CHAPTER 1. GENERAL DESCRIPTION
CONTENTS
1. Product Overview ----------------------------------------------------------------------------------------------------------------------------- 1-1
1-1 Concepts -------------------------------------------------------------------------------------------------------------------------------- 1-1
1-2 Main Features-------------------------------------------------------------------------------------------------------------------------- 1-1
1-2-1 Direct Printer Compatible ------------------------------------------------------------------------------------------------- 1-2
1-2-2 DV Messenger -------------------------------------------------------------------------------------------------------------- 1-2
1-3 Function and Performance List------------------------------------------------------------------------------------------------------ 1-3
1-4 Function and Performance Comparison Chart ------------------------------------------------------------------------------------ 1-4
2. Technical Explanation-----------------------------------------------------------------------------------------------------------------------1-10
2-1 Design ---------------------------------------------------------------------------------------------------------------------------------1-10
2-1-1 Concept ---------------------------------------------------------------------------------------------------------------------1-10
2-1-2 Variation --------------------------------------------------------------------------------------------------------------------1-10
2-2 DMC III Digital Mechanism Chassis----------------------------------------------------------------------------------------------1-11
2-2-1 Improved Quality----------------------------------------------------------------------------------------------------------1-11
2-2-2 Configuration Comparison of DMC II and DMC III ----------------------------------------------------------------1-11
2-2-3 DMC III Slide In/Out Status---------------------------------------------------------------------------------------------1-12
2-3 Direct Print (Canon Camera Direct Correspondence Printer)------------------------------------------------------------------1-13
2-3-1 Direct Print Operation Specifications ----------------------------------------------------------------------------------1-13
2-3-2 Calling Up the Direct Print Setting Screen ----------------------------------------------------------------------------1-13
3. Performance and Functions -----------------------------------------------------------------------------------------------------------------1-14
4. System Diagram (Common to all Models) ------------------------------------------------------------------------------------------------1-24
5. Overview of Viewfinder / LCD Panel Displays ------------------------------------------------------------------------------------------1-25
5-1 Camera Mode -------------------------------------------------------------------------------------------------------------------------1-25
5-2 VCR Mode ----------------------------------------------------------------------------------------------------------------------------1-32
5-3 Card/Camera Mode (ZR70 MC A, ZR65 MC A only) --------------------------------------------------------------------------1-36
5-4 Card Playback Mode (ZR70 MC A, ZR65 MC A only) ------------------------------------------------------------------------1-39
5-5 Menu Display -------------------------------------------------------------------------------------------------------------------------1-41
5-6 Card-Related Screen Displays ------------------------------------------------------------------------------------------------------1-52
5-7 Direct Print Setting Screen----------------------------------------------------------------------------------------------------------1-60
5-8 Print ------------------------------------------------------------------------------------------------------------------------------------1-63
5-9 Warning Displays---------------------------------------------------------------------------------------------------------------------1-64
6. Backing Up Various Data-------------------------------------------------------------------------------------------------------------------1-66
6-1 Backup by Main Power Supply ----------------------------------------------------------------------------------------------------1-66
6-2 Backup by Main Power Supply or Backup Power Supply (Lithium Coin Primary Battery) ------------------------------1-66
6-3 Backup Conditions Related to Switch Operation --------------------------------------------------------------------------------1-67
6-3-1 Turning OFF the Power --------------------------------------------------------------------------------------------------1-67
6-3-2 Switching the Power Switch to a Different Position -----------------------------------------------------------------1-68
6-3-3 Switching Camera Modes/Switching Program AE Modes ----------------------------------------------------------1-69

7. Other Features --------------------------------------------------------------------------------------------------------------------------------1-70
7-1 Green Mode ---------------------------------------------------------------------------------------------------------------------------1-70
7-2 On Screen -----------------------------------------------------------------------------------------------------------------------------1-70
7-3 Headphones and Speaker------------------------------------------------------------------------------------------------------------1-71
7-4 Battery Indicator, Low-Power Warning, and Low-Power Shutoff-------------------------------------------------------------1-71
7-5 System Data Displays----------------------------------------------------------------------------------------------------------------1-71
7-6 Data Code Display -------------------------------------------------------------------------------------------------------------------1-71
7-7 MP Tape Support ---------------------------------------------------------------------------------------------------------------------1-71
7-8 Confirmation Beep -------------------------------------------------------------------------------------------------------------------1-72
7-9 Using Analog Line Recording and DV Recording ------------------------------------------------------------------------------1-73
7-10 Support for Analog Signal I/O Copyright Protection Signals ----------------------------------------------------------------1-74
7-11 Video ID1 Detection/Output Support --------------------------------------------------------------------------------------------1-74
7-12 Audio Dubbing ----------------------------------------------------------------------------------------------------------------------1-75
7-12-1 Tapes to which Audio Dubbing can be Added -----------------------------------------------------------------------1-75
7-12-2 Selecting an Audio Dubbing Signal Input Source-------------------------------------------------------------------1-75
7-12-3 Audio Dubbing Procedure ----------------------------------------------------------------------------------------------1-75
7-12-4 CGMS ----------------------------------------------------------------------------------------------------------------------1-75
7-13 AV Insert (Not available on PAL Models) ---------------------------------------------------------------------------------------1-76
7-13-1 Tapes Allowing AV Insert-----------------------------------------------------------------------------------------------1-76
7-13-2 AV Insert Signal Input Source Selection -----------------------------------------------------------------------------1-76
7-13-3 AV Insert Procedure -----------------------------------------------------------------------------------------------------1-76
7-13-4 CGMS ---------------------------------------------------------------------------------------------------------------------1-76
7-14 Analog/Digital Signal Conversion------------------------------------------------------------------------------------------------1-77
7-14-1 A/D Signal Conversion Pocedure -------------------------------------------------------------------------------------1-77
7-14-2 CGMS ---------------------------------------------------------------------------------------------------------------------1-77
7-15 Multi Switch -------------------------------------------------------------------------------------------------------------------------1-77

ZR70 MC A, ZR65 MC A, ZR60 A
CHAPTER 1. GENERAL DESCRIPTION OF PRODUCT
1-1
1. Product Overview
1-1 Concepts
◆Benefits from efforts to reform the cost structure of the Canon lineup.
◆Deluxe, more stylish design.
◆Retains the superb performance of the ZR50 MC A, ZR45 MC A, ZR47 MC KR, ZR40 A series while
adding multimedia features.
◆More advanced picture quality than the ZR50 MC A, ZR45 MC A, ZR47 MC KR, ZR40 A.
◆Available in three separate models to meet a range of user requirements.
1-2 Main Features
(1) Compact & Stylish
●New Stylish Design
(2) High Performance Lens
●22×optical zoom lens compatible with 1/ 6- inch CCD (ZR70 MC A only)
(3) Excellent Picture Quality
●MACS system for improved picture quality
(4) Multimedia
●Memory card slot, USB terminal (ZR70 MC A, ZR65 MC A only)
●Motion- JPEG (ZR70 MC A only) Camera Direct
●Camera Direct
(5) Advanced Specification
●Advanced accessory shoe (ZR70 MC A only)
●New Digital Feature
(6) All In One
●2.5- inch LCD and CVF, terminals on camera body
Multi Media
Compact & Stylish Camcorder
The ZR70 MC A, ZR65 MC A, ZR60 A is more stylish than the ZR50 MC A, ZR45 MC A,
ZR47 MC KR, ZR40 A and delivers functions to rival multimedia models.

ZR70 MC A, ZR65 MC A, ZR60 A
CHAPTER 1. GENERAL DESCRIPTION OF PRODUCT
1-2
1-2-1 Direct Printer Compatible
Easy to connect and easy to print
◆Printing XGA still images stored on a memory card is simple.
1-2-2 DV Messenger
A peer-to-peer type bidirectional communications software program for linking digital video camcorders and PCs.
◆Allows bidirectional sending of audio or video content and messages (text or images) via the Internet.
◆Basic specifications are compatible with Windows Messenger.
◆Allows control (camera zoom and focus, VCR playback and stop, access to the memory card) of the digital video camcorder
from a remote PC.
Control printer from DVC
ZR70 MC, ZR65 MC
XGA-size (1024 ×768) still images
Direct Printer
Camera Direct Printer
(BJ F890PD)
(BJ 895PD)
(BJ 535PD)
Printer cable
IEEE1394 IEEE1394
Internet

ZR70 MC A, ZR65 MC A, ZR60 A
CHAPTER 1. GENERAL DESCRIPTION OF PRODUCT
1-3
1-3 Function and Performance List
Specifications ZR70 MC A ZR65 MC A ZR60 A
Zoom mag. 22× optical zoom/ 20×optical zoom/ 18×optical zoom/
440×digital zoom*1400×digital zoom*1 360×digital zoom*1
CCD 1/6-inch interlaced CCD (total pixels : 680,000)
Image stabilization Electronic image stabilizer (motion video effective pixels : 340,000)
Monitor 2.5-inch screen, 112,000 pixels LCD monitor
EVF 0.33-inch screen, 113,000 pixel color viewfinder
Analog line input ●●
*2
Memory card function ●(SD memory card, MultiMediaCard) ×
Card Still images Progressive Photo ×
recording (1024×768, 640×480)
Card motion video Motion JPEG + audio ××
recording (monaural)
USB file transfer ●×
USB direct print ●×
IEEE1394 file ●
transfer
IEEE1394 streaming ●
video
USB compatible ●×
Accessory shoe ●(Compatible with ●
advanced accessory shoe)
Auxiliary illumination White LED
function (Super Night mode: tape) ×
(Low light + time: card)
Illuminated keys ●(6 colors) ×
Night mode ●(Super Night mode) ●
Wide attachment lens ●×
BP-512 BP-508
*1 : Tape mode only
*2 : Not applicable to PAL models

ZR70 MC A, ZR65 MC A, ZR60 A
CHAPTER 1. GENERAL DESCRIPTION OF PRODUCT
1-4
1-4 Function and Performance Comparison Chart
Item ZR70 MC A, ZR65 MC A, ZR60 A
Camera
Image sensing Image size Tape 1/6-inch CCD
device Card 1/6-inch
System (filter) Interlacing (color correction filters)
Total pixels 680,000 pixels
Effective pixels Tape 340,000 pixels
Card 447,000 pixels
Lens Optical zoom Tape ZR70 MC A : 22×2.8 - 61.6 mm (approx. 54 - 1,188 mm)
magnification, ZR65 MC A : 20×2.8 - 56 mm (approx. 54 - 1,080 mm)
focal length ZR60 A : 18×2.8 - 50.4 mm (approx. 54 - 972 mm)
(35mm equivalent) Card ZR70 MC A : 22×2.8 - 61.6 mm (approx. 48 - 1,056 mm)
ZR65 MC A : 20×2.8 - 56 mm (approx. 48 - 960 mm)
Digital zoom Tape ZR70 MC A : 88×/440×246.4 mm / 1,232 mm
magnification (equivalent to approx. 4,752 mm / 23,760 mm)
ZR65 MC A : 80×/400×224 mm / 1,120 mm
(equivalent to approx. 4,320 mm / 21,600 mm)
ZR 60 A : 72×/360×201.6 mm / 1,008 mm
(equivalent to approx. 3,888 mm / 19,440 mm)
Card None
System Tape CCD readout
Card -----
F number ZR70 MC A : F1.6 - 3.6, ZR65 MC A : F1.6 - 3.2, ZR60 A : F1.6 - 2.9
Aperture blades 2
Zoom speed Variable
Filter diameter 30.5mm P0.5
Noise reduction Camera Tape Either CCD-NR or Y/C-NR
Card None
Chroma-only, median filter
Recorder C-NR
Minimum Night mode 1.6 lx
illumination Low Light mode 3.4 lx
Auto mode 14 lx
Image Adjustment Tape Electronic
stabilization system Card None
Sensing method Angular velocity sensing
Shooting functions
AE mode Program AE Tape (Full Auto)
(Auto, Sports, Portrait, Spotlight, Surf & Snow, Low Light, Night,
Super Night (ZR70 MC A only))
Card (Full Auto)
(Auto, Sports, Portrait, Spotlight, Surf & Snow, Low Light,
Low Light+ (ZR70 MC A only))
Photometric Center-bottom-weighted average Full Auto, Auto, Sports, Portrait, Low Light, Night, Super Night (ZR70
system MC A only)
Evaluative photometry + 128 segments (Spotlight mode, Surf & Snow mode (Sand & Snow mode))
All area photometry
Magnifica-
tion,focal
length
(35mm
equivalent)
Motion
video
Still
images

ZR70 MC A, ZR65 MC A, ZR60 A
CHAPTER 1. GENERAL DESCRIPTION OF PRODUCT
1-5
Item ZR70 MC A, ZR65 MC A, ZR60 A
Shooting functions
Exposure AE lock ×
adjustment AE shift Supported (after pressing Setting key, adjust using Multi-switch and press
Setting key again) ± 2 steps
(Disabled during Green mode, Spotlight mode, Surf & Snow mode, Night
mode, and Super Night mode)
Exposure correction ×
Gain setting/sensitivity increase Auto
Back light correction ×
Shutter speed High-speed shutter Tape 6 levels
(
1/60, 1/100, 1/250, 1/500, 1/1000, 1/2000, second. (Auto mode ))
Card Switches upper limit to
1/250 second (included Program AE)
Auto Tape 1/60 sec - 1/500 sec.
Card 1/30 sec - 1/250 sec.
Slow shutter 1/15 sec (Low Light mode, Low Light +), 1/8 sec to 1/60 sec (Night
mode, Super Night mode)
Aperture value Auto iris
Image quality Color gain adjustment ×
adjustment Hue adjustment ×
(custom preset) Sharpness adjustment ×
Setup adjustment ×
White Balance Auto ●
Preset Outdoor, Indoor
System TTL, 128 segments
Focus Mode AF/MF, forced infinity
Manual focus Multi-switch operation
16:9 Recording system Tape Vertical Stretching
Card ×
Area marker display ×
Digital fade Tape Motion video Auto Fade, Wipe, Corner Wipe, Jump, Flip, Puzzle, Zigzag, Beam, Tide
(executed by pressing the Start/Stop button.)
Still Image ×
Card Motion video ×
Still Image ×
Digital effect Tape
Motion video/still Image Art, Black & White, Sepia, Mosaic, Ball, Cube, Wave, Color Mask, Mirror
Card Motion video/still Image Black & White
Card mix Tape Motion video/still Image Card Lumi key, Card Chroma key, Camera Chroma key, Animation
Card Motion video/still Image ×
Multi-screen Tape Motion video/still Image Supported (disabled in Night mode and Super Night mode)
Card Motion video/still Image ×
Capture speed 1/60 sec. Manual, Fast (every 4th field), Normal (every 6th field),
Shutter speed Slow (every 8 fields)
1/15 sec. Manual, Fast (every 4 fields), Normal (every 8 fields),
Shutter speed Slow (every 12 fields)
Motion video Mode Tape Normal
shooting Card 320 × 240 pixels (continuous, approx. 10 seconds), 160 × 120 pixels
(ZR70 MC A only) (continuous, approx. 30 seconds)

ZR70 MC A, ZR65 MC A, ZR60 A
CHAPTER 1. GENERAL DESCRIPTION OF PRODUCT
1-6
Item ZR70 MC A, ZR65 MC A, ZR60 A
Shooting functions
Still image Mode Tape Normal (field)
Card Progressive (iris shutter) (disabled in Night mode)
Single image Tape 6.5 sec.
recording time Card ×
Continuous Tape ×
shooting Card ×
Photo button Form Still image only button
Half depressed Supported (recording standby only)
Still image confirmation Only with card mounted
Strobe support (models) ×
Recorded image Frame image (video output is field image)
Frame processing Pseudo frame (Low Light mode, Night mode, Super Night (Slow) mode)
Negative-positive reversal ×
Video light ×(For only ZR70 MC A, white LED is provided (turned ON in
super-night mode, low-light mode))
Zebra pattern ×
Color bar display ×
Selftimer 10 sec./remote control: 2 sec.
Interval timer ×
Clear scan ×
Recorded image size/file format VGA: 640(H) × 480 (V), XGA: 1024(H) × 768(V)/JPEG (ZR70 MC A,
ZR65 MC A only)
Memory card SD memory card, MultiMediaCard
REC search ●
REC review ●
Standby switch ×
Power save (after 5 minutes in Recording pause) Power shutoff
Displayed text recording ×
Audio 16-bit 2-channel (48KHz)
12-bit 4-channel (32 kHz) Simultaneous 4-channel recording not possible
Wind screen ●ON/OFF switch (built-in microphone only)
EVF Size 0.33-inch (TFT color RGB delta arrangement)
Pixels 113,000
Brightness adjustment ×
Color adjustment ×
Movable ×
Monitor LCD Size 2.5-inch
Pixels 112,000
Brightness adjustment ●
Movable ●Supports mirror shooting

ZR70 MC A, ZR65 MC A, ZR60 A
CHAPTER 1. GENERAL DESCRIPTION OF PRODUCT
1-7
Item ZR70 MC A, ZR65 MC A, ZR60 A
VCR
Playback Frame playback Forward/Reverse
system Slow playback Forward/Reverse
2X SP playback Forward/Reverse
1X SP playback Forward/Reverse
Cue/review 9.5X speed
Search Photo search ●
Date search ●
Index search ×
Special playback Playback zoom (2X zoom) ●(Tape playback or card still image playback)
effects D. effects Tape Art, Black & White, Sepia, Mosaic, Ball, Cube, Wave, Color Mask, Mirror
Card ×
D. fade Tape Auto fade, Wipe, Corner wipe, Jump, Flip, Puzzle, Zig Zag, Beam, Tide
Card ×
Multi screen 4/9/16 screen (tape only)
Data code display Time and Date display
Card Slide show ●(ZR70 MC A, ZR65 MC A only)
Index playback ●(ZR70 MC A, ZR65 MC A only)
(6-screen playback)
Card fast forward/rewind Card jump (ZR70 MC A, ZR65 MC A only)
Audio dubbing ●
AV insert Digital ●
Analog ●
Zero set memory ●
Edit function Simple editing ×
Special effects ×
