CASIO
DT-X8 Series
Software Manual
(Version 1.02)
CASIO Computer Co., Ltd.
Copyright ©2011. All rights reserved.
March 2011

2
Table of the Contents
Editorial Record 6
Preview 7
Chapter 1. Product Overview 8
1.1 Model by Feature 8
1.2 Available Options 9
Chapter 2. Functions 10
2.1 Basic Specifications 10
2.1.1 Windows Embedded CE 6.0 R3 10
2.1.2 Display 17
2.1.3 Touch Panel 19
2.1.4 Keys 20
2.1.5 Audio 28
2.1.6 Buzzer Sounds 29
2.1.7 Memory Management 30
2.1.8 Reset 32
2.1.9 Memory Corruption Check 34
2.1.10 LED 35
2.1.11 Vibration 37
2.2 Laser Scanner 38
2.2.1 Basic Specifications 38
2.2.2 Scanning Method 40
2.2.3 Scanning Parameters 42
2.2.4 Scanning Output Format 45
2.2.5 Scan Result Notification 54
2.2.6 Expanded Features 55
2.2.7 Power Control 77
2.3 CMOS Imager 78
2.3.1 Basic Specifications 78
2.3.2 Scanning Method 81
2.3.3 Scanning Parameters 83
2.3.4 Scan Result Notification 85
2.3.5 Expanded Features 86
2.4 USB 97
2.4.1 Basic Specifications 97
2.4.2 COM Port 98
2.4.3 Product ID 98
2.5 Bluetooth 99
2.5.1 Basic Specifications 99
2.5.2 Communication Profiles 100
2.5.3 Security 101
2.5.4 COM Port 101
2.5.5 Communication Procedure 102
2.5.6 Communication Procedure by Profile 103
2.5.7 Process after Communication Interruption 104
2.5.8 Process During Suspend and Resume 104
2.5.9 Setting SR Mode Parameter 104
2.5.10 Simultaneous Use with WLAN 105

3
2.5.11 Communication Range 106
2.6 WLAN 107
2.6.1 Basic Features 107
2.6.2 Expanded Features 108
2.6.3 Roaming 109
2.6.4 Zeroconfig 110
2.6.5 Channels 111
2.6.6 WLAN Setting with Configuration File 111
2.7 Power Control 118
2.7.1 Monitoring Low Voltage 118
2.7.2 Power ON Factors 121
2.7.3 Power OFF Factors 122
2.7.4 Controls on Power Key 123
2.7.5 Power Saving 124
2.7.6 CPU Power State Control 126
2.7.7 Virtual OFF by Application 128
2.7.8 Virtual OFF by System 130
2.7.9 Charging/Supplying the Power 131
2.7.10 Temperature Control 132
2.8 Security 133
2.8.1 Setting Password for Terminal 133
2.8.2 Setting Password for Date and Time 133
2.8.3 Setting Individual ID 133
2.8.4 Setting Distributor ID 133
Chapter 3. Control Panel Applets 134
3.1 System 136
3.2 Version Info 138
3.3 Regional Settings 139
3.4 Date/Time 141
3.5 Owner 142
3.6 Dialing 145
3.7 Network and Dial-up Connections 146
3.8 Internet Options 149
3.9 Certificates 155
3.10 Terminal Server Client Licenses 156
3.11 Display 157
3.12 Brightness 159
3.13 Stylus 162
3.14 Mouse 163
3.15 Input Panel 164
3.16 Keyboard 165
3.17 Volume & Sounds 167
3.18 Buzzer 168
3.19 Storage Manager 169
3.20 Remove Programs 174
3.21 Laser Setting 175
3.22 Imager Setting 180
3.23 PC Connection 188
3.24 USB Connection 189
3.25 Bluetooth Device Properties 190

4
3.25.1 Bluetooth Power (Bluetooth Manager) 190
3.25.2 Scan Device 190
3.25.3 Connection between DT-X8 and PC by ActiveSync 191
3.26 WLAN Power 192
3.27 WLAN Settings 193
3.28 Power 202
3.29 CPU Speed 205
3.30 Password 206
Chapter 4. Application Programs 207
4.1 Internet Explorer 208
4.2 TextEditor 210
4.3 Explorer 211
4.4 Command Prompt 213
4.5 Remote Desktop Connection 214
4.6 CMail 216
4.7 Voice Recorder 227
4.8 Notes 228
4.9 Backup Tool 230
4.10 Laser Scanner Demo 236
4.11 Laser Scanner Read 239
4.12 Image Scanner Demo 240
4.13 Image Scanner Read 244
4.14 LCD Display 245
4.15 Buzzer / Vibration 245
4.16 Copy Devices 246
4.17 FLCE 253
4.18 ActiveSync 254
4.19 NetSearch 255
4.20 WLAN Barcode Setting 259
4.21 System Barcode Setting 259
4.22 System Settings 260
4.23 Mobile Module Updater 260
4.24 LogViewer 261
4.25 Auto rescue tool 275
4.26 Easy Data Collection 276
4.27 System Menu 277
Chapter 5. Utilities 279
5.1 FCHKCE 279
5.2 Auto Setup 279
5.3 Welcome Wizard 280
5.4 Input Panel (SIP) 281
5.5 IE Cache Delete Tool 281
5.6 DiskClean 282
Chapter 6. PC Application Programs 284
6.1 ActiveSync 284
6.2 Windows Mobile Device Center (WMDC) 284
6.3 LMWIN 285
6.4 FCHK 285

5
No part of this document may be produced or transmitted in any form or by any means, electronic
or mechanical, for any purpose, without the express written permission of CASIO Computer Co.,
Ltd. in Tokyo Japan. Information in this document is subject to change without advance notice.
CASIO Computer Co., Ltd. makes no representations or warranties with respect to the contents or
use of this manual and specifically disclaims any express or implied warranties of merchantability
or fitness for any particular purpose.
© 2011 CASIO Computer Co., Ltd. All rights reserved.

6
Editorial Record
Manual
Version no. Date edited Page Content
1.00 January 2011 all Original version
191 In Chapter 3.25.3, content is added.
9 In Chapter 1.2, HA-F21LBAT-A option is deleted.
1.01 February 2011
261 In Chapter 4.22, description about execution log is deleted.
10, 97,
133, 277
OS description name is updated.
259 System Barcode Setting is added.
1.02 March 2011
260 System Settings is added.

7
Preview
The features and specifications described in this reference manual give an overview of the
functional detailed specifications of the DT-X8 series handheld terminal.

8
1. Product Overview
1.1 Model by Feature
The major features integrated in each model of the DT-X8 series are shown below.
Table 1.1 List of available models
Model no. Scanner Extension slot WLAN
(802.11 b/g) Bluetooth
DT-X8-10E Laser microSD Yes Yes
DT-X8-10C-CN Laser microSD Yes Yes
DT-X8-20E Imager microSD Yes Yes
DT-X8-20C-CN Imager microSD Yes Yes
Note:
“-CN” attached at the end of model number denotes that the model is dedicated for the final
destination of China. A note about compliance with the Chinese “RoHS” requirement
promulgated by the Ministerial Decree No. 39 is accompanied in the carton box; the RoHS
compliant seal is affixed on the body and the seal of the packing material recycle marking is
affixed on the carton box.

9
1.2 Available Options
The following dedicated options are available for DT-X8 series.
Table 1.2 List of options
Option Product Model no. Remark
HA-K60IOUSB Cradle
HA-K60IO-CN
HA-K62IOEthernet Cradle
HA-K62IO-CN
HA-K65US
Cradle
USB and Charging Unit
HA-K65US-CN
HA-F32DCHGBattery charger Dual Battery Charger
HA-F32DCHG-CN
AD-S15050B-N
AD-S15050BE-CN
- For HA-K60IO, HA-K65US
AD-S42120B-N
AC adaptor
AD-S42120BE-CN
- For HA-K62IO, HA-F32DCHG
AC-CORD-EU - For Europe
AC-CORD-US - For USA/Canada
AC-CORD-TW - For Taiwan
AC-CORD-KR - For Korea
Power Cable for AD-S15050B-N,
AD-S42120B-N
AC-CORD-AU - For Australia/New Zealand
HA-K23XLBATBattery Large Battery Pack
HA-K23XLBAT-CN
DT-380USB-ACable USB cable
DT-380USB-A-CN
- For between cradle and PC
HA-K95HBOthers Hand Belt
HA-K95HB-CN
Note:
“-CN” attached at the end of model number denotes that the model is dedicated for the final
destination of China. A note about compliance with the Chinese “RoHS” requirement
promulgated by the Ministerial Decree No. 39 is accompanied in the carton box; the RoHS
compliant seal is affixed on the body and the seal of the packing material recycle marking is
affixed on the carton box.

10
2. Functions
This chapter describes about detailed specifications of the functions implemented in the terminal
and the options.
2.1 Basic Specifications
This chapter describes about basic specifications of the terminal.
2.1.1 Windows Embedded CE 6.0 R3
The terminal integrates Microsoft®Windows Embedded CE 6.0 R3 as its operating system.
•Easy-to-use user interface
•Improvement of kernel (note)
•Large file size (4GB) is supported
•SDHC card (SDHC Ver2.0 standard) is supported
•RDP6.0 is supported
•Easy development thanks to open environment
•PPC application operation with AYGShell
•.NET Compact FrameWork 2.0 / 3.5 is supported
•High speed processing
Note:
The performance of the OS integrated in the terminal has been significantly improved by the
modified kernel architecture. The modification has resulted in reduction of the overhead for the
system call. This improvement includes that the driver can run in the kernel mode, the virtual
memory space is expanded to 2 GB, and the 32K process is made possible. Thus, the unstable
system in the WindowsCE Ver. 5.0 or earlier caused by the lack of resource has been also solved.
