CDA HCG 730 Users operating instructions Product guide

Built-in
cooking hob
HCG 730
HCG 740
Before operating this hob,
please read these instructions carefully
Users Operating Instructions
Installation instructions
GB

2
Dear Customer,
Thank you for choosing one of our products.
The warnings and tips given below are intended to protect
your safety and that of others. They will also help you make
the most of your appliance.
Keep this booklet in a safe place. It will be useful if you, or
anyone else, have any questions about use of the appliance.
This appliance must only be used for the purpose for
which it was designed, i.e. for cooking foods.
Any other use should be considered incorrect and
therefore dangerous.
The manufacturer is not responsible for damage
caused by improper, incorrect or irresponsible use of
the appliance.

3
Important:
This appliance is designed and manufactured solely for the cooking of domestic
(household) food and is not suitable for any non domestic application and there-
fore should not be used in a commercial environment.
The appliance guarantee will be void if the appliance is used within a non domes-
tic environment i.e. a semi commercial, commercial or communal environment.
Declaration of CE conformity
✓ This hob (Class 3) has been designed for use only as a cooking appliance. Any
other use (e.g. heating rooms) should be considered incorrect and therefore
dangerous.
✓ This hob has been designed, constructed and put on to the market in conformi-
ty with:
- Safety requirements of EU Directive "Gas" 90/396/EEC;
- Safety requirements of EU Directive "Low Voltage" 2006/95/EC;
- Protection requirements of EU Directive "EMC" 89/336/EEC;
- Requirements of EU Directive 93/68/EEC.
These instructions are only valid for those countries whose identification sym-
bol appears on the cover of the instruction booklet and on the appliance.
GB

4
BEFORE USING FOR THE FIRST TIME
•Read the instructions carefully before installing and using the appliance
• After unpacking the appliance, make sure it is not damaged. In case of doubt, do not
use the appliance and contact your supplier or a qualified engineer.
• Remove all packaging and do not leave the packing material (plastic bags, poly-
styrene, bands etc ) in easy reach of children as they may cause serious injury. The
packaging materials are recyclable.
• The appliance should be installed and all the gas/electrical connections made by a
qualified engineer in compliance with local regulations in force and following the
manufacturer’s instructions.
• Do not attempt to modify the technical properties of the appliance, as it may become
dangerous to use.
CAUTION:
If the burner is accidentally extinguished, turn the gas off at the control knob and
wait at least 1 minute before attempting to relight.
CAUTION:
Gas hobs produce heat and humidity in the environment in which they are installed.
Ensure that the cooking area is well ventilated by opening the natural ventilation
grilles or by installing an extractor hood connected to an outlet duct.
CAUTION:
If the hob is used for a prolonged time it may be necessary to provide further ventila-
tion by opening a window or by increasing the suction power of the extractor hood
(if fitted).

5
IMPORTANT SAFEGUARDS & RECOMMENDATIONS
•Do not carry out any cleaning or maintenance without first disconnecting the appli-
ance from the electrical supply.
•During and after use of the hob, certain parts will become very hot. Do not touch
hot parts.
•After use always ensure that the control knobs are in the “●” OFF position.
•Young children should be supervised to ensure that they do not play with the appli-
ance.
•Keep children away from the hob during use.
•The appliance is not intended for use by young children or infirm persons unless they
have been adequately supervised by a responsible person to ensure that they can
use the appliance safely.
•Do not allow young children or infirm persons to use the appliance without your
supervision.
•WARNING
When correctly installed, your product meets all safety requirements laid down for
this type of product category. However special care should be taken around the
underneath of the appliance as this area is not designed or intended to be touched
and may contain sharp or rough edges, that may cause injury.
•Fire Risk! Do not leave inflammable materials on the hob top.
•Make sure that electrical cords connecting other appliances in the proximity cannot
come in to contact with the hob top.
•Never use a damaged appliance. Get it checked or repaired: “see appliance servicing”.
•When the appliance is not being used, it is advisable to keep the gas tap closed.
•Regular lubrication of the gas taps must only be carried out by qualified engineers.
Contact Service in case of problems with the operation of the gas taps.
•Before disposing of an unwanted appliance, it is recommended that it is made inop-
erative and that all potentially hazardous parts are made harmless.
•If the supply cord is damaged, it must be replaced by a special cord by a
qualified electrical technician in order to avoid a hazard.

6
COOKING POINTS
1. Auxiliary burner (A) - 1,00 kW
2. Semirapid burner (SR) - 1,75 kW
3. Rapid burner (R) - 3,00 kW
4. Triple-ring burner (TR) - 3,50 kW
CONTROL PANEL DESCRIPTION
5. Auxiliary burner control knob (1)
6. Rear left semirapid burner control knob (2)
7. Triple ring burner control knob (4)
8. Rapid burner control knob (3)
9. Front right semirapid burner control knob (2)
This appliance is class 3
Figure 1 Figure 2
Models: HCG 740
6 7 8 95




6 7 8 95




Models: HCG 730
Features
NOTE:
✓The appliance may be provided with:
• a gas-lighter incorporated in the knobs ( symbol beside big flame -
maximum aperture or max gas flow)
• no gas-lighter (no symbol beside the knob)
• safety valve system.
✓If the appliance has a safety valve system fitted (beside every burner is a T-shaped probe,
as in Fig. 7 - not to be confused with the S-shaped electrode of the gas lighter), the flow
of gas will be stopped if and when the flame should accidentally go out.

7
GAS BURNERS
Gas flow to the burners is adjusted by turning the knob illustrated in figs. 3a - 3b which
control the valves.
Turning the knob so that the indicator line points to the symbols printed on the panel
achieves the following functions:
✓full circle ●= closed valve
✓symbol – = maximum aperture or flow
✓symbol = minimum aperture or flow
The maximum aperture position permits rapid boiling of liquids, whereas the minimum
aperture position allows slower warming of food or maintaining boiling conditions of
liquids.
To reduce the gas flow to minimum, rotate the knob further anti-clockwise to point
the indicator towards the small flame symbol.
Other intermediate operating adjustments can be achieved by positioning the indicator
between the maximum and minimum aperture positions, not between the maximum
aperture and closed positions.
Use of the Hob
N.B. When the hob is not being used, set the gas knobs to their closed posi-
tions and also close the cock valve on the gas bottle or the main gas supply
line.
Figure 3a Figure 3b
Models with safety cut-off valves Models without safety cut-off valves
Models with
electric
ignition only
Models with
electric
ignition only

8
Figure 4
LIGHTING THE BURNERS
Models without safety cut-off valves
In order to light the burner, you must:
Models without electric ignition:
1 – To light one of the gas burners, hold a flame (e.g. a match) close to the top
part of the burner, push in and turn the relative knob (fig. 3b) in an anti-
clockwise direction (fig. 4), pointing the knob indicator towards the large flame
symbol (i.e. max. gas flow).
2 – Adjust the burner according to the power required.
3 – To turn it off, turn the knob towards the right, up to the safety click.
Models with electric ignition incorporated into the knobs:
1 – Lightly press the knob fig. 3b in anti-clockwise direction (fig. 4) up to the maxi-
mum aperture (symbol ), push in and hold the knob; this will light the gas.
In the case of a mains failure light the burner with a match or lighted taper.
2 – Adjust the burner according to the power required.
3 – To turn it off, turn the knob towards the right, up to the safety click.
N.B. If your local gas supply makes
it difficult to light the burner with
the knob set to maximum, set the
knob to minimum and repeat the
operation.

9
LIGHTING THE BURNERS
Models fitted with safety cut-off valves
In order to light the burner, you must:
Models without electric ignition:
1 – To light one of the gas burners, hold a flame (e.g. a match) close to the top
part of the burner, push in and turn the relative knob (fig. 3a) in an anti-
clockwise direction (fig. 4), pointing the knob indicator towards the large flame
symbol (i.e. max. gas flow).
2 – Wait about ten seconds after the gas lighting before releasing the knob
(starting time for the valve).
3 – Adjust the gas valve to the desired power.
Models fitted with electric ignition incorporated into the knobs:
1 – Press in the corresponding knob and turn counter-clockwise (fig. 4) to the full
flame position marked by the symbol (fig. 3a) and hold the knob in until
the flame has been lit.
In the case of a mains failure light the burner with a match or lighted taper.
2 – Wait about ten seconds after the gas lighting before releasing the knob (starting
time for the valve).
3 – Adjust the gas valve to the desired power.
MODELS FITTED WITH SAFETY CUT-OFF VALVES
Important
If the burner flame should go out for some reason, the safety valve will automatically
stop the gas flow.
To re-light the burner, return the knob to the closed ●position, wait for at least 1
minute and then repeat the lighting procedure.
If your local gas supply makes it difficult to light the burner with the knob set to maxi-
mum, set the knob to minimum and repeat the operation.

10
PAN DIAMETER
BURNER MINIMUM MAXIMUM
Auxiliary 12 cm 14 cm
Semirapd 16 cm 24 cm(1)
Rapid 24 cm 26 cm
Triple-ring 26 cm 28 cm
Woks (2) max 36 cm
do not use pans with concave or convex bases
(1) front right burner, maximum diameter 22 cm.
(2) Models with triple-ring burner and with wok pan adapter supplied: wok pans have to
be used only with the special grille fitted (see correct use of triple-ring burner).
CHOICE OF BURNER
The symbols printed on the panel by the side of the knob indicate which burner you
are controlling.
Choose a suitable burner depending on the cookware diameter and capacity.
The pan diameter should be suitable for the burner power to make the most of the
burner's high efficiency and not waste fuel.
A small pan does not boil more quickly on a large burner (fig. 5).
Attention: During use the hob becomes very hot under the cooking zones.
Keep children away.
Figure 5

11
WRONG CORRECT
Figure 6a Figure 6b
CORRECT USE OF TRIPLE-RING BURNER
✓The flat-bottomed pans are to be placed directly onto the pan-support.
✓To use the WOK you need to place the proper stand (supplied with some models
only) in order to avoid any faulty operation of the triple-ring burner (Fig. 6a).
IMPORTANT:
The special grille for wok pans (supplied with some models only) (fig. 6b) MUST BE
PLACED ONLY over the pan-rest for the triple-ring burner.

12
GENERAL TIPS
✓Before cleaning the hob switch it off and wait for it to cool down.
✓Clean with a cloth, hot water and soap or liquid detergent.
✓Do not use products which are abrasive, corrosive or chlorine based.
✓Do not use steel pads.
✓Do not leave acid or alkaline substances (vinegar, salt, lemon juice, etc.) on the
hob.
✓Do not use steam jet cleaners because the humidity could infiltrate into
the appliance making it dangerous.
✓WARNING: When correctly installed, your product meets all safety requirements
laid down for this type of product category. However special care should be taken
around the underneath of the appliance as this area is not designed or intended
to be touched and may contain sharp or rough edges, that may cause injury.
ENAMELLED PARTS
✓All the enamelled parts must be washed only with a sponge with soapy water or
other non-abrasive products.
✓Dry preferably with a soft cloth.
✓If acid substances such as lemon juice, tomato conserve, vinegar etc. are left on
the enamel for a long time they will etch it, making it opaque.
STAINLESS STEEL SURFACES
✓Stainless steel parts should be rinsed with water and dried with a microfibre or
soft cloth.
✓For persistent dirt, use specific non-abrasive products available commercially or a
little hot vinegar.
✓Note: regular use will cause discolouring around the burners, because of the high
flame temperature.
Cleaning and Maintenance

13
BURNERS AND GRIDS
✓These parts can be removed and cleaned with appropriate products.
✓After cleaning, the burners and their flame spreaders must be well dried and correct-
ly replaced.
✓It is very important to check that the burner flame spreader and the cap have been
correctly positioned. Failure to do so can cause serious problems.
✓In appliances with electric ignition, check that the electrode “S” (fig. 7) is always
clean to ensure trouble-free sparking.
✓In the models with safety device, check that the probe “T” (fig. 7) next to each burn-
er is always clean to ensure correct operation of the safety valves.
✓Both the probe and ignition plug must be very carefully cleaned.
✓Note: To avoid damage to the electric ignition do not use it when the
burners are not in place.
GAS TAPS
✓Regular lubrication of the gas taps must only be performed by specialised engineers.
✓If the gas taps are not working properly call the After-Sales Service.
CONTROL KNOBS
✓The control knobs may be removed for cleaning but care should be taken not to
damage the seal.

14
Figure 7 Figure 8
F
C
Probe "T" -
models with
safety cut-off
valves only
Electrode "S" -
models with
electric ignition
only
CORRECT POSITIONING OF THE BURNERS
✓It is very important to check that the burner flame spreader “F” and the cap “C” have
been correctly positioned (see figs. 7 and 8).
Failure to do so can cause serious problems.

15
Figure 9
CORRECT POSITION OF TRIPLE RING BURNER
The triple ring burner must be correctly positioned (see fig. 9); the burner ribs must be
fitted in their housing as shown by the arrow.
The burner correctly positioned must not rotate (fig. 10).
Then position the cap Aand the ring B (figs. 10 - 11).
AB
Figure 10
Figure 11

16
Tips for installation
Location
✓The appliance may be installed in a kitchen, Kitchen/diner or a bed sitting room, but
not in a room or space containing a bath or a shower.
✓The appliance must not be installed in a bed-sitting room of less than 20 m3.
✓The appliance is designed and approved for domestic use only and should not be
installed in a commercial, semi commercial or communal environment.
✓Your product will not be guaranteed if installed in any of the above environments
and could affect any third party or public liability insurances you may have.
✓This hob should only be installed by a qualified installer.
Failure to observe this rule leads to cancellation of the guarantee.
✓The appliance must be installed correctly, in compliance with the regulations in force
and following the manufacturer's instructions.
✓Any repair or maintenance must be performed with the appliance switched off.
✓These appliances have been designed and manufactured to be fitted into heat-resis-
tant units.
✓These hobs are designed to be fitted into 600 mm deep kitchen units.
✓The unit walls must not be higher than the working surface and must withstand a
temperature of 75°C more than room temperature.
✓Avoid installation near inflammable materials (e.g. curtains).

17
TECHNICAL INFORMATION
FOR THE INSTALLER
In order to install the cooktop into the
kitchen fixture, a hole with the dimen-
sions shown in fig. 13 has to be made,
bearing in mind the following:
✓within the unit, between the bottom
of the cooktop and the upper sur-
face of a shelf there must be a clear-
ance of at least 30 mm.
It is absolutely essential that you
place a separator between the base
of the cooktop and the built-in unit
or the oven;
✓the cooktop must be kept no less
than 200 mm away from any side
wall (fig. 13).
✓the hob must be installed at least 60
mm from the wall.
48060
0
–2
560
200 0
–2
680
500
650 mm
450 mm
INSTALLATION IN KITCHEN
CABINET WITH DOOR (fig. 14)
It is recommended that a 30 mm clear-
ance be left between the cooktop and
the fixture surface (fig. 14).
;;
;
;;
;
;
;
;
@
@
@
@








;
;
;
;
@
@
@
@








;
;
;
;
@
@
@
@








;
;
;
;
@
@
@
@








;
;
;
;
@
@
@
@








;
;
;
;
@
@
@
@








;
;
;
;
@
@
@
@








;
;
;
;
@
@
@
@








;
;
;
;
@
@
@
@








;
;
;
;
@
@
@
@








;
;
;
;
@
@
@
@








;
;
;
;
@
@
@
@








;
;
;
;
@
@
@
@








;
;
;
;
@
@
@
@








;
;
;
;
@
@
@
@








;
;
;
;
@
@
@
@








;
;
;
;
@
@
@
@








;
;
;
;
@
@
@
@








;
;
;
;
@
@
@
@








;
;
;
;
@
@
@
@








;
;
;
;
@
@
@
@








;
;
;
;
@
@
@
@








;
;
;
;
@
@
@
@








;
;
;
;
;;;;;;;
;;;;;
;;;;;
30 mm
Space for
connections
Clearance
Door
Figure 12
Figure 14
Figure 13
✓there must be a dis-
tance of at least
650 mm between
the hob and any
wall cupboard or
extractor hood posi-
tioned immediately
above (see fig. 12).
✓if the hob is installed over a built-in
oven, there must be a distance of at
least 30 mm between the two appli-
ances. The two appliances should be
connected to the gas supply with
independent connections.

18
APPLYING THE SEALS
✓Turn the cooktop upside down.
✓Spread the longer seal “A” around the left, rear and right sides as shown in figure
15a.
✓With a cutter or a scissors cut the excess seal “C” and retain it for next use (figure
15b).
✓Spread the seal “B” around the left, front and right edges of the cooktop as shown in
figure 15c.
✓Spread the seal “C” along the rear edge of the cooktop as shown in figure 15d.
Making sure that the beginning and the end overlap at the seal “B” (see figure 15e).
fig. 15a fig. 15b fig. 15c fig. 15d
fig. 15e
Front side
Rear side
seal A
seal C
seal A
seal C seal B
seal C
seal B
Figures 15

19
FASTENING THE INSTALLA-
TION BRACKETS
Each cooktop is provided with an instal-
lation kit including brackets and screws
for fastening the top to fixture panels
from 2 to 4 cm thick.
✓Turn the cooktop upside down and
fasten the brackets “Fand R” to the
appropriate socket holes, without
tightening the screws “B” for the
moment.
✓Make sure that the brackets are fas-
tened as shown in figures 16a, 16b
and 16c.
FASTENING THE COOKTOP
✓Insert the cooktop into the hole and
position it correctly.
✓Adjust the position of the brackets “F
and R” and tighten screws “B” to
block the cooktop firmly in position.
✓With a sharp cutter or trimmer knife
trim the excess sealing material
around the edge of the cooktop.
Take care not to damage the work-
bench.
Rear side Front side
20 mm min. 40 mm max.
B
seal A
F
F
F
R
R
20 mm min. 40 mm max.
B
seal
C
seal A
R
FRONT
fig. 16a
fig. 16b fig. 16c
Figures 16

20
Ventilation requirements
✓The appliance should be installed into a room or space with an air supply in accor-
dance with BS 5440-2: 2000.
✓For rooms with a volume of less than 5 m3- permanent ventilation of 100 cm2free
area will be required.
✓For rooms with a volume of between 5 m3and 10 m3a permanent ventilation of
50 cm2free area will be required unless the room has a door which opens directly to
the outside air in which case no permanent ventilation is required.
✓For rooms with a volume greater than 10 m3- no permanent ventilation is required.
NB. Regardless of room size, all rooms containing the appliance must
have direct access to the outside air via an openable window or
equivalent.
✓Where there are other fuel burning appliances in the same room, BS 5440-2: 2000
should be consulted to determine the correct amount of free area ventilation require-
ments.
✓The above requirements allow also for use of a gas oven and grill but if there are
other gas burning appliances in the same room, consult a qualified engineer.
