CBi electric QAT-TRDM Installation guide

low voltage
3990A640 REV B
NOV 2014
QAT Guide
Page 1
Auxiliary Products
The programmable time switch can be used to automatically control
pool pumps, lights, geysers, etc.
QAT-TRDM – ELECTRONIC TIME SWITCH
Installation and Programming Guide
General
1. During a power failure, the symbol is displayed and the time
switch enters standby.
2. The time switch has a backup power feature which requires
30 minutes to charge.
Important Notes
1. Isolate supply power before installing time switch.
2. Install the time switch on either mini rail or DIN rail (remove the escutcheon clip for DIN).
3. Connect the time switch according to Figure 1 or Figure 2.
Use a suitable contactor (Figure 3) if necessary to switch higher current.
Observe markings for Line and Neutral poles.
4. Apply power and set the time and desired program schedule (see overleaf).
Installation
Technical Data
Parameter Specication
Supply Voltage 230 VRMS 50 Hz, 1Ph
Maximum Load Resistive (Geysers, under oor heating, lights) 21 A
Inductive (Pool pump, air conditioners) 10 A
Contact Endurance 25 000 (minimum) Operations
Degree of Ingress Protection IP41(not waterproofed)
Operating Temperature -20 °C to +55 °C
Single Segment Period 15 min.
Maximum Period for all Segments 96 x 15 min. Segments
Clock Accuracy ± 3 min. per month
Time Retention (Power Outage) 24 h
Figure 1: DB wiring Figure 2: Stand alone wiring Figure 3:Wiring a contactor for loads
greater than 21 A resistive or 10 A inductive
L N
Load
L N
L
L N
Time
Switch
Neutral
Bar
Load
L N
L
L N
Time
Switch
L N
L N
L
Time
Switch
Coil
Load
L1 L2 L3
T1 T2 T3
Contactor
Supply
L N
3. In the event of a power failure, a fully charged time switch will keep time for up to 24 hours.
The programmed schedule is always retained.
4. CBIadvisesthatthetimeswitchbeinstalledbyasuitablyqualiedperson.

A member of the Group
SOUTH AFRICA
CBI-electric: low voltage
Tripswitch Drive Elandsfontein
Gauteng South Africa
Tel: [phone]
Fax: + 27 11 392 2354
Email: [email protected]
Website: www.cbi-lowvoltage.co.za
3990A640 REV B
NOV 2014
QAT Guide
Page 2
Please review our CustomerTerms and Conditions on www.cbi-lowvoltage.co.za
All rights reserved. Unless otherwise indicated, all materials on these pages are copyrighted by CBI (Pty) Ltd. No part of these pages, either text or image
maybeusedforanypurposeotherthanpersonaluse.Therefore,reproduction,modication,storageinaretrievalsystemorretransmission,inanyform
or by any means,electronic, mechanical or otherwise, for reasons other than personal use, is strictly prohibited without prior written permission. CBI (Pty)
Ltd reserves the right to alter any details of this document without notice and while every effort is made to ensure the accuracy of the content, no warranty
is given as to accuracy of this document and no responsibility will be accepted for error or misinterpretation and any resulting loss.
NEW TOUCH BUTTONS Usetheeshofyourindexngeronthescreen
Programming Instructions
EXAMPLE: Geyser on in the morning
Start time: 05:30
End time: 07:00
OFF 00:00 05:30 (segments off)
ON 05:30 07:00 (segments on)
The home screen displays the current time and the switch on/off status according to the program schedule.
A. Home Screen
1. From the Home screen, press and hold FUNCTION until is displayed.
2. Press the HOUR and MINUTE buttons to set the clock to the current time.
3. Press FUNCTION to store the time.
B. Setting the Clock
24 OUTER SEGMENTS
REPRESENTS HOURS
4 INNER SEGMENTS
15 MINUTES EACH
To override the normal program e.g. to keep the geyser off over a weekend away:
1. From the home screen, long press BYPASS until is displayed.
2. Then select ON or OFF as desired with a long press ON/OFF.
To return to normal time switch operation:
1. Long press BYPASS again to return to home screen.
D. Manually Bypass the Program Schedule
Decide when your load should be on e.g. a geyser on from 05:30 to 07:00.
1. From the Home screen, press FUNCTION until is displayed.
The cursor starts at 00:00.
A program schedule is built up by turning segments on when the load must be on. Before reading
further, see the clock diagram of segments on the right.
2. Set all time segments prior to your scheduled start to off*, by repeatedly pressing (or holding)
OFF until the clock indicates the start time e.g. 05:30.
3. Set all time segments during the schedule to on, by repeated pressing (or holding) ON until the
clock indicates the end time e.g. 07:00.
As you advance the cursor, it will leave a trail of turned-on segments, representing the program.
You may repeat steps 2 and 3 for additional schedules e.g. geyser also on from 18:15 to 21:00.
4. Press FUNCTION to store the new program and return to home screen.
Notes:
If any 15 minute segment within a particular hour is set, that hour segment will be lit.
The schedule will be repeated daily.
* Use the HOUR button to step the cursor one hour at a time, without altering the program.
This is handy to review your program.
C. Setting the Program Schedule
D. BYPASS
Override using ON/OFF
LONG PRESS:
B. SET CLOCK
Adjust clock using
HOUR/MIN:
A. HOME
Default screen. Displays
clock and ON/OFF status:
C. SET PROGRAM
Turn 15 min segments on/off
using ON/OFF:
Step C.2: load off period,
turn segments OFF:
Step C.3: load on period,
turn segments ON:
BYPASS LONG PRESS
FUNCTION
LONG PRESS
FUNCTION
START HERE
FUNCTION
LONG PRESS
