Carrier 25HBC3 Series Operation manual

25HBC3
Base 13 Heat Pump
with PuronrRefrigerant
1 --- 1 / 2 t o 5 N o m i n a l To n s
Product Data
the environmentally sound refrigerant
Carrier heat pumps with Puronrrefrigerant provide a collection of
features unmatched by any other family of equipment. The 25HBC
has been designed utilizing Carrier’s Puron refrigerant. The
environmentally sound refrigerant allows consumers to make a
responsible decision in the protection of the earth’s ozone layer.
As an Energy StarrPartner, Carrier Corporation has determined
that this product meets the Energy Starrguidelines for energy
efficiency. Refer to the combination ratings in the Product Data for
system combinations that meet Energy Starrguidelines.
NOTE:Ratings contained in this document are subject to
change at any time. Always refer to the AHRI directory
(www.ahridirectory.org) for the most up--to--date ratings
information.
INDUSTRY LEADING
FEATURES / BENEFITS
Efficiency
S13 SEER/ 10.5 -- 12.5 EER/ 7.7 -- 8.2 HSPF
SMicrotube Technologytrefrigeration system
SIndoor air quality accessories available
Sound
SSound level as low as 72 dBA
SSound levels as low as 72 dBA with accessory sound blanket
Comfort
SSystem supports EdgerThermidistattor standard thermostat
controls
Reliability
SPuronrrefrigerant -- environmentally sound, won’t deplete the
ozone layer and low lifetime service cost.
SScroll compressor
SInternal pressure relief valve
SInternal thermal overload
SHigh pressure switch
SLoss of charge switch
SFilter drier
SBalanced refrigeration system for maximum reliability
Durability
WeatherArmortprotection package:
SSolid, durable sheet metal construction
SDense wire coil guard available
(3--phase units come standard with dense wire coil guard)
SBaked--on powder paint
Applications
SLong--line -- up to 250 feet (76.20 m) total equivalent length, up
to 200 feet (60.96 m) condenser above evaporator, or up to 80 ft.
(24.38 m) evaporator above condenser (See Longline Guide for
more information.)
SLow ambient (down to --20_F/--28.9_C) with accessory kit

2
MODEL NUMBER NOMENCLATURE
12345678910111213
N N A A A/N N N N A/N A/N A/N N N
25 H B C 3 36 A 0 0 3 0
Product
Series
Product
Family Tier Major Series SEER Cooling Capacity
Grille
Variations Open Open Voltage Minor Series
25 = HP H = RES HP B=Base C = Puron 3=13 SEER A=Dense Grille
W=Wide Grille
0=Not
Defined
0=Not
Defined
3=208/230---1
5=208/230---3
6=460/3
0, 1, 2...
the environmentally sound refrigerant
REGISTERED
ISO 9001:2000
This product has been designed and manufactured to
meet Energy Star®criteria for energy efficiency when
matched with appropriate coil components. However,
proper refrigerant charge and proper air flow are critical
to achieve rated capacity and efficiency. Installation of
this product should follow all manufacturing refrigerant
charging and air flow instructions. Failure to confirm
proper charge and air flow may reduce energy
efficiency and shorten equipment life.
Use of the AHRI Certified
TM Mark indicates a
manufacturer’s
participation in the
program For verification
of certification for individual
products, go to
www.ahridirectory.org.
STANDARD FEATURES
Feature 18 24 30 36 42 48 60
Puron Refrigerant XXXXXXX
Maximum SEER Rating 14.5 14.5 14.0 14.5 15.0 14.5 14.0
Scroll Compressor XXXXXXX
FieldInstalledFilterDrier XXXXXXX
Front Seating Service Valves XXXXXXX
Internal Pressure Relief Valve XXXXXXX
Internal Thermal Overload XXXXXXX
Long Line capability XXXXXXX
Low Ambient capability with Kit XXXXXXX
Suction Line Accumulator XXXXXXX
High Pressure Switch XXXXXXX
Loss of Charge Switch XXXXXXX
X=Standard
25HBC3

3
PHYSICAL DATA
UNIT SIZE SERIES 18 --- 30 24 --- 30 30 --- 30, 50 36--- 30, 50,
60 42 --- 30, 50 48--- 30, 50, 60 60--- 30, 50, 60
Operating Weight lb (kg) 127
(57.6)
133
(60.3)
146
(66.2)
152
(69.0)
193
(87.5)
216
(98.0)
250
(113.4)
Shipping Weight lb (kg) 153
(69.4)
158
(77.6)
180
(81.6)
178
(80.7)
229
(103.8)
251
(113.8)
282
(127.9)
Compressor Type Scroll
REFRIGERANT Puron (R---410A)
Indoor Control Piston
52
Piston
57
Piston
67
Piston
70
Piston
76
Piston
80
TXV
(Puron Hard
Shutoff)
Outdoor Heating Piston # 40 46 55 57 65 65 76
Charge lb (kg) 5.16
(2.34)
5.95
(2.70)
6.40
(2.90)
6.34
(2.88)
8.88
(4.03)
10.41
(4.72)
11.00
(4.99)
COND FAN Propeller Type, Direct Drive
Air Discharge Vertical
Air Qty (CFM) 1881 2196 3167 3167 2614 3365 4046
Motor HP 1/12 1/10 1/5 1/5 1/10 1/4 1/4
Motor RPM 1100 1100 1100 1100 1100 1100 800
COND COIL
Face Area (Sq ft) 11.49 13.13 15.09 17.25 15.09 19.40 17.60
Fins per In. 25 25 20 20 20 20 20
Rows 1 1 1 1 2 2 2
Circuits 4 4 5 5 6 8 8
VALVE CONNECT. (In.) ID
Vapor 5/8 5/8 3/4 3/4 7/8 7/8 7/8
Liquid 3/8
REFRIGERANT TUBES* (In.) OD
Rated Vapor* 5/8 5/8 3/4 3/4 7/8 7/8 1 --- 1 / 8
Liquid 3/8”
*Units are rated with 25 ft (7.6 m) of lineset length. See Vapor Line Sizing and Cooling Capacity Loss table when using other sizes and lengths of lineset.
Note: See unit Installation Instruction for proper installation.
VAPOR LINE SIZING AND COOLING CAPACITY LOSS
Acceptable vapor line diameters provide adequate oil return to the compressor while avoiding excessive capacity loss. The suction line
diameters shown in the chart below are acceptable for HP systems with Puron refrigerant:
Vapor Line Sizing and Cooling Capacity Losses -- PuronrRefrigerant 1-- Stage Heat Pump Applications
Unit
Nominal
Size (Btuh)
Maximum
Liquid Line
Diameters
(In. OD)
Vapor Line
Diameters
(In.) OD
Cooling Capacity Loss (%)
Total Equivalent Line Length ft. (m)
Standard
Application Long Line Application Requires Accessories
26 --- 50
(7.9---15.2)
51 --- 80
(15.5---24.4)
81 --- 100
(24.7---30.5)
101 --- 125
(30.8---38.1)
126 --- 150
(38.4---45.7)
151 --- 175
(46.0---50.3)
176 --- 200
(53.6---60.0)
201 --- 225
(61.3---68.6)
226 --- 250
(68.9---76.2)
18,000
1 --- S t a g e
HP with
Puron
3/8
1/2 1 2 3 4 6 7 8 9 10
5/8 0 0 1 1 1 2 2 3 3
24,000
1 --- S t a g e
HP with
Puron
3/8
5/8 0 1 1 2 3 3 4 4 5
3/4 0 0 0 0 1 1 1 1 1
30,000
1 --- S t a g e
HP with
Puron
3/8
5/8 1 2 3 3 4 5 6 7 8
3/4 0 0 1 1 1 2 2 2 3
7/8 0 0 0 0 1 1 1 1 1
36,000
1 --- S t a g e
HP with
Puron
3/8
5/8 1 2 4 5 6 7 9 10 11
3/4 0 0 1 1 2 2 3 3 4
7/8 0 0 0 0 1 1 1 1 2
42,000
1 --- S t a g e
HP with
Puron
3/8
3/4 0 1 2 2 3 4 4 5 6
7/8 0 0 1 1 1 2 2 2 3
48,000
1 --- S t a g e
HP with
Puron
3/8
3/4 0 1 2 3 4 5 5 6 7
7/8 0 0 1 1 2 2 2 3 3
60,000
1 --- S t a g e
HP with
Puron
3/8
3/4 1 2 4 5 6 7 9 10 11
7/8 0 1 2 2 3 4 4 5 5
1 --- 1 / 8 0 0 0 1 1 1 1 1 1
Standard Length = 80 ft. (24.4 m) or less total equivalent length
Applications in this area are long line. Accessories are required as shown recommended on Long Line Application Guidelines
Applications in this area may have height restrictions that limit allowable total equivalent length, when outdoor unit is below indoor unit See Long Line Applica-
tion Guidelines
25HBC3

4
REFRIGERANT PIPING LENGTH LIMITATIONS
Maximum Line Lengths:
The maximum allowable total equivalent length for heat pumps varies depending on the vertical separation. See the tables below for
allowable lengths depending on whether the outdoor unit is on the same level, above or below the outdoor unit.
Maximum Line Lengths for Heat Pump Applications
MAXIMUM ACTUAL LENGTH
ft (m)
MAXIMUM EQUIVALENT LENGTH{
ft (m)
MAXIMUM VERTICAL
SEPARATION ft (m)
Units on equal level 200 (61) 250 (76.2) N/A
Outdoor unit ABOVE
indoor unit 200 (61) 250 (76.2) 200 (61)
Outdoor unit BELOW
indoor unit See Table ’Maximum Total Equivalent Length: Outdoor Unit BELOW Indoor Unit’
{Total equivalent length accounts for losses due to elbows or fitting. See the Long Line Guideline for details.
Maximum Total Equivalent Length{-- Outdoor Unit BELOW Indoor Unit
Size
Liquid Line
Diameter
w/ TXV
HP with PuronrRefrigerant --- Maximum Total Equivalent Length{
Vertical Separation ft (m) Outdoor unit BELOW indoor unit;
0 --- 2 0
(0 --- 6.1)
21 --- 30
(6.4 --- 9.1)
31 --- 40
(9.4 --- 12.2)
41 --- 50
(12.5 --- 15.2)
51 --- 60
(15.5 --- 18.3)
61 --- 70
(18.6 --- 21.3)
71 --- 80
(21.6 --- 24.4)
18000
HP with
Puron
3/8 250* 250* 250* 250* 250* 250* 250*
24000
HP with
Puron
3/8 250* 250* 250* 250* 250* 250* 250*
30000
HP with
Puron
3/8 250* 250* 250* 250* 250* 250* 250*
36000
HP with
Puron
3/8 250* 250* 250* 250* 250* 250* 250*
42000
HP with
Puron
3/8 250* 250* 250* 250* 250* 250* 150
48000
HP with
Puron
3/8 250* 250* 250* 250* 230 160 --- ---
60000
HP with
Puron
3/8 250* 225* 190 150 110 --- --- --- ---
* Maximum actual length not to exceed 200 ft (61 m)
{Total equivalent length accounts for losses due to elbows or fitting. See the Long Line Guideline for details.
--- --- = o u t s i d e a c c e p t a b l e r a n g e
LONG LINE APPLICATIONS
An application is considered Long Line when the refrigerant level in the system requires the use of accessories to maintain acceptable
refrigerant management for systems reliability. Defining a system as long line depends on the liquid line diameter, actual length of the tubing,
and vertical separation between the indoor and outdoor units.
For Heat Pump systems, the chart below shows when an application is considered Long Line. Beyond these lengths, long line accessories
are required:
HP WITH PURONrREFRIGERANT LONG LINE DESCRIPTION ft (m)
Beyond these lengths, long line accessories are required
Liquid Line Size Units On Same Level Outdoor Below Indoor Outdoor Above Indoor
3/8 80 (24.4) 20 (6.1) vertical or 80 (24.4) total 80 (24.4)
Note: SeeLongLineGuidelinefordetails
25HBC3

5
ACCESSORIES
ORDER NUMBER DESCRIPTION 18--- 30 24---30 30--- 30 30--- 50 36---30 36--- 50 36--- 60 42---30 42--- 50 48--- 30 48--- 50 48--- 60 60--- 30,
50 60--- 60
HC32GE234 BALL BEARING MOTOR X
HC34GE239 BALL BEARING MOTOR X
HC36GE219 BALL BEARING MOTOR X X X X
HC34GE240 BALL BEARING MOTOR X X
HC38GE232 BALL BEARING MOTOR
HC38GE461 BALL BEARING MOTOR X
HC38GE228 BALL BEARING MOTOR
HC40GE226 BALL BEARING MOTOR X X
HC40GE466 BALL BEARING MOTOR X
HC40GE228 BALL BEARING MOTOR X
HC40GE467 BALL BEARING MOTOR X
KAACH1701AAA CRANKCASE HTR X X X X
KAACH1601AAA CRANKCASE HTR X
STANDARD CRANKCASE HTR S SS SSSSSS
KSACY0101AAA CYCLE PROTECTOR X X X X X X X X X X X X X X
KAAFT0101AAA FREEZE THERMOSTAT X X X X X X X X X X X X X X
KSAHS1701AAA HARD START X X X X X X X X X X X X X X
KHAIR0101AAA ISOLATION RELAY X X X X X X X X X X X X X X
KSALA0301410 LOW AMBIENT PSW X X X X X X X X X X X X X X
KSALA0601AAA{MOTORMASTER 230V X X X X X X X X X X X X X X
KHAOT0201SEC OUTDOOR THERMOSTAT X X X X X X X X X X X X X X
KHAOT0301FST OUTDOOR THERMOSTAT X X X X X X X X X X X X X X
KHALS0401LLS SOLENOID VALVE X X X X X X X X X X X X X X
KHASS0606MPK* SNOW STAND RACK XXXXXXXXXXXXX
KSASH0601COP SOUND BLKT X X X X X X X X X X X X
KSASH2101COP SOUND BLKT X X
KAACS0201PTC STARTASSISTPTC X X X X X X X X X X X X X X
KSASF0101AAA SUPPORT FEET X X X X X X X X X X X X X X
KAATD0101TDR TIME DELAY RELAY X X X X X X X X X X X X X X
KSATX0201PUR TXV PURON HSO XXXX
KSATX0301PUR TXV PURON HSO XXXXX
KSATX0401PUR TXV PURON HSO XXX
KSATX0501PUR TXV PURON HSO X X
x = Accessory S = Standard
*AvailablethroughRCD
{Required accessories include ball bearing fan motor, compressor start assist (CAP / Relay), crankcase heater, evaporator freeze stat, isolation relay, hard
shut---off TXV or liquid line solenoid valve.
ACCESSORY THERMOSTATS
THERMOSTAT / SUBBASE
PKG. DESCRIPTION
T P --- P R H 0 1 --- A Programmable Thermidistat
T P --- N R H 0 1 --- A Non---programmable Thermidistat
TP---PHP01 Performance Series Programmable HP Stat
T P --- N H P 0 1 Performance Series Non---programmable HP Stat
TC---PHP01 Comfort Series Programmable HP Stat
T C --- N H P 0 1 Comfort Series Non ---programmable HP Stat
TB---PHP01 Base Series Programmable HP Stat
T B --- N H P 0 1 Base Series Non--- programmable HP Stat
TSTATXXSEN01---B* Outdoor Air Temperature Sensor
TSTATXXNBP01 Backplate for Non---Programmable Thermostat
TSTATXXPBP01 Backplate for Programmable Thermostat and ThermidistattControl
TSTATXXSBP01 Backplate for Standard Programmable Thermostat
TSTATXXBBP01 Backplate for Builder’s Thermostat
TSTATXXCNV10{Thermostat Conversion Kit (4 to 5 Wire) — 10 Pack
* Outdoor temperature sensor is an accessory for all Carrier electronic thermostats, except the non ---programmable air conditioner version and builders
thermostats. It allows the temperature at a remote location (outdoors) to be displayed on the thermostat. The outdoor air temperature sensor must be used
with the HybridHeatt(dual fuel) thermostat.
{Thermostat conversion kit is a 24---vac accessory that can turn a 4 ---wire thermostat application into a 5 ---wire application. This kit can also be used to
replace a broken thermostat wire, or add an extra wire when needed.
The outdoor air temperature sensor is included with the Thermidistat Control and HybridHeatt(dual fuel) thermostat.
25HBC3
