Cecilware JAVA 2-QB User manual

P
a
g
e
2
INSTALLATION
Water Inlet Connection:
ThisequipmentistobeinstalledtocomplywiththeapplicableFederal,State,orlocalplumbingcodeshavingjurisdiction. In
addition:
1. A quick disconnect water connection or enough extra coiled tubing (at least 2 times the depth of the unit) so that the
machine can be moved for cleaning underneath.
2.Anapprovedbackflowpreventiondevice,suchasadoublecheckvalvetobeinstalledbetweenthemachineandthewater
supply.
The JAVA2-QB is equipped with a 1/4" Flare Water Inlet Fitting, located behind the unit near the bottom.
HIGHLY RECOMMENDED:
AWATERSHUT-OFFVALVEandAWATERFILTER,preferablyacombinationCharcoal/PhosphateFilter,toremoveodorsand
inhibit lime and scalebuildupinthemachine. Note: Inareaswithextremelyhardwater,awatersoftenermustbeinstalled
in order to prevent a malfunctioning of the equipment and in order not to void the warranty.
STARTUP PROCEDURE
Caution: Make sure that the Heater Switch, located behind unit near the bottom, is in the OFF
(toggle down) position.
1. Connect the 1/4" Dia. copper waterline to the 1/4" flare water inlet fitting of the valve.
2. Connect the power cord into a proper receptacle.
3. Activate the Power Switch(Toggle Up). Thetank will start filling. Allow approximately 5 minutesforthetanktofill.
4. Activate the HeaterSwitch.Allow approximately20-45 minutesfor thewater toreacha presettemperature of 200°F.
The heat up time will depend on the water inlet temperature, the inputvoltage,andthewattageoftheelementsinthe
machine.
5. Placecupundernozzleandpressdispenseswitch,buttonwilllight whiledispensing. Themachine willdispense waterat
the rate of 1.3 oz. per second.
Repeat it several times for each dispense switch to check for consistent output.
6. While the tank is heating up, remove the hoppers, load them with products and reposition them back in the machine.
NOTE: Carrier capacity is 1 ½ Gallons.
Machine is factory set to brew 1 Gallon of coffee at a time.
When volume drops below ½ Gallon, another 1 Gallon of coffee
can be safely brewed without overfilling.

Page 3
PROGRAMMING FOR AUTOMATIC DISPENSE
(See Door diagram)
1. Turn Power Switch ON (toggle switch inside door).
2. PRESS and HOLD [red] STOP Button with one hand.
3. PRESS and HOLD [green] DISPENSE Button with other hand.
4. RELEASE [red] STOP Button ONLY.
5. Continue to HOLD [green] DISPENSE Button for 5 SECONDS,
then RELEASE.
6. PRESS and RELEASE [green] DISPENSE Button.
Product begins dispensing.
When it reaches the “DESIRED VOLUME”,
7. PRESS and RELEASE [green] DISPENSE Button to
SET “DESIRED VOLUME”.
DISPENSE Button can be jogged to top off.
8. PRESS and RELEASE [red] STOP Button to LOCK IN
“DESIRED VOLUME”.
Repeat steps 1 to 8 for each Dispense Button.
The Automatic Dispense Buttons are factory programmed to dispense
1.3 oz. of water per second.
PRODUCT STRENGTH ADJUSTMENTS:
The JAVA 2-QB units have variable speed control auger
motors with variable speed of 10 to 90 RPM].
Drink or Product Strength can be changed by adjusting the
Gram Throw Dial on inside door panel.
The Gram Throw is factory preset at approx. 2.2 gr. per 8 oz.
cup for the JAVA 2-QB machines.
The water flow rate adjustment for the dispense valve
should remain fixed at 1.3 oz per sec.
POWER SWITCH RINSE SWITCH
STOP BUTTON
DISPENSE BUTTON
DRINK STRENGTH KNOBS
READY LIGHT HEATING LIGHT

P
a
g
e
4
CLEANING AND SANITIZING:
SANITIZING: All food dispensing units should be sanitized periodically. All parts to be sanitized must be cleaned first.
To prepare a sanitizing solution: ADD 2 TSP. OF LIQUID CLOROX BLEACH (5.25% CONCENTRATION) TO 1 GALLON OF
WATER AT ROOM TEMPERATURE (70°F -90°F).
Soak all parts for a minimum of 3 min. in the sanitizing solution. Note: Always start with an unopened bottle of Clorox
Bleach since the solution from an opened bottle has a short life span.
Let all sanitized parts drain and dry naturally. DO NOT WIPE THEM DRY. Before using the sanitized unit (or parts) with
foodstuffs, rinse all parts thoroughly with water.
CARE FOR STAINLESS STEEL:
STAINLESS STEEL surfaces, that comes in contact with food substances, MUST BE CLEANED EVERY DAY.
WHEN CLEANING STAINLESS STEEL, ONLY A PH NEUTRAL CLEANER IS TO BE USED.
Use nylon or brass brushes (not steel wire brushes) for removing food deposit.
Many food products contain acids, alkalis, or other substances, which corrode Stainless Steel.
RECOMMENDED DAILY CLEANING AND MAINTENANCE
1. Empty drip tray and wash with dish detergent.
Rinse Chamber:
Flip Toggle SWITCH to RINSE position and press DISPENSE BUTTON. When done, flip toggle switch to SERVE position.
Remove and refill Hopper.
Note: Turn PRODUCT GUIDE UP to reduce spillage. Return to down position
when re-inserting hopper
CLEAN HOPPER (once a week)
1. Turn the product guide up, and remove hopper.
2. Empty out Hopper.
3. Pull off Product Guide.
4. Wash parts with dish detergent.
5. Rinse, dry, and re-assemble parts.
CLEAN DISPENSE CHAMBER (once a week)
1. Twist CW and pull off STEAM DEFLECTOR.
2. Pull off DISPENSE CHAMBER.
3. Wash components with dish detergent.
4. Rinse, dry, and re-assemble parts.

N
BLK
L1
N
4
2
3
1
3
1
4
2
COFFEE DECAFF
DISPENSE
VALVE
TEACH-ME
TIMER TEACH-ME TIMER
SPEED
CONTROL
D.C.
AUGER
MOTOR
SPEED
CONTROL
D.C.
AUGER
MOTOR
WATER INLET
VALVE
VACUUMFAN
THERMOSTAT HEATERSWHI-LIMIT
MAIN UNIT DOOR UNIT
CONTACTOR
READY
HEATING
NL1L2
TERMINAL
BLOCK
POWER
1 PHASE:
1. USEAPPROPRIATELINECORD5-15PFORU.S.A.
2. USEAPPROPRIATELINECORD5-20PFORCANADA.
"A"
"B""C"
"D"
RINSE
SWITCH
RED WIRE
STOP SWITCH
WARMER
100W
3PIN
CONNECTOR
WATERLEVEL
PROBES
LIQUID LEVEL CONTROL
WATER
RED
WHT
BLU
YEL
GRN

N
BLK
L1
N
4
2
3
1
3
1
4
2
COFFEE DECAFF
DISPENSE
VALVE
TEACH-ME
TIMER TEACH-ME TIMER
SPEED
CONTROL
D.C.
AUGER
MOTOR
SPEED
CONTROL
D.C.
AUGER
MOTOR
WATER INLET
VALVE
VACUUMFAN
THERMOSTAT
HI-LIMIT
MAIN UNIT DOOR UNIT
NL1
TERMINAL
BLOCK
POWER
RINSE
SWITCH
STOP SWITCH
WARMER
100W
3PIN
CONNECTOR
WATERLEVEL
PROBES
LIQUID LEVEL CONTROL
WATER
RED
WHT
BLU
YEL
GRN
READY
HEATERSW
HEATING

CARRIERCONVERSION KIT# SK79Q
FOR MODELS ORIGINALLY EQUIPPED
WITH AIRPOT DISPENSER
TO CONVERT TO CAR-1 CARRIER DISPENSER:
1. Disconnect Electrical Power to the Machine.
2. Remove Tower Cover SH62Q and Base Cover SH59A (Used with Airpot Dispenser).
3. Make electrical connection to Warmer Deck SH73Q (2 pin plug and socket).
4. Drain Water Tank, Remove drain plug M391A from hot water hose, then connect hose to hot
water faucet. Install hose clamp P217A.
5. Install Tower Cover SJ73Q and Warmer Deck SH73Q (Used with CAR-1 CARRIER
Dispenser).

TO CONVERT TO AIRPOT DISPENSER:
1. Disconnect Electrical Power to the Machine.
2. Remove Tower Cover SJ73Q and Warmer Deck SH73Q (Used with Carrier Dispenser).
3. Disconnect electrical connection to Warmer Deck (3 pin plug and socket), Insulate with cap
plug B155A and tape connector back into the main harness.
4. Drain Water Tank, Disconnect hot water hose from hot water faucet and plug the end of the
hose with drain plug M391A.
5. Install Tower Cover SH62Q and Base Cover SH59A (Used with Airpot Dispenser).
FOR MODELS ORIGINALLY EQUIPPED
WITH CAR-1 CARRIER DISPENSER

RETROFITCARRIER KIT# SK66Q
FOR JAVA 2-QB SHIPPED PRIOR TO APRIL 2002
