CDA HCN510 Reference manual

1
Customer Care Department • The Group Ltd. • Harby Road • Langar • Nottinghamshire • NG13 9HY
T: 01949 862 012 F: 01949 862 003 E: [email protected] W: www.cda.eu
Passionate about style
HCN510 Induction Hob
Manual for Installation, Use and Maintenance
IMPORTANT: PLEASE REFER TO PAGE 13 FOR INFORMATION ON
CONFIGURING THE POWER CONSUMPTION MODE CORRECTLY. THE HOB
MUST BE CONFIGURED AT FIRST SWITCH ON.

2
Important
The CDA Group Ltd cannot be held responsible for injuries or losses caused by incorrect use or installation of this product. Please
note that CDA reserve the right to invalidate the guarantee supplied with this product following incorrect installation or misuse
of the appliance or use in a commercial environment.
This appliance is not designed to be used by people (including children) with reduced physical, sensorial or mental capacity, or
who lack experience or knowledge about it, unless they have had supervision or instructions on how to use the appliance by
someone who is responsible for their safety.
Under no circumstances should any external covers be removed for servicing or maintenance except by suitably qualified
personnel.
Appliance information:
Please enter the details on the appliance rating plate below for reference, to assist CDA Customer Care in the event of a fault with
your appliance and to register your appliance for guarantee purposes.
Appliance Model
Serial Number
CE Declarations of Conformity
This appliance has been manufactured to the strictest standards and complies with all applicable legislation, including Electrical
safety (LVD) 2006/95/EC and Electromagnetic interference compatibility (EMC) 2004/108/EC. Parts intended to come into
contact with food conform to 89/109/EC.
IMPORTANT INFORMATION FOR CORRECT DISPOSAL OF THE PRODUCT IN ACCORDANCE WITH EC DIRECTIVE
2002/96/EC.
At the end of its working life, the product must be taken to a special local authority waste collection centre or to a dealer
providing appliance recycling services.
Disposing of a household appliance separately avoids possible negative consequences for the environment and health. It also
enables the constituent materials to be recovered, saving both energy and resources. As a reminder of the need to dispose of
household appliances separately, the product is marked with a crossed-out wheeled dustbin.
Please note:
•Induction hobs become hot and remain hot during and immediately after use. Do not touch the hob until it has
been allowed to cool.
•Keep children away from the appliance when in use.
•Never use the hob top for storage.
•Pan handles should never stand out beyond the edge of the worktop. This will ensure children cannot reach them.
•Do not lean over the hob when it is in use.
•Follow the cleaning instructions carefully.
•Ensure the base of the saucepan is clean and dry before placing it on the hob.
•Avoid hard shocks from cookware – the vitroceramic glass surface is highly resistant but not unbreakable.
•Do not place hot lids flat on the hob top. A “suction” effect could cause damage to the hob.
•Do not drag cookware across the hob top: in the long term, this could cause damage to the hob.
•Do not store cleaning or flammable products in the unit below the hob.

3
•Always use appropriate cookware.
•Do not cook unopened tins of food directly on the hob.
•Never put cooking foil or plastic materials on the ceramic surface when the hob is hot. These materials could melt and cause
damage to the hob.
•This hob (Class 3) has been designed for use only as a cooking appliance. Any other use should be considered incorrect and
therefore dangerous.
FOR THOSE WITH HEART PACEMAKERS OR ACTIVE IMPLANTS:
The function of this hob conforms to current electromagnetic interference standards and thus is in total compliance with legal
requirements (2004/108/CE directives).
To avoid interference between your hob and a pacemaker, your pacemaker must be designed and programmed in compliance
with the regulations that apply to it. As such, CDA guarantee only that our product is compliant.
With regard to the compliance of the pacemaker or any potential incompatibility, you should obtain information from the
manufacturer or your attending physician.
Important
•Do not use the hob if the glass surface is cracked or damaged to prevent the risk of electric shock. Disconnect it from the
power supply.
•Ensure that the power cable of a connected electrical appliance near the hob is not in contact with the cooking zones.
Important: Please refer to page 13 for information on configuring the power consumption mode correctly. The hob
must be configured at first switch on.
Cooking on Induction
The principle of induction cooking is based on magnetic effect.
When you put your cookware on an induction zone and switch it on, the electronic boards in the hob produce induced currents in
the base of the cookware and instantly raise its temperature. This heat is then transferred to the food inside the cookware.
The best cookware to use with induction cooking has thick flat bases, as the heat will be better distributed so cooking
more evenly.
Most cookware is compatible with induction cooking. There are three ways to check the suitability of your cookware:
1. Using a magnet to see if the base of the pan is magnetic: if three magnet sticks, then the cookware is compatible.
2. Place the pan on one of the cooking zones switched on to power level 4: if the display remains on, then the cookware is
compatible. If the display flashes, the cookware cannot be used on an induction hob.
3. Check the instructions or packaging of the pans for the symbols indicating suitability for use with induction.

4
Using your Hob
The table below offers guidance as to what each power level is for.
Power level Type of cooking
0 Switched off
1/2 For melting (butter/chocolate) or keeping food warm
2/3 Keeping food hot or to heat small quantities of liquid
3/4 Heat larger quantities of liquid (sauces etc.)
4/5 Slow boiling, e.g spaghetti, soups, stews, potatoes
6/7 Gentle frying
7/8 Browning meats, frying fish, omelettes
9 Fast frying steaks
Fig.1
2
1
4
3
Zones:
1. Front left 1.8 kW 210 mm
2. Back left 1.2 kW 145 mm
3. Back right 1.8 kW 210 mm
4. Front right 1.2 kW 145 mm
5
Control panel:
5. Power key
6. Timer keys
7. Childlock key
8. Zone power level keys
9. Zone displays
6 7 98

5
Using your Hob
To switch the hob on
To switch the power on, touch and hold the for approximately two seconds. The hob will beep and all four zone displays will
show zero.
Please note: If a power level is not set within ten seconds, the hob will switch off automatically.
To set the power level
There are power keys for each individual zone which allow you to set the power level by touching the or keys for the zone
required.
To increase the power level from 1 (minimum) to 9 (maximum), touch the key
To go straight to power level 9, touch the key when the zone display shows 0.
To turn the power off
To switch off a single zone, touch the and keys for the zone no longer required. This will set the power level to zero.
Alternatively, touch the key until the zone display shows zero. When all the zones are at zero, the hob will switch off
automatically after approximately ten seconds.
Alternatively, to switch off the hob immediately, touch and hold for approximately two seconds.
Booster
The hob is equipped with a booster function, allowing a higher power level than the maximum for approximately ten minutes. To
turn on the booster function, touch the key when the power level is already set at 9. Pwill show in the display. To cancel the
booster at any time, touch the key to return to power level 9.
Timer
The hob is equipped with a timer that allows a finish time to be set for the end of cooking on any zone, between a minimum of
one minute and a maximum of 99 minutes. This timer can be used only one zone at a time.
To set the timer
First switch on the hob.
Touch either the or keys. The timer display will show 00 and the zone displays will flash t.
Set the power level for the zone requiring the timer by touching the or minus keys for the required zone. The timer indicator
LED will illuminate on the zone to confirm the timer is selected.
Set the required duration using the or keys within five seconds. Touching the key will go straight to the maximum 99
minutes. Touch and hold the or keys to scroll through the duration quickly.
After approximately five seconds, the LED and the timer display will stop flashing and the countdown will start. The timer display
will show the minutes remaining until the last minute, when it will show the seconds remaining.
At the end of the timer, the selected zone will switch off and the timer display and the zone timer LED will flash. The hob will
beep for approximately one minute. To switch off the beep and the flashing displays, touch any key.
To cancel the timer
Touch the or keys together.
Please note: Cancelling the timer will not switch off the zone. You should switch the zone off manually if required.
Please note: the power level can be adjusted during the countdown using the or keys.

6
Childlock
The hob is equipped with a childlock to lock the controls. This can be used when the hob is off or during cooking.
To switch on the childlock
Touch the key for approximately two seconds until the LED above the childlock key illuminates and the hob beeps to confirm
the childlock is switched on.
To turn off the childlock
Touch the key for approximately two seconds until the LED above the childlock key switches off and the hob beeps to confirm
the childlock is switched on.
Use of the childlock when the hob is off
The childlock LED is illuminated to show the childlock is on.
Use of the childlock when the hob is in use
The childlock LED is illuminated to confirm that childlock is switched on and no adjustments can be made to any of the zones or
the timer.
It is possible to switch off the hob using the key when the childlock is on for safety reasons.
Please note:
The childlock is switched on automatically when the hob is first connected to the power. You must switch off the childlock to be
able to configure and use the hob.
Residual heat indicators
The hob is equipped with residual heat indicators to warn when any of the zones are still hot to the touch after cooking. An Hwill
show in the relevant zone display after cooking until the zone is at a safe temperature to touch.
In the event of a power cut, the residual heat indictors will illuminate after the power supply is restored. However, when there is
no power supply to the hob the residual heat indicators will not work, so extra care must be taken.
Please note:
You should avoid touching the zones when the hob is in use, or when an His showing on the zone display.
Small object safety
Anything left on the control panel (e.g. cutlery or towels) will cause the hob to switch off automatically and there will be a beep
every ten seconds until the obstruction is removed.
Temperature limiter
The hob is equipped with a temperature limiting sensor that will switch off the zone and show Calternating with the power level
in the zone display until the hob temperature is within the limits preset.
Pan detection
The hob is equipped with a sensor that will advise when the pan is removed from the zone, or is unsuitable for use on induction
hobs. The zone display will show Ualternating with the power level until a suitable pan is placed on the zone. The zone will
switch off after approximately one minute if no suitable pan is placed on the zone.

7
Efficient Use of your Hob
The hob is equipped with zones of different sizes, designed to accommodate most shapes and sizes of pan. For best results, only
use pans with flat bottoms and choose an appropriate zone depending on the size of the pan. The most efficient use of the hob is
shown below, where the pan and zone are correctly chosen.
Use pan lids where possible to minimize the energy usage of your appliance.
It is very important that the pans used on the hob are made of a suitable material and have the correct type of base. The base of
the pan must be clean before use to prevent any scratches on the hob top.
Zone Size
160mm
180mm
210mm
Maximum Pan Size (cm)
18
22
24
Minimum Pan Size (cm)
10
12
18
Fig.2

8
Care and Maintenance
Always disconnect the appliance from the power supply before undertaking any cleaning or maintenance.
Important:
•Steam cleaners must not be used when cleaning this appliance.
•You should use a non-abrasive cleaner to clean the hob top. Any abrasive cleaner (including Cif) will scratch the surface and
could erase the control panel markings.
•Sugar and starch can cause permanent damage to the surface of the hob. Wipe away any spillages immediatly.
If your hob is not working:
1. Check that the zone is switched on.
2. Check that the mains supply has not been switched off.
3. Check that the fuse in the spur has not blown.
4. Check the hob is configured correctly (see page 13)
In the event of a fault with the hob, please advise CDA Customer Care of any fault code shown on the display
Contact CDA Customer Care
A : Customer Care Department, The CDA Group Ltd, Harby Road, Langar, Nottinghamshire, NG13 9HY
T : 01949 862 012 F : 01949 862 003 E : [email protected] W : www.cda.eu
Types of residues Clean with Cleaning advice
Light Cleaning sponge and soft cloth Wipe over the zone to be cleaned with a sponge and hot
water, and then wipe off with a soft dry cloth.
Accumulated baked-on stains/
dirt, sugar spills or melted plastics Cleaning sponge or glass scraper and soft cloth
Wipe over the zone to be cleaned with a sponge and hot
water, using a ceramic scraper to remove any large marks
or stains and then wipe off with a soft dry cloth.
Rings and hard water residues White vinegar and soft cloth Pour a small amount of warm white vinegar onto the stain,
leave it to stand, and then wipe off with a soft dry cloth.
Shiny metallic streaks Cleaning agent for vitroceramic glass etc.) Slow boiling, e.g.
spaghetti, soups, stews, potatoes
Use specialist vitroceramic glass cleaner (preferably one
with silicone for its protective properties)
9 fast frying steaks

9
You observe that Possible Causes What should you do?
The display shows a series of digits and
symbols on first connection Working normally Nothing, the hob will be ready to use within approximately 10 seconds
Installation blows a fuse or
only one side of the hob works The electrical connection of the hob is incorrect Check that it is set up properly (see the Electrical Connection section)
The hob produces an odour during the
first cooking sessions New appliance Heat a saucepan full of water on each cooking zone for 30 minutes
9 fast frying steaks
Troubleshooting
On first use
IMPORTANT - PLEASE NOTE: In the event of any breakage, crack or cracking – even minimal – of the vitroceramic glass, im-
mediately disconnect your appliance to prevent a risk of electric shock and contact CDA Customer Care.
In use
You observe that Possible Causes What should you do?
The hob has stopped operating. The
hob beeps at approximately ten second
intervals
There was an overflow or an object is in
contact with the control panel Clean the hob or remove the object, and begin cooking again
Cshows on the zone display The temperature limiter sensor has been
activated Allow the zone time to cool down.
Uflashes on the zone display
The cookware used is not suitable
for induction or is less than 12 cm in
diameter (10 cm on the 16 cm zone)
See page 3 for information on cooking
on induction
The saucepans make noise
during cooking or your hob makes a
clicking sound during cooking
This is normal with some types of
cookware. This is caused by the transfer
of energy from the hob to the cookware
Nothing. There is no risk, neither to your
hob nor to your cookware
The fan continues to function for a few
minutes after the hob is turned off Cooling of the electronic components.
Working normally Nothing.
The hob keeps blowing the mains fuse This is most likely to be caused by an
incorrect power configuration setting
Refer to the instructions on configuring
your hob (page 13)
9 fast frying steaks
You observe that Possible Causes What should you do?
The hob does not work and the lights on
the control panel do not switch on The hob is not connected to the power supply or the power supply is faulty Check the electrical circuit breaker and fuses
The hob is not working and the display
shows a non-standard graphic The electronics are not functioning correctly Call CDA Customer Care
The hob is not working and the childlock
LED is on The childlock is on Switch off the childlock before trying to use the hob.
9 fast frying steaks
On switching on

10
Fitting the Hob
Unpacking the hob:
Take care not to lose or mishandle any parts.
Fitting position of the hob:
This appliance must be installed a minimum of 50mm from any back wall and a minimum of 180mm away from any adjacent vertical
surfaces, e.g. a tall cupboard end panel. This may be reduced to 100mm if the adjacent surface is resistant to fire (tiles or steel, for
example). These dimensions are shown in Fig.6.
Ventilation requirements:
This appliance must be installed to allow air to flow freely to the air intake and from the air outlet. Failure to allow sufficient ventilation
could cause damage to the hob and constitutes incorrect installation, which is not covered by the warranty.
If fitting a cooker hood above the hob:
If a cooker hood is to be installed above the hob, the height of the hood above the hob must be at least 600mm (650mm is
recommended) (Fig.5). If the instructions supplied with the hood dictate that the hood must be installed at a height greater than
600mm, then that height is the minimum required.
Wall furniture requirements:
The minimum height of any cabinet immediately above the hob is 900mm. The minimum height of any adjacent units (including light
pelmets) is 400mm, unless they are manufactured from a material resistant to fire (steel, for example)
Notes:
• Do not position this appliance above a refrigeration unit. The heat generated may cause the refrigeration unit to fail.
• This appliance is designed to be installed into cabinet units capable of withstanding temperatures of 65°C or greater above
ambient temperature.
• Never place perishable foods, cleaning products or ammable items in the cupboard below the appliance.
• If an oven is to be installed below the hob, the thermal safety system on the hob will not allow the hob to be used at the same time
as a pyrolytic programme on the oven.
• The hob is equipped with an anti-overheating safety device that can be activated if the hob is installed over an oven that is not
sufficiently ventilated. In the event that this occurs, the zone display will show C. We recommend that you increase the ventilation
of the hob by creating an opening in the side of the cabinet (8 cm x 5 cm).
• Ensure that the top rail is removed prior to installation, and that no unit cross member is blocking the air outlets.
• If the hob is to be located above a working drawer, we recommend that the drawer is not used for storing soft items, for example
dusters or towels; this is to minimize the risk of the cooling system air intakes being obstructed.
If there are no vents provided in the plinth run, then a vent should be provided to ensure there is enough free air available for ventilation.

11
How to install the hob:
Overall dimensions of the hob:
Width: 580 mm Depth: 510 mm
Worktop cut-out dimensions:
Width: 560 mm Depth: 490 mm
1. Make the required hole in the worktop. Before doing this, you must check the instructions supplied with any cooker hood
to ensure that you will have the required clearance. The cut-out (Fig.5) shows a 60mm gap from the wall to the cut-out edge.
The distance from the hob, when fitted, to the back wall is 50mm.
If a splashback/worktop upstand is to be fitted, take this into account when cutting the hole. The minimum distance that the
hob should be positioned away from the rear wall or splashback is 50mm.
2. Fix the foam seal underneath the appliance by following the outline of the worktop upon which the hob will rest
This ensures an airtight seal with the worktop. Do not use silicone type sealant.
Fig.3 Fig.4
400mm
600mm
Fig.5
40
40
60
40
A
ventilation
space
510
580/770
490
560 / 750
64
580
560 50
50
600mm minimum
(650mm recommended)
50mm
25mm
500 x 10
50mm
6mm

12
Power configuration
This hob can be connected to a 13, 16, 25 or 32amp supply and configured to work on any of these power settings.
If the hob is connected to a 32amp supply all four zones can be used on the maximum setting with boost at the same time. If
however, the hob is connected and configured to a 13amp supply and all four zones are selected at the same time the hob will
limit the maximum power consumed so that the 2.8kW power supply cannot be exceeded.
To configure the hob (at first switch on)
1. Touch the to switch off the childlock.
2. Touch the plus and minus keys for the front left and right zones simultaneously
3. Touch the front left zone plus key to cycle through the options. The displays will show:
Front left zone display Timer display Front right zone display Power level
4. Touch the plus and minus keys for the front left and right zones simultaneously to confirm the setting.
All displays will show 8and then switch off. The childlock will be switched back on automatically, and the hob is now configured
ready for use.
Left Right Power Settings
2 PO 8 2.8 kW
3 PO 5 3.5 kW
6 PO 0 6.0 kW
7 PO 2 7.2 kW

13
Mains Electricity Connection
Warning! this appliance must be earthed
We recommend that the appliance is connected by a qualified electrician, who is a member of the N.I.C.E.I.C. and who will comply
with the I.E.E. and local regulations.
This hob is intended to be connected to permanent, fixing wiring and dependent on the power configuration is intended to be
connected to a 13A supply or connected via a 13A plug. The table below shows the recommended size of cable and the fuse that
will be required for each power configuration mode.
Power configuration mode Mains cable size (CSA, mm2) Fuse protection required
2.8kW 1.5 13
3.5kW 1.5 16
6.0kW 2.5 - 4.0 25
7.2kW 2.5 - 4.0 32
The following diagram shows the main connection terminal block: (use the diagram from the HCC561 manual)
Terminal connections:
1&2: Live (linked)
4: Neutral
: Earth
2.8kW mode
When the hob is configured in 2.8kW mode it can be connected via a
standard 13A switched fused spur.
3.5kW-7.2kW modes
When configured in any mode other the 2.8kW, the hob should be installed
into a dedicated cooker outlet and protected by the size of fuse shown in the
table above.
This appliance is intended to be connected to fixed wiring by a double pole
switch, having a contact separation of at least 3mm in all poles. The switch
must be positioned no further than 2m from the appliance.
Please note:
The mains cable must only be replaced by a qualified electrician or service engineer and be of a cross sectional area appropriate
for the power configuration mode of the hob, as shown in the table above.
The marking of the current rating of the fuse or circuit breaker protecting this appliance should be marked on the socket outlet.
Assembly and electrical connection should be carried out by specialised personnel.
When installing this product we recommend you seek the help of another individual.
Ensure that the brass links are securely fitted. Failure to do so will prevent the hob from operating correctly.
Any service call arising from incorrect installation may result in a charge.
Fig.6

14

15

16
Customer Care Department • The Group Ltd. • Harby Road • Langar • Nottinghamshire • NG13 9HY
T: 01949 862 012 F: 01949 862 003 E: [email protected] W: www.cda.eu
Passionate about style
To contact our Customer Care Department, or for Service,
please contact us on the details below.
