Carrier TC-PHP01-BLK User manual

TC-PHP01-BLK
CarrierProgrammable Thermostat
Air Conditioner and Heat Pump
Applications
Installation Guide
A07051

1
INTRODUCTION
Welcome and from all of us at Carrier®, thank you for purchasing your new
Carrier programmable thermostat. This thermostat is designed to be simple to
install but it’s best to review all of the instructions in this manual before you
start to help ensure there are no surprises during installation.
If any questions arise during your installation, we’re here to help:
SVisit www.carrier.com/homecomfort for how-to videos and answers to
frequently asked questions.
STechnical support is also available by phone or email at:
d1.800.CARRIER or 1.800.227.7437
[e-mail]
SThe thermostat is also supported by the world's greatest network of
professional contractors. Find an Expert Carrier Contractor at
www.carrier.com/dealers
Let’s get started!

2
COMPATIBLE HEATING AND COOLING SYSTEMS
This thermostat works with many centralized residential heating and cooling
systems.
SConventional Heating and Cooling (AC): up to one stage of heating and
two stages of cooling
SHeat Pump (HP): up to three stages of heating and two stages of cooling
dHeat pumps work to provide cooling in the summer but in the winter,
they do it in reverse, drawing their heat energy from the outside air.
SSystemswithaCommon(C)wire
dRecommended to whenever possible
SSystems without a Common (C) wire
dTwo alkaline AA batteries required
!This thermostat is not compatible with Duel Fuel or Geothermal
Systems. Review all documentation to ensure that you have
selected the appropriate model thermostat for your system.

3
ITEMS INCLUDED IN THE BOX
A. The Carrier®Programmable Thermostat
B. Mounting screws and drywall plugs
C. Installation Guide and Owner’s Manual
D. Batteries
Installation Guide
Owner’s Manual
A. B.
C. D.
A150216
Tip: Write down your thermostat serial number and save it for
future reference. It is located on the thermostat circuit board next
to the model number TP-PHP.

4
ITEMS YOU’LL NEED FOR INSTALLATION
A. Pencil
B. Phillips screwdriver
C. Small flathead screwdriver
D. Drill with a 3/16” drill bit
A. C. D.
B.
A150218
Tip: Review all the instructions before you start to help
ensure that there are no surprises during installation

5
STEP 1. REMOVE THE COVER FROM
YOUR OLD THERMOSTAT
1. Most covers snap off easily but some are attached by screws.
2. Note if either of the following apply to your old thermostat:
a. If you do not have a wire connected to C, two alkaline AA batter-
ies are required.
b. If you have wires connected to Rh and Rc and C, you’ll use two
breakers or switches to disconnect power in Step 2.
3. If you find that you have additional wires labeled anything other than
those shown in the diagram below – STOP and review to see if this
model thermostat is compatible with your system
O/B - reversing valve
Y1 - Cooling
Low Stage
Rc - 24 VAC, from cooling equipment
Rh - 24 VAC, from heating equipment
W - Heating
C - Common 24 VAC
G - Fan
Y/Y2 - Cooling High or Single Stage
A09271
4. Reattach the cover of your old thermostat. You’ll use it in Step 2 to
confirm the power is disconnected.

6
B.
110/120V
HC
HC
A.
A150045
!
Warning! If your old thermostat is labeled 110V or
120V, or is connected by thick wires and wire nuts,
it is a high voltage system and is not compatible
STEP 2. POWER OFF YOUR HEATING AND COOLING SYSTEM
1. Turn off the power to your heating and cooling system.
a. You can do this either at your circuit breaker box or a switch at
your indoor furnace or fan coil.
b. Most systems have one switch, but some systems or systems
with Rh and Rc and C wires noted in Step 1 will have two switch-
es.
2. Make sure your system is without power by using your old thermostat
to adjust the temperature. Your system should not turn on.

7
or
A150046
!Warning! Electrical operation hazard. Failure to
follow this warning could result in injury, death, or
equipment damage
STEP 3. REMOVE YOUR OLD THERMOSTAT
1. Remove the cover of your old thermostat.
2. Using your old thermostat as a guide, record wire color and corre-
sponding letter where it is connected on the thermostat terminal block.
Don’t worry about any non-connected wires.
3. Also note if there is a jumper wire or bracket between Rh, Rc, or R. If
yes, you will need to jumper these terminals on your new thermostat
as well.

8
A150219
Wire Color Connected to Terminal Letter
Green G
There is a jumper wire or bracket between Rh, Rc, or R?
Yes No
Tip: Take a photo of your old thermostat wiring with
your smartphone for reference later
4. Disconnect each wire. Most thermostat wires are connected using
screws; simply loosen each screw with a small screwdriver. Be careful
not to let any wires fall back into the wall.
5. Remove your old thermostat base by unscrewing it from the wall.

9
STEP 4. INSTALL YOUR CARRIER®THERMOSTAT
1. Separate front display and mounting back plate of thermostat by
pressing the thumb release at the top of the thermostat and carefully
snap apart.
A150220
2. Gently pull the wires through the hole in the back plate.
3. Center the wires in the back plate.
4. Mark four mounting holes on the wall with a pencil.
5. Drill mounting holes on the pencil marks with a 3/16” drill bit.
6. Insert the plastic drywall anchors into the wall. Use the screws pro-
vided to secure the back plate to the wall.

10
A150224
STEP 5. CONNECTING THE WIRES
1. Using the table you created on page 8, use a small screwdriver to
loosen the screws then insert each wire into its matching connector
block hole.
a. Insert only one wire in each connector.
b. Only connect wires that were connected to your old thermostat
c. If you need additional help with the wiring, refer to the terminal
descriptions and wiring diagrams beginning on page 22.
2. After inserting a wire, tighten screw using a small screwdriver.

11
HC
A150221
3. When all the wires are connected, gently push any excess wire back
into the wall.
STEP 6. CONNECTING THE DISPLAY
1. With the Carrier®logo positioned at the bottom, attach thermostat
display to back plate by inserting tab on bottom edge and hinging up
until top snap secures.
2. Close thermostat assembly making sure pins on back of circuit board
align with sockets in connector.
3. Now you can turn the power back on to your heating and cooling sys-
tem. Return to your circuit breaker or on/off switch and restore the
power to your system.
4. The thermostat will automatically power on.

12
A150223
STEP 7. SET THERMOSTAT CONFIGURATION
When power is applied, all display icons are lit for 2 seconds to test the
display.
Following this, the equipment type for which the thermostat is configured is
displayed for an additional 2 seconds. It will be one of HP, H2, AC, A2, H or
C. You may need to make an adjustment to this setting depending on the
system you've connected. See explanation under Step 3, Option 01 below.
The remaining settings are preconfigured for the most common system type.
To adjust the default configuration, you will need to enter Configuration Mode.
A description of each configurable option is listed below.
To Enter The Configuration Mode:
1. Press and hold the FAN key for about 10 seconds until the display
changes so that only two pairs of digits are showing.

13
A150225
a. The left display shows the configuration number.
b. The right shows the configuration setting.
2. The configuration number will be flashing which means it can be ad-
justed using the UP and DOWN keys.
A150226
3. To cause the opposite pair to flash (to be adjustable), press the
MODE key.
A150227
4. Successive presses of the MODE key alternate between the configu-
ration number and the configuration setting.
5. To exit the configuration mode, press the FAN key.

14
A150225
6. If no key is pressed for 3 minutes, the configuration mode will auto-
matically exit, returning the thermostat to normal operation.
Option 01 - Equipment type
You may need to make an adjustment to this setting depending on the system
you've connected. If you're unsure about your system type, refer to wiring
diagrams beginning on page 23.
Options:HP,H2,AC,A2,H,C
Description:
SHP controls 1 speed heat pump with 1 stage of auxiliary heat.
SA2 controls two stages of cooling and one stage of furnace heat.
SH2 controls a 2 Speed HP with 1 stage of auxiliary heat.
SAC controls 1 speed air conditioner with 1 stage of heat.
SH operates a heat only system: furnace or fan coil only; no outdoor unit.
SC operates a cool only system: outdoor AC unit with an indoor fan coil; no
strip heater support.
Option 03 - Fahrenheit/Centigrade
Default: Fahrenheit (F)
Selections: Fahrenheit (F), Centigrade (C)

15
Description: This selection operates the thermostat in either Fahrenheit or
Centigrade.
Option 04 - G (fan) ON with W(Heat) Selection
Default: G not energized with W (OF)
Options: G not energized with W (OF), G energized with W (ON)
Description: This selection determines whether the fan (G) is to be ON or
OFF when W (furnace or strip heat) is ON. Furnaces and fan coils which
manage their own blowers do not require a separate G signal. Some auxiliary
heaters require a separate G signal to operate the blower when W is applied.
Option 07 - Zoning
Default: Non-zoned system (OF)
Options: Non-zoned system (OF), Zoned system (ON)
Description: ON disables thermostat’s internal timers which are not needed
with zoning system controls. Must be set to OF for non-zoned systems.
Option 10 - Reversing Valve
Default: Reversing valve energized in cooling (C)
Options: Reversing valve energized in cooling (C), Reversing valve energized
in heating (H)
Description: Applies only when configured for Heat Pump applications. Most
systems use the orange (O) wire and are energized in cooling.
SSelect Energized in Cooling (C) if you connected an (O) wire in the O/B
terminal to activate the reversing valve output when there is a call for
cooling.
SSelect Energized in Heating (H) if you connected a (B) wire in the O/B
terminal to activate the reversing valve output when there is a call for
heating.

16
SIf you are unsure, consult your heating and cooling system equipment
installation instructions or contact Carrier customer support.
Option 11 - Minimum Deadband Between Heating And Cooling
Default: 02
Options: 01 through 06
Description: Sets the minimum allowable number of degrees between heating
and cooling setpoints. One setpoint will “push” the other to maintain this
difference.
Option 12 - Smart Recovery
Default: 90
Options: OF, 30, 60, 90
Description: The Smart Recovery feature transitions your home from one
temperature period
(P1, P2, P3, P4) to the next so that your home’s temperature matches the
temperature setting at the start of each time period. This means, for example,
that if your sleep period temperature setting is lower than the period that
precedes it, the thermostat will start cooling down the home before the
beginning of the scheduled sleep period. It does this at an energy-efficient
rate. This not only helps make your home as comfortable as possible, it also
makes your thermostat more cost effective.
Smart Recovery OF means setpoints change immediately at a program
schedule change. Thirty, 60, or 90 selects the number of minutes recovery
starts before programmed recovery time. Recovery takes place smoothly
during the selected recovery time, ending at the recovery time and
temperature which is programmed. If the setpoint is changed during smart
recovery, the smart recovery is cancelled and the new setpoint is effective
immediately.

17
Option 13 - Room Air Temperature Offset
Default: 0°F
Options: - 5°F to 5°F
Description: The number of degrees to be added to the displayed temperature
to calibrate the measured room temperature. The selected number is the
number of degrees, plus or minus, which will be added to actual temperature.
Thisoptionisin°FevenifOption03issetfor°C.
Option 15 - Auto Changeover
Default: Off (ON)
Options: On (ON), Off (OF)
Description: This feature allows the thermostat to automatically change
between heating and cooling mode as demand requires. If disabled (OF), the
thermostat maintains either heating or cooling mode only. Auto changeover is
not available when H or C is selected under Option 01.
Option 16 - Maximum Cycles Per Hour
Default: 4
Options:2,4,or6
Description: The maximum cycle rate is limited by internal timers to the
selected number of cycles per hour. Selection of a higher number causes
faster cycling resulting in more constant room temperature.
Option 17 - Minimum Time Between Equipment Stages
Default: 15
Options: 10, 15, 20, 25
Description: When there is an auxiliary stage of heat available, this is the
amount of time the heat pump must operate before the auxiliary stage can
turn on. With heat pumps, longer times can reduce the amount of auxiliary
heat used.

18
Option 18 - Backlight Configuration
Default: OF
Options: On (ON), Off (OF)
Description: When ON is selected and the thermostat is not battery operated,
a low level continuous display backlight is always on. With OF selected, the
backlight is only on for a short time after the door is opened or a key is
pressed. Continuous backlight is not available with battery operation.
Option 21 - Keypad Lockout
Default: Off (OF)
Options: On (ON), Off (OF)
Description: With OF selected, the keypad cannot be locked. With ON
selected the keypad will be locked and can be unlocked by simultaneously
pressing the UP and DOWN keys for 5 seconds. Once unlocked, it will re lock
2 minutes after the last keypad press. A “lock” icon is displayed while it is
locked.
Option 24 - Programmable/Non-Programmable
Default: Programmable (P)
Options: Programmable (P), Non-programmable (nP)
Description: Enabling nP mode disables programming. The clock is displayed,
but the program schedule, the HOLD and TEMPORARY HOLD functions are
disabled.
Option 25 - Number of Programmable Periods
Default: 4
Options:2,4
Description: The number of programmable periods available in your schedule
per day.
SSelecting 2 allows 2 programming periods per day, P1 and P2. For
