Carrol Touch TouchSystems CarrollTouch Prog Manual

CARROLLTOUCH
TOUCHPRODUCTS
ancompanyAMP
TouchSystem
Programmer's
Guide

Touch System
Programmer’s
Guide
CARROLL TOUCH
TOUCH PRODUCTS
an AMP company Part #: 2970-0011-01-Rev A
August 1996

Copyright
Copyright ©1996 Carroll Touch. All rights reserved.
Trademarks
Smart-Frame is a trademark of Carroll Touch, Round Rock, Texas.
IBM and PC are trademarks of International Business Machines
Corporation.
All other brands and product names are trademarks of their respective
owners.
Disclaimer
Carroll Touch has a policy of continually improving products as new
technologybecomesavailable.CarrollTouchreservestherighttomake
changes and improvements to the specifications of this equipment at
any time without notice.
Carroll Touch has made every attempt to ensure that the information in
this document is accurate and complete. Carroll Touch assumes no
liability for any damages that result from the use of this manual or the
equipment it documents. Carroll Touch reserves the right to make
changes to this document at any time without notice.

CARROLL TOUCH Table of Contents
i
Table of Contents
Welcome . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .xi
Purpose . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xi
Audience . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xi
Organization . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xi
Conventions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xiii
1. Introduction to Infrared Touch Systems . . . . . . . 1-1
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
Touch Frames . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
Touch Controller . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
Interpolating Touch Coordinates. . . . . . . . . . . . . . . . . . . . 1-3
Reporting Touch Coordinates . . . . . . . . . . . . . . . . . . . . . . 1-4
Failed Beams . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-4
Criteria for Failing a Beam . . . . . . . . . . . . . . . . . . . . . 1-5
Failed Beam Timing Parameters . . . . . . . . . . . . . . . . . 1-5
Criteria for Unfailing a Beam . . . . . . . . . . . . . . . . . . . 1-7
Failed Beam Reports . . . . . . . . . . . . . . . . . . . . . . . . . . 1-7
2. Introduction to Guided Wave Touch Systems . . . 2-1
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-2
Touch Screens . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-2
Touch Controllers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-2
EEPROM File and Parameters . . . . . . . . . . . . . . . . . . . . . 2-3
3. General Programming Issues . . . . . . . . . . . . . . . . 3-1
Hardware Configurations . . . . . . . . . . . . . . . . . . . . . . . . . 3-2
Built-In Controllers . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-2
External Controllers. . . . . . . . . . . . . . . . . . . . . . . . . . . 3-2
Application Program Interface . . . . . . . . . . . . . . . . . . 3-4
Calibration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-6
Floating Point Calibration Program Design . . . . . . . . 3-7
Floating Point Calibration Examples. . . . . . . . . . . . . . 3-8
HBC I/O Registers. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-9
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-9
Sending a Touch Command to the HBC . . . . . . . . . . . 3-9
Receiving Touch Data from the HBC . . . . . . . . . . . . 3-10
Polling Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-10
Interrupt Mode. . . . . . . . . . . . . . . . . . . . . . . . . . . 3-11
Resetting the HBC. . . . . . . . . . . . . . . . . . . . . . . . . . . 3-11

Table of Contents CARROLL TOUCH
ii
4. Smart-Frame Protocol . . . . . . . . . . . . . . . . . . . . . . 4-1
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-2
SFP and SFP-II . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-2
Types of SFP Commands . . . . . . . . . . . . . . . . . . . . . . . . . 4-2
Communication Commands . . . . . . . . . . . . . . . . . . . . 4-3
Reporting Method Commands. . . . . . . . . . . . . . . . . . . 4-3
Touch Mode Commands . . . . . . . . . . . . . . . . . . . . . . . 4-4
Information Request Commands. . . . . . . . . . . . . . . . . 4-5
System Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-5
Reports. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-6
Touch System Initialization. . . . . . . . . . . . . . . . . . . . . . . . 4-7
Resetting the Touch System . . . . . . . . . . . . . . . . . . . . 4-7
Power Cycle. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-7
Dedicated Reset Signal . . . . . . . . . . . . . . . . . . . . . 4-7
Break (Hardware Detected). . . . . . . . . . . . . . . . . . 4-7
HBC Hardware Reset Register . . . . . . . . . . . . . . . 4-8
Break (Firmware Detected) . . . . . . . . . . . . . . . . . . 4-8
Reset (45H) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-8
Performing the Autobaud/Autoparity Sequence . . . . . 4-8
Checking for Touch System Errors . . . . . . . . . . . . . . . 4-9
Setting the Reporting Method and Touch Mode . . . . 4-10
Touch System Initialization Examples . . . . . . . . . . . . . . 4-10
Using Autobaud/Autoparity . . . . . . . . . . . . . . . . . . . 4-10
Using a Fixed Baud Rate. . . . . . . . . . . . . . . . . . . . . . 4-11
Using the HBC. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-11
Using an SBC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-12
Compatibility Issues/Programming Tips. . . . . . . . . . . . . 4-12
Number of Processors Independence . . . . . . . . . . . . 4-13
Firmware Version Independence. . . . . . . . . . . . . . . . 4-13
Frame Size Independence . . . . . . . . . . . . . . . . . . . . . 4-13
Touch System Response Time Independence . . . . . . 4-13
SFP Timing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-14
Autobaud/Autoparity Delay Time. . . . . . . . . . . . . . . 4-14
Maximum Command Completion Time . . . . . . . . . . 4-14
Reset Time/Diagnostics Completion Time . . . . . . . . 4-14
SFP Programming Examples. . . . . . . . . . . . . . . . . . . . . . 4-14
5. Smart-Frame Protocol II . . . . . . . . . . . . . . . . . . . . 5-1
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-2
Extensibility. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-2
Modal Protocols. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-4
Backward Compatibility . . . . . . . . . . . . . . . . . . . . . . . 5-4
Types of SFP-II Functions. . . . . . . . . . . . . . . . . . . . . . . . . 5-5
Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-5

CARROLL TOUCH Table of Contents
iii
Commands. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-6
Validation Layer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-7
Interpretation Layer. . . . . . . . . . . . . . . . . . . . . . . . . . . 5-7
Example. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-8
Reports. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-8
Validation Layer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-9
Interpretation Layer. . . . . . . . . . . . . . . . . . . . . . . . . . 5-10
Example. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-10
Reporting Modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-11
Report Transfer Mode . . . . . . . . . . . . . . . . . . . . . . . . 5-11
Error Reporting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-12
Invalid Command Number . . . . . . . . . . . . . . . . . . . . 5-12
Invalid Parameter Value . . . . . . . . . . . . . . . . . . . . . . 5-13
Unsupported Feature . . . . . . . . . . . . . . . . . . . . . . . . . 5-13
Invalid Byte Count. . . . . . . . . . . . . . . . . . . . . . . . . . . 5-14
Not Enough Parameters. . . . . . . . . . . . . . . . . . . . . . . 5-17
Too Many Parameters . . . . . . . . . . . . . . . . . . . . . . . . 5-17
Overloaded Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-18
Shared Parameters between SFP and SFP-II. . . . . . . . . . 5-19
Touch Detection . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-19
Report Transfer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-20
6. Touch Application Program Interface (TAPI) . . 6-1
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-2
Installing a TAPI Driver . . . . . . . . . . . . . . . . . . . . . . . . . . 6-3
SBC Driver . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-3
HBC Driver . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-4
RS-232 Driver . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-4
Error Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-6
Determining if a TAPI Driver Is Installed. . . . . . . . . . . . . 6-7
Calling TAPI Functions. . . . . . . . . . . . . . . . . . . . . . . . . . . 6-7
Touch System Initialization Using a TAPI Driver . . . . . . 6-8
TAPI Programming Examples. . . . . . . . . . . . . . . . . . . . . . 6-9
7. CTKERN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-1
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-2
Calibration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-2
Scaling. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-4
Touch Reporting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-5
Calibration and Scaling Examples. . . . . . . . . . . . . . . . . . . 7-5
Temporal Filter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-8
Methods for Interfacing CTKERN and an Application
Program. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-9
Polling Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-9
Interrupt Mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-9

Table of Contents CARROLL TOUCH
iv
Loading the CTKERN Driver . . . . . . . . . . . . . . . . . . . . . . 7-9
Command Line . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-9
Error Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-10
Determining If the CTKERN Driver Is Installed . . . . . . 7-13
Calling CTKERN Functions . . . . . . . . . . . . . . . . . . . . . . 7-13
CALIB.EXE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-13
Command Line . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-14
Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-15
Calibrate Mono, EGA, VGA Video Modes . . . . 7-16
Calibrate Other Video Modes . . . . . . . . . . . . . . . 7-17
Edit Entry. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-18
Delete Entry. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-18
CALIB.DAT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-20
CTKERN Programming Examples . . . . . . . . . . . . . . . . . 7-20
8. Dynamic Link Library (DLL) Functions . . . . . . . 8-1
Calling Windows Driver DLL Functions . . . . . . . . . . . . . 8-2
A. Smart-Frame Protocol Command Reference . . . A-1
Add_Exit_Point_Modifier (29H) ()) . . . . . . . . . . . . . .A-5
Clear_Touch_Report_Buffer (3DH) (=) . . . . . . . . . . .A-6
Continuous_Mode (27H) (’) . . . . . . . . . . . . . . . . . . . .A-7
Coordinate_Reporting (23H) (#) . . . . . . . . . . . . . . . . .A-8
Echo_Off (21H) (!) . . . . . . . . . . . . . . . . . . . . . . . . . .A-10
Echo_On (20H) (SPACE) . . . . . . . . . . . . . . . . . . . . .A-11
Enter_Point_Mode (25H) (%) . . . . . . . . . . . . . . . . . .A-12
Exit_Point_Mode (28H) (() . . . . . . . . . . . . . . . . . . . .A-13
Get_Configuration_Report (33H) (3) . . . . . . . . . . . .A-14
Get_Error_Report (32H) (2) . . . . . . . . . . . . . . . . . . .A-15
Get_Failed_Beam_Report (36H) (6). . . . . . . . . . . . .A-19
Get_Firmware_Version_Report (34H) (4) . . . . . . . .A-21
Get_Frame_Size_Report (37H) (7) . . . . . . . . . . . . . .A-23
Get_One_Report (46H) (F) . . . . . . . . . . . . . . . . . . . .A-24
Get_State_Report (47H) (G) . . . . . . . . . . . . . . . . . . .A-25
Hardware_Flow_Control_Off (42H) (B). . . . . . . . . .A-27
Hardware_Flow_Control_On (41H) (A). . . . . . . . . .A-28
Report_Transfer_Off (43H) (C) . . . . . . . . . . . . . . . .A-29
Report_Transfer_On (44H) (D). . . . . . . . . . . . . . . . .A-30
Reset (45H) (E) . . . . . . . . . . . . . . . . . . . . . . . . . . . . .A-31
Run_Diagnostics (3AH) (:) . . . . . . . . . . . . . . . . . . . .A-32
Scan_Reporting (22H) (”) . . . . . . . . . . . . . . . . . . . . .A-33
Software_Reset (3CH) (<). . . . . . . . . . . . . . . . . . . . .A-34
SwitchToSFP-II (65H) . . . . . . . . . . . . . . . . . . . . . . .A-35
Touch_Scanning_Off (2BH) (+) . . . . . . . . . . . . . . . .A-37

CARROLL TOUCH Table of Contents
v
Touch_Scanning_On (2AH) (*) . . . . . . . . . . . . . . . .A-38
Tracking_Mode (26H) (&) . . . . . . . . . . . . . . . . . . . .A-39
B. Smart-Frame Protocol II Function Reference . . B-1
GetConfiguration (11H) . . . . . . . . . . . . . . . . . . . . . . . B-3
GetCoordinateRanges (10H) . . . . . . . . . . . . . . . . . . . . B-8
GetProtocolVersion (65H). . . . . . . . . . . . . . . . . . . . . B-10
GetTouchState (01H). . . . . . . . . . . . . . . . . . . . . . . . . B-12
SetReportProperties (21H) . . . . . . . . . . . . . . . . . . . . B-14
SetReportTransferMode (22H) . . . . . . . . . . . . . . . . .B-19
SetTouchModes (20H) . . . . . . . . . . . . . . . . . . . . . . . B-24
SwitchToClassicSFP (64H). . . . . . . . . . . . . . . . . . . . B-29
C. TAPI Function Reference . . . . . . . . . . . . . . . . . . . C-1
CheckForReports (3) . . . . . . . . . . . . . . . . . . . . . . . . . . C-3
GetCommunicationParameters (4) . . . . . . . . . . . . . . . C-4
GetReports (2) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-6
GetTAPIDriverConfiguration (6) . . . . . . . . . . . . . . . .C-7
GetUserEventHandlerParameters (8) . . . . . . . . . . . . . C-8
Reset (0). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-9
SendCommand (1). . . . . . . . . . . . . . . . . . . . . . . . . . . C-10
SetCommunicationParameters (5). . . . . . . . . . . . . . .C-11
SetSBCFrameSize (40H). . . . . . . . . . . . . . . . . . . . . . C-13
SetUserEventHandler (7). . . . . . . . . . . . . . . . . . . . . . C-14
D. CTKERN Function Reference . . . . . . . . . . . . . . . D-1
GetCalibrationTableEntry (7) . . . . . . . . . . . . . . . . . . .D-5
GetCommunicationParameters (22) . . . . . . . . . . . . . .D-7
GetCTKERNDriverConfiguration (20). . . . . . . . . . . .D-8
GetCurrentCalibrationModeAndParameters (5) . . . . .D-9
GetCurrentScalingModeAndParameters (10) . . . . . .D-10
GetTAPIDriverConfiguration (19) . . . . . . . . . . . . . .D-11
GetTemporalFilterModeAndParameters (16) . . . . . .D-12
GetTouchState (1) . . . . . . . . . . . . . . . . . . . . . . . . . . .D-13
GetTouchSystemStatus/Configuration (17) . . . . . . .D-15
GetUserEventHandlerModeAndParameters (25) . . .D-16
GetZ-AxisScalingModeAndParameters (13) . . . . . .D-17
Reset (0). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .D-18
SendSmart-FrameProtocolCommand
AndGetReport (18) . . . . . . . . . . . . . . . . . . . . . . . .D-20
SetCalibrationMode (3). . . . . . . . . . . . . . . . . . . . . . .D-22
SetCalibrationParameters (4). . . . . . . . . . . . . . . . . . .D-23
SetCalibrationTableEntry (6) . . . . . . . . . . . . . . . . . .D-24
SetCommunicationParameters (21). . . . . . . . . . . . . .D-26
SetScalingMode (8). . . . . . . . . . . . . . . . . . . . . . . . . .D-28

Table of Contents CARROLL TOUCH
vi
SetScalingParameters (9). . . . . . . . . . . . . . . . . . . . . .D-29
SetTemporalFilterMode (14). . . . . . . . . . . . . . . . . . .D-31
SetTemporalFilterParameters (15) . . . . . . . . . . . . . .D-34
SetTouchState (2) . . . . . . . . . . . . . . . . . . . . . . . . . . .D-36
SetUserEventHandlerMode (23) . . . . . . . . . . . . . . . .D-37
SetUserEventHandlerParameters (24). . . . . . . . . . . .D-39
SetZ-AxisScalingMode (11) . . . . . . . . . . . . . . . . . . .D-40
SetZ-AxisScalingParameters (12) . . . . . . . . . . . . . . .D-41
E. Dynamic Link Library (DLL) Function Reference E-1
DisableMouse (11) . . . . . . . . . . . . . . . . . . . . . . . . . . . E-3
DisableTouch (12). . . . . . . . . . . . . . . . . . . . . . . . . . . . E-4
EnableMouse (9) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-5
EnableTouch (10) . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-6
GetMouseInfo (13) . . . . . . . . . . . . . . . . . . . . . . . . . . . E-7
GetTemporalFilterInfo (18). . . . . . . . . . . . . . . . . . . . . E-8
GetTouchInfo (14). . . . . . . . . . . . . . . . . . . . . . . . . . . . E-9
GetTouchStateandCoord (5) . . . . . . . . . . . . . . . . . . . E-10
InitializeTouch (16). . . . . . . . . . . . . . . . . . . . . . . . . . E-11
SetCalibInfo (7). . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-12
SetTemporalFilterInfo (17) . . . . . . . . . . . . . . . . . . . . E-14
SetTouchEvents (8) . . . . . . . . . . . . . . . . . . . . . . . . . . E-16
Glossary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .GL-1
Index. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . IN-1

CARROLL TOUCH Table of Contents
vii
List of Figures
Figure 1-1. Infrared Touch Frame . . . . . . . . . . . . . . . . . . . . . . . . 1-2
Figure 1-2. Beam Averaging - Example 1 . . . . . . . . . . . . . . . . . . 1-3
Figure 1-3. Beam Averaging - Example 2 . . . . . . . . . . . . . . . . . . 1-4
Figure 2-1. Guided Wave Touch Screen . . . . . . . . . . . . . . . . . . . 2-2
Figure 3-1. Built-In Smart-Frame Controller Hardware . . . . . . . 3-2
Figure 3-2. RS-232 Controller Hardware (Modular IR Touch
Systems) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-3
Figure 3-3. SBC and HBC Hardware (Modular IR Touch
Systems) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-4
Figure 3-4. Touch Control Software . . . . . . . . . . . . . . . . . . . . . . . 3-5
Figure 3-5. Touch Calibration Screen . . . . . . . . . . . . . . . . . . . . . 3-6
Figure 7-1. Touch System to Application Communication . . . . . 7-3
Figure 7-2. Calibration Mode Fixed or Automatic and Scaling
Mode Fixed or Automatic . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-6
Figure 7-3. Calibration Mode Fixed or Automatic and Scaling
Mode Disabled . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-7
Figure 7-4. Calibration Mode Disabled and Scaling Mode
Fixed or Automatic . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-7
Figure 7-5. Calibration Mode Disabled and Scaling Mode
Disabled . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-8
Figure 7-6. Calibration Main Menu Screen . . . . . . . . . . . . . . . . 7-15
Figure 7-7. Calibration Menu Screen . . . . . . . . . . . . . . . . . . . . . 7-16
Figure 7-8. Calibration Target Screen . . . . . . . . . . . . . . . . . . . . 7-16
Figure 7-9. Calibration Other Video Mode Screen #1 . . . . . . . . 7-17
Figure 7-10. Calibration Other Video Mode Screen #2 . . . . . . . 7-17
Figure 7-11. Calibration Other Video Mode Screen #3 . . . . . . . 7-18
Figure 7-12. Calibration Manual Edit Menu Screen . . . . . . . . . 7-19
Figure 7-13. Calibration Exit Prompt Screen . . . . . . . . . . . . . . . 7-19
Figure B-1. Flow Diagram for Report Transfer Mode . . . . . . . . B-19
Figure D-1. Temporal Filter Spatial Box Size . . . . . . . . . . . . . .D-32

Table of Contents CARROLL TOUCH
viii

CARROLL TOUCH Table of Contents
ix
List of Tables
Table 1-1. Failed Beam Timing Parameters . . . . . . . . . . . . . . . . . 1-5
Table 3-1. HBC I/O Registers . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-9
Table 3-2. Status Register Bit 0 Values . . . . . . . . . . . . . . . . . . . 3-10
Table 3-3. Status Register Bit 1 Values . . . . . . . . . . . . . . . . . . . 3-10
Table 4-1. SFP Communication Commands . . . . . . . . . . . . . . . . 4-3
Table 4-2. SFP Reporting Method Commands . . . . . . . . . . . . . . 4-4
Table 4-3. SFP Touch Mode Commands . . . . . . . . . . . . . . . . . . . 4-4
Table 4-4. SFP Information Request Commands . . . . . . . . . . . . . 4-5
Table 4-5. SFP System Commands . . . . . . . . . . . . . . . . . . . . . . . 4-6
Table 4-6. SFP Default Settings . . . . . . . . . . . . . . . . . . . . . . . . . . 4-9
Table 6-1. TAPI Error Messages and Explanations . . . . . . . . . . . 6-6
Table 7-1. CTKERN Error Messages . . . . . . . . . . . . . . . . . . . . . 7-10
Table A-1. SFP Commands in Alphabetical Order . . . . . . . . . . .A-3
Table A-2. SFP Commands in Numerical Order . . . . . . . . . . . . .A-4
Table A-3. Smart-Frame Protocol Error Report Error Codes . . .A-16
Table A-4. Touch System Default Settings . . . . . . . . . . . . . . . .A-34
Table B-1. SFP-II Functions in Alphabetical Order . . . . . . . . . . .B-2
Table B-2. SFP-II Functions in Numerical Order . . . . . . . . . . . . B-2
Table B-3. ComponentTypes, AttributeTags and
AttributeValues . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . B-5
Table C-1. TAPI Functions in Alphabetical Order . . . . . . . . . . . . C-2
Table C-2. TAPI Functions in Numerical Order . . . . . . . . . . . . . C-2
Table C-3. Typical BL/BH Register Contents . . . . . . . . . . . . . . .C-7
Table D-1. CTKERN Functions in Alphabetical Order . . . . . . . .D-3
Table D-2. CTKERN Functions in Numerical Order . . . . . . . . . .D-4
Table D-3. Typical BX Register Contents . . . . . . . . . . . . . . . . . .D-8
Table D-4. Typical BL/BH Register Contents . . . . . . . . . . . . . .D-11
Table E-1. Windows Driver DLL Functions in
Alphabetical Order . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-2
Table E-2. Windows Driver DLL Functions in
Numerical Order . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-2
Table E-3. Definition of Touch Events . . . . . . . . . . . . . . . . . . . E-17

Table of Contents CARROLL TOUCH
x

Touch System Programmer’s Guide xi
WelcomeWelcome
s computers become a part of daily life, a technology that makes
them easier to use has become a necessity. Carroll Touch provides
the solution through the power of touch.
Thank you for your purchase of a Carroll Touch product and welcome
to Carroll Touch.
Purpose
This Programmer’s Guide is designed to:
•Give an overview of the touch technologies used by Carroll Touch,
with a particular emphasis on hardware and software information
(such as calibration and initialization) needed by programmers.
•Define the use and functions of the Smart-Frame Protocol, the
Smart-Frame Protocol II, the Touch Application Program Interface
(TAPI) driver, the CTKERN application interface, and the
Windows driver dynamic link libraries (DLLs).
Audience
This guide is designed for the programmer or software engineer who
integrates Carroll Touch touch systems with host computer systems.
Organization
Chapter 1, “Introduction to Infrared Touch Systems,” is an overview of
Carroll Touch infrared touch system hardware and operating principles.
A

Welcome CARROLL TOUCH
xii Touch System Programmer’s Guide
Chapter 2, “Introduction to Guided Wave Touch Systems,” is an
overview of Carroll Touch guided wave touch system hardware and
operating principles.
Chapter 3, “General Programming Issues,” includes information on
programming topics that apply to all Carroll Touch touch systems, such
as calibration and HBC I/O registers.
Chapter 4, “Smart-Frame Protocol,” gives an overview of the SFP
firmware protocol, including a discussion of command and report
types, initialization, timing, and programming tips and examples.
Chapter 5, “Smart-Frame Protocol II,” gives an overview of the SFP-II
firmware protocol, which extends the capabilities of SFP by offering
support of z-axes and higher resolution. Explanations of command and
report formats are included.
Chapter 6, “Touch Application Program Interface (TAPI),” includes an
overview of the TAPI software functions, and TAPI driver installation
and initialization information.
Chapter 7, “CTKERN,” includes an overview of the CTKERN
software functions, CTKERN driver installation,and parameters. It
also discusses the operation of the CTKERN calibration program
(CALIB.EXE).
Chapter8, “DynamicLink Library(DLL) Functions,” describeshow to
use the DLL function calls to the Carroll Touch Windows driver.
Appendix A, “Smart-Frame Protocol Command Reference,” gives the
specifications for each SFP command and report.
Appendix B, “Smart-Frame Protocol II Function Reference,” gives the
specifications for each SFP-II function.
Appendix C, “TAPI Function Reference,” gives the specifications for
each TAPI function.
Appendix D, “CTKERN Function Reference,” gives the specifications
for each CTKERN function.
Appendix E, “Dynamic Link Library (DLL) Function Reference,”
gives the specifications for each Windows driver DLL.

CARROLL TOUCH Welcome
Touch System Programmer’s Guide xiii
Conventions
For clarity, this guide uses certain conventions to visually distinguish
different types of information. The conventions are:
•Bold is used to emphasize a word or phrase, including definitions
of important concepts.
•SMALL CAPITALLETTERS(such as SPACEor ENTER) indicates a
key on the keyboard.
•Courier font indicates file names, directory names, messages
displayed by the computer, parameters in command lines, and
information to be typed by the user.
•Italics indicate a command, function name, or mode (such as
Debug Mode).
•Reports (such as the Touch Coordinate Report) and menus (such as
the Configuration Menu) use initial capital letters.
•Courier italic font indicates a variable in a command line
for which you must substitute a value.
•Hexadecimal numbers in text are identified with capital H; for
example, 1BH is the hexadecimal value 1B. Command and report
formats and examples reproduce numbers as they appear on the
screen and thus do not use the H convention.
•Information of particular importance or actions that may have
undesirable results if performed improperly are included under the
headings Note and Caution.

Welcome CARROLL TOUCH
xiv Touch System Programmer’s Guide

Touch System Programmer’s Guide 1-1
Introduction to
Infrared Touch
Systems
1
his chapter gives an overview of Carroll Touch scanning infrared
touch systems, and covers the following topics:
•Overview.
•Touch Frames.
•Touch Controllers.
•Interpolating Touch Coordinates.
•Reporting Touch Coordinates.
•Failed Beams.
T
Introduction to
Infrared Touch
Systems

Chapter 1 - Introduction to Infrared Touch Systems CARROLL TOUCH
1-2 Touch System Programmer’s Guide
Overview
A Carroll Touch infrared touch system consists of a touch controller and
touch frame or a combined touch frame and controller. The touch
system uses scanning infrared (IR) beam technology to detect operator
input. Generating an invisible grid of IR light beams in front of the host
video display screen, the touch system reports touch input when the IR
light field is interrupted by a stylus (typically a finger). This input can
be used by a touch application just as similar applications use input from
pointing devices such as a mouse, light pen or trackball.
Touch Frames
The typical Carroll Touch touch frame is a thin, flat rectangle comprised
offourjoinedprintedcircuitboards(PCBs). Two adjacent PCBs contain
arrays of IR light emitting diodes (LEDs), while the other two PCBs
contain arrays of phototransistor/receivers. Each IR LED and the
phototransistor opposite it is called an opto-pair. The IR LED of each
opto-pair emits an IR light beam that is detected by the phototransistor.
The x-axis and y-axis arrays of opto-pairs are pulsed sequentially to
create a grid of IR beams, as shown in Figure 1-1.
Figure 1-1. Infrared Touch Frame
A beam, or a beam pair, consists of an IR LED and phototransistor
directly across from each other in the touch frame.
Touch Controller
The touch controller is the circuitry required to create and monitor the
IR grid. A sequence of electrical pulses is sent to the LEDs to create the

CARROLL TOUCH Chapter 1 - Introduction to Infrared Touch Systems
Touch System Programmer’s Guide 1-3
grid of IR beams in front of the video display surface. This grid of IR
beams is the touch active area.
When a stylus enters the touch active area, light beams are obstructed at
a particular location on the grid. The touch frame then transmits to the
controller a list that indicates which beams have been interrupted. The
controller converts this list into an x, y coordinate that identifies the
location of the touch. The x, y coordinate data is transmitted to the host
processor via the PC bus or the RS-232 serial port and is then processed
and used by the application program.
Interpolating Touch Coordinates
To achieve finer resolution than the physical IR beam grid provides,
Carroll Touch IR touch systems interpolate a virtual beam between each
pair of physical beams. The physical beams are assigned even numbers
(0, 2, 4, and so on). The virtual beams are assigned odd numbers (1, 3,
5, and so on). The combination of physical beams and virtual beams
results in a set of logical beams.
The coordinate system formed by the logical beams is called the logical
coordinate system. The origin of the logical coordinate system (0, 0) is
located in the upper left corner of the display. When multiple beams are
interrupted, the touch system averages them and reports one x, y logical
coordinate pair to the host, a process known as beam averaging.
Examples of beam averaging are shown in Figures 1-2 and 1-3.
Figure 1-2. Beam Averaging - Example 1
In Figure 1-2, beams 2, 4, and 6 are interrupted on both the x- and
y-axes. The logical coordinate pair reported to the host is 4, 4.
02 04 0806 1000
00
02
04
06
08
4,4
