Carriage House CycleWorks TrikeTable User manual

Additional Adjustments
Front Width Adjustment
The front cradles arrive pre-
installed at a stable, wide width.
For trikes with narrow widths,
the front cradle posts can be
adjusted inward by loosening
the adjusng nuts on each front
slider. Move the sliders into the
desired posion and ghten.
Warranty/Disclaimer
The TrikeTable is covered by a lifeme warranty against defects in
material or workmanship. TrikeTables or their components that
become worn through normal use or damaged byaccident, abuse or
modificaon will not be covered under warranty. This warranty does
not cover consequenal damage or cost of injury incurred by the
user.
Servicing and repairing recumbent trikes cansomemes be
dangerous. CarriageHouse CycleWorks, LLC. is not responsiblefor
any injuries and/or damage causedby or during the use of a
TrikeTable.
TrikeTable
by Carriage House CycleWorks, LLC
Assembly & User Guide
chcycleworks.com
[e-mail]
RIKE
ABLE
Height Adjustment
If the TrikeTable isplacedon a large
surface, like a large table, the frame
cradles are height adjustable. Loosen
the tube clamps and raise the cradles
as needed but always keep about 2"
inserted in the lower tube.

Using your TrikeTable
Placement
TheTrikeTable isdesigned to be placed on a flat
surface that supports the enre base of the stand.
Securing your trike
Loosen the rear adusng
knoba turn or two.
Rotate front cradles to fit
angle of frame and set trike
in the cradles.
Rest the trike in the rear
frame cradle and ghten
the rear adjusng knob.
If necessary, use the included bungee to secure the main frame of
the trike to the stand.
Raise the rear of the trike.
Adjust the sliding frame
cradle to an open spot on
the trike frame.
Cleaning & Care
Servicing and repairing recumbent trikes can be messy
so don’t worry about geng the TrikeTable dirty. The
TrikeTable uses a durable finish and stainless fasteners
to resist corrosion. Occasionally, remove any debris or
oils from the stand using a dish soap and warm water.
Assembling your TrikeTable
Tools Required
4mm Hex Key 5mm Hex Key 10mm Wrench
Step 1
Step 2
Step 3
Choose Orientaon
& Align Holes
Aach Joining Plate
Install Frame Cradle
Posts
Use the joining plate and
the 4 included fastener
assemblies to join the base
secons with a5mm hex
key and 10mm wrench.
Slide each of the 3frame
cradle posts in the lower
posts and ghten the tube
clamp with a4mm hexkey.
For tadpole-style trikes
(2 wheels in front), use
Posion A. For delta-style
trikes (1 wheel in front),
use Posion B.
1
3
2
4
A
B
