CCL ELECTRONICS C6081A User manual

WI-FI weather station with
7-In-1 professional sensor
Model: C6081A
User Manual
* POLE IS FOR ILLUSTRATION PURPOSE. IT'S NOT INCLUDED.

ABOUT THIS USER’S MANUAL
This symbol represents a warning. To ensure safe use, always
adhere to the instructions described in this documentation.
This symbol is followed by a user’s tip.
PRECAUTIONS
- Keep and reading the “User manual” is highly recommended. The manufacturer and
supplier cannot accept any responsibility for any incorrect readings, export data lost and any
consequences that occur should an inaccurate reading take place.
- This product is designed for use in the home only as indication of weather conditions. This
product is not to be used for medical purposes or for public information
- Do not subject the unit to excessive force, shock, dust, temperature or humidity.
- Do not cover the ventilation holes with any items such as newspapers, curtains etc.
- Do not immerse the unit in water. If you spill liquid over it, dry it immediately with a soft, lint-free
cloth.
- Do not clean the unit with abrasive or corrosive materials.
- Do not tamper with the unit’s internal components. This invalidates the warranty.
- Placement of this product on certain types of wood may result in damage to its nishing
for which manufacturer will not be responsible. Consult the furniture manufacturer’s care
instructions for information.
- Only use fresh batteries. Do not mix new and old batteries.
- Only use attachments / accessories specied by the manufacturer.
- Images shown in this manual may differ from the actual display.
- When disposing of this product, ensure it is collected separately for special treatment.
- Dispose of used batteries according to the instructions.
- CAUTION! risk of explosion if battery is replaced by an incorrect type.
- The socket-outlet shall be installed near the equipment and easily be accessible.
- The contents of this manual may not be reproduced without the permission of the manufacturer.
- Technical specications and user manual contents for this product are subject to change without
notice.
- When replacement parts are required, be sure the service technician uses replacement
parts specied by the manufacturer that have the same characteristics as the original parts.
Unauthorized substitutions may result in re, electric shock, or other hazards.
- This product is not a toy. Keep out of the reach of children.
- The console is intended to be used only indoors.
- Place the console at least 20cm from nearby persons.
- The console shall be used with the adaptor that included in the packaging.
- This device is only suitable for mounting at height < 2m.

TABLE OF CONTENTS
INTRODUCTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
OVERVIEW . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
CONSOLE. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
LCD DISPLAY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
WIRELESS INDOOR HYGRO-THERMO SENSOR . . . . . . . . . . . . . . . . . . . . . . . . . . 2
WIRELESS 7-IN-1 SENSOR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
INSTALLATION AND SETUP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
INSTALL WIRELESS 7-IN-1 SENSOR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
INSTALL WIRELESS INDOOR SENSOR. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
SETUP THE CONSOLE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
SYNCHRONIZING ADDITIONAL WIRELESS SENSOR(S) (OPTIONAL) . . . . . . . . . . . . . . .6
POINTING THE WIRELESS 7-IN-1 SENSOR TO SOUTH . . . . . . . . . . . . . . . . . . . . . . . 6
CREATE WEATHER SERVER ACCOUNT & SETUP WI-FI CONNECTION . . . . . . . . . . . . . . . . 7
CREATE WEATHER UNDERGROUND ACCOUNT . . . . . . . . . . . . . . . . . . . . . . . . . .7
CREATE WEATHERCLOUD ACCOUNT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
SETUP WI-FI CONNECTION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
SETUP THE WEATHER SERVER CONNECTION . . . . . . . . . . . . . . . . . . . . . . . . . . 11
ADVANCE SETTING IN WEB INTERFACE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
VIEW YOUR WEATHER DATA IN WUNDERGROUND . . . . . . . . . . . . . . . . . . . . . . . 13
VIEW YOUR WEATHER DATA IN WEATHERCLOUD . . . . . . . . . . . . . . . . . . . . . . . . 13
FIRMWARE UPDATE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
OTHER SETTING & FUNCTIONS OF THE CONSOLE . . . . . . . . . . . . . . . . . . . . . . . . . 14
MANUAL CLOCK SETTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
MOON PHASE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
SUNRISE & SUNSET TIME. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
SETTING ALARM TIME. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
ACTIVATING ALARM AND TEMPERATURE PRE-ALARM FUNCTION . . . . . . . . . . . . . . . 16
TEMPERATURE / HUMIDITY FUNCTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
TREND INDICATOR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
WIND . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
WEATHER INDEX . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
WEATHER FORECAST . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
BAROMETRIC PRESSURE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
RAIN. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
LIGHT INTENSITY, UV INDEX & SUNBURN TIME. . . . . . . . . . . . . . . . . . . . . . . . . . 21
MAX / MIN DATA RECORD. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
PAST 24 HOURS HISTORY DATA . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
WEATHER ALERT SETTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
BACKLIGHT. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
DISPLAY CONTRAST. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
MAINTENANCE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
BATTERY REPLACEMENT. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
WIRELESS 7-IN-1 SENSOR MAINTNANCE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
TROUBLESHOOT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
SPECIFICATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
CONSOLE. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
WIRELESS 7-IN-1 SENSOR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
WIRELESS THERMO-HYGRO INDOOR SENSOR . . . . . . . . . . . . . . . . . . . . . . . . . 28

1
INTRODUCTION
Thank you for selecting WI-FI weather station with 7-in-1 professional sensor. This system
gathers and automatically uploads accurate and detail weather data to Weather Underground
and Weathercloud website - the famous weather service which allows weather observers to
upload their local weather data with automated personal weather stations (PWS) - at which
you can access and upload your weather data freely. This product offers professional weather
observers or serious weather enthusiasts robust performance with a wide range of options and
sensors. You will get your own local forecast, high/lows, totals and averages for virtually all
weather variables without using a PC.
The 7-in-1 sensor which measures outdoor temperature, humidity, wind, rain UV and Light
together with up to 7 individual temperature humidty sensors, which can add to a sensor array
of maximum 7 units continually, transmits weather data to the console. Both sensors are fully
assembled and calibrated for your easy installation. They send data at a low power radio
frequency to the console from up to 150m/450 feet away (line of sight).
In the console, high-speed processors are embedded to analyze the received weather data
and these real-time data can be published to Wunderground.com and weathercloud.net through
your home Wi- router. The console can also synchronize with internet time server to show high
precision time and for its weather data time stamp. The color LCD display shows informative
weather readings with advanced features, such as high/low alert alarm, different weather index,
and MAX/MIN records. With calibration, sunrise / sunset and moon phase features, this system
is truly a remarkably personal yet professional weather station for your own backyard.
NOTE:
This instruction manual contains useful information on the proper use and care of this product.
Please read this manual through to fully understand and enjoy its features, and keep it handy
for future use.
OVERVIEW
CONSOLE
XXXXXXXXXXXX
XXXXXXXX
Model No.:XXXXX
1
23456789
1110 12 13 14 15
16 17 18 19 20 21 22 23

2
1. [ SNOOZE ] key
2. [ HISTORY ] key
3. [ MAX / MIN ] key
4. [ CHANNEL ] key
5. [ BARO ] key
6. [ WIND ] key
7. [ SUNT ] key
8. [ RAIN ] key
9. LCD display
10.[ WI-FI / SENSOR ] key
11. [ REFRESH ] key
12.Wall mounting holder
13.[ CLOCK SET ] key
14.[ V / INDEX ] key
15.[ Ʌ ] key
16.[ OFF / LO / HI ] key
17.Table stand
18.[ ALARMT ] key
19.[ ALERT ] key
20.Power jack
21.Battery compartment
22.[ °C / °F ] key
23.[ RESET ] slide switch
LCD DISPLAY
12 3
4
6
5
7
8
9
Display section:
1. Outdoor temperature & humidity
2. Wind direction & speed
3. Indoor (Ch) temperature & humidity
4. Weather index
5. UV index & light intensity (SUN)
6. Weather forecast
7. Barometer
8. Rain
9. Time & Data, moon phase, Sunrise/Sunset
time
WIRELESS INDOOR HYGRO-THERMO SENSOR
1
2
3
4
5
1. Transmission status LED
2. Wall mounting holder
3. Channel slide switch
4. [ RESET ] key
5. Battery compartment

3
WIRELESS 7-IN-1 SENSOR
4
5
6
1
2
3
7
810
11
9
12
1. Antenna
2. Radiation shield & Thermo-hygro sensor
3. Mounting parts (t for 35 ~40mm diameter
pole)
4. Battery door
5. [ RESET ] key
6. Transmission status LED
7. Bubble level gradienter
8. Rain collector
9. Wind vane
10.UV / light sensor
11. Solar panel
12. Wind cups

4
INSTALLATION AND SETUP
Your console can pair up with one wireless 7-in-1 outdoor sensor and up to 7 wireless indoor
sensors. (1pc wireless indoor sensor included)
INSTALL WIRELESS 7-IN-1 SENSOR
Your wireless 7-IN-1 sensor measures wind-speed, wind-direction, rainfall, UV, light intensity,
temperature and humidity for you. It’s assembled and calibrated for your easy installation.
INSTALL RAIN COLLECTOR
Rain Collector Installation
1 Align
Lock grooves
2 Lock
INSTALL BATTERIES
Unscrew the battery door at bottom of unit and insert the batteries
according to the +/- polarity indicated. Screw the battery door
compartment on tightly.
NOTE:
The red LED will begin ashing every 12 seconds.
Screw
location
3 x AA
batteries
MOUNTING POLE AND DIRECTION ALIGNMENT
Install the wireless 7-IN-1 sensor in an open
location with no obstructions above and around the
sensor for accurate rain and wind measurement.
Install the sensor with the smaller end facing the
North to properly orient the wind direction vane.
Secure the mounting stand and bracket (included)
to a 35 ~ 40mm diameter steel post or pole, and
allow minimum 2m off the ground.
Point to
SOUTH
Point to
NORTH
2 meter
off the
ground
mounting pole
and stand not
included
Add rubber
pad before
mounting on
pole or post

5
INSTALL WIRELESS INDOOR SENSOR
1. Remove the battery door of the sensor.
2. Use the channel slide switch to set the channel number for the
sensor (e.g. Channel 1)
3. Insert 2 x AAsize batteries into the battery compartment and close
the battery door according to the polarity information marked on the
battery compartment.
4. The sensor is in synchronization mode, and can be registered to the
console within the next few minutes. The transmission status LED
will begin to ash every 1 minute.
NOTE:
- If you need to re-assign the sensor channel, slide the channel slide switch to the new channel
position. For the new channel number to be effective, press [ RESET ] key on the sensor.
- Avoid placing the sensors in direct sunlight, rain or snow.
- To avoid the sensor/s and console pairing failure during new console setup, please power up
the sensor/s rst, and then press [ RESET ] key on the main unit (no need on sensors).
PLACING THE WIRELESS INDOOR SENSOR
Place a screw on the wall that you wish to hang the sensor on.
Hang the sensor onto the screw by the wall mounting holder. You
can also place the sensor on a table by itself.
SETUP THE CONSOLE
POWER UP THE CONSOLE
1. Plug the adapter provided to the power jack at the back of the console.
2. Once the console is turned on, all the segments of the LCD will be shown momentarily.
3. The console will automatically enters sensor synchronization mode and AP mode (refer to
SETUP WI-FI CONNECTION).
NOTE:
If no display appears on the LCD after you plug the adaptor, press [ RESET ] key by using a
pointed object.
SYNCHRONIZING WIRELESS 7-IN-1 SENSOR AND INDOOR SENSOR(S)
Immediately after power up, while still in Synchronization mode, the 7-in-1 sensor and Indoor
Sensor can be paired to the console automatically. Once your sensors are paired up, the
sensors' signal strength indicator and weather reading will appear on your console display.
BACKUP BATTERY
Backup batteries are used to keep time-sensitive information on the console’s memory during
power failure. These include:
-Time & Date, Alarm Time, Max/Min & Past 24 hours weather records, Alert setting values,
Sensor(s) channel history, and Units

6
1. Remove the battery door of the console.
2. Insert 3 new AAAbatteries as per the polarity indicated,
3. Replace the battery door.
BUILT-IN MEMORY
The console has built-in FLASH memory that holds the vital settings. These include:
-Time Zone, DST status, Time SYNC status, WI-FI and Weather server setting, Latitude /
Longitude, Hemisphere setting, Calibration values, and Sensor ID of paired sensor(s)
RESET AND FACTORY HARD RESET
To reset the console and start again, press the [ RESET ] key once. To hard reset the
console and resume factory settings, press and hold the [ RESET ] key for 6 seconds
RESYNCHRONIZE SENSORS
Press the [ SENSOR / WI-FI ] key once for the console to enter sensor Synchronization mode,
and the console will re-register all the sensors that have already been registered to it before.
i.e. the console will not lose the connection of the sensors that you’d paired up before.
CHANGING BATTERIES AND MANUAL PAIRING OF SENSOR
Whenever you changed the batteries of the wireless indoor or 7-in-1 weather sensor, re-
synchronization must be done manually.
1. Change all the batteries to new ones in the sensor.
2. Press [ SENSOR / WI-FI ] key on the console to enter sensor synchronization mode.
3. Press [ RESET ] key on the wireless indoor or 7-in-1 weather sensor.
SYNCHRONIZING ADDITIONAL WIRELESS SENSOR(S) (OPTIONAL)
The console can support up to 7 additional wireless sensors.
1. Press the [ SENSOR / WI-FI ] key once on the console to enter synchronization mode.
2. Press the [ RESET ] key on the new sensor, and wait for a few minutes for the new sensor
to paired to the console.
NOTE:
- Channel number of the indoor sensor must not be duplicated among the sensors. Please refer
to “INSTALL WIRELESS INDOOR SENSOR” for details
- This console can support different type of additional wireless sensor, e.g. soil moisture and
pool sensor. If you would like to pair up additional sensors, please check with your retailer for
more detail.
POINTING THE WIRELESS 7-IN-1 SENSOR TO SOUTH
The outdoor 7-IN-1 sensor is calibrated to point to North for the maximum accuracy. However,
for the user's convenience (e.g. users in the Southern hemisphere), it is possible to use the
sensor with the wind vane pointing to South.
1. Install the 7-IN-1 wireless sensor with its wind meter end pointing to South. (Please refer to
INSTALLATION OF THE WIRELESS SENSOR section for mounting details)
2. Select "S' in hemisphere section of the setup UI setup page. (Please refer to SETUP THE
WEATHER SERVER CONNECTION section for setup details)
3. Press Apply icon to conrm and exit.
NOTE:
Changing the hemisphere setting will automatically switch the direction of the moon phase on
the display.

7
CREATE WEATHER SERVER ACCOUNT & SETUP WI-FI CONNECTION
The console can upload weather data to WUnderground and / or Weathercloud through WI-FI
router, you can follow the step below to setup your device.
NOTE:
The Weather Underground and Weathercloud website are subjected to change without notice.
CREATE WEATHER UNDERGROUND ACCOUNT
1. In https://www.wunderground.com click the "Join" on the top right corner to open the
registration page. Follow the instructions to create your account.
NOTE:
Use the valid email address to register your account.
2. After you have created your account and completed the Email validation, please go back to
the WUndergound web page to login. Then, click “My Prole” button on the top to open the
drop-down menu and click "My Weather Station".
3. In "My Weather Station" page bottom, press the "Add New Device" button to add your
device.
4. Follow their instruction to enter your station information, in the Step "Tell Us More About
Your Device", (1) enter a Name for your weather station. (2) choose “Other” in “Device
Hardware” section and ll in other the other information (3) select "I Accept" to accept
Weather underground's privacy terms, (4) click “Next” to create your station ID and key.
(2)
(2)
(3)
(4)
(1)

8
5. Jot down Your "Station ID" and "Station key" for the further setup step.
CREATE WEATHERCLOUD ACCOUNT
1. In https://weathercloud.net enter your information in "Join us today" section, then follow
the instructions to create your account.
NOTE:
Use the valid email address to register your account.
2. Sign in weathercloud and then you will go the "Devices" page, click "+ New" to create new
device.

9
3. Enter all the information in Create new device page, for the Model* selection box select
the "W100 Series" under "CCL" section. for the Link type* selection box select the
"SETTINGS", Once you have completed, click Create.
4. Jot down your ID and key for the further setup step.

10
SETUP WI-FI CONNECTION
1. When you power up the console for the rst time, the console LCD will show ashing "AP"
and " " icon to signify that it has entered AP (Access Point) mode, and is ready for WI-FI
settings. User can also press and hold the [ SENSOR / WI-FI ] key for 6 seconds to enterAP
mode manually.
2. Use the smart phone, tablet, or computer to connect the console through WI-FI.
3. In PC choose WiFi network settings or In Android / iOS choose setting WI-FI to select the
console’s SSID: PWS-XXXXXX in the list and it will need several second to connect.
PWS-XXXXXX
PWS-XXXXXX
PC (Windows 10) WI-FI network interface Android WI-FI network interface
4. Once connected, enter the following IP address into your internet browser’s address bar, to
access the console’s web interface:
http://192.168.1.1
NOTE :
- Some browsers will treat 192.168.1.1 as a search, so make sure you include http:// header.
- Recommended browsers, such as the latest version of Chrome, Safari, Edge, Firefox or
Opera.
- WI-FI network interface of PC or mobile subject to change.
WI-FI CONNECTION STATUS
Below is the WI-FI icon status on the console LCD:
Stable: Console is in
connection with WI-FI router Flashing: Console is trying to connect to WI-FI router Flashing: Console currently in Access Point (AP) mode

11
SETUP THE WEATHER SERVER CONNECTION
Enter the following information into the below web interface "SETUP" page to connect the
console to weather server, If you do not want to use Wunderground.com or Weathercloud.net,
please empty the station ID & key to ignore the data upload.
nist.time.gov
Server URL:
0.0000 North
*Latitude:
0.0000
Enter 0 to 90, no negative numbers
Enter 0 to 180, no negative numbers
East
*Longitude:
Time server setup
Location for sunrise / sunset
WiFi Router setup
ADVANCED
Wunderground
Station ID: WDw124
******
******
******
IPACIR23Wc
Weather server setup
Station key:
Router:
Add Router
Search
Security type:
Router Password:
WAP2
ROUTER_A
Language: English
Weathercloud
Station ID:
Station key:
******
IDCR21w1
http://WAC.com
Station ID:
URL:
Station key:
Mac address 00:0E:C6:00:07:10
Hemisphere
* Depends on the model
SETUP
Apply
Firmware version: 1.00
0:00
Time Zone:
N
Press "ADVANCED" icon
to Advanced page
Press to search router
Press to allow add
router manually
E
nter the Latitude value
Enter the Longitude
value
SETUP page
Select setup UI display language
Press to complete the setting
Select router (SSID) for connection
Enter new Station ID and Station key
that assigned by Wundergriund
Enter new Station ID and Station key
that assigned by weathercloud
Enter new Station ID and Station key
that assigned by the corresponding
weather server
Manually enter the SSID if not on list
Select time server
Select time zone of your location
Select the direction (e.g. EU
countries Longitude is East and US
is West)
Select the sensor located hemisphere
(e.g. US and EU countries are also "N"
,
Australia is "S")
Reserved for validated weather server,
detail please consult with your retailer
Select router's security type (usually
WAP2)
Router's password (leave blank if the
Security type is "Open")
SETTINGS
NOTE:
- When WI-FI setup is completed, your PC or mobile will resume your default WI-FI connection.
- During AP mode, you can press and hold the [ SENSOR / WI-FI ] key for 6 seconds to stop
AP mode and the console will restore your previous setting.
TIME ZONE
To automtically set the time display to your time-zone, change the time zone in SETUP page of
previous section from '0:00' (default) to your time zone (e.g.+1:00 for Germany).
nist.time.gov
Server URL:
Time server setup
0:00
Time Zone:

12
TIME SERVER CONNECTION STATUS
After the console has connected to the internet, it will
attempt to connect to the internet time server to obtain
the UTC time. Once the connection succeeds and the
console's time has been updated, the “ ” icon will
appear on the LCD.
The time will automatically synchronize Internet time server at 12:00AM and 12:00PM per day.
Also you can press the [REFRESH ] key to get the internet time manually within 1 minute.
ADVANCE SETTING IN WEB INTERFACE
Press "ADVANCED" key at the top of web interface to enter the advance setting page, this
page allow you to set and view the calibration data of the console, as well as update the
rmware version on PC web browser.
Upload
Browse
Firmware version: 1.00
-560~ 560hpa / -16.54 ~ 16.54inHg / -420 ~ 420mmHg
Setting Range:
Temperature oC
Outdoor
Indoor
CH 1
CH 2
CH 3
CH 4
CH 5
CH 6
CH 7
Humidity %
Relative Pressure Offset:
Absolute Pressure Offset:
hpa
Range: -20 ~ 20
(Default: 0.0)
Current offset: 10Current offset: -9
Current offset: -5Current offset: 2
Current offset: -2Current offset: 3
Current offset: -2Current offset: 1.2
Current offset: -5Current offset: -0.2
Current offset: -3Current offset: -20.1
Current offset: -10Current offset: 11.5
Current offset: -3
Current offset: -3
(Default: 0)
Current offset: 10
(Default: 0)
Current offset: 0.2
Current offset: -5Current offset: 1
Pressure
Range: -20.0 ~ 20.0oC
-36.0 ~ 36.0oF (Default: 0.0)
*UV gain: Range: 0.01 ~ 10(Default: 1.00)
Current gain: 1.1
*Light gain: Range: 0.01 ~ 10(Default: 1.00)
Current gain: 1.1
* Depends on the model
*Wind speed gain:
*Wind direction:
*Rain gain: Range: 0.5 ~ 1.5(Default: 1.00)
Range: -10 ~ 10(Default: 0o)
Range: 0.5 ~ 1.5(Default: 1.00)
Current gain: 0.85
Current offset: 2o
Current gain: 0.75
SETUP ADVANCED
Select setting unit
Press "SETUP" icon to
Setup page
Outdoor and Ch 1~7
temperature calibration
section
Pressure calibration
section
version function only available
in PC web browser
ADVAN
C
ED page
Select setting unit
The rain, wind speed, UV and Light
calibration use gain method. The
wind direction is +/- 10 offset.
Outdoor and Ch 1~7 humidity
calibration section
Current offset value is the value
that you set before to offset the
pressure reading.
SETTINGS
CALIBRATION
1.User can input the offset and/or gain values for different parameters while current offset and
gain values are shown next to their corresponding blank.
2.Once completed, press Apply at the bottom of the SETUP page
The current offset value will show the previous value that you entered, please input the new
value in the blank if any changes needed, the new value will effective once you press Apply
icon in SETUP page.

13
NOTE:
- Calibration of most parameter is not required, with the exception of Relative Pressure, which
must be calibrated to sea-level to account for altitude effects.
- Indoor temperature and humidity calibration values are not applicable for this console.
VIEW YOUR WEATHER DATA IN WUNDERGROUND
To view your weather station live data in a web browser (PC or mobile version), please visit http://
www.wunderground.com, and then enter your “Station ID” in the searching box. Your weather
data will show up on the next page. You can also login your account to view and download the
recorded data of your weather station.
Another way to view your station is use the web browser URL bar, type below in the URL bar:
https://www.wunderground.com/dashboard/pws/XXXX
Then replace the XXXX by your Weather underground station ID to view your station live data.
You can also check Weather Underground web site to learn more about their mobile App for
Android and iOS.
VIEWING YOUR WEATHER DATA IN WEATHERCLOUD
1. To view your weather station live data in a web browser (PC or mobile version), please visit
https://weathercloud.net and sign in your own account.
2. Click the icon inside the pull down menu of your station.
3. Click "Current", "Wind", "Evolution" or "Inside" icon to view the live data of your weather
station.

14
FIRMWARE UPDATE
The console supports OTA rmware update capability. Its rmware may be updated over the
air anytime (whenever necessary) through any web-browser on a PC with WI-FI connectivity.
Update function, however, is not available through mobile/smart devices.
Upload
Browse
Firmware version: 1.00
Current rmware
version
Bottom of web interface ADVANCED page Press to start upload the rmware
to console
Please to select the rmware le for
update
FIRMWARE UPDATE STEP
1. Download the latest version rmware to your PC.
2. Set the Console into AP (access point) mode then connect the PC to the console (ref to
"SETUP WI-FI CONNECTION" section in previous page).
3. Click the Browse in rmware update section and browse the location of the le you
download in step 1. To update the WI-FI rmware, click the Browse in WI-FI rmware
section.
4. Click the corresponding Upload to start transfer the rmware le to console.
5. In the meantime, the console will execute the update automatically
and will show the update progress on display (i.e. 100 is completion).
The update time is around 5 ~ 8 minutes
6. The console will restart once the update is completed.
7. The console will stay in AP mode for you to check the rmware version and all the current
setting.
IMPORTANT NOTE:
- Please keep connecting the power during the rmware update process.
- Please make sure your PC's WI-FI connection is stable.
- When the update process start, do not operate the PC and console until the update nished.
- During rmware update the console will stop upload data to the cloud server. It will reconnect
to your WI-FI router and upload the data again once the rmware update succeed. If the
console cannot connect to your router, please enter the SETUP page to setup again.
- After the rmware update, If the setup informations are missing, please input the setup
information again.
- Firmware update process have potectial risk, which cannot guarantee 100% success. If the
update fail, please redo the above step to update again.
OTHER SETTING & FUNCTIONS OF THE CONSOLE
MANUAL CLOCK SETTING
This console is designed to obtain the UTC time by synchronize with the assigned internet time
server. If you want to use it ofine, you can set the time and date manually. During the rst time
startup, press and hold the [ SENSOR / WI-FI ] key for 6 seconds and let the console back to
normal mode.
1. In normal mode, press and hold [ CLOCK SET ] key for 2 seconds to enter setting.
2. The setting sequence: DST AUTO/OFF Hour Minute second 12/24 hour
format Year Month Day M-D/D-M format Time sync ON/OFF weekday
Language.
3. Press [ ] or [ ] key to change the value. Press and hold the key for quick-adjust.
4. Press [ CLOCK SET ] key to save and exit the setting mode, or the unit will automatically
exit the setting mode 60 seconds later without pressing any key.

15
NOTE:
- In normal mode, press [ CLOCK SET ] key to switch between year and date display.
- During the setting, you can press and hold [ CLOCK SET ] key for 2 seconds to back to
normal model.
DAYLIGHT SAVING TIME (DST)
DST function is set to "AUTO" by default (for EU or US version). If the current date on display is
with in the summer daylight saving period, the time will be automatically adjusted forward by +1
hour, and DST icon will be shown on the LCD display.
MOON PHASE
The moon phase is determined by the
time, date and time zone. The following
table explains the moon phase icons of
the Northern and Southern Hemispheres.
Please refer to
POINTING THE
WIRELESS 7-IN-1 SENSOR TO SOUTH
section about how to setup for the
Southern Hemispheres.
Northern
Hemisphere Moon Phase Southern Hemisphere
New Moon
Waxing Crescent
First quarter
Waxing Gibbous
Full Moon
Waning Gibbous
Third quarter
Waning
Crescent
SUNRISE & SUNSET TIME
The console indicates your location’s sunrise & sunset time by the
time zone, latitude and longitude you entered. Please enter the correct
information in the regarding settings. If the latitude and longitude values
do not match the time zone, the sunrise & sunset time cannot be shown.
SETTING ALARM TIME
1. In normal time mode, press and hold [ ALARM ] key for 2 seconds until the alarm hour digit
ashes to enter alarm time setting mode.
2. Press [ ] or [ ] key to change the value. Press and hold the key for quick-adjust.
3. Press [ ALARM ] key again to step the setting value to Minute with the Minute digit ashing.
4. Press [ ] or [ ] key to adjust the value of the ashing digit.
5. Press [ ALARM ] key to save and exit the setting.
NOTE:
- In alarm mode, the “ ” icon will display on the LCD.
- The alarm function will turn on automatically once you set the alarm time.

16
ACTIVATING ALARM AND TEMPERATURE PRE-ALARM FUNCTION
1. In normal mode, press [ ALARM ] key to show the alarm time for 5 seconds.
2. When the alarm time displays, press [ ALARM ] key again to activate the alarm function.
Or press [ ALARM ] key twice to activate the alarm with ice pre-alarm function.
Alarm off Alarm on Alarm with ice-alert
NOTE:
Once the ice pre-alert activates, the pre-set alarm will sound and ice-alert icon will ash 30
minutes earlier if the outdoor temperature is below -3°C.
When clock reach the alarm time, alarm sound will start.
Where it can be stopped by following operation:
- Auto-stop after 2 minutes alarming if without any operation and the alarm will activate again in
the next day.
- By pressing [ALARM / SNOOZE] key to enter snooze that the alarm will sound again after 5
minutes.
- By pressing and hold [ALARM / SNOOZE] key for 2 seconds to stop the alarm and will
activate again in the next day
- By pressing [ ALARM ] key to stop the alarm and the alarm will activate again in the next day.
NOTE:
- The snooze could be used continuously in 24 hours.
- During the snooze, the alarm icon “ ” will keep ashing.
TEMPERATURE / HUMIDITY FUNCTION
- The temperature and humidity reading are display on the outdoor and indoor (CH) section.
- Use the [ °C / °F ] slide switch to select the temperature display unit.
- If temperature / humidity is below the measurement range, the reading will show “Lo”. If
temperature / humidity is above the measurement range, the reading will show “HI”.
COMFORT INDICATION
The comfort indication is a pictorial indication
based on indoor air temperature and humidity in
an attempt to determine comfort level. Too cold Comfortable Too hot
NOTE:
- Comfort indication can vary under the same temperature, depending on the humidity.
- There is no comfort indication when temperature is below 0°C (32°F) or over 60°C (140°F).
WIRELESS SENSOR SIGNAL RECEIVING
1. The console display signal strength for the wireless sensor(s), as per table below:
Outdoor 7-in-1 sensor
Indoor channel sensor
No signal Weak signal Good signal
2. If the signal has discontinued and does not recover within 15 minutes, the signal icon will
disappear. The temperature and humidity will display “Er” for the corresponding channel.
3. If the signal does not recover within 48 hours, the “Er” display will become permanent. You
need to replace the batteries and then press [ SENSOR / WI-FI] key to pair up the sensor
again.

17
VIEW THE OTHER INDOOR CHANNELS (OPTIONAL FEATURE WITH ADD ON EXTRA
SENSORS)
This console is capable to pair with a wireless 7-IN-1 sensor and up to 7 wireless indoor
sensors. If you have 2 or more Indoor sensors, you can press [ CHANNEL ] key to switch
between different wireless channels in normal mode, or press and hold [ CHANNEL ] key for 2
seconds to toggle auto-cycle mode to display the connected channels at 4 seconds interval.
During auto-cycle mode, the icon will show on the indoor channel section of the console's
display. Press [ CHANNEL ] key to stop auto cycle and display the current channel.
TREND INDICATOR
The trend indicator shows the trends of changes in the
forthcoming few minutes. The icon will appear in temperature,
humidity, index and baro section. Rising Steady Falling
WIND
WIND SPEED AND DIRECTION SECTION OVERVIEW
Average / gust
wind speed
Real time wind
direction indicator
Past wind
directions indicator
Wind direction
Wind speed
level indicator
*While the big arrow shows the real time wind direction, total up to 5 small pointers show the most recent
wind directions giving user a general direction of the wind. The pointers will disappear after 5 minutes or
being replaced by new pointers as wind direction changes.
TO SELECT THE WIND DISPLAY MODE
In normal mode, press [ WIND ] key to switch between BEAUFORT scale, AVERAGE and
GUST wind speed.
1. Average Wind speed – this refers to the average wind speed over the course of 12s.
2. Gust Wind speed – this refers to the highest wind speed measured in the same period.
TO SET THE WIND SPEED UNIT AND DIRECTION DISPLAY FORMAT
1. In normal mode, press and hold [ WIND ] key for 2 seconds to enter into wind speed unit
mode and the unit will ash. Press [ ] or [ ] key to change the wind speed unit in this
sequence: m/s km/h knots mph
2. Press [ WIND ] key again to enter wind direction setting mode. The wind direction reading
will ash, and then press [ ] or [ ] key to select the display format between 360 degree
or 16 direction.
3. Press [ WIND ] key again to return normal mode.
