Canon PowerShot SD430 DIGITAL ELPH WIRELESS Service manual

IMPORTANT!
You must install the software before connecting the
camera to the computer.
Register the target
device with the camera.
Connect Wirelessly.
CDP-E054-010 © 2006 CANON INC.
Start by installing the software.
Software supplied with the camera
ImageBrowser Wireless Updater
Camera firmware
Download
Download
Wireless Settings Guide
(For Mac OS X v10.4 Users)
[Camera

Computer]

Table of contents
2
Table of contents
Wireless Network Settings for the Computer and Camera 3
Procedures ..........................................................................................3
Preparation—Before You Use the Wireless Connection .................4
Registering the Target Device with the Camera ..............................9
Connecting .......................................................................................17
Disconnecting ...................................................................................19
Deleting a Target Device .................................................................20
Using the Wireless Networking Function 21
Actions Possible with the Camera Connected to a Computer ......21
Wireless Connection Troubleshooting 22
Before Contacting Us .......................................................................22
Firewalls ............................................................................................23
Trademark Acknowledgments
• Macintosh and Mac OS are trademarks of Apple Computer Inc., registered in the United
States and other countries.
•Wi-Fi
®and the Wi-Fi logo are registered trademarks of the Wi-Fi Alliance; and Wi-Fi
CERTIFIED., WPA. and the Wi-Fi CERTIFIED logo are trademarks of the Wi-Fi Alliance.
Copyright © 2006 Canon Inc. All rights reserved.
Disclaimer
• While every effort has been made to ensure that the information contained in this guide is
accurate and complete, no liability can be accepted for any errors or omissions. Canon
reserves the right to change the specifications of the hardware and software described
herein at any time without prior notice.
• No part of this guide may be reproduced, transmitted, transcribed, stored in a retrieval
system, or translated into any language in any form, by any means, without the prior
written permission of Canon.
• Canon makes no warranties for damages resulting from corrupted or lost data due to a
mistaken operation or malfunction of the camera, the software, SD memory cards (SD
cards), personal computers, peripheral devices, or use of non-Canon SD cards.

3
Wireless Network Settings for the
Computer and Camera
This chapter explains how to configure the wireless networking function to connect the camera
to the computer over a wireless connection.
Procedures
Follow the procedures below to configure the wireless settings.
Preparation
Check Your Computer's Operating Environment
Confirm that your computer's operating system is Mac OS X v10.4 or later.

Check Your Wireless Connection Configuration
In order to ensure that the registration procedures for the connection proceed smoothly,
confirm the network configuration for your computer and prepare it as necessary.

Check If Required Software Is Installed
Confirm that the software required for a wireless connection has been installed.

Registering the Target Device
Register the Target Device with the Camera
Connect the camera to the computer with the interface
cable and register the target device (your computer)
with the camera.

Software supplied with
the camera
Downloaded
ImageBrowser Wireless
Updater
Downloaded camera
firmware

Wireless Network Settings for the Computer and Camera
4
Preparation
—
Before You Use the Wireless Connection
This section explains the preparations to make before you use the wireless connection.
Start by checking your computer's operating environment.
Checking Your Computer's Operating Environment
Operating System
The wireless feature can only used with Macintosh computers that come with Mac OS X v10.4
or later pre-installed. Please note it cannot be used with Macintosh computers equipped with
Intel processors.
Environment Required for the Wireless Networking Function
Either of the following two configurations is required to use the wireless feature.
• The computer has built-in wireless networking (e.g. built-in AirPort networking, built-in
wireless LAN card, such as an AirPort card)
• A wireless LAN router, such as an AirPort Base Station, is connected to the computer
Using the Wireless Networking Function
Use the Wireless Networking Function
Connect the camera and computer over the wireless
connection and download camera images to the
computer or print them. See Actions Possible with the
Camera Connected to a Computer (p. 21) for the
features that can be used over a wireless connection.
The procedures in the "Preparation" and "Registering the Target Device" sections
are performed the first time you make a wireless connection. Thereafter, only the
procedures in the "Using the Wireless Networking Function" section are required.
The firewall settings in your security software may prevent the camera and
computer from connecting. See Firewalls (p. 23).

5
Checking Your Wireless Connection Configuration
The method for connecting the camera to the computer will vary according to your computer's
wireless connection configuration. See the following diagram and confirm that your
configuration uses connection method or .
Wireless Network
Already in Use
1:1 Direct
Connection
between Camera
and Computer

Add the camera to the wireless
network in use.
Create a new network for the camera
and computer.
Check the settings for your wireless
network and note them in the
checklist (p. 6).
Connecting a camera and computer
via an access point, such as a wireless
LAN router, is called an
"infrastructure connection".
Connecting a camera and computer
directly in a 1:1 connection is called
an "ad hoc connection".
•A router is a device for connecting several computers or other equipment in a
network (LAN). A router with built-in wireless networking is called a wireless LAN
router.
• See your computer's user guide if you are uncertain about its operating system.
A B
A
B
Existing Network
Wireless LAN Router

Wireless Network Settings for the Computer and Camera
6
Checking Your Wireless Network Configuration (Configuration Only)
If you are already using a wireless network, check the following settings and note them in the
checklist.
If you are using an AirPort network, you can check each setting in the AirPort Admin Utility.
• If you are configuring a network managed by a system administrator, obtain
the network settings information from the network administrator.
• An encryption key is an important asset. Manage it securely so that no one
else can learn what it is.
• See the user guide for your wireless LAN router for details on checking the
settings.
Checklist
• Network Name (SSID, ESSID) Please enter the name assigned to
the wireless network you are using.
• Network Authentication/Data
Encryption (Encryption Method,
Encryption Mode)
 Invalid
 WEP (Open)
 WEP (Shared Key)
 WPA-PSK-TKIP
 WPA-PSK-AES
"Network Authentication/Data
Encryption" is the encryption method
for data during a wireless
transmission.
Enter a check mark beside the
method used by your wireless
network.
If you are using an AirPort network,
check the wireless utility settings and
select the following.
•[None] or [Do not use] [Disabled]
•[128 Bit WEP] [WEP (Open)]
•[40 Bit WEP] [WEP (Open)]
•[WPA Personal] [WPA-PSK-TKIP]
If a setting other than the above is
selected, the camera will not be able
to connect to the wireless network.
Reset it with one of the options
above.
• Encryption Key (Network Key) The Encryption Key is the key used to
encrypt data during a wireless
transmission. Confirm the key used in
your wireless network. (Be extremely
careful in handling it since it is vital
information.)
If you are using an AirPort network,
enter the password you set for the
network as the Encryption Key.
A

7
Check If Required Software Is Installed
Before configuring the wireless settings, confirm that the following software has been
installed.
Checking if the Software Supplied with the Camera Has Been Installed
Check to see if the software supplied with the camera has been installed. If it is not installed,
use the supplied Canon Digital Camera Solution Disk and install it according to the procedures
in Using the Software on the Macintosh Platform—Preparations (p. 47) in the Software &
Wireless Guide.
Installing the ImageBrowser Wireless Updater
Download the ImageBrowser Wireless Updater from the same website you downloaded this
guide from.
1Confirm that ImageBrowser is installed on the computer.
ImageBrowser is normally installed if you have installed the software supplied with your
camera. If it is not installed, install it according to the procedures in Using the Software on
the Macintosh Platform—Preparations (p. 47) in the Software & Wireless Guide.
• Key Index (Transmit Key)
 1
 2
 3
 4
The Key Index is a key that is set
when the Network Authentication/
Data Encryption setting is WEP. Up to
four keys can be set for one access
point. Please place a check mark
beside the key index used by your
wireless network.
If you are using an AirPort network,
select [1].
If you are using an AirPort network:
You can check the password by selecting your base station in the AirPort
Admin Utility and clicking the [key] icon in the window.
Download

Wireless Network Settings for the Computer and Camera
8
2Double-click the downloaded file.
The file will decompress and the [IB56wOSX] icon will appear in the Finder.
3Double-click the [IB56wOSX] icon, followed by the [Update Installer] icon.
4Follow the onscreen instructions to install the software.
It will update ImageBrowser as well as install software for connecting via wireless
networks.
Updating the Camera Firmware
Update the camera's firmware (software inside the camera) to support wireless networking
with Mac OS X v10.4. Download the firmware upgrade from the same website you
downloaded this guide from. Also refer to the website for instructions on updating the
camera's firmware.
Uninstalling the Software
• If you should no longer require the wireless networking software, you can uninstall it by
opening the [Applications] folder, followed by the [Canon Utilities] folder,
[CameraWindow] folder and [Wireless] folder, and double-clicking the [UnInstall] folder
within.
• To uninstall the software supplied with the camera, drag and drop the folder for each
program into the trash and empty the trash.
Download

9
Registering the Target Device with the Camera
Attach the camera to the computer using the interface cable and register the target device
(computer to be connected wirelessly) with the camera. Register the target device using the
Camera Wireless Setup program (a wireless configuration utility). This step is only required the
first time you register a target device.
1 If your wireless network is already in use, confirm that the computer and router are
correctly connected and that the router's wireless settings are correctly configured.
If there is a 1:1 direct connection between the camera and computer, confirm
that the computer's wireless networking function is working.
2Attach the supplied interface cable to the
computer's USB port and the camera's
DIGITAL terminal.
3Turn on the camera and set it to the playback
mode.
The camera's (Print/Share) button will light
blue. It will not light up if the memory card in the
camera does not contain any images.
Before you register the target device, update the camera firmware (software
inside the camera) to the latest version. Download the firmware upgrade
from the same website you downloaded this guide from. Also refer to the
website for instructions on updating the camera's firmware.
• The camera cannot connect wirelessly to computers that have not been
registered as target devices.
• The camera can register up to 7 devices.
Wireless Network Already in Use
1:1 Direct Connection between Camera and Computer
For Step 9 onward go to Wireless Network Already in Use (p. 12) or 1:1 Direct
Connection between Camera and Computer (p. 14).
A
B
A B
A
B
Power Button
Playback
Mode

Wireless Network Settings for the Computer and Camera
10
The Camera Control Window will appear on the
computer screen. Leave this window as is without
closing it.
4Press the camera's MENU button.
5Select the [ (Wireless)] menu in the
camera's LCD monitor and choose [Reg.
Target Device].
6Press the FUNC./SET button.
"Input data on PC" will appear on the camera's
LCD monitor.
MENU
Button
FUNC./SET
Button

11
The Camera Wireless Setup utility, as shown to
the right, will start up. Set the wireless settings in
this window.
7Click [Next].
8Select [Simple Mode] and click [Next].
We recommend you use the Simple Mode for
most purposes.
• We recommend you use the [Advanced Mode] if the following
conditions apply to your computer's wireless configuration.
• You are configuring an ad hoc network.
• You are performing the settings within a network with a system
administrator.
• The computer and wireless LAN router are connected by a cable.
• A fixed IP address is assigned. (IP address: an identifying number
assigned to a computer or other device on a network)
• Wireless LAN router is not equipped with a DHCP server function.
(DHCP server function: short for dynamic host configuration protocol
server function, which assigns dynamic IP addresses to devices in a
network)
• You can change the registered information in the camera if you place a
check mark beside [Change registered information in camera] and click
[Next].
If you are already using a wireless network, please proceed to Step 9 in the Wireless
Network Already In Use section (p. 12).
If you are using a 1:1 direct connection between the camera and computer, skip to
Step 9 in the 1:1 Direct Connection between Camera and Computer section (p. 14).
A
B

Wireless Network Settings for the Computer and Camera
12
9Select [I am using an access point] and click
[Next].
This window will not appear if the wireless
configuration information is automatically
detected. Proceed to the next step.
10 Enter the settings information from the
checklist (p. 6) and click [Next].
Some of the wireless configuration information
may already be entered if it was automatically
detected. Make sure the information is the same
as entered in the checklist, and enter the
information required for the remaining settings
categories.
11 Confirm the displayed information and click
[Next].
The registration name you enter here will display
in the camera's [Target Device] category.
Wireless Network Already in Use
Perform steps 1-8 (pp. 9-11) before proceeding below.
If you do not understand the terminology in the window, place the mouse cursor
over it. A brief explanation will display at the bottom of the window.
If the "Insufficient space in camera" message appears, delete target devices that are
not needed and proceed to the next step.
A

13
12 After confirming the displayed settings, click
[Print] to print out the configuration
contents.
This information will be necessary if you cannot
make a connection or later change the settings.
Store this information in a secure place because it
is important information about your computer.
13 After the printing finishes, click [Next].
14 Click [Finish].
15 When [Registration completed] appears on
the LCD monitor, press the FUNC./SET button.
This registers the network configuration on the
camera.
16 Press the camera's MENU.
The camera will return to the playback mode.
17 Turn off the camera.
The Camera Control Window on the computer screen will close.
18 Detach the interface cable and connect wirelessly.
Please use the procedures in Connecting to test the correction operation of the wireless
connection (p. 17).

Wireless Network Settings for the Computer and Camera
14
9Select [I do not have an access point, but my
computer is compatible with wireless
networks] and click [Next].
This window will not appear if the wireless
configuration information is automatically
detected. Proceed to the next step.
10 Confirm the configuration settings and click
[Next].
The configuration settings will automatically take
effect and appear in the window. These settings
generally do not require adjusting.
11 Confirm the displayed information and click
[Next].
The registration name you entered here will
display in the camera's [Target Device] category.
1:1 Direct Connection between Camera and Computer
Perform steps 1-8 (pp. 9-11) before proceeding below.
If you do not understand the terminology in the window, place the mouse cursor
over it. A brief explanation will display at the bottom of the window.
If the "Insufficient space in camera" message appears, delete target devices that are
not needed and proceed to the next step.
B

15
12 After confirming the displayed settings, click
[Print] to print out the configuration
contents.
This information will be necessary if you cannot
make a connection or later change the settings.
Store this information in a secure place because it
is important information about your computer.
13 After the printing finishes, click [Next].
14 Change the computer settings to match the
displayed settings content.
Read the user guide for your computer for details
on changing the settings.
See the checklist (p. 6) for an explanation of the
settings.
This screen will not display if the wireless settings
information is automatically detected. Proceed to
Step 16.
15 Click [OK].
16 Click [Finish].

Wireless Network Settings for the Computer and Camera
16
17 When [Registration completed] appears on
the LCD monitor, press the FUNC./SET button.
This registers the network configuration on the
camera.
18 Press the camera's MENU button.
The camera will return to the playback mode.
19 Turn off the camera.
The Camera Control Window on the computer screen will close.
20 Detach the interface cable and connect wirelessly.
Please use the procedures in Connecting to test the correction operation of the wireless
connection (p. 17).

17
Connecting
Connect to the computer using the camera controls.
You will not require an interface cable because you are connecting wirelessly.
Connect after you have registered the target device (computer) according to the procedures in
Registering the Target Device with the Camera (p. 9).
1Turn on the camera and set it to the playback
or shooting modes.
Playback Mode
After connecting, you can download camera
images to the computer and print them on a
printer.
Shooting Modes
After connecting, you can transmit a recorded
image immediately to the computer.
See Actions Possible with the Camera Connected to a Computer (p. 21) for details.
2Press the button.
A menu for selecting the target device will appear
on the LCD monitor.
The button will light blue.
• The wireless networking function can be operated up to approximately 30
meters away with a direct line of sight to the target device. However, this
distance will depend upon the operating conditions.
• You cannot have more than one camera connected at a time.
•You cannot connect to multiple target devices at once. If you are already
connected to one device and attempt to connect another, the current
connection will close and the camera will begin to connect to the new target
device.
• Always use the camera to disconnect from a wireless connection (p. 19).
•The movie mode cannot be used over a wireless connection.
• You can switch between the playback and shooting modes during a
wireless connection.
Alternatively, you can display the menu for selecting the target device by
pressing the MENU button, selecting the [ (Wireless)] menu followed
by the [Connect/Disconnect] option, and pressing the FUNC./SET button.
Power Button
Playback
Mode or
Shooting
Modes
Button
FUNC./SET
Button
MENU
Button

Wireless Network Settings for the Computer and Camera
18
3After you have selected a target device, select
[Connect].
The name registered for the target device in Step
11 (p. 12, 14) in Registering the Target Device
with the Camera will appear in the [Target Device]
category.
4Press the button (or FUNC./SET button).
The wireless lamp and button will blink
while the two devices connect.
The LCD monitor will display an indicator that
shows the connection status.
Wait until the wireless lamp stops blinking and
lights steadily and an antenna showing the signal
strength (0-3 bars) appears on the LCD monitor.
• The connection may take some time to establish if there are many images in
the camera.
• Do not perform the following procedures on the computer during a wireless
connection:
* Shut down, log out or restart the computer system
* Close the Camera Control Window
Before attempting any of the above procedures, first use the camera to
disconnect from the wireless connection (p. 19).
• Unless you change the target device, you can connect later simply by
pressing the button in Step 2 for one second.
• If an error message displays on the camera's LCD monitor, see Connection
Difficulty in the Software & Wireless Guide (p. 100).
Button
FUNC./SET
Button
In Playback Mode

19
Disconnecting
Disconnect the camera from the computer using camera commands.
1Set the camera to the playback or shooting modes.
2Press the MENU button.
3In the [ (Wireless)] menu, select [Connect/
Disconnect] and press the FUNC./SET button.
4After you select the target device, select
[Disconnect].
5Press the FUNC./SET button.
This will disconnect the camera and computer.
The wireless lamp will turn off when the camera is
disconnected from the computer.

Wireless Network Settings for the Computer and Camera
20
Deleting a Target Device
Delete a target device if its registration is no longer required or you wish to register a new
device but have already reached the maximum number of registrations.
1Set the camera to the playback or shooting modes.
2Press the MENU button.
3In the [ (Wireless)] menu, select [Delete
Registration] and press the FUNC./SET button.
4Select the target device you would like to
delete.
5Select [Delete] and press the FUNC./SET
button.
The selected device will be deleted and the name
of the next device will display.
6Press the MENU button.
