Canon XF400 User manual

4K Camcorder
PUB. DIE-0518-000
Instruction Manual
PAL

2
Introduction
COPYRIGHT WARNING
Unauthorized recording of copyrighted materials may infringe on the rights of copyright owners and be
contrary to copyright laws.
Trademark Acknowledgements
• SD, SDHC and SDXC Logos are trademarks of SD-3C, LLC.
• Microsoft and Windows are trademarks or registered trademarks of Microsoft Corporation in the United
States and/or other countries.
• Apple, macOS are trademarks of Apple Inc., registered in the U.S. and other countries.
• HDMI, the HDMI logo and High-Definition Multimedia Interface are trademarks or registered trademarks of
HDMI Licensing LLC in the United States and other countries.
• Wi-Fi is a registered trademark of the Wi-Fi Alliance.
• Wi-Fi Certified, WPA, WPA2, and the Wi-Fi Certified logo are trademarks of the Wi-Fi Alliance.
• WPS as used on the camcorder’s settings, onscreen displays and in this manual signifies Wi-Fi Protected
Setup.
• The Wi-Fi Protected Setup Identifier Mark is a mark of the Wi-Fi Alliance.
• JavaScript is a trademark or registered trademark of Oracle Corporation, its affiliates or subsidiaries in the
United States and other countries.
• Other names and products not mentioned above may be trademarks or registered trademarks of their
respective companies.
• This device incorporates exFAT technology licensed from Microsoft.
• This product is licensed under AT&T patents for the MPEG-4 standard and may be used for encoding
MPEG-4 compliant video and/or decoding MPEG-4 compliant video that was encoded only (1) for a
personal and non-commercial purpose or (2) by a video provider licensed under the AT&T patents to provide
MPEG-4 compliant video. No license is granted or implied for any other use for MPEG-4 standard.

3
Highlights of the XF405 / XF400
The Canon XF405 / XF400 4K Camcorder is a high-performance camcorder whose compact size makes it ideal
in a variety of situations. The following are just some of the many functions featured in the camcorder.
4KRecording
Advanced sensor and image processor
The camcorder is equipped with a 1.0-type CMOS
sensor that captures video at an effective pixel count
of approximately 8.29 megapixels (3840x2160). The
video is then processed by the state-of-the-art dual
DIGIC DV 6 image processing platform. This allows
the camcorder to excel in low-light situations and
achieve improved image stabilization.
Wide zoom lens
The camcorder features a 15x optical zoom lens
with a focal length at full wide angle of 25.5 mm
(35 mm equivalent), offering superb wide-angle
shooting capability.
Convenience and Functionality
Emphasison versatility
This camcorder has features to make it usable as a
main camera but is also small enough to be very
portable. The advanced image stabilization (A61)
will let you shoot in a variety of situations in the field.
The handle unit is removable so you can attach it to
enjoy additional audio options and infrared
functionality, or remove it when you need improved
portability.
Manual controlsat your fingertips
The focus/zoom ring helps you achieve the focus
you are looking for. You can easily change the ring's
functionality so that you can operate the zoom. You
can also assign certain frequently used functions to
a customizable button and adjust those functions
with the accompanying dial (A93). Additionally,
the camcorder also features 5 assignable buttons
on the camcorder and one onscreen assignable
touch button to which you can assign a variety of
functions to access them with ease (A94).
Infrared recording
Record in darkness using infrared recording
(A88). With the built-in infrared light on the handle
unit, you can record nocturnal animals in their
natural environment or other such scenes.
SD card recording options
The camcorder can record 4K video in MP4 format
on an SD card. It is equipped with 2 SD card slots,
allowing you to use dual recording (A47) to record
the same clip on two SD cards, or relay recording to
automatically switch to the other SD card when the
one being used is full. Dual recording is a convenient
way to create a backup of your recordings, while
relay recording effectively extends the available
recording time.
Networkfunctions(A113)
You can connect the camcorder to a Wi-Fi or wired
(Ethernet) network. This allows you to control the
camcorder remotely from a connected network
device using the Browser Remote application
(A123) and to easily transfer files to a remote FTP
server using the FTP protocol (A131).
Time code options(A74)
The time code generated by the camcorder can be
output from the SDI OUT terminal (monly) or
HDMI OUT terminal in order to synchronize it with
other external devices. A user bit code (A76) can
also be output with the output signal.
Dual Pixel CMOSAF
The camera features Dual Pixel CMOS AF
technology for improved autofocus functions
(A49). In addition to continuous AF, AF-boosted
MF lets you focus manually most of the way and let
the camcorder finish focusing automatically. With
AF-boosted MF the camcorder does not perform
unreliable focus adjustments, resulting in a smoother
focusing operation than with continuous AF. The
camcorder can also focus automatically on people's
faces and track moving subjects while keeping them
in focus (A54).
Even while focusing manually, the newly-added Dual
Pixel Focus Guide function (A50) serves as a
visual, intuitive guide that you can use to check if the
image is in focus and the required adjustment, if it is
not. This can be very helpful to ensure you always
get amazingly sharp 4K video.

4
Creativity and Artistic Expression
Special recording modes(A48, 87)
When you make recordings, you can change the
recording frame rate to achieve a fast or slow motion
effect. Alternatively, you can use pre-recording to
record 3 seconds before you decide to start
recording, helping you capture those hard-to-catch
opportunities.
Looks (A73)
You can adjust various aspects of the picture, such
as the color depth, sharpness and brightness, to
create a desired "look". If you prefer, you can use
one of the preset looks offered. The [Wide DR] look,
for example, applies a gamma curve with a very
wide dynamic range and an appropriate color
matrix.
Other Features
• Battery packs compatible with Intelligent System
give you an estimate (in minutes) of the remaining
recording time.
• Compatibility with the optional GP-E2 GPS
Receiver to geotag your recordings (A90).
• Multiple image stabilization options (A61) to
match your recording conditions.
• Compatibility with the optional RC-V100 Remote
Controller (A89) when you need a professional
level of remote control far surpassing that of the
supplied wireless controller.
• Clear, adjustable LCD panel (A24) and
adjustable viewfinder (A24) for ease of use
regardless of the recording angle.

5
1. Introduction 9
About thisManual 9
Conventions Used in this Manual 9
Supplied Accessories11
Namesof Parts12
Camcorder 12
Handle Unit 17
WL-D89 Wireless Controller 18
2. Preparations 19
Preparing the Power Supply 19
Using a Battery Pack 19
Preparing the Camcorder 22
Attaching the Microphone Holder Unit 22
Attaching the Handle Unit 22
Using the Lens Hood and Lens Cap 23
Using the Viewfinder 24
Using the LCD Screen 24
Adjusting the Grip Belt and Using Straps 25
Wireless Controller 26
Using a Tripod 27
Basic Operation of the Camcorder 28
Turning the Camcorder On and Off 28
Changing the Camcorder's Operating Mode 29
Using the MENU Button and Joystick 29
Date, Time and Language Settings30
Setting the Date and Time 30
Changing the Language 31
Changing the Time Zone 31
Using SD Cards32
Compatible SD Cards 32
Inserting and Removing an SD Card 33
Initializing an SD Card 34
Selecting the SD Card for Recordings 34
Using the Menus35
FUNC Menu 35
Setup Menus 36
3. Recording 39
Recording Video and Photos39
Preparing to Record 39
Basic Recording 40
Reviewing the Latest Clip Recorded 41
Using the Fan 42
Onscreen Displays 42
Video Configuration: Resolution, Bit Rate and
Frame Rate 46
Selecting Internal Recording 46
Selecting the Resolution and Bit Rate 46
Selecting the Frame Rate 46
Dual Recording and Relay Recording 47
Slow & Fast Motion Recording 48
Adjusting the Focus49
Manual Focus 49
AF-Boosted MF 52
Continuous AF 53
Changing the AF Frame Size 53
Face Detection & Tracking 54
Zooming 56
Using the Focus/Zoom Ring 56
Using the Zoom Rockers 57
Using the Supplied Wireless Controller or an
Optional Remote Controller 59
Using the Touch Screen’s Zoom Controls 59
Digital Tele-Converter 60
Image Stabilization 61
Dynamic IS or Standard IS 61
Powered IS 61
Automatic Gain Control (AGC) Limit 63
Shooting Modes64
Programmed AE (’)64
Shutter Priority AE (‚)64
Aperture Priority AE (“)65
Manual Exposure (n)65
Special Scene Modes 66
Adjusting the Exposure 67
Exposure Lock (AE Lock) 67
Touch Exposure 67
Exposure Compensation 68
Backlight Correction 68
Zebra Pattern 69
ND Filter 70
Table of Contents

6
White Balance 71
Using Looks 73
Setting the Time Code 74
Selecting the Time Code Mode 74
Setting the User Bit 76
Recording Audio 77
Selecting the Audio Recording Format 77
Audio Settings and Recorded Audio Channels 78
Connecting an External Microphone or External
Audio Input Source to the Camcorder 79
Selecting the Audio Input Source for Audio
Channels 80
Adjusting the Audio Recording Level 81
Advanced Microphone Settings 83
Using Headphones85
Color Bars/Audio Reference Signal 86
Recording Color Bars 86
Recording an Audio Reference Signal 86
Pre-Recording 87
Infrared Recording 88
Using the Optional RC-V100 Remote
Controller 89
Using the Optional GP-E2 GPSReceiver 90
4. Customization 93
CUSTOM Dial and Button 93
Assignable Buttons94
Changing the Assigned Function 94
Assignable functions 95
Saving and Loading Camcorder Settings96
Saving Camcorder Settings 96
Loading Camcorder Settings 96
5. Playback 97
Basic Playback97
The Playback Index Screen 97
Changing the Index Screen 98
Playing Back Recordings 98
Playback Controls 99
Adjusting the volume 100
Displaying Clip Information 100
Clip and Photo Operations101
Deleting Clips and Photos 101
Trimming Clips 102
Copying Clips and Photos 103
Recovering Clips 104
6. External Connections 105
Video Output Configuration 105
Video Output Configuration by Terminal (Internal
Recording Priority) 105
Video Output Configuration by Terminal (External
Recording Only) 106
Connecting to an External Monitor or
Recorder 107
Connection Diagram 107
Recording Video Using an External Recorder 107
Connecting an External Monitor 108
Audio Output 110
Selecting the Audio Channels 110
Working with Clipson a Computer 111
7. Network Functions 113
About the NetworkFunctions113
Connecting to a Wi-Fi Network115
Camera Access Point 116
Connecting in Infrastructure Mode 117
Wi-Fi Protected Setup (WPS) 118
Searching for Access Points 119
Manual Setup 120
Connecting to a Wired (Ethernet) Network121
Selecting a NetworkConnection and Changing
NetworkSettings122
Selecting a Network Connection 122
Changing Network Settings 122
Browser Remote: Controlling the Camcorder from
a NetworkDevice 123
Setting Up Browser Remote 123
Starting Browser Remote 124
Using Browser Remote 126
FTP File Transfer 131
Setting Up the FTP Server and Transfer
Settings 131
Transferring Clips (FTP Transfer) 132

7
8. Additional Information 133
Menu Options133
FUNC Menu 133
Setup Menus 134
Troubleshooting 141
List of Messages 145
Safety Instructionsand Handling Precautions149
Maintenance/Others153
Optional Accessories154
Specifications156
Reference Tables159
Charging Times 159
Approximate Recording Time on an SD Card 159
Approximate Recording Times with a Fully
Charged Battery Pack 159
Index 161

8

1
9
Introduction
About this Manual
Thank you for purchasing the Canon XF405 / XF400. Please read this manual carefully before you use the
camcorder and retain it for future reference. Should your camcorder fail to operate correctly, refer to
Troubleshooting (A141).
Conventions Used in this Manual
• IMPORTANT: Precautions related to the camcorder’s operation.
• NOTES: Additional topics that complement the basic operating procedures.
•A: Reference page number within this manual.
•m: Text and/or illustrations that apply only to the model indicated in the icon.
• The following terms are used in this manual:
“Memory card” refers to an SD, SDHC or SDXC card.
“Screen” refers to the LCD screen and the viewfinder screen.
“Clip” refers to a single movie unit recorded with a single recording operation (for example, from the point when
the REC button is pressed to start recording until it is pressed again to stop).
“Network device” refers to a device (like a smartphone or tablet) connected to the camcorder via Wi-Fi or
through a wired network using the (Ethernet) terminal.
• The photos included in this manual are simulated pictures taken with a still camera. Unless indicated
otherwise, illustrations refer to the m. Some screenshots have been altered to make them easier to
read.
• Operating mode icons: A shaded icon (like ) indicates that the function described can be used in the
operating mode shown; a non-shaded icon (like ) indicates that the function cannot be used.
Operating modes:
Position of the POWER switch: shooting (CAMERA) or playback (MEDIA) mode.
For details, refer to Turning the Camcorder On and Off (A28).
Position of the mode switch. For details refer to Changing the Camcorder's
Operating Mode (A29).

About thisManual
10
• The following style is used to represent menu selections. For a detailed explanation on how to use the menus,
refer to Using the Menus (A35). For a summary of all available menu options and settings, refer to Menu
Options (A133).
This indicates to press the
MENU button.
Brackets [ ] indicate text as it appears on the
camcorder's screen (menu options, onscreen
buttons, messages, etc.).
This arrow indicates a deeper
level in the menu hierarchy or
the next step in a procedure.
1Select [Internal/External Rec].
>[3!Recording Setup] >[Internal/External Rec]
2 Touch [vInternal Rec Priority] and then touch [X].
The menu page number is given
only for main procedures.

11
Supplied Accessories
Supplied Accessories
The following accessories are supplied with the camcorder:
CA-946 AC Adapter
(incl. power cord)
BP-828 Battery Pack Microphone holder unit
(incl. screws)
Handle unit (incl. screws)
Lens hood with lens barrier Lens cap WL-D89 Wireless Controller
(incl. CR2025 lithium button
battery)
Quick Guide

Namesof Parts
12
Names of Parts
Camcorder
1 ND FILTER +/– buttons (A70)
2 PRE REC (pre-recording) button (A87)/
Assignable button 3 (A94)
3u(review recording) button (A41)/
Assignable button 4 (A94)
4 Lens barrier switch (A39)
5Lenshood(A23)
6 Focus/Zoom ring (A49, 56)
7 CUSTOM (customizable) dial (A93)
8 CUSTOM (customizable) button (A93)
9 Focus/Zoom ring switch (A49, 56)
10 INFRARED switch (A88)
11 DISP (onscreen display) button (A42)/
BATT. INFO (battery information) button (A21)
1
78 9 10 11
23
45 6

13
Namesof Parts
1 Exhaust ventilation outlet (A42)
2 Built-in speaker (A100)
3 SD CARD (open the SD card compartment
cover) switch (A33)
4 Air intake vent (A42)
5 Lens hood release button (A23)
6 Grip belt (A25)
7USBterminal(A90)
8 HDMI OUT terminal (A107)
9 (Ethernet) indicator (A121)
10 (Ethernet) terminal (A121)
11 MIC terminal (A79)
12 mSDI OUT terminal (A107)
2314
5
68
10
11
12
7
9

Namesof Parts
14
1 Joystick (A29)/SET button (A29)
2 MENU button (A29, 36)
3 Remote sensor (A27)
4 AF/MF button (A49)/
Assignable button 1 (A94)
5 POWERED IS button (A61)/
Assignable button 2 (A94)
6 LCD touch screen (A24)
7 Viewfinder (A24)
8 Dioptric adjustment lever (A24)
9 Strap mount (A25)
10 MAGN. (magnification) button (A52)/
Assignable button 5 (A94)
11 REC (start/stop recording video) button (A39)
12 Battery attachment unit (A19)
13 Serial number
14 REMOTE terminal
For connecting the optional RC-V100 Remote
Controller (A89) or commercially available
remote controllers.
15 ×(headphones) terminal (A85, 110)
16 DC IN terminal (A19)
1
7
8
9
10
11
14
15
16
2
3
4
5
612
13

15
Namesof Parts
1 Handle attachment unit (A22)
2 POWER/CHG (battery charging) indicator
(A19)
3 Power switch (A28)
4 Cold shoe/Handle attachment unit (A22)
5 Built-in stereo microphone (A77)
6ACCESSindicator(A39)
7 Zoom rocker (A56)
8 Mode switch (A29)
9 SD card compartment cover (A33)
10 SD card slot 2(A33)
11 SD card slot 3(A33)
1
798
10 11
23 4 5
6

Namesof Parts
16
1 Socket for tripod's anti-rotation pin
2 Tripod socket (A27)
3 BATTERY RELEASE switch (A20)
4Eyecup(A24)
2134

17
Namesof Parts
Handle Unit
1 Cold shoe
2 Handle zoom rocker (A57)
3 REC button's lock (C) lever (A41)
4 REC (start/stop recording video) button (A39)
5–(audio level) dials for CH1 (left) and CH2
(right) (A82)
6 Audio level switches: for CH1 (left) and CH2
(right) (A81)
7 Audio input selection switches: for CH1 (left)
and CH2 (right) (A80)
8 INPUT terminals (XLR): INPUT 1 (right), INPUT 2
(left) (A79)
9Infraredlight(A88)
10 Tally lamp (A40)
11 Audio controls cover (A81)
12 Handle unit front screw (A22)
13 Handle unit rear screws (A22)
14 INPUT 1 (left) / INPUT 2 (right) switches
(audio source selection) (A80)
Microphone Holder Unit (A22, 79)
1 Microphone lock screw
2 Microphone holder
3 Microphone cable clamp
1
7
8 9 10 11 12 13 14
234 5
6
1
2
3

Namesof Parts
18
WL-D89 Wireless Controller
1 START/STOP button (A39)
Same as the REC button on the camcorder,
used to start/stop recording video.
2G(open the index selection screen) button
(A98)
3 MENU button (A36)
4 DISP. (onscreen display) button (A42)
5 SET button
6Ñ(stop) button (A98)
7 PHOTO button (A40)
8 Zoom buttons (A59)
9 Navigation buttons (Í/Î/Ï/Ð)
10 Ò(play/pause) button (A98)
1
7
8
9
10
2
3
4
5
6

2
19
Preparations
Preparing the Power Supply
You can power the camcorder using a battery pack or directly using the supplied AC adapter. If you connect the
AC adapter to the camcorder while a battery pack is attached, the camcorder will draw power from the power
outlet.
Using a Battery Pack
You can power the camcorder using the supplied BP-828 Battery Pack or the optional BP-820 Battery Pack.
Both battery packs are compatible with Intelligent System so you can check the approximate remaining battery
usage time (in minutes) on the screen. For more accurate readings, when using a battery pack for the first time,
charge it fully and then use the camcorder until the battery pack is completely exhausted.
Charging the Battery Pack
Charge battery packs using the supplied CA-946 AC Adapter.
1 Make sure the power switch is set to OFF.
2 Connect the AC adapter's DC plug to the camcorder's DC IN
terminal.
3 Connect the power cord to the AC adapter.
4 Plug the power cord into a power outlet.
5 Attach the battery pack to the camcorder.
• Press the battery pack softly into the battery attachment unit
and slide it forward until it clicks in place.
햲
햴
햳
햵
햶

Preparing the Power Supply
20
6 Charging will start.
• The POWER/CHG indicator will illuminate in red while the
battery is charging. The indicator will go out when charging is
completed. If the POWER/CHG indicator starts flashing, refer to
Troubleshooting (A141).
7 When charging has completed, disconnect the AC adapter in the
order shown in the illustration.
To remove the battery pack
1 Slide the BATTERY RELEASE switch in the direction of the arrow
and hold it pressed down.
2 Slide the battery pack down and then pull it out.
햷
POWER/CHG (battery charging) indicator
햸-1
햸햸-3
햸-4
햸
햲
햳
