setting Paper Size and Type.......................................................3-7
4 Copying ....................................................................................4-1
Scan Settings...............................................................................4-3
Image Quality................................................................4-3
Density..........................................................................4-4
Zoom Ratio ...................................................................4-6
5 Printing.....................................................................................5-1
6 Scanning ..................................................................................6-1
7 Maintenance.............................................................................7-1
Cleaning the Machine..................................................................7-1
Exterior .........................................................................7-1
Interior...........................................................................7-2
Fuser Roller ..................................................................7-5
Scanning area...............................................................7-6
Replacing the Toner Cartridge ...................................................7-7
Redistributing Toner .....................................................7-7
Replacing the Toner Cartridge with a New One ...........7-9
Transporting the Machine.........................................................7-12

vi
What Can I Do with This Machine?
8 Troubleshooting ......................................................................8-1
Clearing Jams ..............................................................................8-1
Paper Jams...................................................................8-1
LCD Messages .............................................................................8-7
Common .......................................................................8-7
Printer .........................................................................8-11
If You Cannot Solve a Problem ................................................8-12
9 Machine Settings.....................................................................9-1
Machine Settings .........................................................................9-1
Accessing the Setting Menu .........................................9-1
Setting Menu ................................................................................9-3
PAPER SETTINGS ......................................................9-3
COMMON SETTINGS .................................................9-3
COPY SETTINGS ........................................................9-4
TIMER SETTINGS .......................................................9-4
ADJUST./CLEANING ..................................................9-5
10 Appendix ..............................................................................10-1
Specifications ............................................................................10-1
General .......................................................................10-1
Copier .........................................................................10-2
Printer .........................................................................10-3
Index ...........................................................................................10-4

vii
What Can I Do with This Machine?
How to Use This Guide
Symbols Used in This Manual
The following symbols are used throughout the manuals for the machine and indicate
the warnings, cautions and notes you should keep in mind when using the machine.
WARNING Indicates a warning that may lead to death or serious injury if not
observed.
CAUTION Explains how to avoid actions that could injure you or damage your
machine.
NOTE Explains operating restrictions and how to avoid minor difficulties.
In addition, this guide uses distinctive notations to identify keys and information in the
LCD:
– The keys you press appear in square brackets: [Stop/Reset].
– Information in the LCD appears in angle brackets: <LOAD PAPER>.
The numbers that point to the keys on the operation panel diagram correspond to the
order of steps to take in the procedure.

viii
What Can I Do with This Machine?
Illustrations Used in This Manual
Unless otherwise mentioned, illustrations used in this manual are those taken when no
optional equipment is attached to the MF4010.
The model MF4010 is used for illustration purposes in this manual.

ix
What Can I Do with This Machine?
Legal Notices
Trademarks
Canon and the Canon logo are trademarks of Canon Inc.
All other product and brand names are registered trademarks, trademarks or service
marks of their respective owners.
Copyright
Copyright © 2007 by Canon Inc. All rights reserved. No part of this publication may be
reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any
language or computer language in any form or by any means, electronic, mechanical,
magnetic, optical, chemical, manual, or otherwise, without the prior written permission
of Canon Inc.
Disclaimers
The information in this document is subject to change without notice.
CANON INC. MAKES NO WARRANTY OF ANY KIND WITH REGARD TO THIS
MATERIAL, EITHER EXPRESS OR IMPLIED, EXCEPT AS PROVIDED HEREIN,
INCLUDING WITHOUT LIMITATION, THEREOF, WARRANTIES AS TO
MARKETABILITY, MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE
OF USE OR NON-INFRINGEMENT. CANON INC. SHALL NOT BE LIABLE FOR ANY
DIRECT, INCIDENTAL, OR CONSEQUENTIAL DAMAGES OF ANY NATURE, OR
LOSSES OR EXPENSES RESULTING FROM THE USE OF THIS MATERIAL.

1-1
Before Using the Machine
Before Using the
Machine
Machine Components
A Platen glass cover
Open this cover when placing a document on
the platen glass.
B Operation panel
Controls the machine.
C Output tray
Receives copies and prints.
D Paper feeding tray
Loads the paper supply.
A
BCD

1-2
Before Using the Machine
E Platen glass
Place documents.
F Output tray extension
Extension for the output tray.
G Paper stopper
Prevents the paper from falling off the output
tray.
Open the paper stopper from its original
position for A4 paper.
H Slide guides for multi-purpose tray
Adjusts to the width of the paper.
I Paper guide rail
Holds the paper supply.
J Dust cover
Protects the paper supply in the paper
feeding tray from the dirt and dust.
K Multi-purpose tray
Feeds paper when you insert one by one
manually.
L Scanning platform
Open this platform when replacing the toner
cartridge or clearing paper jams.
M Main power switch
Turn the power on or off.
H
EF
I
M
G
JKL

1-3
Before Using the Machine
N USB port
Connect the USB (Universal Serial Bus)
cable.
O Rear cover
Open this cover when clearing paper jams.
P Power socket
Connect the power cord.
N
O
P

1-4
Before Using the Machine
Operation Panel
Main Operation Panel
A [System Monitor] key
Press to check print status, print and scan
counts.
B [View Settings] key
Press to confirm settings of the copy function.
C [COPY] key
Press to switch to the Copy mode.
D [SCAN] key
Press to switch to the Scan mode.
E [Additional Functions] key
Press to select or cancel the modes in
Additional Functions.
F [Enlarge/Reduce] key
Press to enlarge or reduce copy ratio.
G[Density]key
Press to adjust copy.
H [Image Quality] key
Press to select image quality for copy.
I [Collate/2 on 1] key
Press to collate copies, or press to set 2 on 1
copying.
J [Energy Saver] key
Press to set or cancel the Sleep mode
manually. The key lights green when the
Sleep mode is set, and goes off when the
mode is canceled.
K [Stop/Reset] key
Press to stop a current job. Also, press to
return the machine to the standby mode.
AB C D E F G I JH
TS R Q P NMLK
O

1-5
Before Using the Machine
L Error indicator
Flashes when an error has occurred.
M Processing/Data indicator
Lights when the machine has waiting jobs.
N [Start] key
Press to start copying and scanning.
ONumerickeys
Enter numbers.
P [Clear] key
Press to clear entered alphanumeric characters.
Q[ ]key
Press to increase the value for various
settings. Also press to see the next item in
the menu.
R[OK]key
Press to accept a set function or mode.
S[]key
Press to decrease the value for various
settings. Also press to see the previous item
in the menu.
T LCD display
Displays messages and prompts during
operation. Displays selection, text, and
numbers when adjusting the settings.

1-6
Before Using the Machine
LCD (Standby Mode)
Copy Mode
AZoomratio
B Paper size
C Quantity
DDensity
E Image quality
Scan Mode
NOTE
– Depending on your needs, you can change the standby display which appears when the main power
switch is turned on. For details, see “Setting Menu,” on p. 9-3.
– When the main power switch is turned on, the LCD displays <PLEASE WAIT> first, and then displays
<INITIALIZING...> until the standby display appears. It is also possible to see the standby display
without having <INITIALIZING...> shown.
– If the machine remains idle for one minute, the display returns to the standby mode (Auto Clear
Function).
100% A4
TEXT/PHOTO 1
A
DE
BCSCANNING MODE

1-7
Before Using the Machine
Toner Cartridge
The lifetime of the Canon Genuine toner cartridge used in this machine is
approximately 2,000 pages. The page counts are on the basis of ISO/IEC 19752*
when printing A4 size paper with the default print density setting. The level of toner
consumption varies depending on the type of documents printed. If your average
document contains a lot of graphics, tables, or charts, the life of the toner cartridge
will be shorter as they consume more toner. When you are replacing a toner
cartridge, be sure to use a toner cartridge designed for this product. To purchase a
new Canon genuine toner cartridge, contact your local authorized Canon dealer or
Canon help line.
* “ISO/IEC 19752” is the global standard related to “Method for the determination of toner cartridge yield
for monochromatic electrophotographic printers and multi-function devices that may contain printer
components” issued by ISO (International Organization for Standardization).
Model Name Supported Canon Genuine Cartridge Print Yield
MF4010
MF4018 Canon FX10 Cartridge Approx. 2,000 pages
Toner Cartridge name:
Canon FX10 Cartridge

1-8
Before Using the Machine
Maintaining the Toner Cartridge
●Keep the toner cartridge away from computer screens, disk drives, and floppy disks.
The magnet inside the toner cartridge may harm these items.
●Avoid locations subject to high temperature, high humidity, or rapid changes in
temperature.
●Do not expose the toner cartridge to direct sunlight or bright light for more than five
minutes.
●Store the toner cartridge in its protective bag. Do not open the bag until you are
ready to install the toner cartridge in the machine.
●Save the toner cartridge’s protective bag in case you need to repack and transport
the toner cartridge at a later date.
●Do not store the toner cartridge in a salty atmosphere or where there are corrosive
gases such as from aerosol sprays.
●Do not remove the toner cartridge from the machine unnecessarily.
●Do not open the drum protective shutter on the toner cartridge. Print quality may
deteriorate if the drum surface is exposed to light or is damaged.
●Always hold the toner cartridge by its handle to avoid touching the drum protective
shutter.
●Do not stand the toner cartridge on end, and do not turn it upside down. If toner
becomes caked in the toner cartridge, it may become impossible to free it even by
shaking the toner cartridge.
CAUTION
Do not place the toner cartridge in fire. Toner powder is flammable.

1-9
Before Using the Machine
Timer Settings
Setting the Sleep Mode
When the machine remains idle for a certain period of time, it automatically enters the
Sleep mode.
1Press [Additional Functions].
2Press [ ] or [ ] to select <TIMER SETTINGS>, then press [OK].
3Press [ ] or [ ] to select <AUTO SLEEP>, then press [OK].
1
2
3
[OK]

1-10
Before Using the Machine
4Press [ ] or [ ] to select <ON>, then press [OK].
5Press [ ] or [ ] to select the desired interval, then press [OK].
You can set the interval from 3 to 30 minutes (in one-minute increments).
You can also enter values with the numeric keys.
6Press [Stop/Reset] to return to the standby mode.
4
5
[OK]
6
