CBC H1 User manual


Page1


CBCAmericaCorp.  www.computarganz.com
55MallDrive  Tele:800‐422‐6707
Commack,NY11725



InstructionManualH1andH2SecurityCameraHousing


Thesehousingaredesignedwitheaseofinstallationandexcellentenvironmentalperformance
inmind.Withcableentryoptionsthroughtherearcapandthemountingfoot,thesefeatures
willallowforavarietyofinstallationoptions.Theaccompanyingmountpermitscable
concealmentwhenthecablesareroutedthroughthemount.
Theall‐aluminumconstructioniscoatedwithalightcoloredUVprotectedpowerpaintfor
minimumheatabsorptionandenvironmentalsealedwithallUVprotectedsiliconegaskets.The
3mmglassviewingwindowprovidesforHDopticalclaritythatwillnotfadoryellowovertime.
Sizedtofitavaryingrangeofcamerasandlenses,thesehousingprovideaperfectcomplement
tomostcompletesecurityandsurveillancesystemsolutions.Contactyoursecuritydealeror
customerservicerepresentativetomatchthebestequipmentanddevicesforyourapplication.



Page2


IMPORTANTSAFEGUARDS
1.ReadInstructions‐Allthesafetyandoperatinginstructionsshouldbereadbeforetheunitisoperated.
2.RetainInstructions‐Thesafetyandoperatinginstructionsshouldberetainedforfuturereference.
3.HeedWarnings‐Allwarningsontheunitandintheoperatinginstructionsshouldbeadheredto.
4.FollowInstructions‐Alloperatinganduseinstructionsshouldbefollowed.
5.Cleaning–Disconnectfrompowersourcebeforecleaning.Useadampclothforcleaning.
6.Donotuseattachmentsnotrecommendedbytheproductmanufacturerastheymaycausehazards.
7.PowerSources‐Thisunitshouldbeoperatedonlyfromthetypeofpowersourceindicatedonthemarking
label.Ifyouarenotsureofthetypeofpowersupplyyouplantouse,consultyourappliancedealerorlocalpower
company.Forunitsintendedtooperatefrombatterypower,orothersources,refertotheoperatinginstructions.
8.GroundingorPolarization‐Thisunitmaybeequippedwithapolarizedcurrentlineplug.Thisplugwillfitinto
thepoweroutletonlyoneway.Thisisasafetyfeature.Ifyouareunabletoinserttheplugfullyintotheoutlet,try
reversingtheplug.Iftheplugshouldstillfailtofit,contactyourelectriciantoreplaceobsoleteoutlet.Alternately,
thisunitmaybeequippedwitha3‐wiregrounding‐typeplug,aplughavingathird(grounding)pin.Thisplugwill
onlyfitintoagrounding‐typepoweroutlet.Thisisasafetyfeature.Ifyouareunabletoinserttheplugintothe
outlet,contactyourelectriciantoreplaceyourobsoleteoutlet.Donottrytodefeatthesesafetyfeatures.
9.Power‐CordProtection‐Power‐supplycordsshouldberoutedsothattheyarenotlikelytobewalkedonor
pinchedbyitemsplaceduponoragainstthem,payingparticularattentiontocordsandplugs,convenience
receptacles,andthepointwheretheyexitfromtheappliance.
10.PowerLines‐Anoutdoorsystemshouldnotbelocatedinthevicinityofoverheadpowerlinesorotherelectric
lightorpowercircuits,orwhereitcanfallintosuchpowerlinesorcircuits.Wheninstallinganoutdoorsystem,
extremecareshouldbetakentokeepfromtouchingsuchpowerlinesorcircuitsascontactwiththemmightbe
fatal.U.S.A.modelsonly‐refertotheNationalElectricalCodeArticle820regardinginstallationofCATVsystems.
13.Overloading‐Donotoverloadoutletsandextensioncordsasthiscanresultinariskoffireorelectricshock.
12.ObjectandLiquidEntry‐Neverpushobjectsofanykindintothisunitthroughopeningsastheymaytouch
dangerousvoltagepointsthatcouldresultinafireorelectricshock.Neverspillliquidofanykindontheunit.
13.Servicing‐Donotattempttoservicethisunityourselfasopeningorremovingcoversmayexposeyouto
dangerousvoltageorotherhazards.Referallservicingtoqualifiedservicepersonnel.
14.ReplacementParts‐Whenreplacementpartsarerequired,besuretheservicetechnicianhasusedreplacement
partsspecifiedbythemanufacturerorhavethesamecharacteristicsastheoriginalpart.Unauthorized
substitutionsmayresultinfire,electricshockorotherhazards.
15.CoaxGrounding‐Ifanoutsidecablesystemisconnectedtotheunit,besurethecablesystemisgrounded.
U.S.A.modelsonly‐‐Section810oftheNationalElectricalCode,ANSI/NFPANo.70‐1981,providesinformationwith
respecttopropergroundingofsupportingstructure,groundingofthecoaxtoadischargeunit,sizeofgrounding
conductors,locationofdischargeunit,connectiontoground,andrequirementsforthegroundingelectrode.

FCCINFORMATION
WARNING‐ThisequipmentcomplieswiththelimitsforaClassBdigitaldevice,pursuanttoPart15oftheFCC
Rules.Limitsaredesignedtoprovidereasonableprotectionagainstharmfulinterferencewhentheequipmentis
operatedinaresidentialinstallation.Thisequipmentgeneratesandcanradiateradiofrequencyenergy,ifnot
installedandusedinaccordancewiththeinstructions,maycauseharmfulinterferencetoradiocommunications.
However,thereisnoguaranteethatinterferencewillnotoccurinaparticularinstallation.Ifthisequipmentdoes
causeharmfulinterferencetoradioortelevisionreception,whichcanbedeterminedbyturningtheequipmentoff
andon,theuserisencouragedtotrytocorrecttheinterferencebyoneormoreofthefollowingmeasures:
‐Reorientorrelocatethereceivingantennaorincreasetheseparationbetweentheequipmentandreceiver.
‐Connecttheequipmentintoanoutletonacircuitdifferentfromthattowhichthereceiverisconnected.
‐Consultthedealeroranexperiencedradio/TVtechnicianforhelp.
Intentionalorunintentionalchangesormodificationsnotexpresslyapprovedbythepartyresponsiblefor
complianceshallnotbemade.Anysuchchangesormodificationscouldvoidtheuser'sauthoritytooperatethe
equipment.TheusermayfindthefollowingbookletpreparedbytheFederalCommunicationsCommissionhelpful:
"HowtoIdentifyandResolveRadio‐TVInterferenceProblems",availablefromU.S.GovernmentPrintingOffice,
Washington,DC20402,StockNo.004‐000‐00345‐4.


Page3


1.UNPACKING
Unpackcarefully.Thisequipmentshouldbehandledwithcare.
Checkforthefollowingitems:
•Verifytheunitmodelnumber.
•Verifythatpartslistedbelowhavebeenincluded.
Ifanitemappearstohavebeendamagedinshipment,replaceitproperlyinitscartonandnotifytheshipper.If
anyitemsaremissing,notifyyourdealerormanufacture’sSalesRepresentativeorCustomerService.Theshipping
cartonisthesafestcontainerinwhichtheunitmaybetransported.Saveitforpossiblefutureuse.
HardwareKit
2x¼‐20x3/8”HexCrossRecessedHeadScrews
1x¼”FlatWasher
1x¼”LockWasher

2.INSTALLATION
Toolsrequired:
#2CrossRecessedScrewdriver(Phillips)
1/8”WidthFlatBladeScrewdriver
3/4”OpenEndWrench
GeneralPurposeWireStripperwithCutter
Optional:AdjustableWrench
Materialsrequired:
OutdoorRatedCablesforPowerandVideo
Cablesmustberoundinshapewithanouterjacketdiameterof0.170”minimumto0.310”maximum.

1. Choosedesiredlocationforcamerahousinginstallation.Verifymountingstructureandsurfaceiscapableof
supportingthecameraandnoobstacleorinterferenceispresentfromexistinginstalleddevicesorwiring.
2. Openhousingbyloosenthe2Phillipsheadscrewslocatedonthe
rearcap.Donotremovethelowertwoscrewsontherearcap.
3. Holdingthehousingbasesecurely,graspfrontcapandcover,
pullforwardslidingthecoveroffthebase.










4. Removecameramountingbracketbyloosentworetainingscrews.Slideandliftbracket.
5. Attachcameraandlenstobracketusing¼‐20screw.Thepositionofthecameracanbeadjustedbyflipping
thebracket.Thelensmustnotextendmorethan¾”(0.750”)beyondthefrontedgeofthebracket.
6. Choosecableentrypathforpowerandvideo.Using¾”wrench,installcableglandfittingseitherintherear
capormountingfootdependingontheentrypointchosen.Installplugsintheholesnotusedforcableentry.
Loosen
These
Screws
DoNot
Remove
GraspHereSlide


Page4


7. Attachpowertoconnectorterminalblock.Blockmounting
platecanberemovedforeaseofinstallationbyloosening
twoscrewstoslideandlifttheplate.Powermustbe
connectedtoterminals2and3.Groundcanbeconnectedto
terminal4oroptionalinstallationbycrimpinggroundtoring
terminalonthegroundingstud.Attachterminalblockplate
tohousingbaseandtightenscrews.
8. Positioncameraintohousingandattachbackandwhite
wirestocamerapowerterminalasrecommendedbythecameramanufacture.
9. Attachvideocabletocameraorotherdeviceasspecifiedbythecameraordevicemanufacture.
10. Positioncablestorelieveexcessstressandtightenthecableglandfittingsusing¾”wrench.
11. Slidecoverintoplace,tightentwoPhillipsheadscrewstosecure.
12. Attachhousingtomountingbracketandsetposition.

3.SERVICE
Iftheuniteverneedsrepairorservice,pleasecontactthedealerormanufacture’ssalesrepresentative.

4.CAREANDMAINTENANCE
Iftheunitneedscleaning,useasoftdampclothtowipetheexternalcoverandviewingwindow.

5.ACCESSORIES
Recommended:
WB1–WallMountingBracketwithfeedthroughAdjustableHeadfeature
SS1–Sunshieldtopromotecoolingbyprotectingthehousingfromdirectsunlight

6.SPECIFICATIONS

Seefollowingdrawingsforadditionaldimensionalinformation.
Construction UVProtectedPowderCoatedAluminumBody,FrontandRearCaps;
UVProtectedSiliconeSeals;GlassWindowforHDOpticalClarity
Color CoolGray(Pantone1C)
Power 12Vto24V;w/heater10Watts;420mA@24Vac
OperatingTemerature w/heaterandsunshield‐40~55C
StorageTemerature ‐65Cto65C
Weight‐Product 2.6‐lbsw/outcameraandlens
Weight‐Shipping 3.0‐lbs
Size 4.4"Hx4.35"Wx11.6"L
MECHANICAL
