Portwell LEAD-PPC-2150-X User manual

1
LEAD-PPC-2150-X/ LEAD-PPC-2360-X
Panel PC
21.5"/ 23.6” Entry Level Panel PC
User's Manual
Version 1.0
Copyright © PORTWELL, Inc., 2021. All rights reserved.
All other brand names are registered trademarks of their respective owners.

Preface
2
Table of Contents
How to Use This Manual
Chapter 1 System Overview..........................................................................................................1
1.1 Introduction ...........................................................................................................1
1.2 Check List...............................................................................................................2
1.3 Product Specification............................................................................................3
1.4 Mechanical Dimension.........................................................................................4
1.5 Safety Instruction ..................................................................................................6
1.5.1 Electrostatic Discharge (ESD).....................................................................7
1.5.2 Grounding Method......................................................................................7
1.5.3 Instructions for the Lithium Battery..........................................................8
1.5.4 FCC Statement..............................................................................................8
1.5.5 Electromagnetic Compatibility ..................................................................8
Chapter 2 System Installation.......................................................................................................9
2.1 I/O Interfaces ........................................................................................................9
2.1.1 Front View.....................................................................................................9
2.1.2 Rear View ....................................................................................................10
2.1.3 VESA®Mount.............................................................................................11
Chapter 3 BIOS Setup Information.............................................................................................12
3.1 Entering Setup—Launch System Setup...........................................................12
3.2 Main ......................................................................................................................13
3.3 Configuration ......................................................................................................14
3.4 Boot .......................................................................................................................27
3.5 Save and Exit .......................................................................................................29
Chapter 4 Important Instructions ...............................................................................................31
4.1 Note on the Warranty.........................................................................................31
4.2 Exclusion of Accident Liability Obligation .....................................................31
4.3 Liability Limitations / Exemption from the Warranty Obligation..............31
4.4 Declaration of Conformity.................................................................................31
Chapter 5 Frequent Asked Questions........................................................................................32

Preface
3
How to Use This Manual
The manual describes how to configure your LEAD-PPC-2150-X/ LEAD-PPC-2360-X
Panel PC system to meet various operating requirements. It is divided into six
chapters, with each chapter addressing a basic concept and operation of Fan-less
Panel PC System.
Chapter 1: System Overview. Present what you have in the box and give you an
overview of the product specifications and basic architecture for Panel PC system.
Chapter 2: System Installation. Show the definitions and locations of all the
interfaces and describe a proper installation guide so that you can easily configure
your system.
Chapter 3: BIOS Setup Information. Specify the meaning of each setup parameters,
how to get advanced BIOS performance and update new BIOS. In addition, POST
checkpoint list will give users some guidelines of trouble-shooting.
Chapter 4: Important Instructions. Indicate some instructions which must be
carefully followed when the Panel PC system is used.
Chapter 5: Frequent Asked Questions. Provide the answers for the most frequently
asked questions.
The content of this manual is subject to change without prior notice. These changes
will be incorporated in new editions of the document. The vendor may make
supplement or change in the products described in this document at any time.
Portwell, Inc. clearly informs the users that this manual only encloses a general
description of technical processes and instructions which may not be applicable in
every single case. In cases of doubt, please contact Portwell, Inc.
© 2021 Portwell, Inc. All Rights Reserved.
Portwell, Inc.
http://www.portwell.com.tw
Address ：No. 242, Bo-Ai Street, Shu-Lin District, New Taipei City, 238, Taiwan
TEL：[phone] ；FAX：[phone]

Preface
4
Revision History
Revision
Date
Details of Change(s)
V1.0
2021/8/17
Initial Release

1
Chapter 1
System Overview
1.1 Introduction
LEAD-PPC-2150-X/ LEAD-PPC-2360-X is a 21.5"/ 23.6”panel PC with Intel®Atom®
x5-E3930 processor (formerly Apollo Lake) mainly for semi-industrial applications.
Portwell specially builds two sizes: 21.5”/ 23.6”, two volt of DC input: 12V/ 24V and
also three OS: Win 10, Android, Linux Ubuntu for LEAD-PPC series product intend
to fit various application in automation, digital signage, smart retail, kiosk and public
infotainment.
In this modern society, we cannot live without screens. With a reliable human
machine interface, people can easily receive necessary information as well as interact
with devices or machines. To be an ideal human machine interface system, in
addition to Win 10, Android and Linux OS compatibility, LEAD-PPC-2150-X/
LEAD-PPC-2360-X also features larger projected capacitive multi-touch screen, 1920
x 1080 full HD display, two 3W speakers and multiple wire or optional wireless
communication supports.
LEAD-PPC series equipped with 8G DDR3L memory and 128G SSD; one HDMI; 2x
USB3.0 ports and one COM port for RS-232 on rear I/O. Moreover, its streamlined
outlook, ultra compact design, light weight, plus low power consumption with
efficient computing power make LEAD-PPC-2150-X/ LEAD-PPC-2360-X a perfect
solution for application including smart retail applications such as digital signage,
recognition, customized advertisements/ promotions, merchandise locations,
self-checkout, and delivery. Also, kiosk applications include point of interest, point of
information in hospitality locations such as hotel or restaurant; transportation such as
parking lot, train station, airport; library, exhibition hall; government infrastructure;
industrial/factory automation; facility management; intralogistics or smart
warehouse and much more.
The graceful mechanical design and advantageous performance—with Intel®Atom®
X5-E3930 processor @1.3 GHz and tailor-made specification for semi-industrial
application—make that PORTWELL LEAD-PPC series a perfect and practical
solution to face end-users with standalone or VESA®75mm x 75mm mounting
options. Certified by CE (EN 55032 and EN 55024), FCC and EN 60068-2-6/ EN
60068-2-27 for vibration/ shock absorption, IP65 water and dust proof in front panel,
this true flat LEAD-PPC series prove its reliability to be used in semi-industrial areas.

2
1.2 Check List
The LEAD-PPC-2150-X/ LEAD-PPC-2360-X Panel PC package covers the following
items:
Essential
One LEAD-PPC series Panel PC
Panel Size, spec
Model name
21.5 inch, 12V input
21.5 inch, 24V input
23.6 inch, 12V input
23.6 inch, 24V input
LEAD-PPC-2150-A
LEAD-PPC-2150-B
LEAD-PPC-2360-A
LEAD-PPC-2360-B
AC-DC Power Adapter
Optional
Power Cords (EU/US type)
Power Cord (US type)
Power Cord (EU type)
If any of these items is damaged or missing, please contact your vendor and keep all
packing materials for future replacement and maintenance.

3
1.3 Product Specification
Display
LCD Size
LEAD-PPC-2150-X: 21.5"
LEAD-PPC-2360-X: 23.6”
Panel Type
TN
Resolution
FHD 1920 x 1080 (16:9)
Brightness
250 cd/m²
Contrast Ratio
1000 : 1
Backlight
LED type
Touch Screen
Projected capacitive 10 point multi-touch
System
SoC
Intel® Atom® Dual-Core x5-E3930 (1.3GHz, up to 1.8GHz)
Memory
1x 8GB DDR3L/1600 SO-DIMM
Storage Device
1x 128GB 3D TLC mSATA SSD
I/O Interface
Series Port
1x RS-232/422/485
Display
Output: 1x HDMI
USB
2x USB 3.0
Ethernet
2x Gigabit Ethernet
Audio
2x 3W speaker
Power Switch
1x power on/off switch
Power
Power Input
12V via DC Jack / 24V via 3-pin terminal block connector (Optional)
Power Supply
65W/60W AC-DC Adapter
Mechanical& Environmental
Water/Dust Resistance
Front panel: IP65
Operating Temperature
0°C ~ 50°C
Operating Humidity
0% ~ 95%
Storage Temperature
-20°C ~ 60°C
Storage Humidity
0% ~ 95%
Dimensions
LEAD-PPC-2150-X: 521.9(W) x 321.4(H) x 44.3(D) mm
LEAD-PPC-2360-X: 561.9(W) x 353.4(H) x 43(D) mm
Mounting (mm)
Standalone; VESA Mount 75 x 75
Certificate
CE/ FCC Class B, VCCI Conformity

4
1.4 Mechanical Dimension
Front and side view of LEAD-PPC-2150-X
Back view of LEAD-PPC-2150-X

5
Front and side view of LEAD-PPC-2360-X
Back view of LEAD-PPC-2360-X

6
1.5 Safety Instruction
Caution:
This section should be carefully read and please abide by the instructions for
your own safety and correct use of the unit.
The chapter also includes information on approval and interference inhibition of your
unit. Please abide by the warnings and instructions on the unit and in the manual.
The LEAD-PPC-2150-X/ LEAD-PPC-2360-X Panel PC was built and tested by
PORTWELL, Inc. in accordance with and kept the company within under perfectly
safe condition.
In order to retain this condition and ensure safe operation, the users must abide by
the instructions and warnings
The unit must be used in accordance with the instructions of usage.
The electrical installations in the room must not violate the requirements of the
local (country-specific) regulations.
Pay careful attention that there are no cables, especially power cables, in areas that
people can go over them.
Only use the power cord supplied as specification. Don’t use damaged power
cords.
Hints for DC power connection: The DC power source should be able to be switched
off and on via an isolating switch. The unit is only completely disconnected from the
DC main power source when the DC power cord is disconnected either from the
power source or the unit. Therefore, the DC power cord and its connectors must
always remain within reach. The Power source should be SELV or from the
secondary circuits are circuits where separation from MAINS CIRCUITS is achieved
by a transformer in which the primary windings are separated from the secondary
windings by REINFORCED INSULATION, DOUBLE INSULATION, or a screen
connected to the PROTECTIVE CONDUCTOR TERMINAL
Hints for AC power connection via external AC/DC adapter: The main power cable
of the optional external AC/DC adapter serves as disconnecting device. For this
reason the outlet of the AC power source must be located near to the device and easy
to reach.
Never place the unit under direct sunlight, near heat sources or in a humid place.
Make sure the unit has proper ventilation.
All plugs on the connection cables must be screwed or locked to the housing.
LEAD-PPC-2150-X/ LEAD-PPC-2360-X Panel PC is designed to be used on the
desk or upright with the I/O interfaces downwards.
The unit generates heat under operation condition. Make sure it is properly
ventilated. Never cover up the air intake and exhaust openings of the unit. Do not
impede the fins of the heat sink.
Be aware of the warm surface of heat sink at back side. A protective wear is
recommended.

7
Repairs may only be operated by specialists or technicians qualified and
authorized by PORTWELL, Inc.
Maintenance or repair on the open unit may only be operated by specialists or
technicians qualified and authorized by PORTWELL, Inc. and familiar with the
related hazards.
When accessing internal components, users must switch off the unit and
disconnect it from the power source.
Only original accessories (or suggested optional parts) approved and supplied by
PORTWELL, Inc. may be used.
The installation that the safety of any system incorporating the equipment is the
responsibility of the assembler of the system.
If the equipment is used in a manner not specified by the manufacturer, the
protection provided by the equipment may be impaired.
Assumption of safe operation no longer possible must be taken,
- if the unit has obvious damage or
- if the unit no longer functions.
Under such cases, the unit must be shut down and secured against any
unintended operation.
1.5.1 Electrostatic Discharge (ESD)
A sudden discharge of electrostatic electricity can damage electrostatic-sensitive
devices or circuits. Adequate packaging and grounding techniques are essential to
avoid damage. Following precautions should be taken:
1. Deliver printed circuit boards in electrostatic-safe containers such as cartons,
boxes or anti-static bags.
2. Keep electrostatic-sensitive parts in their containers until they reach an
electrostatic-free station.
3. Follow adequate grounding when a sensitive PCB, components, or assemblies are
touched.
4. Store electrostatic-sensitive PCB’s in a protective packaging or on conductive
foam.
1.5.2 Grounding Method
Protect against electrostatic damage of the unit by taking the following preventative
measures:
1. Cover workstations with approved anti-electrostatic material. Provide a wrist
strap connected to a working bench and properly grounded tools and equipment.
2. For extra protection use anti-electrostatic mats, heel straps, or air ionizers.
3. Handle electrostatic-sensitive components, PCBs, and assemblies with care
nearby the case or the edge of the board.
4. Prevent contact with pins, leads, or circuitry.
5. Switch off power and input signals before plugging and removing connectors or
test equipment.

8
6. Keep the work area free from non-conductive materials such as ordinary plastic
assembly aids and Styrofoam.
7. Use field service tools with conductivity, such as screwdrivers, pliers, and
vacuum cleaners.
8. Always put drives and PCBs with the component-side down on the working
bench.
1.5.3 Instructions for the Lithium Battery
Caution:
Please contact. PORTWELL, Inc directly. Prohibit replace by user
Do not throw away used CMOS batteries to domestic waste. Throw away the
battery according to the local regulations pertaining to the disposal of these
special materials (e. g. to the collecting points for disposal of batteries).
1.5.4 FCC Statement
This equipment has been tested and found to comply with the limits for a Class B
digital device. These limits are designed to provide reasonable protection from
harmful interference when the equipment is operated in a commercial environment.
This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instruction manual, may cause harmful
interference to radio communications. Operation of this equipment in residential
areas is likely to cause harmful interference in which case the users will be required to
correct the interference at his/her own expense.
1.5.5 Electromagnetic Compatibility
The system has been designed for industrial use. The most recent version of the EMC
guidelines (EMC Directive 2014/30/EU) is applied following standards, CE/FCC
class B. If users modify and/or add device to the equipment (e.g. installation of
add-on cards), the prerequisite for the CE conformity declaration (safety
requirement) may not be applicable anymore.

System Installation
9
Chapter 2
System Installation
This chapter provides you with instructions to set up your LEAD-PPC-2150-X/
LEAD-PPC-2360-X Series Panel PC. Definitions and locations of all the interfaces are
described so that you can easily configure your system.
2.1 I/O Interfaces
2.1.1 Front View
TFT-LCD Display with Projective Capacitive Touch Screen:
The Panel PC is built in a TFT-LCD display and designed with a projective capacitive
touch screen. The surface of the display is also mechanically protected through the
touch screen. The touch screen of LEAD-PPC series can support up to 10 touch
points.
Plastic Front Bezel:
Plastic front bezel which meets IP65 protection
True Flat Projective Capacitive Touch Screen:
The projective capacitive touch screen (USB interface) registers contacts of a
conductive object such as fingers and allows moving the mouse pointer. It can sense a
passive stylus or gloved fingers as well. Users don’t need to install touch screen
driver for projected capacitive multi-touch because driver is included in operating
system.

System Installation
10
Do not use a hard or a pointed object (like screw drivers or pliers) to operate
the touch screen, because such an action will damage the surface of touch
screen.
Front Panel Care and Clean
Front Mild detergent and water, or isopropyl alcohol is recommended for
cleaning. Use of solvents with strong acidity or alkalinity, which could react
with the paint or printed color or plastic, should be avoided.
The true flat touch screen surface is subject to burning and scaring from direct heat
sources such as lighters or cigarettes. The front display is against water and dust
(IP65). The touch screen built in LEAD-PPC-2150-X/ LEAD-PPC-2360-X can resist the
following chemicals such as acetone, methylene chloride, methyl ethyl ketone,
isopropyl alcohol, hexane, unleaded gas, diesel fuel, motor oil vinegar, cooking oil,
saline water, and so on.
2.1.2 Rear View
DC-IN 12V via DC Jack or DC-IN 24V via 3-pin Terminal Block Connector:
Provide power connection of Panel PC to the main power source via DC power cable
or AC/DC adapter.
Gigabit Ethernet:
Two Gigabit Ethernet (10/100/1000 Mbits/sec) LAN ports by using Intel WGI210IT
USB (Universal Serial Bus) ports:
Two USB 3.0 Connectors for USB-compatible devices
COM ports:
One connector for RS-232 connection
HDMI:
Type A HDMI display output
Power Button:
Press the button to turn ON/OFF the Panel PC.

System Installation
11
2.1.3 VESA®Mount
The Panel PC can install with VESA®75x75 compliant adapter plates in order to be
mounted on a wall. M4*10L screws must be used to fix the system onto the wall
mount adapter plate.

BIOS Setup Information
12
Chapter 3
BIOS Setup Information
LEAD-PPC-2150-X/ LEAD-PPC-2360-X Panel PC adopts MEDB-1002 mother
board. MEDB-1002 is equipped with the AMI BIOS stored in Flash ROM. These
BIOS has a built-in Setup program that allows users to modify the basic system
configuration easily. This type of information is stored in CMOS RAM so that it is
retained during power-off periods. When system is turned on,
LEAD-PPC-2150-X/ LEAD-PPC-2360-X communicates with peripheral devices
and checks its hardware resources against the configuration information stored in
the CMOS memory. If any error is detected, or the CMOS parameters need to be
initially defined, the diagnostic program will prompt the user to enter the SETUP
program. Some errors are significant enough to abort the start up.
3.1 Entering Setup—Launch System Setup
Power on the computer and the system will start POST (Power On Self Test)
process. When the message below appears on the screen, press <Del> key will
enter BIOS setup screen.
Press <Del> to enter SETUP
If the message disappears before responding and still wish to enter Setup, please
restart the system by turning it OFF and On or pressing the RESET button. It can
be also restarted by pressing <Ctrl>, <Alt>, and <Delete> keys on keyboard
simultaneously.
Press <F1> to Run General Help or Resume
The BIOS setup program provides a General Help screen. The menu can be easily
called up from any menu by pressing <F1>. The Help screen lists all the possible
keys to use and the selections for the highlighted item. Press <Esc> to exit the
Help screen.

BIOS Setup Information
13
3.2 Main
Use this menu for basic system configurations, such as time, date etc.
BIOS Information, Memory Information
These items show the firmware and memory specifications of your system. Read
only.
System Date
The date format is <Day>, <Month> <Date> <Year>. Use [＋] or [－] to configure
system Date.
System Time
The time format is <Hour> <Minute> <Second>. Use [＋] or [－] to configure
system Time.

BIOS Setup Information
14
3.3 Configuration
Use this menu to set up the items of special enhanced features.

BIOS Setup Information
15
CPU configuration
CPU Configure the specific active core(s) and advanced processor management
technologies.
Active Processor Cores
Number of cores to enable in each processor package.
The choice: Disabled(Default). Enabled.
Intel Virtualization Technology
When enabled, a VMM can utilize the additional hardware capabilities provided
by Vander pool Technology.
The choice: Disabled. Enabled(Default).
VT-d
Enable/ Disable CPU VT-d
The choice: Disabled. Enabled(Default).
EIST
Enable/Disable Intel Speed Step.
The choice: Disabled. Enabled(Default).
C-States
Enable or Disable C-States.
The choice: Disabled(Default). Enabled.

BIOS Setup Information
16
Chipset Configuration
Configuration Chipset feature.
HD-Audio Support
Enable or Disable the HD-Audio support.
The choice: Disabled. Enabled(Default).
8254 Clock Gating
Enable or Disable the 8254 Clock Gating
The choice: Disabled(Default). Enabled.
