ANT-EXT
User Manual
1. Description.
ANT-EXTis an omnidirectional antenna with pole/wall installation clamp, with brass cable/antenna connection, with stiff protection
and hole for condensation drain.
2. Mounting instructions.
Use 2 dowels fischer type for 6mm diameter holes. Antenna can be wall or pole mounted.
ATTENTION: For a correct installation place the antenna with vertical dial and 10 cm far from any metal surface.
3. V.S.W.R.
Picture 1 - Product Image

WA5078E_ANT-EXT_User Manual_R01
CAPETTI ELETTRONICA s.r.l. - Strada Stratta 57
10090 CASTIGLIONE TORINESE - TORINO - ITALY
VAT 04837130014 - Phone [phone] - Fax [phone]
e-mail [email protected] - web www.capetti.it
2/4
ANT-EXT
User Manual
4. Radiation diagram.
The user interface consists of a “virtual” button that can be activated using the WineCapKey and of a two-coloured led.
To give a command, user must approach the WineCapKey to the device’s sensible area and keep it in that position.; the following
picture (Pic. 3) shows device’s sensible points.
5. Technical Information.
Frequency
860 - 880 MHz
Impedance
50 Ω
V.S.W.R.
< 1,5 : 1
Maximum power
15 W
Polarization
Linear
Radiation
Omnidirectional
Gain
2,15 dBi
Dimensions
150x100x150 mm
Weight
0,230 kg
Cable
RG58 tinplated, 5 m
Working temperature
-40° / +80°C
Screws/clamp material
Stainless steel
Radiant element material
Steel, brass

WA5078E_ANT-EXT_User Manual_R01
CAPETTI ELETTRONICA s.r.l. - Strada Stratta 57
10090 CASTIGLIONE TORINESE - TORINO - ITALY
VAT 04837130014 - Phone [phone] - Fax [phone]
e-mail [email protected] - web www.capetti.it
3/4
ANT-EXT
User Manual
6. Mechanical dimensions.
Picture 2 - Mechanical dimensions
150mm
100mm
150mm

WA5078E_ANT-EXT_User Manual_R01
CAPETTI ELETTRONICA s.r.l. - Strada Stratta 57
10090 CASTIGLIONE TORINESE - TORINO - ITALY
VAT 04837130014 - Phone [phone] - Fax [phone]
e-mail [email protected] - web www.capetti.it
4/4
ANT-EXT
User Manual
7. Reference standards.
EN 61010 -1
For electromagnetic compatibility
EN 61000 - 3 - 2
EN 61000 - 3 - 3
EN 300 220 -2
EN 301 489 - 03
EN 61000 - 6 -1
This symbol indicates that this product is compliant with the European Directive 2011/65/CE that restricts
the use of substances in the manufacturing of electronic devices.
The “WEEE” logo on the label indicates that this product is compliant with the "WEEE" EC Directive.This
symbol (valid only in the European Union countries) indicates that the product it is applied to, MUST NOT
be discarded with ordinary household or industrial waste, but must be sent to an authorized reception
point. The end user should contact the device provider, either the manufacturer or the reseller, in order to
agree a collection and disposal process, after having checked the terms and conditions of sale.
The features shown may be subject to change without notice.
