IT-G400 Series
Android 6.0
Hardware Manual
This document describes hardware
specifications of the IT-G400.
Ver 1.00

No part of this document may be produced or transmitted in any form or by any means, electronic or mechanical,
for any purpose, without the express written permission of CASIO Computer Co., Ltd. in Tokyo Japan.
Information in this document is subject to change without advance notice.
CASIO Computer Co., Ltd. makes no representations or warranties with respect to the contents or use of this
manual and specifically disclaims any express or implied warranties of merchantability or fitness for any
particular purpose.
© 2017 CASIO Computer Co.,Ltd.
The Bluetooth word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such
marks by CASIO COMPUTER CO.,LTD. is under license. Other trademarks and trade names are those of their
respective owners.
Wi-Fi is a registered trademark of Wi-Fi Alliance.
Android, Android Wear, Google, Google Play, Google Now and other marks are trademarks of Google Inc.
Other company, product and service names used in this manual also may be trademarks or registered trademarks of
others.

-Table of contents -
1. Overview··········································································································································································1
1.1 Model composition················································································································································1
1.1.1 List of models ·················································································································································1
1.1.2 List of options·················································································································································1
1.2 Interfaces·································································································································································2
1.3 Appearance ·····························································································································································3
1.3.1 IT-G400 ····························································································································································3
1.3.2 USB Cradle······················································································································································5
1.3.3 Four-bay Battery Charger ·························································································································5
1.3.4 Four-cradle Battery Charger ····················································································································6
1.4 Hardware specification········································································································································7
1.4.1 IT-G400 ····························································································································································7
1.4.2 USB Cradle··················································································································································· 12
1.4.3 Four-bay Battery Charger ······················································································································ 12
1.4.4 Four-cradle Battery Charger ················································································································· 13
1.5 Environmental Sprcification···························································································································· 13
1.5.1 IT-G400 ························································································································································· 13
1.5.2 USB Cradle··················································································································································· 13
1.5.3 Four-bay Battery Charger ······················································································································ 14
1.5.4 Four-cradle Battery Charger ················································································································· 14
2. Precautions·································································································································································· 15
2.1 Handling and Operating Precautions··········································································································· 15
2.2 Storage ·································································································································································· 17
2.3 Safety precautions ············································································································································ 17
3. Maintenance································································································································································· 17
4. Setup and Installation··············································································································································· 17

1
1. Overview
1.1 Model composition
1.1.1 List of models
model Imager Camera WAN
GPS
WLAN
Bluetooth
NFC Battery
Size
Remark
IT-G400-C21M ○○×○○Standard
IT-G400-C21L ○○×○○Large
IT-G400-WC21M ○○○○○Standard
IT-G400-WC21L ○○○○○Large
1.1.2 List of options
Product name Model number
Standard battery HA-R20BAT
Large battery HA-R21LBAT
USB Cradle HA-R60IO
Four-bay Battery Charger HA-R34CHG
Four-cradle Battery Charger HA-R38CHG
Battery Cover（for Standard battery）HA-R22BC
Battery Cover（for Large battery）HA-R24LBC
AC adaptor（5V/2A）AD-S10050B
AC adaptor（5V/2A）
For Austrilia（AS）Plug
AC-PLUG-AU2A
AC adaptor（5V/4A）
For Austrilia（AS）Plug
AC-PLUG-AU4A
AC adaptor（12V/5A）
For Japanese（JP）Plug, AC Code
AC-CORD3
AC adaptor（12V/5A）
For Europe（CB）Plug, AC Code
AC-CORD3-EU
AC adaptor（12V/5A）
For United Kingdom（UK）Plug, AC
Code
AC-CORD3-UK
AC adaptor（12V/5A）
For Austrilia（AS）Plug, AC Code
AC-CORD3-AU
Screen protector HA-R95PS10
USB cable HA-R81USBC

2
1.2 Interfaces
IT-G400
Wireless LAN
GSM/W CDMA/LTE
Bluetooth
NFC
Power Supply/Data
Communication
Terminal
microSD card slot
SIM card slot
Wi-Fi
Products
Access Point
Telephone
Network
Bluetooth
Products
Headset Pocket Printer
PDA PC
ISO14443
Type A,B
Felica
ISO15693
USB cradle
(microUSB port、
Serial port、
AC adaptor、
Battery Charger)
microSD card
SIM card
Battery pack
(standard/Large)
Four-bay Battery
Charger
AC adaptor(12V/5A)
AC adaptor(5V/4A)
USB client
ＰＣ
PC
GPS
GPS
Satellites
RS232C devices
USB cable
AC adaptor(5V/2A)
Battery pack
(standard/Large
Four-cradle
Battery Charger
AC adaptor(12V/5A)
Battery pack
(standard/Large)
USB products
USB host
AC cord
Battery pack
(standard/Large
Battery pack
(standard/Large
Battery pack
(standard/Large
AC cord
AC adaptor(5V/2A)
AC adaptor jack
Battery Pack Power
Contacts
earphone jack
earphone microphone
SAM card slot SAMcard ※Th ere is a SAM s l o t, but i t can no t be us e d.
※There is a serial port, but
it c an n o t be u se d.

3
1.3 Appearance
1.3.1 IT-G400

4
No. Name Description
1 Receiver Receiver for voice call
2 Charging Status LED Show charging status
3 Notification LED Show notifications
4 Illuminance/Proximity Sensor Measure brightness and proximity of object
5 Front Camera Take picture and movie
6 Screen (Touch Panel) Display words and operation instructions
Input data in IT-G400 by finger or Stylus (Pen)
7 Recent Apps Key Switch applications
8 Home Key Go home screen
9 Back Key Back to previous screen
Close dialog box, option menu and notification panel
10 Function Key Launch program buttun app
Able to set an optional function
11 Microphone Microphone
12 Barcode Reader Laser or LED light of 2D imager radiates to read barcode
13 Volume Up Key Volume up
14 Volume Down Key Volume down
15 L Trigger Key Scan barcode
Able to set an optional function
16 Headset Jack Connect the headset
17 Power Key Power down/power on IT-G400
18 R Trigger Key Scan barcode
Able to set an optional function
19 Camera Take picture and movie
20 LED Light Torch around and camera flach
21 Microphone Microphone
22 Speaker Output sound like alarm
23 Strap Holes Attach strap
24 Battery Cover Cover battery pack
25 NFC Reader Reading NFC card
26 Battery Cover Lock Switch Open battery cover by sliding
27 Standard SIM Card Slot Insert SIM card after remving batery pack
28 microSD Card Slot Insert microSD card card after remving batery pack
29 SAM Card Slot There is a SAM slot, but it can not be used
30 Reset Switch Cold reset
31 AC Adapter Jack Connect the dedicated AC adaptor
32 Power Supply/Data
Communication Terminal
Used for data communication and power supply from USB Cradle or Four-cradle
Battery Charger.

5
1.3.2 USB Cradle
No. Name Description
1 USB Client Port Transfer data to PC using USB cable
2 Serial Port There is a serial port, but it can not be used
3 AC Adapter Jack Connect AC adaptor
4 Power Supply/Data
Communication Termina Data communication and power supply to IT-G400
5 Battery Pack Power Contacts Power supply to battery pack
6 Charging Status LED
Indicates the battery charging state
Red: Charging
Green: Charged
Blink: Charge safe time out or temperature failure
1.3.3 Four-bay Battery Charger
No. Name Description
1 Battery Pack Power Contacts Power supply to battery pack
2 Charging Status LED
Indicates the battery charging state
Red: Charging
Green: Charged
Blink: Charge safe time out or temperature failure
3 AC Adapter Jack Connect AC adaptor

6
1.3.4 Four-cradle Battery Charger
No. Name Description
1 Terminal Contacts Power supply to IT-G400
2 AC Adapter Jack Connect AC adaptor

7
1.4 Hardware specification
1.4.1 IT-G400
Item Specification Memo
CPU ARM Cortex-A53 microprocessor
(Quad core 1.2 GHz)
OS Android 6.0.1
RAM 2GB
Memory
ROM 16GB
Sensor CMOS、832 x 640、monochrome
Aimer laser (λ = 650nm), ＜ 1 mW、Class 2 Laser
Scan Angle 0 °
Minimum Resolution
1D: 0.127mm
2D Stacked: 0.168mm
2D Matrix: 0.191mm
PCS ≧ 0.45
Depth of Field
1D: 50mm ～ 400mm
2D Stacked: 50mm ～ 230mm
2D Matrix: 70mm ～ 300mm
Field of View Max 43mm（Depth of Field 50mm）
Max 277mm（Depth of Field 400mm）
Focal Distance 5.0 inches
Ambient Light Sunlight, ≦ 50,000Lux
Readable Symbologies
(1D)
UPC-A, UPC-E, EAN8(JAN8), EAN13(JAN13),
Codabar(NW7), Code39, Interleaved2of5(ITF), MSI,
ISBT, Code93, Code128(GS1-128(EAN128)), GS1
DataBarOmnidirectional(RSS-14), GS1
DataBarLimited (RSS Limited), GS1 DataBar
Expanded (RSS Expanded), GS1 DataBar Truncated
(RSS-14 Truncated), Code 32
Readable Symbologies
(2D Stacked)
PDF417, Micro PDF, Composite, Codablock F, GS1
DataBar Stacked Omnidirectional (RSS-14 Stacked
Omnidirectional), GS1 DataBar Expanded Stacked
(RSS Expanted Stacked), GS1 DataBar Stacked
(RSS-14 Stacked)
2D imager
Readable Symbologies
(2D Matrix)
Aztec, DataMatrix, Maxicode, QR Code, Micro QR,
Han Xin Code
Vibrator notification of scanner
Display device TFT
Display size 5.0 inches
Number of dots 720 (horizontal) x 1280 (vertical) HD
Gradation 1677M Colors
Display
View angle 75°(up and down, left and right)
Touch Panel Capacitive Touch Panel, Multi-touch (10 points)
Stylus (Pen) cannot be used
with external power supply to
prevent input error
