Carver MULTICLAMP User manual

MULTICLAMP
ASSEMBLY INSTRUCTIONS
If you have a QR reader
on your mobile phone,
please visit our web site.
Manufactured in the UK
PART No C605055 Issue B

1
2
Standard reach
3
Max Load: 850DaN
1 Fit the head to the bar by inserting
the split pin into the smaller hole
in the bar.*
2 Insert the cap screw and hand tighten
with the allen key provided.**
3 Loosen the screw on the moving arm
to enable it to slide onto the bar.
NOTES:
* THE MATING FACES MUST BE KEPT CLEAN AND FREE FROM DAMAGE.
**DO NOT USE AN EXTENSION BAR ON THE ALLEN KEY TO TIGHTEN THE CAP SCREW OTHERWISE
THE INTERNAL THREADS IN THE BAR ARE LIKELY TO STRIP. IN THE EVENT THAT THIS THREAD
DOES GET DAMAGED IT CAN BE REPLACED; REMOVE THE DAMAGED HELICOIL AND REPLACE
IT WITH A NEW ONE - SEE PART No C301247 BELOW.
*THE CLAMP MUST NOT BE ASSEMBLED / USED WITHOUT THE SPLIT PIN IN PLACE. IF THE PIN IS
DAMAGED / MISSING THEN REPLACE WITH SPARES PART No C301248 BELOW.

Long reach
Max Load: 425DaN
3
1
2
1 Fit the head to the bar by inserting
the split pin into the smaller hole
in the bar.*
2 Insert the cap screw and hand tighten
with the allen key provided.**
3 Loosen the screw on the moving arm
to enable it to slide onto the bar.
NOTES:
* THE MATING FACES MUST BE KEPT CLEAN AND FREE FROM DAMAGE.
**DO NOT USE AN EXTENSION BAR ON THE ALLEN KEY TO TIGHTEN THE CAP SCREW OTHERWISE
THE INTERNAL THREADS IN THE BAR ARE LIKELY TO STRIP. IN THE EVENT THAT THIS THREAD
DOES GET DAMAGED IT CAN BE REPLACED; REMOVE THE DAMAGED HELICOIL AND REPLACE
IT WITH A NEW ONE - SEE PART No C301247 BELOW.
*THE CLAMP MUST NOT BE ASSEMBLED / USED WITHOUT THE SPLIT PIN IN PLACE. IF THE PIN IS
DAMAGED / MISSING THEN REPLACE WITH SPARES PART No C301248 BELOW.

SPARE PARTS
PART NUMBER DESCRIPTION
BAR
STANDARD REACH HEAD
LONG REACH HEAD
STANDARD REACH MOVING ARM
LONG REACH MOVING ARM
M10 x 1.5 x 45 SOCKET HEAD SCREW
ALLEN KEY
M10 x 1.5 x 1.5D HELICOIL
SPLIT SPRING TENSION PIN
C301243
C301244
C301245
C301246
C301247
C301248
C301249
C301000
C301100

AA1
BB3
L
L1
B1
B2
S (max)
A2
B4
CONFIGURATION S A A1 A2 B B1 B2 B3 B4 L L1
STANDARD
REACH
LONG
REACH
320 25 21.5 76 32 65 55 32 76 450 45
320 25 21.5 76 32 120 106 32 76 450 45
