Care Fusion Alaris 8600 Operating manual

Technical Service Manual
Alaris®Auto-ID Module, Model 8600
Supports: Guardrails®Suite MX
November 2010
READY
SCAN
CANCEL

Alaris®Auto-ID Module
Technical Service Manual
General Contact Information
CareFusion
San Diego, California
United States
carefusion.com
Customer Advocacy - North America
(Clinical and technical feedback.)
Phone: [phone]
E-mail: [e-mail]
Technical Support - North America
(Maintenance and service information support; troubleshooting.)
Phone, United States: 888.876.4287
Phone, Canada: 800.387.8309
Customer Care - North America
(Product return, service assistance, and order placement.)
Phone, United States: 888.876.4287
Phone, Canada: 800.387.8309
Order Numbers:
Printed Copy:12207531 © 2007, 2010 CareFusion Corporation or one of its subsidiaries. All rights reserved.
Alaris® and Guardrails® are registered trademarks of CareFusion Corporation or one of its subsidiaries. All other trademarks belong to
their respective owners.

Table of Contents
i
Alaris®Auto-ID Module
Technical Service Manual
Chapter 1 – General Information
1.1 Introduction...................................................................................................................................... 1-1
Chapter 2 – Checkout and Configuration
2.1 Introduction...................................................................................................................................... 2-1
2.2 New Instrument Checkout ............................................................................................................... 2-1
2.3 Configuration Options and Setup .................................................................................................... 2-1
Chapter 3 – Preventive Maintenance
3.1 Introduction...................................................................................................................................... 3-1
3.2 Cleaning........................................................................................................................................... 3-1
Chapter 4 – Principles of Operation
4.1 Introduction ...................................................................................................................................... 4-1
4.2 Principles of Operation .................................................................................................................... 4-1
4.2.1 LED (READY Indicator) ...................................................................................................... 4-1
4.2.2 Keypad................................................................................................................................ 4-1
4.2.3 Camera Assembly .............................................................................................................. 4-1
4.2.4 Handheld Scanner Connection .......................................................................................... 4-2
4.2.5 Speaker............................................................................................................................... 4-2
4.2.6 Logic Board......................................................................................................................... 4-2
4.2.7 IUI Board............................................................................................................................. 4-2
Chapter 5 – Corrective Maintenance
5.1 Introduction...................................................................................................................................... 5-1
5.2 Disassembly/Reassembly................................................................................................................ 5-1
5.2.1 Latch Assembly and Feet ................................................................................................... 5-3
5.2.2 IUI Connectors and Case Separation................................................................................. 5-4
5.2.3 Speaker Assembly.............................................................................................................. 5-6
5.2.4 Camera/Frame/Board Assembly ........................................................................................ 5-7
5.2.5 IUI Bracket and Board Assemblies..................................................................................... 5-8
5.2.6 Internal Cable (Handheld Connector) and Lens ................................................................. 5-10
Chapter 6 – Troubleshooting
6.1 Introduction...................................................................................................................................... 6-1
6.2 General Troubleshooting ................................................................................................................. 6-1

ii
Table of Contents
Alaris®Auto-ID Module
Technical Service Manual
Chapter 7 – Illustrated Parts Breakdown
7.1 Introduction ...................................................................................................................................... 7-1
7.2 Illustrations....................................................................................................................................... 7-1
7.3 Parts List.......................................................................................................................................... 7-1
7.4 Ordering Parts ................................................................................................................................. 7-2
Figures
4-1 Block Diagram ................................................................................................................................. 4-3
6-1 Communications Boards - Model 8000 ........................................................................................... 6-3
7-1 Front Case Assembly ...................................................................................................................... 7-5
7-2 IUI Bracket and Board Assemblies - Camera/Frame Assembly...................................................... 7-6
7-3 Board/Frame Assembly - Front Case Assembly ............................................................................. 7-7
7-4 Speaker Assembly........................................................................................................................... 7- 8
7-5 IUI Connectors and Case Assembly................................................................................................ 7-9
7-6 Feet, Latch Assembly, Labels.......................................................................................................... 7-10
7-7 IUI Board.......................................................................................................................................... 7-11
7-8 Logic Board...................................................................................................................................... 7-12
Tables
1-1 Defined Terms ................................................................................................................................. 1-2
1-2 Abbreviations, Acronyms, Symbols ................................................................................................. 1-2
5-1 Required Materials, Supplies and Tools .......................................................................................... 5-2
5-2 Torque Values.................................................................................................................................. 5-11
5-3 Level of Testing Guidelines.............................................................................................................. 5-12
6-1 Software Compatibility..................................................................................................................... 6-2
6-2 Technical Troubleshooting Guide .................................................................................................... 6-4
6-3 Error Codes ..................................................................................................................................... 6-5
7-1 Parts List.......................................................................................................................................... 7-3

1-1
Alaris®Auto-ID Module
Technical Service Manual
1.1 INTRODUCTION
This manual describes how to service the
Auto-ID Module (Model 8600). It is used in
conjunction with the following Alaris®System
documents and software:
• Alaris®System Directions for Use (DFU)
• Maintenancesoftwareandusermanual
This manual is intended for personnel
experienced in analysis, troubleshooting,
and repair of analog/digital microprocessor-
based electronic equipment.
Refer to the Alaris®System DFU for a
product introduction, detailed setup and
operationprocedures,denitions(including
precautiondenitions),specications,and
other information related to the use of the
Alaris®System.
If the Auto-ID Module requires service while
under warranty, it must be serviced only by
CareFusion authorized service personnel.
Refer to the "Warranty" and "Service
Information" sections in the Alaris®System
DFU.
CAUTION
To avoid damaging the keypad, do not use a
sharp object (such as pen or pencil) to press the
SCAN/CANCEL key.
CAUTION
Any attempt to service this product by anyone
other than an authorized CareFusion Service
Representative, while the product is under
warranty, may invalidate the warranty.
Chapter 1 – General Information

1-2
General Information
Alaris®Auto-ID Module
Technical Service Manual
Table 1-1 Dened Terms
The following table identifies the defined terms used throughout this document for certain trademarked
products and product features.
Product / Feature Defined Term
Alaris®Auto-ID module Auto-ID Module
Alaris®PCA module PCA Module
Alaris®PC Unit PC Unit
Alaris®Pump module Pump Module
Alaris®Syringe module Syringe Module
Guardrails®data set Data Set
Table 1-2 Abbreviations, Acronyms, Symbols
Various abbreviations, acronyms and symbols are used throughout this manual. This table defines
those that are not commonly known or easily recognized.
DFU Directions for Use
IUI inter-unit interface
NDC National Drug Code

2-1
Alaris®Auto-ID Module
Technical Service Manual
CAUTION
Should an instrument be dropped or severely
jarred, remove it from use immediately. It should
be thoroughly tested and inspected by qualified
service personnel to ensure proper function prior
to reuse.
2.1 INTRODUCTION
This chapter describes Auto-ID Module initial
setup and configuration.
2.2 NEW INSTRUMENT CHECKOUT
Prior to placing a new instrument in use,
perform a check-in procedure using the
applicable maintenance software.
Contact CareFusion authorized service
personnel if the instrument has physical
damage or fails to satisfactorily pass the
check-in test.
2.3 CONFIGURATION OPTIONS AND
SETUP
Configure the Auto-ID Module using the
applicable maintenance software.
Refer to the Alaris®System DFU for
system configurable settings. Refer to the
PC Unit/Pump Module Service Manual
for instructions on how to change System
Configuration parameters.
Chapter 2 – Checkout and Configuration

2-2
Checkout and Configuration
Alaris®Auto-ID Module
Technical Service Manual
THIS PAGE
INTENTIONALLY
LEFT BLANK

3-1
Alaris®Auto-ID Module
Technical Service Manual
WARNING
Failure to perform regular and preventive
maintenance inspections may result in improper
instrument operation.
3.1 INTRODUCTION
Perform regular and preventive maintenance
inspections to ensure that the Auto-ID
Module remains in good operating condition.
• Performregularinspectionsbeforeeach
use.
• Performpreventivemaintenance
inspections once a year.
Use the applicable maintenance software to
check in, upgrade/repair, diagnose, calibrate
and perform preventive maintenance.
These requirements and guidelines are
intended to complement the intent of
the Joint Commission on Accreditation
of Healthcare Organizations (JCAHO)
requirements.
3.2 CLEANING
Refer to the Alaris®System DFU.
Chapter 3 – Preventive Maintenance

3-2
Preventive Maintenance
Alaris®Auto-ID Module
Technical Service Manual
THIS PAGE
INTENTIONALLY
LEFT BLANK

4-1
Alaris®Auto-ID Module
Technical Service Manual
4.1 INTRODUCTION
This chapter describes the principles of
operation for the Auto-ID Module.
Refer to the PC Unit/Pump Module Technical
Service Manual for Alaris®System principles
of operation.
4.2 PRINCIPLES OF OPERATION
Circuit boards are not field repairable and
must be returned to a CareFusion Service
Center for repair.
4.2.1 LED (READY Indicator)
A green LED on the front panel lights
to confirm that the camera assembly
(embedded scanner) or handheld scanner is
ready to scan.
4.2.2 Keypad
The keypad includes the SCAN/CANCEL
key. Pressing once begins scanning, and
pressing during scanning cancels the scan.
4.2.3 Camera Assembly
The Camera Assembly reads bar codes
(including linear and two-dimensional bar
code formats) using technology similar to
digital cameras. Bar code readers use
high-intensity LEDs to illuminate the bar code
image, allowing the code to be scanned
regardless of ambient light conditions.
The Camera Assembly scans the bar code,
then sends signals to decoding circuitry on
the Logic Board.
Chapter 4 – Principles of Operation

4-2
Principles of Operation
Alaris®Auto-ID Module
Technical Service Manual
4.2.4 Handheld Scanner Connection
CareFusion offers a handheld scanner
that can be connected to the front panel of
the Auto-ID Module. The Auto-ID Module
is designed for use only with handheld
scanners supplied by CareFusion.
4.2.5 Speaker
The speaker provides audible confirmation of
key presses and successful scans.
4.2.6 Logic Board
The Logic Board interfaces all of the Auto-ID
Module components. Decoding circuitry on
the Logic Board recognizes the bar code
symbology, analyzes the content of the
scanned code, and converts the data to a
traditional data format.
The Logic Board receives its power from the
PC Unit via the IUI Board. The Logic Board
converts power to internal supply voltages
and monitors supply voltages during
operation.
A watchdog timer circuit is designed to put
the Auto-ID Module into a safe state if the
Logic Board main processor fails.
4.2.7 IUI Board
The IUI Board contains IUI circuitry that
allows it to communicate with the PC Unit.

4-3
Principles of Operation
Alaris®Auto-ID Module
Technical Service Manual
Figure 4-1 Block Diagram
Camera
Assembly
Logic Board
LED
Keypad
External
Handheld
Connection
Speaker
IUI Board
J4
J6
J5
J11
J2
J7
Camera
Cable
Keypad
Harness
LED
Harness
Internal
Cable
Speaker
Cable
Logic/IUI
Cable
J3
Left IUI
Connector
Right IUI
Connector
J9

4-4
Principles of Operation
Alaris®Auto-ID Module
Technical Service Manual
THIS PAGE
INTENTIONALLY
LEFT BLANK

5-1
Alaris®Auto-ID Module
Technical Service Manual
5.1 INTRODUCTION
This chapter describes how to disassemble
and reassemble the Auto-ID Module.
The circuit boards and surface mount
devices are not field repairable. Return
circuit boards to an authorized CareFusion
Service Center for repair. Attempting circuit
board repairs voids all warranties.
For replacement part information, see the
"Illustrated Parts Breakdown" chapter.
Following any level of maintenance, perform
the applicable tests, as identified in the
"Level of Testing Guidelines" table.
Due to product changes over time,
components/assemblies illustrated in this
chapter may differ from the instrument being
serviced.
5.2 DISASSEMBLY/REASSEMBLY
The disassembly procedures in this chapter
are presented in the most efficient sequence.
To reassemble, perform the steps in reverse
order.
Before adhering gaskets and labels to the
instrument, clean the surface with a cotton
swab or soft cloth lightly dampened with 70%
Isopropyl Alcohol.
WARNING
Disconnect the Auto-ID Module from the Alaris®
System prior to performing maintenance.
The instrument case should only be opened
by qualified personnel using proper grounding
techniques.
CAUTION
CMOS devices are sensitive to static electrical
charges and may be damaged during repair if the
repair activity is not performed in an electrostatic
discharge (ESD) protected environment using
approved ESD protective procedures, including
personnel grounding.
CAUTION
To avoid the risk of an electrical hazard or
damage to the instrument circuitry, do not spray
fluids directly onto the instrument or allow fluids to
enter the instrument.
Chapter 5 – Corrective Maintenance

5-2
Corrective Maintenance
Alaris®Auto-ID Module
Technical Service Manual
Table 5-1 Required Materials, Supplies and Tools
NOTE: Contact/source information is subject to change.
• SiliconeGrease,DowCorningMolykote33, or equivalent (www.dowcorning.com)
• SmallDiagonalCutter
• PhillipsScrewdrivers
• NutDrivers
• CottonSwabs
• IsopropylAlcohol
• TorqueScrewdriverwithaminimumrangeof3-15 in-lbs. Recommend torque screwdriver, Micro-
Adjustable, TT #844SC5002 or TT #304TO034.
5.2 DISASSEMBLY/REASSEMBLY (Continued)

5-3
Corrective Maintenance
Alaris®Auto-ID Module
Technical Service Manual
5.2 DISASSEMBLY/REASSEMBLY (Continued)
5.2.1 Latch Assembly and Feet
1. Remove screws (2) attaching Latch
Assembly to bottom of Rear Case.
2. Remove Latch Assembly components
from bottom of Rear Case. Pay close
attention to Compression Spring
location to ensure proper installation
during reassembly.
3. Pull Feet (2) from underside of module.
During Reassembly:
Apply thin layer of silicone grease to Feet
before insertion. Feet press-fit into module.
Compression Spring
Foot (2 PL)
Latch
Latch Support
Leaf Spring

5-4
Corrective Maintenance
Alaris®Auto-ID Module
Technical Service Manual
5.2 DISASSEMBLY/REASSEMBLY (Continued)
5.2.2 IUI Connectors and Case Separation
1. Remove screws (2) attaching each IUI
(left and right) to module.
2. Remove IUI Connectors and Gaskets.
3. Remove screws (2) and associated
washers attaching Rear Case to Front
Case Assembly.
4. Pull Rear Case away from Front Case
Assembly.
5. If replacing Rear Case, note model/
reference number and serial number.
During Reassembly:
• Ensuregroundclipsarestillinstalledon
both IUI Connectors.
• ToinstallRightIUI Connector Gasket,
remove protective backing and adhere to
IUI Connector.
• ToinstallLeftIUI Connector Seal, position
seal on one end of connector and stretch
to other end to conform to connector
body. Gently press on seal to seat
completely. Use lint-free swab to apply
alcohol to top, sides, and bottom of seal
for lubrication while installing to Rear
Case. Do not apply alcohol to contacts or
connector.
• EnsureSiliconeTubinginRearCaseisin
place and not damaged.
• Usecarenottopinchwireswhen
reinstalling Rear Case.
• IfreplacingRearCase:
a. Use permanent black ink to print
instrument's model/reference number
and serial number on Serial Number
Replacement Label.
b. Apply Serial Number Replacement
Label to instrument.
c. Adhere transparent label over Serial
Number Replacement Label.

5-5
Corrective Maintenance
Alaris®Auto-ID Module
Technical Service Manual
READY
SCAN
CANCEL
IUI Connector, Right
IUI Connector, Left
Silicone Tubing
Front Case assembly
5.2 DISASSEMBLY/REASSEMBLY (Continued)
5.2.2 IUI Connectors and Case Separation
(Continued)
IUI Gasket
IUI Seal

5-6
Corrective Maintenance
Alaris®Auto-ID Module
Technical Service Manual
5.2 DISASSEMBLY/REASSEMBLY (Continued)
5.2.3 Speaker Assembly
1. Disconnect Speaker Assembly cable
from Logic Board J7.
2. Remove Speaker Assembly from Front
Case.
During Reassembly:
Speaker Assembly snaps into place when
installed into Front Case.
J7
Logic Board
Speaker Assembly
