Canon DR-5060F User manual

Backup
FILME F
A
FeedingOption
NewFile
Space
CountOnly
Manual
Auto
Semi-Auto
Scanner
DOCUMENT SCANNER
INSTRUCTIONS

NOTICE
qCopyright© 2001 by CANON ELECTRONICS INC. All rights reserved. No part of this publication may be reproduced,
transmitted, transcribed, stored in a retrieval system, or translated into any language or computer language in any form or by
anymeans,electronic,mechanical,magnetic,optical,chemical,manual,orotherwise,withoutthepriorpermissionofCANON
ELECTRONICS INC.
wThe contents of this manual are subject to change without notice.
eEvery effort has been made to ensure the accuracy of information presented in this manual. However, Canon Electronics Inc.
and the subsidiaries on the back cover assume no responsibility for any errors or their consequences.
rWe do not assume any responsibility for damage resulting from operations regardless of item e.
Trademarks and RegisteredTrademarks
●Microsoft WindowsRand Microsoft Windows NTR are registered trademark of Microsoft Corporation in the U.S. and in
other countries.
●ISISR is a registered trademark of Pixel Translation, a division of ActionPoint Inc.
●Product names mentioned herein are for identification purposes only and may be trademarks and/or registered trademarks of
their respective companies.

1
INTRODUCTION
Thank you for purchasing the Canon Document Scanner DR-5060F. This manual
describes how to use Scanning Utility 5060 for scanning in images to the
computer on Document Scanner DR-5060F. Be sure to read this manual and the
separate DR-5060F Instructions before use to ensure that the functions of this
Scanning Utility are effectively utilized.
Scanner drivers such as an ISIS or TWAIN driver are not required as this
Scanning Utility packaged with the DR-5060F uses an exclusive scanner driver.
Introduction

2Introduction
CONVENTIONS
This manual uses the following symbols and indications.
Before you start reading this manual, read the following and familiarize yourself
with their meanings.
WARNING
Read carefully to avoid death or serious injury.
CAUTION
Read carefully to avoid serious injury or damage to the equipment or loss of
valuable data.
NOTE
Read carefully to avoid damage to the equipment.
MEMO
Memos indicate where you will find useful information in this manual.

3
Contents
Contents
INTRODUCTION.................................................................................................................. 1
CONVENTIONS................................................................................................................... 2
Chapter 1 Installation and Basic Operation of Scanning Utility 5060 .... 5
System Requirements ....................................................................................................... 6
Installing Scanning Utility 5060 ........................................................................................ 7
BeforeYou Begin.......................................................................................................... 7
Installing Scanning Utility 5060 .................................................................................... 7
Uninstalling Scanning Utility 5060.............................................................................. 10
Basic Scanning Utility 5060 Operations ........................................................................ 11
Starting Up Scanning Utility 5060 .............................................................................. 11
Explanation of the Scanning Utility 5060 Screen ....................................................... 12
Exiting Scanning Utility 5060 ..................................................................................... 18
Chapter 2 Scanning a Document..........................................................19
BeforeYou Start Scanning .............................................................................................. 20
Setting Basic Scan Conditions ....................................................................................... 22
Scanner Settings........................................................................................................ 23
Scanning Originals and Saving Scanned Images......................................................... 25
Scan Page.................................................................................................................. 25
Scan Batch to File...................................................................................................... 27
Film Address File Name............................................................................................. 31
Saving Scanned Images .................................................................................................. 35
Restrictions in the Number of Characters in File Names ........................................... 35
About Save Formats .................................................................................................. 35
Saving Scanned Images to File (Scan Page) ............................................................ 36
Saving Multiple Page Originals .................................................................................. 37
Opening Saved Files........................................................................................................ 39
Scanning and Printing Documents ................................................................................ 40
Printing Opened Images ............................................................................................ 40
Scan Batch to Printer ................................................................................................. 42
Other Scan Operations .................................................................................................... 45
Verify Scan................................................................................................................. 45
Using Patch Codes/Function Sheets ......................................................................... 47

4Contents
Chapter 3 Setting Detailed Scan Conditions .......................................51
Setting Scan Conditions.................................................................................................. 52
Setting up the Scanner .............................................................................................. 52
Detailed Settings .............................................................................................................. 54
Image Controls........................................................................................................... 55
Option Devices........................................................................................................... 58
Feeder Option ............................................................................................................ 63
Separation.................................................................................................................. 65
Function Key Settings ................................................................................................ 66
Setting the Gamma Curve ......................................................................................... 68
Imprinter/Addon Settings ........................................................................................... 70
Barcode Settings........................................................................................................ 75
Patch Code Settings .................................................................................................. 78
Chapter 4 Troubleshooting....................................................................81
When An Error Message orWarning is Displayed ........................................................ 82
WhenThe Scanned Image is Not Normal....................................................................... 85
Index.................................................................................................................................. 86

5
Installation and Basic Operation of Scanning Utility 5060
1
Chapter 1
Installation and Basic Operation
of Scanning Utility 5060
This chapter describes how to install
Scanning Utility 5060, and basic operation of
Scanning Utility 5060.
System Requirements................................. 6
Installing Scanning Utility 5060 .................7
BeforeYou Begin..................................... 7
Installing Scanning Utility 5060 .............7
Uninstalling Scanning Utility 5060 ...... 10
Basic Scanning Utility 5060 Operations.. 11
Starting Up Scanning Utility 5060........11
Explanation of the Scanning Utility
5060 Screen ...........................................12
Exiting Scanning Utility 5060 ...............18

6System Requirements
System Requirements
You must have the following hardware and OS for Scanning Utility 5060 to work.
●An IBM PC/AT or compatible computer with a Pentium 133 MHz CPU or
faster and at least 64 MB of memory
• OS: Microsoft Windows®95/98/Me or Microsoft Windows NT®4.0
Workstation, Microsoft Windows®2000 Professional
• At least 100 MB of hard disk space (at least 5 MB at installation)
●An SVGA compatible display
●A MicrosoftWindows compatible keyboard, mouse and printer, CD-ROM
drive (4×speed or faster recommended)
●A SCSI card whose operation has been confirmed
Operation of the following SCSI cards has been confirmed:
Adaptec AHA-2930 series and AHA-2940 series
●SCSI-2 compatible SCSI cable
MEMO
●Scanning Utility 5060 uses a dedicated scanner driver. Scanner drivers such
as the ISIS driver and TWAIN driver are not required.
●When you install Scanning Utility 5060, another folder “\ceiscan” is created
under the Windows folder in addition to the installation destination folder,
and the file “cei*.dll” is copied to \Windows\system.
Scanning Utility 5060 will not function properly if these files are modified.
●Scanning Utility 5060 uses “wnaspi32.dll” for controlling the scanner. The
scanner will not operate if “wnaspi32.dll” is not correctly installed.
NOTE
When Scanning Utility 5060 is used, set the scanner to the Backup mode or
the Scanner Only mode. If Scanning Utility 5060 is used in the Filmer only
mode, an error message is displayed when scanning is started.

7
Installation and Basic Operation of Scanning Utility 5060
1
Installing Scanning Utility 5060
Installing Scanning Utility 5060
This section describes how to install Scanning Utility 5060 and the installation
procedure.
BeforeYou Begin
Check the following items before you begin to install Scanning Utility 5060.
●Make sure that the OS of the computer on which you are going to install
Scanning Utility 5060 is either Microsoft Windows®95/98/Me or Microsoft
Windows NT®4.0 Workstation, Microsoft Windows®2000 Professional.
●Connection with your computer
For details on how to connect the scanner, refer to the separate DR-5060F
Instructions.
Installing Scanning Utility 5060
The following describes the procedure for installing Scanning Utility 5060 on the
computer.
1
Turn the scanner ON.
2
Turn the computer ON, and boot up Windows.
3
Insert the setup disc into the CD-ROM drive.

8Installing Scanning Utility 5060
4
Click [Start] and select Run....
5
At Open, type“D:¨\su5060\setup.exe” and click OK.
In these instructions, the CD-ROM drive is specified as D.
The Choose Setup Language dialog box appears.
6
Select English (United States) and click OK.
The Welcome dialog box appears.

9
Installation and Basic Operation of Scanning Utility 5060
1
Installing Scanning Utility 5060
7
Click [Next].
The Choose Destination Location dialog box appears.
8
Check the displayed installation directory, and then click [Next].
Installation begins.
9
This continues the installation. After a while, the Setup Complete
dialog box appears.
10
Click [Finish] to complete the installation.

10 Installing Scanning Utility 5060
Uninstalling Scanning Utility 5060
To uninstall Scanning Utility 5060, open “Add/Remove Programs” in the control
panel, select [Scanning Utility 5060] and click [Add].

11
Installation and Basic Operation of Scanning Utility 5060
1
Basic Scanning Utility 5060 Operations
Basic Scanning Utility 5060 Operations
This section describes how to start up and exit Scanning Utility 5060, and the
Scanning Utility 5060 screens.
Starting Up Scanning Utility 5060
Before you start operating the scanner, turn ON the scanner and the computer,
and then start up Scanning Utility 5060.
1
Turn the scanner ON.
2
Turn the computer ON.
Windows boots up.
3
Click [Start] and choose [Program] - [Scanning Utility 5060].
Scanning Utility 5060 starts up.

12 Basic Scanning Utility 5060 Operations
Explanation of the Scanning Utility 5060 Screen
This section describes the functions of the menu bar and Toolbar, and the mouse
pointer on the Scanning Utility 5060 screen.
◆Menu bar
File menu
Open...
Opens images saved on Scanning Utility 5060. You can open files saved in one
of the TIFF (*.tif), BMP (*.bmp), JPEG (*.jpg) or JBIG (*.jbg) file formats on
Scanning Utility 5060. (See “Opening Saved Files” P. 39)
Save Page As...
Saves currently displayed pages under a different name. Pages that are not
displayed when a file comprising two or more pages are not saved to file.
(See “Saving Scanned Images to File (Scan Page)” P. 36)
Statusbar
Menu bar
Toolbar
Mouse pointer

13
Installation and Basic Operation of Scanning Utility 5060
1
Basic Scanning Utility 5060 Operations
Print
Prints the image (See “Scanning and Printing Documents” P. 40)
Print Format
Sets the size of the image to be printed.
Actual size : Prints at the same size as the paper regardless of the size of
paper to be printed or the resolution at which the image was
scanned.
Fit to paper : Prints the image matched to the paper size when the document
is larger than the paper, and prints at the actual size when the
document is smaller than the paper.
Actual pixel : Prints each single dot in the scanned image using one output
dot on the printer. For this reason, the print size becomes
smaller when a scanned image is output on a small dot high-
resolution printer.
Printer setting...
Sets the printer.
Scanner setting...
Sets the scanner. (See “Setting Basic Scan Conditions” P. 22)
Scan page
Scans only a single page. (See “Scan Page” P. 25)
Scan batch to file...
Scans and saves the document to a specified file. (See “Scan Batch to File” P.
27)
Scan batch to printer...
Scans and prints the document on the printer currently set at Normally used
printer. (See “Scan Batch to Printer” P. 42)
Cancel Scan
Cancels the current scan job.
Select scanner...
Selects the scanner to be used.
Film address file name
Scans the document, and saves the film address to a specified folder as a file
name or folder name. (See “FilmAddress File Name” P. 31)
Exit
Exits Scanning Utility 5060.

14 Basic Scanning Utility 5060 Operations
View menu
Toolbar
You can switch display of the toolbar ON and OFF.
Statusbar
You can switch display of the statusbar ON and OFF.
Zoom In
Each click of this button enlarges the image on screen.
Zoom Out
Each click of this button reduces the image on screen.
Best Fit
Displays the entire image in the window.
Fit to width
Displays the image so that its width matches the width of the window.
Rotate Left
Rotates images left (counterclockwise) by 90°.
Rotate Right
Rotates images right (clockwise) by 90°.
View Gray
Switches between black-and-white display and gray scale display. Reduced
images are easier to view when View Gray is set.

15
Installation and Basic Operation of Scanning Utility 5060
1
Page menu
Next page
Displays the image on the next page.
Prev. page
Displays the image on the previous page.
GoTo Page
Opens the Goto Page dialog box. Entering any page number and clicking OK
jumps to the page you specified.
Help menu
About
Displays the version information of Scanning Utility 5060.
◆Toolbar
(Open): Open images saved on Scanning Utility 5060.
(Save PageAs): Saves currently displayed pages under a different name.
Pages that are not displayed when a file comprising two or more pages are
not saved to file.
(Print): Prints the displayed image.
(Fit to width): Displays the image so that its width matches the width of the
window.
(Best Fit): Displays the entire image in the window.
Basic Scanning Utility 5060 Operations

16
(Zoom In): Each click of this button enlarges the image on screen.
(Zoom Out): Each click of this button reduces the image on screen.
(Rotate Left): Rotates the image left (counterclockwise) by 90°.
(Rotate Right): Rotates the image right (clockwise) by 90°.
(Scroll page):
This button on the toolbar is enabled when a document comprising two or
more pages is displayed. Pressing moves to the next page, while
pressing moves to the previous page. Entering any page number at the
specified page box and pressing Enter on the keyboard jumps to the page
you specified.
(Scanner setting...): Sets the scanner.
(Scan batch to file...): Scans and saves the image to a specified file.
(Film address file name):
Scans the image, and saves the film address to a specified folder as a file
name or folder name.
(About): Displays the version information of Scanning Utility 5060.
: Displays the folder and file name of the currently
opened image.
◆Mouse pointer
The mouse pointer is normally displayed as an arrow pointer ( ). However, the
shape of the pointer changes shape to an open hand ( ) when an image is
displayed, and the mouse pointer is moved to inside the window.
Basic Scanning Utility 5060 Operations

17
Installation and Basic Operation of Scanning Utility 5060
1
◆Scrolling images
The scroll bar appears when an image is enlarged, and the enlarged image is
larger than the window. To scroll the image, move the scroll bars. If you press the
left mouse button in this state, the mouse pointer changes shape to a clenched
hand . You can scroll the image by dragging the image in any direction and
releasing the left mouse button.
◆Statusbar
The statusbar displays explanations for menus and buttons, and warnings when
the scanner is about to run out of film.
When the mouse pointer is over a menu or button, a menu or button explanation
appears on the left of the statusbar.
When the scanner detects that it is about to run out of film during scanning, the
scanner sounds a warning buzzer, and displays the “About to run out of film”
warning on the right side of the status bar. (See “Warning” P. 84)
Basic Scanning Utility 5060 Operations

18
Exiting Scanning Utility 5060
1
Select [Quit application] from the File menu on the menu bar.
Scanning Utility 5060 is quit.
NOTE
The mouse pointer changes shape to an hourglass when scanning is started,
scanning is interrupted or when the scanner performs some operation after
start of scanning is instructed.
If the mouse pointer changes shape to an hourglass while scanning is not
being performed, the previous scanning job has not ended. Either press the
Clear/Stop key on the operation panel, or select [Stop Scanning] from the File
menu on the menu bar to cancel display of the hourglass and then exit
Scanning Utility 5060.
Basic Scanning Utility 5060 Operations
