E
Advanced User Guide
This manual is for the EOS M6 Mark II with rmware version 1.1.0 or later
installed.

2
Introduction
Before Starting to Shoot, Be Sure to Read the Following
To avoid shooting problems and accidents, rst read the “Handling
Precautions” (=31) and “Safety Instructions” (=28). Also, read this
manual carefully to ensure that you use the camera correctly.
Refer to This Manual while Using the Camera to Further
Familiarize Yourself with the Camera
While reading this manual, take a few test shots and see how they come
out. You can then better understand the camera. Be sure to store this
manual safely, too, so that you can refer to it again when necessary.
Testing the Camera Before Use and Liability
After shooting, play images back and check whether they have been
properly recorded. If the camera or memory card is faulty and the images
cannot be recorded or downloaded to a computer, Canon cannot be held
liable for any loss or inconvenience caused.
Copyrights
Copyright laws in some countries prohibit the unauthorized use of images
recorded with the camera (or music/images with music transferred to the
memory card) for purposes other than personal enjoyment. Also be aware
that certain public performances, exhibitions, etc. may prohibit photography
even for private enjoyment.

3
Item Check List
Before starting, check that all the following items are included with your
camera. If anything is missing, contact your dealer.
Camera
(with body cap)
Battery Pack LP-E17
(with protective cover) Battery Charger
LC-E17/LC-E17E
Strap
zThe camera does not come with a memory card (=11), interface cable, or HDMI
cable.
zFor details on the Advanced User Guide and Instruction Manuals, see “Instruction
Manuals” (=4).
zIf you purchased a Lens Kit, check that the lenses are included.
zBe careful not to lose any of the above items.
zWhen you need Lens Instruction Manuals, download them from the Canon
website (=4).
zThe Lens Instruction Manuals (PDF les) are for lenses sold individually. Note
that when purchasing the Lens Kit, some of the accessories included with the
lens may not match those listed in the Lens Instruction Manual.

4
Instruction Manuals
The Instruction Manual included with the camera provides
basic instructions for the camera and Wi-Fi functions.
The Advanced User Guide (this PDF le), which provides
complete instructions, can be downloaded from the Canon
website to a computer or other device.
Downloading the Advanced User Guide/Instruction Manuals
The Advanced User Guide and Instruction Manuals for lenses and software
(PDF les) can be downloaded from the Canon website to a computer or
other device.
zDownload site
Advanced User Guide/Supplemental Information
www.canon.com/icpd
Lens Instruction Manual
www.canon.com/icpd
Software Instruction Manual
www.canon.com/icpd
zTo view the PDF les, an Adobe PDF viewing software such as Adobe
Acrobat Reader DC (most recent version recommended) is required.
zAdobe Acrobat Reader DC can be downloaded for free from the Internet.
zDouble-click the downloaded PDF le to open it.
zTo learn how to use PDF viewing software, refer to the software’s Help section
or the like.

5
Instruction Manuals
Downloading the Advanced User Guide/Instruction Manuals
Using QR Code
The Advanced User Guide and Instruction Manuals for lenses and software
(PDF les) can be downloaded to a smartphone or tablet using the QR
code.
www.canon.com/icpd
zA software app is required to read the QR code.
zSelect your country or region of residence, then download the Advanced User
Guide/Instruction Manuals.
zSelect [5: Manual/software URL] to display the QR code on the camera
screen.

6
Quick Start Guide
1Insert the battery (=44).
zUpon purchase, charge the battery
to start using (=42).
2Insert the card (=44).
zInsert the card with the label facing
the front of the camera.
3Attach the lens (=51).
zAlign the white mount index on the
lens with the white mount index on
the camera to attach the lens.
zRemove the lens cap.
4
(1)
(2)
Prepare to shoot.
zPress (1) as you turn (2) slightly,
and then release (1).
zTurn (2) a little more until it clicks.

7
Quick Start Guide
5Set the power switch to <1>
(=49).
6Set the focus mode switch to
<AF>.
z<AF> stands for autofocus.
z<MF> stands for manual focus.
Autofocus will not operate.
7Set the Mode dial to <A>
(=72).
zAll the necessary camera settings
will be set automatically.
8Focus on the subject (=60).
z[p] (an AF point) appears over any
face detected.
zPress the shutter button halfway,
and the camera will focus on the
subject.

8
Quick Start Guide
9Take the picture (=60).
zPress the shutter button completely
to take the picture.
10
Review the picture.
zThe image just captured will be
displayed for approx. 2 sec. on the
screen.
zTo display the image again, press
the <x> button (=306).
zTo view the images captured so far, see “Image Playback” (=306).
zTo delete images, see “Erase Images” (=329).

9
About This Manual
Icons in this Manual
<6>: Indicates the Main dial.
<5>: Indicates the Quick control dial.
<W> <X> <Y> <Z>: Indicates the corresponding direction on the <V>
cross keys.
<5>: Indicates the control dial.
<Q> <0>: Indicates the Quick Control/Setting button.
*: Indicates the duration (in * seconds) of the
operation for the button you pressed, as timed after
you release the button.
y In addition to the above, the icons and symbols used on the camera’s buttons and
displayed on the screen are also used in this manual when discussing relevant
operations and functionality.
M(in page titles) : Functions only available in Creative Zone modes
(<t>, <d>, <s>, <f>, or <a> mode) or for
movies recorded with manual exposure.
=*** : Reference page numbers for more information.
: Warning to prevent shooting problems.
: Supplemental information.
: Tips or advice for better shooting.
: Troubleshooting advice.

10
About This Manual
Basic Assumptions for Operational Instructions, Sample
Photos
zBefore following any instructions, make sure the power switch is set to
<1> (=49).
zIt is assumed that all the menu settings and Custom Functions are set to
their defaults.
zThe illustrations in this manual show the camera attached with the
EF-M15-45mm f/3.5-6.3 IS STM lens as an example.
zThe sample photos displayed on the camera and used in this manual are
for instructional purposes only.
zIn references to using EF or EF-S lenses, it is assumed that a mount
adapter is used.

11
Compatible Cards
The following cards can be used with the camera regardless of capacity.
If the card is new or was previously formatted (initialized) by another
camera or computer, format the card with this camera (=492).
zSD/SDHC/SDXC memory cards
UHS-II and UHS-I cards supported.
Cards that Can Record Movies
When recording movies, use a high-capacity card with ample performance
(fast enough writing and reading speeds) for the movie recording size. For
details, see =581.
In this manual, “card” refers to SD memory cards, SDHC memory
cards, and SDXC memory cards.
* The camera does not come with a card for recording photos/
movies. Please purchase it separately.

12
Chapters
Introduction 2
Preparation and Basic Operations 41
Basic Zone 71
Creative Zone 105
Shooting 117
Flash Photography 285
Playback 303
Wireless Features 377
Set-up 483
Custom Functions / My Menu 527
Reference 551

13
Introduction 2
Item Check List ......................................................................................3
Instruction Manuals................................................................................4
Quick Start Guide...................................................................................6
About This Manual .................................................................................9
Compatible Cards ................................................................................11
Chapters...............................................................................................12
Contents...............................................................................................13
Index to Features .................................................................................23
Safety Instructions ...............................................................................28
Handling Precautions...........................................................................31
Part Names ..........................................................................................34
Preparation and Basic Operations 41
Charging the Battery ............................................................................42
Inserting/Removing the Battery and Card............................................44
Using the Screen .................................................................................48
Turning on the Power...........................................................................49
Attaching and Detaching a Lens ..........................................................51
Attaching and Detaching EF/EF-S Lenses ..........................................53
Using an Electronic Viewnder (Sold Separately)................................56
Basic Operations..................................................................................59
Menu Operations and Settings ............................................................64
Touch-Screen Operation ......................................................................68
Quick Control .......................................................................................69
Contents

14
Contents
Basic Zone 71
Scene Intelligent Auto/Hybrid Auto (Fully Automatic)...........................72
Special Scene Mode (SCN) .................................................................80
Self Portrait Mode ................................................................................82
Portrait Mode........................................................................................83
Smooth Skin Mode...............................................................................84
Landscape Mode .................................................................................85
Sports Mode.........................................................................................86
Panning Mode......................................................................................87
Close-up Mode.....................................................................................89
Food Mode...........................................................................................90
Night Portrait Mode ..............................................................................91
Handheld Night Scene Mode ...............................................................92
HDR Backlight Control Mode ...............................................................93
Cautions for the <SCN> Modes ...........................................................94
Creative Filters Mode...........................................................................98
Creative Zone 105
Program AE Mode (P)........................................................................106
Shutter-priority AE Mode (Tv).............................................................108
Aperture-priority AE Mode (Av) ..........................................................110
Manual Exposure Mode (M)...............................................................112
Flexible-priority AE (Fv)......................................................................114

15
Contents
Shooting 117
Still Photo Shooting 118
Tab Menus: Still Photo Shooting ........................................................119
Image Quality.....................................................................................124
Still Image Aspect Ratio .....................................................................127
Image Review Time............................................................................129
Lens Aberration Correction ................................................................130
Drive Mode.........................................................................................135
Self-Timer...........................................................................................137
RAW Burst Mode ...............................................................................139
Exposure Compensation....................................................................142
Auto Exposure Bracketing .................................................................143
ISO Speed Settings ...........................................................................145
Auto Lighting Optimizer......................................................................151
Highlight Tone Priority ........................................................................152
Metering Mode ...................................................................................153
Metering Timer ...................................................................................155
Exposure Simulation ..........................................................................156
White Balance....................................................................................157
White Balance Correction/Bracketing ................................................162
Color Space .......................................................................................164
Picture Style Selection .......................................................................165
Picture Style Customization ...............................................................168
Picture Style Registration...................................................................171
Long Exposure Noise Reduction .......................................................173

16
Contents
High ISO Speed Noise Reduction......................................................174
Dust Delete Data Acquisition .............................................................176
HDR Mode .........................................................................................178
Focus Bracketing ...............................................................................182
Touch Shutter.....................................................................................186
Shutter Release Method ....................................................................188
Interval Timer .....................................................................................189
Long (Bulb) Exposures ......................................................................192
Anti-icker Shooting ...........................................................................195
AF Operation......................................................................................197
AF Method..........................................................................................200
Eye Detection AF ...............................................................................211
Continuous AF ...................................................................................213
Touch & Drag AF................................................................................214
Manually Focusing with a Lens after AF ............................................216
AF-Assist Beam Firing .......................................................................217
Image Stabilization.............................................................................218
Exposure Lock (AE Lock) ..................................................................219
Manual Focus.....................................................................................220
MF Peaking (Outline Emphasis) ........................................................222
Focus Mode Switching.......................................................................223
Type of Digest Movie .........................................................................224
Remote Control Shooting...................................................................225
General Still Photo Shooting Cautions...............................................226

17
Contents
Movie Recording 229
Tab Menus: Movie Recording ............................................................230
Movie Mode........................................................................................234
HDR Movie Mode...............................................................................241
Movie Recording Quality....................................................................243
Sound Recording ...............................................................................250
Time-lapse Movies .............................................................................252
Video Snapshots................................................................................263
Miniature Effect Movie .......................................................................268
Movie Digital IS ..................................................................................270
Auto Level for Movies ........................................................................272
Movie Servo AF..................................................................................273
Other Menu Functions .......................................................................278
General Movie Recording Cautions ...................................................282
Flash Photography 285
Shooting With the Built-in Flash.........................................................286
Flash Function Settings .....................................................................291
Shooting With External Speedlites.....................................................302
Playback 303
Tab Menus: Playback.........................................................................304
Image Playback .................................................................................306
Magnied Image Display....................................................................309
Index Display (Multiple-Image Display)..............................................310

18
Contents
Movie Playback..................................................................................311
Editing a Movie’s First and Last Scenes ............................................315
Frame Extraction................................................................................317
Digest Movie Editing ..........................................................................319
Still Photo Extraction from RAW Burst Images ..................................321
Playback on a TV Set.........................................................................323
Protect Images...................................................................................325
Rotate Images....................................................................................328
Erase Images.....................................................................................329
Print Ordering.....................................................................................333
Photobook Set-up ..............................................................................337
Creative Filters...................................................................................340
RAW Image Processing .....................................................................343
Creative Assist ...................................................................................349
Quick Control RAW Processing .........................................................351
Red-Eye Correction............................................................................352
Create Album .....................................................................................353
Cropping.............................................................................................356
Resizing .............................................................................................358
Rating.................................................................................................360
Slideshows.........................................................................................363
Set Image Search Conditions ............................................................365
Main Dial Browsing ............................................................................367
Playback Information Display.............................................................369
Highlight Alert.....................................................................................371
AF Point Display.................................................................................372

19
Contents
Playback Grid.....................................................................................373
View from Last Seen..........................................................................374
Magnication (Approx.) ......................................................................375
Wireless Features 377
Tab Menus: Wireless Tab...................................................................378
Selection of Wi-Fi/Bluetooth Connection ...........................................379
Connecting to a Smartphone .............................................................381
Connecting to a Computer via Wi-Fi ..................................................410
Connecting to a Printer via Wi-Fi .......................................................418
Sending Images to a Web Service.....................................................428
Wi-Fi Connection via Access Points ..................................................443
Connecting to a Wireless Remote Control.........................................448
Reconnecting via Wi-Fi ......................................................................451
Registering Multiple Connection Settings ..........................................453
Wi-Fi Settings.....................................................................................454
Bluetooth Settings..............................................................................455
Changing the Nickname.....................................................................456
Geotagging Images with GPS Information from Other Devices.........457
Changing or Deleting Connection Settings ........................................460
Clearing Wireless Communication Settings to Default ......................462
View Info Screen................................................................................463
Virtual Keyboard Operations..............................................................464
Responding to Error Messages .........................................................465
Wireless Communication Function Notes ..........................................476

20
Contents
Security ..............................................................................................478
Checking Network Settings................................................................479
Wireless Communication Status ........................................................480
Set-up 483
Tab Menus: Set-up.............................................................................484
Select Folder......................................................................................486
File Numbering...................................................................................488
Auto Rotate ........................................................................................491
Format Card.......................................................................................492
Mode Guide .......................................................................................494
Feature Guide ....................................................................................495
Eco Mode...........................................................................................496
Power Saving.....................................................................................497
Display Brightness .............................................................................498
Date/Time/Zone .................................................................................499
Language ...........................................................................................502
Focus Mode Switch (AF/MF)..............................................................503
Video System.....................................................................................504
Sensor Cleaning ................................................................................505
Touch Control.....................................................................................509
Beeping..............................................................................................510
HDMI Resolution................................................................................511
HDMI HDR Output .............................................................................512
Shutter Button Function for Movies....................................................513
Shooting Information Display .............................................................514
