Network Video Recorder
VK-64/VK-16 v2.0 Viewer Operation Guide This guide explains a basic operation of VK Viewer. For more detailed explanations, refer to the Administrator's
Manual and Setup Guide.
* This guide also applies to VK-Lite Viewer (simplified version of VK Viewer).
Location/Zone
Camera Selection Area
Thumbnails from all the
cameras located in each zone
are displayed. The number of
thumbnails represents the
number of cameras in the zone.
Video Window
Live or recorded video from a
camera is displayed in this
window.
Viewing Area
Video Windows are displayed
here.
Timeline
Recording information and
events that have occurred are
displayed.
Playhead
The time of the video currently
being played is displayed.
Launching VK Viewer
1
2
4
3
Double-click the VK Viewer v2.0 desktop icon.
The connect option menu (Startup Screen) for the Storage Server is
displayed.
* Different icon is displayed for VK-Lite.
Select Master Storage
Server and click
Connect.
If you select localhost or Use
IP address, the Login dialog
box appears.
Enter your User Name
and Password and click
Login.
VK Viewer starts up.
Make a note of your ID and
password here.
Select File →Exit in the
menu bar.
VK Viewer shuts down.
Note that the login information is case-sensitive.
Check with the system administrator for your ID and password.
If you note down your ID and password in this guide, take particular
care to ensure that this does not lead to unwanted disclosure of your
login details.
Exiting VK Viewer
If you are using a screensaver on your PC, the screen saver may
start up after VK Viewer shuts down. To restore the viewing window,
simply move the mouse.
VK Viewing Screen
For information on operations such as changing the video window display position, size or layout, see Chapter 5 Viewer Reference in the
Administrator's Manual.
The camera selection area, timeline and video window title bars can all be hidden using options in the View menu in the menu bar.
Video Window
ID
Password
Location Groups of zones.
Zone Areas in which
cameras are located.
Video display
Live or recorded video is displayed.
Title bar
The camera name and the video status are displayed.
The title bar color changes according to the displayed video content, as shown below.
Live video The video currently being shot.
Recorded video Video recorded on the storage server.
Title bar color Video status
During live video display
During recorded video
display
Black
Gray
Live
Recording time
COPY

Controlling A Camera
2Select View →Camera Control in the
menu bar.
The Camera Control panel appears.
3Click Get Control in the Camera Control
panel.
Once you have the camera control, all the buttons in
the Camera Control panel become active.
For details, see Chapter 5 Viewer Reference in the Administrator's
Manual.
If you have the camera control and do not make any changes for 30
seconds, a message appears saying "Control will be lost in 10 seconds".
You will then lose the control if it is left for another 10 seconds.
To control a camera while it is recording, check with the administrator and
review the procedure beforehand.
Playing Recorded Video
1Click a video window of the camera you want to play.
3Click the time you want to play.
The recorded video appears in the selected video window.
2Click and drag the time bar to the left or right to change
the playback time.
1Click a video window of the camera you want to play.
Rewind Play/Pause Fast forward
2Click Jump to Time.
The Jump to Time dialog box
appears.
3Select a date and time and
click OK.
The recorded video appears in the
selected video window.
If a message appears saying "Can't get
camera control", system administration
privileges of other Viewers of tools may
be controlling the camera. Contact the
administrator.
Rewind and nudge back cannot be used when viewing recorded MPEG-4 video. *MPEG-4 video cannot be recorded with VK-Lite.
QuickTime version 6.5.1 or later is recommended.
On Windows Vista, videos cannot be saved into the Program Files folder or Windows folder on the system drive.
SSaving a specified video
Saving a specified video
Jump to next event
You can use these controls to play, pause, rewind, fast forward, nudge
forward or back and jump to the previous or next event. You can also
change the rewind and fast forward speeds sequentially from 1x →2x
→5x →10x.
This button switches the video display from recorded video back to
live video.
You can save recorded videos to any location in .mov format.
The saved videos can then be viewed in QuickTime Player or any
other player that supports the .mov format.
These controls change the level of detail shown in the timeline.
Jump to previous event Nudge forward
Pan (left/right) and Tilt (up/down)
These controls move the camera in the direction
of the arrows.
Pan and tilt either by briefly clicking an arrow, or
by clicking and holding the arrow.
Zoom
Click and drag the zoom slider to zoom in or out.
Pan/Tilt/Zoom speed
Set the camera pan/tilt, and zoom speed.
Zoom In To view the timeline in more detail.
Zoom Out To view the entire timeline at once.
File-Saving format QuickTime (file extension: mov)
Recording duration Max. 1 hour
Pan/Tilt/Zoom Control
Adjusting/Saving Played Video
1Click a video window for the camera you want to control.
Preset
Choose one of preset positions from a list.
Nudge back
Using the timeline to plUsing the timeline to play video
Using the timeline to play video
PlPlaying video of a specified time
Playing video of a specified time
Controlling plControlling playback
Controlling playback
Zooming in and out on the timelineZooming in and out on the timelineZooming in and out on the timeline
Zooming in and out on the timeline
Returning to Live Video
Returning to Live Video
PUB. YT1-1395-000 © CANON INC.2008
