Carrier SYNERGY 2000 38YDA Operation manual

Product
Data
SYNERGY 2000
38YDA (60 Hz)
Two-Speed Electric
Heat Pump
Sizes 036, 048, and 060
Copyright 1997 Carrier Corporation Form 38YDA-3PD
Model 38YDA Heat Pumps
incorporate innovative 2-speed
compressor technology to provide
quiet, efficient summer cooling and
winter heating performance. Built into
theseunitsarefeaturesmost desired by
homeowners today, including SEER
ratings up to 16.1 and HSPF of 8.8
when used with the components
designated by the manufacturer. All
models are UL, c-UL, and CSA-EEV
approved.PerformanceratingsareARI
and CEC listed.
FEATURES/BENEFITS
Electrical Range — All units are
offered in 208/230v single phase.
Simplified field-stripped lead wire
connections facilitate ease of
installation.
Range of Sizes — Available in
3 nominal sizes 036, 048, and 060 to
meet the needs of residential
applications.
Weather-Armor II Cabinet — Steel
isgalvanizedand coatedwith alayer of
zinc phosphate. A coat of modified
polyester powder coating is then
applied and baked on providing each
unitwitha hard,smoothfinish that will
last for many years.
All screws on the cabinet exterior are
ceramic coated for a long-lasting, rust-
resistant, high-quality appearance.
Unit Design — The coil incorporates
copper tubing and enhanced,
aluminum fins for optimum heat
transfer. Hot condenser air and sound
are discharged vertically and away
from adjacent patio areas and foliage
through the top. Polymer spacers raise
the coil in a deep draw-style basepan
for easy removal of water, dirt, and
debris.

2
An electronic ICM fan motor provides
multispeed operation and enhanced
low-speed efficiencies and sound
levels.
Auto-reset high- and low-pressure
switches continuously monitor system
operation.
Mechanical and electrical interlocks
between the low- and high-speed
contactors eliminate the potential of
compressor motor burnout due to
contactor malfunction.
A compressor crankcase heater,
energized at the proper temperature
during the compressor off cycle, helps
to provide reliable starting.
Application Versatility — The
38YDA can be combined with a wide
variety of evaporator coils, fan coils,
and furnaces to provide quiet,
dependable comfort. Unit can be
installed on a roof or at ground level on
a slab.
External Service Valves — Both
service valves are brass, back seating
type with sweat connections. Valves
are externally located so refrigerant
connections can be made quickly and
easily.Eachvalvehasaservice port for
ease of checking operating refrigerant
pressures.
Easy Serviceability — Removal of
access panel and control box cover
provides easy access to all electrical
controlsandcompressor.Removaloftop
provides access to fan motor and coil.
A self-diagnostic indicator on the
electronic control board informs the
service technician of the problem area.
Compressor Protection — Each
compressor is protected with internal
PTC-type overloads. An internal
pressure relief valve provides high-
pressure protection to the refrigerant
system.
Standard Features — An electronic
control eliminates excessive wiring,
and features selectable second-stage
latching, TimeGuard II® short cycle
protection,amalfunctionoutput signal
to the indoor thermostat, built in
Optimizer II®, zoning interface, and
outdoor thermostat for auxiliary heat
staging.
A compressor sound hood and
discharge muffler provide improved
sound power levels as well as sound
quality.
Compressor Quick Start —
Capacitor and relay.
Thermostatic Expansion Valve —
This unit must be installed with a TXV
on the indoor coil. The FK4 and FC4
indoorfancoilscomefactory equipped
with a bi-flow TXV. When installed in
this application, no further change is
required. If any other indoor fan coil or
furnace coil is used, an accessory
bi-flow TXV must be installed. See
accessory list in this publication for
correct part number. TXV is not
shipped with unit.
Limited Warranty — One-year
limited warranty on all parts with an
extended second-year warranty on the
control board and extended second-
throughtenth-yearlimited warrantyon
the compressor. Refer to warranty
certificate for specific details.
Model number nomenclature
38YDA 036
Electric Heat Pump
Nominal Capacity
036 — 36,000 Btuh
048 — 48,000 Btuh
060 — 60,000 Btuh
301
Packaging
Series
Electrical
3 — 208/230-1
M
A
N
U
F
A
C
T
U
R
E
R
C
E
R
T
I
F
I
E
D
T
O
A
R
I
A
S
C
O
M
P
L
Y
I
N
G
W
I
T
H
A
R
I
S
T
A
N
D
A
R
D
2
4
0
U
N
I
T
A
R
Y
H
E
A
T
P
U
M
P
E
Q
U
I
P
M
E
N
T
®
CERTIFICATION OF MANUFACTURING SITE. CERTIFICATION APPLIES ONLY
WHENTHE COMPLETE SYSTEM
IS LISTED WITH ARI.
As an ENERGY STAR
SM
Partner, Carrier Corporation
has determined that this
product meets the ENERGY
STAR guidelines for energy
efficiency.

3
Physical data
* Tube sizes are for runs up to 100 ft. Maximum tube set length is 100 ft.
NOTE: See unit Installation Instructions for proper installation.
Accessories
Accessory description and usage (Listed alphabetically)
1. Filter Drier — Bi-flow
A device for removing contaminants from refrigerant circulating in a heat pump system: 2-direction flow.
SUGGESTED USE: Split-system heat pumps.
2. Snow Stand
Coated wire rack which supports unit 18 in. above mounting pad to allow for drainage from unit base.
SUGGESTED USE: Heat pump installations in heavy snowfall areas.
Heat pump installations in snowdrift locations.
Heat pump installations in areas of prolonged subfreezing temperatures.
All commercial installations.
3. Support Feet
Four stick-on plastic feet which raise the unit 4 in. above the mounting pad. This allows sand, dirt, and other debris to be flushed from the unit base;
minimizes corrosion.
SUGGESTED USE: Coastal installations.
Windy areas or where debris is normally circulating.
Rooftop installations.
4. Thermostatic Expansion Valve (TXV) — Bi-Flow
A modulating flow-control valve which meters refrigerant liquid flow rate into the evaporator in response to the superheat of the refrigerant gas leaving the
evaporator. Kit includes valve, adapter tubes, and external equalizer tube. Both hard shutoff and RBP valves are available.
SUGGESTED USE: For improved system performance in cooling mode for certain combinations of indoor and outdoor units. Refer to ARI Unitary Directory.
Required for use on all zoning applications.
UNIT SIZE-SERIES 036-30 048-30 060-30
OPERATING WEIGHT (Lb)
316 316 318
REFRIGERANT 22
Cooling Control TXV
Heating Piston 57 70 70
CHARGE (Lb) 15.6 14.6 14.4
COND FAN Propeller Type, Direct Drive
Air Discharge Vertical
Air Qty (CFM) — High Speed 2650 3200
COND COIL
Face Area (Sq Ft)
Copper Tube, Aluminum Plate Fin
18.0
VALVE CONNECT. (In. ID)
Vapor
Liquid
Sweat
7/8
3/8
REFRIGTUBES*
(In. OD)
Vapor
Liquid
7/8 1-1/8
3/8
ORDERING
NUMBER DESCRIPTION
KHASS0206MPK
Snow Stand
KSASF0101AAA Support Feet (4)
KHATX1501HSO Thermostatic Expansion Valve (Required)
P504-8163S (RCD) Filter Drier — Bi-flow
THERMOSTAT AND SUBBASE DESCRIPTION
TSTATCCN2S01-A
Carrier Thermostat, Auto Changeover, Non-Programmable, ° F/ ° C, 2-stage heat/2-stage cool in AC mode,
3-stage heat/2 stage cool in HP mode
TSTATCCP2S01-A Carrier Thermostat, Auto Changeover, 7-Day Programmable, ° F/ ° C, 2-stage heat/2-stage cool in AC mode,
3-stage heat/ 2-stage cool in HP mode
TSTATCCSEN01 Outdoor Sensor

4
Electrical data
UNIT SIZE-
SERIES V/PH
OPERVOLTS* COMPRESSOR
FAN
FLA MCA
MINWIRE
SIZE
60
° C/75 ° C**
MAX
LENGTH
(Ft)‡
60 ° C/75 ° C**
MAX FUSE†
OR
HACRTYPE
CKT BKR
AMPSMax Min LRA RLA
036-30
048-30
060-30
208/230/1 253 187 90.0 120.0
141.0
17.6
23.6
30.8
1.5
1.5
1.5
23.5
31.0
40.0
12/12
8/10
8/8
52/50
100/61
78/74
40
50
60
* Permissible limits of the voltage range at which unit will operate
satisfactorily.
† Time-delay fuse.
‡ Length shown is as measured 1 way along wire path between unit and
service panel for voltage drop not to exceed 2%.
** If wire is applied at ambient greater than 30 ° C (86 ° F), consult Table
310-16 of the NEC (ANSI/NFPA 70).
The ampacity of nonmetallic-sheathed cable (NM), trade name
ROMEX, shall be that of 60 ° C (140 ° F) conductors, per the NEC
(ANSI/NFPA 70) Article 336-30.
If other than uncoated (non-plated), 60 or 75 ° C (140 or 167 ° F) insula-
tion, copper wire (solid wire for 10 AWG and smaller, stranded wire for
larger than 10 AWG) is used, consult applicable tables of the NEC
(ANSI/NFPA 70).
FLA — Full Load Amps
HACR — Heating, Air Conditioning, Refrigeration
LRA — Locked Rotor Arms
MCA — Minimum Circuit Amps
RLA — Rated Load Amps
NOTE: Control circuit is 24v on all units and requires external power
source 27va minimum. Copper wire must be used from service
disconnect to unit. All motors/compressors contain internal overload
protection.

5
Dimensions
A97086
UNIT SIZE SERIES MINIMUM MOUNTING PAD DIMENSIONS (In.)
036 30 26 x 32
048 30 26 x 32
060 30 26 x 32
1. Allow 30 In. clearance to service side of unit, 48 In. above unit, 6 In. on one side,
12 In. on remaining side, and 24 In. between units for proper airflow.
2. Minimum outdoor operating ambient in cooling mode is 55°F, max. 125°F.
3. Maximum outdoor operating ambient in heating mode is 66°F.
4. Series designation is the 13th position of the unit model number.
5. Center of gravity .
NOTES:
AIR DISCHARGE
3⁄8-IN. DIA
LIQUID 
LINE CONN
AIR DISCHARGE
AIR DISCHARGE AIR IN
AIR IN
C
LACCESS
PANEL
FIELD POWER SUPPLY CONN
7⁄8-IN. DIA HOLE WITH 
1 1⁄8-IN. DIA KNOCKOUT
AND 
1 3⁄8-IN. DIA KNOCKOUT
AIR IN
7⁄8-IN. DIA VAPOR LINE CONN
10 1⁄2″
4 3⁄16″
3⁄8-IN.
DIA TIEDOWN KNOCKOUTS
(2) PLACES IN BASEPAN
2 1⁄2″1 9⁄16″
1 1⁄4″
19 15⁄16″
8 3⁄16″
9 3⁄4″
4″
13 1⁄2″FIELD CONTROL
SUPPLY CONN
7⁄8-IN. DIA HOLE
34 15⁄16″
1 3⁄4″
2 15⁄16″
27 1⁄2″
33 7⁄8″
39 13⁄16″
30″
16 3⁄4″

6
38YDA BALANCE POINT WORKSHEET
BUILDING HEAT LOSS, 1000 BTU/HR
UNIT INTEGRATED HEATING CAPACITY, 1000 BTU/HR
OUTDOOR TEMPERATURE, °F
-10 010 20 30 40 50 60 70 80
2.9 5.9 8.8 11.7 14.7 17.6 20.5
70 60 50 40 30 20 10
KW
BASED ON INDOOR ENT. AIR AT
70°F AND AT RATED CFM
A - 38YDA036/FK4CNB006 B - 38YDA048/FK4CNB006 C - 38YDA060/FK4CNB006
LOW SPEED
A
HIGH SPEED
A
C
C
B
B
A96084

7
Combination ratings
See notes on pg. 10.
UNIT
SIZE-
SERIES INDOOR MODEL EVAP AIR CFM COOLING CAPACITY SEASONAL
EFF (SEER) HEATING CAPACITY SEASONAL
EFF (HSPF)
SOUND
RATING
High/Low
(dBA)High Low High Low High† Low
036-30
FK4CNB006* 1100 745 40,000 22,000 16.10 35,000 20,400 8.80 76/70
F(A,B)4AN(F,B)042 1230 1230 37,400 21,000 12.30 34,000 22,000 7.70 76/70
F(A,B)4ANF036 1287 1287 36,000 20,000 11.80 34,000 22,000 7.50 76/70
FC4BN(F,B)042 1230 1230 37,400 21,000 12.30 34,000 22,000 7.70 76/70
FC4BNF036 1287 1287 36,000 20,000 11.80 34,000 22,000 7.50 76/70
FK4CNF001 1100 680 36,000 20,000 14.20 33,000 19,800 7.50 76/70
FK4CNF002 1100 680 36,600 20,600 14.50 34,000 20,000 8.00 76/70
FK4CNF003 1100 680 37,400 20,600 14.90 34,000 19,800 8.15 76/70
FK4CNF005 1100 680 38,500 21,400 15.45 34,800 20,200 8.50 76/70
CC5A/CD5A/CD5BA036 1400 850 37,600 20,800 13.00 34,000 21,400 7.75 76/70
CC5A/CD5A/CD5BA042 1400 850 37,600 20,800 13.00 34,000 21,400 7.75 76/70
CC5A/CD5A/CD5BW042 1400 850 37,600 20,600 12.90 34,000 21,400 7.75 76/70
CD5A/CD5BW036 1400 850 37,600 20,800 13.00 34,000 21,400 7.75 76/70
CD3(A,B)A036 1400 850 37,600 20,800 13.00 34,000 21,400 7.75 76/70
CD3(A,B)A042 1400 850 37,600 20,800 13.00 34,000 21,400 7.75 76/70
CE3AA036 1400 850 37,000 20,000 12.80 33,400 21,400 7.50 76/70
CE3AA042 1400 850 37,600 20,600 13.00 33,600 21,600 7.60 76/70
CF5AA036 1400 850 34,000 21,000 13.00 34,000 21,000 7.50 76/70
CJ5A/CK5A/CK5BA036 1400 850 37,600 20,800 13.00 35,000 21,200 7.75 76/70
CJ5A/CK5A/CK5BA042 1400 850 37,600 20,800 13.00 35,000 21,200 7.75 76/70
CJ5A/CK5A/CK5BN042 1400 850 37,600 20,800 13.00 35,000 21,200 7.75 76/70
CJ5A/CK5A/CK5BN060 1400 850 38,500 21,000 13.20 36,000 21,400 8.00 76/70
CJ5A/CK5A/CK5BW036 1400 850 37,600 20,800 13.00 35,000 21,200 7.75 76/70
CK3BA036 1400 850 37,600 20,800 13.00 35,000 21,200 7.75 76/70
CK3BA042 1400 850 37,600 20,800 13.00 35,000 21,200 7.75 76/70
COILS + 58MVP060-14VARIABLE-SPEED FURNACE
CC5A/CD5A/CD5BA036 1200 800 37,000 21,000 14.50 33,000 20,800 7.80 76/70
CC5A/CD5A/CD5BA042 1200 800 37,000 21,000 14.50 33,000 20,800 7.80 76/70
CC5A/CD5A/CD5BW042 1200 800 37,000 21,000 14.00 33,000 20,800 7.80 76/70
CD5A/CD5BW036 1200 800 37,000 21,000 14.50 33,000 20,800 7.80 76/70
CD3(A,B)A036 1200 800 37,000 21,000 14.50 33,000 20,800 7.80 76/70
CD3(A,B)A042 1200 800 37,000 21,000 14.50 33,000 20,800 7.80 76/70
CE3AA036 1200 800 36,000 20,000 14.00 33,000 20,800 7.80 76/70
CE3AA042 1200 800 37,000 21,000 14.20 33,000 20,800 7.80 76/70
CJ5A/CK5A/CK5BA036 1200 800 37,000 21,000 14.40 34,000 20,200 7.80 76/70
CJ5A/CK5A/CK5BN042 1200 800 37,000 21,000 14.40 34,000 20,200 7.80 76/70
CK3BA036 1200 800 36,800 21,000 14.20 34,000 20,200 7.80 76/70
CK3BA042 1200 800 37,000 21,000 14.40 34,000 20,200 7.80 76/70
COILS + 58MVP080-14VARIABLE-SPEED FURNACE
CC5A/CD5A/CD5BA036 1200 800 37,000 21,000 14.70 33,000 20,800 8.00 76/70
CC5A/CD5A/CD5BA042 1200 800 37,000 21,000 14.70 33,000 20,800 8.00 76/70
CC5A/CD5A/CD5BW042 1200 800 37,000 21,000 14.70 33,000 20,800 8.00 76/70
CD5A/CD5BW036 1200 800 37,000 21,000 14.70 33,000 20,800 8.00 76/70
CD3(A,B)A036 1200 800 37,000 21,000 14.70 33,000 20,800 8.00 76/70
CD3(A,B)A042 1200 800 37,000 21,000 14.70 33,000 20,800 8.00 76/70
CE3AA036 1200 800 36,000 20,000 14.20 33,000 20,600 7.80 76/70
CE3AA042 1200 800 37,000 21,000 14.70 33,000 20,800 7.80 76/70
CJ5A/CK5A/CK5BA042 1200 800 37,000 21,000 14.70 34,000 20,200 8.00 76/70
CJ5A/CK5A/CK5BW036 1200 800 37,000 21,000 14.70 34,000 20,200 8.00 76/70
CK3BA036 1200 800 37,000 21,000 14.70 34,000 20,200 8.00 76/70
CK3BA042 1200 800 37,000 21,000 14.70 34,000 20,200 8.00 76/70
COILS + 58MVP100-20VARIABLE-SPEED FURNACE
CC5A/CD5A/CD5BA036 1200 800 37,000 21,000 14.70 33,000 20,800 8.00 76/70
CC5A/CD5A/CD5BA042 1200 800 37,000 21,000 14.70 33,000 20,800 8.00 76/70
CC5A/CD5A/CD5BW042 1200 800 37,000 21,000 14.70 33,000 20,800 8.00 76/70
CD5A/CD5BW036 1200 800 37,000 21,000 14.70 33,000 20,800 8.00 76/70
CD3(A,B)A036 1200 800 37,000 21,000 14.70 33,000 20,800 8.00 76/70
CD3(A,B)A042 1200 800 37,000 21,000 14.70 33,000 20,800 8.00 76/70
CE3AA036 1200 800 36,000 20,000 14.20 33,000 20,600 7.80 76/70
CE3AA042 1200 800 37,000 21,000 14.70 33,000 20,800 7.80 76/70
CJ5A/CK5A/CK5BA042 1200 800 37,000 21,000 14.70 34,000 20,200 8.00 76/70
CJ5A/CK5A/CK5BW036 1200 800 37,000 21,000 14.70 34,000 20,200 8.00 76/70
CK3BA036 1200 800 37,000 21,000 14.70 34,000 20,200 8.00 76/70
CK3BA042 1200 800 37,000 21,000 14.70 34,000 20,200 8.00 76/70
COILS + 58U(H,X)V060-12VARIABLE-SPEED FURNACE
CC5A/CD5A/CD5BA036 1120 660 37,000 20,600 14.50 33,000 20,400 7.80 76/70
CC5A/CD5A/CD5BA042 1115 660 37,000 20,600 14.50 33,000 20,400 7.80 76/70
CC5A/CD5A/CD5BW042 1115 660 37,000 20,600 14.50 33,000 20,200 7.80 76/70
CD5A/CD5BA036 1120 660 37,000 20,600 14.50 33,000 20,400 7.80 76/70
CD3(A,B)A036 1120 660 37,000 20,600 14.50 33,000 20,400 7.80 76/70
CD3(A,B)A042 1115 660 37,000 20,600 14.50 33,000 20,400 7.80 76/70
CD3CA036 1110 660 36,000 20,200 14.50 32,600 20,200 7.80 76/70
CD3CA042 1110 660 36,000 20,200 14.50 32,600 20,200 7.80 76/70
CE3AA036 1130 660 36,000 20,400 14.00 33,000 20,200 7.80 76/70
CE3AA042 1115 660 37,000 20,600 14.20 33,000 20,400 7.80 76/70
CJ5A/CK5A/CK5BA036 1125 660 37,000 20,600 14.50 34,000 19,800 7.80 76/70
CK3BA036 1125 660 37,000 20,600 14.50 34,000 19,800 7.80 76/70
CK3BA042 1120 660 37,000 20,600 14.50 34,000 19,800 7.80 76/70
COILS + 58U(H,X)V080-16VARIABLE-SPEED FURNACE
CC5A/CD5A/CD5BA036 1130 755 37,000 20,800 14.70 33,000 20,400 8.00 76/70
CC5A/CD5A/CD5BA042 1125 760 37,000 20,800 14.70 33,000 20,400 8.00 76/70

8
Combination ratings continued
See notes on pg. 10.
UNIT
SIZE-
SERIES INDOOR MODEL EVAP AIR CFM COOLING CAPACITY SEASONAL
EFF (SEER) HEATING CAPACITY SEASONAL
EFF (HSPF)
SOUND
RATING
High/Low
(dBA)High Low High Low High† Low
036-30
CC5A/CD5A/CD5BW042 1125 760 37,000 20,800 14.70 33,000 20,400 8.00 76/70
CD5A/CD5BW036 1130 755 37,000 20,800 14.70 33,000 20,400 8.00 76/70
CD3(A,B)A036 1130 755 37,000 20,800 14.70 33,000 20,400 8.00 76/70
CD3(A,B)A042 1125 760 37,000 20,800 14.70 33,000 20,400 8.00 76/70
CD3CA036 1125 765 36,000 20,200 14.70 32,600 20,200 8.00 76/70
CD3CA042 1125 765 36,000 20,600 14.70 32,600 20,200 8.00 76/70
CE3AA036 1120 750 37,000 20,800 14.30 33,000 20,400 8.00 76/70
CE3AA042 1125 760 37,000 20,800 14.50 33,000 20,400 8.00 76/70
CJ5A/CK5A/CK5BA042 1125 755 37,000 21,200 14.70 34,000 20,200 8.00 76/70
CJ5A/CK5A/CK5BW036 1125 755 37,000 20,800 14.70 34,000 20,200 8.00 76/70
CK3BA036 1130 750 37,000 20,800 14.70 34,000 20,200 8.00 76/70
CK3BA042 1125 755 37,000 20,800 14.70 34,000 20,200 8.00 76/70
COILS + 58U(H,X)V100-20VARIABLE-SPEED FURNACE
CC5A/CD5A/CD5BA036 1090 795 37,000 21,000 14.80 33,000 20,800 8.00 76/70
CC5A/CD5A/CD5BA042 1090 790 37,000 21,000 14.80 32,800 20,800 8.00 76/70
CC5A/CD5A/CD5BW042 1090 790 37,000 21,000 14.80 32,600 20,600 8.00 76/70
CD5A/CD5BW036 1090 795 37,000 21,000 14.80 33,000 20,800 8.00 76/70
CD3(A,B)A036 1090 795 37,000 21,000 14.80 33,000 20,800 8.00 76/70
CD3(A,B)A042 1090 790 37,000 21,000 14.80 32,800 20,800 8.00 76/70
CD3CA036 1060 775 36,000 20,800 14.80 32,000 20,600 8.00 76/70
CD3CA042 1060 775 36,000 20,800 14.80 32,000 20,600 8.00 76/70
CE3AA036 1090 800 37,000 21,000 14.40 32,600 20,600 8.00 76/70
CE3AA042 1090 790 37,000 21,000 14.60 33,000 20,800 8.00 76/70
CJ5A/CK5A/CK5BA042 1090 795 37,000 21,000 14.80 34,000 20,200 8.00 76/70
CJ5A/CK5A/CK5BW036 1090 795 37,000 21,000 14.80 34,000 20,200 8.00 76/70
CK3BA036 1090 800 37,000 21,000 14.80 34,000 20,200 8.00 76/70
CK3BA042 1090 795 37,000 21,000 14.80 34,000 20,200 8.00 76/70
COILS + 58U(H,X)V120-20VARIABLE-SPEED FURNACE
CC5A/CD5A/CD5BA036 1080 810 37,000 21,000 14.80 33,000 20,800 8.00 76/70
CC5A/CD5A/CD5BA042 1060 810 37,000 21,000 14.80 32,800 20,800 8.00 76/70
CC5A/CD5A/CD5BW042 1070 810 37,000 21,000 14.80 32,600 20,600 8.00 76/70
CD5A/CD5BW036 1080 810 37,000 21,000 14.80 33,000 20,800 8.00 76/70
CD3(A,B)A036 1080 810 37,000 21,000 14.80 33,000 20,800 8.00 76/70
CD3(A,B)A042 1060 810 37,000 21,000 14.80 32,800 20,800 8.00 76/70
CD3CA036 1025 810 35,800 20,800 14.80 32,000 20,600 8.00 76/70
CD3CA042 1025 805 35,800 20,800 14.80 32,000 20,600 8.00 76/70
CE3AA036 1085 815 37,000 21,000 14.40 32,600 20,600 8.00 76/70
CE3AA042 1065 810 37,000 21,000 14.60 33,000 20,800 8.00 76/70
CJ5A/CK5A/CK5BA042 1070 810 37,000 21,000 14.80 34,000 20,200 8.00 76/70
CJ5A/CK5A/CK5BW036 1070 810 37,000 21,000 14.80 34,000 20,200 8.00 76/70
CK3BA036 1090 815 37,000 21,000 14.80 34,000 20,200 8.00 76/70
CK3BA042 1070 810 37,000 21,000 14.80 34,000 20,200 8.00 76/70
048-30
FK4CNB006* 1470 995 51,000 28,600 14.50 49,500 26,800 8.40 78/72
F(A,B)4AN(F,B)048 1800 1800 48,000 28,000 11.30 50,000 27,000 7.70 78/72
F(A,B)4AN(F,B)060 1800 1800 50,000 28,600 11.00 50,000 27,000 7.70 78/72
FB4ANB070 1800 1800 51,500 28,600 11.80 50,500 29,000 8.00 78/72
FC4BN(F,B)048 1800 1800 48,000 28,000 11.30 50,000 27,000 7.70 78/72
FC4BN(F,B)060 1800 1800 50,000 28,600 11.00 50,000 27,000 7.70 78/72
FC4BNB070 1800 1800 51,500 28,600 11.80 50,500 29,000 8.00 78/72
FK4CNF005 1470 910 49,000 27,400 14.10 47,000 26,000 7.70 78/72
CC5A/CD5A/CD5BA060 1850 1050 48,000 26,000 12.00 49,000 27,000 7.60 78/72
CC5A/CD5A/CD5BW048 1850 1050 48,000 26,000 12.00 49,000 27,000 7.60 78/72
CC5A/CD5A/CD5BW060 1850 1050 49,000 27,000 12.40 49,500 27,000 7.80 78/72
CD5A/CD5BA048 1850 1050 48,000 26,000 12.00 49,000 27,000 7.60 78/72
CD3(A,B)A048 1850 1050 48,000 26,000 12.00 49,000 27,000 7.60 78/72
CD3(A,B)A060 1850 1050 48,000 26,000 12.00 49,000 27,000 7.60 78/72
CE3AA048 1850 1050 48,000 26,000 12.00 49,000 27,000 7.60 78/72
CE3AA060 1850 1050 49,000 27,000 12.40 49,500 27,000 7.80 78/72
CF5AA048 1850 1050 48,000 26,000 12.00 49,000 27,000 7.60 78/72
CJ5A/CK5A/CK5BA048 1850 1050 47,500 27,400 12.00 49,000 27,000 7.60 78/72
CJ5A/CK5A/CK5BA060 1850 1050 48,000 27,600 12.00 49,000 27,000 7.60 78/72
CJ5A/CK5A/CK5BN060 1850 1050 49,000 28,000 12.20 49,500 27,400 7.80 78/72
CJ5A/CK5A/CK5BW048 1850 1050 47,000 27,400 12.00 49,000 27,000 7.60 78/72
CJ5A/CK5A/CK5BX060 1850 1050 49,000 28,000 12.40 49,000 27,400 7.80 78/72
CK3BA048 1850 1050 47,000 27,400 12.00 49,000 27,000 7.60 78/72
CK3BA060 1850 1050 48,000 27,600 12.00 49,000 27,000 7.60 78/72
COILS + 58MVP100-20VARIABLE-SPEED FURNACE
CC5A/CD5A/CD5BA060 1600 1000 47,000 26,000 13.00 49,500 26,200 7.80 78/72
CC5A/CD5A/CD5BW048 1600 1000 47,000 26,000 13.00 49,000 26,000 7.80 78/72
CC5A/CD5A/CD5BW060 1600 1000 48,000 26,400 13.40 49,500 26,200 8.00 78/72
CD5A/CD5BA048 1600 1000 47,000 26,000 13.00 49,000 26,000 7.80 78/72
CD3(A,B)A048 1600 1000 47,000 26,000 13.00 49,000 26,000 7.80 78/72
CD3(A,B)A060 1600 1000 47,000 26,000 13.00 49,000 26,000 7.80 78/72
CE3AA048 1600 1000 47,000 26,000 13.00 49,000 26,000 7.70 78/72
CE3AA060 1600 1000 48,000 26,400 13.40 49,000 26,000 7.80 78/72
CJ5A/CK5A/CK5BA048 1600 1000 46,500 27,000 13.30 49,000 26,000 7.80 78/72
CJ5A/CK5A/CK5BA060 1600 1000 47,000 27,000 13.30 49,000 26,000 7.80 78/72
CJ5A/CK5A/CK5BN060 1600 1000 48,000 27,600 13.50 49,500 26,200 8.00 78/72
CJ5A/CK5A/CK5BX060 1600 1000 48,000 27,600 13.50 49,500 26,200 8.00 78/72
CK3BA048 1600 1000 46,500 27,000 13.30 48,500 26,000 7.80 78/72
CK3BA060 1600 1000 47,000 27,000 13.30 49,000 26,000 7.80 78/72

9
Combination ratings continued
See notes on pg. 10.
UNIT
SIZE-
SERIES INDOOR MODEL EVAP AIR CFM COOLING CAPACITY SEASONAL
EFF (SEER) HEATING CAPACITY SEASONAL
EFF (HSPF)
SOUND
RATING
High/Low
(dBA)High Low High Low High† Low
048-30
COILS + 58U(H,X)V080-16VARIABLE-SPEED FURNACE
CC5A/CD5A/CD5BA060 1505 950 47,000 26,400 13.00 48,000 25,800 7.70 78/72
CC5A/CD5A/CD5BC048 1505 950 46,000 26,000 13.00 47,500 25,800 7.50 78/72
CC5A/CD5A/CD5BW048 1505 950 46,000 26,000 13.00 48,000 25,800 7.70 78/72
CC5A/CD5A/CD5BW060 1505 950 48,000 27,000 13.30 48,000 25,800 7.80 78/72
CD5A/CD5BA048 1505 950 46,000 26,000 13.00 48,000 25,800 7.70 78/72
CD3(A,B)A048 1505 950 46,000 26,000 13.00 48,000 25,800 7.70 78/72
CD3(A,B)A060 1505 950 47,000 26,400 13.00 48,000 25,800 7.70 78/72
CD3CA048 1505 945 46,000 26,000 13.00 48,000 25,800 7.70 78/72
CD3CA060 1500 945 47,000 26,400 13.00 48,000 25,800 7.80 78/72
CE3AA048 1505 955 47,000 26,400 13.00 48,000 25,800 7.70 78/72
CE3AA060 1505 950 48,000 27,000 13.30 48,000 25,800 7.80 78/72
CJ5A/CK5A/CK5BA048 1505 950 46,000 26,000 13.40 48,000 25,800 7.80 78/72
CK3BA048 1505 950 46,000 26,000 13.40 48,000 25,800 7.80 78/72
CK3BA060 1505 955 47,000 26,000 13.40 48,000 25,800 7.80 78/72
COILS + 58U(H,X)V100-20VARIABLE-SPEED FURNACE
CC5A/CD5A/CD5BA060 1460 915 47,000 26,600 13.50 47,000 25,600 7.80 78/72
CC5A/CD5A/CD5BC048 1465 920 47,000 26,600 13.50 47,000 25,600 7.60 78/72
CC5A/CD5A/CD5BW048 1460 920 47,000 26,600 13.50 47,000 25,600 7.80 78/72
CC5A/CD5A/CD5BW060 1450 910 48,000 27,000 13.80 48,000 26,000 8.00 78/72
CD5A/CD5BA048 1460 920 47,000 26,600 13.50 47,000 25,600 7.80 78/72
CD3(A,B)A048 1460 920 47,000 26,600 13.50 47,000 25,600 7.80 78/72
CD3(A,B)A060 1460 915 47,000 27,000 13.50 47,000 25,600 7.80 78/72
CD3CA048 1440 920 46,500 26,200 13.30 47,000 25,600 7.80 78/72
CD3CA060 1435 915 47,000 26,600 13.50 48,000 26,000 8.00 78/72
CE3AA048 1460 920 47,000 26,600 13.50 47,000 25,600 7.80 78/72
CE3AA060 1455 915 48,000 27,000 13.80 48,000 26,000 8.00 78/72
CJ5A/CK5A/CK5BA060 1470 935 47,000 27,000 13.50 47,000 26,000 7.80 78/72
CJ5A/CK5A/CK5BW048 1470 930 47,000 27,000 13.50 47,000 26,000 7.80 78/72
CJ5A/CK5A/CK5BX060 1460 925 48,000 27,600 13.80 48,000 26,200 8.00 78/72
CK3BA048 1470 930 47,000 27,000 13.50 47,000 26,000 7.80 78/72
CK3BA060 1470 935 48,000 27,000 13.80 47,000 26,000 7.80 78/72
COILS + 58U(H,X)V120-20VARIABLE-SPEED FURNACE
CC5A/CD5A/CD5BA060 1470 995 47,000 26,600 13.50 47,000 25,600 7.80 78/72
CC5A/CD5A/CD5BC048 1490 1000 47,000 26,600 13.50 47,000 25,600 7.60 78/72
CC5A/CD5A/CD5BW048 1475 1000 47,000 26,600 13.50 47,000 25,600 7.80 78/72
CC5A/CD5A/CD5BW060 1455 995 48,000 27,000 13.80 48,000 26,000 8.00 78/72
CD5A/CD5BA048 1465 995 47,000 26,600 13.50 47,000 25,600 7.80 78/72
CD3(A,B)A048 1475 1000 47,000 26,600 13.50 47,000 25,600 7.80 78/72
CD3(A,B)A060 1470 995 47,000 26,600 13.50 47,000 25,600 7.80 78/72
CD3CA048 1435 990 46,500 26,200 13.30 47,000 25,600 7.80 78/72
CD3CA060 1430 990 47,000 26,600 13.50 48,000 26,000 8.00 78/72
CE3AA048 1490 1015 47,000 26,600 13.50 47,000 25,600 7.80 78/72
CE3AA060 1465 995 48,000 27,000 13.80 48,000 26,000 8.00 78/72
CJ5A/CK5A/CK5BA060 1455 1000 47,000 27,000 13.50 47,000 26,000 7.80 78/72
CJ5A/CK5A/CK5BW048 1485 1000 47,000 27,000 13.50 47,000 26,000 7.80 78/72
CJ5A/CK5A/CK5BX060 1465 995 48,000 27,600 13.80 48,000 26,200 8.00 78/72
CK3BA048 1485 1000 47,000 27,000 13.50 47,000 26,000 7.80 78/72
CK3BA060 1460 1000 47,000 27,000 13.80 47,000 26,000 7.80 78/72
060-30
FK4CNB006* 1835 1240 57,000 32,000 14.00 55,500 31,000 8.30 80/72
F(A,B)4AN(F,B)060 2000 2000 56,000 32,000 10.80 52,000 34,000 7.70 80/72
FB4ANB070 2005 2005 57,000 32,000 10.80 52,000 34,000 8.00 80/72
FC4BN(F,B)060 2000 2000 56,000 32,000 10.80 52,000 34,000 7.70 80/72
FC4BNB070 2005 2005 57,000 32,000 11.60 52,000 34,000 8.00 80/72
CC5A/CD5A/CD5BA060 2100 1200 54,500 30,200 11.70 49,500 31,000 7.70 80/72
CC5A/CD5A/CD5BW060 2100 1200 56,000 30,800 12.00 51,000 31,000 7.80 80/72
CD3(A,B)A060 2100 1200 54,500 30,200 11.70 49,500 31,000 7.70 80/72
CE3AA060 2100 1200 56,000 30,800 12.00 50,000 31,000 7.80 80/72
CJ5A/CK5A/CK5BA060 2100 1200 55,000 30,200 12.00 55,000 31,000 7.60 80/72
CJ5A/CK5A/CK5BN060 2100 1200 56,000 30,800 12.20 56,000 31,200 7.80 80/72
CJ5A/CK5A/CK5BX060 2100 1200 56,000 30,800 12.20 56,000 31,200 7.80 80/72
CK3BA060 2100 1200 55,000 30,200 12.00 55,000 31,000 7.60 80/72
COILS + 58MVP100-20VARIABLE-SPEED FURNACE
CC5A/CD5A/CD5BA060 1600 1000 52,500 30,000 12.80 47,500 29,600 7.60 80/72
CC5A/CD5A/CD5BW060 1600 1000 54,000 30,000 13.00 48,500 30,000 7.80 80/72
CD3(A,B)A060 1600 1000 52,500 30,000 12.80 47,500 29,600 7.60 80/72
CE3AA060 1600 1000 54,000 30,000 13.00 48,500 30,000 7.80 80/72
CJ5A/CK5A/CK5BA060 1600 1000 53,500 30,600 13.00 54,000 30,000 7.80 80/72
CJ5A/CK5A/CK5BN060 1600 1000 54,500 31,000 13.30 54,500 30,000 8.00 80/72
CJ5A/CK5A/CK5BX060 1600 1000 54,500 31,000 13.30 54,500 30,000 8.00 80/72
CK3BA060 1600 1000 53,500 30,600 13.00 54,000 30,000 7.80 80/72
COILS + 58U(H,X)V100-20VARIABLE-SPEED FURNACE
CC5A/CD5A/CD5BA060 1880 1165 53,000 30,000 13.00 53,000 29,000 7.80 80/72
CC5A/CD5A/CD5BW060 1870 1155 55,000 30,600 13.30 54,000 29,200 8.00 80/72
CD3(A,B)A060 1880 1165 53,000 30,000 13.00 53,000 29,000 7.80 80/72
CD3CA060 1865 1145 53,000 30,000 13.00 54,000 29,200 8.00 80/72
CE3AA060 1880 1165 55,000 30,600 13.30 54,000 29,200 8.00 80/72
CJ5A/CK5A/CK5BA060 1875 1175 54,000 30,600 13.00 54,500 30,400 7.80 80/72
CJ5A/CK5A/CK5BX060 1875 1165 55,500 31,200 13.50 55,000 30,600 8.00 80/72
CK3BA060 1875 1175 54,000 30,600 13.00 54,500 30,400 7.80 80/72

10
Combination ratings continued
* Tested combination.
† Capacities shown are at ARI rating point 47 ° F, high speed.Unit is factory shipped to operate on low speed at 47 ° F.See Heat Pump Heating Per-
formance tables for low speed capacity at 47 ° F.
NOTES: 1. Ratings are net values reflecting the effects of circulating fan motor heat.Supplemental electric heat is not included.
2. Rating values reflect coil combinations plus field-installed TXV (except when specifying FK4 and FC4 coils).
3. Tested outdoor/indoor combinations have been tested in accordance with DOE test procedures for heat pumps. Ratings for other
combinations are determined under DOE computer simulation procedures.
4. Determine actual CFM values obtainable for your system by referring to fan performance data in fan coil or furnace coil literature.
5. Do not apply to capillary tube coils.
6. Unit is factory set to change speeds in heating mode based on ambient temperature. See Ambient Temperatures for High- and
Low-Speed Operation table for speed change temperatures.
7. Coefficient of Performance (COP) can be calculated by using the Heat Pump Heating Performance tables. Normally the high tempera-
ture COP is calculated at 47 ° F, and the low temperature COP is calculated at 17 ° F.The formula for calculating the COP is as follows:
COP =
THC=total heating capacity at either 47 ° F or 17 ° F, 70 ° F indoor dry bulb and rated airflow.
KW=power input in kilowatts.
AMBIENT TEMPERATURES FOR HIGH- AND
LOW-SPEED OPERATION
UNIT
SIZE-
SERIES INDOOR MODEL EVAP AIR CFM COOLING CAPACITY SEASONAL
EFF (SEER) HEATING CAPACITY SEASONAL
EFF (HSPF)
SOUND
RATING
High/Low
(dBA)High Low High Low High† Low
060-30
COILS + 58U(H,X)V120-20VARIABLE-SPEED FURNACE
CC5A/CD5A/CD5BA060 1840 1135 53,000 30,000 13.00 53,000 29,000 7.80 80/72
CC5A/CD5A/CD5BW060 1825 1135 55,000 30,600 13.30 54,000 29,200 8.00 80/72
CD3(A,B)A060 1840 1156 53,000 30,000 13.00 53,000 29,000 7.80 80/72
CD3CA060 1795 1130 53,000 30,000 13.00 54,000 29,200 8.00 80/72
CE3AA060 1840 1135 55,000 30,600 13.30 54,000 29,200 8.00 80/72
CJ5A/CK5A/CK5BA060 1830 1135 54,000 30,600 13.00 54,500 30,400 7.80 80/72
CJ5A/CK5A/CK5BX060 1835 1135 55,000 31,200 13.50 55,000 30,400 8.00 80/72
CK3BA060 1830 1135 54,000 30,600 13.00 54,500 30,400 7.80 80/72
UNIT
SIZE AMBIENTTEMPERATURE (
° F)
High Speed Low Speed
036 30 or less 31 or greater
048 33 or less 34 or greater
060 40 or less 41 or greater
THC
KW x 3.413

11
Detailed cooling capacities*
See notes on pg. 20.
EVAPORATOR
AIR CONDENSER ENTERING AIRTEMPERATURES °F 85 95 105 115
CFM EWB
Capacity
MBtuh† Total
System
Kw**
Capacity
MBtuh† Total
System
Kw**
Capacity
MBtuh† Total
System
Kw**
Capacity
MBtuh† Total
System
Kw**Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡
38YDA036-30 Outdoor Section in High-SpeedWith FK4CNB006 Indoor Section
800
72 43.6 20.8 3.29 41.2 19.8 3.53 38.8 18.8 3.76 36.3 17.9 3.99
67 39.4 24.9 3.19 37.2 23.9 3.41 34.9 22.9 3.62 32.7 21.9 3.83
63‡‡ 36.4 24.2 3.11 34.3 23.2 3.32 32.2 22.2 3.52 30.1 21.2 3.70
62 35.6 28.9 3.09 33.6 27.9 3.29 31.5 26.9 3.49 29.4 25.9 3.67
57 32.4 32.4 3.00 30.9 30.9 3.21 29.4 29.4 3.40 27.8 27.8 3.60
900
72 44.9 21.7 3.33 42.4 20.7 3.58 39.9 19.7 3.81 37.3 18.8 4.04
67 40.6 26.3 3.23 38.3 25.3 3.46 36.0 24.3 3.68 33.6 23.3 3.88
63‡‡ 37.6 25.6 3.16 35.4 24.6 3.37 33.2 23.6 3.57 30.9 22.5 3.76
62 36.7 30.9 3.13 34.6 29.8 3.34 32.4 28.8 3.54 30.2 27.8 3.73
57 34.1 34.1 3.07 32.5 32.5 3.28 30.9 30.9 3.48 29.2 29.2 3.68
990
72 45.9 22.5 3.37 43.2 21.5 3.62 40.6 20.5 3.86 37.9 19.5 4.08
67 41.6 27.6 3.27 39.2 26.6 3.50 36.7 25.5 3.72 34.2 24.5 3.92
63‡‡ 38.5 26.8 3.19 36.2 25.8 3.41 33.9 24.7 3.61 31.5 23.7 3.80
62 37.6 32.6 3.17 35.4 31.5 3.38 33.2 30.5 3.58 30.9 29.4 3.77
57 35.5 35.5 3.12 33.8 33.8 3.33 32.1 32.1 3.54 30.3 30.3 3.75
1100
72 46.9 23.4 3.41 44.2 22.4 3.66 41.4 21.4 3.90 38.7 20.4 4.13
67 42.5 29.1 3.31 40.0 28.0 3.54 37.5 27.0 3.76 34.9 26.0 3.97
63‡‡ 39.3 28.2 3.23 37.0 27.1 3.45 34.5 26.1 3.65 32.1 25.0 3.85
62 38.6 34.6 3.21 36.2 33.5 3.43 33.9 32.4 3.63 31.6 31.3 3.82
57 37.0 37.0 3.17 35.2 35.2 3.39 33.4 33.4 3.61 31.5 31.5 3.82
1225
72 47.8 24.4 3.44 45.0 23.4 3.70 42.2 22.4 3.94 39.3 21.4 4.17
67 43.4 30.7 3.35 40.8 29.6 3.58 38.1 28.6 3.81 35.5 27.6 4.01
63‡‡ 40.2 29.7 3.27 37.7 28.7 3.49 35.2 27.6 3.70 32.7 26.5 3.89
62 39.4 36.8 3.25 37.0 35.7 3.47 34.7 34.5 3.68 32.7 32.7 3.89
57 38.5 38.5 3.23 36.6 36.6 3.46 34.7 34.7 3.68 32.7 32.7 3.89
Multipliers for Determining the Performance With Other Indoor Sections
Indoor
Section Size Cooling Indoor Section Size Cooling Capacity Sensible†† Power Capacity Sensible†† Power
F(A,B)4ANF 036 0.90 0.90 1.07 CE3AA 036 0.90 0.89 1.02
F(A,B)4AN(F,B) 042 0.94 0.93 1.06 042 0.93 0.92 1.03
FC4BN(F,B) 042 0.94 0.93 1.06 CJ5A/CK5A/CK5BA 036 0.93 0.93 1.05
FC4BNF 036 0.90 0.90 1.07 CJ5A/CK5A/CK5BN 042 0.93 0.93 1.05
FK4CNB 006 1.00 1.00 1.00 CK3BA 036 0.92 0.92 1.09
FK4CNF 001 0.90 0.90 1.01 042 0.93 0.93 1.04
002 0.91 0.91 1.02 COILS + 58MVP080-14VARIABLE-SPEED FURNACE
003 0.94 0.93 0.99 CC5A/CD5A/CD5BA 036 0.93 0.91 1.02
005 0.96 0.96 1.00 042 0.93 0.91 1.02
CC5A/CD5A/CD5BA 036 0.94 0.94 1.07 CC5A/CD5A/CD5BW 042 0.93 0.89 1.01
042 0.94 0.94 1.07 CD5A/CD5BW 036 0.93 0.91 1.02
CC5A/CD5A/CD5BW 042 0.94 0.94 1.07 CD3(A,B)A 036 0.93 0.91 1.02
CD5A/CD5BW 036 0.94 0.94 1.07 042 0.93 0.91 1.02
CD3(A,B)A 036 0.94 0.94 1.07 CE3AA 036 0.90 0.90 1.01
042 0.94 0.94 1.07 042 0.93 0.93 1.01
CE3AA 036 0.93 0.93 1.07 CJ5A/CK5A/CK5BA 042 0.93 0.93 1.04
042 0.94 0.94 1.08 CJ5A/CK5A/CK5BW 036 0.93 0.93 1.04
CF5AA 036 0.93 0.93 1.07 CK3BA 036 0.93 0.93 1.04
CJ5A/CK5A/CK5BA 036 0.94 0.94 1.09 042 0.93 0.93 1.04
042 0.94 0.94 1.09 COILS + 58MVP100-20 VARIABLE-SPEED FURNACE
CJ5A/CK5A/CK5BN 042 0.94 0.94 1.09 CC5A/CD5A/CD5BA 036 0.93 0.91 1.01
060 0.96 0.96 1.11 042 0.93 0.91 1.01
CJ5A/CK5A/CK5BW 036 0.94 0.94 1.09 CC5A/CD5A/CD5BW 042 0.93 0.90 1.00
CK3BA 036 0.94 0.94 1.09 CD5A/CD5BW 036 0.93 0.91 1.01
042 0.94 0.94 1.09 CD3(A,B)A 036 0.93 0.91 1.01
COILS + 58MVP060-14VARIABLE-SPEED FURNACE 042 0.93 0.91 1.01
CC5A/CD5A/CD5BA 036 0.93 0.91 1.03 CE3AA 036 0.90 0.90 1.01
042 0.93 0.91 1.03 042 0.93 0.93 1.01
CC5A/CD5A/CD5BW 042 0.93 0.89 1.02 CJ5A/CK5A/CK5BA 042 0.93 0.93 1.02
CD5A/CD5BW 036 0.93 0.91 1.03 CJ5A/CK5A/CK5BW 036 0.93 0.93 1.02
CD3(A,B)A 036 0.93 0.91 1.03 CK3BA 036 0.93 0.93 1.03
042 0.93 0.91 1.03 042 0.93 0.93 1.02

12
Detailed cooling capacities* continued
See notes on pg. 20.
EVAPORATOR
AIR CONDENSER ENTERING AIRTEMPERATURES °F 85 95 105 115
CFM EWB
Capacity
MBtuh† Total
System
Kw**
Capacity
MBtuh† Total
System
Kw**
Capacity
MBtuh† Total
System
Kw**
Capacity
MBtuh† Total
System
Kw**Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡
38YDA036-30 Outdoor Section in High-SpeedWith FK4CNB006 Indoor Section continued
800
72 43.6 20.8 3.29 41.2 19.8 3.53 38.8 18.8 3.76 36.3 17.9 3.99
67 39.4 24.9 3.19 37.2 23.9 3.41 34.9 22.9 3.62 32.7 21.9 3.83
63‡‡ 36.4 24.2 3.11 34.3 23.2 3.32 32.2 22.2 3.52 30.1 21.2 3.70
62 35.6 28.9 3.09 33.6 27.9 3.29 31.5 26.9 3.49 29.4 25.9 3.67
57 32.4 32.4 3.00 30.9 30.9 3.21 29.4 29.4 3.40 27.8 27.8 3.60
900
72 44.9 21.7 3.33 42.4 20.7 3.58 39.9 19.7 3.81 37.3 18.8 4.04
67 40.6 26.3 3.23 38.3 25.3 3.46 36.0 24.3 3.68 33.6 23.3 3.88
63‡‡ 37.6 25.6 3.16 35.4 24.6 3.37 33.2 23.6 3.57 30.9 22.5 3.76
62 36.7 30.9 3.13 34.6 29.8 3.34 32.4 28.8 3.54 30.2 27.8 3.73
57 34.1 34.1 3.07 32.5 32.5 3.28 30.9 30.9 3.48 29.2 29.2 3.68
990
72 45.9 22.5 3.37 43.2 21.5 3.62 40.6 20.5 3.86 37.9 19.5 4.08
67 41.6 27.6 3.27 39.2 26.6 3.50 36.7 25.5 3.72 34.2 24.5 3.92
63‡‡ 38.5 26.8 3.19 36.2 25.8 3.41 33.9 24.7 3.61 31.5 23.7 3.80
62 37.6 32.6 3.17 35.4 31.5 3.38 33.2 30.5 3.58 30.9 29.4 3.77
57 35.5 35.5 3.12 33.8 33.8 3.33 32.1 32.1 3.54 30.3 30.3 3.75
1100
72 46.9 23.4 3.41 44.2 22.4 3.66 41.4 21.4 3.90 38.7 20.4 4.13
67 42.5 29.1 3.31 40.0 28.0 3.54 37.5 27.0 3.76 34.9 26.0 3.97
63‡‡ 39.3 28.2 3.23 37.0 27.1 3.45 34.5 26.1 3.65 32.1 25.0 3.85
62 38.6 34.6 3.21 36.2 33.5 3.43 33.9 32.4 3.63 31.6 31.3 3.82
57 37.0 37.0 3.17 35.2 35.2 3.39 33.4 33.4 3.61 31.5 31.5 3.82
1225
72 47.8 24.4 3.44 45.0 23.4 3.70 42.2 22.4 3.94 39.3 21.4 4.17
67 43.4 30.7 3.35 40.8 29.6 3.58 38.1 28.6 3.81 35.5 27.6 4.01
63‡‡ 40.2 29.7 3.27 37.7 28.7 3.49 35.2 27.6 3.70 32.7 26.5 3.89
62 39.4 36.8 3.25 37.0 35.7 3.47 34.7 34.5 3.68 32.7 32.7 3.89
57 38.5 38.5 3.23 36.6 36.6 3.46 34.7 34.7 3.68 32.7 32.7 3.89
Multipliers for Determining the Performance With Other Indoor Sections
Indoor
Section Size Cooling Indoor Section Size Cooling Capacity Sensible†† Power Capacity Sensible†† Power
COILS + 58U(H,X)V060-12VARIABLE-SPEED FURNACE COILS + 58U(H,X)V100-20VARIABLE-SPEED FURNACE
CC5A/CD5A/CD5BA 036 0.93 0.89 1.00 CC5A/CD5A/CD5BA 036 0.93 0.88 0.98
042 0.93 0.88 1.00 042 0.93 0.89 0.97
CC5A/CD5A/CD5BW 042 0.93 0.87 0.99 CC5A/CD5A/CD5BW 042 0.93 0.87 0.97
CD5A/CD5BA 036 0.93 0.89 1.00 CD5A/CD5BW 036 0.93 0.88 0.98
CD3(A,B)A 036 0.93 0.88 1.00 CD3(A,B)A 036 0.93 0.91 0.98
042 0.93 0.89 1.00 042 0.93 0.89 0.97
CD3CA 036 0.90 0.85 0.98 CD3CA 036 0.90 0.84 0.94
042 0.90 0.85 0.98 042 0.90 0.84 0.94
CE3AA 036 0.90 0.88 1.00 CE3AA 036 0.93 0.88 0.97
042 0.93 0.90 1.00 042 0.93 0.90 0.97
CJ5A/CK5A/CK5BA 036 0.93 0.93 1.02 CJ5A/CK5A/CK5BA 042 0.93 0.93 0.99
CK3BA 036 0.93 0.93 1.02 CJ5A/CK5A/CK5BW 036 0.93 0.93 0.99
042 0.93 0.93 1.02 CK3BA 036 0.93 0.92 0.99
COILS + 58U(H,X)V080-16VARIABLE-SPEED FURNACE 042 0.93 0.93 0.99
CC5A/CD5A/CD5BA 036 0.93 0.89 0.99 COILS + 58U(H,X)V120-20VARIABLE-SPEED FURNACE
042 0.93 0.89 1.00 CC5A/CD5A/CD5BA 036 0.93 0.88 0.98
CC5A/CD5A/CD5BW 042 0.93 0.87 0.99 042 0.93 0.87 0.97
CD5A/CD5BW 036 0.93 0.89 0.99 CC5A/CD5A/CD5BW 042 0.93 0.86 0.97
CD3(A,B)A 036 0.93 0.89 0.99 CD5A/CD5BW 036 0.93 0.88 0.98
042 0.93 0.89 0.99 CD3(A,B)A 042 0.93 0.87 0.97
CD3CA 036 0.90 0.86 0.96 036 0.93 0.88 0.98
042 0.90 0.86 0.96 CD3CA 036 0.90 0.83 0.95
CE3AA 036 0.93 0.88 0.99 042 0.90 0.83 0.95
042 0.93 0.91 0.99 CE3AA 042 0.93 0.89 0.97
CJ5A/CK5A/CK5BA 042 0.93 0.93 1.01 CJ5A/CK5A/CK5BA 042 0.93 0.92 0.99
CJ5A/CK5A/CK5BW 036 0.93 0.93 1.01 CJ5A/CK5A/CK5BW 036 0.93 0.92 0.99
CK3BA 036 0.93 0.93 1.01 CK3BA 036 0.93 0.92 0.99
042 0.93 0.93 1.01 042 0.93 0.92 0.99

13
Detailed cooling capacities* continued
See notes on pg. 20.
EVAPORATOR
AIR CONDENSER ENTERING AIRTEMPERATURES °F 85 95 105 115
CFM EWB
Capacity
MBtuh† Total
System
Kw**
Capacity
MBtuh† Total
System
Kw**
Capacity
MBtuh† Total
System
Kw**
Capacity
MBtuh† Total
System
Kw**Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡
38YDA036-30 Outdoor Section in Low-SpeedWith FK4CNB006 Indoor Section
670
72 25.4 13.1 1.45 23.9 12.6 1.61 22.4 12.1 1.77 20.9 11.5 1.93
67 23.0 16.5 1.45 21.6 15.9 1.60 20.2 15.4 1.75 18.8 14.8 1.89
63‡‡ 21.2 15.9 1.45 19.9 15.3 1.59 18.6 14.8 1.73 17.3 14.2 1.86
62 20.8 19.8 1.45 19.5 19.2 1.59 18.4 18.4 1.73 17.4 17.4 1.87
57 20.4 20.4 1.45 19.4 19.4 1.59 18.4 18.4 1.73 17.4 17.4 1.87
745
72 25.9 13.7 1.45 24.4 13.2 1.62 22.8 12.7 1.78 21.3 12.1 1.94
67 23.5 17.5 1.46 22.0 16.9 1.61 20.6 16.4 1.76 19.2 15.8 1.90
63‡‡ 21.6 16.9 1.46 20.3 16.3 1.60 18.9 15.7 1.74 17.6 15.2 1.88
62 21.3 21.1 1.46 20.1 20.1 1.60 19.1 19.1 1.74 18.0 18.0 1.88
57 21.2 21.2 1.45 20.1 20.1 1.60 19.1 19.1 1.74 18.0 18.0 1.88
820
72 26.3 14.3 1.46 24.7 13.8 1.63 23.1 13.3 1.79 21.5 12.7 1.95
67 23.8 18.4 1.46 22.3 17.9 1.62 20.9 17.3 1.77 19.4 16.8 1.91
63‡‡ 22.0 17.8 1.46 20.6 17.2 1.61 19.2 16.6 1.75 17.8 16.0 1.89
62 21.9 21.9 1.46 20.8 20.8 1.61 19.7 19.7 1.76 18.6 18.6 1.90
57 21.9 21.9 1.46 20.8 20.8 1.61 19.7 19.7 1.76 18.6 18.6 1.90
950
72 26.9 15.4 1.47 25.2 14.8 1.64 23.6 14.3 1.80 21.9 13.7 1.96
67 24.3 20.1 1.47 22.8 19.5 1.63 21.3 18.9 1.78 19.8 18.4 1.93
63‡‡ 22.5 19.3 1.47 21.1 18.7 1.62 19.6 18.1 1.77 18.2 17.5 1.91
62 23.0 23.0 1.47 21.8 21.8 1.63 20.6 20.6 1.78 19.4 19.4 1.93
57 23.0 23.0 1.47 21.8 21.8 1.63 20.6 20.6 1.78 19.4 19.4 1.93
1075
72 27.2 16.3 1.48 25.6 15.8 1.65 23.9 15.2 1.82 22.2 14.7 1.98
67 24.8 21.6 1.48 23.2 21.0 1.64 21.7 20.4 1.80 20.2 19.8 1.95
63‡‡ 22.9 20.7 1.48 21.4 20.1 1.64 20.0 19.5 1.78 18.6 18.6 1.92
62 23.9 23.9 1.48 22.6 22.6 1.64 21.3 21.3 1.80 20.1 20.1 1.95
57 23.9 23.9 1.48 22.6 22.6 1.64 21.3 21.3 1.80 20.1 20.1 1.95
1200
72 27.5 17.2 1.49 25.8 16.7 1.66 24.1 16.1 1.83 22.4 15.6 1.99
67 25.1 23.1 1.49 23.5 22.5 1.65 22.0 21.8 1.81 20.6 20.6 1.97
63‡‡ 23.2 22.1 1.49 21.8 21.4 1.65 20.4 20.4 1.80 19.1 19.1 1.94
62 24.6 24.6 1.49 23.3 23.3 1.65 22.0 22.0 1.81 20.6 20.6 1.97
57 24.6 24.6 1.49 23.3 23.3 1.65 22.0 22.0 1.81 20.6 20.6 1.97
Multipliers for Determining the Performance With Other Indoor Sections
Indoor
Section Size Cooling Indoor Section Size Cooling Capacity Sensible†† Power Capacity Sensible†† Power
F(A,B)4ANF 036 0.91 0.91 1.28 CE3AA 036 0.91 0.90 1.03
F(A,B)4AN(F,B) 042 0.95 0.95 1.24 042 0.95 0.92 1.03
FC4BN(F,B) 042 0.95 0.95 1.24 CJ5A/CK5A/CK5BA 036 0.95 0.95 1.06
FC4BNF 036 0.91 0.91 1.28 CJ5A/CK5A/CK5BN 042 0.95 0.95 1.06
FK4CNB 006 1.00 1.00 1.00 CK3BA 036 0.95 0.95 1.06
FK4CNF 001 0.91 0.90 1.02 042 0.95 0.95 1.06
002 0.94 0.91 1.02 COILS + 58MVP080-14VARIABLE-SPEED FURNACE
003 0.94 0.91 1.01 CC5A/CD5A/CD5BA 036 0.95 0.92 1.02
005 0.97 0.94 1.00 042 0.95 0.92 1.02
CC5A/CD5A/CD5BA 036 0.95 0.91 1.14 CC5A/CD5A/CD5BW 042 0.95 0.90 1.02
042 0.95 0.91 1.14 CD5A/CD5BW 036 0.95 0.92 1.02
CC5A/CD5A/CD5BW 042 0.94 0.90 1.14 CD3(A,B)A 036 0.95 0.92 1.02
CD5A/CD5BW 036 0.95 0.91 1.14 042 0.95 0.92 1.02
CD3(A,B)A 036 0.95 0.91 1.14 CE3AA 036 0.91 0.91 1.02
042 0.95 0.91 1.14 042 0.95 0.93 1.02
CE3AA 036 0.91 0.90 1.14 CJ5A/CK5A/CK5BA 042 0.95 0.95 1.04
042 0.95 0.93 1.14 CJ5A/CK5A/CK5BW 036 0.95 0.95 1.04
CF5AA 036 0.95 0.91 1.14 CK3BA 036 0.95 0.95 1.04
CJ5A/CK5A/CK5BA 036 0.95 0.95 1.16 042 0.95 0.95 1.04
042 0.95 0.95 1.16 COILS + 58MVP100-20 VARIABLE-SPEED FURNACE
CJ5A/CK5A/CK5BN 042 0.95 0.95 1.16 CC5A/CD5A/CD5BA 036 0.95 0.92 1.02
060 0.95 0.95 1.16 042 0.95 0.92 1.02
CJ5A/CK5A/CK5BW 036 0.95 0.95 1.16 CC5A/CD5A/CD5BW 042 0.95 0.90 1.02
CK3BA 036 0.95 0.95 1.16 CD5A/CD5BW 036 0.95 0.92 1.02
042 0.95 0.95 1.16 CD3(A,B)A 036 0.95 0.92 1.02
COILS + 58MVP060-14VARIABLE-SPEED FURNACE 042 0.95 0.92 1.02
CC5A/CD5A/CD5BA 036 0.95 0.91 1.03 CE3AA 036 0.91 0.91 1.02
042 0.95 0.91 1.03 042 0.95 0.93 1.02
CC5A/CD5A/CD5BW 042 0.95 0.90 1.03 CJ5A/CK5A/CK5BA 042 0.95 0.95 1.04
CD5A/CD5BW 036 0.95 0.91 1.03 CJ5A/CK5A/CK5BW 036 0.95 0.94 1.04
CD3(A,B)A 036 0.95 0.91 1.03 CK3BA 036 0.95 0.95 1.04
042 0.95 0.91 1.03 042 0.95 0.95 1.04

14
Detailed cooling capacities* continued
See notes on pg. 20.
EVAPORATOR
AIR CONDENSER ENTERING AIRTEMPERATURES °F 85 95 105 115
CFM EWB
Capacity
MBtuh† Total
System
Kw**
Capacity
MBtuh† Total
System
Kw**
Capacity
MBtuh† Total
System
Kw**
Capacity
MBtuh† Total
System
Kw**Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡
38YDA036-30 Outdoor Section in Low-SpeedWith FK4CNB006 Indoor Section continued
670
72 25.4 13.1 1.45 23.9 12.6 1.61 22.4 12.1 1.77 20.9 11.5 1.93
67 23.0 16.5 1.45 21.6 15.9 1.60 20.2 15.4 1.75 18.8 14.8 1.89
63‡‡ 21.2 15.9 1.45 19.9 15.3 1.59 18.6 14.8 1.73 17.3 14.2 1.86
62 20.8 19.8 1.45 19.5 19.2 1.59 18.4 18.4 1.73 17.4 17.4 1.87
57 20.4 20.4 1.45 19.4 19.4 1.59 18.4 18.4 1.73 17.4 17.4 1.87
745
72 25.9 13.7 1.45 24.4 13.2 1.62 22.8 12.7 1.78 21.3 12.1 1.94
67 23.5 17.5 1.46 22.0 16.9 1.61 20.6 16.4 1.76 19.2 15.8 1.90
63‡‡ 21.6 16.9 1.46 20.3 16.3 1.60 18.9 15.7 1.74 17.6 15.2 1.88
62 21.3 21.1 1.46 20.1 20.1 1.60 19.1 19.1 1.74 18.0 18.0 1.88
57 21.2 21.2 1.45 20.1 20.1 1.60 19.1 19.1 1.74 18.0 18.0 1.88
820
72 26.3 14.3 1.46 24.7 13.8 1.63 23.1 13.3 1.79 21.5 12.7 1.95
67 23.8 18.4 1.46 22.3 17.9 1.62 20.9 17.3 1.77 19.4 16.8 1.91
63‡‡ 22.0 17.8 1.46 20.6 17.2 1.61 19.2 16.6 1.75 17.8 16.0 1.89
62 21.9 21.9 1.46 20.8 20.8 1.61 19.7 19.7 1.76 18.6 18.6 1.90
57 21.9 21.9 1.46 20.8 20.8 1.61 19.7 19.7 1.76 18.6 18.6 1.90
950
72 26.9 15.4 1.47 25.2 14.8 1.64 23.6 14.3 1.80 21.9 13.7 1.96
67 24.3 20.1 1.47 22.8 19.5 1.63 21.3 18.9 1.78 19.8 18.4 1.93
63‡‡ 22.5 19.3 1.47 21.1 18.7 1.62 19.6 18.1 1.77 18.2 17.5 1.91
62 23.0 23.0 1.47 21.8 21.8 1.63 20.6 20.6 1.78 19.4 19.4 1.93
57 23.0 23.0 1.47 21.8 21.8 1.63 20.6 20.6 1.78 19.4 19.4 1.93
1075
72 27.2 16.3 1.48 25.6 15.8 1.65 23.9 15.2 1.82 22.2 14.7 1.98
67 24.8 21.6 1.48 23.2 21.0 1.64 21.7 20.4 1.80 20.2 19.8 1.95
63‡‡ 22.9 20.7 1.48 21.4 20.1 1.64 20.0 19.5 1.78 18.6 18.6 1.92
62 23.9 23.9 1.48 22.6 22.6 1.64 21.3 21.3 1.80 20.1 20.1 1.95
57 23.9 23.9 1.48 22.6 22.6 1.64 21.3 21.3 1.80 20.1 20.1 1.95
1200
72 27.5 17.2 1.49 25.8 16.7 1.66 24.1 16.1 1.83 22.4 15.6 1.99
67 25.1 23.1 1.49 23.5 22.5 1.65 22.0 21.8 1.81 20.6 20.6 1.97
63‡‡ 23.2 22.1 1.49 21.8 21.4 1.65 20.4 20.4 1.80 19.1 19.1 1.94
62 24.6 24.6 1.49 23.3 23.3 1.65 22.0 22.0 1.81 20.6 20.6 1.97
57 24.6 24.6 1.49 23.3 23.3 1.65 22.0 22.0 1.81 20.6 20.6 1.97
Multipliers for Determining the Performance With Other Indoor Sections
Indoor
Section Size Cooling Indoor Section Size Cooling Capacity Sensible†† Power Capacity Sensible†† Power
COILS + 58U(H,X)V060-12VARIABLE-SPEED FURNACE COILS + 58U(H,X)V100-20VARIABLE-SPEED FURNACE
CC5A/CD5A/CD5BA 036 0.94 0.84 1.00 CC5A/CD5A/CD5BA 036 0.95 0.92 1.01
042 0.94 0.84 0.99 042 0.95 0.92 1.00
CC5A/CD5A/CD5BW 042 0.94 0.83 0.99 CC5A/CD5A/CD5BW 042 0.95 0.91 1.00
CD5A/CD5BA 036 0.94 0.84 1.00 CD5A/CD5BW 036 0.95 0.92 1.01
CD3(A,B)A 036 0.94 0.84 1.00 CD3(A,B)A 036 0.95 0.92 1.01
042 0.94 0.84 0.99 042 0.95 0.92 1.00
CD3CA 036 0.92 0.82 0.99 CD3CA 036 0.95 0.89 0.99
042 0.92 0.82 0.99 042 0.95 0.89 0.99
CE3AA 036 0.93 0.83 1.00 CE3AA 036 0.95 0.91 1.01
042 0.94 0.84 0.99 042 0.95 0.93 1.00
CJ5A/CK5A/CK5BA 036 0.94 0.90 1.02 CJ5A/CK5A/CK5BA 042 0.95 0.95 1.02
CK3BA 036 0.94 0.90 1.02 CJ5A/CK5A/CK5BW 036 0.95 0.95 1.02
042 0.94 0.90 1.02 CK3BA 036 0.95 0.95 1.03
COILS + 58U(H,X)V080-16VARIABLE-SPEED FURNACE 042 0.95 0.95 1.02
CC5A/CD5A/CD5BA 036 0.95 0.90 1.00 COILS + 58U(H,X)V120-20VARIABLE-SPEED FURNACE
042 0.95 0.90 1.00 CC5A/CD5A/CD5BA 036 0.95 0.93 1.01
CC5A/CD5A/CD5BW 042 0.95 0.89 1.00 042 0.95 0.93 1.00
CD5A/CD5BW 036 0.95 0.90 1.00 CC5A/CD5A/CD5BW 042 0.95 0.92 1.00
CD3(A,B)A 036 0.95 0.90 1.00 CD5A/CD5BW 036 0.95 0.93 1.01
042 0.95 0.90 1.00 CD3(A,B)A 036 0.95 0.93 1.01
CD3CA 036 0.92 0.88 0.99 042 0.95 0.93 1.00
042 0.94 0.88 0.99 CD3CA 036 0.95 0.91 0.99
CE3AA 036 0.95 0.88 1.00 042 0.95 0.91 0.99
042 0.95 0.91 1.00 CE3AA 036 0.95 0.92 1.01
CJ5A/CK5A/CK5BA 042 0.95 0.95 1.02 042 0.95 0.94 1.00
CJ5A/CK5A/CK5BW 036 0.95 0.95 1.02 CJ5A/CK5A/CK5BA 042 0.95 0.95 1.02
CK3BA 036 0.95 0.95 1.02 CJ5A/CK5A/CK5BW 036 0.95 0.95 1.02
042 0.95 0.95 1.02 CK3BA 036 0.95 0.95 1.03
———— 0420.95 0.95 1.02

15
Detailed cooling capacities* continued
See notes on pg. 20.
EVAPORATOR
AIR CONDENSER ENTERING AIRTEMPERATURES °F 85 95 105 115
CFM EWB
Capacity
MBtuh† Total
System
Kw**
Capacity
MBtuh† Total
System
Kw**
Capacity
MBtuh† Total
System
Kw**
Capacity
MBtuh† Total
System
Kw**Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡
38YDA048-30 Outdoor Section in High-SpeedWith FK4CNB006 Indoor Section
1070
72 55.5 26.6 4.69 53.0 25.6 5.04 50.5 24.6 5.39 47.9 23.7 5.73
67 50.5 32.4 4.54 48.2 31.4 4.86 45.9 30.4 5.18 43.3 29.4 5.48
63‡‡ 46.9 31.6 4.42 44.7 30.6 4.73 42.4 29.6 5.02 40.0 28.5 5.28
62 45.9 38.1 4.39 43.8 37.1 4.69 41.6 36.0 4.97 39.1 34.9 5.23
57 42.6 42.6 4.28 40.9 40.9 4.57 39.2 39.2 4.86 37.4 37.4 5.12
1200
72 56.8 27.7 4.76 54.1 26.7 5.11 51.5 25.7 5.47 48.8 24.7 5.82
67 51.7 34.2 4.61 49.3 33.2 4.94 46.8 32.1 5.27 44.3 31.1 5.57
63‡‡ 48.1 33.3 4.49 45.8 32.3 4.80 43.5 31.2 5.10 40.9 30.1 5.38
62 47.1 40.6 4.46 44.8 39.5 4.77 42.6 38.4 5.06 40.1 37.3 5.33
57 44.5 44.5 4.38 42.8 42.8 4.68 40.9 40.9 4.98 39.0 39.0 5.26
1325
72 57.8 28.7 4.83 55.0 27.7 5.18 52.3 26.7 5.54 49.5 25.7 5.89
67 52.7 35.8 4.67 50.2 34.8 5.00 47.7 33.8 5.33 45.0 32.7 5.65
63‡‡ 49.0 34.9 4.55 46.6 33.8 4.87 44.2 32.7 5.17 41.6 31.6 5.45
62 48.0 42.8 4.52 45.7 41.7 4.83 43.4 40.7 5.14 40.9 39.5 5.41
57 46.1 46.1 4.46 44.3 44.3 4.78 42.4 42.4 5.09 40.4 40.4 5.38
1470
72 58.8 29.8 4.89 55.9 28.7 5.25 53.1 27.8 5.61 50.2 26.7 5.97
67 53.6 37.7 4.74 51.0 36.6 5.07 48.4 35.6 5.41 45.7 34.5 5.72
63‡‡ 49.9 36.6 4.62 47.4 35.5 4.94 44.9 34.5 5.24 42.3 33.3 5.53
62 49.0 45.4 4.59 46.7 44.2 4.91 44.3 43.1 5.21 41.9 41.7 5.50
57 47.7 47.7 4.55 45.8 45.8 4.87 43.9 43.9 5.20 41.8 41.8 5.50
1625
72 59.7 31.0 4.95 56.6 29.9 5.31 53.7 28.9 5.68 50.8 27.9 6.04
67 54.5 39.6 4.80 51.8 38.5 5.13 49.1 37.5 5.47 46.3 36.4 5.80
63‡‡ 50.6 38.4 4.68 48.1 37.3 5.00 45.6 36.2 5.32 42.9 35.1 5.61
62 49.9 47.9 4.66 47.6 46.7 4.98 45.2 45.2 5.30 43.1 43.1 5.62
57 49.2 49.2 4.64 47.2 47.2 4.97 45.2 45.2 5.30 43.0 43.0 5.62
Multipliers for Determining the Performance With Other Indoor Sections
Indoor
Section Size Cooling Indoor Section Size Cooling Capacity Sensible†† Power Capacity Sensible†† Power
F(A,B)4AN(F,B) 048 0.94 0.94 1.05 CC5A/CD5A/CD5BW 048 0.92 0.88 1.01
060 0.98 0.98 1.08 060 0.94 0.93 1.02
FB4ANB 070 1.01 1.01 1.07 CD5A/CD5BA 048 0.92 0.89 1.01
FC4BN(F,B) 048 0.94 0.94 1.05 CD3(A,B)A 048 0.92 0.89 1.01
060 0.98 0.98 1.08 060 0.92 0.89 1.01
FC4BNB 070 1.01 1.01 1.07 CE3AA 048 0.92 0.92 1.02
FK4CNB 006 1.00 1.00 1.00 060 0.94 0.94 1.02
FK4CNF 005 0.96 0.96 1.01 CJ5A/CK5A/CK5BA 048 0.91 0.91 1.03
CC5A/CD5A/CD5BA 060 0.94 0.94 1.04 060 0.92 0.92 1.04
CC5A/CD5A/CD5BW 048 0.94 0.94 1.03 CJ5A/CK5A/CK5BN 060 0.94 0.94 1.04
060 0.96 0.96 1.05 CJ5A/CK5A/CK5BX 060 0.94 0.94 1.04
CD5A/CD5BA 048 0.94 0.94 1.03 CK3BA 048 0.91 0.91 1.03
CD3(A,B)A 048 0.94 0.94 1.03 060 0.92 0.92 1.04
060 0.94 0.94 1.04 COILS + 58U(H,X)V080-16 VARIABLE-SPEED FURNACE
CE3AA 048 0.94 0.94 1.04 CC5A/CD5A/CD5BA 060 0.92 0.87 0.99
060 0.96 0.96 1.05 CC5A/CD5A/CD5BC 048 0.90 0.85 0.99
CF5AA 048 0.94 0.94 1.04 CC5A/CD5A/CD5BW 048 0.90 0.87 0.99
CJ5A/CK5A/CK5BA 048 0.93 0.93 1.05 060 0.94 0.91 1.00
060 0.94 0.94 1.06 CD3(A,B)A 048 0.90 0.87 1.00
CJ5A/CK5A/CK5BN 060 0.96 0.96 1.07 060 0.92 0.87 0.99
CJ5A/CK5A/CK5BW 048 0.92 0.92 1.05 CD3CA 048 0.90 0.86 0.97
CJ5A/CK5A/CK5BX 060 0.96 0.96 1.07 060 0.92 0.90 0.98
CK3BA 048 0.92 0.92 1.05 CE3AA 048 0.92 0.90 1.00
060 0.94 0.94 1.06 060 0.94 0.93 1.00
COILS + 58MVP100-20VARIABLE-SPEED FURNACE CJ5A/CK5A/CK5BA 048 0.90 0.90 1.01
CC5A/CD5A/CD5BA 060 0.92 0.89 1.01 CK3BA 048 0.90 0.90 1.01
———— 0600.92 0.92 1.02

16
Detailed cooling capacities* continued
See notes on pg. 20.
EVAPORATOR
AIR CONDENSER ENTERING AIRTEMPERATURES °F 85 95 105 115
CFM EWB
Capacity
MBtuh† Total
System
Kw**
Capacity
MBtuh† Total
System
Kw**
Capacity
MBtuh† Total
System
Kw**
Capacity
MBtuh† Total
System
Kw**Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡
38YDA048-30 Outdoor Section in High-SpeedWith FK4CNB006 Indoor Section continued
1070
72 55.5 26.6 4.69 53.0 25.6 5.04 50.5 24.6 5.39 47.9 23.7 5.73
67 50.5 32.4 4.54 48.2 31.4 4.86 45.9 30.4 5.18 43.3 29.4 5.48
63‡‡ 46.9 31.6 4.42 44.7 30.6 4.73 42.4 29.6 5.02 40.0 28.5 5.28
62 45.9 38.1 4.39 43.8 37.1 4.69 41.6 36.0 4.97 39.1 34.9 5.23
57 42.6 42.6 4.28 40.9 40.9 4.57 39.2 39.2 4.86 37.4 37.4 5.12
1200
72 56.8 27.7 4.76 54.1 26.7 5.11 51.5 25.7 5.47 48.8 24.7 5.82
67 51.7 34.2 4.61 49.3 33.2 4.94 46.8 32.1 5.27 44.3 31.1 5.57
63‡‡ 48.1 33.3 4.49 45.8 32.3 4.80 43.5 31.2 5.10 40.9 30.1 5.38
62 47.1 40.6 4.46 44.8 39.5 4.77 42.6 38.4 5.06 40.1 37.3 5.33
57 44.5 44.5 4.38 42.8 42.8 4.68 40.9 40.9 4.98 39.0 39.0 5.26
1325
72 57.8 28.7 4.83 55.0 27.7 5.18 52.3 26.7 5.54 49.5 25.7 5.89
67 52.7 35.8 4.67 50.2 34.8 5.00 47.7 33.8 5.33 45.0 32.7 5.65
63‡‡ 49.0 34.9 4.55 46.6 33.8 4.87 44.2 32.7 5.17 41.6 31.6 5.45
62 48.0 42.8 4.52 45.7 41.7 4.83 43.4 40.7 5.14 40.9 39.5 5.41
57 46.1 46.1 4.46 44.3 44.3 4.78 42.4 42.4 5.09 40.4 40.4 5.38
1470
72 58.8 29.8 4.89 55.9 28.7 5.25 53.1 27.8 5.61 50.2 26.7 5.97
67 53.6 37.7 4.74 51.0 36.6 5.07 48.4 35.6 5.41 45.7 34.5 5.72
63‡‡ 49.9 36.6 4.62 47.4 35.5 4.94 44.9 34.5 5.24 42.3 33.3 5.53
62 49.0 45.4 4.59 46.7 44.2 4.91 44.3 43.1 5.21 41.9 41.7 5.50
57 47.7 47.7 4.55 45.8 45.8 4.87 43.9 43.9 5.20 41.8 41.8 5.50
1625
72 59.7 31.0 4.95 56.6 29.9 5.31 53.7 28.9 5.68 50.8 27.9 6.04
67 54.5 39.6 4.80 51.8 38.5 5.13 49.1 37.5 5.47 46.3 36.4 5.80
63‡‡ 50.6 38.4 4.68 48.1 37.3 5.00 45.6 36.2 5.32 42.9 35.1 5.61
62 49.9 47.9 4.66 47.6 46.7 4.98 45.2 45.2 5.30 43.1 43.1 5.62
57 49.2 49.2 4.64 47.2 47.2 4.97 45.2 45.2 5.30 43.0 43.0 5.62
Multipliers for Determining the Performance With Other Indoor Sections
Indoor
Section Size Cooling Indoor Section Size Cooling Capacity Sensible†† Power Capacity Sensible†† Power
COILS + 58U(H,X)V100-20VARIABLE-SPEED FURNACE COILS + 58U(H,X)V120-20VARIABLE-SPEED FURNACE
CC5A/CD5A/CD5BA 060 0.92 0.87 0.96 CC5A/CD5A/CD5BA 060 0.92 0.87 0.97
CC5A/CD5A/CD5BC 048 0.92 0.89 0.88 CC5A/CD5A/CD5BC 048 0.92 0.86 0.97
CC5A/CD5A/CD5BW 048 0.92 0.87 0.96 CC5A/CD5A/CD5BW 048 0.92 0.87 0.97
060 0.94 0.91 0.97 060 0.94 0.90 0.98
CD5A/CD5BA 048 0.92 0.87 0.96 CD5A/CD5B 048 0.92 0.87 0.96
CD3(A,B)A 048 0.92 0.87 0.96 CD3(A,B)A 048 0.92 0.87 0.97
060 0.92 0.87 0.96 060 0.92 0.87 0.97
CD3CA 048 0.91 0.86 0.94 CD3CA 048 0.91 0.85 0.95
060 0.92 0.89 0.95 060 0.92 0.89 0.96
CE3AA 048 0.92 0.90 0.97 CE3AA 048 0.92 0.90 0.98
060 0.94 0.93 0.97 060 0.94 0.93 0.98
CJ5A/CK5A/CK5BA 060 0.92 0.92 0.99 CJ5A/CK5A/CK5BA 060 0.92 0.92 0.99
CJ5A/CK5A/CK5BW 048 0.92 0.92 0.98 CJ5A/CK5A/CK5BW 048 0.92 0.92 0.99
CJ5A/CK5A/CK5BX 060 0.94 0.94 0.99 CJ5A/CK5A/CK5BX 060 0.94 0.94 1.00
CK3BA 048 0.92 0.92 0.98 CK3BA 048 0.92 0.92 0.99
060 0.94 0.94 0.99 060 0.92 0.92 0.99

17
Detailed cooling capacities* continued
See notes on pg. 20.
EVAPORATOR
AIR CONDENSER ENTERING AIRTEMPERATURES °F 85 95 105 115
CFM EWB
Capacity
MBtuh† Total
System
Kw**
Capacity
MBtuh† Total
System
Kw**
Capacity
MBtuh† Total
System
Kw**
Capacity
MBtuh† Total
System
Kw**Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡
38YDA048-30 Outdoor Section in Low-SpeedWith FK4CNB006 Indoor Section
895
72 33.0 17.3 1.97 31.1 16.6 2.19 29.2 16.0 2.40 27.4 15.3 2.61
67 29.8 21.9 1.97 28.1 21.2 2.17 26.4 20.6 2.37 24.7 19.9 2.56
63‡‡ 27.6 21.2 1.97 26.0 20.5 2.16 24.3 19.8 2.34 22.7 19.1 2.51
62 27.1 26.4 1.97 25.6 25.6 2.15 24.3 24.3 2.34 23.1 23.1 2.52
57 26.8 26.8 1.96 25.6 25.6 2.15 24.3 24.3 2.34 23.0 23.0 2.52
995
72 33.5 18.1 1.98 31.6 17.4 2.20 29.6 16.8 2.42 27.7 16.1 2.63
67 30.4 23.2 1.98 28.6 22.6 2.19 26.8 21.9 2.39 25.1 21.2 2.58
63‡‡ 28.1 22.4 1.98 26.4 21.7 2.17 24.7 21.0 2.35 23.1 20.3 2.53
62 27.9 27.9 1.98 26.5 26.5 2.17 25.2 25.2 2.36 23.8 23.8 2.55
57 27.9 27.9 1.98 26.5 26.5 2.17 25.2 25.2 2.36 23.8 23.8 2.55
1095
72 33.9 18.9 1.99 32.0 18.2 2.21 30.0 17.6 2.43 28.0 16.9 2.64
67 30.8 24.5 1.99 29.0 23.8 2.20 27.2 23.1 2.40 25.4 22.5 2.60
63‡‡ 28.5 23.6 1.99 26.8 22.9 2.19 25.1 22.2 2.37 23.4 21.5 2.55
62 28.7 28.7 1.99 27.3 27.3 2.19 25.9 25.9 2.38 24.5 24.5 2.58
57 28.7 28.7 1.99 27.3 27.3 2.19 25.9 25.9 2.38 24.5 24.5 2.58
1200
72 34.3 19.7 2.00 32.3 19.0 2.23 30.3 18.4 2.45 28.3 17.7 2.66
67 31.2 25.8 2.01 29.3 25.1 2.21 27.5 24.4 2.42 25.7 23.7 2.61
63‡‡ 28.9 24.9 2.00 27.1 24.1 2.20 25.4 23.4 2.39 23.7 22.7 2.57
62 29.5 29.5 2.00 28.1 28.1 2.21 26.6 26.6 2.41 25.1 25.1 2.60
57 29.5 29.5 2.00 28.1 28.1 2.21 26.6 26.6 2.41 25.1 25.1 2.60
1325
72 34.7 20.6 2.01 32.7 20.0 2.24 30.6 19.3 2.47 28.6 18.6 2.68
67 31.6 27.4 2.02 29.7 26.7 2.23 27.8 25.9 2.44 26.0 25.2 2.64
63‡‡ 29.2 26.3 2.02 27.4 25.5 2.22 25.7 24.8 2.41 24.0 23.9 2.60
62 30.4 30.4 2.02 28.8 28.8 2.23 27.3 27.3 2.43 25.8 25.8 2.63
57 30.4 30.4 2.02 28.9 28.9 2.23 27.3 27.3 2.43 25.8 25.8 2.63
1450
72 35.0 21.5 2.03 32.9 20.9 2.26 30.8 20.2 2.48 28.8 19.6 2.70
67 31.9 28.9 2.03 30.0 28.1 2.25 28.1 27.3 2.46 26.4 26.4 2.66
63‡‡ 29.6 27.6 2.03 27.8 26.8 2.23 26.1 25.9 2.43 24.5 24.5 2.62
62 31.1 31.1 2.03 29.6 29.6 2.25 27.9 27.9 2.45 26.4 26.4 2.66
57 31.1 31.1 2.03 29.5 29.5 2.25 28.0 28.0 2.45 26.4 26.4 2.66
Multipliers for Determining the Performance With Other Indoor Sections
Indoor
Section Size Cooling Indoor Section Size Cooling Capacity Sensible†† Power Capacity Sensible†† Power
F(A,B)4AN(F,B) 048 0.98 0.98 1.26 CD5A/CD5BA 048 0.91 0.87 1.00
060 1.00 1.00 1.30 CD3(A,B)A 048 0.91 0.87 1.00
FB4ANB 070 1.00 1.00 1.26 060 0.91 0.87 1.00
FC4BNB 070 1.00 1.00 1.26 CE3AA 048 0.91 0.89 1.01
FC4BN(F,B) 048 0.98 0.98 1.26 060 0.92 0.91 1.01
060 1.00 1.00 1.30 CJ5A/CK5A/CK5BA 048 0.94 0.94 1.02
FK4CNB 006 1.00 1.00 1.00 060 0.94 0.94 1.03
FK4CNF 005 0.96 0.94 1.00 CJ5A/CK5A/CK5BN 060 0.97 0.97 1.03
CC5A/CD5A/CD5BA 060 0.91 0.86 1.10 CJ5A/CK5A/CK5BX 060 0.97 0.97 1.02
CC5A/CD5A/CD5BW 048 0.91 0.87 1.10 CK3BA 048 0.94 0.94 1.02
060 0.94 0.90 1.10 060 0.94 0.94 1.03
CD5A/CD5BA 048 0.91 0.87 1.10 COILS + 58U(H,X)V080-16VARIABLE-SPEED FURNACE
CD3(A,B)A 048 0.91 0.87 1.10 CC5A/CD5A/CD5BA 060 0.92 0.85 0.99
060 0.91 0.86 1.10 CC5A/CD5A/CD5BC 048 0.91 0.83 0.99
CE3AA 048 0.91 0.89 1.10 CC5A/CD5A/CD5BW 048 0.91 0.85 0.99
060 0.94 0.91 1.10 060 0.94 0.88 0.99
CF5AA 048 0.91 0.87 1.10 CD5A/CD5BA 048 0.91 0.85 0.99
CJ5A/CK5A/CK5BA 048 0.96 0.95 1.12 CD3(A,B)A 048 0.91 0.85 0.99
060 0.97 0.96 1.12 060 0.92 0.85 0.99
CJ5A/CK5A/CK5BN 060 0.98 0.98 1.12 CD3CA 048 0.91 0.85 0.98
CJ5A/CK5A/CK5BW 048 0.96 0.95 1.12 060 0.92 0.87 0.98
CJ5A/CK5A/CK5BX 060 0.98 0.98 1.12 CE3AA 048 0.92 0.87 0.99
CK3BA 048 0.96 0.95 1.12 060 0.94 0.89 0.99
060 0.97 0.96 1.12 CJ5A/CK5A/CK5BA 048 0.91 0.91 1.01
COILS + 58MVP100-20VARIABLE-SPEED FURNACE CK3BA 048 0.91 0.91 1.01
CC5A/CD5A/CD5BA 060 0.91 0.87 1.00 060 0.91 0.91 1.02
CC5A/CD5A/CD5BW 048 0.91 0.87 1.00 ————
060 0.92 0.90 1.00

18
Detailed cooling capacities* continued
See notes on pg. 20.
EVAPORATOR
AIR CONDENSER ENTERING AIRTEMPERATURES °F 85 95 105 115
CFM EWB
Capacity
MBtuh† Total
System
Kw**
Capacity
MBtuh† Total
System
Kw**
Capacity
MBtuh† Total
System
Kw**
Capacity
MBtuh† Total
System
Kw**Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡
38YDA048-30 Outdoor Section in Low-SpeedWith FK4CNB006 Indoor Section continued
895
72 33.0 17.3 1.97 31.1 16.6 2.19 29.2 16.0 2.40 27.4 15.3 2.61
67 29.8 21.9 1.97 28.1 21.2 2.17 26.4 20.6 2.37 24.7 19.9 2.56
63‡‡ 27.6 21.2 1.97 26.0 20.5 2.16 24.3 19.8 2.34 22.7 19.1 2.51
62 27.1 26.4 1.97 25.6 25.6 2.15 24.3 24.3 2.34 23.1 23.1 2.52
57 26.8 26.8 1.96 25.6 25.6 2.15 24.3 24.3 2.34 23.0 23.0 2.52
995
72 33.5 18.1 1.98 31.6 17.4 2.20 29.6 16.8 2.42 27.7 16.1 2.63
67 30.4 23.2 1.98 28.6 22.6 2.19 26.8 21.9 2.39 25.1 21.2 2.58
63‡‡ 28.1 22.4 1.98 26.4 21.7 2.17 24.7 21.0 2.35 23.1 20.3 2.53
62 27.9 27.9 1.98 26.5 26.5 2.17 25.2 25.2 2.36 23.8 23.8 2.55
57 27.9 27.9 1.98 26.5 26.5 2.17 25.2 25.2 2.36 23.8 23.8 2.55
1095
72 33.9 18.9 1.99 32.0 18.2 2.21 30.0 17.6 2.43 28.0 16.9 2.64
67 30.8 24.5 1.99 29.0 23.8 2.20 27.2 23.1 2.40 25.4 22.5 2.60
63‡‡ 28.5 23.6 1.99 26.8 22.9 2.19 25.1 22.2 2.37 23.4 21.5 2.55
62 28.7 28.7 1.99 27.3 27.3 2.19 25.9 25.9 2.38 24.5 24.5 2.58
57 28.7 28.7 1.99 27.3 27.3 2.19 25.9 25.9 2.38 24.5 24.5 2.58
1200
72 34.3 19.7 2.00 32.3 19.0 2.23 30.3 18.4 2.45 28.3 17.7 2.66
67 31.2 25.8 2.01 29.3 25.1 2.21 27.5 24.4 2.42 25.7 23.7 2.61
63‡‡ 28.9 24.9 2.00 27.1 24.1 2.20 25.4 23.4 2.39 23.7 22.7 2.57
62 29.5 29.5 2.00 28.1 28.1 2.21 26.6 26.6 2.41 25.1 25.1 2.60
57 29.5 29.5 2.00 28.1 28.1 2.21 26.6 26.6 2.41 25.1 25.1 2.60
1325
72 34.7 20.6 2.01 32.7 20.0 2.24 30.6 19.3 2.47 28.6 18.6 2.68
67 31.6 27.4 2.02 29.7 26.7 2.23 27.8 25.9 2.44 26.0 25.2 2.64
63‡‡ 29.2 26.3 2.02 27.4 25.5 2.22 25.7 24.8 2.41 24.0 23.9 2.60
62 30.4 30.4 2.02 28.8 28.8 2.23 27.3 27.3 2.43 25.8 25.8 2.63
57 30.4 30.4 2.02 28.9 28.9 2.23 27.3 27.3 2.43 25.8 25.8 2.63
1450
72 35.0 21.5 2.03 32.9 20.9 2.26 30.8 20.2 2.48 28.8 19.6 2.70
67 31.9 28.9 2.03 30.0 28.1 2.25 28.1 27.3 2.46 26.4 26.4 2.66
63‡‡ 29.6 27.6 2.03 27.8 26.8 2.23 26.1 25.9 2.43 24.5 24.5 2.62
62 31.1 31.1 2.03 29.6 29.6 2.25 27.9 27.9 2.45 26.4 26.4 2.66
57 31.1 31.1 2.03 29.5 29.5 2.25 28.0 28.0 2.45 26.4 26.4 2.66
Multipliers for Determining the Performance With Other Indoor Sections
Indoor
Section Size Cooling Indoor Section Size Cooling Capacity Sensible†† Power Capacity Sensible†† Power
COILS + 58U(H,X)V100-20VARIABLE-SPEED FURNACE COILS + 58U(H,X)V120-20VARIABLE-SPEED FURNACE
CC5A/CD5A/CD5BA 060 0.93 0.84 0.97 CC5A/CD5A/CD5BA 060 0.93 0.87 0.98
CC5A/CD5A/CD5BC 048 0.93 0.82 0.98 CC5A/CD5A/CD5BC 048 0.93 0.86 0.98
CC5A/CD5A/CD5BW 048 0.93 0.84 0.98 CC5A/CD5A/CD5BW 048 0.93 0.87 0.98
060 0.94 0.86 0.98 060 0.94 0.90 0.98
CD5A/CD5BA 048 0.93 0.84 0.98 CD5A/CD5BA 048 0.93 0.88 0.98
CD3(A,B)A 048 0.93 0.84 0.98 CD3(A,B)A 048 0.93 0.88 0.98
060 0.94 0.84 0.97 060 0.93 0.87 0.98
CD3CA 048 0.92 0.83 0.97 CD3CA 048 0.92 0.87 0.97
060 0.93 0.86 0.97 060 0.93 0.90 0.97
CE3AA 048 0.93 0.86 0.98 CE3AA 048 0.93 0.90 1.01
060 0.94 0.88 0.98 060 0.94 0.92 0.98
CJ5A/CK5A/CK5BA 060 0.94 0.94 1.00 CJ5A/CK5A/CK5BA 060 0.94 0.94 1.01
CJ5A/CK5A/CK5BW 048 0.94 0.92 1.00 CJ5A/CK5A/CK5BW 048 0.94 0.94 1.01
CJ5A/CK5A/CK5BX 060 0.97 0.94 1.00 CJ5A/CK5A/CK5BX 060 0.97 0.97 1.01
CK3BA 048 0.94 0.92 1.00 CK3BA 048 0.94 0.94 1.01
060 0.94 0.94 1.00 060 0.94 0.94 1.01

19
Detailed cooling capacities* continued
See notes on pg. 20.
EVAPORATOR
AIR CONDENSER ENTERING AIRTEMPERATURES °F 85 95 105 115
CFM EWB
Capacity
MBtuh† Total
System
Kw**
Capacity
MBtuh† Total
System
Kw**
Capacity
MBtuh† Total
System
Kw**
Capacity
MBtuh† Total
System
Kw**Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡
38YDA060-30 Outdoor Section in High-SpeedWith FK4CNB006 Indoor Section
1325
72 62.6 30.2 5.51 59.5 29.0 5.89 56.4 27.8 6.25 53.1 26.6 6.59
67 57.0 37.3 5.33 54.2 36.0 5.67 51.2 34.7 5.99 48.1 33.5 6.30
63‡‡ 53.0 36.3 5.18 50.2 35.0 5.50 47.3 33.7 5.79 44.5 32.4 6.07
62 51.9 44.2 5.14 49.1 42.8 5.45 46.4 41.5 5.74 43.5 40.2 6.02
57 48.7 48.7 5.02 46.6 46.6 5.33 44.5 44.5 5.64 42.2 42.2 5.94
1500
72 64.0 31.5 5.62 60.8 30.3 6.01 57.4 29.0 6.37 54.1 27.8 6.71
67 58.4 39.4 5.43 55.4 38.2 5.79 52.2 36.9 6.11 49.0 35.6 6.42
63‡‡ 54.3 38.4 5.29 51.3 37.0 5.61 48.3 35.7 5.91 45.3 34.4 6.20
62 53.2 47.2 5.25 50.3 45.8 5.57 47.5 44.5 5.87 44.6 43.1 6.15
57 50.9 50.9 5.17 48.7 48.7 5.49 46.3 46.3 5.81 44.0 44.0 6.12
1650
72 65.0 32.5 5.70 61.6 31.3 6.10 58.2 30.1 6.46 54.7 28.9 6.81
67 59.3 41.2 5.52 56.2 40.0 5.87 53.0 38.7 6.21 49.7 37.4 6.52
63‡‡ 55.1 40.0 5.37 52.1 38.7 5.70 49.0 37.4 6.01 45.9 36.1 6.29
62 54.2 49.7 5.33 51.2 48.3 5.66 48.3 46.8 5.97 45.5 45.2 6.26
57 52.5 52.5 5.28 50.2 50.2 5.61 47.8 47.8 5.94 45.3 45.3 6.26
1835
72 65.9 33.8 5.80 62.5 32.6 6.19 59.0 31.4 6.57 55.4 30.1 6.91
67 60.2 43.4 5.61 57.0 42.1 5.97 53.7 40.8 6.31 50.3 39.5 6.62
63‡‡ 56.0 42.1 5.47 52.9 40.7 5.80 49.8 39.4 6.11 46.5 38.0 6.40
62 55.1 52.5 5.44 52.2 51.0 5.77 49.4 49.3 6.09 46.7 46.7 6.41
57 54.2 54.2 5.40 51.8 51.8 5.75 49.3 49.3 6.09 46.7 46.7 6.41
2025
72 66.6 35.0 5.89 63.1 33.8 6.29 59.6 32.6 6.66 55.9 31.3 7.01
67 61.0 45.5 5.70 57.7 44.2 6.07 54.3 42.9 6.41 50.9 41.6 6.72
63‡‡ 56.7 44.0 5.56 53.6 42.7 5.89 50.3 41.3 6.21 47.0 39.9 6.50
62 56.1 55.2 5.54 53.3 53.3 5.88 50.6 50.6 6.22 47.9 47.9 6.55
57 55.8 55.8 5.53 53.2 53.2 5.88 50.6 50.6 6.22 47.9 47.9 6.55
Multipliers for Determining the Performance With Other Indoor Sections
Indoor
Section Size Cooling Indoor Section Size Cooling Capacity Sensible†† Power Capacity Sensible†† Power
F(A,B)4AN(F,B) 060 0.98 0.98 1.05 CJ5A/CK5A/CK5BX 060 0.96 0.91 0.98
FB4ANB 070 1.00 1.00 1.04 CK3BA 060 0.94 0.88 0.97
FC4BN(F,B) 060 0.98 0.98 1.05 COILS + 58U(H,X)V100-20 VARIABLE-SPEED FURNACE
FC4BNB 070 1.00 1.00 1.04 CC5A/CD5A/CD5BA 060 0.93 0.90 0.98
FK4CNB 006 1.00 1.00 1.00 CC5A/CD5A/CD5BW 060 0.96 0.93 0.98
CC5A/CD5A/CD5BW 060 0.98 0.97 1.02 CD3(A,B)A 060 0.93 0.90 0.99
CD5A/CD5A/CD5BA 060 0.96 0.94 1.01 CD3CA 060 0.93 0.92 0.96
CD3(A,B)A 060 0.96 0.93 1.01 CE3AA 060 0.96 0.96 1.00
CE3AA 060 0.98 0.98 1.02 CJ5A/CK5A/CK5BA 060 0.95 0.95 0.99
CJ5A/CK5A/CK5BA 060 0.96 0.96 1.02 CJ5A/CK5A/CK5BX 060 0.97 0.97 1.00
CJ5A/CK5A/CK5BN 060 0.98 0.98 1.03 CK3BA 060 0.95 0.95 0.99
CJ5A/CK5A/CK5BX 060 0.98 0.98 1.03 COILS + 58U(H,X)V120-20 VARIABLE-SPEED FURNACE
CK3BA 060 0.96 0.96 1.02 CC5A/CD5A/CD5BA 060 0.93 0.88 0.99
COILS + 58MVP100-20VARIABLE-SPEED FURNACE CC5A/CD5A/CD5BW 060 0.96 0.92 0.99
CC5A/CD5A/CD5BA 060 0.92 0.83 0.96 CD3(A,B)A 060 0.93 0.88 0.99
CC5A/CD5A/CD5BW 060 0.95 0.87 0.96 CD3CA 060 0.93 0.90 0.96
CD3(A,B)A 060 0.92 0.83 0.96 CE3AA 060 0.96 0.96 1.01
CE3AA 060 0.95 0.89 0.97 CJ5A/CK5A/CK5BA 060 0.95 0.94 0.99
CJ5A/CK5A/CK5BA 060 0.94 0.88 0.97 CJ5A/CK5A/CK5BX 060 0.96 0.96 1.02
CJ5A/CK5A/CK5BN 060 0.96 0.91 0.98 CK3BA 060 0.95 0.94 0.99

20
Detailed cooling capacities* continued
* Detailed cooling capacities are based on indoor and outdoor unit at same elevation per ARI standard 210/240-94.If additional tubing length
and/or indoor unit is located above outdoor unit, a slight variation in capacity may occur.
† Total and sensible capacities are net capacities. Blower motor heat has been subtracted.
‡ Sensible capacities shown are based on 80°F (27°C) entering air at the indoor coil. For sensible capacities at other than 80°F (27°C), deduct
835 Btuh (245 kw) per 1000 CFM (480 L/S) of indoor coil air for each degree below 80°F (27°C), or add 835 Btuh (245°kw) per 1000 CFM
(480 L/S) of indoor coil air per degree above 80°F (27°C).When the required data falls between the published data, interpolation may be
performed.
** Unit kw is total of indoor and outdoor unit kilowatts.
†† Sensible capacity multipliers are based on the rated airflow of the listed indoor section.Refer to the airflow listed in the ‘‘Ratings and
Performance’’ table.
‡‡ At TVA rating indoor condition (75°EDB/63°EWB).All other indoor air temperatures are at 80°EDB.
EVAPORATOR
AIR CONDENSER ENTERING AIRTEMPERATURES °F 85 95 105 115
CFM EWB
Capacity
MBtuh† Total
System
Kw**
Capacity
MBtuh† Total
System
Kw**
Capacity
MBtuh† Total
System
Kw**
Capacity
MBtuh† Total
System
Kw**Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡
38YDA060-30 Outdoor Section in Low-SpeedWith FK4CNB006 Indoor Section
1115
72 36.5 19.6 2.05 34.7 19.0 2.42 32.8 18.3 2.77 30.8 17.6 3.08
67 33.2 25.3 2.14 31.5 24.6 2.48 29.7 23.9 2.78 27.8 23.1 3.06
63‡‡ 30.9 24.4 2.20 29.2 23.7 2.51 27.4 23.0 2.78 25.6 22.2 3.03
62 30.5 30.5 2.20 29.2 29.2 2.50 27.8 27.8 2.78 26.3 26.3 3.04
57 28.9 28.9 2.23 29.2 29.2 2.49 29.5 29.5 2.79 29.9 29.9 3.10
1240
72 37.0 20.5 2.05 35.1 19.9 2.43 33.2 19.2 2.78 31.1 18.5 3.10
67 33.7 26.8 2.15 32.0 26.1 2.49 30.1 25.4 2.80 28.2 24.6 3.08
63‡‡ 31.3 25.8 2.21 29.6 25.1 2.52 27.8 24.3 2.80 25.9 23.6 3.06
62 31.5 31.5 2.20 30.1 30.1 2.51 28.6 28.6 2.80 27.1 27.1 3.07
57 32.5 32.5 2.17 32.9 32.9 2.48 32.9 32.9 2.80 32.9 32.9 3.15
1365
72 37.3 21.4 2.06 35.5 20.8 2.44 33.5 20.1 2.80 31.4 19.4 3.12
67 34.1 28.2 2.15 32.3 27.5 2.50 30.5 26.8 2.82 28.5 26.1 3.11
63‡‡ 31.7 27.2 2.22 30.0 26.5 2.53 28.1 25.7 2.82 26.2 24.9 3.08
62 32.4 32.4 2.20 30.9 30.9 2.52 29.4 29.4 2.82 27.8 27.8 3.10
57 35.9 35.9 2.12 35.9 35.9 2.47 36.0 36.0 2.82 35.7 35.7 3.18
1500
72 37.7 22.3 2.07 35.8 21.7 2.46 33.8 21.1 2.82 31.6 20.4 3.14
67 34.5 29.8 2.16 32.7 29.1 2.52 30.8 28.3 2.84 28.8 27.5 3.13
63‡‡ 32.0 28.6 2.23 30.3 27.9 2.55 28.4 27.1 2.85 26.6 26.1 3.11
62 33.2 33.2 2.20 31.7 31.7 2.53 30.1 30.1 2.84 28.5 28.5 3.13
57 39.0 39.0 2.06 38.8 38.8 2.45 38.5 38.5 2.83 37.8 37.8 3.23
1625
72 37.9 23.2 2.08 36.0 22.6 2.47 34.0 21.9 2.83 31.8 21.2 3.16
67 34.8 31.1 2.17 33.0 30.4 2.53 31.1 29.6 2.86 29.1 28.7 3.15
63‡‡ 32.3 29.9 2.24 30.6 29.1 2.57 28.7 28.2 2.86 26.9 26.9 3.14
62 33.8 33.8 2.20 32.3 32.3 2.54 30.7 30.7 2.86 29.0 29.0 3.15
57 41.4 41.4 2.00 41.1 41.1 2.42 40.5 40.5 2.84 39.3 39.3 3.24
1750
72 38.1 24.1 2.09 36.2 23.4 2.48 34.2 22.8 2.85 32.0 22.1 3.18
67 35.0 32.4 2.18 33.3 31.7 2.55 31.4 30.8 2.88 29.5 29.5 3.18
63‡‡ 32.6 31.1 2.25 30.9 30.2 2.58 29.1 29.1 2.89 27.4 27.4 3.16
62 34.4 34.4 2.20 32.9 32.9 2.55 31.2 31.2 2.88 29.5 29.5 3.18
57 43.4 43.4 1.96 42.8 42.8 2.40 41.9 41.9 2.84 40.0 40.0 3.25
Multipliers for Determining the Performance With Other Indoor Sections
Indoor
Section Size Cooling Indoor Section Size Cooling Capacity Sensible†† Power Capacity Sensible†† Power
F(A,B)4AN(F,B) 060 1.00 1.00 1.29 CJ5A/CK5A/CK5BX 060 0.97 0.87 1.00
FB4ANB 070 1.00 1.00 1.23 CK3BA 060 0.96 0.86 1.01
FC4BN(F,B) 060 1.00 1.00 1.29 COILS + 58U(H,X)V100-20 VARIABLE-SPEED FURNACE
FC4BNB 070 1.00 1.00 1.23 CC5A/CD5A/CD5BA 060 0.94 0.86 1.00
FK4CNB 006 1.00 1.00 1.00 CC5A/CD5A/CD5BW 060 0.96 0.89 0.99
CC5A/CD5A/CD5BA 060 0.94 0.85 1.10 CD3(A,B)A 060 0.94 0.86 1.00
CC5A/CD5A/CD5BW 060 0.96 0.88 1.09 CD3CA 060 0.94 0.89 0.99
CD3(A,B)A 060 0.94 0.85 1.10 CE3AA 060 0.96 0.91 0.99
CE3AA 060 0.96 0.90 1.10 CJ5A/CK5A/CK5BA 060 0.96 0.94 1.01
CJ5A/CK5A/CK5BA 060 0.94 0.92 1.12 CJ5A/CK5A/CK5BX 060 0.98 0.95 1.00
CJ5A/CK5A/CK5BN 060 0.96 0.94 1.11 CK3BA 060 0.96 0.94 1.01
CJ5A/CK5A/CK5BX 060 0.96 0.94 1.11 COILS + 58U(H,X)V120-20 VARIABLE-SPEED FURNACE
CK3BA 060 0.94 0.92 1.12 CC5A/CD5A/CD5BA 060 0.94 0.85 1.00
COILS + 58MVP100-20VARIABLE-SPEED FURNACE CC5A/CD5A/CD5BW 060 0.96 0.88 0.99
CC5A/CD5A/CD5BA 060 0.94 0.80 1.00 CD3(A,B)A 060 0.94 0.85 1.00
CC5A/CD5A/CD5BW 060 0.94 0.82 0.98 CD3CA 060 0.94 0.88 0.99
CD3(A,B)A 060 0.94 0.80 1.00 CE3AA 060 0.96 0.90 0.99
CE3AA 060 0.94 0.84 0.99 CJ5A/CK5A/CK5BA 060 0.96 0.92 1.02
CJ5A/CK5A/CK5BA 060 0.96 0.86 1.01 CJ5A/CK5A/CK5BX 060 0.98 0.94 1.01
CJ5A/CK5A/CK5BN 060 0.97 0.87 1.01 CK3BA 060 0.96 0.92 1.02
