SERVICE MANUAL
HANDHELD TERMINAL
Ver. 4 : Jun. 2017
DT-X200
APR. 2015
DT-X8 (For China Only)
APR. 2015

• BLUETOOTH is a registered trademark owned by Bluetooth SIG, Inc. and licensed to CASIO
COMPUTER CO., LTD.
• Microsoft and Windows are either registered trademarks or trademarks of Microsoft Corporation in the
United States and/or other countries.
Information in this document is subject to change without advance notice. CASIO Computer Co., Ltd. makes
no representations or warranties with respect to the contents or use of this manual and specifi cally disclaims
any express or implied warranties of merchantability or fi tness for any particular purpose.

CONTENTS
SAFETY PRECAUTIONS ....................................................................................................1
1. GENERAL .............................................................................................................................5
1-1. Confi guration by Model ..........................................................................................................5
1-2. Options ...................................................................................................................................5
2. SPECIFICATION ..................................................................................................................6
2-1. System Requirements ............................................................................................................6
2-2. Part Name ............................................................................................................................13
3. TECHNICAL INFORMATION ............................................................................................15
3-1. Wiring Diagram ....................................................................................................................15
3-2. System Diagram ..................................................................................................................16
4. RESET OPERATION ..........................................................................................................17
4-1. Resume ................................................................................................................................17
4-2. Reset ....................................................................................................................................17
4-3. Full Reset .............................................................................................................................17
4-4. User Disk Clear ....................................................................................................................18
4-5. Power-on Reset ...................................................................................................................18
5. HARDWARE TEST / SETTING .........................................................................................19
5-1. General ................................................................................................................................19
5-2. Test Equipment ....................................................................................................................20
5-3. Installing the Test Program ...................................................................................................21
5-4. Function Test ........................................................................................................................23
6. DISASSEMBLY AND REASSEMBLY ................................................................................48
6-1. LOWER-CASE-UNIT ...........................................................................................................49
6-2. UPPER-CASE-UNIT ............................................................................................................51
6-3. INNER-CASE-UNIT .............................................................................................................53
7. EXPLODED VIEW / PARTS LIST......................................................................................67
7-1. EXPLODED VIEW ...............................................................................................................68
7-2. PARTS LIST .........................................................................................................................74
7-3. CRADLE (HA-K60IO/K62IO) ...............................................................................................78
7-4. USB AND CHARGING UNIT (HA-K65US) ...........................................................................80
DT-X200/DT-X8

— 1 —
SAFETY PRECAUTIONS
Congratulations upon your selection of this CASIO product. Be sure to read the following Safety Precautions
before trying to use it for the fi rst time.
Your neglect or avoidance of the warning and caution statements in the subsequent pages causes the
danger of fi re, electric shock, malfunction and damage on the goods as well as personal injury.
Markings and Symbols
The following are the meanings of the markings and symbols used in these Safety Precautions.
This symbol indicates information that, if ignored or applied incorrectly, creates
the danger of death or serious personal injury.
This symbol indicates information that, if ignored or applied incorrectly, creates
the possibility of death or serious personal injury.
This symbol indicates information that, if ignored or applied incorrectly, creates
the possibility of personal injury or property damage.
• A diagonal line indicates something you should not do. The symbol shown here
indicates you should not try to take the unit apart.
• A black circle indicates something you should do. The symbol shown here
indicates you should unplug the unit from the wall outlet.
Disassembly and Modifi cation
• Never try to disassemble or modify the Handheld Terminal and its options
including battery pack and battery in any way.
Abnormal Conditions
• Should the Handheld Terminal and/or its options including battery pack and
battery become hot or start to emit smoke or a strange odor, immediately turn
off the power and contact your dealer or distributor whom you purchased the
product from, or an authorized CASIO service provider.

— 2 —
Dust and Moisture
• Though the Handheld Terminal is dust and water splash resistant, its options
including the battery pack are not. Keep loose metal objects and containers
fi lled with liquid away from your Handheld Terminal and the options. Also,
never handle the Handheld Terminal and the options while your hands are
wet.
Laser Light
• The laser scanner models (model dependant) with the integrated laser
scanning module scan bar codes using laser light. Never look directly into
the laser light or shine the laser light into the eyes.
Interference with the Operation of Other Equipment
(Using Wireless Data Communication)
• Keep your Handheld Terminal at least 22 centimeters (811/16") away from
anyone wearing a pacemaker. Radio waves emitted by the Handheld
Terminal can aff ect the operation of a pacemaker.
• Before the use in aircraft, be sure to consult with cabin crew for interference
the Handheld Terminal emits.
• Before the use in medical facility, be sure to consult with the facility
management or the manufacture of a specifi c medical equipment that the
Handheld Terminal may interfere with.
• Do not use the Handheld Terminal nearby gas pump or chemical tank or any
other places fl ammable or explosive.
• To comply with the relevant European RF exposure compliance
requirements, a separation distance of at least 3.8cm in wireless operation
must be maintained between the terminal and all persons around. This
terminal must not be co-located or operating in conjunction with other
transmitter.
Foreign Objects
• Take care to ensure that metals or combustible objects are not inserted into
the openings of the Handheld Terminal or its options, and not to allow
moisture to get inside of them.
Location
• Install the cradle properly on a fl at and stable surface so that it cannot fall
down onto fl oor.
LCD Screen
• Never apply strong pressure to the screen or subject it to strong impact.
Doing so can crack the LCD Screen.

— 3 —
Optional Lithium-ion Battery Pack
• Never use the Handheld Terminal and its option including the battery pack
and battery next to open fl ame, near a stove, or any other area exposed to
high heat, or leave them for a long period of time in a vehicle parked in direct
sunlight.
• Never use the battery pack with any device other than the Handheld
Terminal.
• Never dispose of the battery pack by incinerating it or otherwise expose it to
heat.
• Never transport or store the battery pack together with metal objects that may
result in shorting positive (+) and negative (–) terminals of the battery pack.
Be sure to place the battery pack in its case whenever transporting or storing
it.
• Never throw the battery pack or otherwise subject it to strong impact.
• Never pierce the battery pack with nails, hit it with a hammer, or step on it.
• Use only the specifi ed battery charger to charge the battery pack.
• Never place the battery pack in a microwave oven or any other high-voltage
device.
• If the amount of time period the battery pack can serve becomes consider-
ably short even after it has been fully charged for the specifi ed time period,
stop using it.
• Should the battery pack start to leak or emit a strange odor, immediately
move it away from any fl ame nearby. Leaking battery fl uid is combustible.
• Should fl uid from the battery pack accidentally get into your eyes or on the
skin, do not rub it. Immediately rinse it off with clean tap water and then
consult a physician.
• Replace only with the same type of battery pack recommended by CASIO.
Dispose of used battery packs according to the local regulation.
• Keep the battery pack out of the reach of small children.

— 4 —
Power Supply / AC Adaptor
• Do not use the Handheld Terminal at a voltage other than the specifi ed
voltage. Also, do not connect the Handheld Terminal to a multi-plug power
strip.
• Never modify, sharply bend, twist, or pull on the power cord.
• Never use a detergent to clean AC adaptor and its power cable, especially on
the plug and the jack.
• When using the battery chargers and the cradles, be sure to use the respec-
tive AC adaptors.
• Never pull on the power cord when unplugging it. Always hold the plug when
unplugging it from the wall outlet.
• Never touch the plug while your hands are wet.
• Be sure to unplug the power cord from the wall outlet before cleaning the
battery chargers and the cradles.
• Unplug the power cord from the wall outlet whenever leaving the battery
chargers and the cradles unattended for a long period.
• The housing of the AC adaptor can become warm during normal use.
• At least once a year, unplug the AC adaptor from the wall outlet and clean
any dust that builds up between the prongs of the plug.
Dust built up between the prongs can lead to the danger of fi re.
Backup Copies of All Important Data
• Note that CASIO Computer Co., Ltd. shall not be held liable to you or any
third party for any damages or loss caused by deletion or corruption of data
due to use of the Handheld Terminal, malfunction or repair of the Handheld
Terminal or its peripherals, or due to the batteries going dead.
• The Handheld Terminal employs electronic memory to store data, which
means that memory contents can be corrupted or deleted if power is inter-
rupted due to the batteries going dead or incorrect battery replacement
procedures. Data cannot be recovered once it is lost or corrupted. Be sure
to make backup of all important data. One way to do this is to use the sepa-
rately sold cradles to transfer data to a computer.

— 5 —
DT-X200/DT-X8
1. GENERAL
1-1. Confi guration by Model
Product Name Scanner W-LAN NFC Remarks
DT-X200-10E 1D IEEE 802.11a/b/g/n 
DT-X200-20E 2D IEEE 802.11a/b/g/n 
DT-X200-11E 1D IEEE 802.11a/b/g/n 
DT-X200-21E 2D IEEE 802.11a/b/g/n 
DT-X200-41E Full Range IEEE 802.11a/b/g/n 
DT-X8-10C-CNV 1D IEEE 802.11a/b/g/n China
DT-X8-20C-CNV 2D IEEE 802.11a/b/g/n China
1-2. Options
Product Name Description
HA-K60IO USB Cradle
HA-K62IO Ethernet Cradle
HA-K65US USB and Charging Unit
HA-K36DCHGE Cradle-type Battery Charger
HA-F32DCHG Dual Battery Charger
DT-380USB-A USB Cable (Cradle-computer connection)
AD-S42120C-N5 AC Adaptor for Ethernet Cradle/Dual Battery Charger
AD-S15050B-N5 AC Adaptor for USB Cradle/USB and Charging Unit
AD-S90190C AC Adaptor for Cradle-type Dual Battery Charger
HA-K23XLBAT
HA-K23XLBAT-CN
Battery Pack
Battery Pack for China
AC-CORD
AC-CORD2 Power Cord
HA-K95HB Hand Belt
HA-K90PS5 Screen Protect Sheet

— 6 —
DT-X200/DT-X8
2. SPECIFICATION
2-1. System Requirements
Item Specifi cations
CPU Marvell® PXA320 806MHz
OS Microsoft® Windows® Embedded Compact7
Memory RAM 256MB
FlashROM 512MB (User area: 300MB)
1D Laser model Frontage Straight 7 degree
Wavelength 645 ~ 664nm
Optical Output 1mW or less
No. of scans 100 ± 20scan/sec
Resolution 0.127mm
Read PCS 0.45 or higher
Readable Distance Approx 40 ~ 550mm
Scan Width Max. 424mm (Depth 550mm)
Ambient light Sunlight 50,000 lux or less
Readable
Symbologies
UPC-A/UPC-E/EAN8(JAN8)/EAN13(JAN13)/Codabar(NW-7)/
Code39Interleaved2of5(ITF)/MSI/Industrial2of5/Code93/
Code128(EAN128)/IATA/GS1 DataBar Omnidirectional(RSS-14)/
GS1 DataBar Limited(RSSLimited)/
GS1 DataBar Expanded(RSS Expanded)/
GS1 DataBar Stacked(RSS-14Stacked)/
GS1 DataBar Expanded Stacked(RSS Expanded Stacked)/
GS1 DataBar Truncated/
GS1 DataBar Stacked Omnidirectional(RSS-14 Stacked Omnidirectional)
2D Scanner
model
Principle CMOS imager, 832 × 640, Monochrome
Aimer Laser: 650nm, 1mW or less
Frontage Straight 30 degree
Resolution 1D: 0.127mm
2D Stacked: 0.168mm
2D Matrix: 0.191mm
Read PCS 0.45 or higher
Readable Distance 1D Resolution 0.25mm: 48 ~ 250mm
1D Resolution 0.5mm: 72 ~ 400mm
2D stacked Resolution 0.25mm: 43 ~ 230mm
2D matrix Resolution 0.25mm: 67 ~ 150mm
2D matrix Resolution 0.5mm: 51 ~ 300mm
* Varies depending on the environment and transmission rate.
Scan Width Max. 39mm (Depth 48mm)
Max. 275mm (Depth 400mm)
* Varies depending on the environment and transmission rate.
Focusing 5 inch
Ambient light Sunlight 50,000 lux or less

— 7 —
DT-X200/DT-X8
Item Specifi cations
2D Scanner
model
Readable
Symbologies
(1D)
UPC-A/UPC-E/EAN8(JAN8)/EAN13(JAN13)/Codabar(NW-7)/
Code39Interleaved2of5(ITF)/MSI/Code93/
Code128(GS1-128(EAN128))/Code11/
GS1 DataBar Omnidirectional(RSS-14)/
GS1 DataBar Limited(RSSLimited)/
GS1 DataBar Expanded(RSS Expanded)/
Code32/GS1 DataBar Truncated(RSS-14 Truncated)/ISBT
Readable
Symbologies
(2D Stacked)
PDF417/Micro PDF/Composite/Codablock F/
GS1 DataBar Stacked Omnidirectional (RSS-14 Stacked Omnidirectional)/
GS1 DataBar Expanded Stacked (RSS Expanted Stacked)/
GS1 DataBar Stacked (RSS-14 Stacked)
Readable
Symbologies
(2D Matrix)
Aztec,DataMatrix,Maxicode,QR Code,Micro QR,HanXin Code
Full Range
Imager model
Principle CMOS imager, 1280 × 1024 (SXGA), Monochrome
Aimer Laser: 650 +10/-5 nm, 1 mW or less
Frontage bend angle 0°
Resolution 1D: 0.127mm
2D Stacked: 0.127mm
2D Matrix: 0.169mm
Read PCS 0.45 or higher
Readable Distance 1D: 130mm (Resolution: 0.127mm) ~ 2500mm (Resolution: 1.0mm)
2D Stacked: 130mm (Resolution: 0.12 7mm) ~ 2500mm (Resolution:
1.0mm)
2D Matrix: 100mm (Resolution: 0.38mm) ~ 20000mm (Resolution: 20mm)
* The value varies with an environment of usage, kinds of codes and
printing status.
Scan Width Max. 36mm (Depth 100mm)
Max. 852mm (Depth 2500mm)
* The value varies with an environment of usage, kinds of codes and
printing status.
Focusing Auto focus
Ambient light Sunlight 10,000 lux or less
Readable
Symbologies
(1D)
UPC-A/UPC-E/EAN8(JAN8)/EAN13(JAN13)/Codabar(NW-7)/
Code39Interleaved2of5(ITF)/MSI/Code93/
Code128(GS1-128(EAN128))/Code11/
GS1 DataBar Omnidirectional(RSS-14)/
GS1 DataBar Limited(RSSLimited)/
GS1 DataBar Expanded(RSS Expanded)/
Code32/GS1 DataBar Truncated(RSS-14 Truncated)/ISBT/Cord32
Readable
Symbologies
(2D Stacked)
PDF417/Micro PDF/Composite/Codablock F/
GS1 DataBar Stacked Omnidirectional (RSS-14 Stacked Omnidirectional)/
GS1 DataBar Expanded Stacked (RSS Expanted Stacked)/
GS1 DataBar Stacked (RSS-14 Stacked)/
Readable
Symbologies
(2D Matrix)
Aztec,DataMatrix,Maxicode,QR Code,Micro QR
Vibrator Notices scan reading

— 8 —
DT-X200/DT-X8
Item Specifi cations
Display System TFT
Display Size 2.7 inch
No. of Dots 240 (horizontal) × 320 (vertical) (QVGA)
Dot Pitch 0.171 mm (vertical) × 0.171 mm (horizontal)
Gradation 65,536 colors
Display Font Scalable font
Backlight LED backlight
View Angle 80 degrees (right - left - up - down)
* Contrast: more than 10
Indicator LED 3-color (Red, Green, Blue) LED × 1
2-color (Red, Green) LED × 1
Input Keyboard With key backlight
Control Keys Power, Reset
Side (Trigger) Keys Center, L, R
WLAN Standards IEEE 802.11a/b/g/n
Type of Emission Spread spectrum communication system
Spread Spectrum
Modulation
802.11a/g/n: OFDM (Orthogonal Frequency Division Multiplexing) method
802.11b: DSSS (Direct Sequence Spread Spectrum) method
Modulation Method BPSK,QPSK,CCK,16QAM,64QAM
ITU code
(Emission Identifi er)
802.11a/g/n: D1D, G1D
802.11b: G1D
Radio Frequency
Center frequency
Frequency range
IEEE802.11a/n(5GHz)
W52: 36/40/44/48ch (5.18 ~ 5.24GHz)
W53: 52/56/60/64ch (5.26 ~ 5.32GHz)
W56: 100/104/108/112/116/120/124/128/132/136/140ch
(5.50 ~ 5.70GHz)
IEEE802.11b: 1 ~ 13ch (2.412 ~ 2.484GHz)
IEEE802.11g/n(2.4GHz): 1 ~ 13ch (2.412 ~ 2.472GHz)
IEEE802.11a/n(5GHz)
W52,W53: 5.15 ~ 5.35GHz
W56: 5.47 ~ 5.725GHz
IEEE802.11b: 2.400 ~ 2.497GHz
IEEE802.11g/n(2.4GHz): 2.400 ~ 2.4835GHz
Transmission Rate 802.11a/g: Max. 54Mbps
802.11b: Max. 11Mbps
802.11n: Max. 65Mbps
* Varies depending on the environment.
Transmission
Distance
802.11b/g/n(2.4GHz): In doors - 50m, Out of doors - 150m
802.11a/n(5GHz): In doors - 50m, Out of doors - 150m
* Varies depending on the environment and transmission rate.
No. of Channels 802.11a/n(5GHz)
W52,W53: 4ch
W56: 11ch
802.11b: 14ch
802.11g/n(2.4GHz): 13ch
Channel Interval 802.11a/n(5GHz): 20MHz
802.11b/g/n(2.4GHz): 5MHz
Channel Bandwidth 802.11a/b/g/n: 20MHz

— 9 —
DT-X200/DT-X8
Item Specifi cations
WLAN Output 802.11a: Max. 14Mbps
802.11b: Max. 20Mbps
802.11g: Max. 15Mbps
802.11n: Max. 14Mbps
Other Function Roaming among multiple access points
* Depends on access point
Security Security: WEP(64/128bit)/WPA/WPA2WPA
Encryption scheme: TKIP/AES
Authentication method: PSK/EAP-TLS/PEAP-MSCHAP-V2
Bluetooth
Communication
Class 2
Standard Bluetooth® Specifi cation Ver.2.1+EDR
Type of Emission Spread spectrum communication system
Spread Spectrum
Modulation
FHSS (Frequency Hopping Spread Spectrum) method
Modulation Method GFSK (1MbpS), Π/4-dqpsk (2Mbps), 8-DPSK(3Mbps)
ITU Code
(Emission Identifi er)
F1D,G1D
Radio Frequency 2.400 ~ 2.4835GHz
Transmission
Distance
Approx. 3 m
* Varies depending on the radio wave conditions and environment.
No. of Channels 79ch
Channel Interval 1MHz
Channel Bandwidth 1MHz
Output Max. 4dBm (PowerClass2)
Profi le GAP, SDP, SPP(Client, Server),DUN, HID(Host),
OBEX Object Push Profi le
NFC Carrier Frequency 13.56MHz ± 7kHz
Antenna Magnetic fi eld type loop antenna
Magnetic Field Output magnetic fi eld strength when contacting the case:
1.5 A/m or more
Output magnetic fi eld strength when 50 mm apart from the case:
0.15 A/m or more
Bit rate ISO14443 Type A : 106kbps
ISO14443 Type B : 106kbps
Felica : 212kbps, 424kbps
Modulation Method ASK
Modulation Degree 10 % modulation, 100 % modulation
Readable Distance ISO14443 Type A/B, FeliCa: 0mm (Touching the case)
ISO15693: 0mm (Touching the case) ~ Max. 80mm
* Depends on the antenna design, etc. of a tag.
Readable Area 32mm × 20mm
* Depends on the kinds of cards and tags.

— 10 —
DT-X200/DT-X8
Item Specifi cations
NFC Communication Protocol
Standards
Supported Operation-check confi rmed IC
ISO14443 Type A MIFARE Standard/MIFARE Ultralight
ISO14443 Type B 
JICSAP
* Before introducing, prior confi rmation of card is required as
some cards may be out of ISO standard.
Felica (JIS X 6319) Felica Standard
ISO15693 
I•CODE SLI, I•CODE SLI-S, I•CODE SLI-L, my-d VID plain,
my-d Light, Tag-it plus, Tag-it pro, Tag-it standard
* It will take time to write data to Tag-it. Also, there are some
commands that require retry on application.
ISO18092
Communication
between terminals
* Not supported by software
ISO18092
Card mode 
USB Host Transmission rate: Full speed (12 Mbps), Low speed (1.5 Mbps)
External output power: 5V ± 0.25V/100 mA
Client Transmission rate: Full speed (12 Mbps)
USB power feeding: 5.0V ± 0.25V/500mA or more
microSD SDHC supported
Extension Port
Speaker Monaural
Microphone Monaural
<
Power Supply/Data Communication Terminals
>
1 2 3 4 5 6
Pin No. Name Function Input/Output
1 V CRADLE I/O box power -
2 D+ USB D+ IN / OUT
3 D– USB D– IN / OUT
4 USB_ID USB host/client switching IN
5 V BUS USB power -
6 GND GND -

— 11 —
DT-X200/DT-X8
<
Power
>
Item Specifi cations Remarks
Main Battery Lithium ion battery Standard/Large-capacity
Backup Battery Rechargeable lithium battery × 1 Built-in type
Operating Time
* Normal temperature
* Brand-new battery
Standard Battery Pack
- Laser model: Approx. 10 hours
- 2D model: Approx. 9 hours
Large-capacity Battery Pack
- Laser model: Approx. 14 hours
- 2D model: Approx. 13 hours
• CPU speed setting
= Automatic power saving mode
• Backlight = ON
• WEB Application mode
• Standby:Key input:Scan:Calculation:Wireless
= 15:5:1:2:2
• CPU speed setting
= Automatic power saving mode
• Backlight = ON
• WEB Application mode
• Standby:Key input:Scan:Calculation:Wireless
= 15:5:1:2:2
• Ratio of scan (NFC:Barcord = 9:1)
Standard Battery Pack
- Laser model: Approx. 17 hours
- 2D model: Approx. 15 hours
Large-capacity Battery Pack
- Laser model: Approx. 25 hours
- 2D model: Approx. 20 hours
• Normal temperature
• Brand-new battery
• CPU speed setting
= Automatic power saving mode
• Backlight = OFF
• Standby:Key input:Scan:Wireless
= 20:1:1:1
Standard Battery Pack:
Approx. 17 hours
Large-capacity Battery Pack
Approx. 25 hours
• Normal temperature
• Brand-new battery
• CPU speed setting
= Automatic power saving mode
• Backlight = OFF
• Standby:Key input:NFC:Wireless
= 20:1:1:1
Standard Battery Pack
- Laser model: Approx. 8 hours
- 2D model: Approx. 7 hours
Large-capacity Battery Pack
- Laser model: Approx. 13 hours
- 2D model: Approx. 11 hours
• JEITA A mode
• Wireless communication is always-on.
• Backlight = ON
• Scans two times in 10 seconds.
• Performs data transmission of 1KB.
Backup Time
(Backup Battery only)
RAM: 10 minutes
RTC: 72 hours or more
• Normal temperature
• Backup battery is fully charged.
Backup Time
(Main Battery +
Backup Battery)
RAM: Approx. 72 hours • After a main-battery remaining alarm occurs.
Main Battery Charge
Time
Standard Battery Pack:
Approx. 3 hours
Large-capacity Battery Pack
Approx. 4 hours
• Normal temperature
• USB Cradle, Ethernet Cradle and USB,
Charging Unit and AC adaptor
* When USB-PC is connected.
Standard Battery Pack:
Approx. 6.5 hours
Large-capacity Battery Pack
Approx. 8 hours
• Normal temperature
• USB and Charging Unit
Backup Battery
Charge Time
Approx. 4 days • Normal temperature
• Time required to be fully charged with the Main
Battery is installed.

— 12 —
DT-X200/DT-X8
<
Dimensions
>
DT-X200-10E/11E/20E/21E
DT-X8-10C-CNV/20C-CNV
DT-X200-41E
Approx. 66mm
(Display)
Approx. 57mm
(Grip)
Approx. 32mm
(Display)
Approx. 187mm
Approx. 41mm
Approx. 57mm
(Grip)
Approx. 32mm
(Display)
Approx. 187mm
Approx. 44mm
Approx. 35mm
(Grip)
<
Weight
>
Approx. 280g (DT-X200-10E/20E/DT-X8-10C-CNV)
Approx. 285g (DT-X200-11E/21E/DT-X8-20C-CNV)
Approx. 295g (DT-X200-41E)
* Including lithium-ion battery pack.

— 13 —
DT-X200/DT-X8
2-2. Part Name
Top
FrontLeft Right
Back
13
123
4
5
6
8
7
9
1015
14
11
12
17
18
20
16
19
20
16
22
2216 16
23
27
24
25 24 25
26
21
28
Bottom

— 14 —
DT-X200/DT-X8
No. Name Description
1 Speaker Generates audio and buzzer tones.
2 Indicator 1 Orange: Charging
Green: Charging complete
Red: Battery pack error or the surrounding temperature is out of the charging
temperature range.
3 Indicator 2 Flashes blue when operating via Bluetooth or orange when operating via W-LAN.
Lights red when there is a bar code scanning error and lights green when a bar
code scans successfully.
Lights red when the alarm function is activated.
Flashes magenta when the DT-X200 is ready to communicate.
4 Screen The screen displays texts, operations, indicators and so forth.
5 Cursor Key Perform the same functions as the up, down, left and right arrow keys on a PC
keyboard.
6 Center Trigger Key Used to perform bar code reading. Can be assigned an arbitrary function.
7 Power Key Turns the power on and off .
8 R Key Can be assigned an arbitrary function.
9 L Key Can be assigned an arbitrary function.
10 Enter Key Press when fi nishing entering numerical values or when moving to the next step.
11 Numeric Keys Used to enter numeric values and decimal points.
12 Function Keys F1: Similar function as the Alt key on a PC keyboard.
F2: Similar function as the Shift+Tab keys combination on a PC keyboard. Used to
move the cursor among entry or selection items.
F3: Similar function as the Tab key on a PC keyboard. Used to move the cursor
among entry or selection items.
F4: Not assigned.
F5: Enter a space.
F6: Similar function as the cursor left key on a PC keyboard.
F7: Similar function as the cursor right key on a PC keyboard.
F8: Select text entry mode.
(The mode changes in order of Numeric → Uppercase letter → Lowercase letter)
13 Microphone Used for audio input (including voice).
14 Fn Key Used to make various settings in combination with the numeric
keys or when starting a pre-registered application.
15 CLR Key Used to clear one letter to the left of the cursor.
16 Strap Holes Used to attach neck strap and hand belt.
17 microSD Card Slot microSD card slot.
18 R Trigger Key Used to perform bar code reading.
19 L Trigger Key Used to perform bar code reading.
20 USB and Charging Unit
Mount Holes
Used to attach the USB and Charging Unit.
21 Barcode Reader/
NFC Reader
Laser light or LED light is emitted from this window that reads bar codes.
When using NFC, hold the card or tag up to the reader.
22 Hand Belt Mount Used to attach the hand belt.
23 Extension Port Provided for future extension.
24 Battery Pack Cover
Lock Switches
Used to lock the battery cover and to release.
25 Mount Holes These holes hold the terminal seating in the optional USB Cradle or in the Ethernet
Cradle.
26 Battery Pack Cover Used to cover the battery compartment that holds the battery pack inside.
27 Reset Switch Used to reset the Handheld Terminal.
28 Power Supply/Data
Communication
Terminals
Used to receive power provided by the USB Cradle, Ethernet Cradle or USB and
Charging Unit. Also used for data communication.

— 15 —
DT-X200/DT-X8
3. TECHNICAL INFORMATION
3-1. Wiring Diagram
CN1
CN3
Speaker
Laser Scaner
LCD
2.7inch TFT
320×240
IC26
Bluetooth
IC1
CPU
CN13
MicroSD Slot
SW1
(Reset Switch)
IC2
ASIC
IC86
W-LAN
CHG-LEDCOM-LED
CN18
WLAN-AntennaWLAN-Antenna
4pin
CN17
CN24
30pin
CN16
13pin 13pin
12pin
30pin 30pin
CN15
39pin
Touch
Panel
(Resistive)
4pin
FPC
FPC
CN14
50pin
Trigger
SW
Trigger
SW
MAIN-PCB
FPC-PY052-EXT
FPC-PY052-NFC
PWB-PY052-NFC
FPC-PY052-NFCANT
FPC-PY052VA-LS or
FPC-PY052VA-2D or
FPC-PY052VA-FRI
FPC-PY052-TR-LC
FPC-PY052-TR-IC
PWB-PY052-BAT
PWB-PY052-KEY
Li-ion
Terminal
- T +
Li-ion
Terminal
Li-ion
Terminal
Vibrator
MicrophoneCradle I/F
4pin
Battery Cover Lock Detect
2pin 2pin
SUB-BAT
CN7
61pin
2D Imager
FPC
30pin
Full Range Imager
(Decoder)
14pin
34pin
Full Range
Imager
(Module)
34pin
PWB-PY052-CAP
KBL
LED
KEY
FPC-PY052-FRIMDL
NFC
Controller

— 16 —
DT-X200/DT-X8
3-2. System Diagram
HA-K21LBAT
HA-K23XLBAT
microSD Card
DT-X200
DT-X8
Battey Pack
AC Adaptor
AD-S42120B-N5
Dual Battery Charger
HA-F32DCHG
Battey Pack
Battey Pack
Dual Battery Charger
HA-F32DCHG
Battey Pack
Battey Pack
Dual Battery Charger
HA-F32DCHG
Battey Pack
Battey Pack
Battery Terminals
microSD Card Slot
Expansion Port
Power Suplly/Data
Communication
Terminals
Bluetooth Module
(Ver2.0+EDR)
USB Terminal
(Host/Client)
IEEE802.11b/g
Module
Bluetooth Products
IEEE802.11a/b/g/n
Products
Access Point
Printer Access Point
TEL/Cellphone
HA-K36DCHG
AC Adaptor
AD-S60160B
HA-K36DCHG
USB Cradle
HA-K60IO
AC Adaptor
AD-S15050B-N5
AC Adaptor
AD-S15050B-N5
USB and Charging Unit
HA-K65US
USB Prodect
AC Adaptor
AD-S42120B-N5
Ethernet Cradle
HA-K62IO
HA-K36DCHG
USB Client
USB Client
USB Client
USB Host
LAN Port
PC

– 17 –
DT-X200/DT-X8
4. RESET
When a power on factor occurs, resume or reset is used to start the system.
A reset clears program execution status. Therefore, data on the RAM in work is discarded, because there is
a possibility that in the middle of writing a fi le is corrupt, you need to be careful. Resume, will return to the
program execution state before power OFF.
4-1. Resume
If the device has had its power turned off (to suspend) normally, it resumes the next time its power is
turned on. Resume, and continue the process that was running the last of the power supply is OFF.
Program execution memory in RAM, unsaved data in use, and data in data storage memory and
FlashDisk are retained.
4-2. Reset
When you press the RESET button, or you can run when you perform a soft reset function.
Running program is discontinued, after shutdown process, and then run the reboot of the OS.
Root disk (¥, ¥ Windows folder, etc.) and registry information, FlashDisk, data on the SD card will be
retained.
[Caution]
(1) If you lock the system during the reset process (when no response time is more than about 10
seconds), it will be forced to reset by skipping the shutdown process.
(2) When not restarting the body even if a RESET button is pressed, please do the following
operation."CLR" while a key and a "0" key are being pushed, a RESET button in the body back is
pressed.
4-3. Full Reset
This occurs if both Fn and CLR keys are held down at the same time and then the Reset button is
pressed for a period of one second or longer, by default, while the terminal is in operation.
Running program is discontinued, after shutdown process, and then restart the OS.
In this situation, the confi rmation message “OK to clear?” is displayed twice. Use the right trigger
key and left trigger key to confi rm. If the right trigger key is pressed in response to both times the
confi rmation message is displayed, the memory (data storage memory, and OS and program execution
memory) is cleared, and initialization is performed. However, data on FlashDisk is retained.
