CE Tech 5535 User manual

Installation: Speaker Volume Control
Distributed by: Home Depot U.S.A., Inc.
2455 Paces Ferry Rd., NE, Atlanta, GA 30339
For assistance, call: 1-800-394-7519
HOMEDEPOT.COM
Item #1000015586
Model #5535
Visual Installation Guide
Speaker Volume Control
Insert the wire from the amplier into the “FROM AMP” positions
of the connector block. Connect speaker wires to the “TO SPEAKER”
positions of the Speaker Volume Control and tighten screws to hold
in place
.
Select location for the Speaker Volume Control Cut speaker wire
1.
4.
2.
Strip and remove wire insulation (approx. 1/4”)
3.
Page 1 of 2

Installation: Speaker Volume Control (continued)
Distributed by: Home Depot U.S.A., Inc.
2455 Paces Ferry Rd., NE, Atlanta, GA 30339
For assistance, call: 1-800-394-7519
HOMEDEPOT.COM
Item #1000015586
Model #5535
Visual Installation Guide
Speaker Volume Control (continued)
Complete installation by screwing down the cover place.
Wires connected to Connector Block Install the spaeker volume control in it’s predetermined location
ensuring that it is facing upwards.
5.
8.
6.
Screw onto the low voltage mounting bracket
7.
Page 2 of 2
