Carlisle BINKS Maple 8/25 User manual

EN
Service Manual
Maple 8/25 Pump
• Model 104042
IMPORTANT! DO NOT DESTRO
Y
It is the Customer's responsibility to have all operators and service personnel read and understand this
manual.
Contact your local Carlisle Fluid Technologies representative for additional copies of this manual.
READ ALL INSTRUCTIONS BEFORE OPERATING THIS PRODUCT
77-3232 R3.2 www.carlisleft.com

EN
27/6/18
Bournemouth,BH11 9LH,UK
EU Declaration of Conformity

This Declaration of conformity / incorporation is issued under the sole responsibility of the
manufacturer:
Machinery Directive 2006/42/EC
ATEX Directive 2014/34/EU
by complying with the following statutory documents and harmonized standards:
EN ISO 12100:2010 Safety of Machinery - General Principles for Design
EN 12621:+A1:2010 Machinery for the supply and circulation of coating materials under pressure - Safety
requirements
EN 1127-1:2011 Explosive atmospheres - Explosion prevention - Basic concepts
EN 13463-1:2009 Non electrical equipment for use in potentially explosive atmospheres - Basic methods and
requirements
EN 13463-5:2011 Non electrical equipment for use in potentially explosive atmospheres - Protection by
constructional safety "c"
Providing all conditions of safe use / installation stated within the product manuals have been complied with and
also installed in accordance with any applicable local codes of practice.
Product Description / Object of Declaration: Pumps - Maple, DVP, 104009, 104010/LS, 104016,
104027, 104032, 104040/1/2, 104077, 104020,
104023, 104025, 104028/9, 106933, 104205,104149-
52, 104207-15, 104147.
This Product is designed for use with: Solvent and Water based materials
Suitable for use in hazardous area: Zone 1
Protection Level:
II 2 G X IIB T4
Notified body details and role: Element Materials Technology (0891)
Lodging of Technical file
This Declaration of conformity / incorporation
is issued under the sole responsibility of the
manufacturer:
Carlisle Fluid Technologies UK Ltd,
Ringwood Road,
Bournemouth, BH11 9LH. UK
Si
g
ned for and on behalf of Carlisle Fluid
Technologies UK Ltd:
D Smith
Director of Sales (EMEA)
77-3232 R3.2 2/20 www.carlisleft.com

EN
In this part sheet, the words WARNING, CAUTION and NOTE are used to emphasize important safety information as
follows:
WARNING CAUTION
READ THE MANUAL. Before operating finishing equipment, read and
understand all safety, operation and maintenance information
provided in the operation manual.
AUTOMATIC EQUIPMENT. Automatic
equipment may start suddenly without
warning.
WEAR SAFETY GLASSES. Failure to wear safety glasses with side
shields could result in serious eye injury or blindness. PROJECTILE HAZARD. You may be
injured by venting liquids or gases that
are released under pressure, or flying
debris.
DE-ENERGIZE, DE-PRESSURISE, DISCONNECT AND LOCK OUT ALL
POWER SOURCES DURING MAINTENANCE. Failure to de-energize,
disconnect and lock out all power supplies before performing
equipment maintenance could cause serious injury or death. KNOW WHERE AND HOW TO SHUT
OFF THE EQUIPMENT IN CASE OF AN
EMERGENCY.
NOISE LEVELS. The A-weighted sound level of pumping and spray
equipment may exceed 85 dB(A) depending on equipment settings.
Actual noise levels are available on request. It is recommended that
ear protection is worn at all times while equipment is in use.
PRESSURE RELIEF PROCEDURE.
Always follow the pressure relief
procedure in the equipment instruction
manual.
INSPECT THE EQUIPMENT DAILY. Inspect the equipment for worn or
broken parts on a daily basis. Do not operate the equipment if you
are uncertain about its condition.
HIGH PRESSURE CONSIDERATION. High pressure can cause serious
injury. Relieve all pressure before servicing. Spray from the gun,
hose leaks or ruptured components can inject fluid into your body
and cause extremely serious injury. KEEP EQUIPMENT GUARDS IN PLACE.
Do not operate the equipment if the
safety devices have been removed.
STATIC CHARGE. Fluid may develop a static charge that must be
dissipated through proper grounding of the equipment, objects to be
sprayed and alll other electrically conductive objects in the dispensing
area. Improper
g
roundin
g
or sparks can cause a hazardous condition
and result in fire, explosion or electric shock and other serious injury.
NEVER MODIFY THE EQUIPMENT. Do
not modify the equipment unless the
manufacturer provides written
approval.
OPERATOR TRAINING. All personnel
must be trained before operating
finishing equipment.
EQUIPMENT MISUSE HAZARD. Equipment misuse can cause the
equipment to rupture, malfunction or start unexpectedly and result in
serious injury. PACEMAKER WARNING. You are in the
presence of magnetic fields which may
interfere with the operation of certain
pacemakers.
PROP 65 WARNING. WARNING: This product contains chemicals
known to the state of California to cause cancer and birth defects or
other reproductive harm.
PINCH POINT HAZARD. Moving parts
can crush and cut. Pinch points are
any areas where ther are moving
parts.
IT IS THE RESPONSIBILITY OF THE EMPLOYER TO PROVIDE THIS INFORMATION TO THE
OPERATOR OF THE EQUIPMENT.
NOTE
Hazards or unsafe practices which could result in
severe personal injury, death or substantial property
damage.
Hazards or unsafe practices which could result in
minor personal injury, product or property
damage
Important installation, operation or maintenance
information.
WARNING
Read the following warnings before using this equipment.
77-3232 R3.2 3/20 www.carlisleft.com

EN
Max. Pump Fluid Inlet Pressure 2 bar [30 psi]
A
ir Quality ISO 8573.1 Class 3.3.2
Air volume / cycle @ 3.1 bar/45psi:
Air volume / cycle @ 6.2 bar/90psi:
Specification
Fluid outlet connection:
Compressed Air Inlet 1/2" BSPP / NPSM
Maximum recommended continous cycle rate [cycles/min]: 20
580 l/m [20.5 CFM]
A
ir consumption @ 30 cycles/min and 6 bar [87 psi] air inlet
pressure: 1160 l/m [41 CFM]
Maximum recommended intermittent cycle rate [cycles /
min]: 40
Fluid inlet connection:
A
ir consumption @ 15 cycles/min and 6 bar [87 psi] air inlet
pressure:
Ratio: 25:1
Maximum air inlet pressure: 7 bar [101.5 psi]
Maximum fluid pressure: 175 bar [2500 psi]
Nominal flow volume / cycle: 0.2 l/m [0.053 US gal/m]
Output @ 60 cycles / min: 12 l/m [3.2 US gal/m]
20 l/m [0.7 SCFM]
40 l/m [1.4 SCFM]
1'' Sanitary
# See Note
Weight: 42 kg / 92 lbs
1/2'' NPT Female
Dirt: 5 microns
Water: -20°C @ 7bar [940ppm]
Oil: 0.1mg/m³
# Note: Class 3.4.2 Air Quality (Refrigerant dried - water +3ºC@7bar) may be used, however, above 15
cycles/min optional heavy duty mufflers 192821 or piped exhaust system should be used, if used continuously.
77-3232 R3.2 4/20 www.carlisleft.com

EN
Dimensions and Mounting Details
MOUNTING LOCATIONS
SECTION A-A
1" Sanitary inlet
1/2'' NPT Outlet Connection
EARTHING POINT
AIR INLET
77-3232 R3.2 5/20 www.carlisleft.com

EN
This product should be flushed with a suitable compatible solvent prior to use.
Installation
Mount the pump securely and position the pump at a convenient height (below the lid height of the
paint container), to allow for maintenance, visual observation, and periodic inspection.
The wall mount bracket is included with all pumps.
The Pump Mounting bracket must be connected to a suitable earth ground to ensure that there is no
possibility of static build up.
Attach suitable flexible hoses to the inlet and outlet connections.
Connect a suitable 1/2" NB air hose and 1/2” Pressure Filter Regulator to the air motor.
(Filter rated at minimum 1500 l/min)
No additional air lubrication is required as piston ring lubricant is applied during assembly or repair.
If an air lubricator is used then this must be maintained.
77-3232 R3.2 6/20 www.carlisleft.com

EN
Installation
Set the pump speed to a slow cycle rate and prime the pump to remove any air before increasing
pressure.
Inspect for any air or fluid leaks.
Set the pump cycle rate to achieve the required paint volume and then adjust the system back
pressure regulator and pump air pressure to achieve the desired system fluid pressure.
A Back Pressure Regulator should be mounted in the paint system return line.
The return line ‘back pressure’ regulator responds to the changes in system fluid flow demand, (due to
variable paint usage) by dynamically adjusting the paint flow rate returning to the system paint tank,
thus maintaining the set pressure.
If an air blow out system is used, never exceed 2 bar [29 psi] on the inlet of the pump.
Exhaust kits are available for these pumps if the air exhaust is required to be piped away from the
pump rather than exhausting locally through the mufflers.
77-3232 R3.2 7/20 www.carlisleft.com

EN
2
2
8
10
2
1
1
2
1
2
2
2
2
2
2
1
1
PISTON SEAL
193367 OUTLET CONNECTION
193369 INLET CYLINDER
193370 OUTLET CYLINDER
193425 OUTLET MANIFOLD
193706 AIR MOTOR ASSEMBLY
193195
2192206
NAMEPLATE
M10 SPRING WASHER
M12 SPRING WASHER
Ø2 x 4.75 RIVET
INLET MANIFOLD
193185 PISTON ASSEMBLY
193190 OUTLET SEAT
5165948 10
171714
177119
192009
192147
192816

21
ITEM QTY REMARKS
4
3
PART NO. DESCRIPTION
165044
165123
1648382
19
20
9
6
7
82

18
8
12
14
11
13
15
16 #
17
192821
192834
10
1'' MUFFLER
1'' SANITARY GASKET
BINKS NAMEPLATE
M12 x 65 SOCKET HEAD CAP SCREW
3/4'' BALL
1'' x 1½'' SANITARY CLAMP
Parts list - Pump Assembly
1162746 Ø25.5 x 2 O-RING 
M10 x 40 SOCKET HEAD CAP SCREW
77-3232 R3.2 8/20 www.carlisleft.com

EN
Pump Assembly
KEY
= LOCTITE
= TORQUE
= MAINTENANCE ORDER
(Reverse for assembly)
= GREASE INTERNAL
(AGMD-010)
= GREASE
(AGMD-010)
77-3232 R3.2 9/20 www.carlisleft.com

EN
2
2
2
20
4
18
2
2
2
1
2
2
2
7
2
1
16199434

DESCRIPTION

165963
7165108
12
ITEM PART NO.
CYLINDER STUD
192799
QTY REMARKS
16 192883
19281514

9
2



18 192888
19
10115-010037 POPPET ASSEMBLY
4
10 165965 4
11
5
AIR CYLINDER
192881
162729
#
BELLOWS SPACER
25
192906 PUMP BRACKET
6
8165135
192887
193094
2161993
SHAFT SEAL
162730
162731
SHAFT BEARING

2
26
1AIR VALVE ASSEMBLY
24 193240 EXHAUST ADAPTER
13 192814 BELLOWS LEAK DETECTION HOSE
PUSH IN ELBOW
KNIFED BELLOWS
1AIR MOTOR PISTON ASSY194983
193605
RETAINING NUT
15
1
#
Ø4.47 x 1.78 O-RING
Ø20.35 x 1.78 O-RING
M8 DOME NUT
M10 PLAIN WASHER
M8 SPRING WASHER
Ø230 x 3 O-RING
M8 x 70 SOCKET HEAD CAP SCREW
M10 x 16 HEX HEAD CAP SCREW
20
177010 2
VENT PLUG
1
END PLATE MACHINING
19323823
1
END PLATE MACHINING
19323722
Parts list - Air Motor Assembly
17
21 193095 CYLINDER STUD - LONG
77-3232 R3.2 10/20 www.carlisleft.com

EN
ITEM 4 DETAIL
KEY
= LOCTITE
= TORQUE
= MAINTENANCE ORDER
(Reverse for assembly)
= GREASE INTERNAL
(AGMD-010)
= GREASE
(AGMD-010)
77-3232 R3.2 11/20 www.carlisleft.com

EN
2
1
Air Motor Piston Assembly
3192882 PISTON SHAFT
4192886 PISTON
ITEM PART NO. DESCRIPTION QTY REMARKS
2
AIR MOTOR PISTON SEAL

M16 x 60 GRUB SCREW 1165975
11162728
KEY
= LOCTITE
= TORQUE
= MAINTENANCE ORDER
(Reverse for assembly)
= GREASE INTERNAL
(AGMD-010)
= GREASE
(AGMD-010)
77-3232 R3.2 12/20 www.carlisleft.com

EN
2
2
2
2
1
1
1
1
QEV PISTON

20115-0104635
2
QEV CARTRIDGE
19324111
BUMPER

4 0115-010431 SPACER
Air Valve Assembly
7 162767

1 2VALVE BLOCK END CAP0115-010425
M6 x 16 BUTTON HEAD CAP SCREW163951
6
Ø30 x 2 O-RING

2
Ø47.29 x 2.62 O-RING
9 192651
10 0115-010424
SPOOL AND SLEEVE ASSEMBLY #
12 193243
13 193244

MAIN VALVE BODY ASSY.
119360614
AIR INLET CONNECTION
AIR EXHAUST GASKET
PLUG 1/8'' BSPP
ITEM PART NO. DESCRIPTION QTY REMARKS
8
1627196
3 0115-010428 MAGNET
2 0115-010427
= MAGNET HAZARD
KEY
= LOCTITE
= TORQUE
= MAINTENANCE ORDER
(Reverse for assembly)
= GREASE INTERNAL
(AGMD-010)
= GREASE
(AGMD-010)
77-3232 R3.2 13/20 www.carlisleft.com

EN
1
1
1
1
1
1
1
1
Ø46 FLUID PISTON
PISTON BALL CHECK SPRING
1605261
1

3162744

4162745

5193181

6193186
Fluid Piston Assembly
ITEM PART NO. DESCRIPTION QTY REMARKS
2162743

Ø7/8'' BALL
Ø29.9 x 1.78 O-RING
Ø23.52 x 1.78 O-RING
Ø33 x 2 O-RING
7193187
PISTON KEEP
8193188

9193189
SEAT
INLET SPRING KEEP
KEY
= LOCTITE
= TORQUE
= MAINTENANCE ORDER
(Reverse for assembly)
= GREASE INTERNAL
(AGMD-010)
= GREASE
(AGMD-010)
77-3232 R3.2 14/20 www.carlisleft.com

EN
Fault Finding
Symptom Possible Cause Remedy
Pump will not ‘Prime’
Air entering the suction hose/manifold Check seals and hose connections.
Worn piston seals Replace piston seals.
Ball checks not seating correctly. Inspect, clean and/or replace balls
and seats.
Pump will not run
No Air or Fluid supply Check air and fluid supply ball valves
and supply hoses.
Air piston seal worn. Replace piston seal.
QE cup defective.
Check for constant exhaust air when
pump is not running.
Check/replace QE cups.
Ball checks not seating correctly. Inspect, clean and/or replace balls
and seats.
Pump runs but has
excessive pulsation.
Air getting into fluid line, air supply restricted. Check seals and hose connections.
Check air supply
Obstructed fluid ball checks.
Remove, clean, and inspect seat,
ball, and ball cage.
Replace if suspect or worn.
Pilot valve assemblies inoperable.
Switch/interchange pilot valves to
isolate faulty pilot valve and
clean/replace.
Check clean/replace Air valve.
77-3232 R3.2 15/20 www.carlisleft.com

EN
Worn air motor piston seals.
Check QE cups and exhaust outlets.
Paint leaking into
detection hose, Air
bleeding from vent
plug
Bellows seal failure Replace bellows seal
Air motor shaft seal leaking Check air motor shaft seal replace as
necessary
Symptom Possible Cause Remedy
Pump runs but has
excessive pulsation.
Fault Finding
Worn/failed air motor shaft seals. Disassemble pump as required to
replace air motor shaft seals.
Worn fluid piston seal. Replace fluid piston seal.
Air exhaust restricted.
Replace air motor piston seal.
77-3232 R3.2 16/20 www.carlisleft.com

EN
1
Perform a pump stall test to ensure correct operation
If pump does not stall check fluid piston seals and ball checks replace as required
If air is escaping through exhaust check air motor piston seal and quick exhaust
diaphragm replace as required
6 Month Test
Inspect Pump for Correct operation
Check for any excessive mechanical noise
Check for excessive fluid pressure pulsation
Weekly
Maintenance schedule
Inspection Operation
Daily Check for any general fluid or air leakage
Replace air piston seal
Replace shaft seals & bearings
Inspect and replace if required: Pilot Air Valves & Main Air Valve Parts
Replace fluid piston seal
Replace Balls, Seats and Bellows
12 to 36 Months (Typically 10
million pump cycles
dependant on air quality and
abrasiveness of the paint
used)
1
1 1 off per pump
# 0115-010424 Main Spool & Sleeve Valve Assembly
1Fluid overhaul kit
250654
# - Recommended spare parts for continually running pumps
2 off per pump
1
Poppet Assembly
0115-010037#
# 192881 Knifed Bellows 1 2 off per pump
2 off per pump1Piston seal
193195#
Spares Kits for Maple 8/25 Pump
KIT No. PART NO. DESCRIPTION QTY REMARKS
250653 Fluid section seal kit
Check main parts list for
details of individual kit
contents
250656
Air Motor Seal Kit
77-3232 R3.2 17/20 www.carlisleft.com

EN
1
Smear loctite 572 over nose of bellows,
thread nut onto bellows ensuring the thread
starts squarely.
Grip bellows lightly by hand and tighten the
nut with a 32mm A/F spanner until the nut
contacts the bellows shoulder.
Bellows Replacement
ITEM
502382
1
2
1 502377 Bellows positioning tool
PART NO. DESCRIPTION QTY
Bellows assembly spigot
REMARKS
Screw Item No. 2 (assembly spi
g
ot) onto the
piston shaft
Using Item No. 1, push bellows over spigot
until located in groove.
12
77-3232 R3.2 18/20 www.carlisleft.com

EN
1'' Sanitary Gasket
1'' Sanitary - 3/4'' NPT (f) Adapter
1'' Sanitary - 1'' NPT (f) Adapter
1 & 1½'' Sanitary Clamp
1'' Manifold Plug
50g Tube
192820 For piped exhaust
502608 For Shaft seal (162729)
502377 Bellows Positioning Tool
AGMD-010 Kluber Isoflex Topas NB 52 Grease
193275
Seal Insertion Tool
Accessories
192803 For piped exhaust
502382
Exhaust Tube Adapter [1.25” NB hose]
Bellows assembly spigot
Exhaust Tube Adapter [1” NB hose] For piped exhaust
192779
194281
ITEM PART NO. QTY
192206
192009
77-3232 R3.2 19/20 www.carlisleft.com

EN
BGK™, Binks®, DeVilbiss®, Hosco®, MS®, and Ransburg® are registered trademarks of Carlisle
Fluid Technologies, Inc.
© 2020 Carlisle Fluid Technologies,Inc.
Americas
Tel: [phone]
Fax: [phone]
Tel: [phone]
Fax: [phone]
Europe, Africa,
Middle East,
India
Tel: [phone]
Fax: [phone]
China
Tel: [phone]
Fax: [phone]
Japan
WARRANTY POLICY
This product is covered by Carlisle Fluid Technologies’ materials and workmanship limited
warranty. The use of any parts or accessories, from a source other than Carlisle Fluid
Technologies, will void all warranties. Failure to reasonably follow any maintenance guidance
provided, may invalidate any warranty.
For specific warranty information please contact Carlisle Fluid Technologies.
Tel: [phone]
Fax: [phone]
Australia
Tel: [phone]
Fax: [phone]
For the latest information about our products, visit www.carlisleft.com
Carlisle Fluid Technologies is a global leader in innovative finishing technologies.Carlisle Fluid
Technologies reserves the right to modify equipment specifications without prior notice.
All rights reserved.
For technical assistance or to locate an authorised distributor, contact one of our international sales and customer
support locations below.
Region Industrial / Automotive Automotive Refinishing
77-3232 R3.2 20/20 www.carlisleft.com
