Canopy Factory 22589 User manual

SET UP
Model #22589
12 x 12
Page 1
STEP 6
01-22589 1/27/05
Missing Parts,Need Replacements,or Help
with Assembly Please Contact Customer Service:
1-800-524-9970
Please read instructions
COMPLETELY before assembly.
West Haven, CT 06516
"Sets Up in 60 Seconds!"
POP-UP CANOPY
STEP 5
Attach the top to the frame by matching the loop fastening strip on
the frame. pull the corners down fully. Push the loop firmly together
at each corner.
STEP 1
Begin by placing your canopy near
the center of the set-up area. Along
with a helper grasp a canopy leg in
each hand. Slightly lift the frame off
the ground and step backwards,
pulling the frame apart until your
arms are fully extended as shown
in the illustration.
STEP 2
Carefully unfold the fabric top and
place it over the frame, making
sure to align the corners of the top
with the corners of the frame.
STEP 3
While taking care not to pinch your fingers, grasp the frame section
marked "Open Here" and push up until the canopy is fully opened.
STEP 4
Slide the auto slider at
each corner up, while
holding the corner of the
frame down until the snap
button engages into the
hole. Then, pull the corner
of the cover down snugly.
Lift up outer legs and slide out the inner legs until the snap button
locks. Repeat on the other legs.
Note:
Slide out the Middle
inner leg first!

TAKE DOWN
Page 2 01-22589 1/27/05
STEP 7
Use anchors at four
corners of canopy
Anchor
CARE & CLEANING INFORMATION
DO NOT expose top or walls to open fire or flame. DO NOT
use barbeque grills or smokers underneath canopy.
DO NOT use harsh abrasives, bleach or cleansers. Cover and walls can be easily cleaned with mild soap and water. Periodically check
stakes or anchors to ensure stability of unit, especially following exposure to high winds or heavy rain. NOT meant to hold snow load,
brush snow off top with a broom or mop.
IMPORTANT:PLEASE READ CAREFULLY
North American Outdoor Products has no control over the elements such as wind, snow or heavy rain, we cannot be responsible for
damage caused by the canopy or to the canopy.We suggest you contact your insurance carrier for information just as you would for any
other outside structure. This is a Temporary Structure and is not recommended as a permanent structure. Safety glasses must be worm
when securing bunges.
Improper Anchoring, Strong Winds, Snow or Ice
North American Outdoor Products does not guarantee these canopies in snow or ice under any circumstances.
Canopies are designed to offer protection from damage caused by sun, light rain, tree sap, & birds, and are not designed to hold the
loads that accompany snow or ice. Any canopy that is not anchored securely or properly will fly away.We will not be responsible for
any canopy that blows away. Proper anchoring is your responsibility. We offer several anchoring kits, call customer service for more
information or to place an order.Your canopy's cover can be quickly removed if needed when you know that a strong or severe weather
front is approaching.
Replacement Parts
Additional covers, tubes, & walls are available directly from the factory through our customer service department.(1.800.524.9970)
Covers and walls have been treated to withstand high U.V. exposure for longer periods of time than tarps or covers bought at hard-
ware stores or home centers.
STEP 1
STEP 2
Depress the snap button on the
center pole so it releases to be
below the center connector.
STEP 3
Grasp the frame section where marked "CLOSE HERE"
on opposite sides . Lift slightly and slowly walk towards
partner as the frame folds in. Keep walking until the fra-
me is about halfway closed. Take care to avoid pinching
your hand or fingers. Take cover off for storage.
STEP 4
Remove canopy. Grab the two outer legs and push together to
fully close the frame . Place your canopy inside the carry bag
for easy transport and storage.
Remove anchors from the ground
and remove the cover straps from
the frame. Depress the height
adjusting button and reduce each
corner leg to it shortest position.
(Be sure button engages at short-
est point)

1. 15429 Leg Tube
2. 15430 Leg Tube
3. 15428 Leg Tube
4. 15293 Connect Piece
5. 15294 Connect Piece
6. 15483 Grnme Tach
7. 15217 Self Drive Bolt
8. 15296 Plug
9. 15270 Corner Cover for Leg Tube
10. 15360 Inner Washer For Leg Tube
11. 15297 Inner Washer For Leg Tube
12. 15298 Slide Connecter For Leg Tube
13. 15433 Gemel
14. 15434 Gemel
15. 15435 Gemel
16. 15437 Slide Tube
17. 15438 Slide Tube
18. 15439 Inclined Holding Tube
19. 15280 Hex Bolt
20. 15281 Hex Bolt
21. 15283 Hex Bolt
22. 15284 Hex Bolt
23. 15256 Nut
24. 10431 Anchor
25. 15379 Spring Pin
26. 15380 Spring Pin
27. 15481 Spring Pin
28. 15285 Top Crest
29. 15286 Plug For Gemel
30. 15287 Gemel Corner Bush
31. 15263 PP Washer
32. 15264 PP Washer
33. 15440 Cover
34. 15487 Bag
No. Part Description
CA
B
C
A & B
F
D
E F
D
E
8
23
32
21
21
21
28
22
925
8
6
29
30
31
32
19
23
13
14
12
1
26 27
29
17
18
16
10
11 2 3 23
31
23
21 32 23
21
32
32
23
23
30
31
32
20
23
30
31
32
19
23
#22589 Part List
