CCTV ALI-L19W User manual

CCTV
Monitor User Manual

User Manual
Table Of Contents
Information ................................................................................................................................................. 1
Important safeguards ................................................................................................................................ 1
Introduction ................................................................................................................................................ 2
Features ...................................................................................................................................................... 2
Assembling the monitor ............................................................................................................................ 2
Assembling the monitor ................................................................................................................................ 2
Disassembling the monitor ........................................................................................................................... 2
Connections ............................................................................................................................................... 3
Front panel controls .................................................................................................................................. 3
Control panel ............................................................................................................................................... 3
Adjustment procedure ...............................................................................................................................4
OSD function ...............................................................................................................................................5
VGA menu ....................................................................................................................................................5
 Picture .............................................................................................................................................................................5
 Sound (optional) ..............................................................................................................................................................6
 System ............................................................................................................................................................................6
 Lock ..............................................................................................................................................................................7
 Motion(optional) ..............................................................................................................................................................7
HDMI/CAM menu ..........................................................................................................................................7
 Picture .............................................................................................................................................................................7
 Sound (optional) ..............................................................................................................................................................8
 System ............................................................................................................................................................................8
 Lock ............................................................................................................................................................................. 9
 Motion (optional) ............................................................................................................................................................ 9
Self-diagnosis........................................................................................................................................... 9
Troubleshooting....................................................................................................................................... 10
Specifications󰾡.......................................................................................................................................... 11
Factory preset timings (VGA mode) ....................................................................................................... 13
Factory preset timings (HDMI mode) ...................................................................................................... 13

1
Information
FCC compliance
Class A: This equipment has been tested and
found to comply with the limits for a Class A digital
device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable
protection against harmful interference when the
equipment is operated in a commercial
environment. This equipment generates, uses, and
can radiate radio frequency energy and, if not
installed and used in accordance with the
instruction manual, may cause harmful interference
to radio communications. Operation of this
equipment in a residential area is likely to cause
harmful interference in which case the user will be
required to correct the interference at his own
expense.
This product was FCC verified under test
conditions that included the use of shielded I/O
cables and connectors between system
components. To be in compliance with FCC
regulations, the user must use shielded cables and
connectors for all except power cables.
Canada
This Class A digital apparatus complies with
Canadian ICES-003.
Cet appareil numérique de la classe A est
conforme à la norme NMB-003 du Canada.
European Union directives
2004/108/EC (EMC directive): This device is in
compliance with the essential requirements and
other relevant provisions of Directive 2004/108/EC.
2002/96/EC (WEEE directive): Products marked
with this symbol cannot be disposed of as unsorted
municipal waste in the European Union. For proper
recycling, return this product to your local supplier
upon the purchase of equivalent new equipment, or
dispose of it at designated collection points.
Important safeguards
1. Installation cautions:
• Do not block any ventilation openings.
• Always ensure that the monitor is located in
a well-ventilated area to prevent the unit
from overheating.
• Only use accessories specified by the
manufacturer or those sold with the product.
• Avoid operating or placing the monitor in
the following environments: extremes of
temperatures, both hot and cold; high
humidity; direct sunlight; excessively dusty
surroundings; avoid close proximity to other
equipment that generates a strong
magnetic field
2. Water and moisture: Do not use this
appliance near water. To reduce the risk of fire
or electric shock, do not expose this unit to rain
or moisture.
3. Power cord and power cord protection:
Power cords should be routed so that they not
likely to be walked on or pinched. Pay
particular attention to the location of cords and
plugs, convenience receptacles, and the point
of exit from the appliance.
4. Product care: Do not touch the screen directly
with fingers. The oils from your skin may leave
marks on the surface of the screen, which are
difficult to be removed and may damage the
screen permanently. Do not apply pressure to
the screen.
5. Cleaning: Clean only with a dry cloth.
6. Servicing: Do not attempt to service this unit
yourself. Opening or removing covers may
expose you to dangerous voltage or other
hazards. Refer all servicing to qualified service
personnel.
7. Lightning: For added protection during a
lighting storm or when this unit is left
unattended and unused for long periods of
time, unplug the unit from the wall outlet and
disconnect the cable system. This will prevent
damage to the unit due to lightning and power
line surges.
8. Mains plug (2 pin/3 pin):
• Do not remove the grounding or earth
connection from the power supply / mains
plug.
• Always remember to unplug the monitor
from the power supply under the following
circumstances if the monitor will not be

2
used for a long period of time, if the power
supply cable or plug/connector is damaged
or if the monitor housing is damaged or
broken.
CAUTION: Do not attempt to dismantle this
product. Any attempt to dismantle or remove the
covers from this product will invalidate the warranty
and may also result in serious injury.
Introduction
This manual explains how to correctly install,
operate and get the best performance from your
monitor. Please read this user manual carefully
before installing your monitor then keep it near
your monitor for quick reference.
First, please check that the contents of the box
correspond with the following checklist:
• Monitor
• Power cord
• VGA cable
• User manual
If any item is missing or damaged, please contact
your dealer. Please keep the box and packing
materials so that you may properly store or
transport your monitor.
Features
 The convenient and user-friendly on-screen
display allows for easy and accurate
adjustments of screen size, position and color.
 The monitor complies with the VESA Display
Data Channel (DDC) specification for Plug and
Play compatibility. Advanced micro circuitry
makes setup and configuration fast and
effortless.
 The monitor features Advanced Color Controls
for fine-tuning to meet application
requirements. Use the on-screen controls to
adjust the color temperature and RGB gain
value for the best possible screen color and
intensity.
Assembling the monitor
The monitors are designed for use on a desktop.
The arm of the monitor stand is shipped pre-
installed on the monitor.
Assembling the monitor
1. Put a smooth pad or cloth on a level surface.
Place the monitor on it facing downwards.
2. Insert the arm of the monitor stand of the
monitor into the pedestal foot provided.
Disassembling the monitor
1. Put a smooth pad or cloth on a level surface.
Place the monitor on it facing downwards.
2. Press the groove on the back of protrude
connected to the body. Detach the rear cover
of the monitor stand with a screw driver.
3. Remove the screws connecting the stand
rear body.
4. Remove the connecting stand front body.
Screw(x4)
Screw(x2)

3
Connections
(19”,22”)
1. AC IN
2. CAM OUT
Composite signal output
3. CAM IN
Composite signal input.
4. HDMI
HDMI signal input.
5. VGA
RGB signal input.
Front panel controls
Control panel
1.MENU
Turns the OSD window on.
Turns the OSD window off and moves from sub
menu to top menu in the OSD window.
*Push the menu button for 5seconds when you
want to unlock the keypad lock.
2. ▲ (Up Arrow)
Primary Function: Select the input source.
Moves cursor to the up in the OSD window and
increases the value of any selected menu.
3. ▼ (Down Arrow)
Moves cursor to the down in the OSD window
and decreases the value of any selected menu.
4. AUTO(*)
Primary Function: Automatically adjusts
the display to the most optimal setting possible.
(VGA mode only)
Secondary Function:Select the sub menu.
5. POWER
Switches the monitor on and off.
*HOT KEY →(*)
Changing a monitor parameter
1. Press the MENU button on the front panel to
obtain the OSD menu screen.
2. Use UP-DOWN buttons to select the menu.
3. Use AUTO button to select the submenus.
4. Use Up-Down buttons to select a submenu
function.
5. Press AUTO/SELECT button, then using left-
right buttons you can make adjustments as
necessary
6. To exit, press MENU.

4
Adjustment procedure
Perform the
Auto tracking
Is the H.Size
proper?
Adjust the
Clock control.
Perform the
H - V Position.
Is the noise
displayed on
the screen?
Adjust the Phase until
the screen is cleared.
Is the noise
displayed on the
screen yet?
End
No
Yes
Yes
Yes
No

5
OSD function
Configure the monitor using the onscreen display
(OSD) menus and submenus. Changes are
immediately saved and implemented.
VGA menu
 Picture
(Advanced Setting)
(VGA setting)
1. Brightness
Adjust the brightness of the image.
2. Contrast
Adjust the contrast of image, the difference
between light and dark areas on the screen.
3. Color Tone
Choose a different preset color temperatures or
set your own customized color parameters.
4. Advanced Setting
4-1 Noise Reduction.
Not used.
4-2 Back Light
Adjust the back light to be brighter or darker.
4-3 DCR (Dynamic Contrast Ratio)
Not used.
4-4 DCC (Dynamic Contrast Control)
Not used.
4-5 H-Position
Not used.
4-6 H-Size
Not used.
4-7 V-Position
Not used.
4-8 V-Size
Not used.
5. VGA Setting
5-1 Auto adjust
Choose automatically the proper horizontal
position and vertical position and size of the
screen image.
5-2 H-Position
Adjust the position of the display horizontally
(left or right).
5-3 V-Position
Adjust the position of the display vertically (up
or down).
5-4 Phase
Remove any horizontal noise and clear or
sharpen the image of the characters.
5-5 Clock
Adjust the width (horizontal size) of the screen
image.

6
 Sound (optional)
1. Sound Mode
Choose a different preset sound mode or your
own customized sound.
2. Balance
Adjust the sound balance of the left and right
speakers.
3. Bass
When you select the user mode, adjust the
bass sound.
4. Treble
When you select the user mode, adjust the
treble sound.
5. Equalizer
Provide an enhanced listening experience.
6. Auto Volume
Automatically remains on the same level of the
volume if you change the program.
 System
(Time setting)
1. Menu Language
Select language for OSD.
2. Screen Format
Select the aspect ratio.
3. OSD Time out
Adjust the display time of the OSD menu.
4. OSD Transparency
Adjust the OSD Transparency.
5. Power status
Decide to select working status of product Set
when turn on main power.
6. Blue Screen
The monitor will display a blue screen when it
has no signal or when the source has been
changed.
7. Time Setting
7-1 Time
Not used.
7-2 Sleep Timer
Set sleep timer
7-3 Auto Sleep
Monitor is turned off when it did not receive any
signal from remote control or any button within
the time that you set up.(The screen warning is
showed before automatic shutdown time that
you set up)
8. Memory Recall
Reset the screen to the factory preset display
settings.

7
 Lock
1. Keypad Lock
Turn keypad lock on or off
2. Remote Control Lock(optional)
Turn Remote Control lock on or off
 Motion (optional)
1. Motion
Turn on or off motion.
2. Motion Duration
Not used.
3. Motion Logo
Not used.
4. Flashing Logo
Not used.
5. Flashing LED
Not used.
6. Alarm
Not used.
7. Beep
Not used.
HDMI/CAM menu
 Picture
(Advanced Setting)
1. Picture Mode
Select the picture mode.
2. Brightness
Adjust the brightness of the image.
3. Contrast
Adjust the contrast of image, the difference
between light and dark areas on the screen.
4. Color Mode
Adjust Color of image.
5. Sharpness
Adjust the display image quality (if the screen
proceed to scaling up).
6. Tint(cam mode only)
Adjust the Tint of image.
7. Color Tone
Choose a different preset color temperatures or
set your own customized color parameters.
8. Advanced Setting

8
8-1 Noise Reduction
Reduce the noise in the picture due to poor
reception or poor picture quality.
8-2 Back Light
Adjust the back light to be brighter or
darker.
8-3 DCR(Dynamic Contrast Ratio)
Turn DCR on or off.
8-4 DCC(Dynamic Contrast Control)
Turn DCC on or off.
8-5 H-Position
Adjust the position of the display
horizontally. (left or right)
8-6 H-Size
Adjust the width (horizontal size) of the
screen image.
8-7 V-Position
Adjust the position of the display
vertically(up or down).
8-8 V-Size
Adjust the height (vertical size) of the
screen image.
 Sound󰾡(optional)
1. Sound Mode
Choose a different preset sound mode or your
own customized sound.
2. Balance
Adjust the sound balance of the left and right
speakers.
3. Bass
When you select the user mode, adjust the
bass sound.
4. Treble
When you select the user mode, adjust the
treble sound.
5. Equalizer
Provide an enhanced listening experience.
6. Auto Volume
Automatically remains on the same level of the
volume if you change the program
 System
(Time Setting)
1. Menu Language
Select language for OSD.
2. Screen Format
Select the aspect ratio.
3. OSD Time out
Adjust the display time of the OSD menu.
4. OSD Transparency
Adjust the OSD Transparency.
5. Power status
Decide to select working status of product Set
when turn on main power.
6. Blue Screen
The monitor will display a blue screen when it
has no signal or when the source has been
changed.

9
7. Video Standard (cam mode only)
Select the CVBS mode.
8. Time Setting
8-1 Time
Not used.
8-2 Sleep Timer
Set sleep timer
8-3 Auto Sleep
Monitor is turned off when it did not receive any
signal from remote control or any button within
the time that you set up.(The screen warning is
showed before automatic shutdown time that
you set up)
9. Memory Recall
Reset the screen to the factory preset display
settings.
 Lock
1. Keypad Lock
Turn keypad lock on or off.
2. Remote Control Lock󰾡(optional)
Turn Remote Control lock on or off.
 Motion󰾡(optional)
1. Motion
Turn on or off motion.
2. Motion Duration
Not used.
3. Motion Logo
Not used.
4. Flashing Logo
Not used.
5. Flashing LED
Not used.
6. Alarm
Not used.
7. Beep
Not used.
Self-diagnosis
If there is no image, the Self-Diagnosis screen will
be displayed. The self-diagnosis function checks if
the status of the monitor screen is No Signal, Out
of Range and Power off Message.
No Signal screen is displayed when the D- Sub
signal connector is connected but the status of
the monitor is on DPMS mode.
Out of Range screen is displayed when the
applied frequency is under or over normal range.
Normal range (Non-interlaced mode only):
H: 30 to 80 kHz
V: 56 to 77 Hz
Press any key to cancel.
(Monitor is turned off when it did not receive any
signal from remote control or any button within
the time that you set up.)

10
Troubleshooting
Symptom
Check
Picture is jittery
Adjust Clock to set the screen position and adjust Clock value carefully
until a noise is no longer displayed.
No picture
Check if the power switch and computer power switch are in the On
position
Check if the signal cable is correctly connected to the video card.
Check if the pins of D sub-connector are not bent.
Check if the computer is in the power- saving mode.
POWER LED is not lite
Check if power switch is in the On position.
Check if the power cord is correctly connected.
Image is unstable
Check if the signal cable is suitable to the video card
Image is not centered,
too small or too large
Adjust Clock or H&V Center to get the proper image.
Picture bounces or a
wave pattern is present
in the picture
Keep the devices that may cause electrical interference away from the
monitor.
See the FCC information at the front cover of the manual.
Picture is blurred
Adjust Contrast and Brightness.
VIDEO screen cannot be
seen
Check if PICTURE mode has been set.
Check if the video terminal is properly connected.
No video
Check if the video cable is correctly connected to the computer and set
to Functions on the OSD picture menu.
Poor color in the video
Adjust the Color or Tint values on the OSD Picture menu.
Grainy picture in the
video
Adjust the Sharpness on the OSD Picture menu.

11
Specifications
Items
ALI-L19W
Panel
Screen size
18.5 in (47cm)
Pixel pitch
0.300 x 0.300 mm
View angle (H/V)
170°/160°
Contrast ratio
1000:1 (typ)
Response time
5 ms
Brightness
250 cd/m² (typ)
Recommended
resolution
1366 x 768 @ 60Hz
Interface
VGA in (15 Pin D-
Sub)
1
HDMI in
1
BNC (in/out)
1/1
Power
Consumption
<20 W
Source
AC 100 - 240 V
Dimensions
W x H x D
(with stand)
444 mm x 337 mm x 172 mm
17.5 in x13.3 in x 6.8 in
W x H x D
(box)
498 mm x 390 mm x 102 mm
119.6 in x 15.4 in x 4.0 in
Weight
Net (with stand)
2.8Kg (6.1lb)
Gross (box)
3.8 Kg (8.4 lb)
VESA mount
Specifications
Hole patterns
VESA standard
100 mm x 100 mm
Spacing screw size
M4 screw
Length
12 mm
Operating
temperature
0 to 40 °C (32 to 104 °F)
The specifications can change without any notice.
The panel may have some defective pixels (ex. slightly light or dark) due to a characteristic of the
panel. But there is no defect in your panel product itself.

12
Items
ALI-L22W
Panel
Screen size
21.5 in (54.6cm)
Pixel pitch
0.248 (H) x 0.248 (V)
View angle (H/V)
170°/160°
Contrast ratio
1000:1 (typ)
Response time
5 ms
Brightness
250 cd/m² (typ)
Recommended
resolution
1920 x 1080 @ 60 Hz
Interface
VGA in
(15 Pin D-Sub)
1
HDMI in
1
BNC (in/out)
1/1
Power
Consumption
<30 W
Source
AC 100 - 240 V
Dimensions
W x H x D
(with stand)
511 mm x 392 mm x 203 mm
20.1 in x 15.4 in x 8.0 in
W x H x D
(box)
564 mm x 436 mm x 144 mm
22.2 in x 17.2 in x 5.7 in
Weight
Net (with stand)
3.9 kg (8.6 lb.)
Gross (box)
5.3 kg (11.7 lb)
VESA mount
Specifications
Hole patterns
VESA standard
100 mm x 100 mm
Spacing screw size
M4 screw
Length
10 mm
Operating
temperature
0 to 40 °C (32 to 104 °F)
The specifications can change without any notice.
The panel may have some defective pixels (ex. slightly light or dark) due to a characteristic of the
panel. But there is no defect in your panel product itself.

13
Factory preset timings (VGA mode)
Pixel Format
Horizontal
Freq.(KHz)
Vertical
Freq.(Hz)
Remark
720 x 400
31.469
70.087
All models
640 x 480
31.469
59.940
All models
640 x 480
37.861
72.809
All models
640 x 480
37.500
75.000
All models
800 x 600
37.870
60.317
All models
800 x 600
48.077
72.188
All models
800 x 600
46.875
75.000
All models
1024 x 768
48.360
60.000
All models
1024 x 768
56.476
70.069
All models
1024 x 768
60.020
75.030
All models
1152 x 864
67.500
75.000
19”,22”
1280 x 1024
63.981
60.020
19”,22”
1280 x 1024
79.974
75.024
19”,22”
1360 x 768
47.712
59.790
19”W,22”
Factory preset timings (HDMI mode)
Pixel Format
Horizontal
Freq.(KHz)
Vertical
Freq.(Hz)
Remark
640 x 480
31.500
60.000
All models
720 x 576
31.250
50.000
All models
1280 x 720
37.500
50.000
All models
1280 x 720
45.000
60.000
All models
1920 x 1080
28.120
50.000
22”
1920 x 1080
33.750
60.000
22”
1920 x 1080
56.250
50.000
22”
1920 x 1080
67.500
60.000
22”
