IT-G400 Series
Android 6.0
Software Manual
This manual describes the IT-G400 software
and specifications of the installed
application.
Cautions!
"Phone", "SIM", "GPS" described in this
document applies only to models with
telephone functions.
Ver 1.01

No part of this document may be produced or transmitted in any form or by any means, electronic or mechanical,
for any purpose, without the express written permission of CASIO Computer Co., Ltd. in Tokyo Japan.
Information in this document is subject to change without advance notice.
CASIO Computer Co., Ltd. makes no representations or warranties with respect to the contents or use of this
manual and specifically disclaims any express or implied warranties of merchantability or fitness for any
particular purpose.
© 2017 CASIO Computer Co.,Ltd.
The Bluetooth word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such
marks by CASIO COMPUTER CO.,LTD. is under license. Other trademarks and trade names are those of their
respective owners.
Wi-Fi is a registered trademark of Wi-Fi Alliance.
Android, Android Wear, Google, Google Play, Google Now and other marks are trademarks of Google Inc.
Other company, product and service names used in this manual also may be trademarks or registered trademarks
of others.

1
- Table of contents -
1. Introduction··············································································································································· 4
2. Basic Functions········································································································································ 5
2.1 Android 6.0·········································································································································· 5
2.2 Languages ··········································································································································· 6
2.2.1 List of supported languages ···································································································· 6
2.3 Home screen ······································································································································ 7
2.3.1 Status bar and icons ················································································································· 8
2.3.2 Notification panel and Quick setting panel·········································································· 9
2.4 Media format ··································································································································· 10
2.5 Power management························································································································ 12
2.5.1 Power status ···························································································································· 12
2.5.2 Power on and suspend···········································································································12
2.5.3 Turn off / Shutdown··············································································································· 12
2.5.4 Hot swap···································································································································· 13
2.5.5 Remaining battery level and Operation restriction························································· 14
2.6 Memory management····················································································································· 15
2.6.1 eMMC partition ························································································································ 15
2.6.2 External storage ······················································································································ 15
2.6.3 Drive specification ·················································································································· 16
2.7 Display ·············································································································································· 17
2.8 Key····················································································································································· 18
2.9 Touch panel ····································································································································· 19
2.10 LED ···················································································································································· 20
2.11 GPS ··················································································································································· 21
2.12 Sensors············································································································································· 22
2.13 Bluetooth·········································································································································· 23
2.14 WLAN················································································································································· 25
2.15 Speaker············································································································································· 26
2.16 Mic ····················································································································································· 27
2.17 Clock ················································································································································· 28
2.17.1 Overview···································································································································· 28
2.17.2 Time synchronization ············································································································· 28
2.18 Vibrator············································································································································· 30
2.19 NFC···················································································································································· 31
2.19.1 List of useable card················································································································ 31
2.20 Barcode scanner ···························································································································· 33
2.20.1 Barcode reading specification······························································································ 33
2.20.2 Reading type····························································································································· 35

2
2.20.3 Reading condition···················································································································· 35
2.20.4 Read result notification ········································································································· 35
2.20.5 Expanded functions················································································································· 36
2.20.6 Image capturing························································································································ 38
2.20.7 Common Functions ················································································································· 39
3. Standard applications ·························································································································· 40
3.1 List of applications ························································································································ 40
3.2 Camera·············································································································································· 41
3.3 Clock ················································································································································· 42
3.4 Calculator········································································································································· 43
3.5 Calendar ··········································································································································· 44
3.6 Drive·················································································································································· 45
3.7 Phone ················································································································································ 46
3.8 Chrome ············································································································································· 47
3.9 Downloads········································································································································ 48
3.10 GMail ················································································································································· 49
3.11 Maps ·················································································································································· 50
3.12 Contacts··········································································································································· 51
3.13 YouTube ··········································································································································· 52
3.14 Messenger········································································································································ 53
3.15 Notes················································································································································· 54
3.16 Play Store ········································································································································ 55
4. Settings ··················································································································································· 56
4.1 List of softwares ···························································································································· 56
4.2 Wireless & networks······················································································································ 57
4.2.1 WLAN·········································································································································· 58
4.2.2 Data usage ( Enable/Disable of Cellular data ) ······························································· 63
4.2.3 More > Cellular networks ······································································································ 63
4.3 Device ··············································································································································· 65
4.4 Personal············································································································································ 66
4.5 System·············································································································································· 67
5. Additional Application·························································································································· 68
5.1 List of applications ························································································································ 68
6. Operation support tools······················································································································ 69
6.1 List of softwares ···························································································································· 69
6.1.1 Program Buttons ····················································································································· 70
6.1.2 ScanSetting ······························································································································ 73
6.1.3 Power Launcher······················································································································· 77
6.1.4 CPU Settings···························································································································· 79
6.1.5 Backup & restore ···················································································································· 80
6.1.6 System Information················································································································· 83

3
6.1.7 Take bug report ······················································································································· 84
7. Demos······················································································································································ 85
7.1 PrintDemo ········································································································································ 86
7.2 GPS Demo········································································································································ 87
7.3 ImageDemo······································································································································· 88
7.4 PingDemo ········································································································································· 89
7.5 ScanDemo ········································································································································ 90
8. Connection with PC ····························································································································· 91
9. Reset switch ·········································································································································· 92
10. Backup & reset······································································································································ 93
11. Maintenance function··························································································································· 94
11.1 OS Update ······································································································································· 94
11.1.1 System updates ······················································································································· 94
11.2 OS Updating from Application····································································································· 97
11.2.1 Overview···································································································································· 97
11.2.2 OS Updating service for application··················································································· 98
11.2.3 How it works····························································································································· 98
11.2.4 Specification····························································································································· 99
11.2.5 About sample program ········································································································· 101

4
1. Introduction
In the factory default state, the language selection screen is displayed in English.
②
①
③
②
①
③
When ①is pressed, a list of selectable languages is displayed, so select the language to use. This
ensures that the initial settings after that will be displayed in the language selected.
Cautions!
Emergency call button in the above figure is displayed only with the model with the phone
function.
"Phone", "SIM", "GPS" and "Mobile Network" described on this document apply only to
models with telephone functions.

5
2. Basic Functions
2.1 Android 6.0
IT-G400 is equipped with Android 6.0.1.
Software Archtecture
The software architecture of the IT-G400 is shown below. IT-G400 consists of barcode scanners,
keys, and tools (extended block) that effectively utilize these functions, in addition to the same
function as Android installed on smartphones (Android standard part). Applications that use the
Android standard block can be developed with Android Studio (Android SDK), but in order to use
the extended block it is necessary to use "IT-G400 Basic Development Kit".
PC
Android Standard Block Extended Block
IT-G400
OS Block
Android Studio （from Google）IT-G400 Basic
Development Kit

6
2.2 Languages
2.2.1 List of supported languages

7
2.3 Home screen
When you turn on the Android phone, the lock screen will be displayed. Sliding this lock screen
will bring up the home screen for selecting and starting the application. You can also move to the
Home screen by pressing [Home] key.
The program responsible for processing the home screen is called as “home application”, or simply
the “launcher”.
①
②
③
④
⑤
⑧
⑦
⑥
① Search panel
② Shortcut
③ Favorite tray
④ Apps list
⑤ Play store
⑥ Widgets list
⑦ Apps list
⑧ Apps/Widgets select

8
2.3.1 Status bar and icons
A bar with icons at the top of the screen is called a status bar. The status bar displays various
"Status icons" indicating the status of the system and "Notification icon" for notifying the operator.
②①②①
①Status icons
②Notification icons
The following is a part of the icon displayed on IT-G400.
Icons related to the phone function displays only on the WAN models.
Status icons
GPRS connected Battery is low
EDGE connected Battery is very low
3G connected GPS is on
LTE connected Alarm is set
No signal Bluetooth is on
Signal strength
Connected to a bluetooth device
Roaming
Speakerphone is on
WLAN connected
Headset connected
Airplane mode
No SIM card inserted
Battery is charging Vibrate mode / Mute
Battery is full Microphone is mute
Battery is partially drained
Barcode scanner is enable
Notification icons
NewGmail™ message
Missed call
New Email message Connected to VPN
New text or multimedia message More notifications are hidden
Problem with SMS or MMS
delivery
microSD is mounted
New Google Hangouts™ message

9
2.3.2 Notification panel and Quick setting panel
Drag the status bar downward to open the notification panel. Drag further downward in this state to
open the quick setting.
Notification panel
Notification Panel uses to read details of the notification. Touch the status bar and drag it
downward to open it.
Quick setting panel
Quick setting panel provides easy access to settings. Touch the notification panel and drag
downward to open the quick setting panel. By touching the icon displayed on the quick setting
panel, you can enable / disable the function and change the mode.

10
2.4 Media format
IT-G400 carries all encoders and decoders supported by Android.
Audio
Supported audio encoders and decoders are as follows.
Format Encoder Decoder
AAC ○○
MP3
○
MIDI
○
WAVE
○
Libraries related to this function are as follows.
Andorid Standard library ※
Android.media This class provides various interfaces related to audio and
video.
Android.media.MediaPlayer This class plays audio / video / still images.
For details of the Android standard library, refer Android official website such as "Android
Developers".
Encoders and decoders of supported images are as follows.
Format Encoder Decoder
JPEG ○○
GIF
○
PNF ○○
BMP
○
WEBP ○○
Libraries related to this function are as follows.
Andorid standard library ※
Android.media This class provides various interfaces related to audio
and video.
Android.media.MediaPlayer
This class plays audio / video / still images.
For details of the Android standard library, refer Android official website such as "Android
Developers".

11
Video
Encoders and decoders of supported videos are as follows.
Format Encoder Decoder
H263 ○○
H264 ○○
MPEG4
○
Libraries related to this function are as follows.
Andorid standard library ※
Android.media This class provides various interfaces related to audio and
video.
Android.media.MediaPlayer This class plays audio / video / still images.
Android.widget.VideoView This class plays video.
For details of the Android standard library, refer Android official website such as "Android
Developers".

12
2.5 Power management
2.5.1 Power status
IT-G400 has following power states.
No State Display RAM CPU Description
1 ON ON ON ON Terminal is in operation
2 Early suspend OFF ON ON Only the screen is OFF.
3 Suspend ※1 OFF ON OFF Nearly all devices except RAM are in OFF
state. OS and applications remain in RAM, but
application programs are stopped except some.
4 Hot Swap ※2 OFF ON OFF Ultra low power consumption mode prepared
for replacing the battery pack.
5 OFF / Shutdown OFF OFF OFF All devices are in the OFF state.
※1 Depending on the application on Android it is sometimes written as "sleep".
※2 For the detail, refar “ 2.5.4 Hot swap (p. 13)”.
The change of state from 5 to 1 is called "BOOT", and the state change from 3, 4, 2 to 1 is called
"RESUME".
2.5.2 Power on and suspend
When the device is in the OFF state, to turn on it, power key must be pressed for several seconds.
This is the specification to prevent unintentional turning on of power.
When the device is in Suspend or Early Suspend state, pressing power key resumes the device
immediately.
2.5.3 Turn off / Shutdown
Press and hold the power key for 1 second, then power menu pops up. If you select "Power off"
from the menu, it goes into OFF (Shutdown) state. Also this operation is called as "Shutdown".

13
2.5.4 Hot swap
Many smartphones in recent years can not exchange batteries to realize small size and light weight.
On the other hand, IT-G400 is compatible with battery replacement in preparation for lower battery
during work. Furthermore, in the case of a normal smartphone, rebooting occurs only by removing
and inserting the battery, but IT-G400 implements Hot swap function to reduce the time required
for rebooting.
Press and hold the power key for 1 second, then power menu pops up.
When "Hot Swap" is selected from the menu, the LED will light red and the transition to the hot
swap state will begin. When the transition is completed, the red LED goes out.
In the hot swapped state, the power key is disabled. This is to avoid accidentally resuming the
operation during battery exchange.
The Hot Swap state continues until finishing the battery replacement.
Cautions!
It is not guaranteed that hot swap will always succeed. For example, if the transition to the hot
swap state is blocked for 90 seconds due to the occupation of system resources by the
application, migration to hot swap may fail. In that case, system will forcibly restart the device,
giving priority to stabilizing the system.
Cautions!
Do not remove the SIM card in the Hot Swap state. In case the SIM card needs to be removed,
shutdown the device first.
Do not remove the microSD card in the Hot Swap state. In case the microSD card needs to be
removed, shutdown the device first.

14
2.5.5 Remaining battery level and Operation restriction
The table below summarizes the relationship between remaining battery level, notification,
and operation restriction. For example, if the remaining battery level is 20% or less, the
LED will light red and a warning of low battery will be issued. At this time, "the battery
leve is lowl" notification is also issued. When the battery level drops below 10%, the LED
will change to blinking red. Also, a notification of "The battery is very low" is issued and
LED lights and cameras are disabled.
Remaining
battery level
Status Notification
(LED)
Notification
(Notification)
Operation
restriction
100% Full charge Lit green none none
99%
～21% Regular use OFF none none
20%
～11%
Battery low
warning
(Low)
Lit red none
10% ～
Very low
warning
(Critical)
Blinking
red
LED flashlight
and Camera
Flash are
restricted to
use
11%
～100%
Charging
(Critical 以上) Lit red none none
～10% Charging
(Critical)
Blinking
red none
LED flashlight
and Camera
Flash are
restricted to
use
The table below summarizes the relationship between remaining battery level and battery
icon.
Remaining battery
level
icon
100% ～16%
15% ～11%
10% ～
Unknown
Charginig
(32% ～100%)
Charging
(～31%)

15
2.6 Memory management
2.6.1 eMMC partition
IT-G400 has a 16GB eMMC (Embedded MultiMediaCard).
The inside of the eMMC is divided into a boot area to be used at booting, a system area used by the
OS, and a user area to be used as Internal Storage.
Figure 2-1
boot area : Approx.100MB
System area : Approx.6GB
User area : Approx. 9GB
2.6.2 External storage
A microSD card slot is equiped to use external memory.
When inserting microSD card, insert it with the contact terminal face down.
Also, when removing, follow the procedure below.
(1) Unmount by [Unmount SD card] from [Settings] →[Storage]
(2) Change to hot swap state (refer to " 2.5.4 Hot swap (p. 13)")
(3) Remove battery and remove the microSD card
(4) Install the battery

16
2.6.3 Drive specification
mount point Storage
/storage/emulated/0 Internal storage
/storage/sdcard1 microSD card ※1
※1 It supports microSD and microSDHC. Transfer speed is up to CLASS 10.

17
2.7 Display
Hardware specification
type TFT
LCD Size 5.0 inch
number of dots W 720 x H 1280 (HD)
Dot pitch W 0.08625 mm x H 0.08625 mm
Color 16 M Colors
Backlight LED backlight
How to detect the resolution
To obtain the screen resolution from the application program, use DisplayMetrics.
DisplayMetrics metrics = new DisplayMetrics();
getWindowManager().getDefaultDisplay().getMetrics(metrics);
For details of the Android DisplayMetrics, refer Android official website such as "Android
Developers".

18
2.8 Key
Key assignment
The assignment of function buttons is as follows.
KEY Function Android Key Event
Switching Applications
Touch to switch to the recent used applications.
This key is also called as “Recent Apps key”.
KEYCODE_APP_SWITCH
Home key
From any application or screen, touch to return to the
Home screen.
Touch and hold to open "Now on Tap".
KEYCODE_HOME
Back Key
Touch to go back to the previous screen, or to close a
dialog box, options menu, the notification panel, etc.
KEYCODE_BACK
Function key
Touch to slect the function you want to set as the
shotcut of program buttons.
KEYCODE_FUNCTION
Power key
Press: Lock the screen/Light up the screen.
Press and hold: Show the pop-up menu to select from
Power off/Reboot/Airplane mode/Hot Swap.
Press the Power key and Volume down key for more
than 12s to reset.
Press the Power key and Volume down key to capture
a screenshot.
KEYCODE_POWER
Volume Up key / Volume Down key
In call mode, adjusts the headset volume.
In Music/Video/Streaming mode, adjusts the media
volume.
In general mode, adjusts the ringtone volume.
Mutes the ringtone of an incoming call.
In camera preview mode, press Volume up or down
key to enter burst shoot.
KEYCODE_VOLUME_UP
KEYCODE_VOLUME_DOWN
Left Triger key
Right Trigger key
For details of the Android standard library, refer Android official website such as "Android
Developers".
